NPS - 'Nominal Pipe Size' and DN - 'Diametre Nominal'

Resources, Tools and Basic Information for Engineering and Design of Technical Applications!

Search

NPS - 'Nominal Pipe Size' and DN - 'Diametre Nominal' The size of pipes, fittings, flanges and valves are often given in inches as NPS - Nominal Pipe Size, or in metric units as DN - 'Diametre Nominal' Pipe is made of a wide variety of materials - like galvanized steel, black steel, copper, cast iron, concrete, and various plastics such as ABS, PVC, VC, polyethylene, polybutylene and more. Pipes are identified by "nominal" or "trade" names that are loosely related to the actual dimensions. For instance, a 2-inch galvanized steel pipe has an inside diameter of about 2 1/8 inches and an outside diameter of about 2 5/8 inches. In plumbing pipe size is referred to as nominal pipe size - NPS, or "Nominal Pipe Size". The metric equivalent is called DN or "diametre nominel". The metric designations conform to International Standards Organization (ISO) usage and apply to all plumbing, natural gas, heating oil, and miscellaneous piping used in buildings. The use of NPS does not conform to American Standard pipe designations where the term NPS means "National Pipe Thread Straight". Diameter Nominal DN (mm)

Nominal Pipe Size NPS (inches)

6

1/8

8

1/4

10

3/8

15

1/2

20

3/4

25

1

32

1 1/4

40

1 1/2

50

2

65

2 1/2

80

3

100

4

150

6

200

8

250

10

300

12

350

14

400

16

450

18

500

20

550

22

600

24

650

26

700

28

750

30

800

32

900

36

1000

40

1050

42

1100

44

1200

48

1300

52

1400

56

1500

60

http://www.engineeringtoolbox.com/nps-nominal-pipe-sizes-d_45.html

1/4

2/1/2014

NPS - 'Nominal Pipe Size' and DN - 'Diametre Nominal' 1600

64

1700

68

1800

72

1900

76

2000

80

2200

88

Related Topics Dimensions - Sizes and dimensions of pipes and tubes, and their fittings - inside and outside diameter, weight and more Piping Systems - Dimensions of pipes and tubes - dimensions, materials, capacities - pressure drop calculations and charts insulation and heat loss diagrams

Related Documents Difference betw een Pipes and Tubes - Pipes and tubes are not the same Pipes Fractional Equiv alents - Comparing fractions and inches for pipes
