Engine ECU Faults (MID 128) Fault Code
Description
FMI Codes
MID 128 PID 26
Engine Fan Speed Percent
3,8
MID 128 PID 27
EGR Valve #1 Position Sensor
3,4,5
MID 128 PID 45
Preheater Relay Status
3,4,5
MID 128 PID 81
Particulate Filter
0,2,3,5,12
MID 128 PID 84
Vehicle Speed
9
MID 128 PID 85
Cruise Control Status
9
MID 128 PID 91
Accelerator Pedal Position
9
MID 128 PID 94
Fuel Supply Pressure
1,3,5,7
MID 128 PID 97
Water in Fuel Indicator
3,4
MID 128 PID 98
Engine Oil Level
1,4,5
MID 128 PID 100 Engine Oil Pressure
1,3,5
MID 128 PID 102 Intake manifold pressure
0,1,2,3,5,11
MID 128 PID 103 Turbo Shaft Speed
0,1,9
MID 128 PID 105 Intake manifold temperature
0,1,2,4,5,10
MID 128 PID 108 Atmospheric pressure
2,3,4,5
MID 128 PID 110 Engine coolant temperature
0,2,4,5,10
MID 128 PID 111 Engine coolant level
1,3,4,5
MID 128 PID 153 Crankcase pressure
0,1,2, 3, 5
MID 128 PID 158 Battery voltage
3, 4
MID 128 PID 171 Ambient Temperature
9
MID 128 PID 173 Exhaust Temperature
0,2,4,5,10
MID 128 PID 175 Engine Oil Temperature
0,2,4,5
MID 128 PID 228 Road speed sensor calibration
11
MID 128 PID 354 Relative Humidity
3,5
MID 128 PID 362 EGR Valve #2 position sensor
3, 5
MID 128 PID 411 EGR Exhaust Back Pressure
2,3,5
MID 128 PID 412 EGR Temperature
0, 4, 5,10
MID 128 PPID 35 EGR Mass Flow Sensor
0,1
MID 128 PPID 86 Engine Brake Torque Percent
9
MID 128 PPID 89 Variable Geometry Turbo Temperature
0
MID 128 PPID 119 High Coolant Temperature
0
MID 128 PPID 122 VCB Compression Brake Status
1, 3, 4, 5
MID 128 PPID 124 EPG Valve (Exhaust Gas Pressure)
1, 3, 4, 5
MID 128 PPID 270 Nox Sensor
2,3,5,9,10,12,13,14
MID 128 PPID 272 Air Pressure Compensation
4,5
MID 128 PPID 326 Soot Level (DPF System)
0,11
MID 128 PPID 328 Aftertreatment Injection Shutoff Valve
3,4,5,7,14
MID 128 PPID 329 Aftertreatment Fuel Injector
3,4,5,7,14
MID 128 PPID 330 Discharge Reciculator Valve (BOV)
3,4,5,7
MID 128 PPID 337 Ash Level (DPF)
0,14
MID 128 PPID 387 Temperature Sensor, Catalytic Converter
2,4,5,10
MID 128 PPID 436 Exhaust Gas Temperature Sensor #3
2,4,5,10
MID 128 PPID 437 Aftertreatment Injector Fuel Pressure Sensor 2,3,5,10 MID 128 PSID 47 Particulate Trap Regeneration (DPF)
0,1,8,12
MID 128 PSID 98 Boost Air Pressure System
0,1
MID 128 PSID 108 Aftertreatment Injector System (ATI)
7
MID 128 PSID 109 Engine Coolant Temperature Sensor
7,12
MID 128 SID 1
Electronic Unit Injectors #1
3, 5, 7, 12
MID 128 SID 2
Electronic Unit Injectors #2
3, 5, 7, 12
MID 128 SID 3
Electronic Unit Injectors #3
3, 5, 7, 12
MID 128 SID 4
Electronic Unit Injectors #4
3, 5, 7, 12
MID 128 SID 5
Electronic Unit Injectors #5
3, 5, 7, 12
MID 128 SID 6
Electronic Unit Injectors #6
3, 5, 7, 12
MID 128 SID 18
Drain Valve, Water Separator
3,4,5
MID 128 SID 21
Engine position, camshaft sensor
3, 8
MID 128 SID 22
Engine speed, flywheel sensor
2, 3, 8
MID 128 SID 27
Variable Geometry Turbo (VGT)
2,4,7,9,13
MID 128 SID 33
Fan control
3, 4, 5
MID 128 SID 70
Preheater element 1
3, 4, 5
MID 128 SID 71
Preheater element 2
3, 4, 5
MID 128 SID 78
Fuel priming pump
4, 5
MID 128 SID 146 EGR Valve #1 motor
3, 5, 6, 7, 12, 13
MID 128 SID 211 5 Volt DC supply (EB connector)
3, 4
MID 128 SID 230 Idle validation switch
3, 4
MID 128 SID 231 SAE J1939 Control link
2
MID 128 SID 232 5 Volt DC supply (EA connector) 3
3, 4
MID 128 SID 240 Program memory
2
MID 128 SID 253 Data set memory EEPROM
2, 12, 13
MID 128 SID 254 Engine electronic control unit (EECU)
3, 8, 12
MID 128 SID 266 EGR Valve #2 motor
3, 5, 6, 7, 12, 13
MID 128 SID 281 EGR reed valve diagnose
7
MID 128 SID 282 EGR cooler efficiency
7
MID 128 PSID 201 SAE J1939 Data Link Interruption
9
Create your FREE Sign up and get started today. FMI Description / Diagnosis Information FMI Codes Display Name
Description
0
Too high value
Data valid, but above normal work range
1
Too low value
Data valid, but below normal work range
2
Incorrect data
Data erratic, intermittent, or incorrect
3
Electrical fault
Voltage above normal or shorted high
4
Electrical fault
Voltage below normal or shorted low
5
Electrical fault
Current below normal or open circuit
6
Electrical fault
Current above normal or grounded circuit
7
Mechanical fault
Mechanical system not responding properly
8
Mech. or electrical fault Abnormal frequency, pulse width, or period
9
Communication fault
10
Mech. or electrical fault Abnormal rate of change
11
Unknown fault
Failure mode not identifiable
12
Component fault
Bad intelligent device or component
13
Incorrect calibration
Out of calibration
14
Unknown fault
Special instructions
15
Unknown fault
Special instructions
Abnormal update rate
Engine Injector Faults (MID 128 SID 1 – SID 6) FMI Injector Codes Description 3
Short circuit to battery voltage, unit injector low side.
5
Open circuit in actuator circuit.
7
Mechanical system does not respond correctly.
12
Resistance too high in injector.
Transmission ECU Faults (MID 130) Fault Code
Description
FMI Codes
MID 130 PID 31
Range Cylinder, Position
3,5,6,13
MID 130 PID 32
Split Cylinder, Position
3,5,6,13
MID 130 PID 33
Clutch Cylinder, Position
2,3,5,12,13
MID 130 PID 36
Clutch Wear Status
0
MID 130 PID 37
Air Pressure, Transmission
0,1,3,5
MID 130 PID 65
Brake Switch
14
MID 130 PID 158 Control Module, Battery Voltage
0,1
MID 130 PID 160 Main Shaft, Rotation Speed
1,2,3,4,5
MID 130 PID 161 Input Shaft, Rotation Speed
1,4,5
MID 130 PID 177 Oil Temperature, Transmission
0,4,5
MID 130 PPID 10 Gear Selector Cylinder 1, Position
3,5,6,13
MID 130 PPID 11 Gear Selector Cylinder 2, Position
3,5,6,13
MID 130 PPID 50 Clutch, Pre-load
0,11,14
MID 130 PPID 51 Clutch Disc, Pull Position
13
MID 130 PPID 54 ECM 5V Output
0,1
MID 130 PPID 55 ECM Temperature
0
MID 130 PPID 140 Inclination Angle
2
MID 130 PSID 1
PWM Valve, Quick Engagement
3,5,6
MID 130 PSID 2
PWM Valve, Slow Engagement
3,5,6
MID 130 PSID 3
PWM Valve, Quick Disconnection
3,5,6
MID 130 PSID 4
PWM Valve, Slow Disconnection
3,5,6
MID 130 PSID 5
Ground, Quick PWM Valves
3,6
MID 130 PSID 6
Ground. Slow PWM Valves
3,6
MID 130 PSID 12 Solenoid Valve, Gear Cylinder 1, Inner
3,5,6
MID 130 PSID 13 Solenoid Valve, Gear Cylinder 1, Outer
3,5,6
MID 130 PSID 14 Solenoid Valve, Gear Cylinder 2, Inner
3,5,6
MID 130 PSID 15 Solenoid Valve, Gear Cylinder 2, Outer
3,5,6
MID 130 PSID 20 Solenoid Valve. Power Take-Off 1
3,5,6
MID 130 PSID 21 Solenoid Valve. Power Take-Off 2
3,5,6
MID 130 PSID 22 Solenoid Valve. Brake, Counter Shaft
3,5,6
MID 130 PSID 23 Split Engagement System
0,1,2,7,11,12
MID 130 PSID 24 Range Engagement System
0,1,11,12
MID 130 PSID 25 Gears 1/R Engagement System
0,1,2,7,11,12
MID 130 PSID 26 Gears 2/3 Engagement System
0,1,2,7,11,12
MID 130 PSID 27 Clutch System
0,1,7,8,11,12,14
MID 130 PSID 28 Transmission Brake
7
MID 130 PSID 200 Data Link Error J1939, Engine ECU
9
MID 130 PSID 201 Data Link Error J1939, Vehicle ECU
8,9
MID 130 PSID 204 Data Link Error J1939, Brake ECU
8,9
MID 130 PSID 207 Data Link Error J1939, Gear Selector ECU 9 MID 130 PSID 210 Data Link Error J1939, Lighting ECU
9
MID 130 PSID 211 Data Link Error J1939, Cruise Control ECU 9 MID 130 PSID 232 Powertrain CAN (2, J1939)
2,9
MID 130 PSID 254 DIEE Signal
3
MID 130 SID 35
Solenoid Valve, High Range
3,5,6
MID 130 SID 36
Solenoid Valve, Low Range
3,5,6
MID 130 SID 37
Solenoid Valve, High Split
3,5,6
MID 130 SID 38
Solenoid Valve, High Split
3,5,6
MID 130 SID 231 SAE J1939 Data Link
2
MID 130 SID 240 Program Memory
2
MID 130 SID 250 SAE J1587 Datalink
9
MID 130 SID 253 Calibration Memory EEPROM
13
ABS / Brake ECU Faults (MID 136) Fault Code
Description
FMI Faults (ABS)
MID 136 SID 1
ABS Wheel Speed Sensor, Steer Axle (L) 1 Data valid, but high = 0
MID 136 SID 2
ABS Wheel Speed Sensor, Steer Axle (R) 1 Date valid, but low = 1
MID 136 SID 3
ABS Wheel Speed Sensor, Drive Front (L) 2 Data erratic = 2
MID 136 SID 4
ABS Wheel Speed Sensor, Drive Front (R) 2 Voltage shorted high = 3
MID 136 SID 5
ABS Wheel Speed Sensor, Drive Rear (L) 3 Voltage shorted low = 4
MID 136 SID 6
ABS Wheel Speed Sensor, Drive Rear (R) 3 Current low or open C = 5
MID 136 SID 7
ABS Valve Actuator, Steer Axle (L) 1
Current high or short C = 6
MID 136 SID 8
ABS Valve Actuator, Steer Axle (R) 1
Mech system no response = 7
MID 136 SID 9
ABS Valve Actuator, Drive Front (L) 2
Abnormal freq or PW = 8
MID 136 SID 10 ABS Valve Actuator, Drive Front (R) 2
Abnormal update rate = 9
MID 136 SID 11 ABS Valve Actuator, Drive Rear (L) 3
Abnormal change rate = 10
MID 136 SID 12 ABS Valve Actuator, Drive Rear (R) 3
Failure unknown = 11
MID 136 SID 13 ABS Retarder Control Relay
Bad device = 12
MID 136 SID 14 ABS Relay, Diagonal 1
Out of calibration = 13
MID 136 SID 15 ABS Relay Diagonal 2
Special instructions = 14
MID 136 SID 18 ABS Diff 1 – ASR Valve MID 136 SID 19 ABS Diff 2 – ASR Valve MID 136 SID 22 Wheel Speed Sensor Reversed MID 136 SID 23 ABS Warning Lamp Circuit MID 136 SID 42 Pressure Modulator Valve, Left MID 136 SID 43 Pressure Modulator Valve, Right MID 136 SID 44 Pressure Modulator Valve, Left MID 136 SID 45 Pressure Modulator Valve, Right MID 136 SID 46 Pressure Modulator Valve, Left MID 136 SID 47 Pressure Modulator Valve, Right MID 136 SID 48 Pressure Modulator Valve, Left MID 136 SID 49 Pressure Modulator Valve, Right MID 136 SID 50 Pressure Modulator Valve, Left MID 136 SID 51 Pressure Modulator Valve, Right MID 136 SID 52 Pressure Modulator Valve, Left MID 136 SID 53 Pressure Modulator Valve, Right MID 136 SID 55 Stop Lamp Switch Defective
MID 136 SID 79 Tire Size Out of Range (Front to Rear) MID 136 SID 93 PMV/TCV/Diff Lock Short MID 136 SID 102 Diff Lock Solenoid MID 136 SID 154 I/O 2, I/O3 Shorted High MID 136 SID 231 J1939 Not Communicating MID 136 SID 251 Battery Voltage, Power Supply MID 136 SID 254 ECU Not Communicating Instrument Cluster Faults (MID 140) Fault Code
Description
FMI Codes
MID 140 PID 77
Forward rear axle temperature
3, 4
MID 140 PID 78
Rear rear axle temperature
3, 4
MID 140 PID 96
Fuel level
3, 4
MID 140 PID 116
Application air pressure
5, 6
MID 140 PID 117
Air brake pressure, front
5, 6
MID 140 PID 118
Air brake pressure, rear
5, 6
MID 140 PID 158
Battery voltage
0
MID 140 PID 171
Ambient temperature
3, 4
MID 140 PID 177
Transmission oil temperature
3, 4
MID 140 PID 178
Air suspension pressure, front
5, 6
MID 140 PID 179
Air suspension pressure, rear
5, 6
MID 140 SID 231
SAE J1939 Data Link
2
MID 140 SID 240
Program memory
2
MID 140 SID 250
SAE J1587/J1708 data link
3, 4, 9, 12
MID 140 SID 253
Calibration memory, EEPROM
2
MID 140 PSID 7
Internal reference resistance
3, 4
MID 140 PSID 200
Open-circuit, J1939 data link, engine
9
MID 140 PSID 201
Open-circuit, J1939 data link, vehicle control unit
9
MID 140 PSID 204
Open-circuit, J1939 data link, anti-lock brake control 9 unit
MID 140 PSID 210
Open-circuit J1939 data link, Lighting control module 9
MID 140 PSID 232
SAE J1939-3 data link
2
Create your FREE Sign up and get started today. Volvo Link System Faults (MID 142) Fault Code
Description
FMI
MID 142 PID 155
Input 1-4
12: Bad component
MID 142 SID 240
Memory Flash/RAM
12: Bad component, 2: Main software corrupt
MID 142 SID 250
J1708/1587 Data Link
9: No data received from J1587/1708 data link
MID 142 SID 253
Memory ROM
2: Dataset corrupt
MID 142 PSID 003
Sending Message Failure
11: Unknown failure, 12: Bad component
MID 142 PSID 004
GPS module/interface
2: Bad GPS antenna 9: No data r eceived 1: Bad ECU
MID 142 PSID 005
DSP module/interface
12: Bad device or antenna
MID 142 PSID 006
ORBCOMM Satellite module/interface
2: Bad antenna 12: Bad ECU
MID 142 PSID 008
J1708/1587 Road Speed
2: Mismatch
MID 142 PSID 161
J1708/1587 VIN Missing
9: No data received
MID 142 PSID 162
VIN Mismatch
2: Internal dataset mismatch with VIN J1587 data link
Vehicle ECU Faults (MID 144)
Fault Code
Description
FMI
MID 144 PID 46
Primary Tank Pressure
1,3,4
MID 144 PID 83
Road Speed Limit Status
14
MID 144 PID 84
Vehicle Speed
2,14
MID 144 PID 86
Cruise Control, Set Speed
14
MID 144 PID 91
Accelerator Pedal Position (Percentage)
3,4,5,6,14
MID 144 PID 152 Vehicle ECU, Number of Resets
12
MID 144 PID 191 Output Shaft Speed
5,6
MID 144 PPID 3
4
Starter Relay Output
MID 144 PPID 60 Idle Switch, Power
4
MID 144 PPID 61 Engine Brake Switch
7
MID 144 PPID 69 Buffered Idle Validation Switch
3,4
MID 144 PPID 70 Pedal Switches, Supply Power
4
MID 144 PPID 71 Cruise Control and Engine Brake, Switch Supply
4
MID 144 PPID 72 Cruise Control and Engine Brake, Sensor Supply
3,4
MID 144 PPID 73 Second Accelerator Pedal, Supply Sensor
3,4
MID 144 PPID 74 Vehicle ECU, Power Supply
4
MID 144 PPID 265 Vehicle Speed Sensor Supply
3,4
MID 144 PPID 279 Air Dryer, Dry Agent Reservoir
0
MID 144 PPID 312 Air Dryer, Regeneration
0,7
MID 144 PPID 430 Air Dryer, Regeneration
0
MID 144 SID 230 Idle Validation Switch 1 (IVS Issue)
7
MID 144 SID 231 SAE J1939 Data Link
2
MID 144 SID 240 Program Memory
2
MID 144 SID 243 Cruise Control Set Switch
7
MID 144 SID 250 SAE J1587 Data Link
2
MID 144 SID 253 Calibration Memory EEPROM
2,14
MID 144 PSID 1
Retarder Control Set Switch
7
MID 144 PSID 2
Idle Validation Switch 2 (IVS Issue)
7
MID 144 PSID 4
Engine Brake Stalk Lever
3,4
MID 144 PSID 8
Neutral Position Error
3,4
MID 144 PSID 16 Power Relay 1 (EMS Power Relay)
3,4
MID 144 PSID 20 Power Take Off Signal
3,4
MID 144 PSID 23 Air Dryer, Regenerating
3,4
MID 144 PSID 24 Compressor, Control
3,4
MID 144 PSID 25 Air Leakage
14
MID 144 PSID 200 Communication Error, J1939 Data Link, Engine ECU
9
MID 144 PSID 202 Communication Error, J1939 Data Link, Cluster Module
9
MID 144 PSID 204 Communication Error, J1939 Data Link, Brake ECU
9
MID 144 PSID 205 Communication Error, J1939 Data Link, Transmission
9
MID 144 PSID 206 Communication Error, J1939 Data Link, Retarder Control
9
MID 144 PSID 207 Communication Error, J1939 Data Link, Gear Selector
9
MID 144 PSID 208 Communication Error, J1939 Data Link, Air Suspension
9
MID 144 PSID 210 Communication Error, J1939 Data Link, Light Control Module 9 MID 144 PSID 211 Communication Error, J1939 Data Link, Collision Avoidance 9 MID 144 PSID 214 Communication Error, J1939 Data Link, Bodybuilder Control 9 MID 144 PSID 230 Software Fault (VICE)
4,5,12
Climate Control Faults (MID 146) Fault code
Description
FMI
MID 146 SID 2
Temperature sensor, evaporator
3. 4
MID 146 SID 5
Stepper Motor, Fresh Air and Recirculation
4
MID 146 SID 6
Stepper motor, air distribution
4
MID 146 SID 9
Stepper motor, air mixture, heat control
4
MID 146 SID 11 Magnetic clutch, A/C compressor
4
MID 146 SID 12 Solenoid valve, water control
3
MID 146 SID 13 Temperature sensor, heat exchanger
3. 4
MID 146 SID 14 Circulation fan, temperature sensor, cab
4
MID 146 SID 15 Fan connection, engine
3
MID 146 SID 16 Stepper motor, phase 1
3
MID 146 SID 17 Stepper motor, phase 2
3
MID 146 SID 18 Stepper motor, phase 3
3
MID 146 SID 19 Stepper motor, phase 4
3
MID 146 SID 22 Pressure sensor, refrigerant, high pressure side 3. 4 MID 146 SID 232 5 volts supply to the sensor
4
MID 146 SID 250 SAE J1708 data link
9
MID 146 PID 170 Cab, temperature sensor
3,4
MID 146 PID 171 Temperature sensor, outer temperature
3,5
Light Control Module Faults (MID 216) Fault Code
Description
FMI Codes
MID 216 PSID 42 Rheostat, instrument lighting
3, 4
MID 216 PSID 44 Central locking alarm (short to ground)
12
MID 216 PSID 45 Side repeater, right
5, 6
MID 216 PSID 46 Side repeater, left
5, 6
MID 216 PSID 48 Park and license plate lights, tractor rear
5, 6
MID 216 PSID 49 Tractor roof marker/clearance lamps
5, 6
MID 216 PSID 50 Tractor front park lights
5, 6
MID 216 PSID 51 Trailer park lights
3, 4
MID 216 PSID 52 Allison retarder indicator LED
4
MID 216 PSID 53 Marker (ICC) trailer
6
MID 216 PSID 54 Marker interrupt
12
MID 216 PSID 55 Headlamp interrupt
12
MID 216 PSID 57 Back of cab lights
5, 6
MID 216 PSID 77 Back of cab switch (short to ground)
12
MID 216 PSID 200 SAE J1939 Open-circuit, data link, engine control unit 9 MID 216 PSID 201 SAE J1939 Open-circuit, data link, vehicle control unit 9 MID 216 PSID 202 DID
9
MID 216 PSID 205 Transmission
9
MID 216 PSID 214 Body Builder Module
9
MID 216 PSID 2
2
No VIN response
Create your FREE Sign up and get started today. Gear Selector Module Faults (MID 223) Fault Code
Description
FMI Codes
MID 223 PSID 9
Gear Selector, Position
12
MID 223 PSID 36 Relay Power Supply
7,12
MID 223 PSID 42 Signals, Key
2
MID 223 PSID 200 Open Circuit, J1939 data link, Engine
9
MID 223 PSID 201 Open Circuit, J1939 data link, Vehicle Control Unit
9
MID 223 PSID 205 Open Circuit, J1939 data link, Transmission control unit 9 MID 223 PSID 214 No Data From BBM
9
MID 223 SID 240 Program Memory
2
MID 223 SID 250 SAE J1587 Data Link
9
MID 223 SID 253 Calibration Memory EEPROM
2
MID 223 SID 254 Hardware Fault
12
Bodybuilder System Faults (MID 249) Fault code
Description
FMI
MID 249 PID 29
Extra Throttle Control, Percent Position
3,4
MID 249 SID 230 Idle Switch
7
MID 249 SID 231 SAE J1939 Data Link
2
MID 249 SID 253 Calibration Memory, EEPROM
2
MID 249 PSID 200 SAE J1939 Open Circuit, Data Link, Engine ECU
9
MID 249 PSID 201 SAE J1939 Open Circuit, Data Link, Vehicle ECU
9
MID 249 PSID 202 SAE J1939 Open Circuit, Data Link, Instrument Cluster
9
MID 249 PSID 205 SAE J1939 Open Circuit, Data Link, Automatic Transmission 9 Steering Wheel Module Faults (MID 250) Fault code
Description
FMI
MID 250 SID 231 SAE J1939 control link
2
MID 250 SID 251 Power supply, control unit steering functions ( SWM) 3, 4 MID 250 SID 254 Control unit steering wheel module (SWM)
12
MID 250 PSID 3 Arrow left
12
MID 250 PSID 4 Arrow right
12
Engine ECU Faults (MID 128) Fault Code
Description
FMI
MID 128 PID 26
Engine Fan Speed Percent
3,8
MID 128 PID 27
EGR Valve #1 Position Sensor
3,4,5
MID 128 PID 45
Preheater Relay Status
3,4,5
MID128 PID 81
Particulate Filter
0,2,3,5,12
MID 128 PID 84
Vehicle Speed
9
MID 128 PID 85
Cruise Control Status
9
MID 128 PID 91
Accelerator Pedal Position
9
MID 128 PID 94
Fuel Supply Pressure
1,3,5,7
MID 128 PID 97
Water in Fuel Indicator
3,4
MID 128 PID 98
Engine Oil Level
1,4,5
MID 128 PID 100 Engine Oil Pressure
1,3,5
MID 128 PID 102 Intake manifold pressure
0,1,2,3,5,11
MID 128 PID 103 Turbo Shaft Speed
0,1,9
MID 128 PID 105 Intake manifold temperature
0,1,2,4,5,10
MID 128 PID 108 Atmospheric pressure
2,3,4,5
MID 128 PID 110 Engine coolant temperature
0,2,4,5,10
MID 128 PID 111 Engine coolant level
1,3,4,5
MID 128 PID 153 Crankcase pressure
0,1,2, 3, 5
MID 128 PID 158 Battery voltage
3, 4
MID 128 PID 171 Ambient Temperature
9
MID 128 PID 173 Exhaust Temperature
0,2,4,5,10
MID 128 PID 175 Engine Oil Temperature
0,2,4,5
MID 128 PID 228 Road speed sensor calibration
11
MID 128 PID 354 Relative Humidity
3,5
MID 128 PID 362 EGR Valve #2 position sensor
3, 5
MID 128 PID 411 EGR Exhaust Back Pressure
2,3,5
MID 128 PID 412 EGR Temperature
0, 4, 5,10
MID 128 PPID 35 EGR Mass Flow Sensor
0,1
MID 128 PPID 86 Engine Brake Torque Percent
9
MID 128 PPID 89 Variable Geometry Turbo Temperature
0
MID 128 PPID 119 High Coolant Temperature
0
MID 128 PPID 122 VCB Compression Brake Status
1, 3, 4, 5
MID 128 PPID 124 EPG Valve (Exhaust Gas Pressure)
1, 3, 4, 5 2,3,5,9,10,
MID 128 PPID 270 Nox Sensor 12,13,14 MID 128 PPID 272 Air Pressure Compensation
4,5
MID 128 PPID 326 Soot Level (DPF System)
0,11
MID 128 PPID 328 Aftertreatment Injection Shutoff Valve
3,4,5,7,14
MID 128 PPID 329 Aftertreatment Fuel Injector
3,4,5,7,14
MID 128 PPID 330 Discharge Reciculator Valve (BOV)
3,4,5,7
MID 128 PPID 337 Ash Level (DPF)
0,14
MID 128 PPID 387 Temperature Sensor, Catalytic Converter
2,4,5,10
MID 128 PPID 436 Exhaust Gas Temperature Sensor #3
2,4,5,10
MID 128 PPID 437 Aftertreatment Injector Fuel Pressure Sensor 2,3,5,10 MID 128 PSID 47 Particulate Trap Regeneration (DPF)
0,1,8,12
MID 128 PSID 98 Boost Air Pressure System
0,1
MID 128 PSID 108 Aftertreatment Injector System (ATI)
7
MID 128 PSID 109 Engine Coolant Temperature Sensor
7,12
MID 128 SID 1
Electronic Unit Injectors #1
3, 5, 7, 12
MID 128 SID 2
Electronic Unit Injectors #2
3, 5, 7, 12
MID 128 SID 3
Electronic Unit Injectors #3
3, 5, 7, 12
MID 128 SID 4
Electronic Unit Injectors #4
3, 5, 7, 12
MID 128 SID 5
Electronic Unit Injectors #5
3, 5, 7, 12
MID 128 SID 6
Electronic Unit Injectors #6
3, 5, 7, 12
MID 128 SID 18
Drain Valve, Water Separator
3,4,5
MID 128 SID 21
Engine position, camshaft sensor
3, 8
MID 128 SID 22
Engine speed, flywheel sensor
2, 3, 8
MID 128 SID 27
Variable Geometry Turbo (VGT)
2,4,7,9,13
MID 128 SID 33
Fan control
3, 4, 5
MID 128 SID 70
Preheater element 1
3, 4, 5
MID 128 SID 71
Preheater element 2
3, 4, 5
MID 128 SID 78
Fuel priming pump
4, 5
MID 128 SID 146 EGR Valve #1 motor
3, 5, 6, 7, 12, 13
MID 128 SID 211 5 Volt DC supply (EB connector)
3, 4
MID 128 SID 230 Idle validation switch
3, 4
MID 128 SID 231 SAE J1939 Control link
2
MID 128 SID 232 5 Volt DC supply (EA connector) 3
3, 4
MID 128 SID 240 Program memory
2
MID 128 SID 253 Data set memory EEPROM
2, 12, 13
MID 128 SID 254 Engine electronic control unit (EECU)
3, 8, 12
MID 128 SID 266 EGR Valve #2 motor
3, 5, 6, 7, 12, 13
MID 128 SID 281 EGR reed valve diagnose
7
MID 128 SID 282 EGR cooler efficiency
7
MID 128 PSID 201 SAE J1939 Data Link Interruption
9
FMI Description / Diagnosis Information FMI Codes Display Name
Description
0
Too high value
Data valid, but above normal work range
1
Too low value
Data valid, but below normal work range
2
Incorrect data
Data erratic, intermittent, or incorrect
3
Electrical fault
Voltage above normal or shorted high
4
Electrical fault
Voltage below normal or shorted low
5
Electrical fault
Current below normal or open circuit
6
Electrical fault
Current above normal or grounded circuit
7
Mechanical fault
Mechanical system not responding properly
8
Mech. or electrical fault Abnormal frequency, pulse width, or period
9
Communication fault
10
Mech. or electrical fault Abnormal rate of change
11
Unknown fault
Failure mode not identifiable
12
Component fault
Bad intelligent device or component
13
Incorrect calibration
Out of calibration
14
Unknown fault
Special instructions
15
Unknown fault
Special instructions
Abnormal update rate
Engine Injector Faults (MID 128 SID 1 – SID 6)
FMI Injector Codes Description 3
Short circuit to battery voltage, unit injector low side.
5
Open circuit in actuator circuit.
7
Mechanical system does not respond correctly.
12
Resistance too high in injector.
Transmission ECU Faults (MID 130) Fault Code
Description
FMI
MID 130 PID 31
Range Cylinder, Position
3,5,6,13
MID 130 PID 32
Split Cylinder, Position
3,5,6,13
MID 130 PID 33
Clutch Cylinder, Position
2,3,5,12,13
MID 130 PID 36
Clutch Wear Status
0
MID 130 PID 37
Air Pressure, Transmission
0,1,3,5
MID 130 PID 65
Brake Switch
14
MID 130 PID 158 Control Module, Battery Voltage
0,1
MID 130 PID 160 Main Shaft, Rotation Speed
1,2,3,4,5
MID 130 PID 161 Input Shaft, Rotation Speed
1,4,5
MID 130 PID 177 Oil Temperature, Transmission
0,4,5
MID 130 PPID 10 Gear Selector Cylinder 1, Position
3,5,6,13
MID 130 PPID 11 Gear Selector Cylinder 2, Position
3,5,6,13
MID 130 PPID 50 Clutch, Pre-load
0,11,14
MID 130 PPID 51 Clutch Disc, Pull Position
13
MID 130 PPID 54 ECM 5V Output
0,1
MID 130 PPID 55 ECM Temperature
0
MID 130 PPID 140 Inclination Angle
2
MID 130 PSID 1
PWM Valve, Quick Engagement
3,5,6
MID 130 PSID 2
PWM Valve, Slow Engagement
3,5,6
MID 130 PSID 3
PWM Valve, Quick Disconnection
3,5,6
MID 130 PSID 4
PWM Valve, Slow Disconnection
3,5,6
MID 130 PSID 5
Ground, Quick PWM Valves
3,6
MID 130 PSID 6
Ground. Slow PWM Valves
3,6
MID 130 PSID 12 Solenoid Valve, Gear Cylinder 1, Inner
3,5,6
MID 130 PSID 13 Solenoid Valve, Gear Cylinder 1, Outer
3,5,6
MID 130 PSID 14 Solenoid Valve, Gear Cylinder 2, Inner
3,5,6
MID 130 PSID 15 Solenoid Valve, Gear Cylinder 2, Outer
3,5,6
MID 130 PSID 20 Solenoid Valve. Power Take-Off 1
3,5,6
MID 130 PSID 21 Solenoid Valve. Power Take-Off 2
3,5,6
MID 130 PSID 22 Solenoid Valve. Brake, Counter Shaft
3,5,6
MID 130 PSID 23 Split Engagement System
0,1,2,7,11,12
MID 130 PSID 24 Range Engagement System
0,1,11,12
MID 130 PSID 25 Gears 1/R Engagement System
0,1,2,7,11,12
MID 130 PSID 26 Gears 2/3 Engagement System
0,1,2,7,11,12
MID 130 PSID 27 Clutch System
0,1,7,8,11,12,14
MID 130 PSID 28 Transmission Brake
7
MID 130 PSID 200 Data Link Error J1939, Engine ECU
9
MID 130 PSID 201 Data Link Error J1939, Vehicle ECU
8,9
MID 130 PSID 204 Data Link Error J1939, Brake ECU
8,9
MID 130 PSID 207 Data Link Error J1939, Gear Selector ECU 9 MID 130 PSID 210 Data Link Error J1939, Lighting ECU
9
MID 130 PSID 211 Data Link Error J1939, Cruise Control ECU 9 MID 130 PSID 232 Powertrain CAN (2, J1939)
2,9
MID 130 PSID 254 DIEE Signal
3
MID 130 SID 35
Solenoid Valve, High Range
3,5,6
MID 130 SID 36
Solenoid Valve, Low Range
3,5,6
MID 130 SID 37
Solenoid Valve, High Split
3,5,6
MID 130 SID 38
Solenoid Valve, High Split
3,5,6
MID 130 SID 231 SAE J1939 Data Link
2
MID 130 SID 240 Program Memory
2
MID 130 SID 250 SAE J1587 Datalink
9
MID 130 SID 253 Calibration Memory EEPROM
13
ABS / Brake ECU Faults (MID 136) Fault Code
Description
FMI Faults (ABS)
MID 136 SID 1
ABS Wheel Speed Sensor, Steer Axle (L) 1 Data valid, but high = 0
MID 136 SID 2
ABS Wheel Speed Sensor, Steer Axle (R) 1 Date valid, but low = 1
MID 136 SID 3
ABS Wheel Speed Sensor, Drive Front (L) 2 Data erratic = 2
MID 136 SID 4
ABS Wheel Speed Sensor, Drive Front (R) 2 Voltage shorted high = 3
MID 136 SID 5
ABS Wheel Speed Sensor, Drive Rear (L) 3 Voltage shorted low = 4
MID 136 SID 6
ABS Wheel Speed Sensor, Drive Rear (R) 3 Current low or open C = 5
MID 136 SID 7
ABS Valve Actuator, Steer Axle (L) 1
Current high or short C = 6
MID 136 SID 8
ABS Valve Actuator, Steer Axle (R) 1
Mech system no response = 7
MID 136 SID 9
ABS Valve Actuator, Drive Front (L) 2
Abnormal freq or PW = 8
MID 136 SID 10 ABS Valve Actuator, Drive Front (R) 2
Abnormal update rate = 9
MID 136 SID 11 ABS Valve Actuator, Drive Rear (L) 3
Abnormal change rate = 10
MID 136 SID 12 ABS Valve Actuator, Drive Rear (R) 3
Failure unknown = 11
MID 136 SID 13 ABS Retarder Control Relay
Bad device = 12
MID 136 SID 14 ABS Relay, Diagonal 1
Out of calibration = 13
MID 136 SID 15 ABS Relay Diagonal 2
Special instructions = 14
MID 136 SID 18 ABS Diff 1 – ASR Valve MID 136 SID 19 ABS Diff 2 – ASR Valve MID 136 SID 22 Wheel Speed Sensor Reversed MID 136 SID 23 ABS Warning Lamp Circuit MID 136 SID 42 Pressure Modulator Valve, Left
MID 136 SID 43 Pressure Modulator Valve, Right MID 136 SID 44 Pressure Modulator Valve, Left MID 136 SID 45 Pressure Modulator Valve, Right MID 136 SID 46 Pressure Modulator Valve, Left MID 136 SID 47 Pressure Modulator Valve, Right MID 136 SID 48 Pressure Modulator Valve, Left MID 136 SID 49 Pressure Modulator Valve, Right MID 136 SID 50 Pressure Modulator Valve, Left MID 136 SID 51 Pressure Modulator Valve, Right MID 136 SID 52 Pressure Modulator Valve, Left MID 136 SID 53 Pressure Modulator Valve, Right MID 136 SID 55 Stop Lamp Switch Defective MID 136 SID 79 Tire Size Out of Range (Front to Rear) MID 136 SID 93 PMV/TCV/Diff Lock Short MID 136 SID 102 Diff Lock Solenoid MID 136 SID 154 I/O 2, I/O3 Shorted High MID 136 SID 231 J1939 Not Communicating MID 136 SID 251 Battery Voltage, Power Supply MID 136 SID 254 ECU Not Communicating Instrument Cluster Faults (MID 140) Fault Code
Description
FMI
MID 140 PID 77
Forward rear axle temperature
3, 4
MID 140 PID 78
Rear rear axle temperature
3, 4
MID 140 PID 96
Fuel level
3, 4
MID 140 PID 116 Application air pressure
5, 6
MID 140 PID 117 Air brake pressure, front
5, 6
MID 140 PID 118 Air brake pressure, rear
5, 6
MID 140 PID 158 Battery voltage
0
MID 140 PID 171 Ambient temperature
3, 4
MID 140 PID 177 Transmission oil temperature
3, 4
MID 140 PID 178 Air suspension pressure, front
5, 6
MID 140 PID 179 Air suspension pressure, rear
5, 6
MID 140 SID 231 SAE J1939 Data Link
2
MID 140 SID 240 Program memory
2
MID 140 SID 250 SAE J1587/J1708 data link
3, 4, 9, 12
MID 140 SID 253 Calibration memory, EEPROM
2
MID 140 PSID 7
3, 4
Internal reference resistance
MID 140 PSID 200 Open-circuit, J1939 data link, engine
9
MID 140 PSID 201 Open-circuit, J1939 data link, vehicle control unit
9
MID 140 PSID 204 Open-circuit, J1939 data link, anti-lock brake control unit 9 MID 140 PSID 210 Open-circuit J1939 data link, Lighting control module
9
MID 140 PSID 232 SAE J1939-3 data link
2
Create your FREE Sign up and get started today. Volvo Link System Faults (MID 142) Fault Code
Description
FMI
MID 142 PID 155
Input 1-4
12: Bad component
MID 142 SID 240
Memory Flash/RAM
12: Bad component, 2: Main software corrupt
MID 142 SID 250
J1708/1587 Data Link
9: No data received from J1587/1708 data link
MID 142 SID 253
Memory ROM
2: Dataset corrupt
MID 142 PSID Sending Message Failure 003
11: Unknown failure, 12: Bad component
MID 142 PSID 004
GPS module/interface
2: Bad GPS antenna 9: No data r eceived 1: Bad ECU
MID 142 PSID 005
DSP module/interface
12: Bad device or antenna
MID 142 PSID 006
ORBCOMM Satellite module/interface
2: Bad antenna 12: Bad ECU
MID 142 PSID 008
J1708/1587 Road Speed
2: Mismatch
MID 142 PSID 161
J1708/1587 VIN Missing
9: No data received
MID 142 PSID 162
VIN Mismatch
2: Internal dataset mismatch with VIN J1587 data link
Vehicle ECU Faults (MID 144) Fault Code
Description
FMI
MID 144 PID 46
Primary Tank Pressure
1,3,4
MID 144 PID 83
Road Speed Limit Status
14
MID 144 PID 84
Vehicle Speed
2,14
MID 144 PID 86
Cruise Control, Set Speed
14
MID 144 PID 91
Accelerator Pedal Position (Percentage)
3,4,5,6,14
MID 144 PID 152 Vehicle ECU, Number of Resets
12
MID 144 PID 191 Output Shaft Speed
5,6
MID 144 PPID 3
4
Starter Relay Output
MID 144 PPID 60 Idle Switch, Power
4
MID 144 PPID 61 Engine Brake Switch
7
MID 144 PPID 69 Buffered Idle Validation Switch
3,4
MID 144 PPID 70 Pedal Switches, Supply Power
4
MID 144 PPID 71 Cruise Control and Engine Brake, Switch Supply
4
MID 144 PPID 72 Cruise Control and Engine Brake, Sensor Supply
3,4
MID 144 PPID 73 Second Accelerator Pedal, Supply Sensor
3,4
MID 144 PPID 74 Vehicle ECU, Power Supply
4
MID 144 PPID 265 Vehicle Speed Sensor Supply
3,4
MID 144 PPID 279 Air Dryer, Dry Agent Reservoir
0
MID 144 PPID 312 Air Dryer, Regeneration
0,7
MID 144 PPID 430 Air Dryer, Regeneration
0
MID 144 SID 230 Idle Validation Switch 1 (IVS Issue)
7
MID 144 SID 231 SAE J1939 Data Link
2
MID 144 SID 240 Program Memory
2
MID 144 SID 243 Cruise Control Set Switch
7
MID 144 SID 250 SAE J1587 Data Link
2
MID 144 SID 253 Calibration Memory EEPROM
2,14
MID 144 PSID 1
Retarder Control Set Switch
7
MID 144 PSID 2
Idle Validation Switch 2 (IVS Issue)
7
MID 144 PSID 4
Engine Brake Stalk Lever
3,4
MID 144 PSID 8
Neutral Position Error
3,4
MID 144 PSID 16 Power Relay 1 (EMS Power Relay)
3,4
MID 144 PSID 20 Power Take Off Signal
3,4
MID 144 PSID 23 Air Dryer, Regenerating
3,4
MID 144 PSID 24 Compressor, Control
3,4
MID 144 PSID 25 Air Leakage
14
MID 144 PSID 200 Communication Error, J1939 Data Link, Engine ECU
9
MID 144 PSID 202 Communication Error, J1939 Data Link, Cluster Module
9
MID 144 PSID 204 Communication Error, J1939 Data Link, Brake ECU
9
MID 144 PSID 205 Communication Error, J1939 Data Link, Transmission
9
MID 144 PSID 206 Communication Error, J1939 Data Link, Retarder Control
9
MID 144 PSID 207 Communication Error, J1939 Data Link, Gear Selector
9
MID 144 PSID 208 Communication Error, J1939 Data Link, Air Suspension
9
MID 144 PSID 210 Communication Error, J1939 Data Link, Light Control Module 9 MID 144 PSID 211 Communication Error, J1939 Data Link, Collision Avoidance 9 MID 144 PSID 214 Communication Error, J1939 Data Link, Bodybuilder Control 9 MID 144 PSID 230 Software Fault (VICE)
4,5,12
Climate Control Faults (MID 146) Fault code
Description
FMI
MID 146 SID 2
Temperature sensor, evaporator
3. 4
MID 146 SID 5
Stepper Motor, Fresh Air and Recirculation
4
MID 146 SID 6
Stepper motor, air distribution
4
MID 146 SID 9
Stepper motor, air mixture, heat control
4
MID 146 SID 11 Magnetic clutch, A/C compressor
4
MID 146 SID 12 Solenoid valve, water control
3
MID 146 SID 13 Temperature sensor, heat exchanger
3. 4
MID 146 SID 14 Circulation fan, temperature sensor, cab
4
MID 146 SID 15 Fan connection, engine
3
MID 146 SID 16 Stepper motor, phase 1
3
MID 146 SID 17 Stepper motor, phase 2
3
MID 146 SID 18 Stepper motor, phase 3
3
MID 146 SID 19 Stepper motor, phase 4
3
MID 146 SID 22 Pressure sensor, refrigerant, high pressure side 3. 4 MID 146 SID 232 5 volts supply to the sensor
4
MID 146 SID 250 SAE J1708 data link
9
MID 146 PID 170 Cab, temperature sensor
3,4
MID 146 PID 171 Temperature sensor, outer temperature
3,5
Light Control Module Faults (MID 216) Fault Code
Description
FMI Codes
MID 216 PSID 42 Rheostat, instrument lighting
3, 4
MID 216 PSID 44 Central locking alarm (short to ground)
12
MID 216 PSID 45 Side repeater, right
5, 6
MID 216 PSID 46 Side repeater, left
5, 6
MID 216 PSID 48 Park and license plate lights, tractor rear
5, 6
MID 216 PSID 49 Tractor roof marker/clearance lamps
5, 6
MID 216 PSID 50 Tractor front park lights
5, 6
MID 216 PSID 51 Trailer park lights
3, 4
MID 216 PSID 52 Allison retarder indicator LED
4
MID 216 PSID 53 Marker (ICC) trailer
6
MID 216 PSID 54 Marker interrupt
12
MID 216 PSID 55 Headlamp interrupt
12
MID 216 PSID 57 Back of cab lights
5, 6
MID 216 PSID 77 Back of cab switch (short to ground)
12
MID 216 PSID 200 SAE J1939 Open-circuit, data link, engine control unit 9 MID 216 PSID 201 SAE J1939 Open-circuit, data link, vehicle control unit 9 MID 216 PSID 202 DID
9
MID 216 PSID 205 Transmission
9
MID 216 PSID 214 Body Builder Module
9
MID 216 PSID 2
2
No VIN response
Gear Selector Module Faults (MID 223) Fault Code
Description
FMI Codes
MID 223 PSID 9
Gear Selector, Position
12
MID 223 PSID 36 Relay Power Supply
7,12
MID 223 PSID 42 Signals, Key
2
MID 223 PSID 200 Open Circuit, J1939 data link, Engine
9
MID 223 PSID 201 Open Circuit, J1939 data link, Vehicle Control Unit
9
MID 223 PSID 205 Open Circuit, J1939 data link, Transmission control unit 9 MID 223 PSID 214 No Data From BBM
9
MID 223 SID 240 Program Memory
2
MID 223 SID 250 SAE J1587 Data Link
9
MID 223 SID 253 Calibration Memory EEPROM
2
MID 223 SID 254 Hardware Fault
12
Bodybuilder System Faults (MID 249) Fault code
Description
FMI
MID 249 PID 29
Extra Throttle Control, Percent Position
3,4
MID 249 SID 230 Idle Switch
7
MID 249 SID 231 SAE J1939 Data Link
2
MID 249 SID 253 Calibration Memory, EEPROM
2
MID 249 PSID 200 SAE J1939 Open Circuit, Data Link, Engine ECU
9
MID 249 PSID 201 SAE J1939 Open Circuit, Data Link, Vehicle ECU
9
MID 249 PSID 202 SAE J1939 Open Circuit, Data Link, Instrument Cluster
9
MID 249 PSID 205 SAE J1939 Open Circuit, Data Link, Automatic Transmission 9 Steering Wheel Module Faults (MID 250) Fault code
Description
MID 250 SID 231 SAE J1939 control link
FMI 2
MID 250 SID 251 Power supply, control unit steering functions ( SWM) 3, 4 MID 250 SID 254 Control unit steering wheel module (SWM)
12
MID 250 PSID 3 Arrow left
12
MID 250 PSID 4 Arrow right
12
Description
FMI Codes
MID 128 PID 26
Engine Fan Speed Percent
3,8
MID 128 PID 27
EGR Valve #1 Position Sensor
3,4,5
MID 128 PID 45
Preheater Relay Status
3,4,5
MID 128 PID 81
Particulate Filter
0,2,3,5,12
MID 128 PID 84
Vehicle Speed
9
MID 128 PID 85
Cruise Control Status
9
MID 128 PID 91
Accelerator Pedal Position
9
MID 128 PID 94
Fuel Supply Pressure
1,3,5,7
MID 128 PID 97
Water in Fuel Indicator
3,4
MID 128 PID 98
Engine Oil Level
1,4,5
MID 128 PID 100 Engine Oil Pressure
1,3,5
MID 128 PID 102 Intake manifold pressure
0,1,2,3,5,11
MID 128 PID 103 Turbo Shaft Speed
0,1,9
MID 128 PID 105 Intake manifold temperature
0,1,2,4,5,10
MID 128 PID 108 Atmospheric pressure
2,3,4,5
MID 128 PID 110 Engine coolant temperature
0,2,4,5,10
MID 128 PID 111 Engine coolant level
1,3,4,5
MID 128 PID 153 Crankcase pressure
0,1,2, 3, 5
MID 128 PID 158 Battery voltage
3, 4
MID 128 PID 171 Ambient Temperature
9
MID 128 PID 173 Exhaust Temperature
0,2,4,5,10
MID 128 PID 175 Engine Oil Temperature
0,2,4,5
MID 128 PID 228 Road speed sensor calibration
11
MID 128 PID 354 Relative Humidity
3,5
MID 128 PID 362 EGR Valve #2 position sensor
3, 5
MID 128 PID 411 EGR Exhaust Back Pressure
2,3,5
MID 128 PID 412 EGR Temperature
0, 4, 5,10
MID 128 PPID 35 EGR Mass Flow Sensor
0,1
MID 128 PPID 86 Engine Brake Torque Percent
9
MID 128 PPID 89 Variable Geometry Turbo Temperature
0
MID 128 PPID 119 High Coolant Temperature
0
MID 128 PPID 122 VCB Compression Brake Status
1, 3, 4, 5
MID 128 PPID 124 EPG Valve (Exhaust Gas Pressure)
1, 3, 4, 5
MID 128 PPID 270 Nox Sensor
2,3,5,9,10,12,13,14
MID 128 PPID 272 Air Pressure Compensation
4,5
MID 128 PPID 326 Soot Level (DPF System)
0,11
MID 128 PPID 328 Aftertreatment Injection Shutoff Valve
3,4,5,7,14
MID 128 PPID 329 Aftertreatment Fuel Injector
3,4,5,7,14
MID 128 PPID 330 Discharge Reciculator Valve (BOV)
3,4,5,7
MID 128 PPID 337 Ash Level (DPF)
0,14
MID 128 PPID 387 Temperature Sensor, Catalytic Converter
2,4,5,10
MID 128 PPID 436 Exhaust Gas Temperature Sensor #3
2,4,5,10
MID 128 PPID 437 Aftertreatment Injector Fuel Pressure Sensor 2,3,5,10 MID 128 PSID 47 Particulate Trap Regeneration (DPF)
0,1,8,12
MID 128 PSID 98 Boost Air Pressure System
0,1
MID 128 PSID 108 Aftertreatment Injector System (ATI)
7
MID 128 PSID 109 Engine Coolant Temperature Sensor
7,12
MID 128 SID 1
Electronic Unit Injectors #1
3, 5, 7, 12
MID 128 SID 2
Electronic Unit Injectors #2
3, 5, 7, 12
MID 128 SID 3
Electronic Unit Injectors #3
3, 5, 7, 12
MID 128 SID 4
Electronic Unit Injectors #4
3, 5, 7, 12
MID 128 SID 5
Electronic Unit Injectors #5
3, 5, 7, 12
MID 128 SID 6
Electronic Unit Injectors #6
3, 5, 7, 12
MID 128 SID 18
Drain Valve, Water Separator
3,4,5
MID 128 SID 21
Engine position, camshaft sensor
3, 8
MID 128 SID 22
Engine speed, flywheel sensor
2, 3, 8
MID 128 SID 27
Variable Geometry Turbo (VGT)
2,4,7,9,13
MID 128 SID 33
Fan control
3, 4, 5
MID 128 SID 70
Preheater element 1
3, 4, 5
MID 128 SID 71
Preheater element 2
3, 4, 5
MID 128 SID 78
Fuel priming pump
4, 5
MID 128 SID 146 EGR Valve #1 motor
3, 5, 6, 7, 12, 13
MID 128 SID 211 5 Volt DC supply (EB connector)
3, 4
MID 128 SID 230 Idle validation switch
3, 4
MID 128 SID 231 SAE J1939 Control link
2
MID 128 SID 232 5 Volt DC supply (EA connector) 3
3, 4
MID 128 SID 240 Program memory
2
MID 128 SID 253 Data set memory EEPROM
2, 12, 13
MID 128 SID 254 Engine electronic control unit (EECU)
3, 8, 12
MID 128 SID 266 EGR Valve #2 motor
3, 5, 6, 7, 12, 13
MID 128 SID 281 EGR reed valve diagnose
7
MID 128 SID 282 EGR cooler efficiency
7
MID 128 PSID 201 SAE J1939 Data Link Interruption
9
Create your FREE Sign up and get started today. FMI Description / Diagnosis Information FMI Codes Display Name
Description
0
Too high value
Data valid, but above normal work range
1
Too low value
Data valid, but below normal work range
2
Incorrect data
Data erratic, intermittent, or incorrect
3
Electrical fault
Voltage above normal or shorted high
4
Electrical fault
Voltage below normal or shorted low
5
Electrical fault
Current below normal or open circuit
6
Electrical fault
Current above normal or grounded circuit
7
Mechanical fault
Mechanical system not responding properly
8
Mech. or electrical fault Abnormal frequency, pulse width, or period
9
Communication fault
10
Mech. or electrical fault Abnormal rate of change
11
Unknown fault
Failure mode not identifiable
12
Component fault
Bad intelligent device or component
13
Incorrect calibration
Out of calibration
14
Unknown fault
Special instructions
15
Unknown fault
Special instructions
Abnormal update rate
Engine Injector Faults (MID 128 SID 1 – SID 6) FMI Injector Codes Description 3
Short circuit to battery voltage, unit injector low side.
5
Open circuit in actuator circuit.
7
Mechanical system does not respond correctly.
12
Resistance too high in injector.
Transmission ECU Faults (MID 130) Fault Code
Description
FMI Codes
MID 130 PID 31
Range Cylinder, Position
3,5,6,13
MID 130 PID 32
Split Cylinder, Position
3,5,6,13
MID 130 PID 33
Clutch Cylinder, Position
2,3,5,12,13
MID 130 PID 36
Clutch Wear Status
0
MID 130 PID 37
Air Pressure, Transmission
0,1,3,5
MID 130 PID 65
Brake Switch
14
MID 130 PID 158 Control Module, Battery Voltage
0,1
MID 130 PID 160 Main Shaft, Rotation Speed
1,2,3,4,5
MID 130 PID 161 Input Shaft, Rotation Speed
1,4,5
MID 130 PID 177 Oil Temperature, Transmission
0,4,5
MID 130 PPID 10 Gear Selector Cylinder 1, Position
3,5,6,13
MID 130 PPID 11 Gear Selector Cylinder 2, Position
3,5,6,13
MID 130 PPID 50 Clutch, Pre-load
0,11,14
MID 130 PPID 51 Clutch Disc, Pull Position
13
MID 130 PPID 54 ECM 5V Output
0,1
MID 130 PPID 55 ECM Temperature
0
MID 130 PPID 140 Inclination Angle
2
MID 130 PSID 1
PWM Valve, Quick Engagement
3,5,6
MID 130 PSID 2
PWM Valve, Slow Engagement
3,5,6
MID 130 PSID 3
PWM Valve, Quick Disconnection
3,5,6
MID 130 PSID 4
PWM Valve, Slow Disconnection
3,5,6
MID 130 PSID 5
Ground, Quick PWM Valves
3,6
MID 130 PSID 6
Ground. Slow PWM Valves
3,6
MID 130 PSID 12 Solenoid Valve, Gear Cylinder 1, Inner
3,5,6
MID 130 PSID 13 Solenoid Valve, Gear Cylinder 1, Outer
3,5,6
MID 130 PSID 14 Solenoid Valve, Gear Cylinder 2, Inner
3,5,6
MID 130 PSID 15 Solenoid Valve, Gear Cylinder 2, Outer
3,5,6
MID 130 PSID 20 Solenoid Valve. Power Take-Off 1
3,5,6
MID 130 PSID 21 Solenoid Valve. Power Take-Off 2
3,5,6
MID 130 PSID 22 Solenoid Valve. Brake, Counter Shaft
3,5,6
MID 130 PSID 23 Split Engagement System
0,1,2,7,11,12
MID 130 PSID 24 Range Engagement System
0,1,11,12
MID 130 PSID 25 Gears 1/R Engagement System
0,1,2,7,11,12
MID 130 PSID 26 Gears 2/3 Engagement System
0,1,2,7,11,12
MID 130 PSID 27 Clutch System
0,1,7,8,11,12,14
MID 130 PSID 28 Transmission Brake
7
MID 130 PSID 200 Data Link Error J1939, Engine ECU
9
MID 130 PSID 201 Data Link Error J1939, Vehicle ECU
8,9
MID 130 PSID 204 Data Link Error J1939, Brake ECU
8,9
MID 130 PSID 207 Data Link Error J1939, Gear Selector ECU 9 MID 130 PSID 210 Data Link Error J1939, Lighting ECU
9
MID 130 PSID 211 Data Link Error J1939, Cruise Control ECU 9 MID 130 PSID 232 Powertrain CAN (2, J1939)
2,9
MID 130 PSID 254 DIEE Signal
3
MID 130 SID 35
Solenoid Valve, High Range
3,5,6
MID 130 SID 36
Solenoid Valve, Low Range
3,5,6
MID 130 SID 37
Solenoid Valve, High Split
3,5,6
MID 130 SID 38
Solenoid Valve, High Split
3,5,6
MID 130 SID 231 SAE J1939 Data Link
2
MID 130 SID 240 Program Memory
2
MID 130 SID 250 SAE J1587 Datalink
9
MID 130 SID 253 Calibration Memory EEPROM
13
ABS / Brake ECU Faults (MID 136) Fault Code
Description
FMI Faults (ABS)
MID 136 SID 1
ABS Wheel Speed Sensor, Steer Axle (L) 1 Data valid, but high = 0
MID 136 SID 2
ABS Wheel Speed Sensor, Steer Axle (R) 1 Date valid, but low = 1
MID 136 SID 3
ABS Wheel Speed Sensor, Drive Front (L) 2 Data erratic = 2
MID 136 SID 4
ABS Wheel Speed Sensor, Drive Front (R) 2 Voltage shorted high = 3
MID 136 SID 5
ABS Wheel Speed Sensor, Drive Rear (L) 3 Voltage shorted low = 4
MID 136 SID 6
ABS Wheel Speed Sensor, Drive Rear (R) 3 Current low or open C = 5
MID 136 SID 7
ABS Valve Actuator, Steer Axle (L) 1
Current high or short C = 6
MID 136 SID 8
ABS Valve Actuator, Steer Axle (R) 1
Mech system no response = 7
MID 136 SID 9
ABS Valve Actuator, Drive Front (L) 2
Abnormal freq or PW = 8
MID 136 SID 10 ABS Valve Actuator, Drive Front (R) 2
Abnormal update rate = 9
MID 136 SID 11 ABS Valve Actuator, Drive Rear (L) 3
Abnormal change rate = 10
MID 136 SID 12 ABS Valve Actuator, Drive Rear (R) 3
Failure unknown = 11
MID 136 SID 13 ABS Retarder Control Relay
Bad device = 12
MID 136 SID 14 ABS Relay, Diagonal 1
Out of calibration = 13
MID 136 SID 15 ABS Relay Diagonal 2
Special instructions = 14
MID 136 SID 18 ABS Diff 1 – ASR Valve MID 136 SID 19 ABS Diff 2 – ASR Valve MID 136 SID 22 Wheel Speed Sensor Reversed MID 136 SID 23 ABS Warning Lamp Circuit MID 136 SID 42 Pressure Modulator Valve, Left MID 136 SID 43 Pressure Modulator Valve, Right MID 136 SID 44 Pressure Modulator Valve, Left MID 136 SID 45 Pressure Modulator Valve, Right MID 136 SID 46 Pressure Modulator Valve, Left MID 136 SID 47 Pressure Modulator Valve, Right MID 136 SID 48 Pressure Modulator Valve, Left MID 136 SID 49 Pressure Modulator Valve, Right MID 136 SID 50 Pressure Modulator Valve, Left MID 136 SID 51 Pressure Modulator Valve, Right MID 136 SID 52 Pressure Modulator Valve, Left MID 136 SID 53 Pressure Modulator Valve, Right MID 136 SID 55 Stop Lamp Switch Defective
MID 136 SID 79 Tire Size Out of Range (Front to Rear) MID 136 SID 93 PMV/TCV/Diff Lock Short MID 136 SID 102 Diff Lock Solenoid MID 136 SID 154 I/O 2, I/O3 Shorted High MID 136 SID 231 J1939 Not Communicating MID 136 SID 251 Battery Voltage, Power Supply MID 136 SID 254 ECU Not Communicating Instrument Cluster Faults (MID 140) Fault Code
Description
FMI Codes
MID 140 PID 77
Forward rear axle temperature
3, 4
MID 140 PID 78
Rear rear axle temperature
3, 4
MID 140 PID 96
Fuel level
3, 4
MID 140 PID 116
Application air pressure
5, 6
MID 140 PID 117
Air brake pressure, front
5, 6
MID 140 PID 118
Air brake pressure, rear
5, 6
MID 140 PID 158
Battery voltage
0
MID 140 PID 171
Ambient temperature
3, 4
MID 140 PID 177
Transmission oil temperature
3, 4
MID 140 PID 178
Air suspension pressure, front
5, 6
MID 140 PID 179
Air suspension pressure, rear
5, 6
MID 140 SID 231
SAE J1939 Data Link
2
MID 140 SID 240
Program memory
2
MID 140 SID 250
SAE J1587/J1708 data link
3, 4, 9, 12
MID 140 SID 253
Calibration memory, EEPROM
2
MID 140 PSID 7
Internal reference resistance
3, 4
MID 140 PSID 200
Open-circuit, J1939 data link, engine
9
MID 140 PSID 201
Open-circuit, J1939 data link, vehicle control unit
9
MID 140 PSID 204
Open-circuit, J1939 data link, anti-lock brake control 9 unit
MID 140 PSID 210
Open-circuit J1939 data link, Lighting control module 9
MID 140 PSID 232
SAE J1939-3 data link
2
Create your FREE Sign up and get started today. Volvo Link System Faults (MID 142) Fault Code
Description
FMI
MID 142 PID 155
Input 1-4
12: Bad component
MID 142 SID 240
Memory Flash/RAM
12: Bad component, 2: Main software corrupt
MID 142 SID 250
J1708/1587 Data Link
9: No data received from J1587/1708 data link
MID 142 SID 253
Memory ROM
2: Dataset corrupt
MID 142 PSID 003
Sending Message Failure
11: Unknown failure, 12: Bad component
MID 142 PSID 004
GPS module/interface
2: Bad GPS antenna 9: No data r eceived 1: Bad ECU
MID 142 PSID 005
DSP module/interface
12: Bad device or antenna
MID 142 PSID 006
ORBCOMM Satellite module/interface
2: Bad antenna 12: Bad ECU
MID 142 PSID 008
J1708/1587 Road Speed
2: Mismatch
MID 142 PSID 161
J1708/1587 VIN Missing
9: No data received
MID 142 PSID 162
VIN Mismatch
2: Internal dataset mismatch with VIN J1587 data link
Vehicle ECU Faults (MID 144)
Fault Code
Description
FMI
MID 144 PID 46
Primary Tank Pressure
1,3,4
MID 144 PID 83
Road Speed Limit Status
14
MID 144 PID 84
Vehicle Speed
2,14
MID 144 PID 86
Cruise Control, Set Speed
14
MID 144 PID 91
Accelerator Pedal Position (Percentage)
3,4,5,6,14
MID 144 PID 152 Vehicle ECU, Number of Resets
12
MID 144 PID 191 Output Shaft Speed
5,6
MID 144 PPID 3
4
Starter Relay Output
MID 144 PPID 60 Idle Switch, Power
4
MID 144 PPID 61 Engine Brake Switch
7
MID 144 PPID 69 Buffered Idle Validation Switch
3,4
MID 144 PPID 70 Pedal Switches, Supply Power
4
MID 144 PPID 71 Cruise Control and Engine Brake, Switch Supply
4
MID 144 PPID 72 Cruise Control and Engine Brake, Sensor Supply
3,4
MID 144 PPID 73 Second Accelerator Pedal, Supply Sensor
3,4
MID 144 PPID 74 Vehicle ECU, Power Supply
4
MID 144 PPID 265 Vehicle Speed Sensor Supply
3,4
MID 144 PPID 279 Air Dryer, Dry Agent Reservoir
0
MID 144 PPID 312 Air Dryer, Regeneration
0,7
MID 144 PPID 430 Air Dryer, Regeneration
0
MID 144 SID 230 Idle Validation Switch 1 (IVS Issue)
7
MID 144 SID 231 SAE J1939 Data Link
2
MID 144 SID 240 Program Memory
2
MID 144 SID 243 Cruise Control Set Switch
7
MID 144 SID 250 SAE J1587 Data Link
2
MID 144 SID 253 Calibration Memory EEPROM
2,14
MID 144 PSID 1
Retarder Control Set Switch
7
MID 144 PSID 2
Idle Validation Switch 2 (IVS Issue)
7
MID 144 PSID 4
Engine Brake Stalk Lever
3,4
MID 144 PSID 8
Neutral Position Error
3,4
MID 144 PSID 16 Power Relay 1 (EMS Power Relay)
3,4
MID 144 PSID 20 Power Take Off Signal
3,4
MID 144 PSID 23 Air Dryer, Regenerating
3,4
MID 144 PSID 24 Compressor, Control
3,4
MID 144 PSID 25 Air Leakage
14
MID 144 PSID 200 Communication Error, J1939 Data Link, Engine ECU
9
MID 144 PSID 202 Communication Error, J1939 Data Link, Cluster Module
9
MID 144 PSID 204 Communication Error, J1939 Data Link, Brake ECU
9
MID 144 PSID 205 Communication Error, J1939 Data Link, Transmission
9
MID 144 PSID 206 Communication Error, J1939 Data Link, Retarder Control
9
MID 144 PSID 207 Communication Error, J1939 Data Link, Gear Selector
9
MID 144 PSID 208 Communication Error, J1939 Data Link, Air Suspension
9
MID 144 PSID 210 Communication Error, J1939 Data Link, Light Control Module 9 MID 144 PSID 211 Communication Error, J1939 Data Link, Collision Avoidance 9 MID 144 PSID 214 Communication Error, J1939 Data Link, Bodybuilder Control 9 MID 144 PSID 230 Software Fault (VICE)
4,5,12
Climate Control Faults (MID 146) Fault code
Description
FMI
MID 146 SID 2
Temperature sensor, evaporator
3. 4
MID 146 SID 5
Stepper Motor, Fresh Air and Recirculation
4
MID 146 SID 6
Stepper motor, air distribution
4
MID 146 SID 9
Stepper motor, air mixture, heat control
4
MID 146 SID 11 Magnetic clutch, A/C compressor
4
MID 146 SID 12 Solenoid valve, water control
3
MID 146 SID 13 Temperature sensor, heat exchanger
3. 4
MID 146 SID 14 Circulation fan, temperature sensor, cab
4
MID 146 SID 15 Fan connection, engine
3
MID 146 SID 16 Stepper motor, phase 1
3
MID 146 SID 17 Stepper motor, phase 2
3
MID 146 SID 18 Stepper motor, phase 3
3
MID 146 SID 19 Stepper motor, phase 4
3
MID 146 SID 22 Pressure sensor, refrigerant, high pressure side 3. 4 MID 146 SID 232 5 volts supply to the sensor
4
MID 146 SID 250 SAE J1708 data link
9
MID 146 PID 170 Cab, temperature sensor
3,4
MID 146 PID 171 Temperature sensor, outer temperature
3,5
Light Control Module Faults (MID 216) Fault Code
Description
FMI Codes
MID 216 PSID 42 Rheostat, instrument lighting
3, 4
MID 216 PSID 44 Central locking alarm (short to ground)
12
MID 216 PSID 45 Side repeater, right
5, 6
MID 216 PSID 46 Side repeater, left
5, 6
MID 216 PSID 48 Park and license plate lights, tractor rear
5, 6
MID 216 PSID 49 Tractor roof marker/clearance lamps
5, 6
MID 216 PSID 50 Tractor front park lights
5, 6
MID 216 PSID 51 Trailer park lights
3, 4
MID 216 PSID 52 Allison retarder indicator LED
4
MID 216 PSID 53 Marker (ICC) trailer
6
MID 216 PSID 54 Marker interrupt
12
MID 216 PSID 55 Headlamp interrupt
12
MID 216 PSID 57 Back of cab lights
5, 6
MID 216 PSID 77 Back of cab switch (short to ground)
12
MID 216 PSID 200 SAE J1939 Open-circuit, data link, engine control unit 9 MID 216 PSID 201 SAE J1939 Open-circuit, data link, vehicle control unit 9 MID 216 PSID 202 DID
9
MID 216 PSID 205 Transmission
9
MID 216 PSID 214 Body Builder Module
9
MID 216 PSID 2
2
No VIN response
Create your FREE Sign up and get started today. Gear Selector Module Faults (MID 223) Fault Code
Description
FMI Codes
MID 223 PSID 9
Gear Selector, Position
12
MID 223 PSID 36 Relay Power Supply
7,12
MID 223 PSID 42 Signals, Key
2
MID 223 PSID 200 Open Circuit, J1939 data link, Engine
9
MID 223 PSID 201 Open Circuit, J1939 data link, Vehicle Control Unit
9
MID 223 PSID 205 Open Circuit, J1939 data link, Transmission control unit 9 MID 223 PSID 214 No Data From BBM
9
MID 223 SID 240 Program Memory
2
MID 223 SID 250 SAE J1587 Data Link
9
MID 223 SID 253 Calibration Memory EEPROM
2
MID 223 SID 254 Hardware Fault
12
Bodybuilder System Faults (MID 249) Fault code
Description
FMI
MID 249 PID 29
Extra Throttle Control, Percent Position
3,4
MID 249 SID 230 Idle Switch
7
MID 249 SID 231 SAE J1939 Data Link
2
MID 249 SID 253 Calibration Memory, EEPROM
2
MID 249 PSID 200 SAE J1939 Open Circuit, Data Link, Engine ECU
9
MID 249 PSID 201 SAE J1939 Open Circuit, Data Link, Vehicle ECU
9
MID 249 PSID 202 SAE J1939 Open Circuit, Data Link, Instrument Cluster
9
MID 249 PSID 205 SAE J1939 Open Circuit, Data Link, Automatic Transmission 9 Steering Wheel Module Faults (MID 250) Fault code
Description
FMI
MID 250 SID 231 SAE J1939 control link
2
MID 250 SID 251 Power supply, control unit steering functions ( SWM) 3, 4 MID 250 SID 254 Control unit steering wheel module (SWM)
12
MID 250 PSID 3 Arrow left
12
MID 250 PSID 4 Arrow right
12
Engine ECU Faults (MID 128) Fault Code
Description
FMI
MID 128 PID 26
Engine Fan Speed Percent
3,8
MID 128 PID 27
EGR Valve #1 Position Sensor
3,4,5
MID 128 PID 45
Preheater Relay Status
3,4,5
MID128 PID 81
Particulate Filter
0,2,3,5,12
MID 128 PID 84
Vehicle Speed
9
MID 128 PID 85
Cruise Control Status
9
MID 128 PID 91
Accelerator Pedal Position
9
MID 128 PID 94
Fuel Supply Pressure
1,3,5,7
MID 128 PID 97
Water in Fuel Indicator
3,4
MID 128 PID 98
Engine Oil Level
1,4,5
MID 128 PID 100 Engine Oil Pressure
1,3,5
MID 128 PID 102 Intake manifold pressure
0,1,2,3,5,11
MID 128 PID 103 Turbo Shaft Speed
0,1,9
MID 128 PID 105 Intake manifold temperature
0,1,2,4,5,10
MID 128 PID 108 Atmospheric pressure
2,3,4,5
MID 128 PID 110 Engine coolant temperature
0,2,4,5,10
MID 128 PID 111 Engine coolant level
1,3,4,5
MID 128 PID 153 Crankcase pressure
0,1,2, 3, 5
MID 128 PID 158 Battery voltage
3, 4
MID 128 PID 171 Ambient Temperature
9
MID 128 PID 173 Exhaust Temperature
0,2,4,5,10
MID 128 PID 175 Engine Oil Temperature
0,2,4,5
MID 128 PID 228 Road speed sensor calibration
11
MID 128 PID 354 Relative Humidity
3,5
MID 128 PID 362 EGR Valve #2 position sensor
3, 5
MID 128 PID 411 EGR Exhaust Back Pressure
2,3,5
MID 128 PID 412 EGR Temperature
0, 4, 5,10
MID 128 PPID 35 EGR Mass Flow Sensor
0,1
MID 128 PPID 86 Engine Brake Torque Percent
9
MID 128 PPID 89 Variable Geometry Turbo Temperature
0
MID 128 PPID 119 High Coolant Temperature
0
MID 128 PPID 122 VCB Compression Brake Status
1, 3, 4, 5
MID 128 PPID 124 EPG Valve (Exhaust Gas Pressure)
1, 3, 4, 5 2,3,5,9,10,
MID 128 PPID 270 Nox Sensor 12,13,14 MID 128 PPID 272 Air Pressure Compensation
4,5
MID 128 PPID 326 Soot Level (DPF System)
0,11
MID 128 PPID 328 Aftertreatment Injection Shutoff Valve
3,4,5,7,14
MID 128 PPID 329 Aftertreatment Fuel Injector
3,4,5,7,14
MID 128 PPID 330 Discharge Reciculator Valve (BOV)
3,4,5,7
MID 128 PPID 337 Ash Level (DPF)
0,14
MID 128 PPID 387 Temperature Sensor, Catalytic Converter
2,4,5,10
MID 128 PPID 436 Exhaust Gas Temperature Sensor #3
2,4,5,10
MID 128 PPID 437 Aftertreatment Injector Fuel Pressure Sensor 2,3,5,10 MID 128 PSID 47 Particulate Trap Regeneration (DPF)
0,1,8,12
MID 128 PSID 98 Boost Air Pressure System
0,1
MID 128 PSID 108 Aftertreatment Injector System (ATI)
7
MID 128 PSID 109 Engine Coolant Temperature Sensor
7,12
MID 128 SID 1
Electronic Unit Injectors #1
3, 5, 7, 12
MID 128 SID 2
Electronic Unit Injectors #2
3, 5, 7, 12
MID 128 SID 3
Electronic Unit Injectors #3
3, 5, 7, 12
MID 128 SID 4
Electronic Unit Injectors #4
3, 5, 7, 12
MID 128 SID 5
Electronic Unit Injectors #5
3, 5, 7, 12
MID 128 SID 6
Electronic Unit Injectors #6
3, 5, 7, 12
MID 128 SID 18
Drain Valve, Water Separator
3,4,5
MID 128 SID 21
Engine position, camshaft sensor
3, 8
MID 128 SID 22
Engine speed, flywheel sensor
2, 3, 8
MID 128 SID 27
Variable Geometry Turbo (VGT)
2,4,7,9,13
MID 128 SID 33
Fan control
3, 4, 5
MID 128 SID 70
Preheater element 1
3, 4, 5
MID 128 SID 71
Preheater element 2
3, 4, 5
MID 128 SID 78
Fuel priming pump
4, 5
MID 128 SID 146 EGR Valve #1 motor
3, 5, 6, 7, 12, 13
MID 128 SID 211 5 Volt DC supply (EB connector)
3, 4
MID 128 SID 230 Idle validation switch
3, 4
MID 128 SID 231 SAE J1939 Control link
2
MID 128 SID 232 5 Volt DC supply (EA connector) 3
3, 4
MID 128 SID 240 Program memory
2
MID 128 SID 253 Data set memory EEPROM
2, 12, 13
MID 128 SID 254 Engine electronic control unit (EECU)
3, 8, 12
MID 128 SID 266 EGR Valve #2 motor
3, 5, 6, 7, 12, 13
MID 128 SID 281 EGR reed valve diagnose
7
MID 128 SID 282 EGR cooler efficiency
7
MID 128 PSID 201 SAE J1939 Data Link Interruption
9
FMI Description / Diagnosis Information FMI Codes Display Name
Description
0
Too high value
Data valid, but above normal work range
1
Too low value
Data valid, but below normal work range
2
Incorrect data
Data erratic, intermittent, or incorrect
3
Electrical fault
Voltage above normal or shorted high
4
Electrical fault
Voltage below normal or shorted low
5
Electrical fault
Current below normal or open circuit
6
Electrical fault
Current above normal or grounded circuit
7
Mechanical fault
Mechanical system not responding properly
8
Mech. or electrical fault Abnormal frequency, pulse width, or period
9
Communication fault
10
Mech. or electrical fault Abnormal rate of change
11
Unknown fault
Failure mode not identifiable
12
Component fault
Bad intelligent device or component
13
Incorrect calibration
Out of calibration
14
Unknown fault
Special instructions
15
Unknown fault
Special instructions
Abnormal update rate
Engine Injector Faults (MID 128 SID 1 – SID 6)
FMI Injector Codes Description 3
Short circuit to battery voltage, unit injector low side.
5
Open circuit in actuator circuit.
7
Mechanical system does not respond correctly.
12
Resistance too high in injector.
Transmission ECU Faults (MID 130) Fault Code
Description
FMI
MID 130 PID 31
Range Cylinder, Position
3,5,6,13
MID 130 PID 32
Split Cylinder, Position
3,5,6,13
MID 130 PID 33
Clutch Cylinder, Position
2,3,5,12,13
MID 130 PID 36
Clutch Wear Status
0
MID 130 PID 37
Air Pressure, Transmission
0,1,3,5
MID 130 PID 65
Brake Switch
14
MID 130 PID 158 Control Module, Battery Voltage
0,1
MID 130 PID 160 Main Shaft, Rotation Speed
1,2,3,4,5
MID 130 PID 161 Input Shaft, Rotation Speed
1,4,5
MID 130 PID 177 Oil Temperature, Transmission
0,4,5
MID 130 PPID 10 Gear Selector Cylinder 1, Position
3,5,6,13
MID 130 PPID 11 Gear Selector Cylinder 2, Position
3,5,6,13
MID 130 PPID 50 Clutch, Pre-load
0,11,14
MID 130 PPID 51 Clutch Disc, Pull Position
13
MID 130 PPID 54 ECM 5V Output
0,1
MID 130 PPID 55 ECM Temperature
0
MID 130 PPID 140 Inclination Angle
2
MID 130 PSID 1
PWM Valve, Quick Engagement
3,5,6
MID 130 PSID 2
PWM Valve, Slow Engagement
3,5,6
MID 130 PSID 3
PWM Valve, Quick Disconnection
3,5,6
MID 130 PSID 4
PWM Valve, Slow Disconnection
3,5,6
MID 130 PSID 5
Ground, Quick PWM Valves
3,6
MID 130 PSID 6
Ground. Slow PWM Valves
3,6
MID 130 PSID 12 Solenoid Valve, Gear Cylinder 1, Inner
3,5,6
MID 130 PSID 13 Solenoid Valve, Gear Cylinder 1, Outer
3,5,6
MID 130 PSID 14 Solenoid Valve, Gear Cylinder 2, Inner
3,5,6
MID 130 PSID 15 Solenoid Valve, Gear Cylinder 2, Outer
3,5,6
MID 130 PSID 20 Solenoid Valve. Power Take-Off 1
3,5,6
MID 130 PSID 21 Solenoid Valve. Power Take-Off 2
3,5,6
MID 130 PSID 22 Solenoid Valve. Brake, Counter Shaft
3,5,6
MID 130 PSID 23 Split Engagement System
0,1,2,7,11,12
MID 130 PSID 24 Range Engagement System
0,1,11,12
MID 130 PSID 25 Gears 1/R Engagement System
0,1,2,7,11,12
MID 130 PSID 26 Gears 2/3 Engagement System
0,1,2,7,11,12
MID 130 PSID 27 Clutch System
0,1,7,8,11,12,14
MID 130 PSID 28 Transmission Brake
7
MID 130 PSID 200 Data Link Error J1939, Engine ECU
9
MID 130 PSID 201 Data Link Error J1939, Vehicle ECU
8,9
MID 130 PSID 204 Data Link Error J1939, Brake ECU
8,9
MID 130 PSID 207 Data Link Error J1939, Gear Selector ECU 9 MID 130 PSID 210 Data Link Error J1939, Lighting ECU
9
MID 130 PSID 211 Data Link Error J1939, Cruise Control ECU 9 MID 130 PSID 232 Powertrain CAN (2, J1939)
2,9
MID 130 PSID 254 DIEE Signal
3
MID 130 SID 35
Solenoid Valve, High Range
3,5,6
MID 130 SID 36
Solenoid Valve, Low Range
3,5,6
MID 130 SID 37
Solenoid Valve, High Split
3,5,6
MID 130 SID 38
Solenoid Valve, High Split
3,5,6
MID 130 SID 231 SAE J1939 Data Link
2
MID 130 SID 240 Program Memory
2
MID 130 SID 250 SAE J1587 Datalink
9
MID 130 SID 253 Calibration Memory EEPROM
13
ABS / Brake ECU Faults (MID 136) Fault Code
Description
FMI Faults (ABS)
MID 136 SID 1
ABS Wheel Speed Sensor, Steer Axle (L) 1 Data valid, but high = 0
MID 136 SID 2
ABS Wheel Speed Sensor, Steer Axle (R) 1 Date valid, but low = 1
MID 136 SID 3
ABS Wheel Speed Sensor, Drive Front (L) 2 Data erratic = 2
MID 136 SID 4
ABS Wheel Speed Sensor, Drive Front (R) 2 Voltage shorted high = 3
MID 136 SID 5
ABS Wheel Speed Sensor, Drive Rear (L) 3 Voltage shorted low = 4
MID 136 SID 6
ABS Wheel Speed Sensor, Drive Rear (R) 3 Current low or open C = 5
MID 136 SID 7
ABS Valve Actuator, Steer Axle (L) 1
Current high or short C = 6
MID 136 SID 8
ABS Valve Actuator, Steer Axle (R) 1
Mech system no response = 7
MID 136 SID 9
ABS Valve Actuator, Drive Front (L) 2
Abnormal freq or PW = 8
MID 136 SID 10 ABS Valve Actuator, Drive Front (R) 2
Abnormal update rate = 9
MID 136 SID 11 ABS Valve Actuator, Drive Rear (L) 3
Abnormal change rate = 10
MID 136 SID 12 ABS Valve Actuator, Drive Rear (R) 3
Failure unknown = 11
MID 136 SID 13 ABS Retarder Control Relay
Bad device = 12
MID 136 SID 14 ABS Relay, Diagonal 1
Out of calibration = 13
MID 136 SID 15 ABS Relay Diagonal 2
Special instructions = 14
MID 136 SID 18 ABS Diff 1 – ASR Valve MID 136 SID 19 ABS Diff 2 – ASR Valve MID 136 SID 22 Wheel Speed Sensor Reversed MID 136 SID 23 ABS Warning Lamp Circuit MID 136 SID 42 Pressure Modulator Valve, Left
MID 136 SID 43 Pressure Modulator Valve, Right MID 136 SID 44 Pressure Modulator Valve, Left MID 136 SID 45 Pressure Modulator Valve, Right MID 136 SID 46 Pressure Modulator Valve, Left MID 136 SID 47 Pressure Modulator Valve, Right MID 136 SID 48 Pressure Modulator Valve, Left MID 136 SID 49 Pressure Modulator Valve, Right MID 136 SID 50 Pressure Modulator Valve, Left MID 136 SID 51 Pressure Modulator Valve, Right MID 136 SID 52 Pressure Modulator Valve, Left MID 136 SID 53 Pressure Modulator Valve, Right MID 136 SID 55 Stop Lamp Switch Defective MID 136 SID 79 Tire Size Out of Range (Front to Rear) MID 136 SID 93 PMV/TCV/Diff Lock Short MID 136 SID 102 Diff Lock Solenoid MID 136 SID 154 I/O 2, I/O3 Shorted High MID 136 SID 231 J1939 Not Communicating MID 136 SID 251 Battery Voltage, Power Supply MID 136 SID 254 ECU Not Communicating Instrument Cluster Faults (MID 140) Fault Code
Description
FMI
MID 140 PID 77
Forward rear axle temperature
3, 4
MID 140 PID 78
Rear rear axle temperature
3, 4
MID 140 PID 96
Fuel level
3, 4
MID 140 PID 116 Application air pressure
5, 6
MID 140 PID 117 Air brake pressure, front
5, 6
MID 140 PID 118 Air brake pressure, rear
5, 6
MID 140 PID 158 Battery voltage
0
MID 140 PID 171 Ambient temperature
3, 4
MID 140 PID 177 Transmission oil temperature
3, 4
MID 140 PID 178 Air suspension pressure, front
5, 6
MID 140 PID 179 Air suspension pressure, rear
5, 6
MID 140 SID 231 SAE J1939 Data Link
2
MID 140 SID 240 Program memory
2
MID 140 SID 250 SAE J1587/J1708 data link
3, 4, 9, 12
MID 140 SID 253 Calibration memory, EEPROM
2
MID 140 PSID 7
3, 4
Internal reference resistance
MID 140 PSID 200 Open-circuit, J1939 data link, engine
9
MID 140 PSID 201 Open-circuit, J1939 data link, vehicle control unit
9
MID 140 PSID 204 Open-circuit, J1939 data link, anti-lock brake control unit 9 MID 140 PSID 210 Open-circuit J1939 data link, Lighting control module
9
MID 140 PSID 232 SAE J1939-3 data link
2
Create your FREE Sign up and get started today. Volvo Link System Faults (MID 142) Fault Code
Description
FMI
MID 142 PID 155
Input 1-4
12: Bad component
MID 142 SID 240
Memory Flash/RAM
12: Bad component, 2: Main software corrupt
MID 142 SID 250
J1708/1587 Data Link
9: No data received from J1587/1708 data link
MID 142 SID 253
Memory ROM
2: Dataset corrupt
MID 142 PSID Sending Message Failure 003
11: Unknown failure, 12: Bad component
MID 142 PSID 004
GPS module/interface
2: Bad GPS antenna 9: No data r eceived 1: Bad ECU
MID 142 PSID 005
DSP module/interface
12: Bad device or antenna
MID 142 PSID 006
ORBCOMM Satellite module/interface
2: Bad antenna 12: Bad ECU
MID 142 PSID 008
J1708/1587 Road Speed
2: Mismatch
MID 142 PSID 161
J1708/1587 VIN Missing
9: No data received
MID 142 PSID 162
VIN Mismatch
2: Internal dataset mismatch with VIN J1587 data link
Vehicle ECU Faults (MID 144) Fault Code
Description
FMI
MID 144 PID 46
Primary Tank Pressure
1,3,4
MID 144 PID 83
Road Speed Limit Status
14
MID 144 PID 84
Vehicle Speed
2,14
MID 144 PID 86
Cruise Control, Set Speed
14
MID 144 PID 91
Accelerator Pedal Position (Percentage)
3,4,5,6,14
MID 144 PID 152 Vehicle ECU, Number of Resets
12
MID 144 PID 191 Output Shaft Speed
5,6
MID 144 PPID 3
4
Starter Relay Output
MID 144 PPID 60 Idle Switch, Power
4
MID 144 PPID 61 Engine Brake Switch
7
MID 144 PPID 69 Buffered Idle Validation Switch
3,4
MID 144 PPID 70 Pedal Switches, Supply Power
4
MID 144 PPID 71 Cruise Control and Engine Brake, Switch Supply
4
MID 144 PPID 72 Cruise Control and Engine Brake, Sensor Supply
3,4
MID 144 PPID 73 Second Accelerator Pedal, Supply Sensor
3,4
MID 144 PPID 74 Vehicle ECU, Power Supply
4
MID 144 PPID 265 Vehicle Speed Sensor Supply
3,4
MID 144 PPID 279 Air Dryer, Dry Agent Reservoir
0
MID 144 PPID 312 Air Dryer, Regeneration
0,7
MID 144 PPID 430 Air Dryer, Regeneration
0
MID 144 SID 230 Idle Validation Switch 1 (IVS Issue)
7
MID 144 SID 231 SAE J1939 Data Link
2
MID 144 SID 240 Program Memory
2
MID 144 SID 243 Cruise Control Set Switch
7
MID 144 SID 250 SAE J1587 Data Link
2
MID 144 SID 253 Calibration Memory EEPROM
2,14
MID 144 PSID 1
Retarder Control Set Switch
7
MID 144 PSID 2
Idle Validation Switch 2 (IVS Issue)
7
MID 144 PSID 4
Engine Brake Stalk Lever
3,4
MID 144 PSID 8
Neutral Position Error
3,4
MID 144 PSID 16 Power Relay 1 (EMS Power Relay)
3,4
MID 144 PSID 20 Power Take Off Signal
3,4
MID 144 PSID 23 Air Dryer, Regenerating
3,4
MID 144 PSID 24 Compressor, Control
3,4
MID 144 PSID 25 Air Leakage
14
MID 144 PSID 200 Communication Error, J1939 Data Link, Engine ECU
9
MID 144 PSID 202 Communication Error, J1939 Data Link, Cluster Module
9
MID 144 PSID 204 Communication Error, J1939 Data Link, Brake ECU
9
MID 144 PSID 205 Communication Error, J1939 Data Link, Transmission
9
MID 144 PSID 206 Communication Error, J1939 Data Link, Retarder Control
9
MID 144 PSID 207 Communication Error, J1939 Data Link, Gear Selector
9
MID 144 PSID 208 Communication Error, J1939 Data Link, Air Suspension
9
MID 144 PSID 210 Communication Error, J1939 Data Link, Light Control Module 9 MID 144 PSID 211 Communication Error, J1939 Data Link, Collision Avoidance 9 MID 144 PSID 214 Communication Error, J1939 Data Link, Bodybuilder Control 9 MID 144 PSID 230 Software Fault (VICE)
4,5,12
Climate Control Faults (MID 146) Fault code
Description
FMI
MID 146 SID 2
Temperature sensor, evaporator
3. 4
MID 146 SID 5
Stepper Motor, Fresh Air and Recirculation
4
MID 146 SID 6
Stepper motor, air distribution
4
MID 146 SID 9
Stepper motor, air mixture, heat control
4
MID 146 SID 11 Magnetic clutch, A/C compressor
4
MID 146 SID 12 Solenoid valve, water control
3
MID 146 SID 13 Temperature sensor, heat exchanger
3. 4
MID 146 SID 14 Circulation fan, temperature sensor, cab
4
MID 146 SID 15 Fan connection, engine
3
MID 146 SID 16 Stepper motor, phase 1
3
MID 146 SID 17 Stepper motor, phase 2
3
MID 146 SID 18 Stepper motor, phase 3
3
MID 146 SID 19 Stepper motor, phase 4
3
MID 146 SID 22 Pressure sensor, refrigerant, high pressure side 3. 4 MID 146 SID 232 5 volts supply to the sensor
4
MID 146 SID 250 SAE J1708 data link
9
MID 146 PID 170 Cab, temperature sensor
3,4
MID 146 PID 171 Temperature sensor, outer temperature
3,5
Light Control Module Faults (MID 216) Fault Code
Description
FMI Codes
MID 216 PSID 42 Rheostat, instrument lighting
3, 4
MID 216 PSID 44 Central locking alarm (short to ground)
12
MID 216 PSID 45 Side repeater, right
5, 6
MID 216 PSID 46 Side repeater, left
5, 6
MID 216 PSID 48 Park and license plate lights, tractor rear
5, 6
MID 216 PSID 49 Tractor roof marker/clearance lamps
5, 6
MID 216 PSID 50 Tractor front park lights
5, 6
MID 216 PSID 51 Trailer park lights
3, 4
MID 216 PSID 52 Allison retarder indicator LED
4
MID 216 PSID 53 Marker (ICC) trailer
6
MID 216 PSID 54 Marker interrupt
12
MID 216 PSID 55 Headlamp interrupt
12
MID 216 PSID 57 Back of cab lights
5, 6
MID 216 PSID 77 Back of cab switch (short to ground)
12
MID 216 PSID 200 SAE J1939 Open-circuit, data link, engine control unit 9 MID 216 PSID 201 SAE J1939 Open-circuit, data link, vehicle control unit 9 MID 216 PSID 202 DID
9
MID 216 PSID 205 Transmission
9
MID 216 PSID 214 Body Builder Module
9
MID 216 PSID 2
2
No VIN response
Gear Selector Module Faults (MID 223) Fault Code
Description
FMI Codes
MID 223 PSID 9
Gear Selector, Position
12
MID 223 PSID 36 Relay Power Supply
7,12
MID 223 PSID 42 Signals, Key
2
MID 223 PSID 200 Open Circuit, J1939 data link, Engine
9
MID 223 PSID 201 Open Circuit, J1939 data link, Vehicle Control Unit
9
MID 223 PSID 205 Open Circuit, J1939 data link, Transmission control unit 9 MID 223 PSID 214 No Data From BBM
9
MID 223 SID 240 Program Memory
2
MID 223 SID 250 SAE J1587 Data Link
9
MID 223 SID 253 Calibration Memory EEPROM
2
MID 223 SID 254 Hardware Fault
12
Bodybuilder System Faults (MID 249) Fault code
Description
FMI
MID 249 PID 29
Extra Throttle Control, Percent Position
3,4
MID 249 SID 230 Idle Switch
7
MID 249 SID 231 SAE J1939 Data Link
2
MID 249 SID 253 Calibration Memory, EEPROM
2
MID 249 PSID 200 SAE J1939 Open Circuit, Data Link, Engine ECU
9
MID 249 PSID 201 SAE J1939 Open Circuit, Data Link, Vehicle ECU
9
MID 249 PSID 202 SAE J1939 Open Circuit, Data Link, Instrument Cluster
9
MID 249 PSID 205 SAE J1939 Open Circuit, Data Link, Automatic Transmission 9 Steering Wheel Module Faults (MID 250) Fault code
Description
MID 250 SID 231 SAE J1939 control link
FMI 2
MID 250 SID 251 Power supply, control unit steering functions ( SWM) 3, 4 MID 250 SID 254 Control unit steering wheel module (SWM)
12
MID 250 PSID 3 Arrow left
12
MID 250 PSID 4 Arrow right
12
Related Documents c2h70
Codigo De Error Volvo 3s235f
January 2022 0
Codigo De Error 0xc0000185 5h1w6j
January 2023 0
Codigo De Error 6d675a
April 2023 0
Codigo De Error Wd501 - Cargador Frontal Volvo L150g 2h2b1n
February 2023 0
Volvo Error Codes 5b254r
October 2019 200
Code Error Exca Volvo 254h5n
October 2020 0More Documents from "roque" 5l53l
Manual De Servico Cb 300r 2009 714hg
November 2019 96
Codigo De Error Volvo 3s235f
January 2022 0
Rpta Cap 2 Libro 24p5e
November 2020 0
Calculo De Potencia De Motor Para Molinos 432x50
July 2020 3
6g3p1u
October 2019 468
