321136831.xls Design of Composite Columns to EC4 Column on Grid D/9 Ground to First Floor Job Description Redditch Job Number 10590 Length of column L = Effective Length = Aplied Axial Load = Max Moment about Major axis Myy = Max Moment about Minor axis Mzz =

7500 7500 7345 492 492

EC4 Clause

mm mm kN kNm kNm

Material Properties Structural Steel

3.3

Nominal Steel Grade = Nominal Yield Strength fy= Modulus of Elasticity Ea=

50 345 N.mm2 205 kN/mm2

Concrete Class Characteristic Strength fck= Secant Modulus of elasticity s.t. Ecm=

40 40 N.mm2 35 kN/mm2

Concrete 3.1 3.1.4.1

Reinforcing steel Type of steel Characteristic strength fsk= Modulus of elasticity Es=

460 N.mm2 205 kN/mm2

3.2.4

Partial Safety Factors gamma a = gamma c fundamental = gamma c for effective elastic flex stiff = gamma s = Design Strengths fyd=fy/gamma a = fcd=alpha c*fck/gamma c = fsd=fsk/gamma s =

1.05 1.5 1.35 1.15

Table 1

328.6 N.mm2 22.7 N.mm2 400.0 N.mm2

Check limits of acceptablility by hand 4.8.3.1(3) Is column Doubly symmetrical Is Concrete cover within limits Is X-sect A of Longit Rebar>0.04Ac Steel contribution factor Delta = 0.54 Section is within contribution limits Steel Section Properties Steel Section 305x305x158U.C. Breadth of section - b = 310.6 mm Depth of Section - h = 327.2 mm Thickness of Web - tw = 13.8 mm Thickness of flange - tf = 21.7 mm X Sect Area - Aa = 20100 mm2 2nd Moment Area about Major Axis Iay 386900000 mm4 2nd Moment Area about Minor Axis Iaz 125000000 mm4 Plastic Modulus - Wpa.y 2675000 mm3

Waterman Group Confidential

06/14/2016

Page 1

321136831.xls Plastic Modulus - Wpa.z

1225000 mm3 EC4 Clause

Reinforcement Diameter of Bars = Number of Bars = Area of Reinforcement As= Spacing of Reinforcement on Major = Spacing of Reinforcement on Minor = Concrete Area and Cover Breadth of concrete Bz= Depth of Concrete By= Area of conrete Ac = Cover Cz = Cover Cy =

20 4 1257 430 430

mm mm2 mm mm

500 mm 500 mm 228643 mm2 94.7 Cover is Ok 86.4 Cover is Ok

As/Ac = 4% of concrete area (mm2) =

0.55% There is adequate reinforcement for model 9146 There is adequate reinforcement for model

Design Checks Plastic Compression Resistance of Composite Cross-section

4.8.3.3

Npl.rd = Aa*fyd+Ac*fcd+As*fsd =

Eq 2

12290 kN

Evaluate the effective elastic flexural stiffnes of the composite cross-section for short term loading About the Major Axis Ea*Iay = Es*Isy = 0.8*Ecd*Icy =

79314500000 kNmm2 1.1908E+10 kNmm2 98795309618 kNmm2

Effective flexural Stiffness (EI)ey = or About the Minor Axis Ea*Iaz = Es*Isz = 0.8*Ecd*Icz =

1.9002E+11 kNmm2 1.9002E+05 kNm2

2.5625E+10 1.1908E+10 1.0423E+011

Effective flexural Stiffness (EI)ez = or

1.4176E+11 kNmm2 1.4176E+05 kNm2

Evaluate the Non-Dimensional Slenderness Lambda Npl.r =Aa*fy+Ac*0.85*fck+As*fsk=

15286 kN

Ncry = pi^2 * (EIey/l^2) =

33340 kN

Therefore Lambda y =

0.677

Ncrz = pi^2 * (EIez/l^2) =

24873 kN

Waterman Group Confidential

4.8.3.5(1)

06/14/2016

4.8.3.7

Page 2

321136831.xls

Therefore Lambda z =

0.784 EC4 Clause

Check resistance under Axial Compression Major Axis Phi = Reduction Factor X = Major Axis Compression Resistance = Major axis has sufficient axial capacity Minor Axis Phi = Reduction Factor X = Minor Axis Compression Resistance = Minor axis has sufficient axial capacity

0.810 0.796

4.8.3.8

9788 kN

4.8.3.8

0.950 0.672

4.8.3.8

8261 kN

4.8.3.8

Check for Second Order Effects check for second order effects needed

Waterman Group Confidential

4.8.3.10 0.30
