MEET THE CHALLENGER IN BUILDING AUTOMATION REGIN SystemS CONTROLLERS AND THERMOSTATS FOR DIN-RAIL MOUNTING ROOM CONTROLLERS/THERMOSTATS ELECTROMECHANICAL THERMOSTATS ELECTRIC HEATING CONTROLLERS SENSORS AND SWITCHES DETECTORS ENERGY METERS ACCESSORIES VALVES VALVE ACTUATORS DAMPER ACTUATORS MISCELLANEOUS PRODUCTS sYSTEM EXAMPLES & CONTROL THEORY INDEX

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

PRODUCT NEWS

New generation Corrigo and EXOcompact The flexible Corrigo and EXOcompact controllers are now available in a new generation. They are available with or without display and can be used stand-alone or integrated into networks. The third generation controllers have a new housing and blue display, greatly improved processing power, 5-20 times faster T/IP communication, for communication via BACnet, models with 3 communication ports and the option to use both an external and integrated display simultaneously.

New service for easy mobile access of controllers Using CLOUDigo, it is possible to connect Corrigo controllers with integrated web server to a in order to easily view and ister buildings. CLOUDigo s multiple s with different levels of access. Values can be logged and displayed graphically or exported to Excel.

3G modem for CLOUDigo CLO-3G consists of a 3G modem with a factory-installed SIM card, ready for immediate connection to CLOUDigo. The modem functions as a gateway between a T/ IP connected Corrigo and CLOUDigo. It has a built-in DH function that handles connecting to an external unit.

Accessories for third generation controllers Using the ED-RU series of room units, it is possible to control the temperature in single rooms from a distance of up to 300 m. ED-TCV is a pressure sensitive graphical display that can be connected to a dual port Corrigo ventilation and used to change settings, handle alarms, etc. E3-DSP offers full external control access for when EXOcompact or Corrigo is mounted inside a cabinet, etc. The display unit can be used at a range of up to 100 m.

I/O modules with 7 or 10 in-/outputs The IO-RU modules makes it possible to expand the number of inputs and outputs of the EXOflex and EXOcompact controllers. The modules are configured using EXOdesigner by one of Regin’s system integrators.

2

PRODUCT NEWS

RCF with BACnet communication The controllers and thermostats in the RCF series are intended for control of heating, cooling or fan-coils in 2- or 4-pipe installations. They are available with or without communication and can be used stand-alone or integrated into networks. RCF models with communication now also BACnet and are BTL approved.

2- and 3-way zone valves, DN15...DN20 VTTV/VTTR/VTTB are a range of valves used to control heating and cooling in fan-coil or chilled beams applications. The valves are available in 2- and 3-way versions, as well as by versions, and with kvs values ranging from 0.25 to 6.0. They are intended for use together with the thermal RTAN and RTAOM actuators.

Pressure independent control valves The PC(M)TV valves consist of a combined differential pressure regulator, flow limiter and equal percentage control valve with full stroke and authority. The valves are suitable for constant or variable temperature systems and can be used as constant flow limiters in constant volume systems (with no actuators), or as proper pressure independent control valves in variable volume systems (with actuators).

Liquid flow switch The FLS...X range consists of electro-mechanical flow switches that can be used to control the flow of liquids in heating and air conditioning systems, industrial water treatment systems and as safety switches for signalling interruptions or decrease in flow. FLS...X is available in models that can withstand seawater and aggressive fluids.

Mechanical thermostats We now introduce a new series of mechanical thermostats for cooling, heating and ventilation systems. The thermostats are available in a large selection of models for various types of mounting.

3

PRODUCT NEWS

4

1

MEET THE CHALLENGER

MEET THE CHALLENGER

+21°C

5

MEET THE CHALLENGER

The Challenger! A history of knowledge, experience and constant product development Ever since Regin was established in 1947, we have developed and marketed products and systems that create good levels of indoor comfort. Today, we offer one of the widest ranges of building automation in the market. You will also find that we have the knowledge, experience and resources to give you first-class and guidance. What makes Regin stand out the most is probably our undivided commitment and our motivation to do our best for our customers and partners. Many see us as the challenger in building automation. That stimulates us to work even harder.

The year 1947. The foundation of Regin and launch of its first product – a humidistat.

6

The early 70s Regin's first electric heating controllers.

• We have developed energy-efficient solutions since 1947 • Wide range of products & constant development • We do not carry out any installations, we offer a network of partners who compete under equal conditions • Wide technical competence – from electromechanics to system development

The mid-80s A new module-based controller system.

The beginning of the 2000s The first controllers with complete Internet access.

2006. Regio. An entirely new concept for zone control. Awarded the IF Award in 2007.

MEET THE CHALLENGER

Commitment and motivation Our goal is to make Regin your leading supplier of solutions contributing to improved energy consumption and a sustainable development. Therefore, we all share the same values. Our mission is to always do our utmost to solve your problems. As a customer, you will therefore have constant access to our knowledgeable staff in product development, technical sales , training, logistics etc., who will always be there for you.

2007. Optigo. The universal controller for all fundamental control functions.

2008. Regin launches a series of energysaving valves that are 100 % tight

Our guiding values Listen We always listen before we act and react Being knowledgeable We must be knowledgeable and good at what we do Simplicity It must be easy doing business with us Commitment We commit ourselves to what we do

2013.Third generation Corrigo and EXOcompact. Mobile control with CLOUDigo.

2014. Controller builder.

7

MEET THE CHALLENGER

Global strength, strong local presence Regin is an international corporation with representation in more than 70 countries. The head office is located in Kållered (Gothenburg, Sweden). Our product development centres are located in Varberg and Landskrona. Landskrona also houses a sales office and technical , as well as our training centre Regin Academy. Our main warehouse, logistics unit and valve division are located in Osby.

Gothenburg Aarhus

Thanks to our global presence with strong local representation, we are well aware of market requirements as well as of how our products and systems function under the most varying conditions.

• Sales offices in Stockholm, Gothenburg, Aarhus, Paris, Berlin, Madrid, Bressanone, Kiev, Singapore, Hong Kong, Tunis and Jakarta • Reference installations located worldwide • A global network of local distributors and integrators

Stockholm Berlin

Kiev Bressanone

Paris Madrid Tunis

Hong Kong

Singapore Jakarta

Sales Office Stockholm Head Office Gothenburg R&D Varberg R&D and Academy Landskrona

8

Logistics Centre Osby

MEET THE CHALLENGER

Professional partners

Integrators

Distributors

Regin does not perform any installations on our own. Instead, we offer a network of certified integrators who are responsible for planning, installation, commissioning and maintenance. The integrators are certified upon having completed training at Regin Academy. You can choose whichever integrator you wish to work with – they all compete under the exact same conditions.

Our products and systems are kept in stock by distributors in about 70 countries around the world. They represent Regin’s basic range (not systems or system products) and are responsible for marketing the products locally to consultants, installation engineers, real estate companies, as well as to companies working in integration and system solutions.

Regin Gold Certified Integrators • Have mastered all of Regin's products and systems • Carry RGCI certification issued by Regin Academy, having completed all of its courses. • Have access to reference plants (for study visits). • Have access to extensive technical from Regin. Regin Certified Integrators • Have primarily mastered Regin's system products. • Are RCI certified by the Regin Academy and have completed courses in Regin's systems. • Can advance to RGCI – Gold Certified Integrator, by completing all courses.

9

MEET THE CHALLENGER

Regin Systems offer total freedom A complete range – from stand-alone products to building automation systems

Modular construction for flexible, simple and cost-effective system expansion

10

Open systems, capable of integration with systems using other standards and products by other manufacturers

Backwards compatibility

MEET THE CHALLENGER

Regin's energy-efficient solutions can be found the world over Regin's products and systems save energy and facilitate operation and maintenance in buildings in all parts of the world under the most variable conditions.

Tenants and anyone working or staying in the buildings always enjoy a comfortable indoor climate.

Lindholmen Science Park, Sweden

Mövenpick Hotel, Turkey

MAS University Hospital, Sweden

Aqua Mundo, the Netherlands

Pacific Place Mall, Indonesia

Guiyang stadium, China

Visit our website for more information, www.regincontrols.com

11

MEET THE CHALLENGER

Systems for open, flexible integration

Software & Services EXOscada A complete and powerful SCADA system that provides complete control and supervision of various building functions, as well as of collected measurement data.

EXOflex

Controllers for larger systems

A Regin System is built using EXOflex, a series of modular, freely programmable units for control and monitoring.These are supplemented with plug-in units (PIFA) for different applications. Communication is via GSM,T/ IP, LAN/WAN, landline, satellite, etc. A web interface provides access via the Internet.

EXOcompact

Controllers for smaller and intermediate systems EXOcompact is a series of powerful freely programmable controllers for heating, ventilation and zone control that are designed especially for the EXO system.

EXOdesigner A software tool for constructing Regin systems with communication networks, controller configuration and SCADA system creation. EXOopc Driver Enables connecting EXO controllers to other units ing the OPC standard. EXOhotel An add-on program, based on the Fidelio protocol, enabling the connection of a hotel booking system to EXOscada.

Configuration software E tool ® Using E tool ®, a PC-based software tool, Corrigo can be quickly adapted to every application.

Regio Maxi

Zone control Freely programmable controller with communication. Can be connected to bus systems such as LON, Modbus or EXOline (T/IP or RS485). The T-port provides access for remote setpoint reading and adjustment with EXOline over T/IP.

I/O modules

Input and output expansion Regin’s I/O modules offer the possibility to expand the EXOflex and EXOcompact controllers. The I/O modules are available in models for DIN-rail or wall mounting, with 7, 10 or 16 in-/outputs.

Regio tool ® Configuration and commissioning software for the Regio zone control system.

CLOUDigo

The easiest way to control your installations, CLOUDigo opens up to completely new possibilities. You get quick and easy access to your Corrigo controllers from anywhere. CLOUDigo handles historical data for complete overview and control, enabling you to work from the unit of your choice while still retaining full functionality, be it a computer, tablet or mobile phone. Getting started is easy, as controller installation is extremely intuitive and based on our “Ready Steady Go” motto. Choose a platform that grows along with you.You handle your installations – CLOUDigo does all the rest!

12

MEET THE CHALLENGER

Controllers and thermostats

Controllers and thermostats for room control

Regio Maxi

Freely programmable room controllers with communication. Can be connected to bus systems such as LON, Modbus or EXOline (T/IP or RS485). The T-port provides access for remote setpoint reading and adjustment with EXOline over T/IP.

Corrigo / Corrigo with integrated web server

Pre-programmed controllers for control of heating, cooling, zones, etc. Can be equipped with communication ports for T/IP, LON or EXOline networks, e.g. for access via the Internet. Using E tool®, a PC-based software tool, Corrigo can be quickly adapted to every application.

Regio Midi and Mini

Regio Midi

Optigo

A series of pre-programmed stand-alone controllers for control of temperature, CO2, pressure and humidity in HVAC applications, as well as domestic hot water control.

Pre-programmed room controllers with the same features as the stand-alone version, but also including communication via Modbus, BACnet or EXOline (RS485).

Regio Mini

Pre-programmed room controllers for stand-alone control of heating and cooling in a room.

Controllers Duct controller

AL24A1K is a compact controller with builtin sensor and 0...10 V output. It is designed primarily for control of heating or cooling in HVAC systems.

Thermostats

Fan-coil controller

Room controller

A wide range of mechanical and electronic thermostats.

Thermostats A wide range of mechanical and electronic thermostats for wall or device box mounting.

Electronic thermostat for underfloor heating

Room thermostat, electronic

Room thermostat, electromechanical

13

MEET THE CHALLENGER

Electric heating controllers

Sensors, switches and detectors

For wall or DIN-rail mounting, as well as for 1-phase 230V, 2 and 3-phase 230V/400V.

Everything needed for indoor climate control.

Temperature Sensors for room, outdoor, clamp-on, duct and immersion applications. Available featuring the most common sensor elements.

Pressure With excellent long-term stability, few moving parts and fast reaction times. PULSER room controller

CO2/CO/NO2 Also available as a combined CO2 , temperature and humidity sensor.

PULSER controller for DIN-rail mounting

Humidity

Available only for humidity or as a combined humidity and temperature sensor. Room humidity sensor

TTC controller for DIN-rail mounting

Duct humidity sensor

Humidistats, wall or duct mounting

Flow

TTC controller for wall mounting

Stable output signal with temperature variation compensation. Flow switch

Air velocity transmitter

Presence detector

Smoke detectors

Step controllers

Ceiling

14

Wall

Ceiling

Duct

Control and alarm unit

MEET THE CHALLENGER

Accessories

Valves and actuators

Modems

Valves

District heating, hot water, domestic hot water, district cooling, coolant water, fan-coil. Wide range of products, from DN10 to DN150.

Transformers

2-way valves

Power supply unit

Zone valves

2- and 3-way control valves

Pressure independent control valves

Step controllers District heating valves

Flanged 2- and 3-way valves

Valve actuators

With 0…10 V, 3-position or on/off control signal. Thermal actuators for chilled ceilings, underfloor heating and air conditioning units (fan-coil).

Display units

Valve and actuator for fan-coil

Energy meters

Thermal actuators 100 - 140 N

Valve actuators 400 N

Valve actuator RVAN 500 - 2500 N

Damper actuators

Full range of damper actuators, with or without spring return.

Other accessories Casings

Manometer Damper actuators with spring return 4 Nm

Damper actuators with spring return 20 Nm

Damper actuators 5-40 Nm

15

MEET THE CHALLENGER

Regin Academy – knowledge and experience Our activities for more than sixty years have given us knowledge and experience that we want to share. This is why we have been running the Regin Academy for several years with the purpose of training integrators, distributors and other customers in our systems and products. The courses are based on our experience in building automation, as well as on our dialogue with consultants, integrators and property owners and managers.

16

MEET THE CHALLENGER

Our training centre allows you to gain understanding of our complete product range.

17

MEET THE CHALLENGER

Dynamic development Flexible manufacturing Every year, Regin dedicates approx. 10 % of its annual turnover to new product development. Our goal is to find new, intelligent solutions to help save energy. For instance, Regin's own valve centre in Osby has developed a new generation of valves with a sealing technology that makes them absolutely tight when closed. As a leader in the field, Regin now offers several valve series with this sealing technology, which will successively encom more valves.

Ready-Steady-Go makes the job easier Ready-Steady-Go is another example of how our development process is geared towards simplifying installation, commissioning and daily use. The concept can be found in the Corrigo, Regio and Optigo controllers, as well as in our FRS district heating valves.

18

Quality and flexibility in manufacturing Our products are manufactured by a group of selected partners, working with the absolute latest and most modern technology. Our task is to purchase materials and components, planning production, as well as a certain degree of assembly. This arrangement gives us complete control of the entire chain of production from prototyping to manufacturing, ensuring a guaranteed high production quality. At the same time, it provides an extremely high flexibility and short lead times.

MEET THE CHALLENGER

Helping OEM customers realise their ideas Regin has developed products and systems for controlling and monitoring indoor climate since 1947. Together with our production resources, this competence spells an asset for the numerous customers entrusting our OEM department with helping them realise everything from product design to a finished product. Since we have a long tradition in flow control, we also develop and produce valves and actuators for different OEM applications.

Our services: - Product design, construction - Prototyping - PCB assembly - Injection moulding of casings - Assembly - Testing (e.g. climate tests) - Application customisation - Programming - Customised packaging - Manuals, instructions

Examples of OEM applications: - Zone control - Ventilation - Heating/cooling - Dehumidification/humidification - Heat pumps - District heating/cooling - Circuit boards/PCB

19

MEET THE CHALLENGER

20

2 REGIN SYSTEMS

REGIN SYSTEMS

+8°C 21

2

REGIN SYSTEMS

A more efficient use of energy Residential and office buildings for 40 % of Europe's total energy consumption. Regin focuses on improving energy consumption in buildings the world over.

Our products and systems create energyefficient buildings with a high level of indoor comfort.

Solutions for improved energy efficiency Energy efficiency in buildings is greatly dependent on intelligent methods of control. A well-regulated system provides not only a greatly decreased energy consumption, but also improved levels of comfort. Since 1947, Regin has developed systems for improving energy use and comfort. Today, we offer the most comprehensive range of products and systems in the business, combined with over 60 years experience in rendering buildings more energy efficient and environmentally sustainable.

22

We offer complete solutions for control of everything from individual zones to entire buildings in numerous different types of geographic areas. This also includes one of the market’s broadest concepts in building automation, based on T/IP and the Internet.

REGIN SYSTEMS

2

Regin – a partner with resources and experience • Energy-efficient solutions since 1947 • Established in more than 70 countries • Installations all around the world • System solutions – from control of a single unit to complex systems for building automation • Complete range of products and systems – from field equipment to SCADA systems • Completely open systems allow integration and communication with systems operating with other standards and equipment of other brands

Integrators are the key A secure and cost-efficient installation is always based on system integrity, as well as product and component functionality. It is also important for the products to be installed and maintained by professional integrators. We have therefore created a network of competent and specialised integrators that are capable of offering a wide variety of services from planning and project handling to programming, installation, maintenance and service. As we do not work directly with our end customers we are in no way competing with our integrators.

• The broadest concepts in building automation in the market, based on T/IP and the Internet • Modular and flexible design for easy, cost-efficient system expansion • A network of professional integrators handling installation, commissioning and maintenance • No competition with our integrators • Training and seminars offered at Regin Academy • team offers technical and backing

23

REGIN SYSTEMS

Bus systems: • T/IP • BACnet • LON • KNX • EXOline • Modbus • M-Bus, SIOX

Communication: For communication between units and modules in the system and SCADA system. • T/IP • LAN/WAN • Internet • Cable • Satellite • GPRS • 3G • OPCserver • OPCclient

Management/

Integrators

EXOscada EXOdesigner Arrigo EXO OPC EXOflex

EXOflex

Building supervisors Corrigo with integrated web server

OTHER SCADA AND PRODUCTS

EXOcompact

Service and maintenance

CONTROL AND MONITORING

24

MANAGEMENT TOOLS

MANAGEMENT SYSTEMS FOR SMALL BUILDINGS

REGIN SYSTEMS

2 ROUTER

T/IP RS485 LON EXOline Modbus

VENTILATION/ AIR HANDLING EXOflex

EXOcompact

ZONE CONTROL

Regio Maxi R

EX8282

Regio Maxi RU

Regio Maxi RU

RS485

EX8282

Regio Midi

Regio Midi

KNX/EIB

Corrigo with integrated web server

Regio Midi

LIGHTING BLINDS ENTRANCE CONTROL

EXOflex

LOCAL MAINTENANCE/ SUPERVISION

EXOscada Nimbus PC

M-Bus M-Bus

EXOflex

HEATING/ COOLING

Corrigo

HEATING/COOLING

MANAGEMENT SYSTEMS FOR LARGE BUILDINGS

APPLICATIONS

25

REGIN SYSTEMS

SCADA software for complete control Regin SCADA Software specifically designed for use together with Regin’s EXO hardware. The result is a highly effective and -friendly building automation system with software that takes full advantage of all possibilities offered by the hardware.

EXOscada A complete and powerful SCADA system for the EXO system. EXOscada enables an operator to monitor and control system processes using a modern and intuitive interface, as well as to handle alarms and display historical values using reports and diagrams. The built-in report generator enables the creation of advanced reports.

Key features • • • • • • • • •

Dynamic visualization of plants and processes Alarm window with filtering function Time channel program Easy to change control curves A powerful history window Large template library for large server environments Scalable and vector-based graphics Script language available

Design tools The built in configuration tools makes it easy to create -friendly views in EXOscada. The huge library containing graphic symbols and SCADA images simplifies work even further. EXOscada also s animated symbols and offers many options for configuring the SCADA design according to your personal requirements.

SCADA/HMI software for operator stations EXOscada has a graphical interface, making all settings and commands very easy to use. The licensing system is flexible and can easily be adapted to various needs. A dongle and one or more licence codes are needed for every server running EXOscada. EXOscada can communicate via OPC with equipment of other brands using various communication protocols. The BACnet protocol features a driver as an accessory.

26

Article

Description

EXOSCADA-T

EXOscada Trial. Max. 75 I/Os, only one can be logged on at a time.

EXOSCADA-B

EXOscada Base. Max. 200 I/Os, up to three s can be logged on simultaneously.

EXOSCADA-BSD

EXOscada Base Soft Dongle

EXOSCADA-100

EXOscada 100 I/O. Add-on for EXOscada Base, adds another 100 I/Os.

EXOSCADA-500

EXOscada 500 I/O. Add-on for EXOscada Base, adds another 500 I/Os.

EXOSCADA-ULU

EXOscada Unlimited s. Add-on for EXOscada Base, an unlimited amount of s can be simultaneously logged on.

EXOSCADA-UL

EXOscada Unlimited. Add-on for EXOscada Base, unlimited amount of I/Os, an unlimited amount of s can be simultaneously logged on.

EXOSCADA-OPC

EXOscada OPC Connection. Add-on for EXOscada Base, OPC server connection.

EXOSCADA-BC

BACnet OPC server. Add-on for EXOscada Base, requires an EXOscada OPC licence.

EXOHOTEL

Hotel booking system. Add-on for EXOscada Base, requires an EXOscada OPC licence.

EXOSCADA-NIMBUS

Nimbus Alarm Server. Add-on for EXOscada Base with for Nimbus Alarm Server.

REGIN SYSTEMS

EXOscada at a glance

2

27

REGIN SYSTEMS

EXOscada upgrade agreement Provides secure and continuous access to the latest version of Regin’s software at a fixed annual rate. Regin’s upgrade agreement will let you feel safe in the knowledge that your programs will last you both now and into the future. At least once a year, we will also launch new functions which you can make use of directly. Price per server. Article

Description

EXOSCADA-UPGUL

EXOscada Unlimited Upgrade

EXOSCADA-UPG100

EXOscada 100 I/O Upgrade

EXOSCADA-UPG500

EXOscada 500 I/O Upgrade

EXOSCADA-UPG

EXOscada Base Upgrade

EXOSCADA-UPGBSD

EXOscada Base Soft Dongle Upgrade

EXOSCADA-UPGNIMBUS

EXOscada Nimbus Alarm Server Upgrade

EXOSCADA-UPG-OPC

EXOscada OPC Connection Upgrade

EXOSCADA-UPGULU

EXOscada Unlimited s Upgrade

SCADA Web Hotel SCADA Web Hotel is a complete and advanced web hosting service for property management. By connecting your buildings to SCADA Web Hotel, you can manage your properties via a web-based SCADA system and subscribe to different services, while at the same time avoiding investments in e.g. servers. The only thing needed is a computer with a web browser. We take care of daily operation, maintenance, software and hardware upgrades, etc. Please Regin for a quotation.

EXOopc Driver EXOopc Driver enables connecting EXO controllers to any software ing the OPC standard. This means that most SCADA software in the market today can be used together with Regin’s controllers. The system is programmed using EXOdesigner. The program can be prepared in advance on a PC and loaded into the system at installation. All the data will then be available via the OPC interface.

28

Article

Description

EXOOPC-DRIVER

EXOopc Driver

REGIN SYSTEMS

EXOhotel Hotel booking system EXOhotel is an add-on program for EXOscada which connects a hotel booking system running the Fidelio protocol to the full range of functionalities offered by the EXO system. Heating and cooling in each hotel room can be controlled to save energy when the room is empty and provide a comfortable indoor climate when the room is occupied. Article

Description

EXOHOTEL

Hotel booking system. Add-on for EXOscada Base, requires an EXOscada OPC licence.

Reduce energy costs by planning the bookings on each floor.

Integrate fire protection systems, facilitate fire extinguishing.

The corridor lighting is based on the time and occupancy.

Occupancy control common areas to achieve energy savings and safety.

Domestic hot water access based on the total number of guests.

Control the temperature, lighting, blinds and bathroom dryers when the guests check in/out. Open window turns the heating/cooling etc. off.

The ventilation in conference rooms is controlled by measuring the CO2 concentration.

Minimise the risk of leakage.

29

2

REGIN SYSTEMS

EXOdesigner Software tool for design and configuration of a complete EXO system. All EXO controllers are fully software compatible and are programmed using EXOdesigner, a PC-based development environment. The compatibility also applies across product generations, which means you only need to learn one programming tool and are free to change controllers in a system without having to rewrite all programs.

Controller Builder – Graphical programming without limitations Controller Builder is an integrated function that makes it easy to construct a system in EXOdesigner. An extensive library of functions is available. Controller Builder provides increased efficiency and speed with maintained flexibility. The function is compatible with all other parts of the EXO system.

30

Article

Description

EXODESIGNER

Development software

REGIN SYSTEMS

EXOflex – Freely programmable controllers Freely programmable controllers for building automation without limits The EXOflex controllers are primarily intended for use in systems with a large number of I/Os and high demands on communication and adaptability. EXOflex consists of processor and expansion housings available in one to four sections. Programming is made using EXOdesigner or in free EXOL code. The controller is tailored to its application by a selection of PIFA cards (Peripheral Interface Adapters). The cards are easily slotted into place in the housing and all connection ports are then accessible externally, offering easy connection of sensors, actuators, transmitters etc. The PIFA cards enable communication via protocols and field buses such as T/IP, LON, KNX/EIB, Modbus, SIOX and M-Bus. EXOflex also s communication via radio, telephone lines, GSM, cable, satellite, etc.

• • • • • •

For large buildings and integration of many buildings/ installations For systems with a large number of I/Os (cost-efficient for more than 75 I/Os) Easy to expand capacity and adding functions Communication via EXOline, T/IP, LON, KNX/EIB, Modbus, SIOX, M-Bus Gateway to the Arrigo web portal Large number of PIFA cards for different applications

31

2

REGIN SYSTEMS

EXOflex The EXOflex line of freely programmable controllers offers excellent possibilities for creating flexible and powerful systems for control, regulation, supervision and communication. An EXOflex unit can be used stand-alone or together with other EXOflex units and other types of equipment, in small or large systems. The modular design provides unique opportunities for adapting the number and type of inputs and outputs, as well as the type of communication.

Processor housings EXOflex consists of processor housings with one to four sections, each equipped with a main processor. The processor is programmed using EXOdesigner or in EXOL code.

Expansion housings Expansion housings, without a processor, make it possible to increase the functionality by adding more PIFA units.

PIFA units There is a wide range of PIFA units (Peripheral Interface Adapters) for adapting EXOflex to specific applications. All cards are of standardized design and size and can easily be slotted into place in the housings. Once a PIFA card has been mounted, all connection ports are accessible externally, offering easy connection of devices such as sensors and actuators. Most of the PIFA units have their own microprocessor, which facilitates programming and reduces the load on the EXOL processor.

External display unit The external display unit ED9200 can be used locally for viewing alarms, changing setpoint values, etc. Technical data* Operating system

EXOreal

Power supply

24 V DC

Operating temperature

0...50°C

Battery backup

Memory and real-time clock, at least 5 years

Dimensions (WxHxD mm)

1-section housing, 117 x 160 x 137 (EH10-S, EH11-S)2-section housing, 229 x 160 x 137 (EH20-S, EH21-S) 3-section housing, 341 x 160 x 137 (EH30-S, EH31-S) 4-section housing, 453 x 160 x 137 (EH40-S, EH41-S)

Mounting

35 mm DIN-rail, cabinet or wall

Protection class

IP20

Inputs Analogue inputs (AI)

0(4)...20 mA, 0...10 V DC, 0...200 mV, 0...2000 Ω, PT1000, PT100, DIN Ni1000, LGNi1000

Digital inputs (DI)

Floating switch, 24 V DC, configurable for pulse input

Outputs Analogue outputs (AO)

0...10 V DC

Digital outputs, communication (DO)

24 V DC, configurable for pulse output

Available interfaces

RS232/RS485 (EXOline, Modbus, etc.) T/IP, LON, EIB, SIOX, M-Bus. Other connections depend on the PIFA units installed.

* The input and output data depends on the choice of PIFA units.

32

REGIN SYSTEMS

Processor housings Processor housing, 1 section Processor housing with room for the Main Power PIFA and one additional PIFA unit. Article

Description

EH11-S

Processor housing, 1 section

Processor housing, 2 sections Processor housing with room for the Main Power PIFA and three additional PIFA units. Article

Description

EH21-S

Processor housing, 2 sections

Processor housing, 3 sections Processor housing with room for the Main Power PIFA and five additional PIFA units. Article

Description

EH31-S

Processor housing, 3 sections

Processor housing, 4 sections Processor housing with room for the Main Power PIFA and seven additional PIFA units. Article

Description

EH41-S

Processor housing, 4 sections

33

2

REGIN SYSTEMS

Expansion housings Expansion housing, 1 section Expansion housing with room for the Power PIFA for Extender and one additional PIFA unit. The expansion housing connects to the main processor via the EFX channel (115 200 bps). Article

Description

EH10-S

Expansion housing, 1 section

Expansion housing, 2 sections Expansion housing with room for the Power PIFA for Extender and three additional PIFA units. The expansion housing connects to the main processor via the EFX channel (115 200 bps). Article

Description

EH20-S

Expansion housing, 2 sections

Expansion housing, 3 sections Expansion housing with room for the Power PIFA for Extender and five additional PIFA units. The expansion housing connects to the main processor via the EFX channel (115 200 bps). Article

Description

EH30-S

Expansion housing, 3 sections

Expansion housing, 4 sections Expansion housing with room for the Power PIFA for Extender and seven additional PIFA units. The expansion housing connects to the main processor via the EFX channel (115 200 bps).

34

Article

Description

EH40-S

Expansion housing, 4 sections

REGIN SYSTEMS

PIFA units Main Power PIFA Has a socket for the EFX channel and battery backup for the EXOL-processors. LEDs indicating battery error, power supply and communication. Article

Description

EP1011

Main Power PIFA

Accessories Article

Description

X9035

Battery charger/UPS

Power PIFA for Extender Power supply for EXOflex expansion housings. Has a socket for the EFX channel. Article

Description

EP1004

Power PIFA for Extender

32 DI Multifunction PIFA Multifunction PIFA with 32 digital inputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

28 DI with standard functionality (filtering, on/off delay, operating-time measurement). 4 DI with advanced functionality (pulse counting, frequency measurement, etc.) in addition to the standard functions.

Digital inputs (DI)

Signal levels 0 V/24 V DC or floating switch

Article

Description

EP2032

32 DI Multifunction PIFA

16 DO Multifunction PIFA Multifunction PIFA with 16 digital outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

16 DO with standard functionality (on/off delay, pulse-width modulation, frequency generation, settable offline action)

Digital outputs (DO)

Signal levels 0 V/24 V DC current source, max. 0.5 A per output and max. 3.5 A simultaneously. Short-circuit protected thermal protection with software-based error handling (shortcircuit protected output).

Article

Description

EP3016

16 DO Multifunction PIFA

35

2

REGIN SYSTEMS

16 DI / 8 DO Mixed Multifunction PIFA Mixed Multifunction PIFA with 16 digital inputs and 8 digital outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

12 DI with standard functionality (filtering, on/off delay, operating time-measurement). 4 DI with advanced functionality (pulse counting, frequency measurement, etc.) in addition to standard functions. 8 DO with standard functionality (on/off delay, pulse-width modulation, frequency generation, settable offline action).

Digital inputs (DI)

Signal levels 0 V/24 V DC or floating switch

Digital outputs (DO)

Signal levels 0 V/24 V DC current source, max. 0.5 A per output and max. 2 A simultaneously. Short-circuit protected thermal protection with software-based error handling (shortcircuit protected output).

Article

Description

EP4024

16 DI / 8 DO Mixed Multifunction PIFA

12 AI Multisensor PIFA, 12-bit Multisensor PIFA with 12 analogue inputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

12 AI with possibility to set the measuring ranges individually

Analogue inputs (AI)

0...20 mA, 0...10 V DC, 0...200 mV, PT100, PT1000, Ni1000 DIN, LG-Ni1000, resistance 0...2000 Ω, etc. 12-bit A/D converter.

Article

Description

EP5012

12 AI Multisensor PIFA

12 AI Multisensor PIFA, 16-bit Multisensor PIFA with 12 analogue inputs for mounting in EXOflex housings. Technical data

36

Inputs/outputs (I/Os)

12 AI with possibility to set the measuring ranges individually

Analogue inputs (AI)

0...20 mA, 0...10 V DC, 0...200 mV, PT100, PT1000, Ni1000 DIN, Ni1000 LG, resistance 0...2000 Ω, etc. 16-bit A/D converter.

Article

Description

EP5112

12 AI Multisensor PIFA

REGIN SYSTEMS

12 AO Voltage Multifunction PIFA Voltage Multifunction PIFA with 12 analogue outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

12 AO

Analogue outputs (AO)

0...10 V DC, max. 20 mA, 11-bit resolution, scaling factor and offset, ramp generation, settable offline and power-up actions.

Article

Description

EP6012

12 AO Voltage Multifunction PIFA

12 AI / 6 AO Mixed Multifunction PIFA Mixed Multifunction PIFA with 12 analogue inputs and 6 analogue outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

12 AI for individually settable measuring ranges. 6 AO.

Analogue inputs (AI)

0...10 V DC, 0...200 mV, PT100, PT1000, Ni1000 DIN, LGNi1000, resistance 0...2000 Ω, etc. Accuracy: 0.1 % of the measuring range, 12-bit A/D converter.

Analogue outputs (AO)

0...10 V DC, max. 20 mA, 11-bit resolution, scaling factor and offset, ramp generation, settable offline and power-up actions.

Article

Description

EP7218

12 AI / 6 AO Mixed Multifunction PIFA

8 Mixed I/O and Serial PIFA (2 DI / 4 AI / 2 AO) 8 Mixed I/O and Serial PIFA with 2 digital inputs, 4 analogue inputs and 2 analogue outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

2 DI with standard functionality (filtering, on/off delay, operating time-measurement). 4 AI with possibility to set the measuring ranges individually. 2 AO.

Communication

1 serial port (Port 3), switchable between RS232, RS485 (EXOline) and hlEXOline. Can be complemented with option cards for modem, EIB, SIOX, etc. Can also be supplemented with an external M-Bus/SIOX connection.

Digital inputs (DI)

Signal levels 0 V/24 V DC or floating switch

Analogue inputs (AI)

0...20 mA, 0...10 V, 0...200 mV, PT100, PT1000, Ni1000 DIN, LG-Ni1000, resistance 0...2000 Ω, etc. Accuracy: 0.1 % of the measuring range, 12-bit A/D converter with digital filter, scaling factor and offset, monitoring of the measuring range.

Analogue outputs (AO)

0...10 V DC, max. 20 mA, 11-bit resolution, scaling factor and offset, ramp generation, settable offline and power-up actions.

Article

Description

EP7408

8 Mixed I/O and Serial PIFA (2 DI / 4 AI / 2 AO)

37

2

REGIN SYSTEMS

16 Mixed I/O PIFA (6 DI / 2 DO / 4 AI / 4 AO) Mixed I/O PIFA with 6 digital inputs, 2 digital outputs, 4 analogue inputs and 4 analogue outputs for mounting in EXOflex housings. Technical data Inputs/outputs (I/Os)

2 DI with standard functionality (filtering, on/off delay, operating time-measurement). 4 DI with advanced functionality (pulse counting, frequency measurement, etc.) in addition to the standard functions. 2 DO with standard functionality (on/off delay, pulse-width modulation, frequency generation, settable offline action). 4 AI with possibility to set the measuring ranges individually. 4 AO.

Digital inputs (DI)

Signal levels 0 V/24 V DC or floating switch

Digital outputs (DO)

Signal levels 0 V/24 V DC current source, max. 0.5 A per output and max. 0.8 A simultaneously. Short-circuit protected thermal protection with software-based error handling (shortcircuit protected output).

Analogue inputs (AI)

0...20 mA, 0...10 V, 0...200 mV, PT100, PT1000, Ni1000 DIN, LG-Ni1000, resistance 0...2000 Ω, etc. Accuracy: 0.1 % of the measuring range, 12-bit A/D converter with digital filter, scaling factor and offset, monitoring of the measuring range.

Analogue outputs (AO)

0...10 V DC, max. 20 mA, 11-bit resolution, scaling factor and offset, ramp generation, settable offline and power-up actions.

Article

Description

EP7416

16 Mixed I/O PIFA (6 DI / 2 DO / 4 AI / 4 AO)

Basic Serial PIFA Communication PIFA with one serial port. Can be complemented with option cards for modem, EIB, SIOX, etc. Can also be supplemented with an external M-Bus/SIOX connection. Article

Description

EP8101

Basic Serial PIFA

Dual Basic Serial PIFA Communication PIFA with two serial ports. Can be complemented with option cards for modem, EIB, SIOX, etc. Can also be supplemented with an external M-Bus/SIOX connection. Article

Description

EP8102

Dual Basic Serial PIFA

LON PIFA Communication PIFA for LonWorks. Direct connection of SNVTs to other LON-based units and systems. Max. 1024 SNVT variables/PIFA. Connected to the EFX channel.

38

Article

Description

EP8210

LON PIFA

REGIN SYSTEMS

T/IP PIFA Communication PIFA with Ethernet 10Base-T/100Base auto-negotiation for T/IP communication. Occupies one serial port (Port 3). s DH and DNS. Article

Description

EP8282

T/IP PIFA

Slot cover For covering empty PIFA slots in an EXOflex housing. Article

Description

EP0000

Slot cover

Card holder Article

Description

EH-CARDHOLDER

Card holders for EXOflex housings

39

2

REGIN SYSTEMS

Communication options Option KNX (EIB) X9017 is a KNX* communication card for connection to a KNX network via a KNX interface. The KNX interface is ordered by an external supplier. X9017 is intended for internal mounting in an EXOflex house, occupying Port 2 or Port 3. Requires that EP7408, EP8101 or EP8102 is installed. Article

Description

X9017

Option KNX (EIB)

* The EIB system and protocol have been updated and are now called KNX.

T/IP Gateway Communication gateway for T/IP communication, intended for connection of one or several controllers with serial communication to a computer network. Technical data Power supply

18...30 V AC or DC, 5 VA (connected to a network)

Internal serial port

RS232 or RS485, 9600 bps

Ethernet port

10 Base-T/100Base auto-negotiation

Max. cable length

100 m (min. CAT 5) m

Article

Description

EX8282

T/IP Gateway

Battery charger/UPS Battery charger for EXOflex. Charges two external 12 V batteries connected in series (sealed lead cells) for UPS functionality. Batteries are not included. Requires that EP1011 is installed.

40

Article

Description

X9035

Battery charger/UPS

REGIN SYSTEMS

Communication cable Communication cables for RS232 connection between a computer and the EXOflex Main Power PIFA (9pol D-Sub female and RJ45 male). Article

Description

Cable length

EK20

Communication cable, PC - EXOflex

2m

EK22

5m

EK24

10 m

41

2

REGIN SYSTEMS

EXOcompact – Freely programmable controllers The EXOcompact controllers are perfect for stand-alone applications, e.g. zone control, control of heating and air handling units, as well as for system integration. They have a powerful processor and are available in three sizes with 8, 15 or 28 I/Os, with or without display. Programming is performed in EXOdesigner. The controllers communicate via RS485, EXOline or Modbus with communication via LON and T/IP as an option. EXOcompact is available featuring one, two or three communication ports, enabling easy expansion of the number of I/Os for energy meters, PLC:s etc.

• • • • • • • • • • • •

Freely programmable with fixed I/O configuration For control of heating centrals, air handling units etc. 8, 15 or 28 I/Os, with or without display Digital outputs via Mosfet with 2 A, 24 V AC/DC Powerful processor Optional DC supply voltage Possible to expand the number of I/Os using two ports and expansion units based on EXOcompact without display One, two or three communication ports Programming is performed in EXOdesigner T/IP optional Communication via RS485 (EXOline or Modbus), T (EXOline-T, BACnet/IP), M-Bus (via external X1176 unit or internally for M-3 models) Complement to EXOflex in large automation systems

Please Regin for EXOcompact with LON communication.

42

REGIN SYSTEMS

Technical data Supply voltage

24 V AC ±15%, 50…60 Hz or 20…36 V DC

Power consumption

4 VA without load, no display

BTL approval

EXOreal version 3.1-1-02 or later

+C output

+ 24 V DC, 0.15 A, short-circuit proof

Operating system

EXOreal C

Battery backup

Memory and real-time clock, at least 5 years

Ambient temperature

0...50°C

Storage temperature

-20...+70°C

Ambient humidity

Max. 95 % RH

Display

Backlit, LCD, 4 rows of 20 characters, international character set

Dimensions (WxHxD)

149 x 121 x 60 mm

Casing

Polycarbonate, PC

Protection class

IP20

Mounting

DIN-rail or cabinet

Number of modules

8.5

Communication

RS485 (EXOline or Modbus with automatic detection/switchover), T (EXOline-T, BACnet/IP), M-Bus (via external X1176 unit or internally for M-3 models)

Inputs Analogue inputs (AI)

0(4)...20 mA, 0...10 V DC, 0...200 mV, PT1000, Ni1000 DIN, Ni1000 LG, 800...1600 Ω, 0...4000 Ω, 12-bit A/D

Digital inputs (DI)

Floating switch, 24 V DC, configurable for pulse input

Universal inputs (UI)

AI or DI (see above)

Outputs Analogue outputs (AO)

0...10 V DC, 5 mA, 12-bit D/A, short-circuit proof

Digital outputs (DO)

Mosfet 24 V AC/DC, 2 A. Totally max. 8 A.

24 V DC output

0.15 A, short-circuit proof

43

2

REGIN SYSTEMS

Controller with display Article

AI

DI

UI

AO

DO

RS485 ports

C81D-3

2

3

-

1

2

1

C151D-3

4

4

-

3

4

1

C281D-3

4

8

4

5

7

1

C282D-3

4

8

4

5

7

2

Controller without display Article

AI

DI

UI

AO

DO

RS485 ports

C81-3

2

3

-

1

2

1

C151-3

4

4

-

3

4

1

C281-3

4

8

4

5

7

1

C282-3

4

8

4

5

7

2

Controller with T/IP communication, with display Article

AI

DI

UI

AO

DO

RS485 ports

T/IP

Built-in M-Bus

C152DT-3

4

4

-

3

4

1

X

-

C282DT-3

4

8

4

5

7

1

X

-

C283DT-3

4

8

4

5

7

2

X

-

C283DTM-3

4

8

4

5

7

1

X

X

DO

RS485 ports

T/IP

Built-in M-Bus

Controller with T/IP communication, without display Article

AI

DI

AO

C152T-3

4

4

-

3

4

1

X

-

C282T-3

4

8

4

5

7

1

X

-

C283T-3

4

8

4

5

7

2

X

-

C283TM-3

4

8

4

5

7

1

X

X

Controller with LON communication Please Regin for a quotation.

44

UI

REGIN SYSTEMS

EXO accessories Front mounting kit for EXOcompact, Corrigo and Optigo Mounting kit for easier mounting of EXOcompact, Corrigo and Optigo in a control or cabinet door. Technical data Protection class

IP40

Article

Description

FMCE

Front mounting kit, room for one EXOcompact/Corrigo unit

Plug-in terminal blocks for EXOcompact, Corrigo and Optigo A set of angled plug-in terminal blocks for simple wiring of EXOcompact, Corrigo and Optigo when using the front mounting kits FMCE and FMCO. The terminal blocks enable easy access to the clamping screws even after cabinet mounting. Article

Description

PLTCE

Plug-in terminal blocks for EXOcompact/Optigo/Corrigo

Connection unit M-Bus/SIOX External interface converter for connection of meters to processor controllers. X1176 is connected to controllers with RS232, RS485 (EXOline) and hlEXOline. Meters are connected to X1176 via SIOX or M-Bus. Powered by 24 V DC or AC. IP65-classed polycarbonate casing. Article

Description

X1176

Connection unit M-Bus/SIOX

PC-cable for EXOflex and EXOcompact Cables for connecting EXOflex or EXOcompact to RS232 or USB standard. Article

Description

E-CABLE-RS232

Cable for RS232 connection

E-CABLE2-USB

Cable for USB connection

Battery Article

Description

BATTERY-4289

Battery for EP1011, EXOcompact, Corrigo

BATTERY-5518

Battery for 1304/1305

BATTERY-5702

Battery for 5540

45

2

REGIN SYSTEMS

EXOcompact demo kit Complete kit for testing the EXO system, containing an EXOcompact C283DT-3. Simply plug the controller into a wall socket and connect it to a computer running the EXO software to make simulations, trigger alarms, view indications, etc. Article

Description

E-CASE-C283DT-3-24

Complete kit for system evaluation

EXOflex mounting kit Four brackets for mounting an EXOflex controller on a backplate, as an alternative to DIN-rail mounting. Article

Description

X204-0052:4

EXOflex mounting kit

Repeater Repeater for connecting multiple units or for lengthening a cable. REPEAT485 is suitable in Regio systems since it provides galvanic isolation for RC controllers during communication. Article

Description

REPEAT485

Repeater, RS485

RS232 to RS485 converter RS232 to RS485 converter. Can be used together with a PC to convert the serial com port into RS485 when using EXOline. Article

Description

CONV232-485

RS232 to RS485 converter

EXOline to hlEXOline converter RS485 EXOline to hlEXOline converters. Can be used for communication over long distances or unshielded signal cables.

46

Article

Description

X1171A

EXOline to hlEXOline converter

X9021

EXOline to hlEXOline converter

REGIN SYSTEMS

Computer controller The embedded computer CC5 is a PC without a display. It can be used as a T/IP master or as an additional main computer. Technical data U type

Intel Atom N270 1.6 GHz

Flash memory

4 GB

RAM

1 GB

Ports

1 x COM port (RS232), 2 x USB ports, 1 x LAN port (Realtek RLT8111C 10/100/1000 Mbps), 1 x port for connection to a monitor

Supply voltage

Power supply unit for 12 V DC (2.5 A) included in the delivery

Mounting

Wall mounting, VESA 75 x 75 mm (mounting kit included)

Article

Description

CC5

Computer controller

Displays for mounting DP102 and DP156 are computers intended to be mounted in for example a cabinet door. They can easily be connected to Regin’s EXOscada and to Regin’s controllers, with or without integrated web. Technical data U type

Intel Atom N270 1.6 GHz

RAM

1 GB

Supply voltage

Power supply unit for 12 V DC (2.5 A) included in the delivery

Protection class

IP65

Mounting

Cabinet mounting, VESA 75 / 100 (screws included)

Article

Monitor size

Resolution

Flash memory

Ports

DP102

10.2”

1024 x 600

8 GB

3 x COM ports (RS232), 2 x USB ports, 1 x LAN port (Realtek RLT8111C 10/100/1000 Mbps)

DP156

15.6”

1366 x 768

4 GB

5 x COM ports (RS232), 2 x USB ports, 1 x LAN port (Realtek RLT8111C 10/100/1000 Mbps)

47

2

REGIN SYSTEMS

Replacement unit for 5540 controllers EXOflex for replacement of a 5540 controller using existing wiring. Technical data

48

Power supply

24 V DC

Accuracy

+ 1 % (0...20 mA)

Shunt resistors AI

10 Ohm (0...20 mA)

Dimensions (WxHxD)

5540, original: 268 x 115 x 118 mm / 5540, replacement: 258 x 160 x 160 mm

Mounting

DIN-rail (TS35)

Article

Description

5540-EXOFLEX

Replacement unit for 5540 controllers

REGIN SYSTEMS

I/O modules Regin’s I/O modules offer the possibility to expand the EXOflex and EXOcompact controllers. The I/O modules are available in models with 7, 10 or 16 in-/outputs. Integration of the I/O modules into an EXO system is intended for advanced system integrators only, as no specialised tools for the task are yet available. Up to 32 I/O modules can be connected but the limit is set by the system integrator and the application. Article

AI

DI

AO

LED

DO

Switches

Total number of I/Os

IO-RU-7

1

2 DI or CI

-

-

-

-

7

IO-RU-10

1

2 DI or CI

-

-

4

-

10

IO-16AI

16

-

-

-

-

-

16

IO-16DI

-

16

-

X

-

-

16

IO-16DO-M

-

-

-

X

16

X

16

IO-8DO8AI-M

8

-

-

X

8

X

16

IO-8DO8AO-M

-

-

8

X

8

X

16

IO-4X4-M

4

4

4

X

4

X

16

I/O module with 7 or 10 inputs/outputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. Technical data Supply voltage

18...30 V AC, 50...60 Hz

Power consumption

2.5 VA

Ambient temperature

0...50°C

Storage temperature

-20...70°C

Ambient humidity

Max. 90 % RH

Protection class

IP20

Communication

EXOline RS485

Communication speed

9600 bps

Built-in temperature sensor

NTC type, measuring range 0...50°C

Accuracy

±0.5°C at 15...30°C

Material, casing

Polycarbonate (PC)

Weight

110 g

Inputs Analogue inputs (AI)

PT1000, 0...50°C

Condensation input (CI)

Input for Regin’s condensation detector KG-A/1

Digital inputs (DI)

Closing potential-free

Universal inputs (UI)

Analogue input (AI), PT1000 sensor, 0...100°C or digital input (DI)

Outputs Digital outputs (DO)

24 V AC, max. 0.5 A.

Universal outputs (UO)

Digital output (DO) 24 V AC, max. 2.0 A or analogue output (AO), 0...10 V DC

Article

AI

DI

UI

DO

UO

Total number of I/Os

IO-RU-7

1

2 DI or CI

1

-

3

7

IO-RU-10

1

2 DI or CI

1

4

2

10

49

2

REGIN SYSTEMS

I/O module with 16 analogue inputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. Technical data Supply voltage

24 V AC/DC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Inputs

16 analogue, PT1000, Ni1000 (only CAN-Bus), microsensors, 0…10 kΩ, 0...10 V, 0(4)...20 mA

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 59 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-16AI

Input module

I/O module with 16 digital inputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. Terminal status indicated by LEDs. Technical data

50

Supply voltage

24 V AC/DC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Inputs

16 digital, potential-free closing between +C and DI, 24 V DC, can be configured as a pulse input

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 60 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-16DI

Input module

REGIN SYSTEMS

I/O module with 16 digital outputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. The outputs have manual switches which can be set to manual or auto position. Terminal status indicated by LEDs. Technical data Supply voltage

24 V AC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Outputs

16 digital, potential-free relay (closing), 24 / 230 V AC (not mixable), max. 1 A inductive load or 4 A resistive load

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 74 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-16DO-M

Output module

I/O module with 8 digital outputs and 8 analogue inputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. The outputs have manual switches which can be set to manual or auto position. Terminal status indicated by LEDs. Technical data Supply voltage

24 V AC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Inputs

8 analogue, PT1000, Ni1000 (only CAN-Bus), microsensors, 0…10 kΩ, 0...10 V, 0(4)...20 mA

Outputs

8 digital, potential-free relay (closing), 24 / 230 V AC (not mixable), max. 1 A inductive load or 4 A resistive load

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 74 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-8DO8AI-M

Input and output module

51

2

REGIN SYSTEMS

I/O module with 8 digital and 8 analogue outputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. The outputs have manual switches which can be set to manual or auto position. Terminal status indicated by LEDs. Technical data Supply voltage

24 V AC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Outputs

8 digital, potential-free relay (closing), 24 / 230 V AC (not mixable), max. 1 A inductive load or 4 A resistive load. 8 analogue, 0...10 V DC, 5 mA, 8 bit D/A, short-circuit proof.

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 74 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-8DO8AO-M

Output module

I/O module with 4 digital inputs, 4 analogue inputs, 4 digital outputs and 4 analogue outputs I/O module for expansion of Regin’s programmable EXOflex and EXOcompact controllers. The outputs have manual switches which can be set to manual or auto position. Terminal status indicated by LEDs. Technical data

52

Supply voltage

24 V AC ±15 %, 50…60 Hz

Power consumption

Max. 3.5 VA

Communication

EXOline, CAN-Bus

Inputs

4 digital, potential-free closing between +C and DI, 24 V DC, can be configured as a pulse input. 4 analogue, PT1000, Ni1000 (only CAN-Bus), microsensors, 0…10 kΩ, 0...10 V, 0(4)...20 mA.

Outputs

4 digital, potential-free relay (closing), 24 / 230 V AC (not mixable), max. 1 A inductive load or 4 A resistive load. 4 analogue, 0...10 V DC, 5 mA, 8 bit D/A, short-circuit proof.

Mounting

DIN-rail or in a standard casing

Number of modules

8.5

Operating temperature

0...50°C

Dimensions (WxHxD)

148 x 123 x 74 mm (incl. terminals)

Protection class

IP20

Article

Description

IO-4X4-M

Input and output module

3

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

CONTROLLERS AND THERMOSTATS FOR DIN-RAIL MOUNTING

-8°C +23°C +21°C

53

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Versatile, easy to handle controllers... Corrigo is a range of effective controllers which are easy to install and adjust according to your preferences. They can be used as stand-alone units or as part of a larger network.

Easy configuration The controller is supplied with pre-programmed applications and its settings can be configured using the buttons and display, or via a PC using the E tool© software, able free of charge from our web site.

54

24 V AC or 24 V DC Corrigo can be used with both 24 V AC or 24 V DC power supply. Connecting Corrigo to a UPS ensures transmission of alarms and important data even if the main power supply fails.

Available in different versions • With or without built-in display, an external display unit can also be connected. • 8, 15 or 28 I/Os, with expansion options, offers freedom to control many different functions. • Communication via RS485 (Modbus or EXOline), T/IP (EXOline and BACnet/IP) or LON. • One, two or three communication ports.

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

3

...that can be gathered in one place using our intelligent cloud service CLOUDigo – a cloud-based platform

Gathers several units

In today’s market, CLOUDigo is likely the easiest platform available for adding and managing controllers on-line without any programming being required. You will avoid typical problems like firewalls, which often require outside help.

CLOUDigo is the perfect solution for those with one or several Corrigos in the same building or spread out in different facilities. You will obtain a complete overview of all installations and will only have to a single address.

CLOUDigo handles everything for you! Using CLOUDigo, the only thing required is the serial number on the side of the controller. When a unit is added, a process picture is automatically constructed based on the configuration entered into the controller.

• • • • • • • •

Quick handling of controllers Only one single address to Easy access wherever you are No advanced IT skills required Stable and reliable for all mobile platforms (HTML5) Gathers several units Logged values

55

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Corrigo applications Ventilation control Control functions

Temperature control of:

1. 2. 3. 4. 5.

• Water heating, electric heating • Heat exchangers, mixing dampers • Water cooling, DX cooling

Supply air control Outdoor temperature compensated supply air control Cascaded room temperature control Cascade connected extract air temperature control Outdoor temperature dependent switching between room control and supply air control 6. Outdoor temperature dependent switching between extract air control and supply air control

Additional temperature control functions • • • • •

control heating/cooling Free cooling/heating Cooling recovery Enthalpy control External setpoint

Air control of: • 1-speed fan • 2-speed fan

Frequency converters via: • • • • • •

Pressure control Air flow control Manual rotational speed control in percentages One external 0…10 V input signal Supply air pressure control with slave controlled extract air Pressure controlled supply air with flow controlled extract air for balanced ventilation

Additional control functions • • • • •

Humidity control An extra control circuit for after-treatment Recirculation control Possible to expand with more inputs and outputs Two port models can control two VACON/Lenze/Omron/Emerson frequency converters via Modbus communication. • Pretreatment (type ”Puit Canadien”) • Energy visualizer: Software calculating the air handling unit’s energy consumption, enabling a reduced consumption of energy and examining whether an energy measure had the desired result. By connecting the signal to a supervisory logging system, it is possible to monitor energy consumption over time.

Air handling unit

56

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Heating, domestic hot water and boiler control Heating circuits (up to 3 circuits)

Domestic hot water (up to 2 circuits)

Boiler control

• One setpoint curve for each circuit • Pump control with pump stop saves energy • Frost protection • Wind compensation • Consideration to building inertia • Night setback • Power limitation

• Pump control • Daily overheating, preventing growth of Legionella • Night setback

• 1-4 boilers, of which one boiler can be configured for analouge control (0...10 V) • Modulating PI-control or thermostat control • Setpoint settings: fixed, dependent on outdoor temperature or current heating requirements of the heating circuits • Automatic switching between boilers if an alarm occurs • Pump control with automatic pump exercise • Limitation of return temperature to the boilers

Other functions • • • • • • • • •

Control of the storage tank pump Pressure control of a variable speed pump in order to maintain constant pressure in the system Cold and hot water monitoring via pulse and energy leakage alarms Digital timer channels for door locks, lighting etc. Possible to expand with more inputs and outputs Two port models can communicate with M-Bus meters New control circuit for district cooling with dew point control Control of by valve for district cooling Optimizer function

Boiler control

Heating and domestic water control

57

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Corrigo ventilation Corrigo running a ventilation application is intended for control of air handling units with temperature control, 1- or 2-speed operation or, alternatively, pressure or air flow control of supply air fan and extract air fan, humidity control as well as other common functions in ventilation. Technical data Supply voltage

24 V AC ± 15 %, 50...60 Hz or 21...36 V DC

Power consumption

8 VA, 4 W (DC), model E...W-3: 12 VA, 6 W (DC)

Ambient temperature

0...50°C

Storage temperature

-40...+50°C

Ambient humidity

Max. 90 % RH

Protection class

IP20

Connection

Disconnectable terminal strips, 4 mm2

Memory backup

Built-in long life battery gives long backup time of all settings incl. real time

Display

Backlit LCD (blue), 4 rows of 20 characters

Mounting

DIN-rail or cabinet

Number of modules

8.5

Dimensions (WxHxD)

149 x 121 x 60 mm

Languages

22

Communication ports T/IP

Web server, T/IP communication, BACnet/IP communication and Android application

RS485

EXOline and Modbus communication

Inputs Analogue inputs (AI)

For PT1000 sensors (accuracy ± 0.4°C) or 0...10 V DC (accuracy ± 0.15 % of full output signal). 12 bit resolution in the A/O conversion.

Digital inputs (DI)

For potential-free s

Outputs Analogue outputs (AO)

0...10 V DC, 1 mA, short-circuit proof

Digital outputs (DO)

Mosfet outputs, 24 V AC or DC, 2 A continuous. Max. 8 A in total.

Controller with display Article

AI

DI

UI

AO

DO

E81D-3

2

3

-

1

2

E151D-3

4

4

-

3

4

E281D-3

4

8

4

5

7

Controller without display

58

Article

AI

DI

UI

AO

DO

E81-3

2

3

-

1

2

E151-3

4

4

-

3

4

E281-3

4

8

4

5

7

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Controller with built-in web server and T/IP communication, with display Article

AI

DI

UI

AO

DO

RS485 ports

T/IP

E151DW-3

4

4

-

3

4

-

X

E152DW-3

4

4

-

3

4

1

X

E281DW-3

4

8

4

5

7

-

X

E282DW-3

4

8

4

5

7

1

X

E283DW-3

4

8

4

5

7

2

X

Controller with built-in web server and T/IP communication, without display Article

AI

DI

UI

AO

DO

RS485 ports

T/IP

E151W-3

4

4

-

3

4

-

X

E152W-3

4

4

-

3

4

1

X

E281W-3

4

8

4

5

7

-

X

E282W-3

4

8

4

5

7

1

X

E283W-3

4

8

4

5

7

2

X

Controller with LON communication, with display Article

Inputs

Outputs

E8D-S-LON

5

3

E15D-S-LON

8

7

E28D-S-LON

16

12

Technical data for these models differ from the rest, please Regin for more information.

Controller with LON communication, without display Article

Inputs

Outputs

E15-S-LON

8

7

E28-S-LON

16

12

Technical data for these models differ from the rest, please Regin for more information.

59

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Corrigo heating Corrigo running a heating application is intended for control of heating substations in buildings. The controller s control of up to 3 heating circuits and 2 DHW circuits. Corrigo heating also has builtin boiler control for a total of 4 boilers. It can also controll a cooling circuit with dew-point control. Technical data Supply voltage

24 V AC ± 15 %, 50...60 Hz or 21...36 V DC

Power consumption

8 VA, 4 W (DC), model E...W-3: 12 VA, 6 W (DC)

Ambient temperature

0...50°C

Storage temperature

-40...+50°C

Ambient humidity

Max. 90 % RH

Protection class

IP20

Connection

Disconnectable terminal strips, 4 mm2

Memory backup

Built-in long life battery gives long backup time of all settings incl. real time

Display

Backlit LCD (blue), 4 rows of 20 characters

Mounting

DIN-rail or cabinet

Number of modules

8.5

Dimensions (WxHxD)

149 x 121 x 60 mm

Languages

22

Communication ports T/IP

Web server, T/IP communication, BACnet/IP communication and Android application

RS485

EXOline and Modbus communication

Inputs Analogue inputs (AI)

For PT1000 sensors (accuracy ± 0.4°C) or 0...10 V DC (accuracy ± 0.15 % of full output signal). 12 bit resolution in the A/O conversion.

Digital inputs (DI)

For potential-free s

Outputs Analogue outputs (AO)

0...10 V DC, 1 mA, short-circuit proof

Digital outputs (DO)

Mosfet outputs, 24 V AC or DC, 2 A continuous. Max. 8 A in total.

Controller with built-in M-Bus, web server and T/IP communication, with display Article

AI

DI

UI

AO

DO

RS485 ports

T/IP

Built-in M-Bus

E152DWM-3

4

4

-

3

4

1

X

X

E282DWM-3

4

8

4

5

7

1

X

X

E283DWM-3

4

8

4

5

7

1

X

X

Controller with LON communication, with display Article

Inputs

Outputs

E8D-S-LON

5

3

E15D-S-LON

8

7

E28D-S-LON

16

12

Technical data for these models differ from the rest, please Regin for more information.

60

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Controller with LON communication, without display Article

Inputs

Outputs

E15-S-LON

8

7

E28-S-LON

16

12

Technical data for these models differ from the rest, please Regin for more information.

61

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Accessories for Corrigo Display unit for Corrigo Article

Cable length

Protection class

Compatible with

E-DSP-3

3m

IP44

Corrigo E...-S

E-DSP-10

10 m

IP44

Corrigo E...-S Corrigo E...-3

E3-DSP

Max. 100 m

IP40

ED9100-3

3m

IP41

Corrigo E...-S

ED9100-10

10 m

IP41

Corrigo E...-S

ED9100IP65-3

3m

IP65

Corrigo E...-S

ED9200

Max. 10 m (Corrigo E...-S), 100 m (Corrigo E...-3)

IP41

Corrigo E...-S/-3

ED9200IP65

Max. 10 m (Corrigo E...-S), 100 m (Corrigo E...-3)

IP65

Corrigo E...-S/-3

Accessories Article

Description

EDSP-K3

3 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

EDSP-K10

10 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

External graphic touch display For operation of a Corrigo ventilation with two ports. Intended for supervision and control of an air handling system. Technical data

62

Protection class

IP30

Power supply

24 V DC via terminal 4 (+C) and G0 on the Corrigo

Power consumption

50 mA

Connection cable

Twisted pair, 0.25 mm2

Display

TFT-LCD (resistive), backlit LED

Language

Swedish or English, set automatically depending on the language used in the Corrigo

Aspect ratio

4:3

Resolution

320 x 240

Dimensions (WxHxD)

120 x 90 x 27 mm

Mounting

On wall or device box

Communication

EXOline

Article

Description

ED-TCV

External graphic touch display

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

External room unit The ED-RU units are primarily intended for control of an air handling unit via a Corrigo controller running a ventilation application. They can be used to change fan speed, set temperature, extended running, etc. at a distance of up to 300 m. Their stylish design is suitable for all environments. The units have a built-in temperature sensor. An external PT1000-sensor can also be connected. Technical data

E D - RU

3

Supply voltage

24 V AC

Power consumption

25 mA

Protection class

IP20

Ambient humidity

Max. 90 % RH

Storage temperature

-20…+70°C

Mounting

On wall or device box

Dimensions (WxHxD)

95 x 95 x 28 mm

Communication

EXOline

E D - RU - O

E D - RU - F

ED - RU - FO

Article

Occupancy button

3-step fan control

Setpoint knob

Multi-function button

Hidden setpoint

Display

ED-RU

-

-

X

-

-

-

ED-RU-O

X

-

X

-

-

-

ED-RU-F

-

X

X

-

-

-

ED-RU-FO

X

X

X

-

-

-

ED-RU-DO

X

-

-

-

-

X

ED-RU-DFO

X

X

-

-

-

X

ED-RU-DOS

X

-

-

X

-

X

ED-RU-H

-

-

-

-

X

-

The ED-RU range can also be used together with EXOcompact and EXOflex. If so, the room units must first be configured by a competent system integrator via Project Builder.

ED - RU - D O

ED - RU - D FO

E D - RU - H

ED - RU - D O S

63

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Software for configuration of Corrigo E tool© is a PC-based configuration software with graphical interface. The program provides an excellent overview of the settings of the Corrigo. Using E tool© , all settings can be made on the computer and ed into the controller. An infinite number of configurations can be stored in the computer memory for later use. E tool© can be ed free of charge from our website. Article

Description

E-TOOL-S

PC software for fast and easy configuration, can be ed free of charge from our website.

Connection cables and plug-in terminals Article

Description

E-CABLE-RS232

Cable for RS232 connection

E-CABLE2-USB

Cable for USB connection

E-CABLE-T/IP

Cable for T/IP connection directly to a PC

PLT-E8

Set of plug-in terminals for E8 models

PLT-E15

Set of plug-in terminals for E15 models

PLT-E28

Set of plug-in terminals for E28 models

CLOUDigo – Cloud service for controller access CLOUDigo enables connection of Corrigo controllers with integrated web server to a in order to easily view and ister buildings. CLOUDigo s Corrigo version 3.0 and later. • • • • • •

Easy access to Corrigo via the Internet Automatically generated process picture Fixed IP is not required Internet access via 3G or directly Historical data is stored and can be exported to Excel s multiple s with different levels of access

Article

Description

CLOUDIGO

Cloud service for controller access

3G modem for CLOUDigo CLO-3G is a package consisting of a 3G modem with a factory-installed SIM card, ready for immediate connection to CLOUDigo. The modem functions as a gateway between a T/IP connected Corrigo and CLOUDigo. It has a built-in DH function that handles connecting to an external unit. Technical data

CLO-3G

Connection

Ethernet (RJ45, crossover network cable), antenna (SMA-F )

Communication

LAN (T/IP, DH), mobile network (3G or GSM/GPRS)

Ambient temperature

-30...+60°C

Article

Description

CLO-3G

3G modem with factory-installed SIM card for connecting to CLOUDigo

Accessories MOD E M 3 G ANT

64

Article

Description

MODEM3G-ANT

External antenna for MODEM3G with 3.6 m cable

E-CABLE-T/IP

Cable for T/IP connection directly to a PC

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Cabinets for Corrigo Turn-key ready cabinets developed for the Corrigo series. Can also be used for the EXOcompact controllers. All inputs and outputs are pre-connected to the terminals. The CAB-STD... units are delivered with trafo, switches, relays (CAB-STD2 and CAB-STD3, see the table below) and a wiring schematic for the cabinet. M-Bus can be used for dual port controllers by adding X1176. Article

Intended for

Dimensions (HxW)

Protection class

Relays

CAB-STD1

Corrigo E15...D... models

483 x 403 mm

IP65

-

CAB-STD2

Corrigo E15...D... models

483 x 403 mm

IP65

2

CAB-STD3

Corrigo E28...D... models

483 x 403 mm

IP65

3

Corrigo must be ordered separately.

Corrigo demo case Complete case with everything you need to test Corrigo. Simply plug the controller into the wall socket using the included transformer in order to make simulations, trigger alarms, view indications, etc. Technical data Supply voltage

24 V AC

Dimensions

28 x 38 x 9 cm (HxLxW)

Article

Description

E-CASE-E283DW-3-24

Demo case, contains a Corrigo E283DW-3 unit. Transformer included.

Front mounting kit for EXOcompact, Corrigo and Optigo Mounting kit for easier mounting of EXOcompact, Corrigo and Optigo in a control or cabinet door. Technical data Protection class Article

IP40 Description

FMCE

Front mounting kit, room for one EXOcompact/Corrigo unit

FMCO

Front mounting kit, room for one Optigo unit

Plug-in terminal blocks for EXOcompact, Corrigo and Optigo A set of angled plug-in terminal blocks for simple wiring of EXOcompact, Corrigo and Optigo when using the front mounting kits FMCE and FMCO. The terminal blocks enable easy access to the clamping screws even after cabinet mounting. Article

Description

PLTCE

Plug-in terminal blocks for EXOcompact/Optigo/Corrigo

Battery Article

Description

BATTERY-4289

Battery for EP1011, EXOcompact, Corrigo

65

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Optigo – The compact, versatile controller... There is no reason to “over-invest” in a controller with more functions than you need. A basic stand-alone controller is usually enough to control heating, cooling, air or humidity in a building. Optigo, our range of electronic controllers, is an excellent choice in this respect. It is a reliable and cost-efficient controller which solves all your basic control needs. Optigo is based on our experiences from the popular Aqualine range, which has been used in thousands of installations and units.

66

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

3

...which is handled using just a knob Optigo has a knob with an encoder (1) which makes the menu system very easy to use. You can read and set values shown in the back-lit display (2). A value is approved by pressing the knob.

Timer The timer handles for example night set-back, start or stop of fans during weekdays or during a day.

Quick and simple installation Optigo is suitable for DIN-rail (3) or cabinet mounting. Since the terminals (4) are detachable, all connections can be made before Optigo is installed. A mounting kit that makes the controller easier to front mount in a cabinet is available as an accessory.

67

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Optigo – Pre-programmed, stand-alone controllers The controller for simple applications Optigo is a series of compact, economic and versatile stand-alone controllers. They are pre-programmed and intended for smaller applications. The controllers are extremely easy to install, commission and control. Technical data Supply voltage

24 V AC ±15 % / OP10-230 : 230 V AC

Power consumption

4 VA

Ambient temperature

0...50°C

Storage temperature

-40…+50°C

Ambient humidity

Max. 90 % RH

Mounting

DIN-rail

Number of modules

7

Protection class

IP20

Display

Backlit LCD, numeric/graphic, language-independent symbols

Dimensions (WxHxD)

123 x 123 x 60 mm

Clock

Week-based 24-hour clock (OP10 only)

Inputs Analogue inputs (AI)

PT1000

Digital inputs (DI)

Closing potential-free

Universal inputs (UI)

0...10 V DC or digital

Setpoint input (SPI)

For an external PT1000 setpoint device, e.g. TG-R4/PT1000 or TBI-PT1000

Outputs Analogue outputs (AO)

0...10 V DC, short-circuit protected

Digital outputs (DO)

OP10 and OP10-230 only. Triac 24 V AC, 0.5 A (3-point control or alarm output) and one change-over relay 230 V AC, 5 A (fan start).

Inputs/Outputs (I/Os)

68

Article

AI

DI

UI

AO

DO

Total number of I/Os

OP5U

1

1

1

2

0

5

OP10

2

2

1

2

3

10

OP10-230

2

2

1

2

3

10

Article

Supply voltage

Number of I/Os

OP5U

24 V AC ±15 %

5

OP10

24 V AC ±15 %

10

OP10-230

230 V AC

10

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Front mounting kit for EXOcompact, Corrigo and Optigo Mounting kit for easier mounting of EXOcompact, Corrigo and Optigo in a control or cabinet door. Technical data Protection class

IP40

Article

Description

FMCE

Front mounting kit, room for one EXOcompact/Corrigo unit

FMCO

Front mounting kit, room for one Optigo unit

Plug-in terminal blocks for EXOcompact, Corrigo and Optigo A set of angled plug-in terminal blocks for simple wiring of EXOcompact, Corrigo and Optigo when using the front mounting kits FMCE and FMCO. The terminal blocks enable easy access to the clamping screws even after cabinet mounting. Article

Description

PLTCE

Plug-in terminal blocks for EXOcompact/Optigo/Corrigo

69

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Optigo applications Applications Optigo OP5U

Temperature control

Pressure control

CO2 control

Pressure control with outdoor compensation

General control (humidity, CO, etc.)

70

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Applications Optigo OP10

3

Supply air temperature control

Radiator circuit control with outdoor curve

Supply air temperature control with outdoor compensation

Domestic hot water control

Cascade connected, room temperature influenced supply air control

71

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

Thermostats for DIN-rail mounting Thermostat 1-stage, DIN-rail mounting Electronic thermostat for heating or cooling. Adjustable night setback via an external clock. Multiple thermostats can be connected to the same sensor. Technical data Outputs

One, 16 A, 250 V AC, closing relay

Setpoint

0...30°C

Hysteresis

0...10 K

Night setback

0...10 K

Sensor inputs

One Regin NTC sensor

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Dimensions (WxHxD)

53 x 85 x 74 mm

Article

Description

Supply voltage

TM1N/D

Electronic thermostat

230 V AC ±10 %, 3 VA

TM1N-24/D

Electronic thermostat

24 V AC ±10 %, 3 VA

Thermostat, 2-stage, DIN-rail mounting Thermostat with two relay outputs and individually settable steps for heating or cooling function. Sequential or binary function. Technical data Supply voltage

24 V AC, 2 VA

Outputs

Two, 10 A, 250 V AC, closing relays

Setpoint

0...30°C

Hysteresis

0.5...5 K

Step differential

0...5 K

Sensor inputs

One Regin NTC sensor

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Dimensions (WxHxD)

53 x 85 x 74 mm

Article

Description

TM2-24/D

Electronic 2-stage thermostat

Other temperature ranges Alternative setpoint scale for the TM1 and TM2 thermostats, when using sensors with other temperature ranges.

72

Article

Description

Temperature range

SKALA-1228

Scale for TM1N/D, TM1N-24/D and TM2-24/D

20...50°C

C O N T R O L L E R S A N D T H E R M O S T AT S F O R D I N - R A I L M O U N T I N G

Duct controllers Duct controller, one 0...10 V DC output Compact controller for mounting in ventilation ducts. The controller has a built-in sensor and setpoint control. An external setpoint potentiometer can be connected if required. Can be used to control either heating or cooling. P- or PI-control optional. AL24A1K has an input for change-over between heating and cooling. The change-over function can be activated by means of an external closing or a sensor mounted on the supply-water side of the heating/cooling unit. Technical data Supply voltage

24 V AC, 2 VA

Output

One, 0...10 V DC

Setpoint

0...30°C

P-band

0.5...50 K

I-time

2 min/20 min, selectable

Change-over

Input for closing or sensor (0...30°C)

Mounting

Duct

Protection class

IP65

Article

Description

AL24A1K

Duct controller, one 0...10 V DC output

73

3

C O N T R O L L E R S A N D T H E R M O S TA T S F O R D I N - R A I L M O U N T I N G

74

4

R O O M C O N T R O L L E R S / T H E R M O S TAT S

ROOM CONTROLLERS/ THERMOSTATS

4

-3°C +25°C

+21°C

75

R O O M C O N T R O L L E R S / T H E R M O S TA T S

R E G I O

Zone control on every level... Regio is a range of room controllers for heating, ventilation, air conditioning and corresponding functions.

Regio Mini The simple solution for stand-alone

Optimal flexibility Regio covers every need – from control of heating, cooling and ventilation to functions such as lighting, humidity, CO2 monitoring and blinds. Available in three different series, Regio also offers full system level flexibility. Regio enables you to create anything from a stand-alone system for managing the functions in a single room to large integrated SCADA systems.

Regio Midi A complete solution with built-in communication

Regio also offers web and Internet solutions, giving every employee individual control of the climate in his or her room using a PC connected to the office network. Regio is the ultimate solution in offices, schools, hotels, as well as in all buildings where optimal comfort and a low energy consumption is required without making costly investments.

Regio Maxi Freely programmable with communication and T-port

PC with Regio tool©

76

R E G I O

R O O M C O N T R O L L E R S / T H E R M O S TAT S

4

...with stylish design Regio has a modern design and a subtle elegance that enhances many indoor environments.

Applications • Chilled ceilings, chilled beams and radiators • Fan-coil systems • VAV systems • Control and monitoring of room temperature, air control and humidity, as well as control of lighting and blinds.

Key features

Regio has been developed in accordance to our Ready-Steady-Go concept, simplifying every step from installation to management.

• Stand-alone or integrated in a web-based system • Heating/cooling or both • Communication via RS485 (Modbus, BACnet or EXOline), T/IP or LON • Quick and easy configuration using the software Regio tool© • Comprehensive program of supplementary products

Regio Midi and Maxi are configured using Regio tool©, able free of charge from www.regin.se.

77

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Regio Maxi – Freely programmable/pre-programmed zone controllers Regio Maxi consists of R controllers prepared for quick connection of the RU room units. The controllers are compatible with other Regin products and can easily be integrated into systems with EXOflex, Corrigo, EXOcompact and EXOscada. The standard R model includes an application program for climate control in public buildings. It can also be used as a freely programmable room controller. Programming takes place in EXOdesigner, the same environment used for all other Regin system controllers. The R controllers can be used in systems with communication, e.g. EXOline, Modbus, T/IP or LON. They are installed in a ceiling void, on a junction box plate or on a DIN-rail.

Regio tool© The pre-loaded room application is configured in Regio tool©, able free of charge from www.regincontrols.com.

Product overview, Regio Maxi R100 and R200 are the basic models in the range. The other models have various functions, indicated by the letters in the product name: F = Fan control (3-speed), T = T/IP communication, L = LON commiunication Technical data Supply voltage

230 V AC ±10 %, 50...60 Hz

Power consumption

2 VA

Ambient humidity

Max. 95 % RH

Storage temperature

-40...+50°C

Mounting

Ceiling, on a junction box plate, or DIN-rail

Number of modules

8.6

Protection class

IP30 (IP20 cabinet mounting)

Inputs Analogue inputs (AI)

PT1000 (0...10 V DC)

Condensation input (CI)

Input for Regin’s condensation detector KG-A/1

Digital inputs (DI)

Potential-free closing

Outputs Analogue outputs (AO)

0...10 V DC

Digital outputs (DO)

Triac outputs: 24 V AC, 0.5 A / Relay outputs: 230 V AC, 4 A

Dimensions (WxHxD)

150 x 180 x 60 mm

Inputs/outputs (I/Os)

78

Article

AI

DI

CI

AO

DO, 230 V AC relay for fan control

DO, 24 V AC

Total number of I/Os

R100 / R100T / R100L

2

3

1

-

-

5

11

R100F / R100FT / R100FL

2

3

1

-

3

5

14

R200 / R200T / R200L

2

3

1

2

-

2

10

R200F / R200FT / R200FL

2

3

1

2

3

2

13

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Models with communication via RS485 (Modbus or EXOline) Article

3-step fan control

Output signal

Can be combined with

R100

-

3-point or on/off

RU, RU-O, RU-DO, RU-DOS

R100F

X

3-point or on/off

RU-F, RU-FO, RU-DFO, RU-DOS

R200

-

0...10 V DC

RU, RU-O, RU-DO, RU-DOS

R200F

X

0...10 V DC

RU-F, RU-FO, RU-DFO, RU-DOS

Models with T/IP communication Article

3-step fan control

Output signal

Can be combined with

R100T

-

3-point or on/off

RU, RU-O, RU-DO, RU-DOS

R100FT

X

3-point or on/off

RU-F, RU-FO, RU-DFO, RU-DOS

R200T

-

0...10 V DC

RU, RU-O, RU-DO, RU-DOS

R200FT

X

0...10 V DC

RU-F, RU-FO, RU-DFO, RU-DOS

Models with LON communication Article

3-step fan control

Output signal

Can be combined with

R100L

-

3-point or on/off

RU, RU-O, RU-DO, RU-DOS

R100FL

X

3-point or on/off

RU-F, RU-FO, RU-DFO, RU-DOS

R200L

-

0...10 V DC

RU, RU-O, RU-DO, RU-DOS

R200FL

X

0...10 V DC

RU-F, RU-FO, RU-DFO, RU-DOS

By connecting R to a PC with Regio tool©, it is possible to control the conditions in a room.

79

4

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Room units for the R controllers There are seven different room units (RU) in the Regio Maxi range, with or without display. They are intended to be combined with the freely programmable R controllers and are installed directly on the wall or on a wall socket. RU is the basic model. The other models have various functions, indicated by the letters in the product name: RU

D = Display, F = Fan speed control button, O = Occupancy button, S = Multifunction button Technical data

RU - F

Power supply

From R unit

Ambient humidity

Max. 90 % RH

Ambient temperature

0...50°C

Storage temperature

-20...+70°C

Mounting

Wall

Protection class

IP20

Display

Backlit, LCD

Article

RU - O

RU - D O

RU - FO

RU - D FO

RU - D O S

80

Display

Occupancy button

CO2, blinds, lighting, humidity

3-step fan control

Setpoint knob

RU

-

-

-

-

X

RU-F

-

-

-

X

X

RU-O

-

X

-

-

X

RU-DO

X

X

-

-

-

RU-FO

-

X

-

X

X

RU-DFO

X

X

-

X

-

RU-DOS

X

X

X

X

-

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Regio Maxi accessories Article

Description

RU-CBL3

Cable for Regio Maxi, between RU and R, cable length 3 m

RU-CBL10

Cable for Regio Maxi, between RU and R, cable length 10 m

R-CONN:10

A set of 10 connector plates for Regio Maxi R

R-CASE

Regio Maxi R demo kit

REGIO BOX

Regio Maxi R + RU demo kit

4

81

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Regio Midi – Pre-programmed room controllers with communication Regio Midi are controllers with a built-in sensor and an RS485 communication port. Controllers in different rooms can be connected to a bus line enabling communication with a central SCADA system via RS485 (EXOline, BACnet or Modbus).

Regio tool© The room controllers are pre-programmed and can be configured to suit specific needs with the software Regio tool©, able free of charge from www.regincontrols.com.

Product overview, Regio Midi RC-C is the basic model in the range. The other models have various functions, indicated by the letters in the product name: RC-C3H, RC-CTH

C = Communication, D = Display, F = Fan control button, H = Hidden setpoint, O = Occupancy button, T = 3-point output, C (at the end) = CO2 input, 3 = Three universal outputs Technical data

RC-C3, RC-CT

R C - C 3 O, R C - C TO

Supply voltage

18...30 V AC, 50...60 Hz

Power consumption

2.5 VA

Ambient temperature

0...50°C

Storage temperature

-20…+70°C

Ambient humidity

Max. 90 % RH

Communication

RS485 (EXOline or Modbus with automatic detection/changeover, or BACnet)

Modbus

8 bits, 1 or 2 stop bits. Odd, even (FS) or no parity.

Communication speed

9600, 19200, 38400 bps (EXOline, Modbus and BACnet) or 76800 bps (BACnet only)

Built-in temperature sensor

0...50°C NTC linearised 15 kΩ

Accuracy

±0.5°C at 15...30°C

Mounting

Wall

Protection class

IP20

Inputs

RC-C3DOC, R C - C D TO

Analogue inputs (AI)

PT1000, 0...50°C, 0...10 V (CO2)

Condensation input (CI)

Input for Regin’s condensation detector KG-A/1

Digital inputs (DI)

Closing potential-free

Universal inputs (UI)

Analogue input (AI), PT1000 sensor, 0...100°C or digital input (DI)

Outputs

RC-CF

R C - C FO

R C - C D FO

82

Digital outputs (DO)

24 V AC, max. 0.5 A

Universal outputs (UO)

Digital output (DO) 24 V AC, max. 2.0 A or analogue output (AO), 0...10 V DC, max. 5 mA

+C power output for DI only

24 V DC, max. 10 mA, short circuit-protected

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Inputs/outputs (I/Os) Article

AI

DI

UI

Display

UO

Total number of I/Os

RC-C3

1

2

1

-

3

7

RC-C3H

1

2

1

-

3

7

RC-C3O

1

2

1

-

3

7

RC-C3DOC

2

2

-

X

3

7

RC-CF

1

2

1

-

2

10

RC-CFO

1

2

1

-

2

10

RC-CDFO

1

2

1

X

2

10

RC-C3DFOC

2

2

-

X

3

7

RC-CT

1

2

1

-

-

9

RC-CTH

1

2

1

-

-

9

RC-CTO

1

2

1

-

-

9

RC-CDTO

1

2

1

X

-

9

4

Model overview Article

Display

Occupancy button / Forced ventilation

3-step fan control

EC fan control

Setpoint knob

Hidden setpoint

Output

3 universal outputs

RC-C3

-

-

-

X

X

-

0...10 V DC or on/off

X

RC-C3H

-

-

-

X

-

X

0...10 V DC or on/off

X

RC-C3O

-

X

-

X

X

-

0...10 V DC or on/off

X

RC-C3DOC

X

X

-

X

-

-

0...10 V DC or on/off

X

RC-CF

-

-

X

-

X

-

0...10 V DC or on/off

-

RC-CFO

-

X

X

-

X

-

0...10 V DC or on/off

-

RC-CDFO

X

X

X

-

-

-

0...10 V DC or on/off

-

RC-C3DFOC

X

X

X

X

-

-

0...10 V DC or on/off

X

RC-CT

-

-

-

-

X

-

3-point

-

RC-CTH

-

-

-

-

-

X

3-point

-

RC-CTO

-

X

-

-

X

-

3-point

-

RC-CDTO

X

X

-

-

-

-

3-point

-

RC-CT, RC-CTH and RC-CTO are non-stock items.

83

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Regio Mini – Pre-programmed room controllers Stand-alone controllers for control of heating and cooling in a single zone or room The Regio Mini controllers are pre-programmed and can be configured for a specific application via the display or dipswitches (in most cases, though, the default settings can be applied). The controllers have a built-in temperature sensor. Alternatively, an external temperature sensor can be connected. RC-H

RC is the basic model in the range. The other models have various functions, indicated by the letters in the product name: D = Display, F = Fan control (3-speed), H = Hidden setpoint, O = Occupancy button, T = 3-point output Technical data

RC, RC-T

R C - O, R C - TO

R C - D O, R C - D TO

Supply voltage

18...30 V AC, 50...60 Hz

Power consumption

2.5 VA

Ambient temperature

0...50°C

Storage temperature

-20...+70°C

Built-in temperature sensor

0...50°C NTC linearised 15 kΩ

Accuracy

±0.5°C at 15...30°C

Mounting

Wall

Protection class

IP20

Inputs Analogue inputs (AI)

PT1000, 0...50°C

Condensation input (CI)

Input for Regin’s condensation detector KG-A/1

Digital inputs (DI)

Closing potential-free

Universal inputs (UI)

Analogue input (AI), PT1000 sensor, 0...100°C or digital input (DI)

Outputs Digital outputs (DO)

24 V AC, max. 0.5 A.

Universal outputs (UO)

Digital output (DO) 24 V AC, max. 2.0 A or analogue output (AO), 0...10 V DC, max. 5 mA

+C power output for DI only

24 V DC, max. 10 mA, short circuit-protected

Inputs/outputs (I/Os) RC-F

R C - FO

Article

AI

DI

UI

DO

UO

Total number of I/Os

RC

1

2

1

1

2

7

RC-O

1

2

1

1

2

7

RC-H

1

2

1

1

2

7

RC-DO

1

2

1

1

2

7

RC-F

1

2

1

4

2

10

RC-FO

1

2

1

4

2

10

RC-DFO

1

2

1

4

2

10

RC-T

1

2

1

5

-

9

RC-TO

1

2

1

5

-

9

RC-DTO

1

2

1

5

-

9

R C - D FO RC-TO is a non-stock item.

84

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Model overview Article

Occupancy button / Forced ventilation

3-step fan control

Setpoint knob

RC

-

-

X

RC-O

X

-

X

RC-H

-

-

-

RC-DO

X

-

-

RC-F

-

X

X

RC-FO

X

X

X

RC-DFO

X

X

-

RC-T

-

-

X

RC-TO

X

-

X

RC-DTO

X

-

-

85

4

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Regio accessories Relay unit for Regio RC-...F... controllers in fan-coil applications Technical data Outputs

Three closing relays, 230 V AC, 4 A

Inputs

Three inputs, 24 V AC, from an RC-...F... unit

Mounting

DIN-rail

Protection class

IP00

Article

Description

RB3

Relay unit for RC-...F... controllers

Power interface for Regio RC-...F... controllers in fan-coil applications Article

Description

X1178

Power interface for RC-...F... controllers

Service adapter Article

Description

RC-TEST

Service adapter for Regio Midi units

Condensation detector Article

Description

KG-A/1

Condensation detector for Regio controllers, 1 m cable length

Connector plates

86

Article

Description

RC-CONN:10

A set of 10 connector plates for RC units

R O O M C O N T R O L L E R S / T H E R M O S TAT S

4

The RCF range has a stylish design inspired by the award-winning Regio range.

Energy-efficient control of fan-coil units The RCF range’s stand-alone controllers and thermostats for fan-coil units can be used for zone control of heating and/or cooling. Rooms that are heated or cooled when unoccupied, or when a window is open, are a pure waste of energy. By connecting RCF to an occupancy detector, a keycard switch or a window , temperature and air flow are controlled automatically from the occupancy in the room. If a window is open, heating and cooling will be blocked. This way, room comfort is maintained at a comfortable level at the same time as saving energy.

Systems: • Heating/cooling water • Electric heating • 2-pipe systems • 2- or 4-pipe systems Control of: • 3-position actuators • Thermal actuators • On/Off actuators • 0…10 V DC actuators Functions: • 3-speed fan • Connection of occupancy detector, keycard switch or window • Automatic or manual (M models) changeover between heating/cooling • Automatic valve exercise • Models with communication (EXOline, BACnet or Modbus)

87

R O O M C O N T R O L L E R S / T H E R M O S TA T S

For all types of fan-coil units and premises QFDK "ägir II" chilled water cassette

The RCF range can control all types of fan-coil units and is suitable in applications where a high comfort level and low energy consumption is desired.

88

• • • • • •

Hotels Conference rooms Offices Shops Schools Hospitals etc.

QFDK "ägir II" chilled water cassette

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Controllers and thermostats for fan-coil applications Fan-coil thermostat with on/off outputs Electronic fan-coil thermostats for room temperature control. Automatic or manual change-over between heating and cooling. The thermostats have a function for control of a 3-speed fan (for fan-coil), a built-in temperature sensor, backlit display, and an input for a window or an occupancy detector. RCF230CD has communication via RS485 (Modbus, BACnet or EXOline) for integration into systems. Technical data

RC F- 2 3 0 ( C ) D

RC FM - 2 3 0 D

4

Supply voltage

230 V AC ±10 %, 50/60 Hz

Power consumption

< 3 VA

Setpoint

5...35°C

Hysteresis

±0.5 K (adjustable)

Digital outputs (DO)

Three relay outputs for fan control, 230 V AC, 3 A / Two triac outputs for valve actuators, 230 V AC, 300 mA

Analogue inputs (AI)

One PT1000

Digital inputs (DI)

One closing potential-free

Universal inputs (UI)

One PT1000 or closing potential-free

Mounting

Wall

Protection class

IP20

Article

Description

Installations

RCF-230D

Fan-coil thermostat

2- or 4-pipe

Change-over function Automatic

RCF-230CD

Fan-coil thermostat with communication via RS485 (Modbus, BACnet or EXOline)

2- or 4-pipe

Automatic

RCFM-230D

Fan-coil thermostat

2-pipe

Manual

89

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Fan-coil controller for thermal or 3-point actuators Electronic fan-coil controllers for room temperature control. Automatic or manual change-over between heating and cooling. The controllers have a function for 3-speed fan control (for fan-coil), a built-in temperature sensor, backlit display, and an input for a window or an occupancy detector. RCF-230TD and RCF-230CTD also has a function for control of an electric heater. RCF-230CTD has communication via RS485 (Modbus, BACnet or EXOline) for integration into systems. The hysteresis is freely settable. RCF - 2 3 0 ( C ) T D

RC FM - 2 3 0 T D

Technical data Supply voltage

230 V AC ±10 %, 50/60 Hz

Power consumption

< 3 VA

Setpoint

5...35°C

Hysteresis

±0.5 K

P-band

10°C

I-time

300 s

Digital outputs (DO)

Three relay outputs for fan control, 230 V AC, 3 A / Two triac outputs for valve actuators, 230 V AC, 300 mA

Analogue inputs (AI)

One PT1000

Digital inputs (DI)

One closing potential-free

Universal inputs (UI)

One PT1000 or closing potential-free

Mounting

Wall

Protection class

IP20

Article

Description

Installations

Change-over function

RCF-230TD

Fan-coil controller

2- or 4-pipe

Automatic

RCF-230CTD

Fan-coil controller with communication via RS485 (Modbus, BACnet or EXOline)

2- or 4-pipe

Automatic

RCFM-230TD

Fan-coil controller

2-pipe

Manual

EC fan controller for thermal or 3-point actuators Electronic fan-coil controller for control of EC fans. Automatic or manual change-over between heating and cooling. The controller has a function for EC fan control, a built-in temperature sensor, backlit display, and an input for a window or an occupancy detector. It also has a function for control of an electric heater. RCF-230CTD-EC has communication via RS485 (Modbus, BACnet or EXOline) for integration into systems. The hysteresis is freely settable. Technical data

90

Supply voltage

230 V AC ±10 %, 50/60 Hz

Power consumption

< 3 VA

Setpoint

5...35 °C

Hysteresis

±0.5 K

P-band

10°C

I-time

300 s

Analogue outputs (AO)

One for EC fan control, 0...10 V DC, max. 1 mA

Digital outputs (DO)

Two triac outputs for valve actuators, 230 V AC, 300 mA

Analogue inputs (AI)

One PT1000

Digital inputs (DI)

One closing potential-free

Universal inputs (UI)

One PT1000 or closing potential-free

Mounting

Wall

Protection class

IP20

Article

Description

Installations

Change-over function

RCF-230CTD-EC

Fan-coil controller for EC fans with communication via RS485 (Modbus, BACnet or EXOline)

2- or 4-pipe

Automatic

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Fan-coil controller with 0...10 V control signal Electronic fan-coil thermostats for room temperature control. The controllers have automatic changeover between heating and cooling and can be used for 2- or 4-pipe systems. They have a function for control of a 3-speed fan (for fan-coil), a built-in temperature sensor, backlit display, and an input for a window or an occupancy detector. RCF-230CAD has communication via RS485 (Modbus, BACnet or EXOline) for integration into systems. The hysteresis is freely settable. Technical data Supply voltage

230 V AC ±10 %, 50/60 Hz

Power consumption

< 3 VA

Setpoint

5...35°C

Hysteresis

±0.5 K

P-band

10°C

I-time

300 s

Digital outputs (DO)

Three relay outputs for fan control, 230 V AC, 3 A

Analogue outputs (AO)

Two for valve actuators, 0...10 V DC, max. 1 mA

Analogue inputs (AI)

One PT1000

Digital inputs (DI)

One closing potential-free

Universal inputs (UI)

One PT1000 or closing potential-free

Mounting

Wall

Protection class

IP20

Article

Description

RCF-230AD

Fan-coil controller

RCF-230CAD

Fan-coil controller with communication via RS485 (Modbus, BACnet or EXOline)

91

4

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Room controllers 0...10 V DC or 3-point room temperature controller AL24A1T is primarily intended for control of heating or cooling in zone control systems. It has an input for a presence detector (occupancy control). The controller also has an input for change-over, which makes it possible for the control function to switch between heating and cooling. Technical data Supply voltage

24 V AC, ±15 % 50...60 Hz, 2 VA

Output

0...10 V DC, 1 mA or 3-point, 24 V AC, 1 A

Inputs

Two digital and one Regin NTC sensor

Setpoint

0...40°C

P-band

0.5...50 K

Protection class

IP20

Article

Description

AL24A1T

Room temperature controller

3-point room controller with active frost protection Controller intended for control of valve actuators in water-heated systems. AQUA24TF has a built-in room sensor and can be used for control of supply air temperature or room temperature, with or without cascade control. The controller has built-in active frost protection with two alarm relays and automatic heat maintaning function during shutdown. Technical data

92

Supply voltage

24 V AC ±10 %

Power consumption

Max. 5 VA

Control signal (output)

3-point floating control, 24 V AC output (heating)

Sensor inputs

Three 0...30°C (the sensor determines the range (Regin NTC sensor))

Setpoint

0...30°C

Minimum limit

0...30°C (not active for single sensor control)

Cascade factor (CF)

1...15 (must be set to 1 for single sensor control)

Frost alarm setpoint

5

Shutdown mode setpoint

25°C

Fan relay

Breaking for fan or interlock if a frost protection alarm occurs. 230 V AC, 2 A.

Alarm relay

Change-over for alarm indication if a frost protection alarm occurs. 24 V AC, 2 A.

Mounting

Wall

Protection class

IP20

Article

Description

AQUA24TF

Room controller with active frost protection

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Room thermostats Electromechanical room thermostat Room thermostat for control of HVAC systems. The thermostat can control fans, cooling units, electric heaters, etc. Technical data

NO/NC 250 V AC 16 (2,5) A

Temperature range

7...30°C

Ambient temperature

50°C

Ambient humidity

Max. 90 % RH

Casing

ABS, fireproof in accordance with UL94 V-0, white

Weight

128 g

Protection class

IP20

Article

On/off button

Summer/winter switch

R31

-

-

R33

X

-

R34

-

X

Electromechanical room thermostat for fan-coils The thermostat has a switch for cooling or heating/cooling depending on the model, as well as a switch for fan speed control. Technical data Output

10 (3) A, 250 V AC

Setpoint

10...30°C

Hysteresis

0.6 K

Mounting

Wall

Protection class

IP20

Article

Function

RRT025A

Heating or cooling switch

RRT025B

Cooling switch

93

4

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Floorigo – Electronic thermostats for flush-mounting Electronic room thermostat for underfloor heating, with sensor Electronic 1-stage thermostat with an on/off switch, intended for flush mounting. The thermostat is delivered with a floor sensor and has an input for an external sensor. It has a min. and max. limitation feature and night setback function. The unit is supplied with a front cover which fits ELKO casings. Technical data Supply voltage

230 V AC, 6 VA

Output

13 A, 230 V AC, closing relay

Sensor inputs

One for an external sensor, NTC 0...40°C

Setpoint

0...40°C

Night setback

5K

Hysteresis

0.4 K

Mounting

Flush mounting

Protection class

IP21

Article

Description

FL1-S

Electronic room thermostat

Electronic room thermostat with display for underfloor heating Electronic 1-stage thermostat with display and an on/off switch, intended for flush mounting. It has a week-based scheduler with energy saving mode. The thermostat is delivered with a floor sensor and has an input for an external sensor. It has a min. and max. limitation feature and night setback function. The unit is supplied with a front cover which fits ELKO casings. Technical data

94

Supply voltage

230 V AC, 6 VA

Output

13 A, 230 V AC, closing relay

Sensor inputs

One for an external sensor, NTC 0...40°C

Setpoint

0...40°C

Night setback

5K

Hysteresis

0.4 K

Mounting

Flush mounting

Protection class

IP21

Article

Description

FL1-D

Electronic room thermostat

R O O M C O N T R O L L E R S / T H E R M O S TAT S

Electronic room thermostat for underfloor heating Floorigo FL1TP is an electronic 1-stage thermostat with an on/off switch. It is intended for flush mounting. The thermostat has manual output and does not need to be connected to an external sensor. It has a time-proportional output 10...100 % and fits in an ELKO casing. Technical data Supply voltage

230 V AC, 6 VA

Output

13 A, 230 V AC, closing relay

Setpoint

1...10°C

Cycle time

30 min

Mounting

Flush mounting

Protection class

IP20

Article

Description

FL1TP

Electronic room thermostat

95

4

R O O M C O N T R O L L E R S / T H E R M O S TA T S

Electronic thermostats Electronic room thermostat, 1-stage Electronic thermostats intended for heating or cooling with built-in sensor and input for an external sensor. Technical data

96

Supply voltage

230 V AC ±10 %, 1 VA

Outputs

16 A, 230 V AC, change-over relay

Setpoint

0...30°C, 20...50°C

Hysteresis

1K

Sensor inputs

One Regin NTC sensor

Mounting

Wall

Protection class

IP30

Article

Temperature range

TM1-P

0...30°C

TM1-50

20...50°C

5

E L E C T R O M E C H A N I C A L T H E R M O S TAT S

ELECTROMECHANIC AL THERMOSTATS

5

+21°C

-7°C 97

E L E C T R O M E C H A N I C A L T H E R M O S TA T S

Electromechanical room thermostat Room thermostat for control of HVAC systems. The thermostat can control fans, cooling units, electric heaters, etc. Technical data

NO/NC 250 V AC 16 (2,5) A

Temperature range

7...30°C

Ambient temperature

50°C

Ambient humidity

Max. 90 % RH

Casing

ABS, fireproof in accordance with UL94 V-0, white

Weight

128 g

Protection class

IP20

Article

On/off button

R31

-

Summer/winter switch -

R33

X

-

R34

-

X

Electromechanical room thermostat for fan-coils The thermostat has a switch for cooling or heating/cooling depending on the model, as well as a switch for fan speed control. Technical data

98

Output

10 (3) A, 250 V AC

Setpoint

10...30°C

Hysteresis

0.6 K

Mounting

Wall

Protection class

IP20

Article

Function

RRT025A

Heating or cooling switch

RRT025B

Cooling switch

E L E C T R O M E C H A N I C A L T H E R M O S TAT S

Electromechanical frost protection thermostat FT is a series of high quality electromechanical frost protection thermostats for use in cooling, heating and ventilation systems. The DR-05 set of mounting brackets is included upon delivery. Technical data Temperature range

-10...+10°C

s

SPDT microswitch

Switch capacity

15 (8) A, 24...250 V AC

Accuracy

± 1K

Ambient temperature

Max. 55°C

Ambient humidity

10...90 % RH (non-condensing)

Max. bulb temperature

150°C

Casing

Base in ABS, transparent Polycarbonate (PC)

Dimensions

140 x 62 x 65 mm (cable gland included)

Weight

320 g

Protection class

IP65 class I

Article

Hysteresis

Reset

Capillary length

FT18

2K

Automatic

1.8 m

FT30

2K

Automatic

3m

FT60

2K

Automatic

6m

FT18R

-

Manual

1.8 m

FT30R

-

Manual

3m

FT60R

-

Manual

6m

Accessories Article

Description

DR-01

Copper immersion well 120 mm, 12 x 1

DR-02

Stainless steel immersion well 120 mm, 12 x 1

DR-05

Set of mounting brackets for capillary fixing (supplied with product)

99

5

E L E C T R O M E C H A N I C A L T H E R M O S TA T S

Electromechanical immersion thermostats MTIB is a series of high quality electromechanical immersion thermostats for use in cooling, heating and ventilation systems. They are supplied with a standard DR-16/14 model immersion well. Technical data Sensor element

Liquid-filled copper bulb

s

Dust-tight microswitches with SPDT s (heat/cool)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-35...+65°C

Ambient humidity

10...90 RH (non-condensing)

Hysteresis

1K

Casing

Bayblend® base, ABS cover

Weight

570 g

Protection class

IP65 class I

Article

Temperature range

Max. bulb temperature

MTIB60

10...60°C

75°C

MTIB120

50...120°C

140°C

MTIB90

20...90°C

100°C

Accessories

100

Article

Description

DR-16/14

Copper immersion well 120 mm, 10 x 0.5

DR-17/14

Stainless steel AISI 301 immersion well 120 mm, 10 x 0.5

E L E C T R O M E C H A N I C A L T H E R M O S TAT S

Electromechanical capillary thermostat MTIC is a series of high quality electro-mechanical thermostats for use in cooling, heating and ventilation systems. Technical data Sensor element

Liquid-filled copper bulb

Bulb

Ø 9.5 (Ø 8 for range 50...120°C)

Length, capillary tube

1.5 m

s

Dust-tight microswitches with SPDT s (heat/cool)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-35...+65°C

Ambient humidity

10...90 % RH (non-condensing)

Casing

Bayblend® base, ABS cover

Weight

340 g

Protection class

IP65 class I

Article

Temperature range

Steps

Hysteresis

Step diff.

Max. bulb temperature

5 Immersion well to use

Hidden setpoint

MTIC30S

-30...+30°C

1

2...20 K

-

60°C

DBZ-01/02

-

MTIC30H

-30...+30°C

1

2...20 K

-

60°C

DBZ-01/02

X

MTIC30-2

-30...+30°C

2

1K

2...5 K

60°C

DBZ-01/02

-

MTIC30

-30...+30°C

1

1K

-

60°C

DBZ-01/02

-

MTIC30R

-30...+30°C

1

Manual minimum reset

-

60°C

DBZ-01/02

-

100°C

DBZ-01/02

-

-

100°C

DBZ-01/02

X

MTIC90S

20...90°C

1

2...20 K

MTIC90H

20...90°C

1

2...20 K

MTIC90

20...90°C

1

1K

-

100°C

DBZ-01/02

-

MTIC90R

20...90°C

1

Manual minimum reset

-

100°C

DBZ-01/02

-

MTIC120S

50...120°C

1

2...20 K

-

150°C

DBZ-16/17

-

Article

Description

DR-01

Copper immersion well 120 mm, 12 x 1

DR-02

Stainless steel immersion well 120 mm, 12 x 1

DR-16

Copper immersion well 120 mm, 10 x 0.5

DR-17

Stainless steel immersion well 120 mm, 10 x 0.5

101

E L E C T R O M E C H A N I C A L T H E R M O S TA T S

Electromechanical duct thermostat MTID is a series of high quality electro-mechanical thermostats for use in cooling, heating and ventilation systems. Technical data Sensor element

Liquid-filled copper bulb with 200 mm protection spring and mounting bracket

s

Dust-tight microswitches with SPDT s (heat/cool)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-35...+65°C

Ambient humidity

10...90 % RH (non-condensing)

Insertion length

200 / Ø 21 mm

Material

< 95 % RH

Casing

Bayblend® base, ABS cover

Weight

690 g

Protection class

IP65 class I

Article

Temperature range

Steps

Hysteresis

Step diff.

Max. bulb temperature

Hidden setpoint

Manual max. reset

MTID30H

-30...+30°C

1

1K

-

60°C

X

-

MTID60S

0...60°C

1

2...20 K

-

75°C

-

-

MTID60-2

0...60°C

2

1K

2...5

75°C

-

-

MTID60

0...60°C

1

1K

-

75°C

-

-

MTID120HR

50...120°C

1

1K

-

140°C

X

X

Accessories

102

Article

Description

DR-25

Protection spring and mounting bracket (factory-mounted, supplied with above models)

E L E C T R O M E C H A N I C A L T H E R M O S TAT S

Electromechanical wall thermostat MTIR is a series of high quality electromechanical thermostats for use in cooling, heating and ventilation systems. Technical data Sensor element

Liquid-filled coiled copper bulb

s

Dust-tight microswitches with SPDT s (heat/cool)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-35...+60°C

Ambient humidity

10...90 % RH (non-condensing)

Insertion length

200 / Ø 21 mm

Casing

Bayblend® base, ABS cover

Weight

450 g

Protection class

IP65 class I

5

Article

Temperature range

Steps

Hysteresis

Step diff.

Max. bulb temperature

Hidden setpoint

MTIR30S

-30...+30°C

1

2...15 K

MTIR30SH

-30...+30°C

1

2...15 K

-

60°C

-

60°C

MTIR30

-30...+30°C

1

1K

X

-

75°C

-

MTIR30-2

-30...+30°C

2

MTIR60S

0...60°C

1

1K

2...5 K

75°C

-

2...15 K

-

75°C

MTIR60

0...60°C

-

1

1K

-

140°C

MTIR60SH

-

0...60°C

1

1K

-

140°C

X

MTIR60S-2

0...60°C

2

1K

2...5 K

140°C

-

Electromechanical clamp-on thermostat MTIS is a series of high quality electromechanical thermostats for use in cooling, heating and ventilation systems. Technical data Sensor element

Liquid-filled copper bulb for

s

Dust-tight microswitches with SPDT s (heat/cool)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-35...+65°C

Ambient humidity

10...90 % RH (non-condensing)

Hysteresis

2...20 K

Casing

Bayblend® base, ABS cover

Weight

180...500 g

Protection class

IP65 class I

Article

Temperature range

Max. bulb temperature

Hidden setpoint

MTIS60S

0...60°C

75°C

-

MTIS60SH

0...60°C

75°C

X

MTIS90S

20...90°C

110°C

-

MTIS90SH

20...90°C

110°C

X

103

E L E C T R O M E C H A N I C A L T H E R M O S TA T S

104

6

E L E C T R I C H E AT I N G C O N T R O L L E R S

ELECTRIC HEATING CONTROLLERS

6

+21°C -8°C

105

E L E C T R I C H E AT I N G C O N T R O L L E R S

1- or 2-phase 1- or 2-phase, 200...415 V Controllers intended for control of radiators or electric heating coils. They can be mounted on a wall or in a cabinet. The controllers pulse the whole load on/off and utilise time-proportional triac control. Automatic control function adaptation, P- or PI-control. Technical data Supply voltage

200...415 V AC, 50...60 Hz, 1- or 2-phase, automatic adaptation

Ambient temperature

Max. 30°C (NOTE! Pulser generates 20 W heating at full load.)

P-band

20 K (rapid temperature changes) 1,5 K (slow temperature changes)

I-time

6 min (rapid temperature changes)

Pulse period

60 s

Wa ll m ou n t in g

Inputs/outputs (I/Os)

D I N - rail mou n t in g

Sensor

One main sensor or two main sensors (only PULSER-M)

Setpoint

0...30°C (the sensor determines the temperature range (Regin NTC sensor))

Night setback

0...10 K

Output (load)

16 A (min. 1 A) 1-phase max. 3.6 kW) 2-phase max. 6.4 kW

With automatic adaptation to 230 V AC or 400 V AC Article

Description

Mounting

Number of modules

Protection class

PULSER

Electric heating controller

Wall

-

IP30

PULSER/D

Electric heating controller

DIN-rail

6.6 (115 x 88 x 59)

IP20

PULSER-ADD

Add-on unit

Wall

-

IP30

PULSER-M

Electric heating controller with min./ max. limitation

Wall

-

IP30

PULSER-X/D

Electric heating controller for external 0...10 V DC control signal

DIN-rail

6.6 (115 x 88 x 59)

IP30

1-phase (230 V AC) or 2-phase (400 V AC)

106

Article

Description

Supply voltage

Mounting

PULSER220X010

Electric heating controller for external 0...10 V DC control signal

230 V AC

Wall

PULSER380X010

Electric heating controller for external 0...10 V DC control signal

400 V AC

Wall

E L E C T R I C H E AT I N G C O N T R O L L E R S

1-phase, 230 V and 24 V, LON communication PULSER-HC-LON is a room controller based on LON technology. It has a triac output for control of electric heating (10 A) and an extra output (cooling or heating) for 3-position or 24 V AC thermal actuators. The controller has a built-in sensor and a setpoint knob. The setpoint can be adjusted by ±3°C. An external sensor or setpoint device can also be used. PULSER-HC-LON has three different running modes, present, not present and standby. It is possible to set the basic setpoint to different values for heating and cooling. A window can be used to block the control when a window is open. Technical data Supply voltage

1-phase, 230 V AC and 24 V AC

Output (load)

10 A

Setpoint

0...30°C (the sensor determines the temperature range (Regin NTC sensor))

Setpoint adjustment

±3°C

Load (extra output)

24 V AC, 3-point or one on/off, 0.5 A

Mounting

Wall

Protection class

IP30

Article

Description

PULSER-HC-LON

Room controller with LON communication, heating or cooling in sequence

107

6

E L E C T R I C H E AT I N G C O N T R O L L E R S

3-phase 3-phase, 210...415 V, 25 A, wall mounting TTC2000 can be used with internal or external setpoint. Automatic control function adaptation, P- or PI-control. The controller can also be set to be controlled by an external 0...10 V DC signal. Technical data Supply voltage

3-phase, 210...255 / 380...415 V AC, automatic adaptation

Setpoint

0...30°C (the sensor determines the range)

Max. load

Max. 25 A, min. 3 A/phase

Sensor inputs

Two, main and min./max. limiting sensors (Regin NTC sensor)

Control signal

0...10 V DC (external signal)

Mounting

Wall

Protection class

IP30

P-band

Supply air temperature control: 20 K, fixed Room temperature control: 1.5 K, fixed

I-time (supply air temperature control)

6 min, fixed

Pulse period

6...120 s

Article

Description

TTC2000

Electric heating controller

To control extra loads, the slave board TT-S1 can easily be mounted into the unit.

108

E L E C T R I C H E AT I N G C O N T R O L L E R S

210...415 V, 25 A, DIN mounting For control of electric heating coils or radiators. The controllers pulse the whole load on/off and utilise time-proportional triac control. Automatic control function adaptation, P- or PI-control. The controllers can also be controlled by an external 0...10 V DC signal. Technical data Supply voltage

3-phase, 210...255 / 380...415 V AC, automatic adaptation

Ambient temperature

0...40°C

Mounting

DIN-rail

Dimensions (WxHxD)

195 x 200 x 95 mm

Protection class

IP20

P-band

Supply air temperature control: 20 K, fixed Room temperature control: 1.5 K, fixed

I-time

6 min, fixed

Pulse period

6...60 s

Load

25 A

Output

25 A, 3 x 400 V AC, 17 kW (3 x 230 V, 10 kW)

Inputs Setpoint

0...30°C (the sensor determines the range) NOTE: Does not apply to TTC25X.

Sensor inputs

Two, main and max./min. limiting sensors (Regin NTC sensor). Note: Does not apply to TTC25X.

Control signal

0...10 V DC

Article

Description

For use with Regin NTC sensor

For external 0...10 V DC control signal only

External 0...10 V DC control signal option

TTC25

Electric heating controller with temperature control

X

-

X

TTC25X

Electric heating controller

-

X

-

To control larger electrical loads, see the step controllers TT-S4/D and TT-S6/D.

109

6

E L E C T R I C H E AT I N G C O N T R O L L E R S

210...415 V, 40 A, DIN mounting For control of electric heating coils or radiators. The controllers pulse the whole load on/off and utilise time-proportional triac control. Automatic control function adaptation, P- or PI-control. The controllers can also be controlled by an external 0...10 V DC signal. Technical data Supply voltage

3-phase, 210...255 / 380...415 V AC, automatic adaptation

Ambient temperature

0...40°C

Mounting

DIN-rail

Dimensions (WxHxD)

195 x 220 x 95 mm

Protection class

IP20

P-band

Supply air temperature control: 20 K, fixed Room temperature control: 1.5 K, fixed

I-time

6 min, fixed

Pulse period

6...60 s

Load

40 A

Output

40 A, 3 x 400 V AC, 27 kW (3 x 230 V, 16 kW)

Inputs Setpoint

0...30°C (the sensor determines the range) Note: Does not apply to TTC40FX.

Sensor inputs

Two, main and max./min. limiting sensors (Regin NTC sensor). Note: Does not apply to TTC40FX.

Control signal

0...10 V DC

Article

Description

For use with Regin NTC sensor

For external 0...10 V DC control signal only

External 0...10 V DC control signal option

TTC40F

Electric heating controller with temperature control

X

-

X

TTC40FX

Electric heating controller

-

X

-

To control larger electrical loads, see the step controllers TT-S4/D and TT-S6/D.

110

E L E C T R I C H E AT I N G C O N T R O L L E R S

210...415 V, 63 A, DIN mounting For control of electric heating coils or radiators. The controller pulses the whole load on/off through time-proportional triac control. Automatic control function adaptation, P- or PI-control. The controller can also be set to be controlled by an external 0...10 V DC signal. Technical data Supply voltage

3-phase, 400 V AC

Ambient temperature

0...40°C

Mounting

DIN-rail

Dimensions (WxHxD)

195 x 220 x 105 mm

Protection class

IP20

P-band

Supply air temperature control: 20 K, fixed Room temperature control: 1.5 K, fixed

I-time

6 min, fixed

Pulse period

6...120 s

Load

63 A

Output

63 A, 3 x 400 V AC, 43 kW

6

Inputs Setpoint

0...30°C (the sensor determines the range)

Sensor inputs

Two, main and max./min. limiting sensors (Regin NTC sensor).

Control signal

0...10 V DC

Article

Description

For use with Regin NTC sensor

For external 0...10 V DC control signal only

External 0...10 V DC control signal option

TTC63F

Electric heating controller with temperature control

X

-

X

To control larger electrical loads, see the step controllers TT-S4/D and TT-S6/D.

111

E L E C T R I C H E AT I N G C O N T R O L L E R S

210...415 V, 80 A, DIN mounting For control of electric heating coils or radiators. The controller pulses the whole load on/off through time-proportional triac control. Automatic control function adaptation, P- or PI-control. The controller can also be set to be controlled by an external 0...10 V DC signal. Technical data Supply voltage

3-phase, 400 V AC

Ambient temperature

0...40°C

Mounting

DIN-rail

Dimensions (WxHxD)

195 x 220 x 105 mm

Protection class

IP20

P-band

Supply air temperature control: 20 K, fixed Room temperature control: 1.5 K, fixed

I-time

6 min, fixed

Pulse period

6...120 s

Load

80 A

Output

80 A, 3 x 400 V AC, 55 kW

Inputs Setpoint

0...30°C (the sensor determines the range)

Sensor inputs

Two, main and max./min. limiting sensors (Regin NTC sensor).

Control signal

0...10 V DC

Article

Description

For use with Regin NTC sensor

For external 0...10 V DC control signal only

External 0...10 V DC control signal option

TTC80F

Electric heating controller with temperature control

X

-

X

To control larger electrical loads, see the step controllers TT-S4/D and TT-S6/D.

112

E L E C T R I C H E AT I N G C O N T R O L L E R S

Accessories Slave board for TTC2000 TT-S1 is intended for use together with the electric heating controller TTC2000, in order to control extra loads. Article

Description

TT-S1

Slave board for control of extra loads (+17 kW)

Scales and knobs for Pulser and TTC Alternative setpoint scales and knobs, when using sensors with other temperature ranges.

Scales for TTC25/40 and Pulser/D Article

Description

Temperature range

SKALA-3933

Scales for TTC25/40 and Pulser/D

20...50°C

SKALA-3934

Scales for TTC25/40 and Pulser/D

40...70°C

SKALA-3935

Scales for TTC25/40 and Pulser/D

60...90°C

Description

Temperature range

Knobs for TTC2000 Article TRY-RATT-3608

Knobs for TTC2000

20...50°C

TRY-RATT-3609

Knobs for TTC2000

40...70°C

TRY-RATT-3610

Knobs for TTC2000

60...90°C

Knobs for Pulser Article

Description

Temperature range

TRY-RATT-2271

Knobs for Pulser

0...30°C

TRY-RATT-1588

Knobs for Pulser

20...50°C

TRY-RATT-1589

Knobs for Pulser

40...70°C

TRY-RATT-1590

Knobs for Pulser

60...90°C

113

6

E L E C T R I C H E AT I N G C O N T R O L L E R S

Step controller, 4- or 6-stage Controllers intended for control of electric heating coils, four or six relays. The controller can be set to sequential or binary control. It can be used with any controller with an 0...10 V DC or 10...2 V DC output signal. 2 V DC output signal. The required number of steps is set by means of the rotating switch on the front. The 0...10 V DC input signal is divided up into the number of steps, thus setting the switch-on point for each step. Relay 6 on TT-S6/D can be used as a time-lag relay to delay shut-off of the fan when shutting down the system (3 min. delay). The step controllers also have an analogue output (0…10 V) for control of an electric heating controller (TTC or similar) to give proportional heating between steps. Technical data Supply voltage

24 V AC, 6 VA

Output

4 alt. 6 relays (closing), binary or sequential control

Input signal

0...10 V DC

Output signal

0...10 V DC

Mounting

DIN-rail

Number of modules

6

Protection class

IP20

Article

114

Description

Run-on time

TT-S4/D

Step controller with 4 relays

-

TT-S6/D

Step controller with 6 relays

3 min

7

SENSORS AND SWITCHES

SENSORS AND SWITCHES

7

+23°C

+3Pa 115

SENSORS AND SWITCHES

Temperature sensors – NTC Regin Clamp-on sensor, NTC Clamp-on sensor for surface temperature measurement. Supplied with 1.5 m cable. Technical data Sensor element

NTC, 15...10 kΩ

Time constant

13 s

Material

Nickel-plated copper tube

Cable length

1.5 m

Protection class

IP65

Article

Description

Temperature range

TG-A130

Clamp-on sensor, including clamp (Ø 40 mm max.)

0...30°C

Accessories Article

Description

PASTA-20

Heat-conductive paste in tube, 20 g

This sensor cannot be used together with the Pulser series.

Bulb sensor, NTC Universal sensor. Technical data Sensor element

NTC, 15...10 kΩ

Diameter

6 mm

Material

Stainless steel

Cable length

1.5 m

Protection class

IP65

Article

Temperature range

TG-B130

0...30°C

TG-B150

20...50°C

TG-B160

0...60°C

TG-B190

60...90°C

Accessories Article

Description

PASTA-20

Heat-conductive paste in tube, 20 g

This sensor cannot be used together with the Pulser series.

116

SENSORS AND SWITCHES

Floor sensor, NTC Technical data Sensor element

NTC, 15...10 kΩ

Diameter

7 mm

Cable length

2.5 m

Protection class

IP65

Article

Temperature range

TG-G130

0...30°C

Immersion sensor, NTC For water temperature measurement. Technical data Sensor element

NTC, 15...10 kΩ

Time constant

4s

Diameter

R1/4” 6 mm

Material, probe

Stainless steel, SUS304

Pressure rating

PN10

Cable length

1.5 m

Protection class

IP65

Article

Temperature range

Insertion length

TG-D130

0...30°C

135 mm

TG-D150

20...50°C

135 mm

TG-D170

40...70°C

135 mm

TG-D230

0...30°C

220 mm

Accessories Article

Accessories

DF

Mounting flange for TG-D1... for mounting in ventilation ducts

This sensor cannot be used together with the Pulser series.

117

7

SENSORS AND SWITCHES

Well Well for immersion sensors. Technical data Connection

R1/2”

Pressure rating

PN25

Article

Description

Material

Insertion length

DR-90R

Well

Stainless steel, SUS304

90 mm

DR-90W

Well for TG-DHW...

Acid-proof stainless steel, SUS316

90 mm

DR-90WS

Well for TG-DHW...

Stainless steel, SUS304

90 mm

DR-135R

Well

Stainless steel, SUS304

135 mm

Accessories Article

Accessories

ADAPTER

Adapter 1/4” to 1/2”. For mounting TG-D1... in 1/2”.

Duct sensor, NTC For air temperature measurement in ventilation ducts. Adjustable insertion length. Technical data Sensor element

NTC, 15...10 kΩ

Time constant

38 s

Diameter

9 mm

Insertion length

15...130 mm

Cable length

1.5 m

Protection class

IP20

Article

Description

Temperature range

TG-K300

Duct sensor

-30...+30°C

TG-K310

-20...+10°C

TG-K330

0...30°C

TG-K350

20...50°C

TG-K360

0...60°C

TG-K370

40...70°C

TG-K340

Duct sensor for Floorigo/AL24A1T

0...40°C

Room sensor, NTC, with setpoint adjustment Room sensor for room temperature measurement. Can also be used for setpoint adjustment only. Technical data

118

Sensor element

NTC, 15...10 kΩ

Protection class

IP30

Article

Temperature range

TG-R430

0...30°C

SENSORS AND SWITCHES

Room sensor, NTC Technical data Sensor element

NTC, 15...10 kΩ

Protection class

IP30

Article

Description

Temperature range

TG-R530

Room sensor

0...30°C

TG-R550

Room sensor

20...50°C

TG-R540

Room sensor for Floorigo/AL24A1T

0...40°C

TG-R530M

Room sensor for average measurement

0...30°C

Outdoor sensor, NTC Outdoor sensor for outdoor temperature measurement or for temperature measurement in rooms where higher protection class is needed. Technical data Sensor element

NTC, 15...10 kΩ

Protection class

IP54

Article

Temperature range

TG-R600

-30...+30°C

TG-R630

0...30°C

Setpoint device for mounting Setpoint device intended for NTC sensors only. Technical data Protection class

IP20

Article

Temperature range

TBI-10

-20...+10°C

TBI-30

0...30°C

TBI-50

20...50°C

TBI-70

40...70°C

TBI-90

60...90°C

TBI-100

0...100°C

119

7

SENSORS AND SWITCHES

Temperature sensors – Other sensor elements Clamp-on sensor with cable For surface temperature measurement. Including clamp. Technical data Time constant

13 s

Material

Nickel-plated copper tube

Cable length

1.5 m

Protection class

IP65

Article

Description

TG-A1/PT100

Clamp-on sensor, including clamp (Ø 40 mm max.)

TG-A1/PT1000 TG-A1/NTC1,8

120

Sensor element

Nominal resistance

Temperature range

Equivalent

PT100

100 Ω/0°C

-30...+150°C

-

PT1000

1000 Ω/0°C

-30...+150°C

-

NTC 1.8

1800 Ω/25°C

-30...+120°C

TAC

TG-A1/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

-30...+150°C

Johnson Controls

TG-A1/NTC10-01

NTC 10k3A1

10 kΩ/25°C

-30...+150°C

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-A1/NTC10-02

NTC 10k

10 kΩ/25°C

-30...+110°C

Carel - Evco - Eliwell AB Industrietechnik

TG-A1/NTC10-03

NTC 10k4A1

10 kΩ/25°C

-30...+110°C

Andover - Delta Controls - Siebe - York

TG-A1/NTC20

NTC 20k6A1

20 kΩ/25°C

-30...+150°C

Honeywell

TG-A1/NI1000-01

Ni1000

1000 Ω/0°C

-30...+150°C

Siemens - Landis & Staefa

TG-A1/NI1000-02

Ni1000

1000 Ω/0°C

-30...+150°C

Sauter

SENSORS AND SWITCHES

Clamp-on sensor with housing Clamp-on sensor for surface temperature measurement, including a metal strap for easy fastening and a tube of heat-conductive paste. Technical data Cable gland

M16

Time constant

5s

Protection class

IP42 (or IP40 depending on the mounting position)

Article

Sensor element

Nominal resistance

Temperature range

Equivalent

TG-AH1/PT100

PT100

100 Ω/0°C

-20...+120°C

-

TG-AH1/PT1000

PT1000

1000 Ω/0°C

-20...+120°C

-

TG-AH1/NTC1,8

NTC 1.8

1800 Ω/25°C

-20...+120°C

TAC

TG-AH1/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

-20...+120°C

Johnson Controls

TG-AH1/NTC10-01

NTC 10k3A1

10 kΩ/25°C

-20...+120°C

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-AH1/NTC10-02

NTC 10k

10 kΩ/25°C

-20...+110°C

Carel - Evco - Eliwell - AB Industrietechnik

TG-AH1/NTC10-03

NTC 10k4A1

10 kΩ/25°C

-20...+120°C

Andover - Delta Controls Siebe - York

TG-AH1/NTC20

NTC 20k6A1

20 kΩ/25°C

-20...+120°C

Honeywell

TG-AH1/NI1000-01

Ni1000

1000 Ω/0°C

-20...+120°C

Siemens - Landis & Staefa

TG-AH1/NI1000-02

Ni1000

1000 Ω/0°C

-20...+120°C

Sauter

Accessories Article

Description

PASTA-20

Heat-conductive paste in tube, 20 g

Bulb sensor Universal sensor. Technical data

T G - B1 / PT 1 0 0

TG-B640/ PT 1 0 0 0

Protection class

IP65

Temperature range

-30...+100°C

Material

Stainless steel

Diameter

6 mm

Cable length

1.5 m

Article

Sensor element

Nominal resistance

Temperature range

Protection class

TG-B1/PT100

PT100

100 Ω/0°C

-30...+100°C

IP65

TG-B640/PT1000

PT1000

1000 Ω/0°C

-50...+110°C

IP67

Accessories Article

Description

PASTA-20

Heat-conductive paste in tube, 20 g

121

7

SENSORS AND SWITCHES

Duct sensor with housing Duct sensor for air temperature measurement in ventilation ducts. Technical data

122

Temperature range

-30…+70°C

Time constant

16 s

Cable gland

M16

Material, probe

Stainless steel, SUS304

Diameter

8 mm

Protection class

IP65

Article

Sensor element

Nominal resistance

Insertion length

Equivalent

TG-KH/PT100

PT100

100 Ω/0°C

60...205 mm

-

TG-KH/PT1000

PT1000

1000 Ω/0°C

60...205 mm

-

TG-KH/PT1000-430

PT1000

1000 Ω/0°C

60…405 mm

-

TG-KH/NTC1,8

NTC 1.8

1800 Ω/25°C

60...205 mm

TAC

TG-KH/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

60...205 mm

Johnson Controls

TG-KH/NTC10-01

NTC 10k3A1

10 kΩ/25°C

60...205 mm

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-KH/NTC10-02

NTC 10k

10 kΩ/25°C

60...205 mm

Carel - Evco - Eliwell - AB Industrietechnik

TG-KH/NTC10-03

NTC 10k4A1

10 kΩ/25°C

60...205 mm

Andover - Delta Controls Siebe - York

TG-KH/NTC20

NTC 20k6A1

20 kΩ/25°C

60...205 mm

Honeywell

TG-KH/NI1000-01

Ni1000

1000 Ω/0°C

60...205 mm

Siemens - Landis & Staefa

TG-KH/NI1000-02

Ni1000

1000 Ω/0°C

60...205 mm

Sauter

SENSORS AND SWITCHES

Duct sensor Duct sensor for air temperature measurement in ventilation ducts. Adjustable insertion length. Technical data Temperature range

-30…+70°C

Time constant

50 s including dead time

Insertion length

15...140 mm

Diameter

9 mm

Protection class

IP20

Article

Sensor element

Nominal resistance

Cable length

Equivalent

TG-K3/PT100

PT100

100 Ω/0°C

1.5 m

-

TG-K3/PT1000

PT1000

1000 Ω/0°C

1.5 m

-

TG-K3/PT1000/3,0

PT1000

1000 Ω/0°C

3m

-

TG-K3/NTC1,8

NTC 1.8

1800 Ω/25°C

1.5 m

TAC

TG-K3/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

1.5 m

Johnson Controls

TG-K3/NTC10-01

NTC 10k3A1

10 kΩ/25°C

1.5 m

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-K3/NTC10-02

NTC 10k

10 kΩ/25°C

1.5 m

Carel - Evco - Eliwell - AB Industrietechnik

TG-K3/NTC10-03

NTC 10k4A1

10 kΩ/25°C

1.5 m

Andover - Delta Controls Siebe - York

TG-K3/NTC20

NTC 20k6A1

20 kΩ/25°C

1.5 m

Honeywell

TG-K3/NI1000-01

Ni1000

1000 Ω/0°C

1.5 m

Siemens - Landis & Staefa

TG-K3/NI1000-02

Ni1000

1000 Ω/0°C

1.5 m

Sauter

Average temperature sensor with housing Average temperature sensor for duct mounting. It has a cable with four PT1000 elements. The cable is mounted with clamps and is held in place inside the duct by an end spring. Technical data Time constant

1s

Cable gland

M16

Cable length

3m

Insertion length

0...75 mm

Diameter

8 mm

Protection class

IP65

Article

Sensor element

Nominal resistance

Temperature range

TG-MH/PT1000

PT1000

1000 Ω/0°C

0...70°C

123

7

SENSORS AND SWITCHES

Immersion sensor with cable Immersion sensor for water temperature measurement. Technical data Temperature range

-30...+70°C

Time constant

4s

Cable length

1.5 m

Connection

R1/4”

Diameter

4 mm

Material, probe

Stainless steel, SUS304

Pressure rating

PN10

Protection class

IP65

Article

Sensor element

Nominal resistance

Insertion length

Equivalent

TG-D1/PT100

PT100

100 Ω/0°C

135 mm

-

TG-D1/PT1000

PT1000

1000 Ω/0°C

135 mm

-

TG-D1/NTC1,8

NTC 1.8

1800 Ω/25°C

135 mm

TAC

TG-D1/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

135 mm

Johnson Controls

TG-D1/NTC10-01

NTC 10k3A1

10 kΩ/25°C

135 mm

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-D1/NTC10-02

NTC 10k

10 kΩ/25°C

135 mm

Carel - Evco - Eliwell - AB Industrietechnik

TG-D1/NTC10-03

NTC 10k4A1

10 kΩ/25°C

135 mm

Andover - Delta Controls Siebe - York

TG-D1/NTC20

NTC 20k6A1

20 kΩ/25°C

135 mm

Honeywell

TG-D1/NI1000-01

Ni1000

1000 Ω/0°C

135 mm

Siemens - Landis & Staefa

TG-D1/NI1000-02

Ni1000

1000 Ω/0°C

135 mm

Sauter

Article

Sensor element

Nominal resistance

Insertion length

TG-D2/PT100

PT100

100 Ω/0°C

220 mm

TG-D2/PT1000

PT1000

1000 Ω/0°C

220 mm

Accessories

124

Article

Description

DF

Mounting flange for TG-D1... for mounting in ventilation ducts

ADAPTER

Adapter 1/4” to 1/2”. For mounting TG-D1... in 1/2”.

SENSORS AND SWITCHES

Immersion sensor with cable, adjustable insertion length Immersion sensor for water temperature measurement. Technical data Temperature range

-30...+70°C

Time constant

4s

Cable length

1.5 m

Connection

R1/4”

Diameter

4 mm

Material, probe

Stainless steel, SUS304

Pressure rating

PN10

Protection class

IP65

Article

Sensor element

Nominal resistance

Insertion length

Equivalent

TG-D3/PT100

PT100

100 Ω/0°C

Max. 300 mm

-

TG-D3/PT1000

PT1000

1000 Ω/0°C

Max. 300 mm

-

TG-D3/NTC1,8

NTC 1.8

1800 Ω/25°C

Max. 300 mm

TAC

TG-D3/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

Max. 300 mm

Johnson Controls

TG-D3/NTC10-01

NTC 10k3A1

10 kΩ/25°C

Max. 300 mm

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-D3/NTC10-02

NTC 10k

10 kΩ/25°C

Max. 300 mm

Carel - Evco - Eliwell - AB Industrietechnik

TG-D3/NTC10-03

NTC 10k4A1

10 kΩ/25°C

Max. 300 mm

Andover - Delta Controls Siebe - York

TG-D3/NTC20

NTC 20k6A1

20 kΩ/25°C

Max. 300 mm

Honeywell

TG-D3/NI1000-01

Ni1000

1000 Ω/0°C

Max. 300 mm

Siemens - Landis & Staefa

TG-D3/NI1000-02

Ni1000

1000 Ω/0°C

Max. 300 mm

Sauter

125

7

SENSORS AND SWITCHES

Immersion sensor with housing, without well Technical data

126

Temperature range

-20…+120°C

Time constant

4s

Cable gland

M16

Diameter

5 mm

Connection

R1/4”

Material, probe

Stainless steel, SUS304

Diameter, probe

5 mm

Pressure rating

PN16

Protection class

IP65

Article

Sensor element

Nominal resistance

Temperature range

Equivalent

TG-DH4/PT100

PT100

100 Ω/0°C

-20...+120°C

-

TG-DH4/PT1000

PT1000

1000 Ω/0°C

-20...+120°C

-

TG-DH4/NTC1,8

NTC 1.8

1800 Ω/25°C

-20...+120°C

TAC

TG-DH4/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

-20...+120°C

Johnson Controls

TG-DH4/NTC10-01

NTC 10k3A1

10 kΩ/25°C

-20...+120°C

Aquatrol - Johnson Controls - Satchwell Trend - Cylon - Honeywell

TG-DH4/NTC10-02

NTC 10k

10 kΩ/25°C

-20...+110°C

Carel - Evco - Eliwell - AB Industrietechnik

TG-DH4/NTC10-03

NTC 10k4A1

10 kΩ/25°C

-20...+120°C

Andover - Delta Controls Siebe - York

TG-DH4/NTC20

NTC 20k6A1

20 kΩ/25°C

-20...+120°C

Honeywell

TG-DH4/NI1000-01

Ni1000

1000 Ω/0°C

-20...+120°C

Siemens - Landis & Staefa

TG-DH4/NI1000-02

Ni1000

1000 Ω/0°C

-20...+120°C

Sauter

SENSORS AND SWITCHES

Immersion sensor with housing and well The sensor part has a clip fastening which makes it easy to mount. The sensor is supplied with well model DR-90WS. The acid-proof stainless steel well DR-90W can be ordered separately. Technical data Temperature range

-20…+120°C

Cable gland

M16

Time constant

18 s (12 s with heat-conductive paste)

Insertion length

90 mm

Connection, well

R1/2”

Material, probe

Stainless steel, SUS304

Material, well

Stainless steel, SUS304

Diameter, well

8 mm

Pressure rating

PN25

Protection class

IP65

Article

Sensor element

Nominal resistance

Temperature range

Equivalent

TG-DHW1/PT100

PT100

100 Ω/0°C

-20...+120°C

-

TG-DHW1/PT1000

PT1000

1000 Ω/0°C

-20...+120°C

-

TG-DHW1/NTC1,8

NTC 1.8

1800 Ω/25°C

-20...+120°C

TAC

TG-DHW1/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

-20...+120°C

Johnson Controls

TG-DHW1/NTC10-01

NTC 10k3A1

10 kΩ/25°C

-20...+120°C

Aquatrol - Johnson Controls - Satchwell - Trend - Cylon Honeywell

TG-DHW1/NTC10-02

NTC 10k

10 kΩ/25°C

-20...+110°C

Carel - Evco - Eliwell - AB Industrietechnik

TG-DHW1/NTC10-03

NTC 10k4A1

10 kΩ/25°C

-20...+120°C

Andover - Delta Controls Siebe - York

TG-DHW1/NTC20

NTC 20k6A1

20 kΩ/25°C

-20...+120°C

Honeywell

TG-DHW1/NI1000-01

Ni1000

1000 Ω/0°C

-20...+120°C

Siemens - Landis & Staefa

TG-DHW1/NI1000-02

Ni1000

1000 Ω/0°C

-20...+120°C

Sauter

127

7

SENSORS AND SWITCHES

Immersion sensor with housing and well in acid-proof stainless steel The sensor part has a clip fastening which makes it easy to mount. The sensor is supplied with well model DR-90W. Technical data Temperature range

-20…+120°C

Cable gland

M16

Time constant

18 s (12 s with heat-conductive paste)

Insertion length

90 mm

Connection, well

R1/2”

Material, probe

Stainless steel, SUS304

Material, well

Acid-proof stainless steel, SUS316

Diameter, well

8 mm

Pressure rating

PN25

Protection class

IP65

Article

Sensor element

Nominal resistance

Temperature range

TG-DHWA/PT100

PT100

100 Ω/0°C

-20...+120°C

TG-DHWA/PT1000

PT1000

1000 Ω/0°C

-20...+120°C

Well Well for immersion sensors. Technical data Connection

R1/2”

Pressure rating

PN25

Article

Description

Material

Insertion length

DR-90R

Well

Stainless steel, SUS304

90 mm

DR-90W

Well for TG-DHW...

Acid-proof stainless steel, SUS316

90 mm

DR-90WS

Well for TG-DHW...

Stainless steel, SUS304

90 mm

DR-135R

Well

Stainless steel, SUS304

135 mm

Accessories

128

Article

Accessories

ADAPTER

Adapter 1/4” to 1/2”. For mounting TG-D1... in 1/2”.

SENSORS AND SWITCHES

Room sensor For room temperature measurement. Technical data Temperature range

0…50°C

Protection class

IP30

Article

Sensor element

Nominal resistance

Equivalent

TG-R5/PT100

PT100

100 Ω/0°C

-

TG-R5/PT1000

PT1000

1000 Ω/0°C

-

TG-R5/NTC1,8

NTC 1.8

1800 Ω/25°C

TAC

TG-R5/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

Johnson Controls

TG-R5/NTC10-01

NTC 10k3A1

10 kΩ/25°C

Aquatrol - Johnson Controls - Satchwell Trend - Cylon - Honeywell

TG-R5/NTC10-02

NTC 10k

10 kΩ/25°C

Carel - Evco - Eliwell - AB Industrietechnik

TG-R5/NTC10-03

NTC 10k4A1

10 kΩ/25°C

Andover - Delta Controls - Siebe - York

TG-R5/NTC20

NTC 20k6A1

20 kΩ/25°C

Honeywell

TG-R5/NI1000-01

Ni1000

1000 Ω/0°C

Siemens - Landis & Staefa

TG-R5/NI1000-02

Ni1000

1000 Ω/0°C

Sauter

Room sensor with setpoint adjustment For room temperature measurement. Can also be used for setpoint adjustment only. Technical data Sensor element

PT1000

Nominal resistance

1000 Ω/0°C

Protection class

IP30

Article

Description

Temperature range

TG-R4/PT1000

Room sensor with setpoint adjustment

5...30°C

TG-R4/PT1000-RB

Room sensor with setpoint adjustment, red/blue (increase/decrease) scale

0...30°C

129

7

SENSORS AND SWITCHES

Outdoor sensor Technical data Temperature range

-30…+70°C

Cable gland

M16

Protection class

IP65

Article

Sensor element

Nominal resistance

Equivalent

TG-UH/PT100

PT100

100 Ω/0°C

-

TG-UH/PT1000

PT1000

1000 Ω/0°C

-

TG-UH/NTC1,8

NTC 1.8

1800 Ω/25°C

TAC

TG-UH/NTC2,2

NTC 2.2k3A1

2252 Ω/25°C

Johnson Controls

TG-UH/NTC10-01

NTC 10k3A1

10 kΩ/25°C

Aquatrol - Johnson Controls - Satchwell Trend - Cylon - Honeywell

TG-UH/NTC10-02

NTC 10k

10 kΩ/25°C

Carel - Evco - Eliwell - AB Industrietechnik

TG-UH/NTC10-03

NTC 10k4A1

10 kΩ/25°C

Andover - Delta Controls - Siebe - York

TG-UH/NTC20

NTC 20k6A1

20 kΩ/25°C

Honeywell

TG-UH/NI1000-01

Ni1000

1000 Ω/0°C

Siemens - Landis & Staefa

TG-UH/NI1000-02

Ni1000

1000 Ω/0°C

Sauter

Setpoint device for PT1000 sensors Setpoint device which gives resistance corresponding to the standard PT1000 table. Technical data

130

Temperature range

5…30°C

Mounting

mounting

Protection class

IP20

Article

Description

TBI-PT1000

Setpoint device

Sensor characteristics Sensor element

PT100

PT1000

Equivalent

NTC 1,8K

NTC 2,2K

NTC 10K-01

NTC 10K-02

NTC 10K-03

NTC 15K-01

NTC 15K-02

NTC 15K-03

NTC 20K

NI 1000-01

NI 1000-02

Tac

Johnsson Controls

Aquatrol Johnson Controls Satchwell Trend Cylon Honeywell

Carel Evco Eliwell Industrietechnik

Andover Delta Controls Siebe York

Regin

Regin

Regin

Honeywell

Siemens Landis & Staefa

Sauter

Ω

Ω

Ω

Ω

Ω

Ω

Ω

Ω

Ω

Ω

Ω

Temp. ºC

Ω

Ω

150

157.3

1573

140

153.6

1536

71

53

351

1737

1909

130

149.8

1498

87

68

459

1675

1833

120

146.1

1461

110

90

388

482

609

1615

1760

110

142.3

1423

139

115

510

624

818

1557

1688

767

100

138.5

1385

178

153

678

973

817

1114

1500

1618

90

134.7

1347

230

207

916

1266

1084

1541

1444

1549

80

130.9

1309

303

283

1256

1668

1458

2166

1390

1483

70

127.1

1271

403

395

1752

2228

1990

3099

1337

1417

65

125.2

1252

468

469

2082

2588

2339

3732

1311

1385

60

123.2

1232

545

560

2467

3020

2760

4517

1285

1353

55

121.3

1213

638

673

2985

3536

3271

5494

1260

1322

50

119.4

1194

750

811

3601

4160

3893

10000

6718

1235

1291

45

117.5

1175

885

984

4367

4911

4656

10830

8259

1210

1260

40

115.5

1155

1049

1200

5325

5827

5594

11670

10211

1186

1230

35

113.6

1136

1250

1471

6530

6940

6754

12500

12698

1162

1200

30

111.7

1117

1496

1814

8056

8313

8196

10000

13330

15887

1138

1171

29

111.3

1113

1552

1893

8408

8622

8525

10170

16628

1132

1165

28

111.0

1110

1610

1977

8777

8944

8869

10330

17407

1128

1159

27

110.5

1105

1671

2064

9165

9281

9229

10500

18228

1123

1153

26

110.1

1101

1734

2156

9572

9632

9606

10670

19092

1119

1147

25

109.7

1097

1800

2252

10000

10000

10000

10830

20000

1114

1141

24

109.3

1093

1869

2353

10450

10380

10413

11000

20962

1109

1136

23

109.0

1090

1941

2458

10923

10780

10845

11170

21973

1105

1130

22

108.6

1086

2017

2572

11420

11200

11297

11330

23039

1100

1124

21

108.2

1082

2095

2689

11943

11630

11771

11500

24164

1095

1118

20

107.8

1078

2177

2813

12493

12080

12268

11670

25350

1091

1112

19

107.4

1074

13073

12560

12788

11830

26600

1086

1107

18

107.0

1070

13662

13060

13334

12000

27920

1081

1101

17

106.6

1066

14324

13580

1306

12170

29320

1077

1095

10000 10830 11670 12500

14170

13330

15000

16

106.2

1062

15

105.9

1059

14

105.5

1055

16465

15280

15797

13

105.1

1051

17257

15800

16490

12

104.7

1047

18092

16560

17219

13000

1054

1067

11

104.3

1043

18973

17240

17983

13170

1049

1061

10

103.9

1039

19903

17960

18787

13330

1045

1056

9

103.5

1035

20885

18700

19631

13500

1040

1050

8

103.1

1031

21921

19480

20518

13670

1036

1044

7

102.7

1027

23016

20300

21450

13830

1031

1039

6

102.3

1023

24172

21150

22431

14000

1027

1033

5

101.9

1019

25395

22050

23462

14170

53812

1022

1028

4

101.6

1016

26787

23000

24547

14330

56720

1018

1022

3

101.2

1012

28054

23990

25689

14500

59790

1013

1016

2

100.8

1008

29500

25030

26891

14670

63060

1009

1011

1

100.4

1004

31031

26130

28157

14830

66520

1004

1005

15000

1000

2649

3241

3989

3538

4482

5718

15001

14120

14506

12330

30790

1072

1089

15714

14690

15136

12500

32346

1068

1084

12370

1063

1078

12830

1058

1072

14170

15000

41567

0

100.0

1000

4940

7353

32651

27280

29490

70203

1000

-5

98.0

980

6159

9533

42317

33900

37316

92322

978

973

-10

96.1

961

7730

12460

55304

42470

47549

122431

956

946

-15

94.1

941

9771

16428

72911

53410

61031

163777

935

919

-20

92.2

922

12443

21860

97006

67770

78930

221088

914

893

-25

90.2

902

15969

29398

130306

86430

102889

301297

893

867

-30

88.2

882

20659

39908

176803

111300

135233

414698

872

842

-35

86.3

863

26955

54751

242427

144100

179282

576763

851

816

-40

84.3

843

35480

75953

336098

188500

239828

810861

831

791

131

SENSORS AND SWITCHES

Temperature transmitters Temperature transmitter for room mounting Technical data

T RT N , T RT N - 4 2 0

Temperature range

0…50°C

Accuracy

±0.3°C

Mounting

Room

Protection class

IP30

Article

Supply voltage

Display

Output signal

TRTN

24 V AC or 15...40 V DC, 1 VA

-

0...10 V DC

TRTN-D

24 V AC or 15...40 V DC, 1 VA

X

0...10 V DC

TRTN-420

Max. 28 V, min. 10 + 0.02 x RL (where RL is the circuit loop resistance (RL < 500 Ω))

-

4...20 mA

T RT N - D

Temperature transmitter for wall mounting Technical data Temperature range

0…50°C

Accuracy

±0.7°C

Mounting

Wall

Protection class

IP65

Article

Supply voltage

Output signal

TRT50

24 V AC or 15...35 V DC , 1 VA

0...10 V DC

TRT50-420

20...35 V DC

4...20 mA

Temperature transmitter for immersion mounting Technical data Temperature range

0…100°C

Accuracy

±0.5°C at 20°C

Insertion length

75 mm

Mounting

Well

Material, well

Stainless steel, SUS304

Connection

1/4

Protection class

IP65

Article

132

Supply voltage

Output signal

TLT130

24 V AC or 20...35 V DC, 1 VA

0...10 V DC

TLT130-420

20...35 V DC

4...20 mA

SENSORS AND SWITCHES

Temperature transmitter for duct mounting Technical data Temperature range

0…50°C

Accuracy

±0.5°C at 20°C

Insertion length

60...230 mm (adjustable)

Protection class

IP65

Mounting

Duct

Article

Supply voltage

Output signal

TDT200

24 V AC or 20...35 V DC, 1 VA

0...10 V DC

TDT200-420

20...35 V DC

4...20 mA

7 Temperature accessories Well Well for immersion sensors. Technical data Connection

R1/2”

Pressure rating

PN25

Article

Description

Material

DR-90R

Well

Stainless steel, SUS304

Insertion length 90 mm

DR-90W

Well for TG-DHW...

Acid-proof stainless steel, SUS316

90 mm

DR-90WS

Well for TG-DHW...

Stainless steel, SUS304

90 mm

DR-135R

Well

Stainless steel, SUS304

135 mm

Accessories Article

Accessories

ADAPTER

Adapter 1/4” to 1/2”. For mounting TG-D1... in 1/2”.

133

SENSORS AND SWITCHES

Humidistats – Electromechanical Room humidistat, 1-step Electromechanical humidistat with a synthetic element. The setpoint knob can be locked. Technical data Output

One, 230 V AC, 5 A, change-over

Setpoint

35...95 % RH

Hysteresis

7 % RH

Mounting

Wall

Protection class

IP30

Article

Description

HR-S

Room humidistat, 1-step

Room humidistat, 1- or 2-step Electromechanical humidistat with change-over for control of humidification and/or dehumidification. The setpoint knob can be locked. Technical data Setpoint

10...95 % RH

Hysteresis

4 % RH

Mounting

Wall

Protection class

IP21

Article

Description

Output

Step differential

HR1

Room humidistat, 1-step

5 A, 250 V AC

-

HR1-DH

Room humidistat, 1-step, for dehumidification only

10 A, 250 V AC

-

HR2

Room humidistat, 2-step

5 A, 250 V AC

0...30 % RH

Duct/wall humidistat, 1-/2-step or proportional Electromechanical humidistat with change-over . Technical data

134

Output

10 A, 250 V AC, change-over

Setpoint

10...100 % RH

Hysteresis

3 % RH

Mounting

Duct or wall

Protection class

IP54

Article

Output

Step differential

HMH

1-step

-

HMH2

2-step

0...25 % RH

HPH148

Proportional 0...148 Ω

-

HPH1000

Proportional 0...1000 Ω

-

SENSORS AND SWITCHES

Humidity/temperature transmitters Humidity/temperature transmitter for room mounting Transmitters for relative humidity and temperature measurement. They have good long-term stability and are resistant to contamination. Technical data Supply voltage, 0...10 V DC

24 V AC / 15...40 V DC, 1 VA

Supply voltage, 4...20 mA

Max. 28 V, min. 10 + 0.02 x RL (where RL is the circuit loop resistance (RL < 500 Ω))

Output signal

0...10 V DC or 4...20 mA (4...20 mA output signal only at DC supply voltage, two-wire)

Working range

Humidity: 0...95 % RH. Temperature: 0...50°C.

Accuracy, humidity

±3 % RH (±2 % at 40...60 % RH)

Mounting

Wall

Protection class

IP30

Article

Description

Display

Output signal

Accuracy, temperature

HRTN

Humidity transmitter

-

0...10 V DC

-

HRTN-D

Humidity transmitter

X

0...10 V DC

-

HRTN-420

Humidity transmitter

-

4...20 mA

-

HTRTN

Combined humidity and temperature transmitter

-

0...10 V DC

±0.25°C

HTRTN-D

Combined humidity and temperature transmitter

X

0...10 V DC

±0.25°C

HTRTN-420

Combined humidity and temperature transmitter

-

4...20 mA

±0.4°C

Humidity/temperature transmitter Transmitters for relative humidity and temperature measurement, resistant to contamination. Technical data Supply voltage

24 V AC ±20 % or 15...35 V DC

Output

0...10 V DC or 4...20 mA and ive PT1000 signal

Working range

Humidity: 10...95 % RH. Temperature: 0...50°C.

Accuracy, humidity

±2.5 % at 20°C

Accuracy, temperature

±0.3 K at 20°C

Mounting

Wall or duct mounting

Protection class

IP65

Article

Mounting

Output signal

HTRT2500

Wall

0...10 V DC + ive PT1000 signal

HTRT2500-420

Wall

4...20 mA + ive PT1000 signal

HTDT2500

Duct

0..10 V DC + ive PT1000 signal

HTDT2500-420

Duct

4...20 mA + ive PT1000 signal

135

7

SENSORS AND SWITCHES

Humidity/temperature transmitter for wall mounting Transmitters for relative humidity and temperature measurement, resistant to contamination. Technical data Supply voltage

24 V AC / 15...35 V DC, 1 VA

Output

0...10 V DC or 4...20 mA*

Working range

Humidity: 0...100 % RH. Temperature: -20...+80°C.

Accuracy, humidity

±2 % RH (±3 % at 90...100 % RH)

Accuracy, temperature

±0.2 K at 20°C

Mounting

Wall

Protection class

IP65

Article

Description

Output signal

HRT250

Humidity transmitter

0...10 V DC

HRT250-420

Humidity transmitter

4...20 mA

HTRT250

Combined humidity and temperature transmitter

0...10 V DC

HTRT250-420

Combined humidity and temperature transmitter

4...20 mA

Accessories Article

Accessories

CCERT-E

Calibration certificate for HRT250 models, when certified calibration is demanded. Must be ordered together with a new transmitter.

* 4...20 mA output signal only at DC supply voltage (two-wire).

Temperature transmitter for duct mounting Transmitters for relative humidity and temperature measurement, resistant to contamination. Technical data Supply voltage

24 V AC / 15...35 V DC, 1 VA

Output

0...10 V DC or 4...20 mA*

Working range

Humidity: 0...100 % RH. Temperature: -20...+80°C.

Accuracy, humidity

±2 % RH (±3 % at 90...100 % RH)

Accuracy, temperature

±0.2 K at 20°C

Insertion length

60...230 mm (adjustable)

Mounting

Duct

Protection class

IP65

Article

Description

Output signal

HDT2200

Humidity transmitter

0...10 V DC 4...20 mA

HDT2200-420

Humidity transmitter

HTDT2200

Combined humidity and temperature transmitter

0...10 V DC

HTDT2200-420

Combined humidity and temperature transmitter

4...20 mA

* 4...20 mA output signal only at DC supply voltage (two-wire).

136

SENSORS AND SWITCHES

Humidity transmitter for outdoor use Article

Description

EE21-FT3A21

Humidity/temperature transmitter, 0...10 V DC, for use together with the radiation shield HVS

EE21-FT6A21

Humidity/temperature transmitter, 4...20 mA, for use together with the radiation shield HVS

HVS

Weather shield for outdoor mounting of EE21-FT...

Humidity accessories

7

Spare parts for humidstats Article

Description

Length

HH1606

Hair element for HR1/HR2

107 mm

HH1608

Hair element for HMH/HPH

182 mm

SKYDDSRÖR-375

Protective plastic tube for use of HMH in high air velocity conditions

-

Filter for humidity transmitters Article

Description

HA010101

Dust filter made of Gore-Tex, standard on the humidity transmitters

HA010102

Sintered brass filter, protection in demanding environments

HA010103

Sintered stainless steel filter, protection in demanding environments

HA010105

Teflon filter

HA010106

Metal filter

Calibration accessories Article

Description

HA010401

Calibration device for sensor probes, horizontal mounting

HA010402

Calibration device for sensor probes, vertical mounting

HA010410

5 ampoules, 10 % RH, incl. 5 textile discs

HA010435

5 ampoules, 35 % RH, incl. 5 textile discs

HA010450

5 ampoules, 50 % RH, incl. 5 textile discs

HA010480

5 ampoules, 80 % RH, incl. 5 textile discs

HA010495

5 ampoules, 50 % RH, incl. 5 textile discs

137

SENSORS AND SWITCHES

Pressure Differential pressure switch for air and non-corrosive gases Differential pressure switches with excellent long-term stability. Technical data Max. overload pressure

5000 Pa

Relay output

5 A (0.8 A) 250 V AC, change-over

Ambient temperature

-20...+85°C

Protection class

IP54

Article

Working range

DTV200

20...300 Pa

DTV500

50...500 Pa

DTV1000

100...1000 Pa

DTV2000

500...2000 Pa

DTV5000

1000...5000 Pa

Accessories Article

Description

ANS-1

2 m plastic tube and two pressure outlets

Differential pressure transmitter for air, with display Microprocessor-controlled differential pressure transmitter for measurement of air and neutral gases. DMD has four different measuring ranges in the same unit. The range is selected by means of buttons under the cover. Other functions are zero-point adjustment and electronic damping. Supplied with 2 m plastic tube and two pressure outlets. Selectable working range and output signal. Adjustable damping of the measuring signal. Technical data

138

Supply voltage

24 V AC or DC, 5 VA

Output signal

0...10 V DC or 4...20 mA

Working range

0...100 Pa, 0...300 Pa, 0...500 Pa and 0...1000 Pa

Accuracy

Better than ±1 % at 20°C

Electronic damping

0...20 s

Display

LED, 3 digits

Protection class

IP54

Article

Description

DMD

Differential pressure transmitter with display

SENSORS AND SWITCHES

Differential pressure transmitter with built-in controller, with display Microprocessor-controlled differential pressure transmitter with built-in controller for control of dampers, frequency converters, VAV systems, gases etc. DMD-C has four separate measurement ranges in the same unit. The range is selected by means of buttons under the cover. Supplied with 2 m plastic tube and two pressure outlets. Selectable working range. Adjustable damping of the measuring signal. Technical data Supply voltage

24 V AC or DC, 5 VA

Output signal, pressure

0...10 V DC or 4...20 mA

Output signal, controller

0...10 V DC

Working range

0...100 Pa, 0...300 Pa, 0...500 Pa and 0...1000 Pa

Accuracy

±1 % at 20°C

P-band

0...300 %

I-time

0...999 s

D-factor

0...999

Electronic damping

0...20 s

Display

LED, 3 digits

Mounting

Wall

Protection class

IP54

Article

Description

DMD-C

Differential pressure transmitter with built-in controller, with display

139

7

SENSORS AND SWITCHES

Differential pressure transmitter for air and non-corrosive gases (multi-range) Transmitters with a high level of accuracy and stability. Quick and easy mounting. Technical data Supply voltage

24 V AC (24 V DC, two-wire for 4...20 mA), 0.24 VA

Accuracy

±1% fs

Ambient temperature

0...70°C

Protection class

IP54

Models without display Article

Working range

Output signal

DTL1650-420

1600 / 2500 / 5000 Pa

4...20 mA

DTL1650

1600 / 2500 / 5000 Pa

0...10 V DC

DTL516-420

500 / 1000 / 1600 Pa

4...20 mA

DTL516

500 / 1000 / 1600 Pa

0...10 V DC

DTL310-420

300 / 500 / 1000 Pa

4...20 mA

DTL310

300 / 500 / 1000 Pa

0...10 V DC

DTL150-420

100 / 300 / 500 Pa

4...20 mA

DTL150

100 / 300 / 500 Pa

0...10 V DC

Models with display (non-stock item) Article

Working range

Output signal

DTL1650-420-D

1600 / 2500 / 5000 Pa

4...20 mA

DTL1650-D

1600 / 2500 / 5000 Pa

0...10 V DC

DTL150-D

100 / 300 / 500 Pa

0...10 V DC

DTL516-420-D

500 / 1000 / 1600 Pa

4...20 mA

DTL516-D

500 / 1000 / 1600 Pa

0...10 V DC

DTL310-420-D

300 / 500 / 1000 Pa

4...20 mA

DTL310-D

300 / 500 / 1000 Pa

0...10 V DC

DTL150-420-D

100 / 300 / 500 Pa

4...20 mA

Accessories Article

140

Description

ANS-1

2 m plastic tube and two pressure outlets

CCERT-H

Calibration certificate for the DTL series, when certified calibration is demanded.

SENSORS AND SWITCHES

Differential pressure transmitter for air and non-corrosive gases (low pressure) Transmitters with a high level of accuracy and stability. Quick and easy mounting. Technical data Supply voltage

24 V AC (24 V DC, two-wire for 4...20 mA), 0.24 VA

Accuracy

±1% fs

Ambient temperature

0...70°C

Protection class

IP54

Models without display Article

Working range

DTL05/05

-50...+50 Pa

Output signal 0...10 V DC

DTL05/05-420

-50...+50 Pa

4...20 mA

Models with display (non-stock item) Article

Working range

Output signal

DTL05/05-D

-50...+50 Pa

0...10 V DC

DTL05/05-420-D

-50...+50 Pa

4...20 mA

Accessories Article

Description

ANS-1

2 m plastic tube and two pressure outlets

CCERT-H

Calibration certificate for the DTL series, when certified calibration is demanded.

141

7

SENSORS AND SWITCHES

Differential pressure transmitter for liquids and gases Differential pressure transmitter for measurement of liquids (also glycol-mixed) and gases (not ammonia). The measuring element is made of a ceramic material that gives good stability and high measuring accuracy. Technical data Supply voltage

24 V AC / 18...33 V DC (output signal 0...10 V DC), 0.1 VA 11...33 V DC, two-wire (output signal 4...20 mA), 0.5 VA

Output signal

0...10 V DC or 4...20 mA (two-wire)

Ambient temperature

-15...+80°C

Connection

Screw fitting for Ø 6 mm pipe included

Protection class

IP65

Article

Working range

Output signal

Max. overload pressure (one side)

Accuracy ±1.3 % fs

DTK10

0...10 kPa

0...10 V DC

60 kPa

DTK10-420

0...10 kPa

4...20 mA

60 kPa

±1.3 % fs

DTK20

0...20 kPa

0...10 V DC

120 kPa

±1.3 % fs

DTK20-420

0...20 kPa

4...20 mA

120 kPa

±1.3 % fs

DTK40

0...40 kPa

0...10 V DC

200 kPa

±1.3 % fs

DTK40-420

0...40 kPa

4...20 mA

200 kPa

±1.3 % fs

DTK100

0...100 kPa

0...10 V DC

500 kPa

±1.3 % fs

DTK100-420

0...100 kPa

4...20 mA

500 kPa

±1.3 % fs

DTK250

0...250 kPa

0...10 V DC

1200 kPa

±1.3 % fs

DTK250-420

0...250 kPa

4...20 mA

1200 kPa

±1.3 % fs

DTK400

0...400 kPa

0...10 V DC

1200 kPa

±0.8 % fs

DTK400-420

0...400 kPa

4...20 mA

1200 kPa

±0.8 % fs

DTK600

0...600 kPa

0...10 V DC

1200 kPa

±0.5 % fs

DTK600-420

0...600 kPa

4...20 mA

1200 kPa

±0.5 % fs

DTK1000

0...1000 kPa

0...10 V DC

2000 kPa

±0.5 % fs

DTK1000-420

0...1000 kPa

4...20 mA

2000 kPa

±0.5 % fs

DTK1600

0...1600 kPa

0...10 V DC

3200 kPa

±0.5 % fs

DTK1600-420

0...1600 kPa

4...20 mA

3200 kPa

±0.5 % fs

Accessories Article

142

Accessories

DTK-NIPPEL

Nipple (R=1/8’’ 27NPT) for connection of Ø 6 mm copper pipe

DTK-R

Copper pipe, Ø 6 mm, length 30 cm

SENSORS AND SWITCHES

Pressure transmitter for liquids and gases Pressure transmitter for measurement of liquids (also glycol-mixed) and gases (not ammonia). Excellent long-term stability and extremelt low temperature dependency. Can also be delivered with other specifications, e.g. with absolute pressure. Technical data Supply voltage

24 V AC / 18...33 V DC (output signal 0...10 V DC), 0.1 VA 11...33 V DC, two-wire (output signal 4...20 mA), 0.5 VA

Output signal

0...10 V DC or 4...20 mA (two-wire)

Accuracy

±0.3 %

Connection

R1/4”

Packing

EPDM

Temperature range

-15...+80°C

Protection class

IP65

Article

Working range

TTK1

0...100 kPa

Output signal 0...10 V DC

TTK1-420

0...100 kPa

4...20 mA

TTK2

0...200 kPa

0...10 V DC

TTK2-420

0...200 kPa

4...20 mA

TTK5

0...500 kPa

0...10 V DC

TTK5-420

0...500 kPa

4...20 mA

TTK10

0...1000 kPa

0...10 V DC

TTK10-420

0...1000 kPa

4...20 mA

TTK16

0...1600 kPa

0...10 V DC

TTK16-420

0...1600 kPa

4...20 mA

TTK25

0...2500 kPa

0...10 V DC

TTK25-420

0...2500 kPa

4...20 mA

TTK40

0...4000 kPa

0...10 V DC

TTK40-420

0...4000 kPa

4...20 mA

TTK100

0...10000 kPa

0...10 V DC

TTK100-420

0...10000 kPa

4...20 mA

Accessories Article

Accessories

105074

Mounting spacer which lowers the temperature at higher media temperatures than the sensor can handle

ADAPTER

Adapter 1/4” to 1/2”. For mounting TG-D1... in 1/2”.

143

7

SENSORS AND SWITCHES

Flow Air velocity transmitter For air velocity measurement in ventilation ducts. Specially designed thin film sensor elements with high degree of mechanical and electrical repeatability. The working range is selected by means of a jumper on the circuit board. Short reaction time. Adjustable insertion length. Selectable working range and damping. Technical data

144

Supply voltage

24 V AC/DC ±20 %

Working range

0...10 m/s, 0...15 m/s, 0...20 m/s

Output signal

0...10 V (max. 1 mA), 4...20 mA

Time constant

1.5 s at 10 m/s

Accuracy

±(0.3 m/s + 3 % of the value) at 0...10 m/s ±(0.3 m/s + 3 % of the value) at 0...15 m/s ±(0.3 m/s + 4 % of the value) at 0...20 m/s

Damping

0.2 or 2 s

Ambient temperature

-10...+50°C

Insertion length

50...200 mm

Mounting

Duct

Protection class

IP65

Article

Description

AVDT25

Air velocity transmitter

SENSORS AND SWITCHES

Liquid flow switch FLSX is a series of electromechanical flow switches for heating and cooling systems They are available in brass (suitable for normal media), and stainless steel AISI 316L (suitable for seawater and aggressive media). Each model can be ordered with a 1” NPT thread on request. Technical data s

Dust-tight microswitch with switching s (NC/NO)

Switch capacity

15 (8) A, 24...250 V AC

Ambient temperature

-40...+85°C

Ambient humidity

10...90 % RH (non-condensing)

Media temperature

-40...+120°C

Paddles

Stainless steel AISI 316L

Casing

ABS, transparent Polycarbonate (PC) cover

Dimensions

140 x 62 x 65 mm

Protection class

IP65

Article

Connection

Max. pressure

Media

“T” pipe fitting

FLS304X

1...8”

11 bar

Normal

-

FLS304XT

1...8”

11 bar

Normal

-

FLS304XRE

1...8”

11 bar

Normal

-

FLS305XT

1...8”

30 bar

Corrosive

-

FLS305XRE

1...8”

30 bar

Corrosive

-

FLS306X

½”

11 bar

Normal

X

FLS307X

¾”

11 bar

Normal

X

FLS308X

1”

11 bar

Normal

X

Accessories Article

Description

FLZ-09

Stainless steel Aisi 316L paddles for liquid flow switch

145

7

SENSORS AND SWITCHES

CO2/CO/NO2 transmitters Carbon dioxide transmitter, wall mounting The CO2RT series with patented automatic calibration sets new standards for CO2 measurements in climate and ventilation systems. It combines measurements of CO2 level, temperature and relative humidity. Models are avaiable with or without display and relay. The calibration interval is more than 5 years, calibration is not necessary at installation. Technical data Supply voltage

24 V AC ±15 %, 50...60 Hz or 15...35 V DC, 3 VA

Working range, CO2

0…2000 ppm

Working range, temperature

0...50°C

Working range, humidity

10...90 % RH

Accuracy, CO2

< ±(50 ppm +2 % of the working range)

Accuracy, temperature

±0.3°C

Accuracy, humidity

±3 % at 30...70 % RH, ±5 % at 10...90 % RH

Relay output

Max. Max. 1 A at 50 V AC, min. 1 mA at 5 V DC

Mounting

Wall

Protection class

IP30

Outputs

146

CO2

0...10 V DC referring to 0...2000 ppm

Temperature

0...10 V DC referring to 0...50°C , PT1000-sensor (DIN class B)

Humidity

0...10 V DC referring to 0...100 % RH (working range 1...9 V)

Article

Description

Temperature measurement

Humidity measurement

Relay

CO2RT

CO2and temperature transmitter

X

-

-

CO2RT-D

CO2and temperature transmitter

X

-

-

CO2HRT

CO2, temperature and humidity transmitter

X

X

-

CO2HRT-D

CO2, temperature and humidity transmitter

X

X

-

CO2RT-R

CO2transmitter with relay

-

-

X

CO2RT-R-D

CO2transmitter with relay

-

-

X

SENSORS AND SWITCHES

Carbon dioxide transmitter, duct mounting Measures the concentration of carbon dioxide in ducts. The calibration interval is more than five years, calibration is not necessary at installation. Good long-term stability Technical data Supply voltage

24 V AC ±20 %, 50...60 Hz or 15...35 V DC, 3 VA

Working range

0...2000 ppm

Output signal

0...10 V DC / 4...20 mA

Accuracy

±(50 ppm + 2 % of the measured value)

Relay output

Max. Max. 1 A at 50 V AC, min. 1 mA at 5 V DC

Mounting

Duct

Protection class

IP65

Article

Description

Relay

CO2DT

CO2 transmitter

-

CO2DT-R

CO2 transmitter with relay

X

On request also available with 0...5000 ppm working range.

Carbon monoxide transmitter COF is a detector intended for demand-controlled ventilation in parking garages and road tunnels etc. The detector is installed for both safety and energy-saving reasons. It measures the carbon monoxide concentration using an electrochemical method of measurement characterised by high selectivity even in low concentrations. The output signals are linear representations of the gas concentration. The transmitter is TÜV-approved in accordance with VDI 2053. Technical data Supply voltage

12...28 V DC

Measuring range

0...300 ppm

Outputs

4...20 mA, two-wire 0...10 V DC, three-wire

Calibration

Automatic zero adjustment

Protection class

IP56

Article

Description

COF

CO transmitter

147

7

SENSORS AND SWITCHES

Nitrogen dioxide transmitter NO2F is a detector intended for demand-controlled ventilation in parking garages and road tunnels etc. The detector is installed for both safety and energy-saving reasons. It measures the nitrogen dioxide concentration using an electrochemical method of measurement characterised by high selectivity even in low concentrations. The output signals are linear representations of the gas concentration. The transmitter is TÜV-approved in accordance with VDI 2053. Technical data

148

Supply voltage

12...28 V DC

Measuring range

0...20 ppm

Outputs

4...20 mA, two-wire 0...10 V DC, three-wire

Calibration

Automatic zero adjustment

Protection class

IP56

Article

Description

NO2F

NO2 transmitter

8 D E T E C TO R S

DETECTORS

8

149

D E T E C TO R S

Detectors Ionisation single-tube smoke detector for duct mounting 600 mm venturi tube is included. Technical data Supply voltage

9...33 V DC (via ABV control unit). 24 V AC ±15 % for RAC(M) models.

Power consumption, incl. end resistor (not RAC(M))

Normal operation: 11 mA at 24 V DC. Alarm condition: 50 mA at 24 V DC. Service alarm condition: 20 mA at 24 V DC.

Mounting

Duct

Protection class

IP54

Article

Description

SDD-S65

Ionisation detector

SDD-S50

Ionisation detector with service alarm

SDD-S65-RAC

Ionisation detector with AC power supply and relay output only

SDD-S65-RACM

Ionisation detector with AC power supply and relay output only. With auxiliary fan.

SDD-S65-M

Ionisation detector with auxiliary fan

SDD-S50-M

Ionisation detector with auxiliary fan and service alarm

Accessories Article

Accessories

TDS

Mounting spacer for insulated pipe ducts

VR600

Venturi tube, 600 mm length (standard)

VR2000

Venturi tube, 2000 mm length

Optical single-tube smoke detector for duct mounting 600 mm venturi tube is included. Technical data Supply voltage

9...33 V DC (via ABV control unit). 24 V AC ±15 % for RAC(M) models.

Power consumption, incl. end resistor (not RAC(M))

Normal operation: 11 mA at 24 V DC. Alarm condition: 50 mA at 24 V DC. Service alarm condition: 20 mA at 24 V DC.

Mounting

Duct

Protection class

IP54

Article

Description

SDD-OE65

Optical detector

SDD-OE50

Optical detector with service alarm

SDD-OE65-RAC

Optical detector with AC power supply and relay output only.

SDD-OE65-RACM

Optical detector with AC power supply and relay output only. With auxillary fan.

SDD-OE65-M

Optical detector with auxiliary fan

SDD-OE50-M

Optical detector with auxiliary fan and service alarm

Accessories

150

Article

Accessories

TDS

Mounting spacer for insulated pipe ducts

D E T E C TO R S

Smoke detector for ceiling mounting Technical data Supply voltage

15...30 V DC (via ABV control unit)

Power consumption

0.14 mA (50 mA if an alarm occurs)

Mounting

Ceiling

Protection class

IP20

Article

Description

Service alarm

S65-OE

Optical detector

-

S50-OE-GA4

Optical detector with service alarm

X

S65

Ionisation detector

-

S50

Ionisation detector with service alarm

X

Accessories Article

Description

S-BP

Socket for S50 and S65 detectors

S-BPR-S50

Socket for S50 detectors with built-in change-over relay (24 V AC)

S-BPR-S65

Socket for S65 detectors with built-in change-over relay (24 V AC)

8

Control unit for smoke detectors Control units for the SDD, S50 and S65 series. Provides power supply and alarm handling for smoke detectors, with or without service alarm. Two relay s for alarm handling. Technical data Power consumption

30 mA (70 mA if an alarm occurs), 1 VA (1.7 VA if an alarm occurs)

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

Supply voltage

Alarm outputs

Service alarm

ABV24-300/D

Control unit

24 V AC/DC

Two change-over s (smoke alarms)

-

ABV24-S-300/D

Control unit with service alarm

24 V AC/DC

One change-over (smoke), one closing (smoke), one closing (service)

X

ABV-300/D

Control unit

230 V AC

Two change-over s (smoke alarms)

-

ABV-S-300/D

Control unit with service alarm

230 V AC

One change-over (smoke), one closing (smoke), one closing (service)

X

151

D E T E C TO R S

Smoke spray Gas for control of ionisation or optical smoke detectors. Article

Description

SS-260

Smoke spray, 260 ml

Presence detector Detector providing a signal when someone enters the room. The detector has a pulse-detecting function that minimizes the risk of false alarms. Settable on/off delays and change-over relay. Technical data

IR24-P

I R 2 4 - PC

152

Supply voltage

24 V AC/DC, 0.1 VA

Alarm output

200 mA, 24 V DC, floating, change-over relay

Power consumption

15 mA

Temperature range

-20…+50°C

Ambient humidity

Max. 95 % RH

Protection class

IP20

Article

Mounting

Detection area

IR24-P

Wall

15 x 15 m, 110° angle

IR24-PC

Ceiling

Height x 2.5 = coverage diameter, 25° angle

9

ENERGY METERS

ENERGY METERS

9

+21°C

kWh 153

ENERGY METERS

Energy meter with coaxial multi-jet flow meter Compact energy meters intended for heating or cooling. Technical data Calculator Power supply

3 V lithium battery, min. 6 + 1 years

Temperature range

1...150°C

Protection class

IP54

Flow meter Connection

Threaded according to ISO 228/1

Pressure rating

PN16

Media

Water

Mounting position

Horizontal or vertical

Temperature sensor Cable length

1.5 m (the other temperature sensor is integrated into the flow meter)

Sensor element

PT500; separately approved type as per EN60751, unshielded

Diameter, sensor

5 mm

Article

Description

MSH...

Energy meter with coaxial multi-jet flow meter. See ordering code selection table for more information on each model.

Ordering code selection table Options Flow (thread on meter body) (DN) (length of flow meter)

Type of measurement and installation point

Communication interface

MSH 0.6 m³/h (G3/4") (DN15) (110 mm)

15-0.6

1.5 m³/h (G3/4")(DN15) (110 mm)

15-1.5

2.5 m³/h (G1") (DN20) (130 mm)

20-2.5

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus

-

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

154

M

ENERGY METERS

Accessories for MSH Brass threaded fitting with coupling ring and gasket B

A

Article

Connection A

Connection B

Compatible with

VSR-½

G¾

R½

qp0.6/1.5 m3/h

VSR-¾

G1

R¾

qp0.6/1.5/2.5/3.5 m3/h

Ball valve with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

KH-¾

Rp¾

G¾

qp0.6/1.5 m3/h

KH-1

Rp1

G1

qp0.6/1.5/2.5/3.5 m3/h

Ball valve with installation point for a temperature sensor (sockets M10x1) A

A

Article

Connection A

Compatible with

KH-S-¾

G¾

qp0.6/1.5 m3/h

KH-S-1

G1

qp0.6/1.5/2.5/3.5 m3/h

M10x1

Forward flow adapter with gasket, for direct mounting of temperature sensor in T-piece Article

Connection A

VAD-½”

G½, M10x1

VAD-3/8”

G3/8, M10x1

9

Threaded adapter to replace flow meter temporarily or permanently A

L

Article

Connection A

Compatible with

Installation length (L)

PS-110-¾

G¾

qp 0.6/1.5 m3/h

110 mm

PS-130-1

G1

3

qp 2.5 m /h

130 mm

155

ENERGY METERS

Energy meter with multi-jet flow meter Compact energy meters for heating or cooling, consisting of a multi-jet flow meter for horizontal or vertical mounting, a pair of temperature sensors and a calculator. Technical data Calculator Power supply

3 V lithium AA battery, replaceable

Temperature range

1...150°C

Protection class

IP65

Flow meter Connection

Threaded according to ISO 228/1 or flanged according to EN 1092-2 (see ordering code selection table)

Pressure rating

PN16

Media

Water

Mounting position

Horizontal or vertical (see ordering code selection table)

Temperature sensor Cable length

3m

Sensor element

PT500; separately approved type as per EN60751, unshielded

Diameter, sensor

6 mm

Article

Description

MTH...

Energy meter with multi-jet flow meter. See ordering code selection table for more information on each model.

Ordering code selection table Options Connection and installation position (lenght of meter)

Flow select m³/h (DN) (connection)

Type of measurement and installation point

Communication interface

MTH Flanged horisontal (DN20=190 mm, DN25=260 mm, DN40=300 mm)

FH

Threaded horizontal (DN20=190 mm, DN25=260 mm, DN40=300 mm)

TH

Threaded vertical rising pipe (DN20=105 mm, DN25=150 mm, DN40=200 mm)

TVR

Threaded vertical falling pipe (DN20=105 mm, DN25=150 mm, DN40=200 mm)

TVF

1.5 m³/h (DN20) (Flange PN16 or thread G1” on body)

-

20-1.5

2.5 m³/h (DN20) (Flange PN16 or thread G1” on body)

-

20-2.5

3.5 m³/h (DN25) (Flange PN16 or thread G1 1/4” on body)

-

25-3.5

6.0 m³/h (DN25) (Flange PN16 or thread G1 1/4” on body)

-

25-6.0

10 m³/h (DN40) (Flange PN16 or thread G2” on body)

-

40-10

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

156

ENERGY METERS

Accessories for MTH Brass threaded fitting with coupling ring and gasket B

A

Article

Connection A

Connection B

Compatible with

VSR-¾

G1

R¾

qp0.6/1.5/2.5/3.5 m3/h

VSR-1

G1¼

R1

qp3.5/6.0 m3/h

VSR-1½

G2

R1½

qp10 m3/h

Ball valve with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

KH-1

Rp1

G1

qp0.6/1.5/2.5/3.5 m3/h

KH-1¼

Rp1¼

G1¼

qp3.5/6.0 m3/h

KH-2

Rp2

G2

qp10 m3/h

Temperature pocket for installation of universal temperature sensor with 6 mm sheath diameter L A

Article

Connection A

Compatible with

Installation length (L)

TH-85-½

G½

qp3.5/10 m3/h

85 mm

Threaded adapter to replace flow meter temporarily or permanently A

L

Article

Connection A

Compatible with

Installation length (L)

PS-105-1

G1

qp 1.5/2.5 m3/h

105 mm

PS-150-1¼

G1¼

qp 3.5/6 m3/h

150 mm

3

190 mm

PS-190-1

G1

qp 1.5/2.5 m /h

PS-200-2

G2

qp 10 m3/h

200 mm

PS-260-1¼

G1¼

qp 3.5/6 m3/h

260 mm

PS-300-2

G2

qp 10 m3/h

300 mm

157

9

ENERGY METERS

Energy meter with ultrasonic flow meter Compact energy meters with built-in ultrasonic flow meter, intended for heating or cooling. Technical data Calculator Power supply

3 V lithium battery, min. 6 + 1 years

Temperature range

1...105°C

Protection class

IP54

Flow meter Connection

Threaded according to ISO 228/1

Pressure rating

PN16

Media

Water

Mounting position

Horizontal or vertical

Temperature sensor Cable length

1.5 m (the other temperature sensor is integrated into the flow meter)

Sensor element

PT1000, DIN IEC 60751

Diameter, sensor

5 mm

Article

Description

SS2U...

Energy meter with ultrasonic flow meter. See ordering code selection table for more information on each model.

Ordering code selection table Options Flow (thread on meter body) (DN) (length of flow meter)

Type of measurement and installation point

Communication interface

SS2U 0.6 m³/h (G3/4") (DN15) (110 mm)

15-0.6

1.5 m³/h (G3/4")(DN15) (110 mm)

15-1.5

2.5 m³/h (G1") (DN20) (130 mm)

20-2.5

3.5 m³/h (G1") (DN20) (130 mm)

20-3.5

3.5 m³/h (G1 1/4") (DN25) (150 mm)

25-3.5

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

158

ENERGY METERS

Accessories for SS2U Brass threaded fitting with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

VSR-½

G¾

R½

qp0.6/1.5 m3/h

VSR-¾

G1

R¾

qp0.6/1.5/2.5/3.5 m3/h

VSR-1

G1¼

R1

qp3.5/6.0 m3/h

Ball valve with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

KH-¾

Rp¾

G¾

qp0.6/1.5 m3/h

KH-1

Rp1

G1

qp0.6/1.5/2.5/3.5 m3/h

KH-1¼

Rp1¼

G1¼

qp3.5/6.0 m3/h

Ball valve with installation point for a temperature sensor (sockets M10x1)

A

A

M10x1

Article

Connection A

Compatible with

KH-S-¾

G¾

qp0.6/1.5 m3/h

KH-S-1

G1

qp0.6/1.5/2.5/3.5 m3/h

KH-S-1¼

G1¼

qp3.5/6.0 m3/h

Forward flow adapter with gasket, for direct mounting of temperature sensor in T-piece Article

Connection A

VAD-½”

G½, M10x1

VAD-3/8”

G3/8, M10x1

Threaded adapter to replace flow meter temporarily or permanently A

L

Article

Connection A

Compatible with

Installation length (L)

PS-110-¾

G¾

qp 0.6/1.5 m3/h

110 mm

PS-130-1

G1

qp 2.5 m3/h

130 mm

3

150 mm

PS-150-1¼

G1¼

qp 3.5/6 m /h

159

9

ENERGY METERS

Ultrasonic energy meters Horizontal or vertical mounting. Technical data Calculator Power supply

3.6 V lithiumbatteri

Temperature range

1...150°C

Protection class

IP54 (heating), IP65 (cooling)

Flow meter Connection

Flanged according to EN 1092-3

Pressure rating

PN25

Media

Water

Mounting position

Horizontal or vertical

Temperature sensor Cable length

3m

Sensor element

PT500; separately approved type as per EN60751, unshielded

Diameter, sensor

6 mm

Article

Description

US-S/FFL...

Ultrasonic energy meter. See ordering code selection table for more information on each model.

Ordering code selection table Options Flow select m³/h (DN) (Length in mm) (Flange)

Type of measurement and installation point

Communication interface

US-S/FFL 3.5 m³/h (DN25) (260 mm) (PN25 flange with 4 bolt holes)

25-3.5

6.0 m³/h (DN25) (260 mm) (PN25 flange with 4 bolt holes)

25-6.0

10 m³/h (DN40) (300 mm) (PN25 flange with 4 bolt holes)

40-10

15 m³/h (DN50) (270 mm) (PN25 flange with 4 bolt holes)

50-15

25 m³/h (DN65) (300 mm) (PN25 flange with 8 bolt holes)

65-25

40 m³/h (DN80) (300 mm) (PN25 flange with 8 bolt holes)

80-40

60 m³/h (DN100) (360 mm) (PN25 flange with 8 bolt holes)

100-60

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus with power supply

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

160

ENERGY METERS

Accessories for US-S/FFL L A

TH-85 L

Temperature pocket for installation of universal temperature sensor with 6 mm sheath diameter Article

Connection A

Compatible with 3

Installation length (L)

TH-85-½

G½

qp3.5/10 m /h

85 mm

TH-120-½

G½

qp15-100 m3/h

120 mm

A

TH-120

9

161

ENERGY METERS

Ultrasonic energy meters Horizontal or vertical mounting. Technical data Calculator Power supply

3.6 V lithiumbatteri

Temperature range

1...150°C

Protection class

IP54 (heating), IP65 (cooling)

Flow meter Connection

Threaded according to ISO 228/1

Pressure rating

PN16

Media

Water

Mounting position

Horizontal or vertical

Temperature sensor Cable length

3 m (the other temperature sensor is integrated into the flow meter)

Sensor element

PT500; separately approved type as per EN60751, unshielded

Diameter, sensor

5 mm

Article

Description

US-WV...

Ultrasonic energy meter. See ordering code selection table for more information on each model.

Ordering code selection table Options Flow (thread on meter body) (DN) (length of flow meter)

Type of measurement and installation point

Communication interface

US-WV 0.6 m³/h (G3/4") (DN15) (110 mm)

15-0.6

1.5 m³/h (G3/4")(DN15) (110 mm)

15-1.5

0.6 m³/h (G1") (DN20) (190 mm)

20-0.6

1.5 m³/h (G1") (DN20) (190 mm)

20-1.5

2.5 m³/h (G1") (DN20) (190 mm)

20-2.5

3.5 m³/h (G1 1/4") (DN25) (260 mm)

25-3.5

6.0 m³/h (G1 1/4") (DN25) (260 mm)

25-6.0

10 m³/h (G2) (DN40") (300 mm)

40-10

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus with power supply

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

162

ENERGY METERS

Accessories for US-WV Brass threaded fitting with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

VSR-½

G¾

R½

qp0.6/1.5 m3/h

VSR-¾

G1

R¾

qp0.6/1.5/2.5/3.5 m3/h

VSR-1

G1¼

R1

qp3.5/6.0 m3/h

VSR-1½

G2

R1½

qp10 m3/h

Ball valve with coupling ring and gasket

B

A

Article

Connection A

Connection B

Compatible with

KH-¾

Rp¾

G¾

qp0.6/1.5 m3/h

KH-1

Rp1

G1

qp0.6/1.5/2.5/3.5 m3/h

KH-1¼

Rp1¼

G1¼

qp3.5/6.0 m3/h

KH-2

Rp2

G2

qp10 m3/h

Ball valve with installation point for a temperature sensor (sockets M10x1)

A

A

M10x1

Article

Connection A

Compatible with

KH-S-¾

G¾

qp0.6/1.5 m3/h

KH-S-1

G1

qp0.6/1.5/2.5/3.5 m3/h

KH-S-1¼

G1¼

qp3.5/6.0 m3/h

KH-S-2

G2

qp10 m3/h

9

Forward flow adapter with gasket, for direct mounting of temperature sensor in T-piece Article

Connection A

VAD-½”

G½, M10x1

VAD-3/8”

G3/8, M10x1

Threaded adapter to replace flow meter temporarily or permanently A

L

Article

Connection A

Compatible with

Installation length (L)

PS-110-¾

G¾

qp 0.6/1.5 m3/h

110 mm

PS-190-1

G1

qp 1.5/2.5 m3/h

190 mm

3

PS-260-1¼

G1¼

qp 3.5/6 m /h

260 mm

PS-300-2

G2

qp 10 m3/h

300 mm

163

ENERGY METERS

Woltmann type combined energy meter Woltmann flow meters for large nominal flows combined with calculator and temperature sensors. Technical data Calculator Power supply

3 V lithium AA battery, replaceable

Temperature range

1...150°C

Protection class

IP65

Connection

Flanged according to EN 1092-2

Pressure rating

PN16

Media

Water

Mounting position

WSTH horizontal only, WPTH horizontal or vertical

Temperature sensor Cable length

3m

Sensor element

PT500; separately approved type as per EN60751, unshielded

Diameter, sensor

6 mm

Article

Description

WSTH...

Woltmann type combined energy meter for horizontal mounting. See ordering code selection table for more information on each model.

WPTH...

Woltmann type combined energy meter for horizontal or vertical mounting. See ordering code selection table for more information on each model.

Ordering code selection table Options Flow select m³/h (DN) (flange) (length of meter)

Type of measurement and installation point

Communication interface

WSTH 15 m³/h (DN50) (PN16 flange with 4 bolt holes) (270 mm)

50-15

25 m³/h (DN65) (PN16 flange with 4 bolt holes) (300 mm)

65-25

40 m³/h (DN80) (PN16 flange with 8 bolt holes) (300 mm)

80-40

60 m³/h (DN100) (PN16 flange with 8 bolt holes) (360 mm)

100-60

150 m³/h (DN150) (PN16 flange with 8 bolt holes) (500 mm)

150-150

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy or volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

164

ENERGY METERS

Ordering code selection table Options

WPTH

Flow select m³/h (DN) (flange) (length of meter)

15 m³/h (DN50) (PN16 flange with 4 bolt holes) (200 mm)

50-15

25 m³/h (DN65) (PN16 flange with 4 bolt holes) (200 mm)

65-25

32 m³/h (DN80) (PN16 flange with 8 bolt holes) (225 mm)

80-32

60 m³/h (DN100) (PN16 flange with 8 bolt holes) (250 mm)

100-60

100 m³/h (DN125) (PN16 flange with 8 bolt holes) (250 mm)

125-100

200 m³/h (DN150) (PN16 flange with 8 bolt holes) (300 mm)

150-200

250 m³/h (DN200) (PN16 flange with 12 bolt holes) (350 mm)

200-250

400 m³/h (DN250) (PN16 flange with 12 bolt holes) (450 mm)

250-400

600 m³/h (DN300) (PN16 flange with 12 bolt holes) (500 mm)

300-600

Type of measurement and installation point

Communication interface

Heating installation of flow meter in return pipe (MID approval)

-

HR

Cooling¹, installation of flow meter in supply pipe

-

CS

Heating and cooling in combination², installation of flow meter in supply pipe.

-

HCS

Heating and cooling in combination², installation of flow meter in return pipe.

-

HCR

M-Bus

-

M

M-Bus with 2 pulse inputs

-

MPI

Pulse output for energy and volume

-

PO

¹ TÜV approval. 2 MID approval for heating, not for cooling. If any further requirements or options are needed, or for pricing questions, please Regin.

Accessories for WSTH / WPTH Temperature pocket for installation of universal temperature sensor with 6 mm sheath diameter

L A

TH-120 L

Article

Connection A

Compatible with 3

Installation length (L)

TH-120-½

G½

qp15-100 m /h

120 mm

TH-210-½

G½

> qp150 m3/h

210 mm

A

TH-210

165

9

ENERGY METERS

166

10 AC C E S S O R I E S

ACCESSORIES

10

+21°C

167

AC C E S S O R I E S

Rotation sentinel SPINN/D is an electronic rotation sentinel, primarily intended for supervision of rotating heat-exchanger wheels. It has a change-over alarm relay and a function for blocking the alarm output at intentional stops. Technical data Supply voltage

230 V AC, 5 VA

Alarm relay

5 A, 250 V AC, change-over

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

SPINN/D

Rotation sentinel

Accessories

168

Article

Description

RR-G3

Sensor including magnet

MAGNET-424

Extra magnet

AC C E S S O R I E S

Modems 3G modem for CLOUDigo CLO-3G is a package consisting of a 3G modem with a factory-installed SIM card, ready for immediate connection to CLOUDigo. The modem functions as a gateway between a T/IP connected Corrigo and CLOUDigo. It has a built-in DH function that handles connecting to an external unit. Technical data

CLO-3G

Connection

Ethernet (RJ45, crossover network cable), antenna (SMA-F )

Communication

LAN (T/IP, DH), mobile network (3G or GSM/GPRS)

Ambient temperature

-30...+60°C

Article

Description

CLO-3G

3G modem with factory-installed SIM card for connecting to CLOUDigo

Accessories

MODEM3GANT

Article

Description

MODEM3G-ANT

External antenna for MODEM3G with 3.6 m cable

E-CABLE-T/IP

Cable for T/IP connection directly to a PC

Dial-up modem for EXOscada, EXOcompact and Corrigo Industrial auto-dial modem, approved for use in most European countries. Technical data Supply voltage

24 V DC

Mounting

DIN-rail

Number of modules

1.4

Article

Description

MODEM56kINT232

Modem for EXOscada

MODEM56kINT485

Modem for Corrigo/EXOcompact. Delivered with a null modem adapter and an E-CABLE.

Accessories Article

Description

CABLEMODEM56KINT

0.7 m cable for connecting MODEM56kINT to EXOflex

For accessories, see the power supply unit X1111, 230 V AC / 24 V DC.

169

10

AC C E S S O R I E S

GSM modem GSM modem for Nimbus GSM modem to be used together with the Nimbus alarm software, 230 V AC supply voltage. The modem is delivered with a power supply unit, an external antenna and a computer cable with 9-pole D-sub s.

GSM modem for EXOcompact / Corrigo GSM modem for use together with EXOcompact or Corrigo. DIN-rail mounting, 230 V AC or 24 V DC supply voltage. The modem is delivered with a power supply unit, an external antenna and a cable for connection to the RS485 port on the controller.

GSM modem for EXOflex GSM modem for DIN-rail mounting, 24 V DC supply voltage. The modem is delivered with an external antenna and a cable for connection to EXOflex port 3 (RS232). Article

Description

GSM-MAESTRO100

Base modem*

GSM100L-PC

Nimbus kit

GSM100L-CORRIGO

EXOcompact/Corrigo kit

GSM100L-EXOFLEX

EXOflex kit

* A base modem is required for each kit.

GPRS router GPRS router which makes it possible to connect Regin’s controllers to a main computer using GPRS communication. It is strongly recommended that you choose a fixed monthly rate from your internet provider. DIN-rail mounting, 24 V DC supply voltage. The GPRS router is delivered with an external antenna. Article

Description

GPRS5.0E

GPRS Router 5.0 Ethernet

For accessories, see e.g. the power supply units X1111 and X1312, 230 V AC / 24 V DC.

170

AC C E S S O R I E S

Serial adapter for RS485 to T for Modbus ConverterT is a serial adapter that converts Modbus RS485 to T/IP. It can be connected to Regin’s Corrigo, EXOcompact and EXOflex controllers, etc. The adapter can be used for individual units or an entire network. Technical data Working voltage

10...60 V DC

Rated current

125 mA at 24 V DC

Connection

Lift type terminal

Speed

0.3...115.2 kbit/s

Insulation

Power and ports: 3000 V Between ports: 1500 Vrms

Mounting

DIN rail

Dimensions (WxHxD)

35 x 121 x 121 mm

Article

Description

CONVERTERT

Adapter

10

171

AC C E S S O R I E S

Displays External graphic touch display For operation of a Corrigo ventilation with two ports. Intended for supervision and control of an air handling system. Technical data

172

Protection class

IP30

Power supply

24 V DC via terminal 4 (+C) and G0 on the Corrigo

Power consumption

50 mA

Connection cable

Twisted pair, 0.25 mm2

Display

TFT-LCD (resistive), backlit LED

Language

Swedish or English, set automatically depending on the language used in the Corrigo

Aspect ratio

4:3

Resolution

320 x 240

Dimensions (WxHxD)

120 x 90 x 27 mm

Mounting

On wall or device box

Communication

EXOline

Article

Description

ED-TCV

External graphic touch display

AC C E S S O R I E S

External display unit for EXOflex, Corrigo and EXOcompact ED9200 is an external, independent display and configuration unit for EXOflex, Corrigo or EXOcompact. EXOcompact C...-3 and Corrigo E...-3 s use of ED9200 and an internal display at the same time. Earlier versions either only an external or an internal display. When connected to an EXOflex system, it acts as a free-standing PIFA which can be connected to a processor housing via the EFX channel. The display can be connected in two ways, either temporarily via a quick cable connection in the front of the Power PIFA, or permanently via screw connectors. ED9200 can be connected to an EXOflex system configured for EP9040 (LOT). Technical data Power supply

With Corrigo or EXOcompact: Internal supply, via communication cable With EXOflex: 24 V DC, via the EFX channel

Cabling

With Corrigo E...-S or EXOcompact C...-S: EK12 (3 m), EK14 (10 m) With Corrigo E...-3 or C...-3: EDSP-K3 (3 m), EDSP-K10 (10 m) or self-made With EXOflex: Cat 5

Cable type when self-made

With Corrigo or EXOcompact: 26AWG With EXOflex: Cat 5

Quick connection when self-made

With Corrigo E...-3 or EXOcompact C...-3: 4P4C With EXOflex: USB type A male connector

Tolerance

With Corrigo or EXOcompact: With EXOflex: 18...30 V DC

Power consumption

With Corrigo or EXOcompact: With EXOflex: 50 mA

Communication port

With Corrigo or EXOcompact: Serial, special With EXOflex: The EFX channel

Max. cable length

With Corrigo or EXOcompact: 10 m (E...-S and C...-S), 100 m (E...-3 and C...-3) With EXOflex: 200 m

Software requirements

With Corrigo or EXOcompact: EXOreal 2.8-1-29 or later With EXOflex: EXOreal 2.8-1-26 or later

Article

Description

Protection class

ED9200

External display unit

IP41

ED9200IP65

External display unit

IP65

Accessories Article

Description

Cable length

EK10

Cable for connecting ED9200 to an EXOflex system

1.5 m

EK10-3

Cable for connecting ED9200 to an EXOflex system

3m

EK12

Cable for connecting ED9200 to a Corrigo E...-S or EXOcompact C...-S

3m

EK14

Cable for connecting ED9200 to a Corrigo E...-S or EXOcompact C...-S

10 m

EDSP-K3

3 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

3m

EDSP-K10

10 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

10 m

173

10

AC C E S S O R I E S

External display unit for EXOcompact and Corrigo Backlit LCD display for Corrigo and EXOcompact without display. The display offers full external control when the controller is mounted in a or similar. Corrigo and EXOcompact have a RJ12 modular jack for fast connection. Technical data Protection class

IP41 or IP65

Article

Description

Cable length

Protection class

ED9100-3

Display unit

3m

IP41

ED9100-10

Display unit

10 m

IP41

ED9100IP65-3

Display unit

3m

IP65

If the distance between the controller and ED9100 exceeds 10 m, the display repeaters E0-R / E0-R230K can be used.

External display unit for EXOcompact C...-3 and Corrigo E...-3 Display for operation of a EXOcompact C...-3 or Corrigo E...-3. E3-DSP can be connected to controllers with or without a built-in display. The external display and the built-in display can be used simultaneously. Technical data Protection class

IP40

Connection cable

3 m, 10 m or -supplied cable, max. 100 m

Article

Description

E3-DSP

External display

Cable must be ordered separately.

Accessories Article

Description

EDSP-K3

3 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

EDSP-K10

10 m cable for connecting E3-DSP or ED9200 to a Corrigo E...-3 or EXOcompact C...-3

External display unit for EXOcompact C...-S and Corrigo E...-S -friendly, stand-alone display- and configuration unit for Corrigo E...-S and EXOcompact C...-S without display. E-DSP offers full external control when the controller is mounted inside a cabinet etc. Mounting on wall or device box (cc 60 mm) Four row backlit LCD display Technical data Protection class

IP44

Article

Description

Cable length

E-DSP-3

External display

3m

E-DSP-10

External display

10 m

If the distance between the controller and E-DSP exceeds 10 m, the display repeaters E0-R / E0-R230K can be used.

174

AC C E S S O R I E S

Displays for mounting DP102 and DP156 are computers intended to be mounted in for example a cabinet door. They can easily be connected to Regin’s EXOscada and to Regin’s controllers, with or without integrated web. Technical data U type

Intel Atom N270 1.6 GHz

RAM

1 GB

Supply voltage

Power supply unit for 12 V DC (2.5 A) included in the delivery

Protection class

IP65

Mounting

Cabinet mounting, VESA 75 / 100 (screws included)

Article

Monitor size

Resolution

Flash memory

Ports

DP102

10.2”

1024 x 600

8 GB

3 x COM ports (RS232), 2 x USB ports, 1 x LAN port (Realtek RLT8111C 10/100/1000 Mbps)

DP156

15.6”

1366 x 768

4 GB

5 x COM ports (RS232), 2 x USB ports, 1 x LAN port (Realtek RLT8111C 10/100/1000 Mbps)

10

175

AC C E S S O R I E S

External room unit The ED-RU units are primarily intended for control of an air handling unit via a Corrigo controller running a ventilation application. They can be used to change fan speed, set temperature, extended running, etc. at a distance of up to 300 m. Their stylish design is suitable for all environments. The units have a built-in temperature sensor. An external PT1000-sensor can also be connected. Technical data

E D - RU

E D - RU - O

E D - RU - F

E D - RU - FO

ED - RU - D O

ED - RU - D FO

ED - RU - D O S

E D - RU - H 176

Supply voltage

24 V AC

Power consumption

25 mA

Protection class

IP20

Ambient humidity

Max. 90 % RH

Storage temperature

-20…+70°C

Mounting

On wall or device box

Dimensions (WxHxD)

95 x 95 x 28 mm

Communication

EXOline

Article

Occupancy button

3-step fan control

Setpoint knob

Multi-function button

Hidden setpoint

Display

ED-RU

-

-

X

-

-

-

ED-RU-O

X

-

X

-

-

-

ED-RU-F

-

X

X

-

-

-

ED-RU-FO

X

X

X

-

-

-

ED-RU-DO

X

-

-

-

-

X

ED-RU-DFO

X

X

-

-

-

X

ED-RU-DOS

X

-

-

X

-

X

ED-RU-H

-

-

-

-

X

-

The ED-RU range can also be used together with EXOcompact and EXOflex. If so, the room units must first be configured by a competent system integrator via Project Builder.

AC C E S S O R I E S

Display repeater for E-DSP and ED9100 Repeater for handling distances from 10 to 1000 m between Corrigo / EXOcompact and the external display units E-DSP and ED9100. Article

Power supply

Protection class

Mounting

Number of modules

E0-R

24 V AC

IP20

DIN-rail

8.5

E0-R230K

230 V AC

IP65

Wall

10

177

AC C E S S O R I E S

Step controllers Step controller, 1- or 2-stage Step controllers suitable for heating/cooling or alarm applications. Convert a 0...10 V DC input signal to a relay output. The controllers are suitable for DIN-rail or cabinet mounting and have adjustable switching points. SC2/D can be set to either binary or sequential control. Individually settable on/off levels Technical data Supply voltage

24 V AC, 2 VA

Input signal

0...10 V DC

Settings

0...10 V DC

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

Output

Step differential

SC1/D

Step controller with 1 relay (change-over)

One relay, change-over, 10 A, 250 V AC

-

SC2/D

Step controller with 2 relays (closing)

Two relays, closing, 10 A, 250 V AC

0...2 V DC

Step controller, 4- or 6-stage Controllers intended for control of electric heating coils, four or six relays. The controller can be set to sequential or binary control. It can be used with any controller with an 0...10 V DC or 10...2 V DC output signal. 2 V DC output signal. The required number of steps is set by means of the rotating switch on the front. The 0...10 V DC input signal is divided up into the number of steps, thus setting the switch-on point for each step. Relay 6 on TT-S6/D can be used as a time-lag relay to delay shut-off of the fan when shutting down the system (3 min. delay). The step controllers also have an analogue output (0…10 V) for control of an electric heating controller (TTC or similar) to give proportional heating between steps. Technical data

178

Supply voltage

24 V AC, 6 VA

Output

4 alt. 6 relays (closing), binary or sequential control

Input signal

0...10 V DC

Output signal

0...10 V DC

Mounting

DIN-rail

Number of modules

6

Protection class

IP20

Article

Description

TT-S4/D

Step controller with 4 relays

Run-on time -

TT-S6/D

Step controller with 6 relays

3 min

AC C E S S O R I E S

Relay module Relay module with six relays, intended for use together with Regin’s Corrigo / EXOxompact controllers. The relay module can be used for control of objects with higher voltage loads or larger current drain than the Corrigo / EXOcompact outputs can handle. RM6H-24/D has manual switches for manual control of each object. Technical data Supply voltage

24 V AC ±15 %, 5 VA

Inputs

Six 24 V AC

Output

Six potential-free change-over s, 230 V AC, 10 A

Mounting

DIN-rail

Number of modules

6 (105 x 112 x 58)

Protection class

IP20

Article

Description

RM6-24/D

Relay module

RM6H-24/D

Relay module with manual switches

Frost protection unit When there is frost risk, FV1/D has a 0...10 V DC control output that can be used to override the valve. Technical data Supply voltage

24 V AC

Power consumption

2 VA

Setpoint

0...15°C

P-band, control signal override

5 K (fixed)

Inputs Sensor inputs

One, 0...30°C (NTC sensor)

Control signal

0...10 V DC (from the controller)

Outputs Relays

24 V AC, 1 A, change-over and 230 V AC, 1 A, breaking

Output signal

0...10 V DC

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

FV1/D

Frost protection unit (delivered without a sensor)

179

10

AC C E S S O R I E S

Signal converter Signal converter which selects the highest and lowest signal of up to six connected inputs and transforms them into two separate max. and min. output signals. If fewer than six inputs are used, unused inputs are left open. Both outputs can be used simultaneously. No settings are necessary. Technical data Supply voltage

24 V AC, 3 VA

Input signal

Six, 0...10 V DC

Output signal

One max. signal 0...10 V DC and one min. signal 0...10 V DC

Accuracy

±3 % of the input signal

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

MM6-24/D

Signal converter

Transient protection for RS485 (EXOline) and hlEXOline DIN-rail mounting. Article

Description

Number of modules

X1804

Transient protection

2.7

Transient protection for telephone lines DIN-rail mounting. Article

Description

Number of modules

X4106

Transient protection

1

Relay module Coupling module which serves as electrical separation between controller and load. Equipped with screw-type terminal blocks (lift system) providing an easy and rapid wiring. The module has manual control function, LED indication and integral protective circuit. Technical data

180

Nominal voltage UN

24 V AC/DC

Output

One change-over (SPDT)

Max. switching voltage

250 V AC/DC

Max. making current

8A

Continuous current

6A

Ambient temperature

-20...+55°C

Dimensions (WxHxL)

11.2 x 60 x 60 mm

Article

Description

KR24-1W-S

Relay module, 1 relay, on/off/auto switch

AC C E S S O R I E S

Relay modules Relay modules with potential-free high load change-over . The modules operate with a voltage of 24 V AC, 24 V DC or 230 V AC. KRDC24-2WAU and KRAC24-2WAU are especially suitable for use with microsensors. All three relay modules have secure isolation according to DIN VDE 0106-101 and DIN VDE 0160. Technical data Output voltage

250 V AC

Nominal current

8A

Ambient temperature

-40...+70°C

Mounting

On DIN-rail 35 mm

Number of modules

1

Dimensions (WxHxD)

15.6 x 61 x 75 mm

Protection class

IP20

Change-over relays

2

Article

Description

Supply voltage

LED

KRDC24-2WAU

Relay module, suitable for DDC technology

24 V DC

X

KRAC24-2WAU

Relay module, suitable for DDC technology

24 V AC

X

KRAC230-2W

Relay module

230 V AC

X

10

181

AC C E S S O R I E S

Power supply unit 230 V AC / 24 V DC, stabilised.

182

Article

Max. current

Mounting

Number of modules

X1111

0.6 A

DIN-rail or

1.3

X1312

2.1 A

DIN-rail

2.3

X1314

4.2 A

DIN-rail

2.9

AC C E S S O R I E S

Transformers Transformer, 15 VA With built-in thermal overload-limiting device. Technical data Supply voltage

230 V AC

Output voltage

24 V AC

Max. load

15 VA

Mounting

DIN-rail

Number of modules

3

Protection class

IP20

Article

Description

TRAFO15/D

Transformer

Transformer, 40 VA With built-in PTC fuse. Overload and short-circuit proof. Technical data Supply voltage

230 V AC

Output voltage

12 V AC and 24 V AC

Max. load

40 VA

Dimensions (WxHxD)

71 x 85 x 63 mm

Mounting

DIN-rail

Number of modules

4

Protection class

IP20

Article

Description

TRAFO40N/D

Transformer

Transformer, 60 VA With replaceable fuses on both poles of the secondary side. Protection class IP44. Technical data Supply voltage

230 V AC

Output voltage

24 V AC

Max. load

60 VA

Dimensions (WxHxD)

73 x 124 x 61 mm

Mounting

Wall

Protection class

IP44

Article

Description

TRAFO60

Transformer

183

10

AC C E S S O R I E S

Transformer, 75 VA With replaceable fuses on both poles of the secondary side. Delivered with pre-installed wire and plug. Technical data

184

Supply voltage

230 V AC

Output voltage

24 V AC

Max. load

75 VA

Dimensions (WxHxD)

81 x 110 x 80 mm

Mounting

Wall

Protection class

IP23

Article

Description

TRAFO75S

Transformer with pre-installed wire and plug

AC C E S S O R I E S

Push-button Push-button for extended running of air handling units and similar systems. PB can be closing/breaking or have spring return. Technical data Current rating

16 A

Voltage rating

230 V

Mounting

Flush mounting

Protection class

IP20

Article

Description

PB

Push-button for flush-mounting

Push-button with indicator bulb Push-button for extended running of air handling units and similar systems. Pressing PBI results in an instantaneous change-over (closed ), which will activate extended running for the connected system. The push-button has a light bulb which, if desired, can be connected to the system for run indication. Bulbs for 230 V AC and 24 V AC are supplied. Technical data Current rating

16 A

Voltage rating

230 V

Mounting

Flush mounting

Protection class

IP20

Article

Description

PBI

Push-button with indicator bulb for flush mounting

Timer with alternating relay Timer for wall-mounting, activated when pressed. The connection time can be set to 15 min, 30 min, 1 h, 2 h, 4 h and 8 h. The timer is switched off when the set time has expired, or when the timer is pressed during the connection period. Technical data Voltage range

230 V AC

Effect

Alternating voltage: Max. 2300 VA (resistive). Fluorescent tube load: Max. 360 VA.

Connection

Potential-free relay output

Main fuse

Max. 10 A

Connection time

15 min, 30 min, 1 h, 2 h, 4 h, 8 h

Protection class

IP20

Installation

CEE60

Article

Description

TIM480

Timer with alternating relay

185

10

AC C E S S O R I E S

Plastic casing Plastic casings with transparent lid for DIN-rail mounting. Protection class IP65. Article

Description

Width

Number of modules

EK54

Casing IP65

54 mm

3

EK108

Casing IP65

108 mm

6

EK216

Casing IP65

216 mm

12

EK324

Casing IP65

324 mm

18

EK432

Casing IP65

432 mm

24

Front mounting kit For front mounting of controllers and displays as well as other Regin products intended for DIN-rail mounting. Including DIN-rail, nuts and bolts. Room for four small or two large Regin products (12 modules). Technical data Protection class

IP55

Article

Description

FMK2

Front mounting kit

Front mounting kit for EXOcompact, Corrigo and Optigo Mounting kit for easier mounting of EXOcompact, Corrigo and Optigo in a control or cabinet door. Technical data Protection class Article

IP40 Description

FMCE

Front mounting kit, room for one EXOcompact/Corrigo unit

FMCO

Front mounting kit, room for one Optigo unit

Plug-in terminal blocks for EXOcompact, Corrigo and Optigo A set of angled plug-in terminal blocks for simple wiring of EXOcompact, Corrigo and Optigo when using the front mounting kits FMCE and FMCO. The terminal blocks enable easy access to the clamping screws even after cabinet mounting. Article

Description

PLTCE

Plug-in terminal blocks for EXOcompact/Optigo/Corrigo

Cooling spray For control of frost protection. Cools down to -50°C.

186

Article

Description

CS-260

Cooling spray, 200 ml

11 VA LV E S

VALVES

+7°C 11

+21°C

187

VA LV E S

Compatibility table

P

Recommended choice

w

Other possible alternative

Valve

Type

Nominal diameter

Kvs

Stroke

RTV

2-way

DN10-15

1.7 mm

VHR

2-way

DN25

1.7 mm

FVR

2-way

DN10-20

1.7 mm

CTV

2-way

DN10-20

3.5 mm

VTTV

2-way

DN15-20 DN20

4.0 - 6.0

2.5 mm

VTTR

3-way

DN15-20

0.25 - 2.5

2.5 mm

DN20

4.0 - 6.0

2.5 mm

VTTB

3-way with by

DN15-20

0.25 - 2.5

2.5 mm

DN20

4.0 - 6.0

2.5 mm

Male threaded valves 0.25 - 2.5

2.5 mm

ZTV

2-way

DN15-25

5.5 mm

ZTR

3-way

DN15-25

5.5 mm

ETVS

2-way

DN15-50

20 mm

ETRS

3-way

DN15-50

20 mm

MVFL...T

2 and 3-way

DN15-40

0.16 - 25

5.5 mm

Female threaded valves PCTVS

2-way

DN15-20

2.7 mm

PCTV

2-way

DN15-25

2.7 mm

PCMTV

2-way

DN15-25

2.7 mm

PCMTV

2-way

DN25-32

6 mm

ZTVB

2-way

DN25-40

5 mm

ZTRB

3-way

DN25-40

5 mm

BTV

2-way

DN15-50

20 mm

MTVS

2-way

DN15-50

20 mm

MTRS

3-way

DN15-50

20 mm

2 and 3-way

DN32-40

20 mm

DN50-100

20-36 mm

DN125-150

40 mm

DN15-50

20 mm

DN65-80

20 mm

DN100

38 mm

DN125-150

40 mm

Flanged valves GTVS/GTRS

NTVS

FRS

MVFL...F

188

2-way

2-way

2 and 3-way

DN15-25

20 mm

DN32-65

0.6 - 6.3

20 mm

DN32-65

10 - 20

20 mm

DN15-40

0.16 - 25

5.5 mm

VA LV E S

RTAN

RTA(O)M

RVAZ4

RTAN...

RTAN140...

RTAM…

RTAM125.. RTAOM…

RTAOM125...

100 N

140 N

100 N

125 N

125 N

P

P

w

P

w

P

w

P

w

w

P w

P w

P

w

400 N

VA-748X

RVAN

VA-748X

RVAN5... RVAN10... RVAN18... RVAN25...

120 N

500 N

1000 N

1800 N

2500 N

P P P

w

P

RVAZ4...

P w

P P

100 N

RVAZ4L1

P P P P

w

P

w

P

P

w

P

P

w

P

P

w

P

P

w

11

P P P P

w

P

w

P

w

w

P P

w P

P

w P P

w P

P

w

P

w P

P

189

VA LV E S

Zone valves 2-way zone valve, DN10-15 Valves for control in aftertreatment systems. The valve can control water flow to cooling as well as heating batteries and is intended to be used together with the RTA(O)M thermal actuators. Technical data Pressure rating

PN10

Connection, actuator

M28 x 1.5

Leakage

0 % in closed position

Media temperature

5...100°C

Stroke

1.7 mm

Max. diff. pressure

250 kPa

Material Body

Chromed brass CW614N

Seat

Brass CW614N

Stem

Stainless steel 1.4305

O-rings

EPDM

Bonnet

Brass CW614N

Seat packing

NBR

Article

Nominal diameter

Connection, female thread

Connection, male thread

Kvs

Actuator

RTV10

DN10

G3/8” (inlet)

M22 x 1.5 (outlet)

1.2

RTA(O)M

RTV15

DN15

G1/2” (inlet)

M26 x 1.5 (outlet)

1.4

RTA(O)M

2-way valve, DN25 Intended to be used together with the RTA(O)M thermal actuators. Technical data Pressure rating

PN10

Connection, actuator

M28 x 1.5

Leakage

0 % in closed position

Media temperature

5...100°C

Stroke

1.7 mm

Kvs

4.8

Max. diff. pressure

50 kPa

Material

190

Body

Brass

Seat

Brass

Stem

Stainless steel

Packing box

EPDM

Bonnet

Brass

Article

Nominal diameter

Connection, female thread

Connection, male thread

Actuator

VHR25

DN25

G1” (inlet)

M40 x 2.0 (outlet)

RTA(O)M

VA LV E S

2-way zone valve, DN10-20 Valve intended to be used together with the RTA(O)M thermal actuators. Adjustable kvs-value. Technical data Pressure rating

PN10

Connection, actuator

M28 x 1.5

Leakage

0 % in closed position

Media temperature

2...90°C

Stroke

1.7 mm

Material Body

Brass

Seat

Brass

Stem

Stainless steel

Packing box

EPDM

Bonnet

Brass

Article

Nominal diameter

Connection, female thread

Connection, male thread

Kvs (adjustable)

Max. diff. pressure

Actuator

FVR10

DN10

G3/8” (inlet)

M22 x 1.5 (outlet)

0.01...0.9

50 kPa

RTA(O)M

FVR15

DN15

G1/2’’ (inlet)

M26 x 1.5 (outlet)

0.01...0.9

150 kPa

RTA(O)M

FVR20

DN20

G3/4’’ (inlet)

M34 x 1.5 (outlet)

0.01...1.1

150 kPa

RTA(O)M

2-way zone valve, DN10-20 The CTV valve range is intended to be used together with the RTA(O)M thermal actuators for temperature control in heating and cooling systems, such as radiators, convectors, chilled ceilings etc. The valves are supplied with a grey plastic cap which can be used to open/close the valve manually during system installation. Turning the plastic cap clockwise to its end position closes the valve. Adjustable kvs-value.

11

Technical data Pressure rating

PN10

Connection, actuator

M28 x 1.5

Leakage

0 % in closed position

Media temperature

2...90°C

Stroke

3.5 mm

Max. diff. pressure

150 kPa

Material Body

Chromed brass CW614N

Seat

Brass CW614N

Stem

Stainless steel 1.4305

O-rings

EPDM

Bonnet

Brass CW614N

Seat packing

NBR

Article

Nominal diameter

Connection, male thread

Kvs (adjustable)

Actuator

CTV10

DN10

G1/2”

0.12...1.14

RTA(O)M

CTV15-1,9

DN15

G3/4”

0.17...1.9

RTA(O)M

CTV20

DN20

G1”

0.15...1.55

RTA(O)M

191

VA LV E S

2-, 3-way and 3-way (by) zone valves Valves for control of heating and cooling in fan-coil or chilled beams applications. The valves are intended to be used together with the thermal RTAN and RTAOM actuators. Technical data Pressure rating

PN16 (1.6 MPa)

Connection

Male threaded according to ISO 228/1

Flow characteristics

Linear

Leakage

0 % in closed position

Media temperature

2...95°C

Media

Hot or cold water. Also refrigerants (max. 40 % glycol).

Stroke

2.5 mm

Adapter

Included for RTAOM... actuators

Material Body

Brass

Seat

PPO+GP

O-rings

FKM

2-way Article

Connection

Kvs

Max. diff. pressure

Actuator

VTTV15-0,25

G1/2”

0.25

250 kPa

RTAN, RTAOM

VTTV15-0,4

G1/2”

0.4

250 kPa

RTAN, RTAOM

VTTV15-0,6

G1/2”

0.6

250 kPa

RTAN, RTAOM

VTTV15-1,0

G1/2”

1

250 kPa

RTAN, RTAOM

VTTV15-1,6

G1/2”

1.6

250 kPa

RTAN, RTAOM

VTTV20-2,5

G3/4”

2.5

250 kPa

RTAN, RTAOM

VTTV20-4,0

G3/4”

4

100 kPa

RTAN140, RTAOM125

VTTV20-6,0

G3/4”

6

100 kPa

RTAN140, RTAOM125

3-way Article

VTTR15-0,25

Connection

G1/2”

Kvs, A-AB

Kvs, B-AB

0.25

0.25

Max. diff. pressure Mixing valves

Diverting valves

250 kPa

83 kPa

Actuator

RTAN, RTAOM

VTTR15-0,4

G1/2”

0.4

0.4

250 kPa

83 kPa

RTAN, RTAOM

VTTR15-0,6

G1/2”

0.6

0.6

250 kPa

83 kPa

RTAN, RTAOM

VTTR15-1,0

G1/2”

1

0.8

250 kPa

83 kPa

RTAN, RTAOM

VTTR15-1,6

G1/2”

1.6

1

250 kPa

83 kPa

RTAN, RTAOM

VTTR20-2,5

G3/4”

2.5

1.6

250 kPa

83 kPa

RTAN, RTAOM

VTTR20-4,0

G3/4”

4

2.5

100 kPa

33 kPa

RTAN140, RTAOM125

VTTR20-6,0

G3/4”

6

4

100 kPa

33 kPa

RTAN140, RTAOM125

3-way with by

192

Article

Connection

Kvs, A-AB

Kvs, B-AB

Max. diff. pressure

Actuator

Mixing valves

Diverting valves

VTTB15-0,25

G1/2”

0.25

0.25

250 kPa

83 kPa

RTAN, RTAOM

VTTB15-0,4

G1/2”

0.4

0.4

250 kPa

83 kPa

RTAN, RTAOM

VTTB15-0,6

G1/2”

0.6

0.6

250 kPa

83 kPa

RTAN, RTAOM

VTTB15-1,0

G1/2”

1

0.8

250 kPa

83 kPa

RTAN, RTAOM

VTTB15-1,6

G1/2”

1.6

1

250 kPa

83 kPa

RTAN, RTAOM

VTTB20-2,5

G3/4”

2.5

1.6

250 kPa

83 kPa

RTAN, RTAOM

VTTB20-4,0

G3/4”

4

2.5

100 kPa

33 kPa

RTAN140, RTAOM125

VTTB20-6,0

G3/4”

6

4

100 kPa

33 kPa

RTAN140, RTAOM125

VA LV E S

Accessories for zone valves Valve connections, outlet (FVR, RTV och VHR) Article

Description

Connection

Valve

4161201

Tail and nut, for valve outlet (external metric thread on the valve)

3/8’’ (M22 x 1.5)

RTV10, FVR10

1/2’’ (M26 x 1.5)

RTV15, FVR15

4161202 4161203

3/4’’ (M34 x 1.5)

FVR20

4161204

1” (M40 x 2)

VHR25

Connection

Valve

Article

Description

4161841

Nut and olive, for valve outlet (external metric thread on the valve)

4160801

3/8’’ (M22 x 1.5), K12

RTV10, FVR10

1/2” (M26 x 1.5), K15

RTV15, FVR15

Connection for inlet (FVR, RTV) Article

Description

Connection

Valve

4161402

Nut and olive, for valve inlet (internal pipe thread on the valve)

3/8’, K10

RTV10, FVR10

3/8’, K12

RTV10, FVR10

4161403 4161101

1/2”, K10

RTV15, FVR15

4161102

1/2”, K12

RTV15, FVR15

4161103

1/2”, K15

RTV15, FVR15

Pre-set tooling for FVR Article

Description

FV5

Pre-set tooling, key and scale (FVR valves)

FN2

Pre-set tooling, basic key (FVR valves)

Valve connections Apply to CTV, ZTV, ZTR, VTTV, VTTR and VTTB. Article

Description

Connection

Valve

1885136

Nut and olive

1/2”, K12

CTV10, ZTV15, ZTR15, VTTV15, VTTR15, VTTB

1886274

3/4”, K15

CTV15, ZTV20 (kvs 2.0-2.5), ZTR (kvs 2.0-2.5), VTTV20 (kvs 2.5), VTTR20 (kvs 2.5), VTTB20 (kvs 2.5)

1884709

3/4”, K18

CTV15, ZTV20, ZTR20, VTTV20, VTTR20, VTTB20

1886282

1”, K22

CTV20, ZTV25, ZTR25

193

11

VA LV E S

Valve with actuator The DFCM fan-coil valves are intended for on/off control of hot or cold water in heating and cooling systems. The actuator has a synchronous motor and is equipped with a spring return mechanism. Detachable actuator with spring return. Technical data Pressure rating

PN16

Supply voltage

230 V AC

Control signal

On/off

Opening time

Approx. 15 s

Closing time, spring

4...5 s

Media temperature

2...94°C

Connection

BSP female threaded according to ISO 228/1

Body material, valve

Brass

Material, housing (actuator)

Plastic (EFCM, steel)

Protection class

IP44

2-way Article

Nominal diameter

Kvs

Max. diff. pressure

DFCM-215X

DN15

3.2

200 kPa

DFCM-220X

DN20

4.6

150 kPa

DFCM-225X

DN25

5.7

100 kPa

DFCM-232X

DN32

10

80 kPa

Nominal diameter

Kvs

Max. diff. pressure

3-way Article

194

DFCM-315X

DN15

3.2

150 kPa

DFCM-320X

DN20

4.6

100 kPa

DFCM-325X

DN25

5.7

100 kPa

DFCM-332X

DN32

8.4

80 kPa

VA LV E S

Male threaded valves 2- and 3-way zone valves Valves for control of heating and cooling in climate, heating and ventilation systems. Intended to be used together with the RVAZ4 actuators. Technical data Pressure rating

PN16

Connection, actuator

M30 x 1.5

Connection

Male threaded according to ISO 228/1

Flow characteristics

Equal percentage

Leakage

0 % in closed position

Media temperature

1...110°C

Media

Hot or cold water. Also refrigerants (max. 30 % glycol).

Rangeability

50:1

Stroke

5.5 mm

Material Body

Brass CW614N

Seat

Brass CW614N

Plug

Brass CW614N

Stem

Stainless steel 1.4305

Seat packing

EPDM

O-rings

EPDM

2-way Article

Nominal diameter

Connection

Kvs

Max. diff. pressure

Actuator

ZTV15-0,25

DN15

G1/2”

0.25

350 kPa

RVAZ4

ZTV15-0,4

DN15

G1/2”

0.4

350 kPa

RVAZ4

ZTV15-0,6

DN15

G1/2”

0.6

350 kPa

RVAZ4

ZTV15-1,0

DN15

G1/2”

1.0

350 kPa

RVAZ4

ZTV15-1,6

DN15

G1/2”

1.6

350 kPa

RVAZ4

ZTV20-2,0

DN20

G3/4”

2.0

250 kPa

RVAZ4

ZTV20-2,5

DN20

G3/4”

2.5

250 kPa

RVAZ4

ZTV20-4,0

DN20

G3/4”

4.0

150 kPa

RVAZ4

ZTV20-6,0

DN20

G3/4”

6.0

150 kPa

RVAZ4

ZTV25-7,0

DN25

G1”

7.0

70 kPa

RVAZ4

Article

Nominal diameter

Connection

Kvs

Max. diff. pressure

Actuator

ZTR15-0,25

DN15

G1/2”

0.25

350 kPa

RVAZ4

ZTR15-0,4

DN15

G1/2”

0.4

350 kPa

RVAZ4

ZTR15-0,6

DN15

G1/2”

0.6

350 kPa

RVAZ4

ZTR15-1,0

DN15

G1/2”

1.0

350 kPa

RVAZ4

ZTR15-1,6

DN15

G1/2”

1.6

350 kPa

RVAZ4

ZTR20-2,0

DN20

G3/4”

2.0

250 kPa

RVAZ4

ZTR20-2,5

DN20

G3/4”

2.5

250 kPa

RVAZ4

ZTR20-4,0

DN20

G3/4”

4.0

100 kPa

RVAZ4

ZTR20-6,0

DN20

G3/4”

6.0

100 kPa

RVAZ4

ZTR25-7,0

DN25

G1”

7.0

70 kPa

RVAZ4

3-way

195

11

VA LV E S

2-way valve The ETVS valves are designed for control of cold, hot and glycol-mixed water, steam and district heating. They are pressure balanced (from DN20-50, not DN15) and can therefore handle high differential pressure with low force. The valves are intended to be used together with Regin’s RVAN5 actuators. Technical data Pressure rating

PN16

Connection

Male threaded according to ISO 228/1; supplied with threaded connections

Flow characteristics

Equal percentage

Max. leakage

0.0 % of the kvs value (PTFE gasket, carbon-filled 25 %, no leakage)

Media temperature

-5…+150°C

Media

Hot, cold or glycol-mixed water and steam

Rangeability

100:1

Stroke

20 mm

Max. diff. pressure

1600 kPa

Material Body

Gunmetal CC491K (RG5)

Seat

Stainless steel 1.4301

Plug

Stainless steel 1.4305

Stem

Stainless steel 1.4305

Seat packing

PTFE with 25 % carbon

Packing box

Dezincification resistant brass CW 602N, self-adjusting teflon

O-rings

Viton

Material, connections Nut

Malleable cast iron, galvanized

Nipple

Dezincification resistant brass CW 602N

Fitting seal

Novatec 2, Nitrile bonded aramid fibre with graphite

Article

Nominal diameter

Kvs

Actuator

ETVS15-0,63

DN15

0,63

RVAN5

ETVS15-1,25

DN15

1,25

RVAN5

ETVS15-1,6

DN15

1,6

RVAN5

ETVS15-2,5

DN15

2,5

RVAN5

ETVS15-4,0

DN15

4

RVAN5

ETVS20-5,0

DN20

5

RVAN5

ETVS20-6,3

DN20

6,3

RVAN5

ETVS25-8,0

DN25

8

RVAN5

ETVS25-10

DN25

10

RVAN5

ETVS32-12,5

DN32

12,5

RVAN5

ETVS32-16

DN32

16

RVAN5

ETVS40-20

DN40

20

RVAN5

ETVS40-25

DN40

25

RVAN5

ETVS50-31,5

DN50

31,5

RVAN5

ETVS50-40

DN50

40

RVAN5

Accessories

196

Article

Accessories

S0603080300

Spare parts kit, packing box

VA LV E S

3-way control valve The ETRS valves are intended for control of cold, hot and glycol-mixed water in heating, ventilation and domestic hot water systems. The valves are intended to be used together with Regin’s RVAN5 actuators. Valves with DN32-50 may also be used with RVAN10 if a larger actuating force is required. Technical data Pressure rating

PN16

Connection

Male threaded according to ISO 228/1; supplied with threaded connections

Flow characteristics

Equal percentage

Max. leakage

0.1 % of kvs

Media temperature

-5…+185°C

Media

Hot, cold or glycol-mixed water and steam

Rangeability

100:1

Stroke

20 mm

Material Body

Gunmetal CC491K (RG5)

Seat

Gunmetal CC491K (RG5)

Plug

Gunmetal CC491K (RG5)

Stem

Stainless steel 1.4305

Packing box

Dezincification resistant brass CW 602N, self-adjusting teflon

O-rings

Viton

Material, connections Malleable cast iron, galvanized

Nut Nipple

Dezincification resistant brass CW 602N

Fitting seal

Novatec 2, Nitrile bonded aramid fibre with graphite

Article

Nominal diameter

Max. diff. pressure

Kvs

Actuator

ETRS15-0,63

DN15

1600 kPa

0,63

RVAN5

ETRS15-1,25

DN15

1600 kPa

1,25

RVAN5

ETRS15-1,6

DN15

1600 kPa

1,6

RVAN5

ETRS15-2,5

DN15

1600 kPa

2,5

RVAN5

ETRS15-4,0

DN15

1600 kPa

4

RVAN5

ETRS20-5,0

DN20

1600 kPa

5

RVAN5

ETRS20-6,3

DN20

1600 kPa

6,3

RVAN5

ETRS25-8,0

DN25

1000 kPa

8

RVAN5

ETRS25-10

DN25

1000 kPa

10

RVAN5

ETRS32-12,5

DN32

600 kPa

12,5

RVAN5, RVAN10

ETRS32-16

DN32

600 kPa

16

RVAN5, RVAN10

ETRS40-20

DN40

400 kPa

20

RVAN5, RVAN10

ETRS40-25

DN40

400 kPa

25

RVAN5, RVAN10

ETRS50-31,5

DN50

250 kPa

31,5

RVAN5, RVAN10

ETRS50-40

DN50

250 kPa

40

RVAN5, RVAN10

Accessories Article

Accessories

S0603080300

Spare parts kit, packing box

197

11

VA LV E S

Female threaded valves Pressure independent control valve The valve is a combined differential pressure regulator, flow limiter and equal percentage control valve with full stroke and authority. The PC(M)TV valves are suitable for constant or variable temperature systems and can be used as constant flow limiters in constant volume systems (with no actuators), or as proper pressure independent control valves in variable volume systems (with actuators). Technical data Pressure class

25 bar

Flow characteristics

Equal percentage

Media

Hot or cold water, cooling systems (max 50 % glycol)

Leakage

0.01 % of maximum flow, Class IV IEC 60534-4

Temperature range

-10...+120 °C

Material Body

Brass CW602N (CZ121)

Plug parabol

Brass CW614N (CZ132)

Stem

Stainless steel

O-rings

EPDM

Pressure controller

EPDM, stainless steel and high resistance polymer

Models without measuring port connectors Article

Rangeability

Max. diff. pressure

Stroke

Nominal diameter

Connection

Max. startup pressure

Max. flow rate

Actuator

PCTVS15-F600

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G½”

25 kPa

600 l/h

RTAM, VA-748X

PCTVS15-F900

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G½”

30 kPa

900 l/h

RTAM, VA-748X

PCTVS20-F600

50 ~ 100 : 1

400 kPa

2.7 mm

DN20

G¾”

25 kPa

600 l/h

RTAM, VA-748X

PCTVS20-F900

50 ~ 100 : 1

400 kPa

2.7 mm

DN20

G¾”

30 kPa

900 l/h

RTAM, VA-748X

Models with measuring port connectors but no measuring ports

198

Article

Rangeability

Max. diff. pressure

Stroke

Nominal diameter

Connection

Max. startup pressure

Max. flow rate

Actuator

PCTV15-F600

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G1/2”

25 kPa

600 l/h

RTAM, VA-748X

PCTV15-F780

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G1/2”

25 kPa

780 l/h

RTAM, VA-748X

PCTV20-F1000

50 ~ 100 : 1

400 kPa

2.7 mm

DN20

G3/4”

30 kPa

1000 l/h

RTAM, VA-748X

PCTV20-F1500

50 ~ 100 : 1

300 kPa

2.7 mm

DN20

G3/4”

35 kPa

1500 l/h

RTAM, VA-748X

PCTV25-F1500

50 ~ 100 : 1

300 kPa

2.7 mm

DN25

G1”

35 kPa

1500 l/h

RTAM, VA-748X

VA LV E S

Models with measuring ports Article

Rangeability

Max. diff. pressure

Stroke

Nominal diameter

Connection

Max. start-up pressure

Max. flow rate

Actuator

PCMTV15-F600

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G1/2”

25 kPa

600 l/h

RTAM, VA-748X

PCMTV15-F780

50 ~ 100 : 1

400 kPa

2.7 mm

DN15

G1/2”

25 kPa

780 l/h

RTAM, VA-748X

PCMTV20-F1000

50 ~ 100 : 1

400 kPa

2.7 mm

DN20

G3/4”

30 kPa

1000 l/h

RTAM, VA-748X

PCMTV20-F1500

50 ~ 100 : 1

300 kPa

2.7 mm

DN20

G3/4”

35 kPa

1500 l/h

RTAM, VA-748X

PCMTV25-F1500

50 ~ 100 : 1

300 kPa

2.7 mm

DN25

G1”

35 kPa

1500 l/h

RTAM, VA-748X

Models with measuring port connectors Article

Rangeability

Max. diff. pressure

Stroke

Nominal diameter

Connection

Max. startup pressure

Max. flow rate

Actuator

PCMTV25-F2200

100 ~ 150 : 1

400 kPa

6 mm

DN25

Rc1”

25 kPa

2200 l/h

RTAM, VA-748X

PCMTV25-F2700

100 ~ 150 : 1

400 kPa

6 mm

DN25

Rc1”

25 kPa

2700 l/h

RTAM, VA-748X

PCMTV32-F2700

100 ~ 150 : 1

400 kPa

6 mm

DN32

Rc1¼”

25 kPa

2700 l/h

RTAM, VA-748X

PCMTV32-F3000

100 ~ 150 : 1

400 kPa

6 mm

DN32

Rc1¼”

35 kPa

3000 l/h

RTAM, VA-748X

Accessories Article

Description

Actuator

VA64

Adapter for 2.7 or 6 mm stroke (to be ordered separately)

RTAM

OA7010

Adapter for valve with 2.7 mm stroke (to be ordered separately)

VA-7481...,VA-7482-1001

OA748X

Adapter for valve with 6 mm stroke (to be ordered separately)

VA-7481...,VA-7482-1001

199

11

VA LV E S

2- and 3-way zone valves Valves for control of heating and cooling in climate, heating and ventilation systems. The valves are intended to be used together with the RVAZ4 actuators. Technical data Pressure rating

PN16

Connection, actuator

M30 x 1.5

Connection

BSP female threaded according to ISO 228/1

Flow characteristics

Linear

Leakage

0 % in closed position

Media temperature

1...110°C

Rangeability

50:1

Stroke

5 mm

Media

Hot or cold water. Also refrigerants (max. 30 % glycol).

Material Body

Brass CW614N

Seat

Brass CW614N

Plug

Brass CW614N

Stem

Stainless steel 1.4305

Seat packing

EPDM

O-rings

EPDM

2-way Article

Nominal diameter

Connection

Kvs

Max. diff. pressure

Actuator

ZTVB25-8

DN25

G1”

8

250 kPa

RVAZ4

ZTVB32-15

DN32

G1 ¼”

15

250 kPa

RVAZ4

ZTVB40-20

DN40

G1 ½”

20

125 kPa

RVAZ4

Article

Nominal diameter

Connection

Kvs

Max. diff. pressure

Actuator

ZTRB25-8

DN25

G1”

8

250 kPa

RVAZ4

ZTRB32-15

DN32

G1 ¼”

15

250 kPa

RVAZ4

ZTRB40-20

DN40

G1 ½”

20

125 kPa

RVAZ4

3-way

200

VA LV E S

2-way control valves The BTV valves are designed for control of hot, cold or glycol-mixed water in heating and ventilation systems. They are pressure balanced (from DN20-50, not DN15) and can therefore handle high differential pressure with low force. The valves are intended to be used together with Regin’s RVAN5 actuators. They should not be used in domestic hot water systems. Technical data Pressure rating

PN16

Connection

BSP female threaded according to ISO 228/1

Flow characteristics

Equal percentage

Max. leakage

0.0 % of the kvs value (PTFE gasket, carbon-filled 25 %, no leakage)

Max. diff. pressure

1600 kPa

Media temperature

-5...+140°C

Media

Hot, cold or glycol-mixed water (max. 50 % glycol)

Rangeability

100:1

Stroke

20 mm

Material Body

Brass CW614N

Seat

Brass CW614N

Plug

Stainless steel 1.4301

Stem

Stainless steel 1.4305

Seat packing

PTFE with 25 % carbon

O-rings

EPDM

Article

Nominal diameter

Connection

Kvs

Actuator

BTV15-0,6

DN15

G½”

0.6

RVAN5

BTV15-1,0

DN15

G½”

1.0

RVAN5

BTV15-1,6

DN15

G½”

1.6

RVAN5

BTV15-2,5

DN15

G½”

2.5

RVAN5

BTV20-3,9

DN20

G¾”

3.9

RVAN5

BTV25-6,3

DN25

G1”

6.3

RVAN5

BTV25-10

DN25

G1”

10

RVAN5

BTV32-10

DN32

G1¼”

10

RVAN5

BTV32-16

DN32

G1¼”

16

RVAN5

BTV40-16

DN40

G1½”

16

RVAN5

BTV40-27

DN40

G1½”

27

RVAN5

BTV50-27

DN50

G2”

27

RVAN5

BTV50-39

DN50

G2”

39

RVAN5

Accessories Article

Accessories

S02420001

Spare parts kit, O-ring kit for BTV valves from DN15 to DN25

S6321457301

Spare parts kit, packing box

201

11

VA LV E S

2- and 3-way control valves The MTVS and MTRS valves are designed for control of hot, cold or glycol-mixed water or steam in heating and ventilation systems. They also function very well in domestic hot water systems. The valves are intended to be used together with Regin’s RVAN5 actuators. Valves with DN32-50 may also be used with RVAN10 if a larger actuating force is required. Technical data Pressure rating

PN16

Connection

BSP female threaded according to ISO 228/1

Flow characteristics

Equal percentage

Max. leakage

0.1 % of kvs

Media temperature

-5…+185°C

Media

Hot, cold, glycol-mixed (max. 50 %) water or steam

Rangeability

100:1

Stroke

20 mm

Material Body, seat and plug

Gunmetal CC491K (RG5)

Stem

Stainless steel 1.4305

Packing box

Dezincification resistant brass CW 602N, self-adjusting teflon

O-rings

Viton

2-way Article

Nominal diameter

Connection

Max. diff. pressure

Kvs

Actuator

MTVS15-0,63

DN15

G½”

1600 kPa

0.63

RVAN5

MTVS15-1,0

DN15

G½”

1600 kPa

1.0

RVAN5

MTVS15-1,6

DN15

G½”

1600 kPa

1.6

RVAN5

MTVS15-2,1

DN15

G½”

1600 kPa

2.1

RVAN5

MTVS15-2,7

DN15

G½”

1600 kPa

2.7

RVAN5

MTVS20-4,2

DN20

G¾”

1600 kPa

4.2

RVAN5

MTVS20-5,6

DN20

G¾”

1600 kPa

5.6

RVAN5

MTVS25-10

DN25

G1”

1000 kPa

10

RVAN5

MTVS32-16

DN32

G1¼”

600 kPa

16

RVAN5, RVAN10

MTVS40-27

DN40

G1½”

400 kPa

27

RVAN5, RVAN10

MTVS50-39

DN50

G2”

250 kPa

39

RVAN5, RVAN10

3-way Article

Nominal diameter

Connection

Max. diff. pressure

Kvs

MTRS15-0,63

DN15

G½”

1600 kPa

0.63

RVAN5

MTRS15-1,0

DN15

G½”

1600 kPa

1.0

RVAN5

MTRS15-1,6

DN15

G½”

1600 kPa

1.6

RVAN5

MTRS15-2,1

DN15

G½”

1600 kPa

2.1

RVAN5

MTRS15-2,7

DN15

G½”

1600 kPa

2.7

RVAN5

MTRS20-4,2

DN20

G¾”

1600 kPa

4.2

RVAN5

MTRS20-5,6

DN20

G¾”

1600 kPa

5.6

RVAN5

MTRS25-10

DN25

G1”

1000 kPa

10

RVAN5

MTRS32-16

DN32

G1¼”

600 kPa

16

RVAN5, RVAN10

MTRS40-27

DN40

G1½”

400 kPa

27

RVAN5, RVAN10

MTRS50-39

DN50

G2”

250 kPa

39

RVAN5, RVAN10

Accessories

202

Article

Accessories

S0603080300

Spare parts kit, packing box

Actuator

VA LV E S

Flanged valves Flanged 2- and 3-way valves Control valves intended for use in heating and ventilation systems, suitable for cold and hot water, glycolmixed water or steam. The valves are intended to be used together with Regin’s RVAN actuators. Technical data Pressure rating

PN16

Connection

Flanged according to EN 1092-2

Flow characteristics

Square

Max. leakage

0.1 % of kvs

Media temperature

-5…+120°C

Media

Hot, cold, glycol-mixed water

Rangeability

50:1

Material Body

Cast iron EN-JL 1040

Seat and plug

Gunmetal CC491K (RG5)

Stem

Stainless steel 1.4305

Packing box

Dezincification resistant brass CW 602N, self-adjusting teflon

O-rings

Viton

Bonnet

Brass CW614N

2-way Article

Nominal diameter

Kvs

Max. diff. pressure

Stroke

Actuator

GTVS32-16

DN32

16

1300 kPa

20 mm

RVAN10

GTVS40-27

DN40

27

800 kPa

20 mm

RVAN10

GTVS50-39

DN50

39

1000 kPa

37 mm

RVAN18

GTVS65-63

DN65

63

600 kPa

24 mm

RVAN18

GTVS80-100

DN80

100

400 kPa

36 mm

RVAN18

GTVS100-160

DN100

160

250 kPa

36 mm

RVAN18

GTVS125-215

DN125

215

170 kPa

40 mm

RVAN25

GTVS150-310

DN150

310

120 kPa

40 mm

RVAN25

3-way Article

Nominal diameter

Kvs

Max. diff. pressure

Stroke

Actuator

GTRS32-16

DN32

16

1300 kPa

20 mm

RVAN10

GTRS40-27

DN40

27

800 kPa

20 mm

RVAN10

GTRS50-39

DN50

39

1000 kPa

37 mm

RVAN18

GTRS65-63

DN65

63

600 kPa

24 mm

RVAN18

GTRS80-100

DN80

100

400 kPa

36 mm

RVAN18

GTRS100-160

DN100

160

250 kPa

36 mm

RVAN18

GTRS125-215

DN125

215

170 kPa

40 mm

RVAN25

GTRS150-310

DN150

310

120 kPa

40 mm

RVAN25

The valves are available in other materials with temperature range up to 185°C on request.

Accessories Article

Accessories

S0603080300

Spare parts kit, packing box

203

11

VA LV E S

2-way DIN-standard valve The NTVS series is intended for control of hot and cold water, glycol-mixed water, steam and district heating. The valves from DN20 to DN150 are pressure balanced, which means that they can handle higher differential pressure with lower actuator force. For steam applications or at pressure drops of 7 bar or higher, we recommend using a metal packing (stainless steel). Use the extra letter M at the end of the reference type when ordering a valve with metal packing, for example NTVS50-27M instead of the usual NTVS50-27. For valves with metal packing, the maximum leakage is 0.05 % of kvs. The NTVS valves meet the requirements of DIN-standard DIN 3202/F1 and ISO 5752 table 1. The valves are intended to be used together with Regin’s RVAN actuators. Technical data Pressure rating

PN16

Connection

Flanges according to SS 335 table 6

Flow characteristics

Equal percentage

Max. leakage

0.0 % of the kvs value (PTFE gasket, carbon-filled 25 %, no leakage) / 0.05 % of kvs for NTVS...-...M models with metal packing

Media temperature

-5...+185°C

Media

Hot, cold, glycol-mixed water or steam

Rangeability

100:1

Max. diff. pressure

1600 kPa

Material

204

Body

Nodular cast iron (GJS) EN-JS1050

Seat

Stainless steel 1.4301 or gunmetal CC491K (RG5)

Plug

Stainless steel 1.4305 or gunmetal CC491K (RG5)

Stem

Stainless steel 1.4305

Lining

Stainless steel 1.4301

Seat packing, soft seal

PTFE with 25 % carbon

Seat packing, metal seal

Stainless steel 1.4057

Packing box

Dezincification resistant brass CW 602N, self-adjusting teflon

O-rings

Viton

VA LV E S

Article

Nominal diameter

Kvs

Stroke

Actuator

NTVS15-0,4

DN15

0.4

20 mm

RVAN5

NTVS15-1,0

DN15

1.0

20 mm

RVAN5

NTVS15-1,6

DN15

1.6

20 mm

RVAN5

NTVS15-2,7

DN15

2.7

20 mm

RVAN5

NTVS20-0,8

DN20

0.8

20 mm

RVAN5

NTVS20-1,6

DN20

1.6

20 mm

RVAN5

NTVS20-2,7

DN20

2.7

20 mm

RVAN5

NTVS20-3,9

DN20

3.9

20 mm

RVAN5

NTVS20-6,3

DN20

6.3

20 mm

RVAN5

NTVS25-1,6

DN25

1.6

20 mm

RVAN5

NTVS25-2,5

DN25

2.5

20 mm

RVAN5

NTVS25-4,0

DN25

4

20 mm

RVAN5 RVAN5

NTVS25-6,3

DN25

6.3

20 mm

NTVS25-10

DN25

10

20 mm

RVAN5

NTVS32-4,0

DN32

4

20 mm

RVAN5

NTVS32-6,3

DN32

6.3

20 mm

RVAN5

NTVS32-10

DN32

10

20 mm

RVAN5

NTVS32-16

DN32

16

20 mm

RVAN5

NTVS40-6,3

DN40

6.3

20 mm

RVAN5

NTVS40-10

DN40

10

20 mm

RVAN5

NTVS40-16

DN40

16

20 mm

RVAN5

NTVS40-27

DN40

27

20 mm

RVAN5

NTVS50-6,3

DN50

6.3

20 mm

RVAN5

NTVS50-10

DN50

10

20 mm

RVAN5

NTVS50-16

DN50

16

20 mm

RVAN5

NTVS50-27

DN50

27

20 mm

RVAN5

NTVS50-39

DN50

39

20 mm

RVAN5

NTVS65-16

DN65

16

20 mm

RVAN10

NTVS65-27

DN65

27

20 mm

RVAN10

NTVS65-39

DN65

39

20 mm

RVAN10

NTVS65-63

DN65

63

20 mm

RVAN10

NTVS80-100

DN80

100

20 mm

RVAN10

NTVS100-160

DN100

160

38 mm

RVAN18

NTVS125-215

DN125

215

40 mm

RVAN25

NTVS150-310

DN150

310

40 mm

RVAN25

Accessories Article

Accessories

S0603080300

Spare parts kit, packing box

205

11

VA LV E S

Flanged 2-way district heating valve Flanged valves for heating, district heating and air handling systems. The valves are intended for use together with Regin’s RVAN actuators. Adapters are also available for adaptation to actuators of other brands. The valves are mainly intended for district heating and were primarily developed to replace the TAC valve STL. Technical data Pressure rating

PN16

Connection

Flanges according to ISO 7005-2

Flow characteristics

Equal percentage

Max. leakage

0.0 % of the kvs value (PTFE gasket, carbon-filled 25 %, no leakage)

Media temperature

-5...+150°C

Media

Hot, cold, glycol-mixed water or steam

Rangeability

100:1

Stroke

20 mm

Max. diff. pressure

1600 kPa

Material

206

Body

Gunmetal CC491K (RG5)

Seat

Stainless steel 1.4305

Plug

Stainless steel 1.4305

Stem

Stainless steel 1.4305

Seat packing

PTFE with 25 % carbon

Packing box

Dezincification resistant brass CW 602N

O-rings

Viton

Flanges

Epoxy-coated steel

VA LV E S

Article

Nominal diameter

Kvs

Actuator

FRS15-0,6

DN15

0.6

RVAN5

FRS15-1,0

DN15

1.0

RVAN5

FRS15-1,6

DN15

1.6

RVAN5

FRS15-2,5

DN15

2.5

RVAN5

FRS20-0,6

DN20

0.6

RVAN5

FRS20-1,0

DN20

1.0

RVAN5

FRS20-2,5

DN20

2.5

RVAN5

FRS20-1,6

DN20

1.6

RVAN5

FRS20-4,0

DN20

4.0

RVAN5

FRS25-0,6

DN25

0.6

RVAN5

FRS25-1,0

DN25

1.0

RVAN5

FRS25-1,6

DN25

1.6

RVAN5

FRS25-2,5

DN25

2.5

RVAN5

FRS25-4,0

DN25

4.0

RVAN5

FRS32-0,6

DN32

0.6

RVAN5

FRS32-1,0

DN32

1.0

RVAN5

FRS32-1,6

DN32

1.6

RVAN5

FRS32-2,5

DN32

2.5

RVAN5

FRS32-4,0

DN32

4.0

RVAN5

FRS32-6,3

DN32

6.3

RVAN5

FRS32-10

DN32

10

RVAN18

FRS32-16

DN32

16

RVAN18

FRS40-0,6

DN40

0.6

RVAN5

FRS40-1,0

DN40

1.0

RVAN5

FRS40-1,6

DN40

1.6

RVAN5

FRS40-2,5

DN40

2.5

RVAN5

FRS40-4,0

DN40

4.0

RVAN5

FRS40-6,3

DN40

6.3

RVAN5

FRS40-10

DN40

10

RVAN18

FRS40-16

DN40

16

RVAN18

FRS40-20

DN40

20

RVAN18

FRS50-2,7

DN50

2,7

RVAN5

FRS50-6,3

DN50

6.3

RVAN5

FRS50-10

DN50

10

RVAN18

FRS50-16

DN50

16

RVAN18

FRS50-20

DN50

20

RVAN18

FRS65-2,7

DN65

2,7

RVAN5

FRS65-6,3

DN65

6.3

RVAN5

FRS65-10

DN65

10

RVAN18

FRS65-16

DN65

16

RVAN18

FRS65-20

DN65

20

RVAN18

Accessories Article

Accessories

S6321457301

Spare parts kit, packing box

207

11

VA LV E S

MVFL valves Control valves of compact construction with different coupling connection. The valves are intended to be used together with the RVAZ4L1 actuators (adapter kit included in the valve packaging). Technical data Pressure rating

PN16

Connection

External threads or flange

Flow characteristics

Linear

Max. leakage

< 0.0005 % of kvs

Media temperature

2…150°C

Media

Hot or cold water

Rangeability

50:1

Stroke

5.5 mm

Material Body

Cast iron EN-JL 1030

Plug

Stainless steel 1.4021

Seat packing

EPDM

O-rings

EPDM

2-way, thread Article

Nominal diameter

Kvs

kPa

MVFL215/8T

DN15

0.16

400

MVFL215/7T

DN15

0.25

400

MVFL215/6T

DN15

0.4

400

MVFL215/5T

DN15

0.63

400

MVFL215/4T

DN15

1

400

MVFL215/3T

DN15

1.6

400

MVFL215/2T

DN15

2.5

400

MVFL215/1T

DN15

4

400

MVFL220/T

DN20

6.3

350

MVFL225/T

DN25

10

200

MVFL232/T

DN32

16

110

MVFL240/T

DN40

25

60

Nominal diameter

Kvs

kPa

2-way, welded unions Article

208

MVFL215/8W

DN15

0.16

400

MVFL215/7W

DN15

0.25

400

MVFL215/6W

DN15

0.4

400

MVFL215/5W

DN15

0.63

400

MVFL215/4W

DN15

1

400

MVFL215/3W

DN15

1.6

400

MVFL215/2W

DN15

2.5

400

MVFL215/1W

DN15

4

400

MVFL220/W

DN20

6.3

350

MVFL225/W

DN25

10

200

MVFL232/W

DN32

16

110

MVFL240/W

DN40

25

60

VA LV E S

2-way, flange Article

Nominal diameter

Kvs

kPa

MVFL215/8F

DN15

0.16

400

MVFL215/7F

DN15

0.25

400

MVFL215/6F

DN15

0.4

400

MVFL215/5F

DN15

0.63

400

MVFL215/4F

DN15

1

400

MVFL215/3F

DN15

1.6

400

MVFL215/2F

DN15

2.5

400

MVFL215/1F

DN15

4

400

MVFL220/F

DN20

6.3

350

MVFL225/F

DN25

10

200

MVFL232/F

DN32

16

110

MVFL240/F

DN40

25

60

3-way, thread Article

Nominal diameter

Kvs

kPa

MVFL315/7T

DN15

0.25

400

MVFL315/6T

DN15

0.4

400

MVFL315/5T

DN15

0.63

400

MVFL315/4T

DN15

1

400

MVFL315/3T

DN15

1.6

400

MVFL315/2T

DN15

2.5

400

MVFL315/1T

DN15

4

400

MVFL320/T

DN20

6.3

350

MVFL325/T

DN25

10

200

MVFL332/T

DN32

16

110

MVFL340/T

DN40

25

60

3-way, welded unions Article

Nominal diameter

Kvs

kPa

MVFL315/7W

DN15

0.25

400

MVFL315/6W

DN15

0.4

400

MVFL315/5W

DN15

0.63

400

MVFL315/4W

DN15

1

400

MVFL315/3W

DN15

1.6

400

MVFL315/2W

DN15

2.5

400

MVFL315/1W

DN15

4

400

MVFL320/W

DN20

6.3

350

MVFL325/W

DN25

10

200

MVFL332/W

DN32

16

110

MVFL340/W

DN40

25

60

209

11

VA LV E S

3-way, flange

210

Article

Nominal diameter

Kvs

kPa

MVFL315/7F

DN15

0.25

400

MVFL315/6F

DN15

0.4

400

MVFL315/5F

DN15

0.63

400

MVFL315/4F

DN15

1

400

MVFL315/3F

DN15

1.6

400

MVFL315/2F

DN15

2.5

400

MVFL315/1F

DN15

4

400

MVFL320/F

DN20

6.3

350

MVFL325/F

DN25

10

200

MVFL332/F

DN32

16

110

MVFL340/F

DN40

25

60

VA LV E S

Adapter kit for adapting actuators of other brands to Regin’s valves Adapter kits for adapting actuators from other suppliers to Regin’s series of valves. Adapter and stem extension are included in the kit. Article

Actuator supplier

Actuator model

Compatible valves and dimensions

OVA-B1

Belimo

NV...-R

MTRS, MTVS, ETRS, ETVS, FRS, FRSD, MRT, 2SAS (DN15), 2SBS (DN20-80), NTVS (DN15-80), GTRS (DN32-40), GTVS (DN32-40)

OVA-B2

Belimo

AV...-R

GTVS (DN50-150), GTRS (DN50-150), 2SBS (DN100), NTVS (DN100-150)

OVA-B3

Belimo

AV...-R

Old OAB 3/8” UNF thread on the stem: 2SB (DN100), GTV (DN50-150), GTR (DN50-150)

OVA-B4

Belimo

NV...-R

BTV, BTR

OVA-B5

Belimo

NV...-R

Old OAB 3/8” UNF thread on the stem: MTV, MTR, 2SA (DN15), 2SB (DN20-80), GTV (DN25-40), GTR (DN25-40)

OVA-B6

Belimo

EV...

GTVS (DN50-150), GTRS (DN50-150), 2SBS (DN80100), NTVS (DN80-150)

OVA-B7

Belimo

NV...-TPC

MTRS, MTVS, ETRS, ETVS, FRS, FRSD, MRT, 2SAS (DN15), 2SBS (DN20-80), NTVS (DN15-80), GTRS (DN32-40), GTVS (DN32-40)

OVA-RS1

R+S

HM...

MTRS, MTVS, ETRS, ETVS, FRS, FRSD, MRT, 2SAS, 2SBS, NTVS, GTRS, GTVS

OVA-RS2

R+S

HM...

BTV

OVA-T1

TAC Forta

M400/M800

MTRS, MTVS, ETRS, ETVS, FRS, FRSD, MRT, 2SAS (DN15), 2SBS (DN20-80), NTVS (DN15-80), GTRS (DN32-50), GTVS (DN32-50), CVFS

OVA-T2

TAC Forta

M400/M800

Old OAB 3/8” UNF thread on the stem: MTV, MTR, 2SA (DN15), 2SB (DN20-80), GTV (DN25-50), GTR (DN25-50), CFV

OVA-S1

Siemens

All

MTRS, MTVS, ETRS, ETVS, FRS, FRSD, MRT, 2SAS, 2SBS, NTVS, GTRS, GTVS

OVA-AVM

Sauter

AVM234

2SBS (DN50-100), NTVS (DN50-150), GTVS (DN50150), GTRS (50-150)

11

211

VA LV E S

212

12 V A L V E A C T U AT O R S

VALVE ACTUATORS

-4°C +20°C

213

12

V A L V E A C T U AT O R S

Thermal actuator Thermal actuator with position indicator for control of valves in heating or cooling systems. The actuator can be used to control radiator circuits, solar heating systems, heating or cooling coils, floor heating etc. To be combined with the VTTV/VTTR/VTTB range of valves. Technical data Power consumption

3 VA

Stroke

2.5 mm

Ambient temperature

0…50°C

Connection

M30 x 1.5

Dimensions

Ø 40 mm x 61 mm

Cable length

2m

Protection class

IP40 (IP44 when vertically mounted)

Article

Supply voltage

Control signal

Force

Stroke time

RTAN-24

24 V AC

On/off, NC

100 N

4.5 min

RTAN-230

230 V AC

On/off, NC

100 N

3.5 min

RTAN-24A

24 V AC

0...10 V DC, NC

100 N

4.5 min

RTAN140-24

24 V AC

On/off, NC

140 N

4.5 min

RTAN140-230

230 V AC

On/off, NC

140 N

3.5 min

Thermal actuator Thermal actuators with position indication for control of valves in heating or cooling systems. The actuator can be used to control radiator circuits, solar heating systems, heating or cooling coils, floor heating etc. The VA54 adapter is included upon delivery (does not apply to RTAM100-24-10, RTAM100-24-15 and all 125 N variants). Technical data Ambient temperature

0...60°C

Protection class

IP54

Article

Supply voltage

Cable length

Power consumption

Stroke time

Force

Stroke

1 W. Max. inrush current < 300 mA during max. 2 min.

3.5 min

100 N

4 mm

3.5 min

100 N

4 mm

3.5 min

100 N

4 mm

RTAM100-24

24 V AC/DC

On/off, NC

2m

RTAM100-24-10

24 V AC/DC

On/off, NC

10 m

RTAM100-24-15

24 V AC/DC

On/off, NC

15 m

RTAOM100-24

24 V AC/DC

On/off, NO

2m

3.5 min

100 N

4 mm

RTAM100-24A

24 V AC

0...10 V DC, NC

2m

30 s/mm

100 N

4 mm

RTAM100-230

230 V AC

On/off, NC

2m

3.5 min

100 N

4 mm

RTAOM100-230

230 V AC

On/off, NO

2m

3.5 min

100 N

4 mm

RTAM125-24

24 V AC/DC

On/off, NC

2m

RTAOM125-24

24 V AC/DC

On/off, NO

2m

RTAM125-24A

24 V AC

0...10 V DC, NC

2m

RTAM125-230

230 V AC

On/off, NC

2m

RTAOM125-230

230 V AC

On/off, NO

2m

Accessories

214

Control signal

Article

Description

RTA-CASE

Adapter case

1 W. Max. inrush current < 550 mA during max. 100 ms. 1.2 W. Max. inrush current < 300 mA during max. 2 min. 1.2 W. Max. inrush current < 550 mA during max. 100 ms.

4.5 min

125 N

6.5 mm

4.5 min

125 N

6.5 mm

30 s/mm

125 N

6.5 mm

4.5 min

125 N

6.5 mm

4.5 min

125 N

6.5 mm

V A L V E A C T U AT O R S

Adapters for the RTA(O)M actuators Adapters for adjusting the RTA(O)M actuators to valves of other brands. Article

Valve supplier

Connection, valve

Colour

VA02

LK

M30 x 1.5

Grey with red stem

VA10

Siemens/Oventrop

M30 x 1.5

Light grey

VA13H

Controlli

M30 x 1.5

White with black stem

VA16H

Herz

M28 x 1.5

Grey with red stem

VA17

MMA

M28 x 1.5

White

VA18

Honeywell

M30 x 1.5

Light blue

VA26

Giacomini

Clamping ring

Grey

VA32

TA

M28 x 1.5

Green

VA39

Oventrop

M30 x 1.0

White

VA41

Danfoss AB-QM

M30 x 1.5

Dark green

VA44H

Cazzaniga

M32 x 1.5

Grey

VA50

Honeywell

M30 x 1.5

Dark grey

VA54

MMA

M28 x 1.5

Dark blue

VA59

Danfoss RAV/L

Clamping ring

Light grey

VA64

Pettinaroli

M28 x 1.5

Grey

VA66

Industrietechnik

M30 x 1.5

Grey

VA72

Danfoss RAV

Grub screw

Light grey

VA78

Danfoss RA

Grub screw

White

VA80

TA

M30 x 1.5

White/grey

VA90

Valsir

M30 x 1.5

Red

Article

Description

RTA-CASE

Adapter case

12

215

V A L V E A C T U AT O R S

Valve actuator for 0...10 V or 3-position control The RVAZ4 series of valve actuators are easy to mount and have a clear position indication which shows the position of the actuator. The actuator has manual manoeuvring. The RVAZ4 models are intended for use together with Regin’s valve ranges ZTV/ZTR and ZTVB/ZTRB. The RVAZ4L1 models can be used for Regin's MVFL valve range or different brands of valves in combination with the OVA-L1 adapter. Technical data Force

400 N

Stroke

5.5 mm

Ambient temperature

0…50°C

Storage temperature

-10…+80°C

Media temperature

1…110°C

Ambient humidity

Max. 95 % RH

Protection class

IP44

Actuators for Regin’s valve ranges ZTV/ZTR and ZTVB/ZTRB Article

Supply voltage

Power consumption

Control signal

Stroke time

RVAZ4-24

24 V AC ±15 %

0.6 VA

3-position

150 s

RVAZ4-24A

24 V AC ±15 %

6 VA

0...10 V DC

30 s

RVAZ4-230

230 V AC ±15 %

6 VA

3-point

150 s

Valve actuators for Regin’s MVFL valve range or different brands of valves in combination with the OVA-L1 adapter Article

Supply voltage

Power consumption

Control signal

Stroke time

RVAZ4L1-24

24 V AC ±15 %

0.6 VA

3-position

150 s

RVAZ4L1-24A

24 V AC ±15 %

6 VA

0...10 V DC

30 s

RVAZ4L1-230

230 V AC ±15 %

6 VA

3-position

150 s

Electromechanical actuators for the PCTV, PCTVM and PCTVS valves Technical data Max. fluid temperature

95°C

Ambient temperature

0 - 50°C

Protection class

IP43

Force

120 N +30 % -20 %

Stroke time

8 s/mm

Article

Control signal

Stroke

Power supply

Power consumption

VA-7481-0001

3-point

6 mm (max.)

24 V AC

1.5 W / 2.5 VA

VA-7481-0003

3-point

6 mm (max.)

230 V AC

2.2 W / 6.5 VA

VA-7482-1001

0-10 V

6 / 3.2 mm (adjustable)

24 V AC

1.5 W / 2.5 VA

Accessories

216

Article

Description

Actuator

OA7010

Adapter for valve with 2.7 mm stroke (to be ordered separately)

VA-7481...,VA-7482-1001

OA748X

Adapter for valve with 6 mm stroke (to be ordered separately)

VA-7481...,VA-7482-1001

V A L V E A C T U AT O R S

Valve actuator, 24 V supply voltage and 0(2)...10 V DC control Valve actuator with automatic stroke adjustment for control of Regin’s range of valves. Available in models with actuator force of 500, 1000, 1800 or 2500 N. The actuators can be operated manually with the manual override mechanism on the lid. Technical data Supply voltage

24 V AC/DC

Control signal

0...10 V DC or 2...10 V DC

Ambient temperature

0...50°C

Storage temperature

-40...80°C

Ambient humidity

10...90 % RH

Protection class

IP54

Article

Max. power consumption (VA)

Force

Stroke

Stroke time

RVAN5-24A

4.5 VA

500 N

10...30 mm

1.5 s/mm

RVAN10-24A

6 VA

1000 N

10…30 mm

3 s/mm

RVAN18-24A

8 VA

1800 N

10…52 mm

3 s/mm

RVAN25-24A

12 VA

2500 N

10...52 mm

3 s/mm

Valve actuator, 24 V supply voltage and 3-position control Valve actuator for control of Regin’s range of valves. Available in models with actuator force of 500, 1000, 1800 or 2500 N. The actuators can be operated manually with the manual override mechanism on the lid. Technical data Supply voltage

24 V AC

Control signal

3-point

Stroke time

3 s/mm

Ambient temperature

0...50°C

Storage temperature

-40...80°C

Ambient humidity

10...90 % RH

Protection class

IP54

12

Article

Max. power consumption (VA)

Force

Stroke

RVAN5-24

4.5 VA

500 N

10…30 mm

RVAN10-24

6 VA

1000 N

10…30 mm

RVAN18-24

8 VA

1800 N

10…52 mm

RVAN25-24

12 VA

2500 N

10…52 mm

217

V A L V E A C T U AT O R S

Valve actuator, 230 V supply voltage and 3-position control Valve actuator for control of Regin’s range of valves. Available in models with actuator force of 500, 1000, 1800 or 2500 N. The actuators can be operated manually with the manual override mechanism on the lid. Technical data Supply voltage

230 V AC ±15 %, 50 Hz

Control signal

3-point

Power consumption

12 W

Stroke time

3 s/mm

Ambient temperature

0...50°C

Storage temperature

-40...+80°C

Ambient humidity

10...90 % RH

Protection class

IP54

Article

Force

Stroke

RVAN5-230

500 N

10...30 mm

RVAN10-230

1000 N

10…30 mm

RVAN18-230

1800 N

10...52 mm

RVAN25-230

2500 N

10...52 mm

Valve actuator for MMV and MMR valves, 24 V supply voltage The RVAR actuators are intended for control of Regin’s former MMV and MMR valves, as well as other valves. Technical data

218

Max. power consumption

4.5 W

Force

500 N

Stroke

10...30 mm

Ambient temperature

0...50°C

Ambient humidity

10...90 % RH

Storage temperature

-40...80°C

Protection class

IP54

Article

Supply voltage

Control signal

Stroke time

RVAR5-24

24 V AC

3-point

3 s/mm

RVAR5-24A

24 V AC/DC

0...10 V DC or 2...10 V DC

1.5 s/mm

V A L V E A C T U AT O R S

Valve actuator for MMV and MMR valves, 230 V supply voltage The RVAR actuators are intended for control of Regin’s former MMV and MMR valves, as well as other valves. Technical data Control signal

3-point

Max. power consumption

12 W

Stroke time

3 s/mm

Stroke

10...30 mm

Ambient temperature

0...50°C

Storage temperature

-40...+80°C

Ambient humidity

10...90 % RH

Protection class

IP54

Article

Force

RVAR5-230

500 N

RVAR10-230

1000 N

12

219

V A L V E A C T U AT O R S

Adapter kit for adapting Regin’s RVAN actuators to valves of other brands ARI Armaturen Valve

DN min.-max.

Stroke

Actuator

Adapter type

485-489

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

485-489

65 - 100 mm

20 - 30 mm

RVAN18.../RVNA25...

OVA-A2

485-489

40 - 50 mm

14 mm

RVAN18

OVA-A3

Valve

DN min.-max.

Stroke

Actuator

Adapter type

VLF125

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLF135

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLF335

65 - 80 mm

20 mm

RVAN18.../RVAN25...

OVA-F4

VLA121

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLA221

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLA131

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLA325

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLA325

65 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-F4

VLB225

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLB225

65 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-F4

VLA335

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLA335

65 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-F4

VLB235

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLB235

65 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-F4

VLA425

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLE122

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLE132

15 - 50 mm

20 mm

RVAN.../RVAN10...

OVA-131

VLE222

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLE325

20 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLC125

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLC225

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLC325

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VLC425

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2FC

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL3FC

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2TA

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2TAA

25-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL3TA

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2FA

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2FAA

25-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL3FA

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2TB

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2TBA

25-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL3TB

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2FD

15-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

VL2FDA

25-50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

ESBE

220

V A L V E A C T U AT O R S

Honeywell Valve

DN min.-max.

Stroke

Actuator

Adapter type

V5011R

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5013A

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5013F

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5013R

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5015A

100 - 150 mm

38 mm

RVAN18.../RVAN25...

OVA-013

V5329C

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5329A

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5016A

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5016A

100 - 150 mm

38 mm

RVAN18.../RVAN25...

OVA-013

V5025A

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5025A

100 - 150 mm

38 mm

RVAN18.../RVAN25...

OVA-013

V5050A

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V5050A

100 - 150 mm

38 mm

RVAN18.../RVAN25...

OVA-013

V5328A

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V176A

15 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V176B

20 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-011

V176B

100 mm

38 mm

RVAN18.../RVAN25...

OVA-013

V538C6xxx

50 - 150 mm

27 - 40 mm

RVAN18.../RVAN25...

OVA-013

V538C3xxx

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-011

Valve

DN min.-max.

Stroke

Actuator

Adapter type

RF

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

RF

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-A2

RK

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

RK

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-A2

Kieback und Peter

12

221

V A L V E A C T U AT O R S

L&G, L&S, Siemens valves

222

Valve

DN min.-max.

Stroke

Actuator

Adapter type

VFF33 (VARISHUNT)

65 mm

40 mm

RVAN18.../RVAN25...

OVA-031

VFF34 (VARISHUNT)

65 mm

40 mm

RVAN18.../RVAN25...

OVA-031

VFF35 (VARISHUNT)

65 mm

40 mm

RVAN18.../RVAN25...

OVA-031

VFF36 (VARISHUNT)

65 mm

40 mm

RVAN18.../RVAN25...

OVA-031

VFG33 (VARISHUNT)

25- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VFG34 (VARISHUNT)

25- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VFG35 (VARISHUNT)

25- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VFG36 (VARISHUNT)

25- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VPF52E

15 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VPF52F

15 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF21

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF21

100 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VVF31

25 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF31

100 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VVF40

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF40

100 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VVF41

50 - 150 mm

20/40 mm

RVAN18.../RVAN25...

OVA-082

VVF45

50 - 150 mm

20/40 mm

RVAN18.../RVAN25...

OVA-082

VVF51/52

15 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF53

15- 50 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF61

15 - 25 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VVF61

40 - 150 mm

20/40 mm

RVAN18.../RVAN25...

OVA-082

VVG11

20- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VVG12 (VARIVALVE)

25 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VXF21

25 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF21

100 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VXF31

25 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF31

100 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VXF40

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF40

100 - 150 mm

10 mm

RVAN18.../RVAN25...

OVA-082

VXF41

15 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF41

50 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-082

VXF53

15- 50 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF61

15 - 25 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXF61

40 - 150 mm

20/40 mm

RVAN18.../RVAN25...

OVA-082

VVG41

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXG11

20- 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VXG12 (VARIVALVE)

25 - 40 mm

20 mm

RVAN5.../RVAN10...

OVA-134

VXG41

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-081

VXG44

15 - 50 mm

5.5 mm

RVAZ4L1

OVA-L1

VVG44

15 - 40 mm

5.5 mm

RVAZ4L1...

OVA-L1

VVG549

15 - 25 mm

5.5 mm

RVAZ4L1...

OVA-L1

VVI51

15 mm

5.5 mm

RVAZ4L1...

OVA-L1

VVG55

15 - 25 mm

5.5 mm

RVAZ4L1...

OVA-L1

VVP45

10 - 40 mm

5,5 mm

RVAZ4L1...

OVA-L1

VVP45

10 - 40 mm

5,5 mm

RVAZ4L1...

OVA-L1

VVP45

10 - 40 mm

5,5 mm

RVAZ4L1...

OVA-L1

V A L V E A C T U AT O R S

Old Osby valves with 3/8” UNF thread on the stem Valve

DN min.-max.

Stroke

Actuator

Adapter type

2SA/2SB

15 - 80 mm

20 mm

RVAN5.../RVAN10...

OVA-132

2SB

100 mm

38 mm

RVAN18...

OVA-133

CVF

20 - 65 mm

32 mm

RVAN18...

OVA-133

GTR/GTV

25 - 50 mm

20 - 24 mm

RVAN5.../RVAN10...

OVA-132

GTR/GTV

65 - 150 mm

40 mm

RVAN18.../RVAN25...

OVA-133

MTR/MTV

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-132

Old Osby valves with M8 thread on the stem Valve

DN min.-max.

Stroke

Actuator

Adapter type

MMV/MMR

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-134

Valve

DN min.-max.

Stroke

Actuator

Adapter type

RGV2

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-H1

RGV3

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-H1

HMVF2

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-H1

HMVF2

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-H2

HMVF3

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-H1

HMVF3

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-H2

RGVA2

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

RGVA3

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

HMVFA2

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

HMVFA2

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-A2

HMVFA3

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-A1

HMVFA3

65 - 100 mm

20 - 30 mm

RVAN18.../RVAN25...

OVA-A2

Valve

DN min.-max.

Stroke

Actuator

Adapter type

VZ

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-132

VZF

65 - 150 mm

27 - 40 mm

RVAN18.../RVAN25...

OVA-133

Riccius + Sohn

Satchwell

223

12

V A L V E A C T U AT O R S

TAC + Schneider Valve

DN min.-max.

Stroke

Actuator

Adapter type

STL

20 - 65 mm

31.5 mm

RVAN18...

OVA-031

STL-SR

20 - 65 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V241

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V341

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V353

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V231

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V232

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V298

20 - 40 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V211

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V211T

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V282

20 - 32 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V282

40 - 50 mm

31.5 mm

RVAN18...

OVA-031

VG211

15 - 50 mm

16.5/25 mm

RVAN5.../RVAN10...

OVA-131

VG222

65 - 150 mm

25/45 mm

RVAN18...

OVA-031

V311

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V311T

15 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V212

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V212T

25 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V395

40 - 50 mm

20 mm

RVAN5.../RVAN10...

OVA-131

V395

65 - 100 mm

30/39.5 mm

RVAN18.../RVAN25...

OVA-031

V265

40 - 100 mm

31.5/40.9/50.3 mm

RVAN18...

OVA-031

V221

65 - 100 mm

30/39.5 mm

RVAN18...

OVA-031

V384, V386, V392, V394

40 - 50 mm

31.5 mm

RVAN18...

OVA-031

V292

20 - 32 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V292

40 - 100 mm

31.5/40.9/50.3 mm

RVAN18...

OVA-031

V294

20 - 32 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V295

20 - 32 mm

22 mm

RVAN5.../RVAN10...

OVA-131

V295

40 - 100 mm

31.5/40.9/50.3 mm

RVAN18...

OVA-031

Valve

DN min.-max.

Stroke

Actuator

Adapter type

RV 111/T

15 - 40 mm

5.5 mm

RVAZ4L1...

OVA-L1

RV 111/W

15 - 40 mm

5.5 mm

RVAZ4L1...

OVA-L1

RV 111/F

15 - 40 mm

5.5 mm

RVAZ4L1...

OVA-L1

Valve

DN min.-max.

Stroke

Actuator

Adapter type

FM25

25 mm

23.5 mm

RVAR5

OVA-FM

FM50

50 mm

37.5 mm

RVAN18

OVA-FM

LDM

WSE/Norshunt

224

V A L V E A C T U AT O R S

Johnson Valve

DN min.-max.

Stroke

Actuator

Adapter type

VG7201/VG7203

25-32 mm

13 mm

RVAN5.../RVAN10...

OVA-J1

VG7201/VG7203

40-50 mm

19 mm

RVAN5.../RVAN10...

OVA-J1

VG7401/VG7403

25-32 mm

13 mm

RVAN5.../RVAN10...

OVA-J1

VG7401/VG7403

40-50 mm

19 mm

RVAN5.../RVAN10...

OVA-J1

VG7802/VG7804

25-32 mm

13 mm

RVAN5.../RVAN10...

OVA-J1

VG7802/VG7804

40-50 mm

19 mm

RVAN5.../RVAN10...

OVA-J1

BM-2xx2

15-50 mm

19 mm

RVAN5.../RVAN10...

OVA-J1

BM-2xx8

15-50 mm

19 mm

RVAN5.../RVAN10...

OVA-J1

The OVA-J1 adapter applies to valves with a M28x1,5 neck and a 1/4” UNF-28 threaded stem.

Controlli Valve

DN min.-max.

Stroke

Actuator

Adapter type

VSB

15-50 mm

16.5 mm

RVAN5.../RVAN10...

OVA-141

VMB

15-50 mm

16.5 mm

RVAN5.../RVAN10...

OVA-141

Valve

DN min.-max.

Stroke

Actuator

Adapter type

V6R

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

B6R

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

VXD

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

VXE

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

BXD

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

BXE

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

V6F

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

V6G

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

V6S

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

B6F

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

B6G

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

B6S

15 - 50 mm

14 mm

RVAN5.../RVAN10...

OVA-151

Sauter

225

12

V A L V E A C T U AT O R S

226

13 D A M P E R A C T U AT O R S

DAMPER ACTUATORS

13

+21°C

227

D A M P E R A C T U AT O R S

Damper actuators with spring return 4 Nm 4 Nm damper actuator with spring return Technical data Mounting

Directly on jack shaft

For jack shaft

8...16 mm Ø (round shaft), 8...12 mm (square shaft)

Max. damper size

0.8 m2

Torque

4 Nm

Running time, spring return

20 s, -20...+50°C, max. 60 s at -30°C

Protection class

IP54

Article

Control signal

Supply voltage

Running time, actuator

Auxiliary switch

RDAB5S-24

On/off

24 V AC/DC, 7 VA

40...75 s (0...4 Nm)

-

RDAB5S-24S

On/off

24 V AC/DC, 7 VA

40...75 s (0...4 Nm)

1 x SPDT, 6 (1.5) A, 250 V AC. Switching point: adjustable 0...100 %.

RDAB5S-230

On/off

230 V AC, 7 VA

40...75 s (0...4 Nm)

-

RDAB5S-230S

On/off

230 V AC, 7 VA

40...75 s (0...4 Nm)

1 x SPDT, 6 (1.5) A, 250 V AC. Switching point: adjustable 0...100 %.

RDAB5S-24A

0...10 V DC (working range 2...10 V)

24 V AC/DC, 7 VA

150 s

-

10 Nm 10 Nm damper actuator with spring return Technical data

228

Mounting

Directly on jack shaft

For jack shaft

10...22 mm Ø (round shaft), 14...25.4 mm (square shaft)

Max. damper size

2 m2

Torque

10 Nm

Running time, spring return

20 s

Protection class

IP54

Article

Control signal

Supply voltage

Power consumption

Running time, actuator

Auxiliary switch

RDAB10S

On/off

24...240 V AC, 50/60 Hz, 24...125 V DC

10 VA (24 V) / 11 VA (230 V)

75 s

-

RDAB10S-S

On/off

24...240 V AC, 50/60 Hz, 24...125 V DC

10 VA (24 V) / 11 VA (230 V)

75 s

2 x SPDT, 1 mA ... 3 (0.5) A, 250 V AC. Switching points: fixed 10 %, adjustable 10...90 %.

RDAB10S-24A

0...10 V DC (working range 2...10 V, 24 V AC only)

24 V AC, 50/60 Hz, 24 V DC

8 VA

150 s

-

D A M P E R A C T U AT O R S

20 Nm 20 Nm damper actuator with spring return Technical data Mounting

Directly on jack shaft

For jack shaft

10...22 mm Ø (round shaft), 14...25.4 mm (square shaft)

Max. damper size

4 m2

Torque

20 Nm

Running time, spring return

20 s

Protection class

IP54

Article

Control signal

Supply voltage

Power consumption

Running time, actuator

Auxiliary switch

RDAB20S

On/off

24...240 V AC, 50/60 Hz, 24...125 V DC

7 VA (24 V) / 18 VA (230 V)

75 s

-

RDAB20S-S

On/off

24...240 V AC, 50/60 Hz, 24...125 V DC

7 VA (24 V) / 18 VA (230 V)

75 s

2 x SPDT, 1 mA ... 3 (0.5) A, 250 V AC. Switching points: fixed 10 %, adjustable 10...90 %.

RDAB20S-24A

0...10 V DC (working range 2...10 V, 24 V AC only)

24 V AC, 50/60 Hz, 24 V DC

8.5 VA

150 s

-

13

229

D A M P E R A C T U AT O R S

Damper actuators without spring return 5 Nm 5 Nm damper actuator without spring return Technical data Mounting

Directly on jack shaft

For jack shaft

6...16 mm Ø (round shaft), 4...11 mm (square shaft)

Max. damper size

1.0 m2

Torque

5 Nm

Protection class

IP54

Article

Control signal

Supply voltage

Running time, actuator

Auxiliary switch

RDAB5-24

On/off, 3-point

24 V AC/DC, 2 VA

150 s

-

RDAB5-24S

On/off, 3-point

24 V AC/DC, 2 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB5-230

On/off, 3-point

230 V AC, 4 VA

150 s

-

RDAB5-230S

On/off, 3-point

230 V AC, 4 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB5-24A

0...10 V DC (working range 2...10 V)

24 V AC/DC, 2 VA

150 s

-

10 Nm 10 Nm damper actuator without spring return Technical data

230

Mounting

Directly on jack shaft

For jack shaft

8...20 mm Ø (round shaft), 10...16 mm (square shaft)

Max. damper size

2 m2

Torque

10 Nm

Protection class

IP54

Article

Control signal

Supply voltage

Running time, actuator

Auxiliary switch

RDAB10-24

On/off, 3-point

24 V AC/DC, 3.5 VA

150 s

-

RDAB10-24S

On/off, 3-point

24 V AC/DC, 3.5 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB10-230

On/off, 3-point

230 V AC, 6 VA

150 s

-

RDAB10-230S

On/off, 3-point

230 V AC, 6 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB10-24A

0...10 V DC (working range 2...10 V)

24 V AC/DC, 3.5 VA

150 s

-

D A M P E R A C T U AT O R S

20 Nm 20 Nm damper actuator without spring return Technical data Mounting

Directly on jack shaft

For jack shaft

10...20 mm Ø (round shaft), 10...20 mm (square shaft)

Max. damper size

4 m2

Torque

20 Nm

Protection class

IP54

Article

Control signal

Supply voltage

Running time, actuator

Auxiliary switch

RDAB20-24

On/off, 3-point

24 V AC/DC, 4 VA

150 s

-

RDAB20-24S

On/off, 3-point

24 V AC/DC, 4 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB20-230

On/off, 3-point

230 V AC, 6 VA

150 s

-

RDAB20-230S

On/off, 3-point

230 V AC, 6 VA

150 s

1 mA ... 3 (0.5) A, 250 V AC

RDAB20-24A

0...10 V DC (working range 2...10 V)

24 V AC/DC, 4 VA

150 s

-

RDAB20-230A

0...10 V DC (working range 2...10 V)

230 V AC, 6 VA

150 s

-

40 Nm 40 Nm damper actuator without spring return Technical data Mounting

Directly on jack shaft

For jack shaft

12...20 mm Ø (round shaft), 9...16 mm (square shaft)

Max. damper size

8 m2

Torque

40 Nm

Protection class

IP54

Article

Control signal

Supply voltage

Running time, actuator

RDAB40-24

On/off

24 V AC/DC, 7 VA

150 s

RDAB40-230

On/off

230 V AC, 7 VA

150 s

RDAB40-24A

0...10 V DC (working range 2...10 V)

24 V AC/DC, 7 VA

150 s

231

13

D A M P E R A C T U AT O R S

Damper actuator accessories

232

Article

Description

RK8

Ball t for 8 mm push rods

RK8:100

Ball t for 8 mm push rods, 100 pcs

SK10

Ball t for 10 mm push rods

SK10:100

Ball t for 10 mm push rods, 100 pcs

KH8

Damper crank arm, universal, for Ø 10...18 mm or □ 10...14 mm

AH-20

Damper crank arm for RDAB20

AH-25

Damper crank arm for RDAB10

AV10-18

Shaft extension, 250 mm, Ø 10...18 mm, □ 10...14 mm

ZG-LF1

Mounting kit for RDAB5S, for axial movement

ZG-NMA

Mounting kit for RDAB10, for axial movement

ZG-SMA

Mounting kit for RDAB20, for axial movement

K6-1

Spindle clamp for RDAB5S, round shaft, 16...20 mm

S1A

1-pole add-on auxiliary switch for RDAB5 and RDAB40

S2A

2-pole add-on auxiliary switch for RDAB5 and RDAB40

Z-SMA

Ground plate extension for RDAB20

ZA-LM

Adapter 8x8 mm to Ø 16 mm

Z-AF

Ground plate extension for RDAB20S

K7-3

Reversible universal spindle clamp for RDAB10S and RDAB20S

14 MISCELLANEOUS PRODUCTS

MISCELLANEOUS PRODUCTS

+20°C

+21°C 14

233

MISCELLANEOUS PRODUCTS

Miscellaneous Thermometer Robust thermometer for duct mounting. Easy to mount. Can be adjusted to fit different duct sizes by means of a moveable fastening flange. A rubber seal prevents air leakage. Technical data Diameter

65 mm

Total length

162 mm

Article

Temperature range

T40

-40...+40°C

T60

0...60°C

T100

0...100°C

T40:25

-40...+40°C

Differential pressure manometer Simple, compact, easy-to-use filter manometer. MINI1200 is supplied with measuring fluid, pressure outlets and an adhesive label for noting down the filter type and the initial and final pressure drop. Technical data Pressure range

0...1200 Pa

Dimensions

180 x 30 mm

Article

Description

MINI1200

Manometer

MINI1200:25

Manometer, 25 units

Differential pressure manometer Device for high accuracy measurements. The manometer measures up to 600 Pa differential pressure with enhanced resolution between 0...200 Pa. Equipped with blow-out protection and a knob for zeropoint adjustment. Max. total pressure 100 kPa. MV600 is supplied with measuring fluid, pressure outlets, tubing, screws and an adhesive label for noting down the initial and final pressure drop. Technical data

234

Pressure range

0...600 Pa

Accuracy

±3 %

Ambient temperature

-45...+65°C

Dimensions

210 x 140 x 33 mm

Article

Description

MV600

Manometer

MISCELLANEOUS PRODUCTS

Manometer accessories Article

Description

MM-F2

Blue measuring fluid (MINI1200) 1.05 g/cm3, 500 ml

MM-F3

Red measuring fluid (MV600) 0.786 g/cm3, 30 ml

MTU:25

Pressure outlet, black plastic. For 6 mm tubing, 25 pcs

MTU:100

Pressure outlet, black plastic. For 6 mm tubing, 100 pcs

MM-P:25

Plastic tubing Ø 6 mm. Transparent, 25 m.

MM-P:100

Plastic tubing Ø 6 mm. Transparent, 100 m.

IPP8:1000

Expansion plug, grey plastic, 8 mm, 1000 pcs

IPP10:1000

Expansion plug, grey plastic, 10 mm, 1000 pcs

IPP12:250

Expansion plug, grey plastic, 12 mm, 250 pcs

T-ROR:100

Plastic T-branch ing piece, for 6 mm tubing, 100 pcs

14

235

MISCELLANEOUS PRODUCTS

236

15

SYSTEM EXAMPLES AND CONTROL THEORY

SYSTEM EXAMPLES & CONTROL THEORY

+17°C +8°C 800ppm

237

SYSTEM EXAMPLES & CONTROL THEORY

System examples A large Regin system

EXOscada

E-mail / SMS alarms

RS485 GSM PSTN GPRS LAN RADIO WAN

PSTN

EXOflex

EXOflex

EXOflex

EXOcompact Corrigo

LON, EIB, Modbus

T/IP RS485

RS485

Foreign products EXOflex

EXOflex Foreign SCADA with OPC

EXOcompact Corrigo

Several controllers connectable Corrigo

EXO OPC

EXOcompact

EXOcompact

Corrigo

RS485

EX8282

RS485 Several controllers connectable

Regio zone controllers

EXOflex alternatives The PIFA units are used to design the functionality of the EXOflex controllers. They have digital and analogue inputs and outputs, communication ports, etc. Below are a few examples.

• 10 DI • 6 DO • 4 AI • 4 AO

• 20 DI • 12 DO • 12 AI • 6 AO

238

SYSTEM EXAMPLES & CONTROL THEORY

• 36 DI • 20 DO • 12 AI • 12 AO

• 100 DI • 36 DO • 36 AI • 24 AO

15

239

SYSTEM EXAMPLES & CONTROL THEORY

EXOflex and local buses

240

SYSTEM EXAMPLES & CONTROL THEORY

EXOcompact / Corrigo Advanced System EXOcompact

ED9200 Corrigo GPRS router EXOcompact ED9200

E3-DSP

EXOscada Nimbus

Corrigo

T/IP

Modem56kINT232

E-mail / SMS alarm

EXOcompact

ED9200

Corrigo

EXOcompact / Corrigo T/IP Alternatives

T/IP

EXOcompact

EXOscada Nimbus

Corrigo

T/IP

EXOcompact SMS alarms

ED9200 Corrigo

EXOcompact / Corrigo RS485 EXOline Alternatives EXOcompact

15

RS485

Corrigo EXOscada

EXOcompact ED9200

Corrigo

241

SYSTEM EXAMPLES & CONTROL THEORY

EXOcompact / Corrigo Modbus Alternatives EXOcompact

RS485

Corrigo Foreign SCADA

EXOcompact

E3-DSP

Corrigo

EXOcompact / Corrigo BACnet

BACnet/IP Foreign SCADA

EXOcompact

Corrigo

CLOUDigo CLOUDigo

PC

T/IP

Corrigo

242

Corrigo

SYSTEM EXAMPLES & CONTROL THEORY

EXOcompact / Corrigo OPC

T/IP

Foreign SCADA EXO OPC Driver

Controllers of other brands...

EXOcompact

Corrigo

Corrigo

Protocol standards EXOflex

EXOline - RS485 EXOcompact

Corrigo

Corrigo

EXOline - T/IP

M-Bus

Modbus - RS485

EIB

LONWorks

EXO controllers

Remote reading of energy and flow meters

PLC:s, controllers, SCADA, etc.

Lighting, door locks, sensors, etc.

Controllers, HVAC units, actuators, etc.

243

15

SYSTEM EXAMPLES & CONTROL THEORY

Protocol standards EXOcompact

EXOline - RS485 EXOcompact

Corrigo

Corrigo

EXOline - T/IP EXO controllers

Modbus - RS485

PLC:s, controllers, SCADA, etc.

M-Bus

Remote reading of energy and flow meters

BACnet

Controllers, HVAC units, actuators, etc.

Regio RS485

T/IP

EXOflex

RC-C... RS485

T/IP

EXOscada

EXOcompact

RC-C... RS485

R

EX8282 RC-C...

R

R

RU

244

RU

RU

RU

SYSTEM EXAMPLES & CONTROL THEORY

Control theory Constant supply air control Constant supply air control (constant supply air, duct temperature control) is used when heated air is blown into a room at a constant temperature. A temperature sensor is located in the supply air duct. This sensor is connected to a controller (with P- or PI-function) and the controller is connected to an actuator with a valve. The controller can also control multiple actuators in sequence.

Frost protection - frost protection sensor The purpose of the frost protection sensor is to prevent the formation of ice in the air heating coil. If ice is allowed to form, the air heater may freeze and burst, with subsequent water damage. The location of the temperature sensor is of particular importance, since it must be able to sense when the temperature is too low. It can be difficult to determine where in the air heater the temperature is at its lowest.

Room control Room control (constant room temperature, extract air control) is used to maintain a constant temperature in the room. It is also used when the temperature in the room is variable due to draughts, machinery heat loads, etc. The supply air temperature will vary depending on whether it is necessary to heat or to cool the premises. A sensor located in the supply air duct dictates a minimum and a maximum supply air temperature so that air which is too cold or too hot is not blown into the room.

The sensor can be placed on a pipeline (1), on the return (2), or on a pipe bend (3). The best location depends on the design of the heater. Some heating coils are fitted with a standard sensor receptor (4). A frost protection sensor may be electromechanical or electronic. The electronic frost protection sensor often has several functions: A.

To stop the supply air fan at a certain temperature.

B.

To provide a minimum limit for the heating coil temperature when the fan is in operation.

C.

To maintain a constant coil temperature when the fan is nonoperational. The outdoor air damper will close when the frost protection sensor stops the fan.

Regin’s controllers have built-in cascade control. They, in turn, contain two controllers, P+PI or PI+PI. The first controller is connected to a sensor in the room and the second to a sensor in the supply air duct. The controllers are connected so that the output signal of the first controller forms the input signal of the second. A temperature change in the room results in a change of the duct controller setpoint. The size of this change is determined by the cascade factor, CF. The cascade factor is the amplification at the first controller, i.e. the number of degrees by which the supply air temperature should be changed if the room temperature is changed by 1°C. The main sensor is located in the room or in the extract air duct (if the average temperature of multiple rooms is required). The main sensor, together with the controller, determines the supply air temperature for each individual load. The controller can also control several actuators in sequence.

245

15

SYSTEM EXAMPLES & CONTROL THEORY

P-control, P-band P-control stands for proportional control, i.e. a change at the sensor bears a certain relation to a change in the actuator. The magnitude of the actuator movement is determined by the amplification F. A small amplification results in a small movement for a given change, while a large amplification results in a large movement for the same change. However, the amplification F is not usually used in of comfort: instead, we refer to a P-band. The P-band is equal to 1/F (%). The P-band can also be expressed as the temperature change required for the actuator to move from closed to open position. Then the P-band value is specified in°C. One example of P-controllers is automatic thermostat valves fitted to radiators. When the temperature in the room drops, the valve opens to the corresponding extent. These valves usually have a P-band of 2°C, i.e. a change in the room temperature of 2°C is required for the valve to open fully, which means that the temperature in the room will vary within these 2°C. This is known as P deviation. It should then be possible for the P-band to be reduced in order to achieve a more even temperature, but the system would then become unstable, i.e. the valve would start to open and close continuously, with a fluctuating temperature (increasing and decreasing) as a result. P-controllers are sometimes used for ventilation purposes in order to maintain a constant temperature, e.g. the supply air temperature. Then the P deviation results in an undesirable temperature variation. If P deviation is not required, it is possible to use a controller containing an integrator instead so that PI-control is achieved.

Small amplification means a large P-band

PI-control, I-time PI-control is a combination of P-control and I-control. It is possible to compare PI-control with what happens when you fill a bucket with water - first you turn the tap on fully (P-effect) and then you gradually turn it off again (I-effect) until the bucket is full.

I-control means integrating control. This means a control link where the output signal is influenced by the magnitude and time of the input signal. A large deviation over a long period of time gives a large output signal and vice versa - a small deviation over a short period of time gives a small output signal. This signal is added to the signal from the P-controller. I-time is defined as the time it takes to increase the output signal to equal the value of the P stage.

Large amplification means a small P-band

246

SYSTEM EXAMPLES & CONTROL THEORY

Cascade control, cascade factor

Setpoint control

Cascade control is utilised e.g. for room control. Two controllers (P + PI or PI + PI) are used. The first controller is connected to a sensor in the room and the second to a sensor in the supply air duct. The controllers are connected so that the output signal of the first controller forms the input signal of the second. The cascade factor is the amplification at the first controller, i.e. the number of degrees by which the supply air temperature should be changed if the room temperature is changed by 1°C.

The SPC (setpoint control) input is used to change the desired temperature (setpoint value) from distance. This is done by displacing the setpoint value up or down. The input is adjusted to accommodate a standard signal, e.g. 0...10 V DC. At 5 V there is no effect, at 0 V the setpoint value is fully reduced, and at 10 V the value is fully increased.

Outdoor temperature compensation In some cases, it is desirable for the outdoor temperature to influence the main controller setpoint value, i.e. if the outdoor temperature falls below or exceeds a set value, the setpoint value is increased gradually. An outdoor sensor is then connected to the main controller via a separate unit.

Sequence control, neutral zone “Sequence“ means “series“ and therefore “sequence control“ means “series control“. When using sequence control, several actuators (output signals) are controlled in sequence, i.e. one actuator moves to its end position first followed by the next actuator, and so on. Sequence control usually takes place in two (e.g. cooling - heating) or three (e.g. cooling - recycling heating) stages.

Compensation can take place in the summer and/or in the winter. Summer compensation means that the setpoint value is increased when the outdoor temperature exceeds a set value, and winter compensation means that the setpoint value is increased when the outdoor temperature falls below a set value. An amplification factor for both summer and winter compensation determines the amount by which the setpoint value should be increased.

A neutral zone can be set between the cooling stage and the heating stage. The neutral zone (Nz) will give the cooling stage a higher setpoint value. This leads to a saving in energy used for cooling and will result in greater comfort since no sudden cold will be experienced by a person entering the room.

247

15

SYSTEM EXAMPLES & CONTROL THEORY

248

INDEX

Index

C

DP156

47, 175

DR-01

99, 101

E E0-R

177

E0-R230K

177

C81-3

44

DR-02

99, 101

48

C81D-3

44

DR-05

99

105074

143

C151-3

44

DR-16

101

E3-DSP

62

1884709

193

C151D-3

44

DR-16/14

100

E3-DSP

174

1885136

193

C152DT-3

44

DR-17

101

E8D-S-LON

59

1886274

193

C152T-3

44

DR-17/14

100

E8D-S-LON

60

1886282

193

C281-3

44

DR-25

102

E15D-S-LON

59

4160801

193

C281D-3

44

DR-90R

118, 128, 133

E15D-S-LON

60

4161101

193

C282-3

44

DR-90W

118, 128, 133

E15-S-LON

59

4161102

193

C282D-3

44

DR-90WS

118, 128, 133

E15-S-LON

61

4161103

193

C282DT-3

44

DR-135R

118, 128, 133

E28D-S-LON

59

4161201

193

C282T-3

44

DTK10

142

E28D-S-LON

60

4161202

193

C283DT-3

44

DTK10-420

142

E28-S-LON

59

4161203

193

C283DTM-3

44

DTK20

142

E28-S-LON

61

4161204

193

C283T-3

44

DTK20-420

142

E81-3

58

4161402

193

C283TM-3

44

DTK40

142

E81D-3

58

4161403

193

CABLEMODEM56KINT

DTK40-420

142

E151-3

58

4161841

193

CAB-STD1

65

DTK100

142

E151D-3

58

CAB-STD2

65

DTK100-420

142

E151DW-3

59

CAB-STD3

65

DTK250

142

E151W-3

59

CC5

47

DTK250-420

142

E152DW-3

59

5540-EXOFLEX

A

169

ABV24-300/D

151

CCERT-E

136

DTK400

142

E152DWM-3

60

ABV24-S-300/D

151

CCERT-H

140

DTK400-420

142

E152W-3

59

ABV-300/D

151

CCERT-H

141

DTK600

142

E281-3

58

ABV-S-300/D

151

CLO-3G

DTK600-420

142

E281D-3

58

DTK1000

142

E281DW-3

59

ADAPTER

118, 124, 128, 133, 143

CLOUDIGO

64, 169 64

CO2DT

147

DTK1000-420

142

E281W-3

59

AH-20

233

CO2DT-R

147

DTK1600

142

E282DW-3

59

AH-25

233

CO2HRT

146

DTK1600-420

142

E282DWM-3

60

AL24A1K

73

CO2HRT-D

146

DTK-NIPPEL

142

E282W-3

59

AL24A1T

92

CO2RT

146

DTK-R

142

E283DW-3

59

138, 140, 141

CO2RT-D

146

DTL05/05

141

E283DWM-3

60

92

CO2RT-R

146

DTL05/05-420

141

E283W-3

ANS-1 AQUA24TF

59

AV10-18

233

CO2RT-R-D

146

DTL05/05-420-D

141

E-CABLE2-USB

AVDT25

144

COF

147

DTL05/05-D

141

E-CABLE-RS232

45, 64

DTL150

140

E-CABLE-T/IP

64, 169

CONV232-485

B

46

45, 64

CONVERTERT

171

DTL150-420

140

E-CASE-C283DT-3-24

CS-260

186

DTL150-420-D

140

E-CASE-E283DW-3-24

46

CTV10

191

DTL150-D

140

ED9100-3

62, 174

65

BATTERY-4289

45, 65

BATTERY-5518

45

CTV15-1,9

191

DTL310

140

ED9100-10

62, 174

BATTERY-5702

45

CTV20

191

DTL310-420

140

ED9100IP65-3

62, 174

DTL310-420-D

140

ED9200

62, 173

DTL310-D

140

ED9200IP65

62, 173

DTL516

140

ED-RU

63, 176

DTL516-420

140

ED-RU-DFO

63, 176

BTV15-0,6

201

BTV15-1,0

201

BTV15-1,6

201

D

BTV15-2,5

201

DF

BTV20-3,9

201

DFCM-215X

194

DTL516-420-D

140

ED-RU-DO

63, 176

BTV25-6,3

201

DFCM-220X

194

DTL516-D

140

ED-RU-DOS

63, 176

BTV25-10

201

DFCM-225X

194

DTL1650

140

ED-RU-F

63, 176

BTV32-10

201

DFCM-232X

194

DTL1650-420

140

ED-RU-FO

63, 176

BTV32-16

201

DFCM-315X

194

DTL1650-420-D

140

ED-RU-H

63, 176

BTV40-16

201

DFCM-320X

194

DTL1650-D

140

ED-RU-O

63, 176

BTV40-27

201

DFCM-325X

194

DTV200

138

E-DSP-3

62, 174

BTV50-27

201

DFCM-332X

194

DTV500

138

E-DSP-10

62, 174

BTV50-39

201

DMD

138

DTV1000

138

EDSP-K3

62, 173, 174

139

DTV2000

138

EDSP-K10

62, 173, 174

47, 175

DTV5000

138

ED-TCV

DMD-C DP102

117, 124

62, 172

249

16

INDEX

EE21-FT3A21

137

ETVS15-2,5

196

FRS20-1,0

207

GTRS65-63

203

EE21-FT6A21

137

ETVS15-4,0

196

FRS20-1,6

207

GTRS80-100

203

EH10-S

34

ETVS20-5,0

196

FRS20-2,5

207

GTRS100-160

203

EH11-S

33

ETVS20-6,3

196

FRS20-4,0

207

GTRS125-215

203

EH20-S

34

ETVS25-8,0

196

FRS25-0,6

207

GTRS150-310

203

EH21-S

33

ETVS25-10

196

FRS25-1,0

207

GTVS32-16

203

EH30-S

34

ETVS32-12,5

196

FRS25-1,6

207

GTVS40-27

203

EH31-S

33

ETVS32-16

196

FRS25-2,5

207

GTVS50-39

203

EH40-S

34

ETVS40-20

196

FRS25-4,0

207

GTVS65-63

203

EH41-S

33

ETVS40-25

196

FRS32-0,6

207

GTVS80-100

203

EH-CARDHOLDER

39

ETVS50-31,5

196

FRS32-1,0

207

GTVS100-160

203

196

FRS32-1,6

207

GTVS125-215

203

GTVS150-310

203

EK10

173

ETVS50-40

EK10-3

173

EX8282

40

FRS32-2,5

207

EK12

173

EXODESIGNER

30

FRS32-4,0

207

EK14

173

26, 29

FRS32-6,3

207

EK20

41

EXOOPC-DRIVER

28

FRS32-10

207

H

EK22

41

EXOSCADA-100

26

FRS32-16

207

HA010101

137

EK24

41

EXOSCADA-500

26

FRS40-0,6

207

HA010102

137

EK54

186

EXOSCADA-B

26

FRS40-1,0

207

HA010103

137

EK108

186

EXOSCADA-BC

26

FRS40-1,6

207

HA010105

137

EK216

186

EXOSCADA-BSD

26

FRS40-2,5

207

HA010106

137

EK324

186

EXOSCADA-NIMBUS

26

FRS40-4,0

207

HA010401

137

EK432

186

EXOSCADA-OPC

26

FRS40-6,3

207

HA010402

137

EP0000

39

EXOSCADA-T

26

FRS40-10

207

HA010410

137

EP1004

35

EXOSCADA-UL

26

FRS40-16

207

HA010435

137

EP1011

35

EXOSCADA-ULU

26

FRS40-20

207

HA010450

137

EP2032

35

EXOSCADA-UPG

28

FRS50-2,7

207

HA010480

137

EP3016

35

EXOSCADA-UPG100

28

FRS50-6,3

207

HA010495

137

EP4024

36

EXOSCADA-UPG500

28

FRS50-10

207

HDT2200

136

EP5012

36

EXOSCADA-UPGBSD

28

FRS50-16

207

HDT2200-420

136

EP5112

36

EXOSCADA-UPG-NIMBUS

28

FRS50-20

207

HH1606

137

EP6012

37

EXOSCADA-UPG-OPC

28

FRS65-2,7

207

HH1608

137

EP7218

37

EXOSCADA-UPGUL

28

FRS65-6,3

207

HMH

134

EP7408

37

EXOSCADA-UPGULU

28

FRS65-10

207

HMH2

134

EP7416

38

FRS65-16

207

HPH148

134

EP8101

38

207

HPH1000

134

EP8102

38

F

FRS65-20

EP8210

38

FL1-D

EP8282

39

E-TOOL-S

64

EXOHOTEL

FT18

99

HR1

134

94

FT18R

99

HR1-DH

134

FL1-S

94

FT30

99

HR2

134

FL1TP

95

FT30R

99

HR-S

134

ETRS15-0,63

197

FLS304X

145

FT60

99

HRT250

136

ETRS15-1,6

197

FLS304XRE

145

FT60R

99

HRT250-420

136

ETRS15-1,25

197

FLS304XT

145

FV1/D

179

HRTN

135

ETRS15-2,5

197

FLS305XRE

145

FV5

193

HRTN-420

135

ETRS15-4,0

197

FLS305XT

145

FVR10

191

HRTN-D

135

ETRS20-5,0

197

FLS306X

145

FVR15

191

HTDT2200

136

ETRS20-6,3

197

FLS307X

145

FVR20

191

HTDT2200-420

136

ETRS25-8,0

197

FLS308X

145

HTDT2500

135

ETRS25-10

197

FLZ-09

145

HTDT2500-420

135

ETRS32-12,5

197

FMCE

45, 65, 69, 186

HTRT250

136

ETRS32-16

197

FMCO

65, 69, 186

ETRS40-20

197

FMK2

ETRS40-25

197

ETRS50-31,5

G GPRS5.0E

170

HTRT250-420

136

186

GSM100L-CORRIGO

170

HTRT2500

135

FN2

193

GSM100L-EXOFLEX

170

HTRT2500-420

135

197

FRS15-0,6

207

GSM100L-PC

170

HTRTN

135

ETRS50-40

197

FRS15-1,0

207

GSM-MAESTRO100

170

HTRTN-420

135

ETVS15-0,63

196

FRS15-1,6

207

GTRS32-16

203

HTRTN-D

135

ETVS15-1,6

196

FRS15-2,5

207

GTRS40-27

203

HVS

137

ETVS15-1,25

196

FRS20-0,6

207

GTRS50-39

203

250

INDEX

I

MTIC90

101

MVFL215/4W

208

MTIC90H

101

MVFL215/5F

209

N

IO-4X4-M

49, 52

MTIC90R

101

MVFL215/5T

208

NO2F

148

IO-8DO8AI-M

49, 51

MTIC90S

101

MVFL215/5W

208

NTVS15-0,4

205

IO-8DO8AO-M

49, 52

MTIC120S

101

MVFL215/6F

209

NTVS15-1,0

205

IO-16AI

49, 50

MTID30H

102

MVFL215/6T

208

NTVS15-1,6

205

IO-16DI

49, 50

MTID60

102

MVFL215/6W

208

NTVS15-2,7

205

IO-16DO-M

49, 51

MTID60-2

102

MVFL215/7F

209

NTVS20-0,8

205

IO-RU-7

49

MTID60S

102

MVFL215/7T

208

NTVS20-1,6

205

IO-RU-10

49

MTID120HR

102

MVFL215/7W

208

NTVS20-2,7

205

IPP8:1000

236

MTIR30

103

MVFL215/8F

209

NTVS20-3,9

205

IPP10:1000

236

MTIR30-2

103

MVFL215/8T

208

NTVS20-6,3

205

IPP12:250

236

MTIR30S

103

MVFL215/8W

208

NTVS25-1,6

205

IR24-P

152

MTIR30SH

103

MVFL220/F

209

NTVS25-2,5

205

IR24-PC

152

MTIR60

103

MVFL220/T

208

NTVS25-4,0

205

MTIR60S

103

MVFL220/W

208

NTVS25-6,3

205

MTIR60S-2

103

MVFL225/F

209

NTVS25-10

205

MTIR60SH

103

MVFL225/T

208

NTVS32-4,0

205

K K6-1

233

MTIS60S

103

MVFL225/W

208

NTVS32-6,3

205

K7-3

233

MTIS60SH

103

MVFL232/F

209

NTVS32-10

205

MTIS90S

103

MVFL232/T

208

NTVS32-16

205

MTIS90SH

103

MVFL232/W

208

NTVS40-6,3

205

MTRS15-0,63

202

MVFL240/F

209

NTVS40-10

205

157, 159, 163

MTRS15-1,0

202

MVFL240/T

208

NTVS40-16

205

157, 163

MTRS15-1,6

202

MVFL240/W

208

NTVS40-27

205

233

MTRS15-2,1

202

MVFL315/1F

210

NTVS50-6,3

205

KH-S-¾

155, 159, 163

MTRS15-2,7

202

MVFL315/1T

209

NTVS50-10

205

KH-S-1

155, 159, 163

MTRS20-4,2

202

MVFL315/1W

209

NTVS50-16

205

159, 163

MTRS20-5,6

202

MVFL315/2F

210

NTVS50-27

205

KH-S-2

163

MTRS25-10

202

MVFL315/2T

209

NTVS50-39

205

KR24-1W-S

180

MTRS32-16

202

MVFL315/2W

209

NTVS65-16

205

KRAC24-2WAU

181

MTRS40-27

202

MVFL315/3F

210

NTVS65-27

205

KRAC230-2W

181

MTRS50-39

202

MVFL315/3T

209

NTVS65-39

205

KRDC24-2WAU

181

MTU:25

236

MVFL315/3W

209

NTVS65-63

205

MTU:100

236

MVFL315/4F

210

NTVS80-100

205

MTVS15-0,63

202

MVFL315/4T

209

NTVS100-160

205

MTVS15-1,0

202

MVFL315/4W

209

NTVS125-215

205

NTVS150-310

205

KG-A/1

86

KH-¾

155, 159, 163

KH-1

155, 157, 159, 163

KH-1¼ KH-2 KH8

KH-S-1¼

M MAGNET-424

168

MTVS15-1,6

202

MVFL315/5F

210

MINI1200

235

MTVS15-2,1

202

MVFL315/5T

209

MINI1200:25

235

MTVS15-2,7

202

MVFL315/5W

209

MM6-24/D

180

MTVS20-4,2

202

MVFL315/6F

210

O

MM-F2

236

MTVS20-5,6

202

MVFL315/6T

209

OA748X

199

MM-F3

236

MTVS25-10

202

MVFL315/6W

209

OA748X

217

MM-P:25

236

MTVS32-16

202

MVFL315/7F

210

OA7010

199

MM-P:100

236

MTVS40-27

202

MVFL315/7T

209

OA7010

217

64, 169

MTVS50-39

202

MVFL315/7W

209

OP5U

68 68

MODEM3G-ANT MODEM56kINT232

169

MV600

235

MVFL320/F

210

OP10

MODEM56kINT485

169

MVFL215/1F

209

MVFL320/T

209

OP10-230

68

MSH...

154

MVFL215/1T

208

MVFL320/W

209

OVA-AVM

211

MTH...

156

MVFL215/1W

208

MVFL325/F

210

OVA-B1

211

MTIB60

100

MVFL215/2F

209

MVFL325/T

209

OVA-B2

211

MTIB90

100

MVFL215/2T

208

MVFL325/W

209

OVA-B3

211

MTIB120

100

MVFL215/2W

208

MVFL332/F

210

OVA-B4

211

MTIC30

101

MVFL215/3F

209

MVFL332/T

209

OVA-B5

211

MTIC30-2

101

MVFL215/3T

208

MVFL332/W

209

OVA-B6

211

MTIC30H

101

MVFL215/3W

208

MVFL340/F

210

OVA-B7

211

MTIC30R

101

MVFL215/4F

209

MVFL340/T

209

OVA-RS1

211

MTIC30S

101

MVFL215/4T

208

MVFL340/W

209

OVA-RS2

211

251

16

INDEX

OVA-S1

211

RC-C3H

83

RDAB10S

229

RVAN10-24

218

OVA-T1

211

RC-C3O

83

RDAB10S-24A

229

RVAN10-24A

218

OVA-T2

211

RC-CDFO

83

RDAB10S-S

229

RVAN10-230

219

RC-CDTO

83

RDAB20-24

232

RVAN18-24

218

RC-CF

83

RDAB20-24A

232

RVAN18-24A

218

RC-CFO

83

RDAB20-24S

232

RVAN18-230

219

RC-CONN:10

86

RDAB20-230

232

RVAN25-24

218

P PASTA-20

116, 121

PB

185

RC-CT

83

RDAB20-230A

232

RVAN25-24A

218

PBI

185

RC-CTH

83

RDAB20-230S

232

RVAN25-230

219

PCMTV15-F600

199

RC-CTO

83

RDAB20S

230

RVAR5-24

219

PCMTV15-F780

199

RC-DFO

84, 85

RDAB20S-24A

230

RVAR5-24A

219

PCMTV20-F1000

199

RC-DO

84, 85

RDAB20S-S

230

RVAR5-230

220

PCMTV20-F1500

199

RC-DTO

84, 85

RDAB40-24

232

RVAR10-230

220

PCMTV25-F1500

199

RC-F

84, 85

RDAB40-24A

232

RVAZ4-24

217

PCMTV25-F2200

199

RCF-230AD

91

RDAB40-230

232

RVAZ4-24A

217

PCMTV25-F2700

199

RCF-230CAD

91

REGIO BOX

81

RVAZ4-230

217

PCMTV32-F2700

199

RCF-230CD

89

REPEAT485

46

RVAZ4L1-24

217

PCMTV32-F3000

199

RCF-230CTD

90

RK8

233

RVAZ4L1-24A

217

PCTV15-F600

198

RCF-230CTD-EC

90

RK8:100

233

RVAZ4L1-230

217

PCTV15-F780

198

RCF-230D

89

RM6-24/D

179

PCTV20-F1000

198

RCF-230TD

90

RM6H-24/D

179

PCTV20-F1500

198

RCFM-230D

89

RR-G3

168

PCTV25-F1500

198

RCFM-230TD

90

RRT025A

93

S1A

233

PCTVS15-F600

198

RC-FO

84, 85

RRT025A

98

S2A

233

PCTVS15-F900

198

RC-H

84, 85

RRT025B

93

S50

151

PCTVS20-F600

198

RC-O

84, 85

RRT025B

98

S50-OE-GA4

151

PCTVS20-F900

198

R100

78, 79

RTA-CASE

S65

151

R100F

78, 79

RTAM100-24

215

S65-OE

151

215, 216

S

PLTCE

45, 65, 69, 186

PLT-E8

64

R100FL

78, 79

RTAM100-24-10

215

S02420001

201

PLT-E15

64

R100FT

78, 79

RTAM100-24-15

215

S0603080300

196

PLT-E28

64

R100L

78, 79

RTAM100-24A

215

S0603080300

197

PS-105-1

157

R100T

78, 79

RTAM100-230

215

S0603080300

202

PS-110-¾

155, 159, 163

R200

78, 79

RTAM125-24

215

S0603080300

203

PS-130-1

155, 159

R200F

78, 79

RTAM125-24A

215

S0603080300

205

PS-150-1¼

157, 159

R200FL

78, 79

RTAM125-230

215

S6321457301

201

PS-190-1

157, 163

R200FT

78, 79

RTAN-24

215

S6321457301

207

PS-200-2

157

R200L

78, 79

RTAN-24A

215

S-BP

151

PS-260-1¼

157, 163

R200T

78, 79

RTAN140-24

215

S-BPR-S50

151

PS-300-2

157, 163

R-CASE

81

RTAN140-230

215

S-BPR-S65

151

PULSER

106

R-CONN:10

81

RTAN-230

215

SC1/D

178

PULSER220X010

106

RC-T

RTAOM100-24

215

SC2/D

178

PULSER380X010

106

RC-TEST

RTAOM100-230

215

SDD-OE50

150

PULSER-ADD

106

RC-TO

RTAOM125-24

215

SDD-OE50-M

150

PULSER/D

106

RDAB5-24

231

RTAOM125-230

215

SDD-OE65

150

PULSER-HC-LON

107

RDAB5-24A

231

RTV10

190

SDD-OE65-M

150

PULSER-M

106

RDAB5-24S

231

RTV15

190

SDD-OE65-RAC

150

PULSER-X/D

106

RDAB5-230

231

RU

80

SDD-OE65-RACM

150

RDAB5-230S

231

RU-CBL3

81

SDD-S50

150

RDAB5S-24

229

RU-CBL10

81

SDD-S50-M

150

RDAB5S-24A

229

RU-DFO

80

SDD-S65

150

R

84, 85 86 84, 85

R31

93, 98

RDAB5S-24S

229

RU-DO

80

SDD-S65-M

150

R33

93, 98

RDAB5S-230

229

RU-DOS

80

SDD-S65-RAC

150

R34

93, 98

RDAB5S-230S

229

RU-F

80

SDD-S65-RACM

150

RB3

86

RDAB10-24

231

RU-FO

80

SK10

233

84, 85

RDAB10-24A

231

RU-O

80

SK10:100

233

RC-C3

83

RDAB10-24S

231

RVAN5-24

218

SKALA-1228

72

RC-C3DFOC

83

RDAB10-230

231

RVAN5-24A

218

SKALA-3933

113

RC-C3DOC

83

RDAB10-230S

231

RVAN5-230

219

SKALA-3934

113

RC

252

INDEX

SKALA-3935

113

TG-D1/PT1000

124

TG-KH/NI1000-01

122

TRT50-420

132

SKYDDSRÖR-375

137

TG-D2/PT100

124

TG-KH/NI1000-02

122

TRTN

132

SPINN/D

168

TG-D2/PT1000

124

TG-KH/NTC1,8

122

TRTN-420

132

SS2U...

158

TG-D3/NI1000-01

125

TG-KH/NTC2,2

122

TRTN-D

132

SS-260

152

TG-D3/NI1000-02

125

TG-KH/NTC10-01

122

TRY-RATT-1588

113

TG-D3/NTC1,8

125

TG-KH/NTC10-02

122

TRY-RATT-1589

113

TG-D3/NTC2,2

125

TG-KH/NTC10-03

122

TRY-RATT-1590

113

TG-D3/NTC10-01

125

TG-KH/NTC20

122

TRY-RATT-2271

113

T T40

235

TG-D3/NTC10-02

125

TG-KH/PT100

122

TRY-RATT-3608

113

T40:25

235

TG-D3/NTC10-03

125

TG-KH/PT1000

122

TRY-RATT-3609

113

T60

235

TG-D3/NTC20

125

TG-KH/PT1000-430

122

TRY-RATT-3610

113

T100

235

TG-D3/PT100

125

TG-MH/PT1000

123

TTC25

109

TBI-10

119

TG-D3/PT1000

125

TG-R4/PT1000

129

TTC25X

109

TBI-30

119

TG-D130

117

TG-R4/PT1000-RB

129

TTC40F

110

TBI-50

119

TG-D150

117

TG-R5/NI1000-01

129

TTC40FX

110

TBI-70

119

TG-D170

117

TG-R5/NI1000-02

129

TTC63F

111

TBI-90

119

TG-D230

117

TG-R5/NTC1,8

129

TTC80F

112

TBI-100

119

TG-DH4/NI1000-01

126

TG-R5/NTC2,2

129

TTC2000

108

TBI-PT1000

130

TG-DH4/NI1000-02

126

TG-R5/NTC10-01

129

TTK1

143

TDS

150

TG-DH4/NTC1,8

126

TG-R5/NTC10-02

129

TTK1-420

143

TDT200

133

TG-DH4/NTC2,2

126

TG-R5/NTC10-03

129

TTK2

143

TDT200-420

133

TG-DH4/NTC10-01

126

TG-R5/NTC20

129

TTK2-420

143

TG-A1/NI1000-01

120

TG-DH4/NTC10-02

126

TG-R5/PT100

129

TTK5

143

TG-A1/NI1000-02

120

TG-DH4/NTC10-03

126

TG-R5/PT1000

129

TTK5-420

143

TG-A1/NTC1,8

120

TG-DH4/NTC20

126

TG-R430

118

TTK10

143

TG-A1/NTC2,2

120

TG-DH4/PT100

126

TG-R530

119

TTK10-420

143

TG-A1/NTC10-01

120

TG-DH4/PT1000

126

TG-R530M

119

TTK16

143

TG-A1/NTC10-02

120

TG-DHW1/NI1000-01

127

TG-R540

119

TTK16-420

143

TG-A1/NTC10-03

120

TG-DHW1/NI1000-02

127

TG-R550

119

TTK25

143

TG-A1/NTC20

120

TG-DHW1/NTC1,8

127

TG-R600

119

TTK25-420

143

TG-A1/PT100

120

TG-DHW1/NTC2,2

127

TG-R630

119

TTK40

143

TG-A1/PT1000

120

TG-DHW1/NTC10-01

127

TG-UH/NI1000-01

130

TTK40-420

143

TG-A130

116

TG-DHW1/NTC10-02

127

TG-UH/NI1000-02

130

TTK100

143

TG-AH1/NI1000-01

121

TG-DHW1/NTC10-03

127

TG-UH/NTC1,8

130

TTK100-420

143

TG-AH1/NI1000-02

121

TG-DHW1/NTC20

127

TG-UH/NTC2,2

130

TT-S1

113

TG-AH1/NTC1,8

121

TG-DHW1/PT100

127

TG-UH/NTC10-01

130

TT-S4/D

114

TG-AH1/NTC2,2

121

TG-DHW1/PT1000

127

TG-UH/NTC10-02

130

TT-S4/D

178

TG-AH1/NTC10-01

121

TG-DHWA/PT100

128

TG-UH/NTC10-03

130

TT-S6/D

114

TG-AH1/NTC10-02

121

TG-DHWA/PT1000

128

TG-UH/NTC20

130

TT-S6/D

178

TG-AH1/NTC10-03

121

TG-G130

117

TG-UH/PT100

130

TG-AH1/NTC20

121

TG-K3/NI1000-01

123

TG-UH/PT1000

TG-AH1/PT100

121

TG-K3/NI1000-02

123

TH-85-½

157, 161

U

TG-AH1/PT1000

121

TG-K3/NTC1,8

123

TH-120-½

161, 165

US-S/FFL...

160

TG-B1/PT100

121

TG-K3/NTC2,2

123

TH-210-½

165

US-WV...

162

TG-B130

116

TG-K3/NTC10-01

123

TIM480

185

TG-B150

116

TG-K3/NTC10-02

123

TLT130

132

TG-B160

116

TG-K3/NTC10-03

123

TLT130-420

132

TG-B190

116

TG-K3/NTC20

123

TM1-50

96

VA02

216

TG-B640/PT1000

121

TG-K3/PT100

123

TM1N-24/D

72

VA10

216

TG-D1/NI1000-01

124

TG-K3/PT1000

123

TM1N/D

72

VA13H

216

TG-D1/NI1000-02

124

TG-K3/PT1000/3,0

123

TM1-P

96

VA16H

216

TG-D1/NTC1,8

124

TG-K300

118

TM2-24/D

72

VA17

216

TG-D1/NTC2,2

124

TG-K310

118

TRAFO15/D

183

VA18

216

TG-D1/NTC10-01

124

TG-K330

118

TRAFO40N/D

183

VA26

216

TG-D1/NTC10-02

124

TG-K340

118

TRAFO60

183

VA32

216

TG-D1/NTC10-03

124

TG-K350

118

TRAFO75S

184

VA39

216

TG-D1/NTC20

124

TG-K360

118

T-ROR:100

236

VA41

216

TG-D1/PT100

124

TG-K370

118

TRT50

132

VA44H

216

130

V /W

253

16

INDEX

VA50

216

X4106

180

VA54

216

X9017

40

VA59

216

X9021

46

VA64

199, 216

X9035

35

VA66

216

X9035

40

VA72

216

VA78

216

VA80

216

VA90

216

Z-AF

233

VA-7481-0001

217

ZA-LM

233

VA-7481-0003

217

ZG-LF1

233

VA-7482-1001

217

ZG-NMA

233

VAD-½”

155, 159, 163

ZG-SMA

233

VAD-3/8”

155, 159, 163

Z-SMA

233

Z

VHR25

190

ZTR15-0,4

195

VR600

150

ZTR15-0,6

195

VR2000

150

ZTR15-0,25

195

VSR-½

155, 159, 163

ZTR15-1,0

195

VSR-¾

155, 157, 159, 163

ZTR15-1,6

195

VSR-1

157, 159, 163

ZTR20-2,0

195

157, 163

ZTR20-2,5

195

VTTB15-0,4

192

ZTR20-4,0

195

VTTB15-0,6

192

ZTR20-6,0

195

VTTB15-0,25

192

ZTR25-7,0

195

VTTB15-1,0

192

ZTRB25-8

200

VTTB15-1,6

192

ZTRB32-15

200

VTTB20-2,5

192

ZTRB40-20

200

VTTB20-4,0

192

ZTV15-0,4

195

VTTB20-6,0

192

ZTV15-0,6

195

VTTR15-0,4

192

ZTV15-0,25

195

VTTR15-0,6

192

ZTV15-1,0

195

VTTR15-0,25

192

ZTV15-1,6

195

VTTR15-1,0

192

ZTV20-2,0

195

VTTR15-1,6

192

ZTV20-2,5

195

VTTR20-2,5

192

ZTV20-4,0

195

VTTR20-4,0

192

ZTV20-6,0

195

VTTR20-6,0

192

ZTV25-7,0

195

VTTV15-0,4

192

ZTVB25-8

200

VTTV15-0,6

192

ZTVB32-15

200

VTTV15-0,25

192

ZTVB40-20

200

VTTV15-1,0

192

VTTV15-1,6

192

VTTV20-2,5

192

VTTV20-4,0

192

VTTV20-6,0

192

WPTH...

164

WSTH...

164

VSR-1½

X X204-0052:4 X1111

46 182

X1171A

46

X1176

45

X1178

86

X1312

182

X1314

182

X1804

180

254

SENSORS AND SWITCHES

Duct humidity/temperature transmitter, HDT3200

ConversionTransmitter charts for relative humidity and temperature measurement, resistant to contamination. Unit Technical data Inches Supply voltage Feet Output Square inches Working range Square feet

Length Area Volume

Mass Force Speed Flow

Factor

Unit

x 25.4 x 0.3048

= mm =m

x 645.16 x 0.0929

= mm² = m²

Accuracy, humidity Cubic inches Cubic feet Accuracy, temperature Cubic feet Pints Insertion length Imp.gal Mounting Imp.gal IbProtection (pounds) class

x 16387 x 0.02832 x 28.32 x 0.56825 x 4.546 x 0.004546

= mm³ = m³ = litre = litre = litre = m³

x 0.4536

= kg

lb (pounds) Article ft/min HDT3200 imp.gal/min HDT3200-420 Imp.gal/h

x 4.448 Description x 0.00508 Humidity transmitter x 0.07577 Humidity transmitter x 0.000126

ft³/min HTDT3200

Factor

Unit

= inches 24 V ACx/ 0.03937 20...35 V DC, 1 VA x 3.208 = feet 0...10 V DC or 4...20 mA* 0.00155 = in² Humidity: 20...95 % RH Temperature: x 10.764 = ft² 0...50°C ±3 % RH0.000061 (±5 % at 40...60 % RH) = in³ x 35.31 = ft³ ±0.5 K at 20°C = ft³ x 0.0353 = Pints 1.7598 60...230xmm (adjustable) x 0.22 = Imp.gal Duct x 220 = Imp.gal IP65 x 2.2046 = lb

=N

x 0.22482 Output signal x 196.85 0...10 V DC x 13.2 4...20 mA x 7936.51

= m/s

= lb = ft/m

= l/s = m³/s x 0.000472 = m³/s Combined humidity and temperature transmitterx 2118.64 0...10 V DC

= imp.gal/min = imp.gal/h = ft³/min = kcal/h

Heating power

kcal/h HTDT3200-420

x 1.163 =W Combined humidity and temperature transmitterx 0.8598 4...20 mA

Pressure

lb/in² lb/in² Article kg/cm² CCERT-E Pa

x 0.0689 = bar x 14.5 = lb/in² x 0.0703 = kg/cm² x 14.22 = ib/in² Accessories x 0.9807 = bar x 1.020 = kg/cm² Calibration certificate for HRT250 models, when certified calibration is demanded. Must be ordered a new transmitter.mWC bartogether with mmWC MPa kp/cm2 psi

1000

0.01

kPa 1 kPa 1 Pa

0.001

1 bar

100

100

100000

10000

1 mmWC

0.01

10

0.0001

1 mWC

10

10000

0.1

1000

1 Mpa

1000

1 kp/cm2

100

100000

1

10000

1 psi

0.1

0.001

* 4...20 mA output signal only voltage (two-wire). 0.00001 0.1at DC supply 0.0001 0.000001 0.001

Humidity transmitter 1000000 10 for outdoor 100000use

Article 6.666667 6666.667 EE21-FT3A21

10

0.1

0.15 0.00015

1

15

0.00001

0.0001

0.0015

0.01

0.1

1.5

10

150

100 10

0.01 0.00001

0.1

15 Description 0.066667 666.6667 0.666667 0.006667 0.066667 Humidity/temperature transmitter, 0...10 V DC, to be used together with the radiation shield HVS

bar

EE21-FT6A21

x 14.50377 Humidity/temperature transmitter, 4...20 mA, to =bepsi used together with the radiation shield HVS

bar

HVS

x 100 = kPa Weather shield for outdoor mounting of EE21-FT...

kg/cm2

x 14.22334

= psi

inches Hg

x 0.4912

= psi

N/m2

x 1.0

= Pa

mbar

x 100

= Pa

°C

x (1.8x°C)+32

= °F

kgcm

x 0.098

= Nm

litre

x 1000

= m3

gal (IMP)

x 4.5460

= litre

gal (US)

x 3.7854

= litre

gal (IMP)

x 1.20095

= gal (US)

120

– –

T H E T H E

C H A L L E N G E R C H A L L E N G E R

I N I N

B U I L D I N G B U I L D I N G

800ppm

A U T O M A T I O N A U T O M A T I O N

AB Regin 2014. No warranties with regard to printing errors in this catalogue.
