# Overbridge 2.0.19.2 Beta This package contains: - VST plugin, AU plugin, and standalone editor for -

Analog Four Analog Keys Analog Heat Analog Rytm Digitakt Digitone

- Overbridge Engine and Control . - USB Audio drivers for Elektron Overbridge-compatible hardware. ## Functionality Each Elektron Overbridge device typically exposes all individual track/voice channels as separate USB Audio channels, for multi-track recording into DAWs. Some Elektron Overbridge devices such as the Analog Rytm and Analog Four also allow you to route audio from a computer host into individual track audio paths for intricate processing. The Analog Heat acts entirely as a sound processing unit. The plugin routes audio from your computer host, through the effects chain and back into the host. All Elektron Overbridge devices allow you to play audio from the computer host directly to the device's main output, making the device act as a sound card for playing back music etc. The Overbridge Control application is bundled together with the drivers, providing a simple channel monitor for your devices. ### USB Audio drivers for Windows and macOS The USB Audio Drivers will expose Audio and MIDI-interfaces for Elektron Overbridge devices. On Windows, WDM and ASIO audio interfaces are provided. On macOS, HAL and CoreAudio audio interfaces are provided. ### Standalone Editor for Windows and macOS The Standalone Editor allows for controlling the Overbridge enabled devices parameters via a GUI desktop application and also manage sounds and samples on the device. The Overbridge Engine handles all USB communication between your connected Elektron device and the standalone editor. ### Plugins for Windows (VST) and macOS (VST/AU) The Plugin allows for controlling the Overbridge enabled devices and stream audio via a VST Plugin. This makes it possible to sequence, sync and automate the device with your DAW. Audio will be streamed to the plugin making it possible to use your audio interface of choice in your DAW while still receiving audio from your unit. The Overbridge Engine handles all USB communication between your connected Elektron device and the VST Plugin. ## System Requirements ### Computer Operating System Requirements

Overbridge 2.0 s the following computer operating systems. - Windows 10 or higher running on a 64bit system. - Apple macOS 10.12 or higher running on a 64bit system. ### Computer Hardware Requirements Overbridge 2.0 requires a high performance computer with 64bit architecture. Elektron recommends the below specs as minimum specs. -

At least 8GB or RAM. At least Intel Core i5 U. OpenGL 3.2 capable GPU. Dedicated USB host port for each Overbridge hardware device. USB Hubs are generally not ed, and may cause problems with both connectivity and performance.

### ed Elektron Hardware -

Analog Four mkI/mkII running OS 1.36_BETA2 or higher. Analog Keys running OS 1.36_BETA2 or higher. Analog Rytm mkI/mkII running OS 1.46_BETA1 or higher. Analog Heat mkI/mkII running OS 1.11_BETA3 or higher. Digitakt running OS 1.11_BETA6 or higher. Digitone running OS 1.11_BETA1 or higher.

Note that Overbridge plugins may have more strict requirements regarding OS versions compared to this Overbridge USB Driver package. ## Update Notifications Run the Overbridge Control application regularly to ensure you get automatic notifications about availability of software updates directly from Elektron. Also check the Elektron website regularly for availability of additional Overbridge software components. https://www.elektron.se/ ## Upgrading from previous Overbridge versions If upgrading from Overbridge 1.15 or earlier, note that a complete uninstall of the previous version will be performed first. This means you will loose any previously installed Overbridge plugins and Overbridge drivers if you install the Overbridge 2.0 USB Audio Drivers kit.
