Codigo De Error 6d675a

para modelos 2004 en adelante 1 -Pon el interruptor de arranque en la posición "OFF" y el interruptor Run/Stop en "Run". 2 - Mantén apretado el botón de reajuste del odómetro. 3 - Gira el interruptor de arranque a la posición "Ignition" y suelta el botón de reajuste del odómetro. Se encenderá la iluminación de fondo, la aguja del velocímetro deberá recorrer su gama completa y las lámparas indicadoras se deben iluminar. La palabra “diag” debe entonces aparecer. 4 - Aprieta el botón del reajuste del odómetro una vez y verás el menú "PSSPt" con la primera selección "P" destellando. 5 - Cada letra representa un área del módulo del diagnóstico. El módulo que está destellando es el que vas a comprobar. Para moverse a partir de una letra (módulo) al siguiente, aprieta el botón del reajuste del odómetro una vez. (de P a S a SP a t y de nuevo a P etc.) P = ECM/ICM (módulo de control electrónico [EFI]/módulo de control de ignición [Carburador]) S = TSM/TSSM (intermitencias/Alarma) SP = velocímetro T = tacómetro 6 - Para seleccionar un área del diagnóstico, apretar y sostener el botón del reajuste del odómetro hacia adentro durante 5 segundos y soltar. Si hay algún aviso de fallo será exhibido el código, si no aparecerá la palabra "none". Pulsar de nuevo el botón para ver si existen códigos adicionales. 7 - Anotar los códigos. 8 - presionar y soltar el botón del reajuste del odómetro. El número de módulo será exhibido. NOTA: Para determinar si un código es actual o histórico, borre el código exhibido manteniendo apretado el botón del reajuste del odómetro (más de 5 segundos) hasta que aparezca la palabra "clear". Soltar el botón del reajuste del odómetro. Girar a la posición "OFF"e l interruptor de arranque. Arrancar la moto y apagarla, entonces volver a inspeccionar los códigos de error

repitiendo los pasos 1 a 9. Si el código es actual reaparecerá. 9 - Presionar y soltar el botón del reajuste del odómetro para continuar con el módulo siguiente. 10 - Para finalizar, girar el interruptor de arranque a la posición "OFF". ---------------------------------------------------------------------------------------------------------------------------------------no traduzco todos los códigos (mucho curro), si alguien necesita traducir algo que no entiende que lo diga. ---------------------------------------------------------------------------------------------------------------------------------------DTC FAULT CONDITION MODULE "BUS Er" Serial data bus shorted/low/open/high B0563 Battery Voltage High TSM/TSSM B1004 Fuel Level Sending Unit Low Instruments B1005 Fuel Level Sending Unit High/Open Instruments B1006 Accessory Line Overvoltage Instruments B1007 Ignition Line Overvoltage Instruments B1008 Reset Switch Closed Instruments B1122 Right turn output fault B1131 Alarm Output Low TSM/TSSM B1132 Alarm Output High TSM/TSSM B1134 Starter Output High TSM/TSSM B1135 Accelerometer Fault TSM/TSSM B1141 Ignition switch open/low B1151 Sidecar BAS Low TSM/TSSM B1152 Sidecar BAS High TSM/TSSM B1153 Sidecar BAS Out of Range TSM/TSSM P0106 MAP Sensor Rate of Range Error Carb P0107 Map Sensor Failed Open/Low Carb P0107 Map Sensor Open/Low EFI P0108 Map Sensor Failed High Carb P0108 Map Sensor High EFI P0112 IAT Sensor Voltage Low EFI P0113 IAT Sensor Voltage Open/High EFI P0117 ET Sensor Voltage Low EFI P0118 ET Sensor Voltage Open/High EFI

P0122 P0123 P0131 P0132 P0134 P0151 P0152 P0154 P0261 P0262 P0263 P0264 P0373 P0373 P0374 P0374 P0501 P0501 P0502 P0502 P0505 P0562 P0562 P0563 P0563 P0602 P0603 P0603 P0604 P0605 P0605 P0607 P0661 P0662 P1001 P1002 P1003 P1004 P1009 P1009 P1010 P1010 P1351 P1351

TP Sensor Open/Low EFI TP Sensor High EFI Front 02 sensor low (lean) Engine running rich Front 02 sensor open/not responding Rear 02 sensor low (lean) Rear 02 sensor high (rich) Rear 02 sensor open/not responding Front Injector Open/Low EFI Front Injector High EFI Rear Injector Open/Low EFI Rear Injector High EFI CKP Sensor Intermittent Carb CKP Sensor Intermittent EFI CKP Sensor Not Detected Carb CKP Sensor Synch Error EFI VSS Low Carb VSS Low EFI VSS High/Open Carb VSS High/Open EFI Loss of Idle Sped Control EFI Battery Voltage Low Carb Battery Voltage Low EFI Battery Voltage High Carb Battery Voltage High EFI Calibration Memory Error Carb EEPROM Failure Carb ECM EEPROM Error EFI RAM Failure Carb Program Memory Error Carb ECM Flash Error EFI Converter Error Carb Intake solenoid low/open Intake solenoid high/shorted System Relay Coil Open/Low EFI System relay Coil High/Shorted EFI System relay s Open EFI System Relay s Closed EFI Incorrect Carb Incorrect EFI Missing Carb Missing EFI Front Ignition Open/Low Carb Front Ignition Open/Low EFI

P1352 Front Ignition Coil High/Shorted Carb P1352 Front Ignition Coil High/Shorted EFI P1353 Front Cylinder No Combustion EFI P1354 Rear Ignition Coil Open/Low Carb P1354 Rear Ignition Coil Open/Low EFI P1355 Rear Ignition Coil High/Shorted Carb P1355 Rear Ignition Coil High/Shorted EFI P1356 Rear Cylinder No Combustion EFI P1357 Intermittent Secondary Front EFI P1358 Intermittent Secondary Rear EFI U1016 Loss of ICM/ECM Serial Data Instruments U1016 Loss of ECM Serial Data, Vehicle Speed, Vehicle Inhibit Motion or Powertrain Security Status TSM/TSSM U1064 Loss of TSM/TSSM Serial Data Carb U1064 Loss of TSM/TSSM Serial Data EFI U1064 Loss of TSM/TSSM Serial Data Instruments U1097 Loss of Speedometer Serial data Carb U1097 Loss of Speedometer Serial data EFI U1097 Loss of Speedometer Serial data TSM/TSSM U1255 Missing Message at Speedometer EFI U1255 Serial Data Error/Missing Message EFI U1255 Serial Data Error/Missing Message Instruments U1255 Serial Data Error/Missing Message TSM/TSSM U1300 Serial Data Low Carb U1300 Serial Data Low EFI U1300 Serial Data Low Instruments U1300 Serial Data Low TSM/TSSM U1301 Serial Data Open/High Carb U1301 Serial Data Open/High EFI U1301 Serial Data Open/High Instruments U1301 Serial Data Open/High TSM/TSSM 2006 models with 02 sensors (Dynas) P0131 Front 02 sensor lean for any length of time P0151 Rear 02 sensor lean for any length of time Above codes can also be set if 02 sensor fails. ----------------------AFR – Air Fuel Ratio

ATS – Air Temperature Sensor BAS – Bank Angle Sensor CCM – Cruise Control Module CKP – Crank Position Sensor. The CKP generates an “AC signal” which is sent to the ECM where it is used to reference engine position (TDC) and speed. Home position established by taking readings off the 22 teeth on the alternator rotor. DTC – Diagnostic Trouble Codes ECM – Electronic Control Module. (The Computer) Computes the spark advance for proper ignition timing and fuel control based on sensor inputs (from CKP, MAP & TP sensors) and controls the low-voltage circuits for the ignition coils and injectors. The dwell time for the ignition coil is also calculated in the microprocessor and is dependent upon battery voltage. The programmed dwell feature gives adequate spark at all speeds. ECT – Engine Coolant Temperature. Sensor also controls the cooling fan relay that provides 12 Vdc to the fans. EFI – Electronic Fuel Injection EFP – Electronic Fuel Pump ET – Engine Temperature sensor FI – Fuel Injectors FPR – Fuel Pressure regulator IAC – Idle Air Control actuator IAT – Intake Air Temperature sensor ISS – Ion Sensing System…detonation detection MAP – manifold Absolute Pressure sensor. The MAP sensor monitors the intake manifold pressure (vacuum) and sends the information to the ECM. The EMC then adjusts the spark and fuel-timing advance curves for optimum performance.

TP – Throttle Position Sensor TSM/TSSM (Turn Signal/ Turn Signal Security Module) VE – Volume Efficiency VSS – Vehicle Speed Sensor. Used as an input for idle speed control MODELOS 00-03 1 Current 53 ECM flash error 2 Historic 53 ECM flash error 3 Current 54 ECM EEPROM error 4 Historic 54 ECM EEPROM error 5 Current 63 ECM serial data low 6 Current 63 ECM serial data open/high 7 Current 63 TSSM serial data low 8 Current 63 TSSM serial data open/high 9 Current 61 Loss of TSM/TSSM serial data 10 Current 14 Loss of all ECM serial data (state of health) 10 24 Loss of vehicle speed 10 33 Loss of vehicle inhibit motion 10 43 Loss of power train security status 11 Current 33 System relay s open 12 Current 33 System relay coil high/shorted 13 Current 33 System relay coil open/low 14 Current 33 System relay s closed 15 Current 99 Incorrect 16 Current 99 Missing 17 Current 41 CKP sensor intermittent 18 Current 41 CKP sensor synch error 19 Current 11 TP sensor open/low 20 Current 11 TP sensor high 21 Current 12 MAP sensor open/low 22 Current 12 MAP sensor high 23 Current 14 ET sensor voltage low 24 Current 14 ET sensor open/high 25 Current 15 IAT sensor voltage low 26 Current 15 IAT sensor open/high 27 Current 24 Front ignition coil open/low

28 Current 25 Rear ignition coil open/low 29 Current 24 Front ignition coil high/shorted 30 Current 25 Rear ignition coil high/shorted 31 Current 24 Front cylinder combustion intermittent 32 Current 25 Rear cylinder combustion intermittent 33 Current 23 Front injector open/low 34 Current 32 Rear injector open/low 35 Current 23 Front inject or high 36 Current 32 Rear injector high 37 Current 16 Battery volt age low 38 Current 16 Battery volt age high 39 Current 43 VSS sensor low 40 Current 43 VSS sensor high 41 Current N/A (no speedo code for this) Check engine light open/low NO CHECK ENGINE LAMP AT KEY ON or CHECK ENGINE LAMP ON CONTINUOUSLY 42 Current N/A (no speedo code for this) Check engine light high NO CHECK ENGINE LAMP AT KEY ON 43 Current 35 Tachometer low 44 Current 35 Tachometer h igh 45 Current 25 Rear cylinder no combustion 46 Current 24 Front cylinder no combustion 47 Current 34 Loss of idle speed control IDLE AIR CONTROL 48 Current 35 Accelerometer fault 49 Current 34 Starter output high 50 Current 25 Ignition enable output high 51 Current 21 Left turn output fault 52 Current 22 Right turn output fault 53 Current 11 Battery voltage high 54 Current 31 Alarm output low 55 Current 32 Alarm output high 56 Current 41 Ignition switch open/low 57 Current 42 Cam position sensor 57 Historic 63 ECM serial data low 58 Historic 63 ECM serial da ta open/high 59 Historic 63 TSSM serial data low 60 Historic 63 TSSM serial data open/high 61 Historic 61 Loss of TSM/TSSM serial data 62 Historic 14 Loss of all ECM serial data (state of health) 63 Historic 33 System relay s open 64 Historic 33 System relay coil high/shorted 65 Historic 33 System relay coil open/low 66 Historic 33 System relay s closed 67 Historic 99 Incorrect

68 Historic 99 Missing 69 Historic 41 CKP sensor intermittent 70 Historic 41 CKP sensor synch error 71 Historic 11 TP sensor ope n/low 72 Historic 11 TP sensor high 73 Historic 12 MAP sensor open/low 74 Historic 12 MAP sensor high 75 Historic 14 ET sensor voltage low 76 Historic 14 ET sensor open/high 77 Historic 15 IAT sensor voltage low 78 Historic 15 IAT sensor open/high 79 Historic 24 Front ignition coil open/low 80 Historic 25 Rear ignition coil open/low 81 Historic 24 Front ignition coil high/shorted 82 Historic 25 Rear ignition coil high/shorted 83 Historic 24 Front cylinder combustion intermittent 84 Historic 25 Rear cylinder combustion intermittent 85 Historic 23 Front injector open/low 86 Historic 32 Rear injector open/low 87 Historic 23 Front injector high 88 Historic 32 Rear injector high 89 Historic 16 Battery voltage low 90 Historic 16 Battery voltage high 91 Historic 43 VSS sensor lo w 92 Historic 43 VSS sensor high 93 Historic N/A Check engine light open/low NO CHECK ENGINE LAMP AT KEY ON or CHECK ENGINE LAMP ON CONTINUOUSLY 94 Historic N/A Check engine light high NO CHECK ENGINE LAMP AT KEY ON 95 Historic 35 Tachometer low 96 Historic 35 Tachometer high 97 Historic 25 Rear cylinder no combustion 98 Historic 24 Front cylinder no combustion 99 Historic 34 Loss of idle speed control 100 Historic 35 Accelerometer fault 101 Historic 34 Starter output high 102 Historic 25 Ignition enable output high 103 Historic 21 Left turn output fault 104 Historic 22 Right turn output fault 105 Historic 11 Battery voltage high 106 Historic 31 Alarm output low 107 Historic 32 Alarm output high 108 Historic 41 Ignition switc h open/low

Lista ampliada para modelos '08-'09 El sistema para verlos es el mismo que en las '04-up B0563 Battery Voltage High TSM/TSSM B1004 Fuel Level Sending Unit Low Instruments B1005 Fuel Level Sending Unit High/Open Instruments B1006 Accessory Line Overvoltage Instruments B1007 Ignition Line Overvoltage Instruments B1008 Reset Switch Closed Instruments B1121 (TSM) Left Turn Output Fault - (HFSM) Left Turn Output Open B1122 (TSM) Right Turn Output Fault - (HFSM) Right Turn Output Open B1123 (HFSM) Left Turn Output Short to Ground B1124 (HFSM) Right Turn Output Short to Ground B1125 (HFSM) Left Turn Output Short to Battery B1126 (HFSM) Right Turn Output Short to Battery B1131 (HFSM) Alarm Output Low B1131 Alarm Output Low TSM/TSSM B1132 (HFSM) Alarm Output High B1132 Alarm Output High TSM/TSSM B1134 Starter Output High TSM/TSSM B1135 Accelerometer Fault TSM/TSSM B1136 (HFSM) Accelerometer Tip Test Error B1141 (TSM) Ignition Switch Low/Open - (HFSM) Ignition Switch Low/Open B1142 Smart Security System Internal Fault B1143 (HFSM) Security Antenna Short to Ground B1144 (HFSM) Security Antenna Short to Battery B1145 (HFSM) Security Antenna Open B1151 Bank Angle Sensor(BAS) Short to Ground B1151 Sidecar BAS Low TSM/TSSM B1152 Bank Angle Sensor(BAS) Short to Battery B1152 Sidecar BAS High TSM/TSSM B1153 Bank Angle Sensor(BAS) High B1153 Sidecar BAS Out of Range TSM/TSSM B1154 Clutch Switch Input Short to Ground B1155 Neutral Switch Input Short to Battery P0106 MAP Sensor Rate of Range Error Carb P0107 Map Sensor Failed Open/Low Carb P0107 Map Sensor Open/Low EFI

P0108 P0108 P0112 P0113 P0113 P0117 P0118 P0118 P0120 P0122 P0122 P0123 P0123 P0131 P0132 P0134 P0151 P0152 P0154 P0220 P0222 P0223 P0261 P0262 P0263 P0264 P0371 P0372 P0373 P0374 P0374 P0444 P0445 P0501 P0502 P0505 P0562 P0563 P0572 P0577 P0602 P0603 P0603 P0604

Map Sensor Failed High Carb Map Sensor High IAT Voltage Low IAT Sensor Voltage Open/High EFI IAT Voltage Open/High ET Sensor Low ET Sensor High ET Sensor Voltage Open/High EFI TPS1 Range Error TP Sensor Open/Low EFI TPS1 Low TP Sensor High EFI TPS2 High/Open Front Oxygen Sensor Low Front Oxygen Sensor High Front Oxygen Sensor Inactive Rear Oxygen Sensor Low Rear Oxygen Sensor High Rear Oxygen Sensor Inactive TPS2 Range Error TPS2 Low TPS2 High/Open Front Injector Open/Low Front Injector High EFI Rear Injector Open/Low EFI Rear Injector High EFI Crank Position Sensor (CKP) Crank Position Sensor (CKP) CKP Sensor Intermittent CKP Sensor Not Detected Carb CKP Sensor Synch Error EFI Purge Solenoid Open/Low Purge Solenoid High VSS Sensor Low VSS High/Open Loss of Idle Sped Control EFI Battery Voltage Low Battery Voltage High Brake Switch Low Cruise Control Input High Calibration Memory Error Carb ECM EEPROM Memory Error EEPROM Failure Carb RAM Failure Carb

P0605 ECM Flash Error EFI P0605 ECM FLASH Memory Error P0605 Program Memory Error Carb P0607 Converter Error Carb P06415 V+Vref 1 Out Of Range P06515 V+Vref 2 Out Of Range P1001 System Relay Coil Open/Low P1002 System Relay Coil High/Shorted P1003 System relay s open P1004 System Relay s Closed P1009 Incorrect P1010 Missing P1270 TGS Validation Error P1351 Front Ignition Coil Driver Open/Low P1352 Front Ignition Coil Driver High/Shorted P1353 Front Cylinder No Combustion P1354 Rear Ignition Coil Driver Open/Low P1355 Rear Ignition Coil Driver High/Shorted P1356 Rear Cylinder No Combustion P1357 Front Cylinder Combustion Intermittent P1358 Rear Cylinder Combustion Intermittent P1475 Exhaust Actuation Position Error P1477 Exhaust Actuator Open/Low P1478 Exhaust Actuator Shorted/High P1501 Jiffy Stand Sensor Low P1502 Jiffy Stand Sensor High P1510 EFI Limited Performance Mode P1511 EFI Power Management Mode P1512 EFI Forced Idle Mode P1514 Air Flow Fault P1600 EFI Module Processor Internal Error P2100 EFI Motor Circuit Open P2101 EFI Motor Circuit Range Performance (Actuation Error) P2102 EFI Motor Circuit Low P2103 EFI Motor Circuit High P2105 EFI Forced engine shutdown P2107 EFI Module Processor Internal Fault P2119 EFI Motor Throttle Body Range Performance P2122 TGS1 Low/Open P2123 TGS1 High P2127 TGS2 Low/Open P2128 TGS2 High P2135 TPS Correlation Error P2138 TGS Correlation Error (Twist grip sensor)

P2176 EFI Closed Position Not Learned U1016 Loss of ECM Vehicle Speed, Vehicle Inhibit Motion or Powertrain Security Status TSM/TSSM U1016 Loss of ICM/ECM Serial Data Instruments U1064 Loss of TSM/FSFM Serial Data to ICM / ECM U1064 Loss of TSM/TSSM Serial Data Instruments U1097 Loss of Speedometer Serial data Carb U1097 Loss of Speedometer Serial data EFI U1097 Loss of Speedometer Serial Data to ECM U1097 Loss of Speedometer Serial data TSM/TSSM U1255 Missing Message at Speedometer EFI U1255 Serial Data Error U1255 Serial Data Error/Missing Message EFI U1255 Serial Data Error/Missing Message Instruments U1255 Serial Data Error/Missing Message TSM/TSSM U1300 ECM Serial Data Low U1300 Serial Data Low U1300 Serial Data Low Instruments U1300 Serial Data Low TSM/TSSM U1301 Serial Data Open/High Carb U1301 Serial Data Open/High EFI U1301 Serial Data Open/High Instruments U1301 Serial Data Open/High TSM/TSSM
