Wiring Diagram 1m2lb

6. Wiring Diagram

6. Wiring Diagram

6-1. Wiring Diagram 32”/37”/40”

CN1001 CN8002

CN2001

Main Board

CN4007

Function & IR

Speaker

T-CON

CN801

IP Board

Speaker

6-1

6. Wiring Diagram

6-2. Wiring Diagram 46”

CN1

CN1001 CN8002

CN2001

Main Board CN4007

Function & IR

Speaker

T-CON

CN801

CN1806

CN1808

CN1809

IP Board

CN2

CN3

Driver

Speaker

6-2

6. Wiring Diagram

CN8002 (to ) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

HVS T_Micom_Reset PVCC_SW SDA (FRC Control) FRC Reset SCL (FRC Control) LVDS opt H-Sync Out W/P(T_Con) T_Con Check SDA (T_Control) SCL (T_Control) GND RE[4]+ RE[4]RE[3]+ RE[3]GND RECLK+ RECLKGND RE[2]+ RE[2]RE[1]+ RE[1]RE[0]+

27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51

RE[0]GND RO[4]+ RO[4]RO[3]+ RO[3]GND ROCLK+ ROCLKGND RO[2]+ RO[2]RO[1]+ RO[1]RO[0]+ RO[0]GND GND GND NC _VCC _VCC _VCC _VCC _VCC

CN1001 (to Power board) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

H-SYNC Power On/Off GND(5.2V) ST-BY(5.2V) GND GND 14V(Sound Vcc) 14V(Sound Vcc) GND GND GND GND 5.3V 5.3V 5.3V

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

5.3V GND GND GND 12.5V 12.5V 12.5V I-PWM (ANA) SW_INVETER GND E-PWM (PWM) NC DET_5V NC (FAN2_DET) NC (FAN3_DET)

JA3001 (HDMI1)

JA4001 (PC sound)

1 2 3 4 5 6 7 8 9 10 11

1 2 3 4 5 6 7

HDMI1_RX2+ 12 GND HDMI1_RX2HDMI1_RX1+ 15 GND HDMI1_RX1HDMI1_RX0+ 18 GND HDMI1_RX0HDMI1_RXCLK+ GND

JA3004 (HDMI2) 1 2 3 4 5 6 7 8 9 10 11

HDMI2_RX2+ 12 GND HDMI1_RX2HDMI2_RX1+ 15 GND HDMI2_RX1HDMI2_RX0+ 18 GND HDMI2_RX0HDMI2_RXCLK+ GND

GND PC_SR_IN PC_SL_IN PC_SL_IN PC_SL_IN PC_SR_IN PC_SR_IN

CN2001 (sound out) 1 2 3 4

R+ RL+ L-

JA7001 (USB1) 1 2 3 4

USB1 VCC USBN 2.0 USBP 2.0 GND

JA3002 (HDMI3)

JA5004 (side AV)

1 2 3 4 5 6 7 8 9 10 11

1 2 3 4 5 6 7 8 9

HDMI3_RX2+ 12 GND HDMI3_RX2HDMI3_RX1+ 15 GND HDMI3_RX1HDMI3_RX0+ 18 GND HDMI3_RX0HDMI3_RXCLK+ GND

GND VIDEO2 SL IN VIDEO2 SR IN GND VIDEO2 SR IN VIDEO2 SL IN GND VIDEO2 IDENT VIDEO2_CVBS_BAY

6-3

6. Wiring Diagram

CN4007 (to Function IR) 1 2 3 4 5 6

6-4

IR GND A3.3V LED_INDICATOR BUZZER KEY_1

7 8 9 10 11 12

KEY_2 KEY_SDA (NC) A5V KEY_SCL(NC) LED_DECO(NC) A5V(NC)

JA3003_S (HDMI4)

JA4005_PC (PC)

1 2 3 4 5 6 7 8 9 10 11

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

HDMI4_RX2+ 12 GND HDMI4_RX2HDMI4_RX1+ 15 GND HDMI4_RX1HDMI4_RX0+ 18 GND HDMI4_RX0HDMI4_RXCLK+ GND

PC_RED PC_GREEN PC_BLUE GND GND GND GND GND PC_5V PC_IDENT GND EMU_SDA PC_H_SYNC PC_V_SYNC EMU_SCL

6. Wiring Diagram

6-3. Connector Functions Connector

Functions

CN1001 <-> CN801

Supply main power and dimming signal from IP board to Main Board.

CN8002 <-> CN505

The LVDS signal transfered from Main Board to .

CN1806 <-> CN3

signal from driver.

CN1808 <-> CN1

Supply power from IP board to Driver Board(left).

CN1809 <-> CN2

Supply power from IP board to Driver Board(right).

6-4. Cables Main IP (30P) 32”

Main - TCON 32” BN96-10077A (250mm)

BN39-01099H (500mm)

40” BN96-10075A (350mm)

40”/46”/52”

46” BN96-10075A (350mm)

BN39-01099K (700mm)

52” BN96-10074A (450mm)

IP - BalanceBD(L) (2P) 46” BN39-01021C (1100mm)

IP - BalanceBD(R) (2P) 46” BN39-01024A (350mm)

52” BN39-01021D (1200mm)

52” BN39-01021A (450mm)

Use Code

IP - BalanceBD (7P) 46” / 52” BN39-00830B (200mm)


Use Code


6-5
