27b. Selectra Pro Xs 422s2v

Specifications THROUGHPUT • Up to 75 tests per hour. REAGENT AND SAMPLE SYSTEM • One rotor combining both sample and reagent positions; • Positions for 10 ml, 25 ml and 50 ml reagent bottles; • Inner rotor ring: - 15 positions for reagent bottles; - Optionally cooled to approximately 10°C; • Outer rotor ring: - 25 positions for (STAT) samples, controls and calibrators; - 15 positions for reagent bottles at ambient temperature; • All reagent positions can be assigned as R1, R2 and R3; • One needle with level detection, collision protection and integrated mixer; • All sample positions can contain 13 mm Ø primary tubes or sample cups. SAMPLE PREDILUTION • Programmable ratios 1:5 up to 1:100 in one step increments with 3 possible diluents: Pipetting system • 1000 μl Reagent syringe: - R1 volume 110 - 400 μl; - R2 volume 0 - 180 μl; - R3 volume 0 - 180 μl; - Programmable in 1 μl steps; • 100 μl Sample syringe; - Sample volume 1-30 μl; - Programmable in 0.1 μl steps.

CUVETTE ROTOR • Disposable cuvette rotor with 48 cuvettes; • Path length 7 mm; • Minimum measuring volume 220 μl; • Measuring temperature 37˚C, controlled by Peltier elements. LIGHT SOURCE • Quartz-iodine lamp 12V-20W. WAVELENGTH RANGE • 340 - 800 mm; • Optical unit with 8 position filter wheel; • Automatic wavelength selection • 340, 405, 505, 546, 578, 620 600nm standard installed; • One free position; • Other wavelenghts available on request. PHOTOMETRIC RANGE • -0.1 to 3.0 Absorbance; • Resolution 0,001 Abs.

QUALITY CONTROL • Up to 15 different controls can be defined, 3 per test; • Westgard rules; • Levey-Jennings plots; • Quality control statistics.

About ELITech Clinical Systems… ELITech Clinical Systems, the integrated opportunity for clinical laboratories. The acquisition of Vital Scientific in 2007 and the established presence of Seppim

Water Consumption • ~250 mL per hour.

in the ELITech Group enable the combination of broad manufacturing abilities in

STANDARDS • CE-IVD; • CB.

the worldwide clinical chemistry market with a unique platform. ELITech Clinical

DIMENSIONS (BENCH TOP) • 89 x 58 x 60 cm (W x H x D); • No peripherals; • Weight: 67 kg.

Building on the benefits and the strong reputation of proven quality and superior

Interface • Instrument: RS232; • Host: RS232 or Etherhet (T/IP) through LIS-2A protocol.

clinical chemistry. ELITech is now moving towards a system offering and providing Systems connects and reinforces the perfect fit between the Group’s analyzer family and complete range of ready-to-use reagents. results, these systems are backed up by vendor and distributor services that are focused on your kind of laboratory. Welcome to ELITech Clinical Systems the unique platform optimizing your laboratory operations and allowing end s to focus on patient outcomes and patient satisfaction. About Vital Scientific…

ANALYTICAL MODES (SINGLE, DUAL AND TRIPLE REAGENT SYSTEM) • Kinetic measurement with linearity check; • Mono- and bichromatic end point measurement with or without bichromatic reagent blank and/or sample blank correction; • Two point measurement; with or without slope blank; • Graphic plot of all measuring points; • Automatic rerun with sample reduction; • Non-linear calibration curves; • Prozone check for immunology tests; • Cut-off declaration; • Calculated tests.

OPTIONS

With over 50 years experience in the design and manufacture of award winning

BAR CODE READER • Hand held CCD bar code reader (can read all common bar codes) used for test requisition, sample and reagent identification.

scientific and laboratory instrumentation, Vital Scientific has the proven expertise

PRINTER • Printer ed by MS Windows™. PC • State of the art Pentium or equivalent; • Operating System: MS Windows™ XP.

and know-how to respond to your needs. Skilled employees, powerful design tools, precision engineering and a policy for top quality components lie at the very heart of our good manufacturing practices. By accepting nothing but the very best, Vital Scientific - an ISO 9001 compliant

Results laboratories can trust every time and on time

and FDA ed company - is well equipped to meet the highest standards. Over the past decades, Vital Scientific has established a solid distribution network that operates world-wide. More than twenty thousand customers have already experienced the quality, convenience and reliability of our instruments. Local is guaranteed by dedicated and well trained sales and service organisations.

Vital Scientific BV an ELITech Group company

CHEMISTRY workstation

The Selectra ProXS gets you the job done every time and on time! • Discrete Random Access;

• Up to 75 tests per hour;

P.O. Box 100

Telephone + 31 313 430 500

• From 15 to 25 on board chemistries;

• Low reagent consumption;

6950 AC Dieren

Fax + 31 313 427 807

• Low water consumption;

• Bar code reader for patient and

The Netherlands

www.vitalscientific.com

• Refrigerated reagent positions;

reagent identification (optional).

[email protected] Distributor details:

Selectra ProXS™ is a trademark of Vital Scientific BV Windows™ is a trademark of Microsoft

Part.nr: 0200-008-02. Content of this document is subject to change.

XS

S E L E C T R A PRO

The integrated opportunity for clinical laboratories!

Introduction

System overview

Software

The ELITech Clinical System Selectra ProXS builds on

STAT or back-up system. Compact, reliable and easy-

You name it, the Selectra ProXS does it

Simplicity

the benefits, functionality and the robust reputation of

to-use, the Selectra ProXS will help you optimize your

Extensive test menu covers a full range of assays and almost

The simplicity of the software allows a skilled technician

the Selectra Family.

laboratory operations for more value-added tasks and

every application in a convenient and flexible manner. Low

to operate the Selectra ProXS within an hour. Interactive

The Selectra ProXS is a versatile system that functions

improve patient outcomes and patient satisfaction.

volumes, low concentrations, turbidimetrics… the superior

and intuitive routines lead the operator to the results

hassle-free in any laboratory environment to get the job

It is a true cost-effective solution requiring minimal

optical design of the Selectra ProXS offers you the predictable

done right every time and on time! Fast with increased

maintenance and efficient use of consumables. Overall

results and costs you need.

reportable result efficiency, the Selectra ProXS is the

costs will be more predictable and you’ll get greater

The Selectra ProXS also features optimized results with

ideal bench-top for every laboratory as a primary,

value for your investment!

ELITech Clinical Systems liquid stable ready-to-use reagents;

On-Board Quality Control

the perfect match for the Selectra Pro series. Reagents are

QC results are stored in memory and are easily

bar-coded for easy operation and programming.

displayed on the screen. The software calculates the

ELITech Clinical Systems Reagents

quickly. The system maintenance instructions are integrated in the software.

Load sample menu

mean, standard deviation and coefficient of variance. Validation using Westgard rules and a display of the Levey Jenning plot are also included. With the Selectra ProXS your return on investment

Sample of Test Menu

is guaranteed:

Three Reagent System

• Limited training involved;

Enzymes

ALT, AST, ALP, LDH, γ-GT

• Low maintenance required;



Amylase, CK-NAC, CK-MB

Sampling Needle with integrated mixer and

feature makes the Selectra ProXS the ideal platform

• Robust system; minimal productivity issues;

Substrates

Albumin, Uric, Acid, Bilirubin Total,

level sensing

for special applications, which require long incubation

• Efficient reagent usage;



Bilirubin Direct, Cholesterol,

• Low water consumption;



HDL Cholesterol, LDL Cholesterol,

• Short result turnaround time.



Creatinine, Glucose, Total Protein,

Network and Host Facilities



Microprotein, Triglycerides,

The use of an external Operator Console easily enables



Urea UV

the integration of the Selectra ProXS to a local network.

Specific proteins

CRP, APO A1, APO B, Microalbumin,

Further, with dedicated remote control software the



Transferrin, IGA, IGG, IGM,

Selectra ProXS can be fully operated and data can



Prealbumin, Haptoglobin,

be examined from any location. Bi-directional Host

Results you can trust every time and on time!

The software s a “three reagent system”. This Evaluate sample menu

times.

Orosomucoid

Connection allows the system to receive instructions

Electrolytes

Calcium, Chloride, Magnesium,

and to transmit data to the data management system.



Iron, Phosphorus

Other

HbA1C

Disposable cuvettes; no cross contamination

Bar code reader: Test requisition, sample and reagent identification

System parameter menu
