Section 2 INSTALLATION DIAGRAM
MT124-019
2-1
CONTENTS Model 826 DIGITAL CALL SYSTEM
2-2
MT124-019
CONTENTS Model 826 DIGITAL CALL SYSTEM
826
CONTENTS Model 826 DIGITAL CALL SYSTEM
INSTALLATION DIAGRAMS
Diagram
Page
PARALLEL CONNECTIONS RING REPEATER RELAY CONNECTION PARALLEL CONNECTION BETWEEN 2 Model 1131 DOORPHONES OR 2 Model 1130 DOORPHONES ......................................................................................................................................2 - 6 PARALLEL CONNECTION BETWEEN 4 Model 1131 DOORPHONES.............................................................. SV102-1563.......................2 - 7 PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 3 Model 1131 DOORPHONES...... SC101-0709.......................2 - 7 PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 1 Model 1131 DOORPHONE .. SV102-1538.......................2 - 8 PARALLEL CONNECTION BETWEEN 2 SCOUT VIDEO DOORPHONES........................................................ SV102-1539.......................2 - 8 PARALLEL CONNECTION BETWEEN 4 SENTRY VIDEO DOORPHONES..................................................... SC124-0003A .....................2 - 9 PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE....................................................................................................................... SV102-1540.......................2 - 10 PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES..................................................... SV102-1561.......................2 - 10 PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES................................................. SV102-1562.......................2 - 10
DOORPHONE SYSTEMS DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Four-port decoders at each floor. ........................................................................................................................ SC101-0656A .....................2 - 12 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS Four-port decoders at each floor. ......................................................................................................................... SC101-0658.......................2 - 13 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Connections at each floor via single-port decoders.............................................................................................. SC124-0019.......................2 - 14 EXAMPLE OF CONNECTIONS ON A SINGLE RISER CABLE WITH OVER 20 DECODERS DIVIDED INTO TWO GROUPS, EACH WITH A POWER SUPPLY UNIT........................................................... SC101-0665.......................2 - 15 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 2 ENTRANCE MODULES FOUR-PORT DECODERS AT EACH FLOOR..................................................................................................... SC101-0657.......................2 - 16 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.................................. SC101-0666.......................2 - 17 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 99 apartment stations. Modules configured for TYPE 2.................................... SC101-0667.......................2 - 18 DOORPHONES ON UP TO 899 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 main entrance module. Each riser cable can have up to 9 apartment stations. Modules configured for TYPE 3...................................... SC101-0668.......................2 - 19 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 160 apartment stations. Modules and digitizers configured for TYPE 1. .......... SC101-0669.......................2 - 20 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 10 apartment stations. Modules and digitizers configured for TYPE 2. ............ SC101-0670.......................2 - 21 DOORPHONE BRANCH CONNECTIONS WITH FOUR-PORT DECODERS Ref. 826/23.............................................................................2 - 22 DOORPHONE CONNECTIONS WITH SINGLE-PORT DECODERS .............................................................................................................2 - 23 DOORPHONE CONNECTIONS TO 1 ENTRANCE MODULE Doorphones are equipped with single-port decoders. .......................................................................................... SC101-1061.......................2 - 24
MT124-019
2-3
826
Model 826 DIGITAL CALL SYSTEM DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 ENTRANCE MODULE. FOUR-PORT DECODERS AT EACH FLOOR..................................................................................................... SC101-0660.......................2 - 26 DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS........................................................................ SC101-0662.......................2 - 27 DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary entrance module. Systems can have up to 9, up to 89 or up to 899 riser cables, configured for TYPE 1, 2 or 3. ........................................................................2 - 28 DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary outdoor station equipped with conventional entrance and digitizers. Systems can have up to 9 or up to 89 riser cables, configured for TYPE 1 or 2. .............................................................................................2 - 29 DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR .............................................................................................................................2 - 30 DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE CONNECTIONS AT EACH FLOOR VIA SINGLE-PORT DECODERS Ref. 826/31........................................................................................2 - 31 DOORPHONE CONNECTIONS WITH SECONDARY OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR .............................................................................................................................2 - 32
VIDEO DOORPHONE SYSTEMS VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE FOUR-PORT DECODERS AT EACH FLOOR.................................................................................................... SV102-1511A .....................2 - 34 VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE VIDEO DOORPHONES EQUIPPED WITH SINGLE-PORT DECODER BRACKET .......................................... SV102-1515A .....................2 - 35 VIDEO DOORPHONES CONNECTED TO 1 VIDEO OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS AT EACH FLOOR.................................................................................................... SV102-1514A .....................2 - 36 VIDEO DOORPHONES CONNECTED TO 2 VIDEO ENTRANCE MODULES WITH AUTOMATIC SWITCHING FOUR-PORT DECODERS AT EACH FLOOR............................................... SV124-0034.......................2 - 37 VIDEO DOORPHONES CONNECTED TO 1 GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 VIDEO ENTRANCE MODULE GUARD DOOR SWITCHBOARD STATION VIDEO DOORPHONE INTERCEPTS OUTSIDE CALLS IN DAY SERVICE ......... SV102-1513B .....................2 - 38 VIDEO DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN VIDEO ENTRANCE MODULE Each riser cable is connected to a secondary video entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1................................. SV102-1516A .....................2 - 39
2-4
MT124-019
CONTENTS Model 826 DIGITAL CALL SYSTEM
CONTENTS
826
PARALLEL CONNECTIONS
MT124-019
2-5
PARALLEL CONNECTIONS
826
RING REPEATER RELAY CONNECTION PARALLEL CONNECTION BETWEEN 2 Model 1131 DOORPHONES OR 2 Model 1130 DOORPHONES
ONE RING REPEATER RELAY CONNECTED IN PARALLEL WITH Model 1131 or Model 1132 DOORPHONE TO CONTROL A SUPPLEMENTARY RINGER
Model 1131 - 1132 DOORPHONES
DIAGRAM SC101-0712
FOUR-PORT DECODER Ref. 826/23
Ringer 12 V~ RELAY Ref. 788/21 MAINS~
TRANSFORMER Ref. 9000/230
PARALLEL CONNECTION BETWEEN 2 Model 1131 / 1132 DOORPHONES
Model 1131Mod. - 1132 DOORPHONES CITOFONI 1131-1132
DIAGRAM SC101-0707
NOTE
FOUR-PORT DECODER Ref. 826/23
NOTE
FOUR-PORT DECODER Ref. 826/23
PARALLEL CONNECTION BETWEEN 2 Model 1130 DOORPHONES
DIAGRAM SC101-0708
Model 1131 - 1132 DOORPHONES
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
2-6
MT124-019
Model 1131/1132 DOORPHONES
MT124-019 FOUR-PORT DECODER Ref. 826/23
MAINS ~
SC101-0709
POWER SUPPLY UNIT Ref. 786/1 - 12 VA Ref. 786/14 - 28 VA
RELAY Ref. 788/21
Output power from decoder terminal CA is sufficient to actuate ringer on only 2 parallelconnected doorphones. For the remaining 3 or 4 doorphones, a supplementary power supply controlled by ring repeater relay must be installed.
NOTE
POWER SUPPLY UNIT Ref. 786/1 - 12 VA Ref. 786/14 - 28 VA
Model 1131/1132 DOORPHONES
SCOUT / WINFLAT VIDEO DOORPHONE
FOUR-PORT DECODER Ref. 826/23
826
PARALLEL CONNECTION BETWEEN 1 SCOUT / WINFLAT VIDEO DOORPHONE AND 3 MODEL 1131 / 1132 DOORPHONES
SV102-1563
PARALLEL CONNECTION BETWEEN 4 MODEL 1131 / 1132 DOORPHONES
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
2-7
PARALLEL CONNECTIONS
MAINS ~ RELAY Ref. 788/21
NOTE
PARALLEL CONNECTION BETWEEN 4 Model 1131 DOORPHONES PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 3 Model 1131 DOORPHONES
PARALLEL CONNECTIONS
826
PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 1 Model 1131 DOORPHONE PARALLEL CONNECTION BETWEEN 2 SCOUT VIDEO DOORPHONES
PARALLEL CONNECTION BETWEEN 1 SCOUT / WINFLAT VIDEO DOORPHONE AND 1 MODEL 1131 / 1132 DOORPHONE
SV102-1538 SCOUT / WINFLAT VIDEO DOORPHONE
NOTE FOUR-PORT DECODER Ref. 826/23
Model 1131/1132 DOORPHONE
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
PARALLEL CONNECTION BETWEEN 2 SCOUT / WINFLAT VIDEO DOORPHONES
SV102-1539 SCOUT / WINFLAT VIDEO DOORPHONE
NOTE The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
FOUR-PORT DECODER Ref. 826/23 POWER SUPPLY UNIT Ref. 789/2
MAINS ~
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station.
2-8
MT124-019
826
SC124-0003A DIGITAL + VIDEO SYSTEM RISER CABLE
FOUR-PORT DECODER Ref. 826/34
POWER SUPPLY UNIT Ref. 789/3
LINE ~ NOTE &
LINE ~ NOTE & POWER SUPPLY UNIT Ref. 789/2 RING REPEATER RELAY Ref. 788/21
TONE GENERATOR Ref. 787/1
VIDEO SPLITTER Ref. 1794/4
MT124-019
TRANSFORMER Ref. 9000/230
2-9
PARALLEL CONNECTIONS
PARALLEL CONNECTION BETWEEN 4 SENTRY VIDEO DOORPHONES
PARALLEL CONNECTIONS
826
PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES
PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE
SV102-1540
RANGER or EXPLORER VIDEO DOORPHONE
NOTE FOUR-PORT DECODER Ref. 826/23
Model 1130 DOORPHONE
PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES
SV102-1561 RANGER VIDEO DOORPHONE
The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
NOTE FOUR-PORT DECODER Ref. 826/23
POWER SUPPLY UNIT Ref. 789/2
MAINS ~
PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES
SV102-1562 EXPLORER VIDEO DOORPHONE
The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
NOTE POWER SUPPLY UNIT Ref. 789/2
FOUR-PORT DECODER Ref. 826/23
MAINS ~
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station.
2 - 10
MT124-019
826
DOORPHONE SYSTEMS
MT124-019
2 - 11
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Four-port decoders at each floor.
SC101-0656A TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
ENTRANCE MODULE Ref. 826/65
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Door lock release
CODES 1 ÷ 9999
ELECTRIC LOCK
2 - 12
NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
MT124-019
826
Four-port decoders at each floor.
SC101-0658
TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
NOTE: Digitizers must be configured for TYPE 1 and may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). It is advisable not to use more than 10 digitizers in series for a maximum of 160 doorphones. Up to 64 apartment stations can be served with 4 digitizers as illustrated in the diagram. Each digitizer can manage 16 doorphones and can thus be programmed with the following codes: 1 to 16, 101 to 116, 201 to 216 - - 901 to 916, 1001 to 1016 - - 9901 to 9916.
FOUR-PORT DECODER Ref. 826/23
NOTE: Power supply unit Ref. 826/25 can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release
ELECTRIC LOCK
MT124-019
ENTRANCE AND SPEAKER UNIT Ref. 5150/500 or ref. 824/500 for Kombi series
2 - 13
DOORPHONE SYSTEMS
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Connections at each floor via single-port decoders.
SC124-0019 TO SUBSEQUENT DOORPHONES AND DECODERS
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
LINE ~ NOTE &
POWER SUPPLY UNIT Ref. 826/25
CODES 1 — 9999 Door lock release ENTRANCE MODULE Ref. 826/6 ELECTRIC LOCK
2 - 14
MT124-019
826
SC101-0665 SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23 2ND GROUP WITH UP TO 30 DECODERS AND UP TO 120 DOORPHONES.
MAINS ~
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
SUBSEQUENT DECODERS
1ST GROUP WITH UP TO 20 DECODERS AND UP TO 80 DOORPHONES. MAINS
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 1ST GROUP AND ENTRANCE MODULE
ENTRANCE MODULE Ref. 826/55 Kombi Series
Door lock release CODES 1 TO 9999
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1).
ELECTRIC LOCK
MT124-019
2 - 15
DOORPHONE SYSTEMS
EXAMPLE OF CONNECTIONS ON A SINGLE RISER CABLE WITH OVER 20 DECODERS DIVIDED INTO TWO GROUPS, EACH WITH A POWER SUPPLY UNIT
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 2 ENTRANCE MODULES FOUR-PORT DECODERS AT EACH FLOOR
SC101-0657
TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 2
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 1 AND RISER CABLE
NOTE: The two entrance modules must be configured for TYPE 1 and must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1).
ENTRANCE MODULE Ref. 826/65 Kombi Series
Door lock release
Door lock release
NOTE: Several power supply units are required. One unit supplies one entrance module and the riser cable with a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The second entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
CODES 1 to 9999
ELECTRIC LOCK
2 - 16
ELECTRIC LOCK
MT124-019
MT124-019
Door lock release
UP TO 999 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
TYPE 1 UP TO 9 RISER CABLES
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
MAINS ~
SECONDARY ENTRANCE CODES 1001 to 1999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
Door lock release
MAIN ENTRANCE CODES 1001 to 9999 8991 MAX. (999 x 9 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
Door lock release
SUBSEQUENT RISER CABLES CODES 3 = 3001 to 3999 4 = 4001 to 4999 5 = 5001 to 5999 6 = 6001 to 6999 7 = 7001 to 7999 8 = 8001 to 8999
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: All entrance modules must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
MAINS ~
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
MAINS ~
SECONDARY ENTRANCE CODES 2001 ÷ 2999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
Door lock release
Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.
826
SC101-0666
2 - 17
DOORPHONE SYSTEMS
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
MAINS ~
SECONDARY ENTRANCE CODES 9001 ÷ 9999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
2 - 18
Door lock release
MAINS ~
Door lock release
MAIN ENTRANCE CODES 1101 to 9999 8811 MAX. (99 x 89 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
SECONDARY ENTRANCE CODES 1101 to 1199
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
UP TO 99 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
TYPE 2 UP TO 89 RISER CABLES
MAINS ~
Door lock release
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
SECONDARY ENTRANCE CODES 9901 to 9999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: The first two digits identify the riser cable (thousands and hundreds places). Codes 1, 2 — 10 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
NOTE: All entrance modules must be configured for TYPE 2. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
SUBSEQUENT RISER CABLES CODES 3 = 1301 to 1399 4 = 1401 to 1499 5 = 1501 to 1599 6 = 1601 to 1699 7 = 1701 to 1799 8 = 1801 to 1899 9 = 1901 to 1999 10 = 2001 to 2099 11 = 2101 to 2199 " " 89 = 2101 to 9999
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
MAINS ~
MAINS ~
SECONDARY ENTRANCE CODES 1201 to 1299
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONE SYSTEMS
826 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 99 apartment stations. Modules configured for TYPE 2.
SC101-0667
MT124-019
MT124-019
Door lock release
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
Door lock release
MAIN ENTRANCE CODES 1011 to 9999 8091 MAX. (9 x 899 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
1001 to 1999
MAINS ~
SECONDARY ENTRANCE CODES 1011 to 1019
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
UP TO 9 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: The first three digits identify the riser cable (thousands, hundreds and tens places). Codes 1, 2 – 100 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
MAINS ~
Each riser cable is connected to 1 main entrance module. Each riser cable can have up to 9 apartment stations. Modules configured for TYPE 3.
826
SC101-0668
2 - 19
DOORPHONE SYSTEMS
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
SECONDARY ENTRANCE CODES 9991 to 9999
ELECTRIC LOCK
Door lock release
TO RISER CABLE
ENTRANCE MODULE Ref. 826/55 Kombi Series
NOTE: All entrance modules must be configured for TYPE 3. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
SUBSEQUENT RISER CABLES CODES 3 = 1031 to 1039 4 = 1041 to 1049 5 = 1051 to 1059 6 = 1061 to 1069 7 = 1071 to 1079 8 = 1081 to 1089 9 = 1091 to 1099 10 = 1101 to 1199 I I 99 = 1991 to 1199 100 = 2001 to 2009 I I 899 = 9991 to 9999
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
TYPE 3 UP TO 89 RISER CABLES
MAINS ~
MAINS ~
SECONDARY ENTRANCE CODES 1021 to 1029
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONES ON UP TO 899 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
MAIN ENTRANCE
ELECTRIC LOCK
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
MAINS ~
7916 8901
6916 7901
5916 6901
4916 5901
3916 4901
9016 9116 9916 (Up to 10 digitizers)
SECONDARY ENTRANCE CODES 9001 9101 9901
MAIN ENTRANCE WITH ENTRANCE MODULE
UP TO 9 RISER CABLES
TYPE 1
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
UP TO 160 DOORPHONES PER RISER CABLE
SECONDARY ENTRANCES WITH CONVENTIONAL ENTRANCE AND DIGITIZER
8016 8116 8916 Max 1440 (160x9 riser cable)
7116 8101
7016 8001
8 =
6 = 6116 7101
5116 6101
5016 6001 6016 7001
4116 5101
4016 5001
5 =
7 =
3116 4101
3016 4001
4 =
SUBSEQUENT RISER CABLES CODES 3 = 3001 3101 3901
DIGITIZER Ref. 826/16
TO RISER CABLE
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
NOTE: All entrance modules and digitizers must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
2016 2116 2916 (Up to 10 digitizers)
1016 1116 1916 (Up to 10 digitizers)
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
SECONDARY ENTRANCE CODES 2001 2101 2901
Door lock release
SECONDARY ENTRANCE CODES 1001 1101 1901
ENTRANCE MODULE Ref. 826/55 Kombi Series
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
Door lock release
2 - 20 Door lock release
DOORPHONE SYSTEMS
826 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 160 apartment stations. Modules and digitizers configured for TYPE 1.
SC101-0669
MT124-019
Door lock release
MAIN ENTRANCE
ELECTRIC LOCK
SECONDARY ENTRANCE CODES 1101 to 1116
ENTRANCE MODULE Ref. 826/55 Kombi Series
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
Door lock release
Door lock release
MAINS ~
SECONDARY ENTRANCE CODES 9901 to 1916
MAIN ENTRANCE WITH ENTRANCE MODULE
UP TO 9 RISER CABLES
TYPE 2
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 2
TO RISER CABLE
UP TO 160 DOORPHONES PER RISER CABLE
NOTE: The first two digits identify the riser cable (thousands and hundreds places). Codes 1, 2 – 10 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
NOTE: All entrance modules and digitizers must be configured for TYPE 2. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 10 apartment stations. Modules and digitizers configured for TYPE 2.
826
SC101-0670
2 - 21
DOORPHONE SYSTEMS
SECONDARY ENTRANCES WITH CONVENTIONAL ENTRANCE AND DIGITIZER
89 = 9901 to 9916 Max 1424 (16 x 89 riser cable)
SUBSEQUENT RISER CABLES CODES 3 = 1301 to 1316 4 = 1401 to 1416 5 = 1501 to 1516 6 = 1601 to 1616 7 = 1701 to 1716 8 = 1801 to 1816 9 = 1901 to 1915 10 = 2001 to 2016 11 = 2101 to 2116
MAINS ~
DIGITIZER Ref. 826/16
NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 4 connected decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
SECONDARY ENTRANCE CODES 1201 to 1216
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 2
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
Door lock release
MT124-019
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
DOORPHONE SYSTEMS
826
DOORPHONE BRANCH CONNECTIONS WITH FOUR-PORT DECODERS Ref. 826/23
For diagrams SC101-0666, SC101-0667, SC101-0668, SC101-0669, SC101-0670
TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
FROM SECONDARY ENTRANCE
2 - 22
MT124-019
826
For diagrams SC101-0666, SC101-0667, SC101-0668, SC101-0669, SC101-0670
TO SUBSEQUENT DOORPHONES AND DECODERS
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
FROM SECONDARY ENTRANCE MODULE
MT124-019
2 - 23
DOORPHONE SYSTEMS
DOORPHONE CONNECTIONS WITH SINGLE-PORT DECODERS
DOORPHONE SYSTEMS
826
DOORPHONE CONNECTIONS TO 1 ENTRANCE MODULE Doorphones are equipped with single-port decoders.
SC101-1061 TO SUBSEQUENT DOORPHONES WITH DECODERS
DOORPHONES WITH SINGLE-PORT DECODER Model. 826
Model 1132 DOORPHONE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
ENTRANCE MODULE Ref. 826/65 Kombi series
Door lock release
CODES 1 to 9999
ELECTRIC LOCK
2 - 24
MT124-019
826
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
MT124-019
2 - 25
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 ENTRANCE MODULE. FOUR-PORT DECODERS AT EACH FLOOR
826
SC101-0660 TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
The guard door switchboard station must be configured for TYPE 1. The entrance module may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) of for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Two power supply units are required. One unit supplies one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
FOUR-PORT DECODER Ref. 826/23
The guard door switchboard station must be supplied by means of the other power supply unit. NOTE: In Day service, the guard door switchboard station intercepts all calls from the entrance module. To disable call interception, connect terminal + 24 from the entrance module to switchboard station terminal +24N instead of power supply unit terminal +24. Under these conditions, the entrance module is fully disabled (entrance door open at all times). The switchboard station can also be programmed for direct communication between entrance module and apartment stations: in this case, all calls from entrance modules will be sent directly to apartment stations in both Day and Night service.
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
MAINS ~
POWER SUPPLY UNIT CONNECTIONS FOR Ref. 826/25 FOR ENTRANCE MODULE DISABLING CALL AND RISER CABLE INTERCEPTION
MAINS ~
ENTRANCE MODULE Ref. 826/11 Model 625 or Ref. 826/55 Kombi Series
Door lock release CODES 1 to 9999
ELECTRIC LOCK
2 - 26
MT124-019
826
SC101-0662 TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
NOTE: Digitizers and guard door switchboard station must be configured for TYPE 1. Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). It is advisable not to use more than 10 digitizers in series for a maximum of 160 doorphones. Up to 64 apartment stations can be served with 4 digitizers as illustrated in the diagram. Each digitizer can manage 16 doorphones and can thus be programmed with the following codes: 1 to 16, 101 to 116, 201 to 216 - - 901 to 916, 1001 to 1016 - - 9901 to 9916.
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
NOTE: Two power supply units are required. One unit can supply can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The guard door switchboard station must be supplied by means of the second power supply unit.
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR DIGITIZERS AND RISER CABLE
MAINS ~
NOTE: The maximum number of devices that can be connected in a system must under no circumstances exceed 400. Here, the term device is used to designate any item connected to data line D, including four-port decoders, entrance modules, power supply units, guard door switchboard station, digitizers and so forth. Doorphones and video doorphones are not included in the total of 400 devices. DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release
ELECTRIC LOCK
MT124-019
ENTRANCE AND SPEAKER UNIT Ref. 5159/500 or Ref. 824/500 for Kombi series
2 - 27
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary entrance module. Systems can have up to 9, up to 89 or up to 899 riser cables, configured for TYPE 1, 2 or 3.
SUBSEQUENT RISER CABLES
UP TO 899 RISER CABLES TYPE 3 UP TO 9 DOORPHONES PER RISER CABLE
CODES 1011 to 1019
CODES 1021 to 1029
Diagram SC101-0672 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 3. NOTE: The first three digits identify the riser cable (thousands, hundreds and tens places).
= = = = = = = =
CODES 1031 to 1041 to 1051 to 1061 to 1071 to 1081 to 1091 to 1101 to
CODES 1101 to 1199
CODES 1201 to 1299
Diagram SC101-0704 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 2. NOTE: The first two digits identify the riser cable (thousands and hundreds places).
99 = 1991 100 = 2001
to to
1199 2009
899 = 9991
to
9999
3 4 5 6 7 8 9 10 11
= = = = = = = = =
CODES 1301 to 1401 to 1501 to 1601 to 1701 to 1801 to 1901 to 2001 to 2101 to
89 = 9901
CODES 1001 to 1999
CODES 2001 to 2999
Diagram SC101-0671 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 1.
TO RISER CABLE
NOTE: The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0). NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module and the guard door switchboard station must each be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units. If an electronic directory is installed on the main entrance module, it can be supplied by the same power supply unit. Any electronic directories installed on secondary entrance s can be supplied by the same power supply unit as the riser cable, taking care not to exceed the maximum permissible consumption (in this case, up to 12 decoders can be used).
CODES 9991 to 9999
to
1339 1449 1559 1669 1779 1889 1999 2009 2109
CODES 9901 to 9999
9999
SUBSEQUENT RISER CABLES
UP TO 9 RISER CABLES TYPE 1 UP TO 999 DOORPHONES PER RISER CABLE
1039 1049 1059 1069 1079 1089 1099 1109
SUBSEQUENT RISER CABLES
UP TO 89 RISER CABLES TYPE 2 UP TO 99 DOORPHONES PER RISER CABLE
3 4 5 6 7 8 9 10
3 4 5 6 7 8
= = = = = =
CODES 3001 to 4001 to 5001 to 6001 to 7001 to 8001 to
3999 4999 5999 6999 7999 8999
TO RISER CABLE
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
CODES 9001 to 9999
TO RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
MAINS ~
ENTRANCE MODULE Ref. 826/55 Kombi Series Door lock release
ELECTRIC LOCK MAIN ENTRANCE
2 - 28
MT124-019
826
Each riser cable is connected to a secondary outdoor station equipped with conventional entrance and digitizers. – Systems can have up to 9 or up to 89 riser cables, configured for TYPE 1 or 2.
UP TO 89 RISER CABLES TYPE 2 CODES 1101 to 1116
UP TO 16 DOORPHONES FOR RISER CABLE
CODES 1216 to 1216
SUBSEQUENT RISER CABLES 3 4 5 6 7 8 9 10 11
Diagram SC101-0674 NOTE: The main entrance module, digitizers and guard door switchboard station must be configured for TYPE 2. NOTE: The first two digits identify the riser cable (thousands and hundreds places).
= = = = = = = = =
CODES 1301 to 1401 to 1501 to 1601 to 1701 to 1801 to 1901 to 2001 to 2101 to
89 = 9901
to
CODES 9901 to 9916
1316 1416 1516 1616 1716 1816 1916 2016 2116 9916
Max 1424 (16 x 89 riser cables) SUBSEQUENT RISER CABLES
UP TO 9 RISER CABLES TYPE 1
CODES 1001 1101 1901
CODES 2001 2101 2901
UP TO 160 DOORPHONES FOR RISER CABLE
1016 1116 1916 Up to 10 digitizers
2016 2116 2916 Up to 10 digitizers
Diagram SC101-0673 NOTE: The main entrance module, digitizers and guard door switchboard station must be configured for TYPE 1.
TO RISER CABLE
CODES 3 = 3001 3101
3901
3016
3116
3916
4 = 4001
4101
4901
4016
4116
4916
5 = 5001
5101
5901
5016
5116
5916
6 = 6001
6101
6901
6016
6116
6916
7 = 7001
7101
7901
7016
7116
7916
8 = 8001
8101
8901
8016
8116
8916
TO RISER CABLE
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
CODES 9001 9101 9901 9016 9116 9916 Up to 10 digitizers
TO RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
NOTE: The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The main entrance module and the guard door switchboard station must each be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units. If an electronic directory is installed on the main entrance module, it can be supplied by the same power supply unit.
MAINS ~
MAINS ~
ENTRANCE MODULE Ref. 826/55 Kombi Series Door lock release
ELECTRIC LOCK MAIN ENTRANCE
MT124-019
2 - 29
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR
For diagrams SC101-0671, SC101-0704, SC101-0672. TO SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23
ENTRANCE MODULE Ref. 826/65 Kombi Series
Door lock release
ELECTRIC LOCK SECONDARY ENTRANCE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 899
FROM MAIN LINE
2 - 30
MT124-019
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE CONNECTIONS AT EACH FLOOR VIA SINGLE-PORT DECODERS Ref. 826/31
826
For diagrams SC101-0671, SC101-0704, SC101-0672
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
ENTRANCE MODULE Ref. 826/65
Door lock release CODES 1 – 9999
ELECTRIC LOCK
SECONDARY ENTRANCE
LINE ~ NOTE &
POWER SUPPLY UNIT Ref. 826/25 FOR SECONDARY ENTRANCE MODULE AND RISER CABLE FROM MAIN LINE
MT124-019
2 - 31
DOORPHONE CONNECTIONS WITH SECONDARY OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR
For diagrams SC101-0673, SC101-0674
TO SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23
DIGITIZER Ref. 826/16
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~. DIGITIZERS For Type 2 systems with up to 89 riser cables, a single digitizer can be installed for a maximum of 16 apartment stations.
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 9
For Type 1 systems with up to 9 riser cables, a maximum of 10 digitizers can be installed on each riser cable.
Door lock release
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
Each digitizer can manage 16 apartment stations. POSSIBLE CODES - 1st digitizer 1 to 16 - 2nd digitizer 101 to 116 - 3rd digitizer 201 to 216 - 4th digitizer 301 to 316 - 10th digitizer 901 to All codes must be preceded by the number indicating the thousands place.
916
ELECTRIC LOCK SECONDARY ENTRANCE
FROM MAIN LINE
2 - 32
ENTRANCE AND SPEAKER UNIT Ref. 5159/500 or Ref. 824/500 for Kombi series
MT124-019
826
VIDEO DOORPHONE SYSTEMS
MT124-019
2 - 33
VIDEO DOORPHONE SYSTEMS
826
VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE FOUR-PORT DECODERS AT EACH FLOOR
SV102-1511A TO SUBSEQUENT DECODERS
VIDEO DOORPHONES
VIDEO DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
VIDEO SPLITTER Ref: 1794/4
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
VIDEO DOORPHONES
CCD DOOR CAMERA UNIT Scout 4.5
Direct vision version Video doorphone Ref. 1204/1 + Bracket Ref. 1204/90 + Back box Ref. 7108/100 or Tabletop conversion kit Ref.1204/92 Reflex vision version Video doorphone Ref. 1204/10 + Bracket Ref. 1204/90
Door lock release
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
2 - 34
ELECTRIC LOCK
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
MT124-019
826
SV102-1515A TO SUBSEQUENT VIDEO DOORPHONES
SCOUT VIDEO DOORPHONE ON BRACKET WITH SINGLE-PORT DECODER
VIDEO DOORPHONES
Scout 4.5”
Direct vision version Video doorphone Ref. 1204/1 + Bracket Ref. 1204/94 + Back box Ref. 7108/100 or Tabletop conversion kit Ref.1204/92 Reflex vision version Video doorphone Ref. 1204/10 + Bracket Ref. 1204/94
Key • on video doorphones is configured internally so as to call the guard door switchboard, if provided. Key ♦ is provided for other uses as desired. NOTE: Bracket with single-port is designed only for use with electronic call tone signaling Scout video doorphones. NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 50).
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
Door camera
CCD DOOR CAMERA UNIT
Door lock release ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999 ELECTRIC LOCK
MT124-019
2 - 35
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE VIDEO DOORPHONES EQUIPPED WITH SINGLE-PORT DECODER BRACKET
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 1 VIDEO OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS AT EACH FLOOR
826
SV102-1514A
TO SUBSEQUENT DECODERS
VIDEO DOORPHONES
VIDEO DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
NOTE: Digitizers must be configured for TYPE 1 and may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
VIDEO SPLITTER Ref: 1794/4
MAINS ~
NOTE: Power supply unit Ref. 826/25 can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together.
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release NOTE
Door camera CCD DOOR CAMERA UNIT
ELECTRIC LOCK
ENTRANCE AND SPEAKER UNIT Ref. 5150/500 or ref. 824/500 for Kombi series OUTDOOR STATION WITH DOOR CAMERA UNIT AND CONVENTIONAL ENTRANCE
2 - 36
MT124-019
826
SV124-0034 TO VIDEO DOORPHONE RISER CABLE TO SUBSEQUENT DECODERS
VIDEO SPLITTER Ref: 1794/4
LINE ~ NOTE &
LINE ~ NOTE &
LINE ~ NOTE &
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE <>
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 1 AND RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 2
RELAY Ref. 1032/9 NOTE ><
Door camera
DOOR CAMERA UNIT
Door camera
DOOR CAMERA UNIT
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
ENTRANCE MODULES Ref. 826/65
Door lock release
ELECTRIC LOCK 1ST VIDEO ENTRANCE
MT124-019
ENTRANCE MODULES Ref. 826/65
Door lock release
ELECTRIC LOCK 2ND VIDEO ENTRANCE
2 - 37
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 2 VIDEO ENTRANCE MODULES WITH AUTOMATIC SWITCHING FOUR-PORT DECODERS AT EACH FLOOR
VIDEO DOORPHONE SYSTEMS
826
VIDEO DOORPHONES CONNECTED TO 1 GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 VIDEO ENTRANCE MODULE GUARD DOOR SWITCHBOARD STATION VIDEO DOORPHONE INTERCEPTS OUTSIDE CALLS IN DAY SERVICE
SV102-1513B TO VIDEO DOORPHONE RISER CABLE TO SUBSEQUENT DECODERS
SWITCHBOARD STATION VIDEO DOORPHONE
VIDEO SPLITTER Ref: 1794/4
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
MAINS ~ MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR GUARD DOOR SWITCHBOARD STATION
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
DOOR CAMERA UNIT
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE
Door camera
NOTE: The entrance module and guard door switchboard station must be configured for TYPE 1. The entrance module may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
Door lock release
ELECTRIC LOCK
2 - 38
MAINS ~
The guard door switchboard station must be supplied by means of its own power supply unit. INSTRUCTIONS: In Day service, guard door switchboard station intercepts all calls from the video entrance module. The switchboard attendant uses the station handset to establish voice communication with the visitor, and the video doorphone to view the visitor. Apartment station video doorphones use the • key to call the switchboard, and the XXX key to release electric door locks. To disable call interception, connect entrance module terminal + 24 to switchboard station terminal +24N instead of riser cable power supply unit terminal +24. Under these conditions, calls from the entrance module will not cause the guard door switchboard station to ring during Day service (entrance door open at all times). For systems of this kind, no video doorphone is installed at the guard door station.
MT124-019
VIDEO SPLITTER Ref: 1794/4
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: All entrance modules must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
NOTE: To use output % on video splitters, remove the 75 W resistor protruding from printed circuit.
Door lock release
MAINS ~
COMMON VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
MAINS ~
TWO VIDEO SPLITTER Ref: 1794/4 NOTE
DOOR CAMERA UNIT
MAIN VIDEO ENTRANCE CODES 1001 to 9999 8991 MAX. (999 X 9 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/65
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 1
ENTRANCE MODULE Ref. 826/65
SECONDARY VIDEO ENTRANCE CODES 1001 to 1999
ELECTRIC LOCK
DOOR CAMERA UNIT
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
Door camera
RELAY Ref. 1032/9 NOTE
VIDEO SPLITTER Ref: 1794/4
Door camera
DOOR CAMERA UNIT
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN MODULE
MAINS ~
SECONDARY VIDEO ENTRANCE CODES 2001 to 2999
Door lock release
MAINS ~
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 9
Each riser cable is connected to a secondary video entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.
826
SV102-1516A
2 - 39
VIDEO DOORPHONE SYSTEMS
ENTRANCE MODULE Ref. 826/65
POWER SUPPLY UNIT Ref. 789/2
VIDEO SPLITTER Ref: 1794/4
SECONDARY VIDEO ENTRANCE CODES 9001 to 9999
RELAY Ref. 1032/9
LINE ~
DOOR CAMERA UNIT
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
RISER CABLE 3 CODES 9001 to 9999
MAINS ~
ELECTRIC LOCK
RELAY Ref. 1032/9 NOTE
TO THE TO THE FOLLOWING FOLLOWING MONITOR DISTRIBUTION
SUBSEQUENT RISER CABLES CODES 3-4-5-6-7-8 3001 to 3999 4001 to 4999 5001 to 5999 6001 to 6999 7001 to 7999 8001 to 8999 VIDEO SPLITTER Ref. 1794/4
EXAMPLE OF VIDEO SPLITTER CONNECTION BY MEANS OF LOCAL POWER SUPPLY UNIT Ref. 789/2 Local power supply unit Ref. 789/2 is essential in cases where the number of video splitters in the entire system exceeds 10.
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 2
ENTRANCE MODULE Ref. 826/65
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
ELECTRIC LOCK
RELAY Ref. 1032/9 NOTE
RISER CABLE 2 CODES 2001 to 2999
Door camera
MT124-019 Door camera
RISER CABLE 1 CODES 1001 to 1999
VIDEO DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN VIDEO ENTRANCE MODULE
MT124-019
2-1
CONTENTS Model 826 DIGITAL CALL SYSTEM
2-2
MT124-019
CONTENTS Model 826 DIGITAL CALL SYSTEM
826
CONTENTS Model 826 DIGITAL CALL SYSTEM
INSTALLATION DIAGRAMS
Diagram
Page
PARALLEL CONNECTIONS RING REPEATER RELAY CONNECTION PARALLEL CONNECTION BETWEEN 2 Model 1131 DOORPHONES OR 2 Model 1130 DOORPHONES ......................................................................................................................................2 - 6 PARALLEL CONNECTION BETWEEN 4 Model 1131 DOORPHONES.............................................................. SV102-1563.......................2 - 7 PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 3 Model 1131 DOORPHONES...... SC101-0709.......................2 - 7 PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 1 Model 1131 DOORPHONE .. SV102-1538.......................2 - 8 PARALLEL CONNECTION BETWEEN 2 SCOUT VIDEO DOORPHONES........................................................ SV102-1539.......................2 - 8 PARALLEL CONNECTION BETWEEN 4 SENTRY VIDEO DOORPHONES..................................................... SC124-0003A .....................2 - 9 PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE....................................................................................................................... SV102-1540.......................2 - 10 PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES..................................................... SV102-1561.......................2 - 10 PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES................................................. SV102-1562.......................2 - 10
DOORPHONE SYSTEMS DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Four-port decoders at each floor. ........................................................................................................................ SC101-0656A .....................2 - 12 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS Four-port decoders at each floor. ......................................................................................................................... SC101-0658.......................2 - 13 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Connections at each floor via single-port decoders.............................................................................................. SC124-0019.......................2 - 14 EXAMPLE OF CONNECTIONS ON A SINGLE RISER CABLE WITH OVER 20 DECODERS DIVIDED INTO TWO GROUPS, EACH WITH A POWER SUPPLY UNIT........................................................... SC101-0665.......................2 - 15 DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 2 ENTRANCE MODULES FOUR-PORT DECODERS AT EACH FLOOR..................................................................................................... SC101-0657.......................2 - 16 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.................................. SC101-0666.......................2 - 17 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 99 apartment stations. Modules configured for TYPE 2.................................... SC101-0667.......................2 - 18 DOORPHONES ON UP TO 899 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 main entrance module. Each riser cable can have up to 9 apartment stations. Modules configured for TYPE 3...................................... SC101-0668.......................2 - 19 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 160 apartment stations. Modules and digitizers configured for TYPE 1. .......... SC101-0669.......................2 - 20 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 10 apartment stations. Modules and digitizers configured for TYPE 2. ............ SC101-0670.......................2 - 21 DOORPHONE BRANCH CONNECTIONS WITH FOUR-PORT DECODERS Ref. 826/23.............................................................................2 - 22 DOORPHONE CONNECTIONS WITH SINGLE-PORT DECODERS .............................................................................................................2 - 23 DOORPHONE CONNECTIONS TO 1 ENTRANCE MODULE Doorphones are equipped with single-port decoders. .......................................................................................... SC101-1061.......................2 - 24
MT124-019
2-3
826
Model 826 DIGITAL CALL SYSTEM DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 ENTRANCE MODULE. FOUR-PORT DECODERS AT EACH FLOOR..................................................................................................... SC101-0660.......................2 - 26 DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS........................................................................ SC101-0662.......................2 - 27 DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary entrance module. Systems can have up to 9, up to 89 or up to 899 riser cables, configured for TYPE 1, 2 or 3. ........................................................................2 - 28 DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary outdoor station equipped with conventional entrance and digitizers. Systems can have up to 9 or up to 89 riser cables, configured for TYPE 1 or 2. .............................................................................................2 - 29 DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR .............................................................................................................................2 - 30 DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE CONNECTIONS AT EACH FLOOR VIA SINGLE-PORT DECODERS Ref. 826/31........................................................................................2 - 31 DOORPHONE CONNECTIONS WITH SECONDARY OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR .............................................................................................................................2 - 32
VIDEO DOORPHONE SYSTEMS VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE FOUR-PORT DECODERS AT EACH FLOOR.................................................................................................... SV102-1511A .....................2 - 34 VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE VIDEO DOORPHONES EQUIPPED WITH SINGLE-PORT DECODER BRACKET .......................................... SV102-1515A .....................2 - 35 VIDEO DOORPHONES CONNECTED TO 1 VIDEO OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS AT EACH FLOOR.................................................................................................... SV102-1514A .....................2 - 36 VIDEO DOORPHONES CONNECTED TO 2 VIDEO ENTRANCE MODULES WITH AUTOMATIC SWITCHING FOUR-PORT DECODERS AT EACH FLOOR............................................... SV124-0034.......................2 - 37 VIDEO DOORPHONES CONNECTED TO 1 GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 VIDEO ENTRANCE MODULE GUARD DOOR SWITCHBOARD STATION VIDEO DOORPHONE INTERCEPTS OUTSIDE CALLS IN DAY SERVICE ......... SV102-1513B .....................2 - 38 VIDEO DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN VIDEO ENTRANCE MODULE Each riser cable is connected to a secondary video entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1................................. SV102-1516A .....................2 - 39
2-4
MT124-019
CONTENTS Model 826 DIGITAL CALL SYSTEM
CONTENTS
826
PARALLEL CONNECTIONS
MT124-019
2-5
PARALLEL CONNECTIONS
826
RING REPEATER RELAY CONNECTION PARALLEL CONNECTION BETWEEN 2 Model 1131 DOORPHONES OR 2 Model 1130 DOORPHONES
ONE RING REPEATER RELAY CONNECTED IN PARALLEL WITH Model 1131 or Model 1132 DOORPHONE TO CONTROL A SUPPLEMENTARY RINGER
Model 1131 - 1132 DOORPHONES
DIAGRAM SC101-0712
FOUR-PORT DECODER Ref. 826/23
Ringer 12 V~ RELAY Ref. 788/21 MAINS~
TRANSFORMER Ref. 9000/230
PARALLEL CONNECTION BETWEEN 2 Model 1131 / 1132 DOORPHONES
Model 1131Mod. - 1132 DOORPHONES CITOFONI 1131-1132
DIAGRAM SC101-0707
NOTE
FOUR-PORT DECODER Ref. 826/23
NOTE
FOUR-PORT DECODER Ref. 826/23
PARALLEL CONNECTION BETWEEN 2 Model 1130 DOORPHONES
DIAGRAM SC101-0708
Model 1131 - 1132 DOORPHONES
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
2-6
MT124-019
Model 1131/1132 DOORPHONES
MT124-019 FOUR-PORT DECODER Ref. 826/23
MAINS ~
SC101-0709
POWER SUPPLY UNIT Ref. 786/1 - 12 VA Ref. 786/14 - 28 VA
RELAY Ref. 788/21
Output power from decoder terminal CA is sufficient to actuate ringer on only 2 parallelconnected doorphones. For the remaining 3 or 4 doorphones, a supplementary power supply controlled by ring repeater relay must be installed.
NOTE
POWER SUPPLY UNIT Ref. 786/1 - 12 VA Ref. 786/14 - 28 VA
Model 1131/1132 DOORPHONES
SCOUT / WINFLAT VIDEO DOORPHONE
FOUR-PORT DECODER Ref. 826/23
826
PARALLEL CONNECTION BETWEEN 1 SCOUT / WINFLAT VIDEO DOORPHONE AND 3 MODEL 1131 / 1132 DOORPHONES
SV102-1563
PARALLEL CONNECTION BETWEEN 4 MODEL 1131 / 1132 DOORPHONES
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
2-7
PARALLEL CONNECTIONS
MAINS ~ RELAY Ref. 788/21
NOTE
PARALLEL CONNECTION BETWEEN 4 Model 1131 DOORPHONES PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 3 Model 1131 DOORPHONES
PARALLEL CONNECTIONS
826
PARALLEL CONNECTION BETWEEN 1 SCOUT VIDEO DOORPHONE AND 1 Model 1131 DOORPHONE PARALLEL CONNECTION BETWEEN 2 SCOUT VIDEO DOORPHONES
PARALLEL CONNECTION BETWEEN 1 SCOUT / WINFLAT VIDEO DOORPHONE AND 1 MODEL 1131 / 1132 DOORPHONE
SV102-1538 SCOUT / WINFLAT VIDEO DOORPHONE
NOTE FOUR-PORT DECODER Ref. 826/23
Model 1131/1132 DOORPHONE
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station. In this case, doorphones will be equipped with key A.
PARALLEL CONNECTION BETWEEN 2 SCOUT / WINFLAT VIDEO DOORPHONES
SV102-1539 SCOUT / WINFLAT VIDEO DOORPHONE
NOTE The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
FOUR-PORT DECODER Ref. 826/23 POWER SUPPLY UNIT Ref. 789/2
MAINS ~
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station.
2-8
MT124-019
826
SC124-0003A DIGITAL + VIDEO SYSTEM RISER CABLE
FOUR-PORT DECODER Ref. 826/34
POWER SUPPLY UNIT Ref. 789/3
LINE ~ NOTE &
LINE ~ NOTE & POWER SUPPLY UNIT Ref. 789/2 RING REPEATER RELAY Ref. 788/21
TONE GENERATOR Ref. 787/1
VIDEO SPLITTER Ref. 1794/4
MT124-019
TRANSFORMER Ref. 9000/230
2-9
PARALLEL CONNECTIONS
PARALLEL CONNECTION BETWEEN 4 SENTRY VIDEO DOORPHONES
PARALLEL CONNECTIONS
826
PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES
PARALLEL CONNECTION BETWEEN 1 EXPLORER OR RANGER VIDEO DOORPHONE AND 1 Model 1130 DOORPHONE
SV102-1540
RANGER or EXPLORER VIDEO DOORPHONE
NOTE FOUR-PORT DECODER Ref. 826/23
Model 1130 DOORPHONE
PARALLEL CONNECTION BETWEEN 2 RANGER VIDEO DOORPHONES
SV102-1561 RANGER VIDEO DOORPHONE
The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
NOTE FOUR-PORT DECODER Ref. 826/23
POWER SUPPLY UNIT Ref. 789/2
MAINS ~
PARALLEL CONNECTION BETWEEN 2 EXPLORER VIDEO DOORPHONES
SV102-1562 EXPLORER VIDEO DOORPHONE
The second video doorphone must be supplied by supplementary power supply unit Ref. 789/2.
NOTE POWER SUPPLY UNIT Ref. 789/2
FOUR-PORT DECODER Ref. 826/23
MAINS ~
NOTE : Connection represented by dash line applies only to systems with guard door switchboard station.
2 - 10
MT124-019
826
DOORPHONE SYSTEMS
MT124-019
2 - 11
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Four-port decoders at each floor.
SC101-0656A TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
ENTRANCE MODULE Ref. 826/65
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Door lock release
CODES 1 ÷ 9999
ELECTRIC LOCK
2 - 12
NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
MT124-019
826
Four-port decoders at each floor.
SC101-0658
TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
NOTE: Digitizers must be configured for TYPE 1 and may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). It is advisable not to use more than 10 digitizers in series for a maximum of 160 doorphones. Up to 64 apartment stations can be served with 4 digitizers as illustrated in the diagram. Each digitizer can manage 16 doorphones and can thus be programmed with the following codes: 1 to 16, 101 to 116, 201 to 216 - - 901 to 916, 1001 to 1016 - - 9901 to 9916.
FOUR-PORT DECODER Ref. 826/23
NOTE: Power supply unit Ref. 826/25 can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release
ELECTRIC LOCK
MT124-019
ENTRANCE AND SPEAKER UNIT Ref. 5150/500 or ref. 824/500 for Kombi series
2 - 13
DOORPHONE SYSTEMS
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 1 ENTRANCE MODULE Connections at each floor via single-port decoders.
SC124-0019 TO SUBSEQUENT DOORPHONES AND DECODERS
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
LINE ~ NOTE &
POWER SUPPLY UNIT Ref. 826/25
CODES 1 — 9999 Door lock release ENTRANCE MODULE Ref. 826/6 ELECTRIC LOCK
2 - 14
MT124-019
826
SC101-0665 SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23 2ND GROUP WITH UP TO 30 DECODERS AND UP TO 120 DOORPHONES.
MAINS ~
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
SUBSEQUENT DECODERS
1ST GROUP WITH UP TO 20 DECODERS AND UP TO 80 DOORPHONES. MAINS
FOUR-PORT DECODER Ref. 826/23
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 1ST GROUP AND ENTRANCE MODULE
ENTRANCE MODULE Ref. 826/55 Kombi Series
Door lock release CODES 1 TO 9999
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1).
ELECTRIC LOCK
MT124-019
2 - 15
DOORPHONE SYSTEMS
EXAMPLE OF CONNECTIONS ON A SINGLE RISER CABLE WITH OVER 20 DECODERS DIVIDED INTO TWO GROUPS, EACH WITH A POWER SUPPLY UNIT
DOORPHONE SYSTEMS
826
DOORPHONES ON A SINGLE RISER CABLE CONNECTED TO 2 ENTRANCE MODULES FOUR-PORT DECODERS AT EACH FLOOR
SC101-0657
TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 2
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 1 AND RISER CABLE
NOTE: The two entrance modules must be configured for TYPE 1 and must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1).
ENTRANCE MODULE Ref. 826/65 Kombi Series
Door lock release
Door lock release
NOTE: Several power supply units are required. One unit supplies one entrance module and the riser cable with a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The second entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
CODES 1 to 9999
ELECTRIC LOCK
2 - 16
ELECTRIC LOCK
MT124-019
MT124-019
Door lock release
UP TO 999 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
TYPE 1 UP TO 9 RISER CABLES
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
MAINS ~
SECONDARY ENTRANCE CODES 1001 to 1999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
Door lock release
MAIN ENTRANCE CODES 1001 to 9999 8991 MAX. (999 x 9 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
Door lock release
SUBSEQUENT RISER CABLES CODES 3 = 3001 to 3999 4 = 4001 to 4999 5 = 5001 to 5999 6 = 6001 to 6999 7 = 7001 to 7999 8 = 8001 to 8999
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: All entrance modules must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
MAINS ~
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
MAINS ~
SECONDARY ENTRANCE CODES 2001 ÷ 2999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
Door lock release
Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.
826
SC101-0666
2 - 17
DOORPHONE SYSTEMS
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
MAINS ~
SECONDARY ENTRANCE CODES 9001 ÷ 9999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
2 - 18
Door lock release
MAINS ~
Door lock release
MAIN ENTRANCE CODES 1101 to 9999 8811 MAX. (99 x 89 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
SECONDARY ENTRANCE CODES 1101 to 1199
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
UP TO 99 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
TYPE 2 UP TO 89 RISER CABLES
MAINS ~
Door lock release
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
SECONDARY ENTRANCE CODES 9901 to 9999
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: The first two digits identify the riser cable (thousands and hundreds places). Codes 1, 2 — 10 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
NOTE: All entrance modules must be configured for TYPE 2. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
SUBSEQUENT RISER CABLES CODES 3 = 1301 to 1399 4 = 1401 to 1499 5 = 1501 to 1599 6 = 1601 to 1699 7 = 1701 to 1799 8 = 1801 to 1899 9 = 1901 to 1999 10 = 2001 to 2099 11 = 2101 to 2199 " " 89 = 2101 to 9999
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
MAINS ~
MAINS ~
SECONDARY ENTRANCE CODES 1201 to 1299
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONE SYSTEMS
826 DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE Each riser cable is connected to 1 secondary entrance module. Each riser cable can have up to 99 apartment stations. Modules configured for TYPE 2.
SC101-0667
MT124-019
MT124-019
Door lock release
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 1
Door lock release
MAIN ENTRANCE CODES 1011 to 9999 8091 MAX. (9 x 899 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
1001 to 1999
MAINS ~
SECONDARY ENTRANCE CODES 1011 to 1019
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
UP TO 9 DOORPHONES PER RISER CABLE
ALL ENTRANCE MODULES
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: The first three digits identify the riser cable (thousands, hundreds and tens places). Codes 1, 2 – 100 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
MAINS ~
Each riser cable is connected to 1 main entrance module. Each riser cable can have up to 9 apartment stations. Modules configured for TYPE 3.
826
SC101-0668
2 - 19
DOORPHONE SYSTEMS
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 89
SECONDARY ENTRANCE CODES 9991 to 9999
ELECTRIC LOCK
Door lock release
TO RISER CABLE
ENTRANCE MODULE Ref. 826/55 Kombi Series
NOTE: All entrance modules must be configured for TYPE 3. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
SUBSEQUENT RISER CABLES CODES 3 = 1031 to 1039 4 = 1041 to 1049 5 = 1051 to 1059 6 = 1061 to 1069 7 = 1071 to 1079 8 = 1081 to 1089 9 = 1091 to 1099 10 = 1101 to 1199 I I 99 = 1991 to 1199 100 = 2001 to 2009 I I 899 = 9991 to 9999
POWER SUPPLY UNIT Ref. 825/25 FOR MAIN ENTRANCE MODULE
POWER SUPPLY UNIT Ref. 825/25 FOR RISER CABLE 2
TYPE 3 UP TO 89 RISER CABLES
MAINS ~
MAINS ~
SECONDARY ENTRANCE CODES 1021 to 1029
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/55 Kombi Series
TO RISER CABLE
DOORPHONES ON UP TO 899 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
MAIN ENTRANCE
ELECTRIC LOCK
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
MAINS ~
7916 8901
6916 7901
5916 6901
4916 5901
3916 4901
9016 9116 9916 (Up to 10 digitizers)
SECONDARY ENTRANCE CODES 9001 9101 9901
MAIN ENTRANCE WITH ENTRANCE MODULE
UP TO 9 RISER CABLES
TYPE 1
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
UP TO 160 DOORPHONES PER RISER CABLE
SECONDARY ENTRANCES WITH CONVENTIONAL ENTRANCE AND DIGITIZER
8016 8116 8916 Max 1440 (160x9 riser cable)
7116 8101
7016 8001
8 =
6 = 6116 7101
5116 6101
5016 6001 6016 7001
4116 5101
4016 5001
5 =
7 =
3116 4101
3016 4001
4 =
SUBSEQUENT RISER CABLES CODES 3 = 3001 3101 3901
DIGITIZER Ref. 826/16
TO RISER CABLE
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
NOTE: All entrance modules and digitizers must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
2016 2116 2916 (Up to 10 digitizers)
1016 1116 1916 (Up to 10 digitizers)
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
SECONDARY ENTRANCE CODES 2001 2101 2901
Door lock release
SECONDARY ENTRANCE CODES 1001 1101 1901
ENTRANCE MODULE Ref. 826/55 Kombi Series
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
Door lock release
2 - 20 Door lock release
DOORPHONE SYSTEMS
826 DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 160 apartment stations. Modules and digitizers configured for TYPE 1.
SC101-0669
MT124-019
Door lock release
MAIN ENTRANCE
ELECTRIC LOCK
SECONDARY ENTRANCE CODES 1101 to 1116
ENTRANCE MODULE Ref. 826/55 Kombi Series
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
Door lock release
Door lock release
MAINS ~
SECONDARY ENTRANCE CODES 9901 to 1916
MAIN ENTRANCE WITH ENTRANCE MODULE
UP TO 9 RISER CABLES
TYPE 2
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 2
TO RISER CABLE
UP TO 160 DOORPHONES PER RISER CABLE
NOTE: The first two digits identify the riser cable (thousands and hundreds places). Codes 1, 2 – 10 can also be assigned, but it is advisable not to use them so that all apartment stations can be coded with four digits.
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~.
NOTE: All entrance modules and digitizers must be configured for TYPE 2. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
Each riser cable is connected to 1 secondary outdoor station equipped with conventional entrance and digitizers. Each riser cable can have up to 10 apartment stations. Modules and digitizers configured for TYPE 2.
826
SC101-0670
2 - 21
DOORPHONE SYSTEMS
SECONDARY ENTRANCES WITH CONVENTIONAL ENTRANCE AND DIGITIZER
89 = 9901 to 9916 Max 1424 (16 x 89 riser cable)
SUBSEQUENT RISER CABLES CODES 3 = 1301 to 1316 4 = 1401 to 1416 5 = 1501 to 1516 6 = 1601 to 1616 7 = 1701 to 1716 8 = 1801 to 1816 9 = 1901 to 1915 10 = 2001 to 2016 11 = 2101 to 2116
MAINS ~
DIGITIZER Ref. 826/16
NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 4 connected decoders. The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
SECONDARY ENTRANCE CODES 1201 to 1216
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
ENTRANCE AND SPEAKER UNIT Ref. 5150/5000 or Ref. 824/500 for Kombi series
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 2
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
Door lock release
MT124-019
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 1
MAINS ~
DIGITIZER Ref. 826/16
TO RISER CABLE
DOORPHONES ON UP TO 89 RISER CABLES CONNECTED TO 1 MAIN ENTRANCE MODULE
DOORPHONE SYSTEMS
826
DOORPHONE BRANCH CONNECTIONS WITH FOUR-PORT DECODERS Ref. 826/23
For diagrams SC101-0666, SC101-0667, SC101-0668, SC101-0669, SC101-0670
TO SUBSEQUENT DECODERS
Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
FROM SECONDARY ENTRANCE
2 - 22
MT124-019
826
For diagrams SC101-0666, SC101-0667, SC101-0668, SC101-0669, SC101-0670
TO SUBSEQUENT DOORPHONES AND DECODERS
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
FROM SECONDARY ENTRANCE MODULE
MT124-019
2 - 23
DOORPHONE SYSTEMS
DOORPHONE CONNECTIONS WITH SINGLE-PORT DECODERS
DOORPHONE SYSTEMS
826
DOORPHONE CONNECTIONS TO 1 ENTRANCE MODULE Doorphones are equipped with single-port decoders.
SC101-1061 TO SUBSEQUENT DOORPHONES WITH DECODERS
DOORPHONES WITH SINGLE-PORT DECODER Model. 826
Model 1132 DOORPHONE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
ENTRANCE MODULE Ref. 826/65 Kombi series
Door lock release
CODES 1 to 9999
ELECTRIC LOCK
2 - 24
MT124-019
826
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
MT124-019
2 - 25
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 ENTRANCE MODULE. FOUR-PORT DECODERS AT EACH FLOOR
826
SC101-0660 TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
The guard door switchboard station must be configured for TYPE 1. The entrance module may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) of for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Two power supply units are required. One unit supplies one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
FOUR-PORT DECODER Ref. 826/23
The guard door switchboard station must be supplied by means of the other power supply unit. NOTE: In Day service, the guard door switchboard station intercepts all calls from the entrance module. To disable call interception, connect terminal + 24 from the entrance module to switchboard station terminal +24N instead of power supply unit terminal +24. Under these conditions, the entrance module is fully disabled (entrance door open at all times). The switchboard station can also be programmed for direct communication between entrance module and apartment stations: in this case, all calls from entrance modules will be sent directly to apartment stations in both Day and Night service.
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
MAINS ~
POWER SUPPLY UNIT CONNECTIONS FOR Ref. 826/25 FOR ENTRANCE MODULE DISABLING CALL AND RISER CABLE INTERCEPTION
MAINS ~
ENTRANCE MODULE Ref. 826/11 Model 625 or Ref. 826/55 Kombi Series
Door lock release CODES 1 to 9999
ELECTRIC LOCK
2 - 26
MT124-019
826
SC101-0662 TO SUBSEQUENT DECODERS Model 1131 DOORPHONES
Model 1131 DOORPHONES
FOUR-PORT DECODER Ref. 826/23
NOTE: Digitizers and guard door switchboard station must be configured for TYPE 1. Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). It is advisable not to use more than 10 digitizers in series for a maximum of 160 doorphones. Up to 64 apartment stations can be served with 4 digitizers as illustrated in the diagram. Each digitizer can manage 16 doorphones and can thus be programmed with the following codes: 1 to 16, 101 to 116, 201 to 216 - - 901 to 916, 1001 to 1016 - - 9901 to 9916.
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
NOTE: Two power supply units are required. One unit can supply can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The guard door switchboard station must be supplied by means of the second power supply unit.
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR DIGITIZERS AND RISER CABLE
MAINS ~
NOTE: The maximum number of devices that can be connected in a system must under no circumstances exceed 400. Here, the term device is used to designate any item connected to data line D, including four-port decoders, entrance modules, power supply units, guard door switchboard station, digitizers and so forth. Doorphones and video doorphones are not included in the total of 400 devices. DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release
ELECTRIC LOCK
MT124-019
ENTRANCE AND SPEAKER UNIT Ref. 5159/500 or Ref. 824/500 for Kombi series
2 - 27
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE Each riser cable is connected to a secondary entrance module. Systems can have up to 9, up to 89 or up to 899 riser cables, configured for TYPE 1, 2 or 3.
SUBSEQUENT RISER CABLES
UP TO 899 RISER CABLES TYPE 3 UP TO 9 DOORPHONES PER RISER CABLE
CODES 1011 to 1019
CODES 1021 to 1029
Diagram SC101-0672 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 3. NOTE: The first three digits identify the riser cable (thousands, hundreds and tens places).
= = = = = = = =
CODES 1031 to 1041 to 1051 to 1061 to 1071 to 1081 to 1091 to 1101 to
CODES 1101 to 1199
CODES 1201 to 1299
Diagram SC101-0704 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 2. NOTE: The first two digits identify the riser cable (thousands and hundreds places).
99 = 1991 100 = 2001
to to
1199 2009
899 = 9991
to
9999
3 4 5 6 7 8 9 10 11
= = = = = = = = =
CODES 1301 to 1401 to 1501 to 1601 to 1701 to 1801 to 1901 to 2001 to 2101 to
89 = 9901
CODES 1001 to 1999
CODES 2001 to 2999
Diagram SC101-0671 NOTE: All entrance modules and guard door switchboard station must be configured for TYPE 1.
TO RISER CABLE
NOTE: The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0). NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module and the guard door switchboard station must each be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units. If an electronic directory is installed on the main entrance module, it can be supplied by the same power supply unit. Any electronic directories installed on secondary entrance s can be supplied by the same power supply unit as the riser cable, taking care not to exceed the maximum permissible consumption (in this case, up to 12 decoders can be used).
CODES 9991 to 9999
to
1339 1449 1559 1669 1779 1889 1999 2009 2109
CODES 9901 to 9999
9999
SUBSEQUENT RISER CABLES
UP TO 9 RISER CABLES TYPE 1 UP TO 999 DOORPHONES PER RISER CABLE
1039 1049 1059 1069 1079 1089 1099 1109
SUBSEQUENT RISER CABLES
UP TO 89 RISER CABLES TYPE 2 UP TO 99 DOORPHONES PER RISER CABLE
3 4 5 6 7 8 9 10
3 4 5 6 7 8
= = = = = =
CODES 3001 to 4001 to 5001 to 6001 to 7001 to 8001 to
3999 4999 5999 6999 7999 8999
TO RISER CABLE
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
CODES 9001 to 9999
TO RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
MAINS ~
ENTRANCE MODULE Ref. 826/55 Kombi Series Door lock release
ELECTRIC LOCK MAIN ENTRANCE
2 - 28
MT124-019
826
Each riser cable is connected to a secondary outdoor station equipped with conventional entrance and digitizers. – Systems can have up to 9 or up to 89 riser cables, configured for TYPE 1 or 2.
UP TO 89 RISER CABLES TYPE 2 CODES 1101 to 1116
UP TO 16 DOORPHONES FOR RISER CABLE
CODES 1216 to 1216
SUBSEQUENT RISER CABLES 3 4 5 6 7 8 9 10 11
Diagram SC101-0674 NOTE: The main entrance module, digitizers and guard door switchboard station must be configured for TYPE 2. NOTE: The first two digits identify the riser cable (thousands and hundreds places).
= = = = = = = = =
CODES 1301 to 1401 to 1501 to 1601 to 1701 to 1801 to 1901 to 2001 to 2101 to
89 = 9901
to
CODES 9901 to 9916
1316 1416 1516 1616 1716 1816 1916 2016 2116 9916
Max 1424 (16 x 89 riser cables) SUBSEQUENT RISER CABLES
UP TO 9 RISER CABLES TYPE 1
CODES 1001 1101 1901
CODES 2001 2101 2901
UP TO 160 DOORPHONES FOR RISER CABLE
1016 1116 1916 Up to 10 digitizers
2016 2116 2916 Up to 10 digitizers
Diagram SC101-0673 NOTE: The main entrance module, digitizers and guard door switchboard station must be configured for TYPE 1.
TO RISER CABLE
CODES 3 = 3001 3101
3901
3016
3116
3916
4 = 4001
4101
4901
4016
4116
4916
5 = 5001
5101
5901
5016
5116
5916
6 = 6001
6101
6901
6016
6116
6916
7 = 7001
7101
7901
7016
7116
7916
8 = 8001
8101
8901
8016
8116
8916
TO RISER CABLE
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
CODES 9001 9101 9901 9016 9116 9916 Up to 10 digitizers
TO RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR SWITCHBOARD STATION
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN ENTRANCE MODULE
NOTE: The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Digitizers may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in). NOTE: Several power supply units are required. Each riser cable must be supplied by its own power supply unit Ref. 826/25, which can supply up to 4 digitizers, the speaker unit and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together. The main entrance module and the guard door switchboard station must each be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units. If an electronic directory is installed on the main entrance module, it can be supplied by the same power supply unit.
MAINS ~
MAINS ~
ENTRANCE MODULE Ref. 826/55 Kombi Series Door lock release
ELECTRIC LOCK MAIN ENTRANCE
MT124-019
2 - 29
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONES ON MULTIPLE RISER CABLES CONNECTED TO 1 DIGITAL GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 MAIN ENTRANCE MODULE
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR
For diagrams SC101-0671, SC101-0704, SC101-0672. TO SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23
ENTRANCE MODULE Ref. 826/65 Kombi Series
Door lock release
ELECTRIC LOCK SECONDARY ENTRANCE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 899
FROM MAIN LINE
2 - 30
MT124-019
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
DOORPHONE CONNECTIONS WITH SECONDARY ENTRANCE MODULE CONNECTIONS AT EACH FLOOR VIA SINGLE-PORT DECODERS Ref. 826/31
826
For diagrams SC101-0671, SC101-0704, SC101-0672
DOORPHONES Ref. 826/31 WITH SINGLE-PORT DECODER
ENTRANCE MODULE Ref. 826/65
Door lock release CODES 1 – 9999
ELECTRIC LOCK
SECONDARY ENTRANCE
LINE ~ NOTE &
POWER SUPPLY UNIT Ref. 826/25 FOR SECONDARY ENTRANCE MODULE AND RISER CABLE FROM MAIN LINE
MT124-019
2 - 31
DOORPHONE CONNECTIONS WITH SECONDARY OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS Ref. 826/23 AT EACH FLOOR
For diagrams SC101-0673, SC101-0674
TO SUBSEQUENT DECODERS
FOUR-PORT DECODER Ref. 826/23
DIGITIZER Ref. 826/16
NOTE: The two entrance pushbutton lighting conductors must be provided with a separate transformer whose power is sufficient for the number of bulbs involved. With 14/15 V bulbs, use a voltage of 12 V~, while with 24 V bulbs, use a voltage of 18 V~. DIGITIZERS For Type 2 systems with up to 89 riser cables, a single digitizer can be installed for a maximum of 16 apartment stations.
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR RISER CABLE 9
For Type 1 systems with up to 9 riser cables, a maximum of 10 digitizers can be installed on each riser cable.
Door lock release
DOORPHONE SYSTEMS WITH GUARD DOOR SWITCHBOARD STATION
826
Each digitizer can manage 16 apartment stations. POSSIBLE CODES - 1st digitizer 1 to 16 - 2nd digitizer 101 to 116 - 3rd digitizer 201 to 216 - 4th digitizer 301 to 316 - 10th digitizer 901 to All codes must be preceded by the number indicating the thousands place.
916
ELECTRIC LOCK SECONDARY ENTRANCE
FROM MAIN LINE
2 - 32
ENTRANCE AND SPEAKER UNIT Ref. 5159/500 or Ref. 824/500 for Kombi series
MT124-019
826
VIDEO DOORPHONE SYSTEMS
MT124-019
2 - 33
VIDEO DOORPHONE SYSTEMS
826
VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE FOUR-PORT DECODERS AT EACH FLOOR
SV102-1511A TO SUBSEQUENT DECODERS
VIDEO DOORPHONES
VIDEO DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
VIDEO SPLITTER Ref: 1794/4
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
VIDEO DOORPHONES
CCD DOOR CAMERA UNIT Scout 4.5
Direct vision version Video doorphone Ref. 1204/1 + Bracket Ref. 1204/90 + Back box Ref. 7108/100 or Tabletop conversion kit Ref.1204/92 Reflex vision version Video doorphone Ref. 1204/10 + Bracket Ref. 1204/90
Door lock release
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
2 - 34
ELECTRIC LOCK
NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
MT124-019
826
SV102-1515A TO SUBSEQUENT VIDEO DOORPHONES
SCOUT VIDEO DOORPHONE ON BRACKET WITH SINGLE-PORT DECODER
VIDEO DOORPHONES
Scout 4.5”
Direct vision version Video doorphone Ref. 1204/1 + Bracket Ref. 1204/94 + Back box Ref. 7108/100 or Tabletop conversion kit Ref.1204/92 Reflex vision version Video doorphone Ref. 1204/10 + Bracket Ref. 1204/94
Key • on video doorphones is configured internally so as to call the guard door switchboard, if provided. Key ♦ is provided for other uses as desired. NOTE: Bracket with single-port is designed only for use with electronic call tone signaling Scout video doorphones. NOTE: The entrance module must be configured for TYPE 1 and may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply the entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 50).
MAINS ~
MAINS ~
POWER SUPPLY UNIT Ref. 826/25 VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
Door camera
CCD DOOR CAMERA UNIT
Door lock release ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999 ELECTRIC LOCK
MT124-019
2 - 35
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 1 VIDEO ENTRANCE MODULE VIDEO DOORPHONES EQUIPPED WITH SINGLE-PORT DECODER BRACKET
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 1 VIDEO OUTDOOR STATION EQUIPPED WITH CONVENTIONAL ENTRANCE AND DIGITIZERS FOUR-PORT DECODERS AT EACH FLOOR
826
SV102-1514A
TO SUBSEQUENT DECODERS
VIDEO DOORPHONES
VIDEO DOORPHONES
FOUR-PORT DECODER Ref. 826/23
FOUR-PORT DECODER Ref. 826/23
NOTE: Digitizers must be configured for TYPE 1 and may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = jumper PT4 out) or UNRESTRICTED DOOR LOCK RELEASE (step 5 = jumper PT4 in).
VIDEO SPLITTER Ref: 1794/4
MAINS ~
NOTE: Power supply unit Ref. 826/25 can supply up to 4 digitizers, the associated speaker unit, and the 16 connected decoders. If more than 4 directly connected digitizers are installed, use one additional power supply unit for every 6 digitizers and the associated 24 decoders. Here again, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together.
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
MAINS ~
POWER SUPPLY UNIT Ref. 826/25
DIGITIZERS Ref. 826/16
N 1
N 2
N 4
Door lock release NOTE
Door camera CCD DOOR CAMERA UNIT
ELECTRIC LOCK
ENTRANCE AND SPEAKER UNIT Ref. 5150/500 or ref. 824/500 for Kombi series OUTDOOR STATION WITH DOOR CAMERA UNIT AND CONVENTIONAL ENTRANCE
2 - 36
MT124-019
826
SV124-0034 TO VIDEO DOORPHONE RISER CABLE TO SUBSEQUENT DECODERS
VIDEO SPLITTER Ref: 1794/4
LINE ~ NOTE &
LINE ~ NOTE &
LINE ~ NOTE &
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE <>
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 1 AND RISER CABLE
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE 2
RELAY Ref. 1032/9 NOTE ><
Door camera
DOOR CAMERA UNIT
Door camera
DOOR CAMERA UNIT
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
ENTRANCE MODULES Ref. 826/65
Door lock release
ELECTRIC LOCK 1ST VIDEO ENTRANCE
MT124-019
ENTRANCE MODULES Ref. 826/65
Door lock release
ELECTRIC LOCK 2ND VIDEO ENTRANCE
2 - 37
VIDEO DOORPHONE SYSTEMS
VIDEO DOORPHONES CONNECTED TO 2 VIDEO ENTRANCE MODULES WITH AUTOMATIC SWITCHING FOUR-PORT DECODERS AT EACH FLOOR
VIDEO DOORPHONE SYSTEMS
826
VIDEO DOORPHONES CONNECTED TO 1 GUARD DOOR SWITCHBOARD STATION WITH PROVISION FOR NIGHT SERVICE AND 1 VIDEO ENTRANCE MODULE GUARD DOOR SWITCHBOARD STATION VIDEO DOORPHONE INTERCEPTS OUTSIDE CALLS IN DAY SERVICE
SV102-1513B TO VIDEO DOORPHONE RISER CABLE TO SUBSEQUENT DECODERS
SWITCHBOARD STATION VIDEO DOORPHONE
VIDEO SPLITTER Ref: 1794/4
GUARD DOOR SWITCHBOARD STATION Ref. 826/18
MAINS ~ MAINS ~
POWER SUPPLY UNIT Ref. 826/25 FOR GUARD DOOR SWITCHBOARD STATION
VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
DOOR CAMERA UNIT
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE
Door camera
NOTE: The entrance module and guard door switchboard station must be configured for TYPE 1. The entrance module may be programmed for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0) or for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). NOTE: Power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30).
ENTRANCE MODULE Ref. 826/65 CODES 1 to 9999
Door lock release
ELECTRIC LOCK
2 - 38
MAINS ~
The guard door switchboard station must be supplied by means of its own power supply unit. INSTRUCTIONS: In Day service, guard door switchboard station intercepts all calls from the video entrance module. The switchboard attendant uses the station handset to establish voice communication with the visitor, and the video doorphone to view the visitor. Apartment station video doorphones use the • key to call the switchboard, and the XXX key to release electric door locks. To disable call interception, connect entrance module terminal + 24 to switchboard station terminal +24N instead of riser cable power supply unit terminal +24. Under these conditions, calls from the entrance module will not cause the guard door switchboard station to ring during Day service (entrance door open at all times). For systems of this kind, no video doorphone is installed at the guard door station.
MT124-019
VIDEO SPLITTER Ref: 1794/4
NOTE: Each riser cable must be supplied by its own power supply unit, as power supply unit Ref. 826/25 can supply one entrance module and a maximum of 20 decoders. Additional power supply units must be installed if further decoders are needed. In this case, power supply unit conductors + 24 must UNDER NO CIRCUMSTANCES be connected together: each must supply a separate group of four-port decoders (up to 30). The main entrance module must be supplied with its own power supply unit; again, conductor + 24 must be separate from the other power supply units.
NOTE: All entrance modules must be configured for TYPE 1. The main entrance module must be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1). Secondary entrance modules may be programmed for DOOR LOCK RELEASE PROTECTED BY PRIVACY FEATURE (step 5 = 1) or for UNRESTRICTED DOOR LOCK RELEASE (step 5 = 0).
NOTE: To use output % on video splitters, remove the 75 W resistor protruding from printed circuit.
Door lock release
MAINS ~
COMMON VIDEO POWER SUPPLY UNIT Ref. 789/5 NOTE
MAINS ~
TWO VIDEO SPLITTER Ref: 1794/4 NOTE
DOOR CAMERA UNIT
MAIN VIDEO ENTRANCE CODES 1001 to 9999 8991 MAX. (999 X 9 RISER CABLES)
ELECTRIC LOCK
ENTRANCE MODULE Ref. 826/65
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 1
ENTRANCE MODULE Ref. 826/65
SECONDARY VIDEO ENTRANCE CODES 1001 to 1999
ELECTRIC LOCK
DOOR CAMERA UNIT
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
Door camera
RELAY Ref. 1032/9 NOTE
VIDEO SPLITTER Ref: 1794/4
Door camera
DOOR CAMERA UNIT
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MAIN MODULE
MAINS ~
SECONDARY VIDEO ENTRANCE CODES 2001 to 2999
Door lock release
MAINS ~
Door lock release
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 9
Each riser cable is connected to a secondary video entrance module. Each riser cable can have up to 999 apartment stations. Modules configured for TYPE 1.
826
SV102-1516A
2 - 39
VIDEO DOORPHONE SYSTEMS
ENTRANCE MODULE Ref. 826/65
POWER SUPPLY UNIT Ref. 789/2
VIDEO SPLITTER Ref: 1794/4
SECONDARY VIDEO ENTRANCE CODES 9001 to 9999
RELAY Ref. 1032/9
LINE ~
DOOR CAMERA UNIT
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
RISER CABLE 3 CODES 9001 to 9999
MAINS ~
ELECTRIC LOCK
RELAY Ref. 1032/9 NOTE
TO THE TO THE FOLLOWING FOLLOWING MONITOR DISTRIBUTION
SUBSEQUENT RISER CABLES CODES 3-4-5-6-7-8 3001 to 3999 4001 to 4999 5001 to 5999 6001 to 6999 7001 to 7999 8001 to 8999 VIDEO SPLITTER Ref. 1794/4
EXAMPLE OF VIDEO SPLITTER CONNECTION BY MEANS OF LOCAL POWER SUPPLY UNIT Ref. 789/2 Local power supply unit Ref. 789/2 is essential in cases where the number of video splitters in the entire system exceeds 10.
POWER SUPPLY UNIT Ref. 826/25 FOR MODULE AND RISER CABLE 2
ENTRANCE MODULE Ref. 826/65
SECONDARY VIDEO POWER SUPPLY UNIT Ref. 789/5
MAINS ~
ELECTRIC LOCK
RELAY Ref. 1032/9 NOTE
RISER CABLE 2 CODES 2001 to 2999
Door camera
MT124-019 Door camera
RISER CABLE 1 CODES 1001 to 1999
VIDEO DOORPHONES ON UP TO 9 RISER CABLES CONNECTED TO 1 MAIN VIDEO ENTRANCE MODULE
Related Documents c2h70
Urmet 826 Digital Call System Wiring Diagram 1g566z
December 2019 110
Wiring Diagram For Cctv System 1i2g6o
October 2021 0
Wiring Diagram 1m2lb
December 2020 0
Wiring Diagram 1m2lb
March 2023 0
Scion Xb 2005 Audio System Wiring Diagram 3b4h2w
December 2019 58
Wiring Diagram-split System Air Conditioner 5t3w5q
October 2019 48More Documents from "G. M." 4g542b
Resumen Contratos Civiles Y Comerciales 5l2u5s
May 2021 0
Urmet 826 Digital Call System Wiring Diagram 1g566z
December 2019 110
Ppe Headquarters - Nppe Sample Chapter 4c5p5
November 2022 0
183235341 Sara Nabucco Vilinski Simboli Kljucevi Eneregije Pdf 5v5s3h
April 2020 39
Nppe Exam - Multiple Choice Sample Exam 5g414
October 2019 137
