Nescafe Barista Manual ss1s

Recommended with NESCAFÉ GOLD Barista Style. Experience the full range today.*

TABLE OF CONTENTS  SAFETY PRECAUTIONS...................................................................................................2-3 MACHINE OVERVIEW.......................................................................................................... 4 FIRST TIME USE & INITIAL RINSING...............................................................................5

REFILLING WITH COFFEE................................................................................................. 6 PREPARING BEVERAGES................................................................................................7-8 INDIVIDUAL ADJUSTMENTS TO YOUR PERSONAL TASTE................................. 9

NESCAFÉ GOLD Barista Style Intense

NESCAFÉ GOLD BLEND

NESCAFÉ GOLD BLEND Decaffeinated

A blend of soluble coffee with added finely ground roast coffee beans. This intense blend delivers a sharp, full-bodied cup with a bouquet of deep aromas.

A blend of Arabica beans that are golden roasted to perfection. Delivers a smooth cup with juicy aromas.

With caffeine naturally removed with water, this decaffeinated version delivers the same perfect cup of NESCAFÉ GOLD BLEND with juicy aromas.

We recommend using NESCAFÉ GOLD Barista Style coffee which is suited and tested for the NESCAFÉ GOLD BLEND Barista system. Alternatively, other freeze-dried coffee options can also be used. Fine powdered coffee is not recommended to be used in the NESCAFÉ GOLD BLEND Barista system as it will result in blockage issues.

US E R MAN UAL

*All NESCAFÉ GOLD products are suitable for use and have been tested for the NESCAFÉ GOLD BLEND Barista system.

www.nescafe.com.sg

CLEANING......................................................................................................................... 10-14 DESCALING....................................................................................................................... 15-16

GREEN & ORANGE LIGHT SIGNALS............................................................................. 17 RED ERROR SIGNALS................................................................................................... 18-19 TROUBLESHOOTING................................................................................................... 20-21

SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should always be followed, including the following: These instructions are to ensure you use this • Do not place coffee box near objects which could be affected by magnet. electric product safely and prevent you and associates from the risk of damage or hazard. • The heating element surface is subject to Please read and follow carefully all indicated residual heat after use. “Warnings” and instructions. “Warnings”: failure to follow these warnings Advised usage: may result in death or severe injury. • Insert the plug in a socket which is properlywired. When using an extension cord, do not Warnings: put many loads on one outlet. It can result • Unplug the cable immediately in a state of in fire caused by abnormal heat. In the event emergency. that the plug and cord get hot, stop using the machine immediately (do not use the • Do not place hands underneath the hot machine abroad). water jet or outlet during the preparation of the beverage (danger of burning). • Do not unplug the machine by pulling the cord. It can cause a short circuit. Do not • Always put a cup underneath the outlets touch the plug with wet hands. It can cause when rinsing the machine. an electric shock. • Ensure electrical plugs are clean and free of dust. It can cause an electric shock, short • This appliance is intended to be used in household only. It is not intended to be circuit or fire. used in the following applications, and the • Unplug the cable when the machine is not in guarantee may not apply for: use to avoid the risk of injury, burn, electric - staff kitchen areas in shops, offices and shock, electric leak or fire caused by dielectric other working environments; degradation. - farm houses; • Do not damage, destroy, remodel, bend, pull or twist the power plug forcedly. The plug - by clients in hotels, motels and other can be damaged and cause fire or electric residential type environments; shock by placing heavy objects on it, taking • The manufacturer is not liable for damage it apart or modifying it. caused by improper use of the machine or • Do not handle plug with wet hands. failure to comply with the instructions of this manual. Such damages are also not covered • Plug the machine only into mains voltage of by the warranty. 230 V - 50 Hz. • Children shall not play with the machine.

2

SAFETY PRECAUTIONS • This machine can be used by children • Patients with pacemakers or defibrillators: aged from 8 years and above and persons Do not hold the coffee box directly over the with reduced physical, sensory or mental pacemaker or defibrillator. capabilities or lack of experience and • Do not wash the power plug or the cord knowledge if they have been given with water nor leave them in liquid, such as supervision or instruction concerning use cleanser. It can cause a failure. of the machine in a safe way and if they • Do not leave water in the water tank when understand the hazards involved. the machine is not used over a long period of • Cleaning and maintenance shall not be time. The water can become contaminated. made by children unless they are older than Use fresh water every time you use the 8 and supervised by an adult. machine. • If the supply cord is damaged, it must be • Do not use the machine when it has a failure, replaced by a special cord or assembly available does not work properly or indicates any from the manufacturer or its service agent. possibility of failure. • The appliance must not be immersed.

• Do not put too much water in the water tank • Do not put anything (hot water, milk, alcohol as it will spill over the power connector. etc) other than potable water in the water • Do not put a load on the machine and do tank. It can dirty or clog the inside of the not squeeze the machine in between two machine and cause failure. We recommend shelves. This could lead to damage. the usage of soft water. • Do not use the machine near fire or place it on hot surfaces (e.g. on top of electric hot Further instructions: • In some situations the machine requires a plate). It can cause a fire. rinsing cycle. Before operating again, put a • Clean machine periodically according to cup underneath the outlets. instructions in chapter «CLEANING». • Drawer can only be inserted when the mixing • When cleaning the machine, unplug the chamber is inserted and locked. machine and let it cool down. Do not clean the machine while it is still hot. You can burn We recommend the use of NESCAFÉ GOLD, which has been tested with NESCAFÉ GOLD yourself. BLEND Barista system and particularly suits it. • The coffee box is equipped with a permanent magnet. Avoid placing the coffee box near The system is not designed for fine soluble coffee (like for instance NESCAFÉ Espresso), appliances and objects that can be damaged nor agglomerated soluble coffee powder by magnetism, e.g. credit cards, usb drives (like for instance NESCAFÉ Classic), and as and other data devices, video tapes, television well not for R&G coffee. Upon use of those and computer monitors with picture tubes, coffee, the system will be blocked. mechanical clocks, hearing aids and loud speakers. 3

FIRST TIME USE AND INITIAL RINSING

MACHINE OVERVIEW NESCAFÉ container

Top cover

Cleaning light  see page 18-19 Mixing chamber rinsing light  see page 18-19

Water tank

Power button (ON/OFF)

Before using the machine for the first time: • A initial rinse must be done. 5i • Perform a rinse with water tank filled to maximum level (approx. 1 L). Preferably use soft water.

1 5

2 5

min. 1/4 L

Place a container with a capacity of at least 1/4 L under the coffee outlet. Take water tank out.

No water indicator light  see page 18-19

Put drinking water in the tank. Never put any liquid other than potable water in the tank!

Menu icons

2

ON Slider cover (green) High velocity hot water jet

230 V 50 Hz

4 5

5

1

Mixing chamber

Mixing chamber lock handle (blue)

Milk measuring cup

3 5

Drawer

~25 sec

Re-attach the water tank to the main body. Plug in the power plug. CAUTION! Do not handle plug with wet hands. Plug the machine only into mains voltage of 230 V - 50 Hz.

Switch machine on. Power button starts blinking green while machine is heating up for approx. 25 seconds.

Power button and Espresso icon light steady green. Touch Espresso icon.

6 5

7 5

8 5

Rinsing starts. Wait until it stops.

Put rinsing water in the sink.

After rinsing is finished all lights are steady green. Machine is now ready for use.

Drip grid Drip tray

1460 W

max. 15 bar

~3,4 kg

5-35 °C 4

1L

B C

A

A = 178 mm B = 319 mm C = 285 mm

5

REFILLING WITH COFFEE

PREPARING BEVERAGES

2

1

1 6

2 6

Push on the top cover and open it.

Power button (ON/OFF)

Menu icons 3 6

Remove coffee box.

Place coffee box as shown and remove cap.

Espresso Suggested cup size: 100 ml

Latte Macchiato Suggested cup size: 300 ml

Lungo Suggested cup size: 200 ml

Cappuccino Suggested cup size: 300 ml

Americano Suggested cup size: 250 ml Hot water function for cup preheating

Black coffee options Espresso

4 6

5 6

Lungo

6

1 7

2 7

Place a cup. Remove drip tray when using a big mug.

Touch the desired menu icon.

3 7

4 7

7i

The selected menu icon flashes. The extraction starts and stops automatically. To stop the extraction partway through, touch selected menu icon again and wait until light stops blinking.

When selected menu icon stops flashing your coffee is ready. All lights are steady green. Enjoy your coffee. CAUTION! Your coffee will be hot!

To heat up the cup before preparing coffee touch Cappuccino and Americano icon simultaneously. CAUTION! Hot water will flow out! Afterwards throw away water and continue with step 1.

Click ! Fill coffee box with suitable coffee (see indication below).

Re-attach coffee box cap.

Click !

6i

7 6

Americano

Insert coffee box back to machine. The logo faces forwards. If you have difficulty to insert back coffee tank, please refer to section TROUBLESHOOTING, page 21.

We recommend using NESCAFÉ GOLD Barista Style coffee which is suited and tested for the NESCAFÉ GOLD BLEND Barista system. Alternatively, other freeze-dried coffee options can also be used. • Maximum filling volume for coffee tank: 150 g Fine powdered coffee is not recommended to be used in the NESCAFÉ GOLD BLEND Barista system as it will result in blockage issues.

Close top cover. Coffee powder is adversely affected by high temperatures and humidity. Please store it in a sealed container in a cool and dry location. Also, the coffee powder in the coffee tank should be used in good time, preferably within one month.

6

7

PREPARING BEVERAGES

INDIVIDUAL ADJUSTMENTS TO YOUR PERSONAL TASTE

Milk coffee options

You can adjust the strength of the coffee by changing the amount of hot water:

Latte Macchiato

To adjust volume, please follow procedure below Cappuccino

1 8

2 8

Menu

Espresso type coffee

Black coffee

Mug-size black coffee

Note: For Latte Macchiato & Cappuccino, cup parameter can not be adjusted   

Parameters (ml)

3 8

Place a cup. Remove drip tray when using a Latte Macchiato glass.

6 8

Pour milk* into the supplied measuring cup: - Latte Macchiato: 60 ml - Cappuccino: 50 ml

Pour milk into the cup.

4 8

5 8

Touch the desired menu icon.

7 8

(Initial setting ) Minimum Strongest quantity (setting ) Maximum Weakest quantity (setting ) Standard quantity

* NESCAFÉ recommends to use milk with at least 3 % fat.

~140 ml ~70 ml ~210 ml

8

Cappuccino

~200 ml ~100 ml ~300 ml

1 9

2 9

3 9

Put a cup in place. Touch and hold the menu icon for the beverage you wish to adjust for 2 seconds.

The power button light changes to orange. The selected menu icon lights green. Coffee extraction starts.

When the selected menu icon stops flashing green you can adjust the amount of hot water.

The selected menu icon starts flashing.

8i

When selected menu icon stops flashing your coffee is ready. All lights are steady green. Enjoy your coffee. CAUTION! Your coffee will be hot!

  

2 sec

4 9 Hot water/coffee extraction starts and stops automatically. To stop the extraction partway through, touch selected menu icon again and wait until light stops blinking. Nevertheless some coffee will continue to flow as long as the icon is flashing.

~60 ml ~40 ml ~120 ml

Latte Macchiato

To heat up the cup before preparing coffee touch Cappuccino and Americano icon simultaneously. CAUTION! Hot water will flow out! Afterwards throw away water and continue with step 1.

+/−

When the beverage reaches the desired amount touch the menu icon to stop. If you do not touch machine will stop at the maximum water level!

9i

After changing the setting... • Once you have changed the setting, the new amount of hot water will be used as the standard amount when you make the next coffee. (The new amount of hot water is not reset when you turn off the power.) • When a small cup is used, the coffee may overflow the cup if you set the amount of hot water too high. • To adjust to a new amount of hot water, repeat the above procedure (the current setting will be overwritten).

9

esetting initial beverage recipes R ① Connect the power plug. ② Check that the power is OFF. ③ Touch and hold the Cappuccino icon THEN the power button simultaneously. ④ Release the buttons when all the icon lights start flashing fast in green. ⑤ Machine is now back to factory settings. ⑥ Initial rinsing must be performed (see page 5).

CLEANING - OVERVIEW OF THE PARTS

CLEANING DRAWER & MIXING CHAMBER 1/2

Cleaning is to be performed when the maintenance icon starts blinking ( ). Regular maintenance of the machine ensures a better in-cup quality and a longer lifetime. About the water tank:

CAUTION! Put none of the parts into a dishwasher!

Coffee box - do not rinse! Coffee box cap

Coffee box

CAUTION! Do not touch the protrusion (connection part) on the bottom of the water tank. If you touch the protrusion on the bottom of tank when it has water in it, the water may spill from the tank.

OFF !

1 11

2 11

3 11

Switch machine off. Unplug power plug.

Pull out the drawer.

Press down the blue lock handle.

4 11

5 11

6 11

Check that the lock handle is down. Remove the mixing chamber.

Press the slider cover inwards from the both sides and pull it out. Sometimes the residue hardens, making it a little bit difficult to remove.

Release the lock under the mixing chamber.

7 11

8 11

9 11

Magnet (Do not expose to magnetic sensitive appliances!)

Dosing unit - rinsing OK! Coffee box scraper Dosing unit (constructed from the three parts below)

Water tank connection part

Lower disk No. 2*

Upper disk No. 1*

Dosing unit housing No. 3* *No. is engraved on the dosing unit housing

Inside the drawer: High velocity hot water jet Slider cover (green) No. 4** Mixing chamber mesh

min. 2 minutes

Mixing chamber

To remove the mixing chamber, pull down on the lock handle.

Mixing chamber lock handle (blue)

Drawer

Rinse drawer and slider cover under hot water. Wipe with a soft damp cloth.

Soak mixing chamber in hot water for at least 2 minutes. If coffee is still adhered, scrape it off gently.

**No. is engraved on the slider cover

10

11

Dry away moisture.

CLEANING DRAWER & MIXING CHAMBER 2/2

CLEANING DRIP TRAY, TANKS & DOSING UNIT 1/2

CAUTION! Put none of the parts into a dishwasher!

CAUTION! Put none of the parts into a dishwasher!

Check inside!

Top

10 12

12

11 12 Click !

Check the holes inside the mixing chamber: If the holes are blocked with coffee, rinse again with hot water.

OFF !

1 13

2 13

3 13

Switch machine off. Unplug power cord.

Rinse drip tray with hot water and clean it with a brush.

Rinse and clean water tank. Afterwards refill with fresh, potable water and insert it to machine.

Bottom

Push down lever until you hear a “Click”.

In case mesh has been removed: Check orientation of the mesh (the mesh has a top and a bottom side).

No. 3

Click !

13 12

14 12

15 12

4 13

5 13

6 13 Click !

No. 1 Push mesh into original position. Ensure it is fully inserted.

Align arrows on slider cover and main body. Press the slider cover in until you hear a “Click”.

Make sure that step 11 has been correctly followed. Push mixing chamber into the main body. Ensure it is fully inserted.

Make sure that coffee tank is empty. Turn the dosing unit clockwise and remove it from the coffee box.

Turn over the dosing unit and remove the upper disk No. 1.

Using the thumbs turn in the direction of the “OPEN” arrow until you hear a “Click”.

Lower disk No. 2

16 12

Click !

17 12

7 13

8 13

Dosing unit housing No. 3

9 13

Click ! Upper disk No. 1 Pull up blue handle to lock mixing chamber.

Slide drawer in until you feel the “Click”.

12

Put your fingers into the openings and remove lower disk No. 2.

Check whether all three parts are there.

13

Wipe away the dirt with a soft damp cloth. Soak disk No. 1 and disk No. 2 in hot water.

DESCALING 1/2

CLEANING DRIP TRAY, TANKS & DOSING UNIT 2/2 CAUTION! Put none of the parts into a dishwasher!

If you don’t descale your machine according to the following recommendations issues and even break down could happen. We recommend to descale your machine depending on water hardness and consumption but at least twice a year (see table below). Water hardness

i 14

11 14

10 14

Hard water Medium Soft

Remove coffee box cap and scraper.

Clean cap and scraper with a soft damp cloth. Do not clean the coffee box with flowing water!

Descaling after ... cups

300 ppm

250 cups

180 ppm

500 cups

80 ppm

750 cups

●●Read instructions and safety information on packaging of descaling agent. ●●Do not wash surface of machine using descaling agent.

Rinse and dry parts carefully before reassembling! Ideally let it dry for one night. Do not use a hair dryer deformation may result!

No. 1 80 g

12 14

13 14 No.3

Click !

No.3 Align marks ▼ No. 3 with No. 2 and fit together. The label “No. 3” gets visible.

1 15

14

Using the thumbs of both hands turn the lower disk No. 2 in the direction of the “CLOSE” arrow until you hear a “Click”.

D ag es en ca t lin

g

No.2

2 15

min. 700 ml

3 15

No. 3 Turn over the dosing unit housing and align the triangular portions on the dosing unit housing No. 3 and upper disk No. 1.

Dissolve 80 g of descaling agent in 700 ml of water. Do not use hot water!

Remove drip tray. Place a container with a capacity of at least 700 ml under the coffee outlet. Take water tank out.

Pour descaling solution into water tank. Insert water tank to machine.

Central protrusion

7 sec

15 14

16 14

17 14

4 15

5 15

6 15

Fit the scraper with the protrusion in the centre facing inwards and insert it into the corresponding recess.

Put coffee box back on dosing unit.

With the dosing unit held steady at the bottom, close by turning the coffee box clockwise until it stops.

To enter the descaling mode, start with machine off, then press on Espresso icon & power button for 7 seconds. All menu icons start flashing. Release the buttons.

Espresso icon and power button lights up steady green. Touch Espresso icon to start descaling process (icon starts flashing green).

Descaling solution is discharged: First from high velocity hot water jet, then from coffee outlet.

14

15

DESCALING 2/2

7 16

8 16

GREEN & ORANGE LIGHT SIGNALS

9 16 ~25 sec

5 min

5 min

Wait 5 minutes to let the descaling solution work. Touch Espresso icon to start again descaling process (icon starts flashing green).

Descaling solution is discharged: First from high velocity hot water jet, then from coffee outlet.

Wait another 5 minutes to let descaling solution work. Throw away water from container. Carefully rinse water tank.

10 16

11 16

12 16

min. 700 ml

Heating up mode Power button: flashing green All menu icons: OFF

Initial rinse mode Power button: steady green Espresso icon: steady green (see page 5)

Operation mode Power button: steady green All menu icons: steady green

+/−

Place a container with a capacity of at least 700 ml under the coffee outlet. Put drinking water in the tank. Insert water tank to machine.

Touch Espresso icon to start rinsing process (icon starts flashing green).

Water is first discharged from the high velocity hot water jet and then from the coffee outlet.

Preparation mode Power button: steady green Selected menu icon: flashing green

Cup warming adjustment mode Power button: steady orange Cappuccino & Americano icon: flashing green In this mode you can adjust the amount of water dispensed when preheating the cup (see page 7+8).

13 16

14 16

Access this mode by touching Cappuccino and Americano icon simultaneously during 2 seconds.

15 16 +/−

When Espresso icon stops flashing, touch Espresso icon again to start second rinsing cycle (icon starts flashing green).

Water is first discharged from the high velocity hot water jet and then from the coffee outlet.

Throw away water from container. Carefully rinse water tank. Fill up water tank with drinking water. Insert water tank back to machine.

i To quit the descaling mode, turn off the machine.

16

Coffee amount adjustment mode Power button: steady orange Selected menu icon: flashing green at the beginning, then steady green when adjustment possible (see page 9)

When the desired amount of water is reached touch the Cappuccino and Americano icon simultaneously to stop. If you do not touch machine will stop at the maximum level!

17

ECO mode (After 5 minutes power turns OFF automatically) Power button: OFF All menu icons: OFF

RED ERROR SIGNALS 2/2

RED ERROR SIGNALS 1/2 Error signal lights

ERROR SIGNAL:

PROCEDURE TO SOLVE THE PROBLEM:

ERROR SIGNAL:

PROCEDURE TO SOLVE THE PROBLEM:

Water tank empty / descaling required

Drawer not correctly inserted

If water tank is EMPTY:

If water tank is NOT EMPTY:

Cleaning light Mixing chamber rinsing light No water indicator light

Americano icon: flashing green Power button: steady red

Insert drawer correctly. Push firmly inside.

Coffee box not correctly inserted

Click !

No water indicator light: flashing red Power button: steady green

Remove coffee box and insert it correctly. Close top cover. If you have difficulty to insert back coffee tank, please refer to section TROUBLESHOOTING, page 21.

ON

Mixing chamber rinsing light: flashing red Espresso icon: steady green Power button: steady red

Coffee dust in machine, cleaning required/recommended

Error has occurred

OFF

2 19

Refill water tank and insert it back to machine correctly. Press green icon to finish beverage preparation.

Descale the machine according to descaling procedure on page 16-17.

1 19

2 19

Descaling Agent

Rinsing mixing chamber required

Click !

Espresso icon: flashing green Power button: steady red

1 19

Remove coffee cup and place container with a capacity of 200 ml under the coffee outlet.

Cleaning light: FLASHING RED  Cleaning is recommended

Touch Espresso icon. Rinsing process starts.

Cleaning light: STEADY RED  Cleaning is required

20 min

All menu icons: OFF Power button: fast flashing red

18

Switch machine off and wait 20 minutes. Afterwards switch machine on. If power button still flashes red desk.

Cleaning light: flashing / steady red All menu icons: steady green Power button: steady green / red

Clean dosing unit (see page 13-14). Put coffee box in place and make a rinse. Additionally clean mixing chamber, slider cover and drawer (see page 11-12).

19

TROUBLESHOOTING 1/2 CAUSE OF TROUBLE:

PROCEDURE TO SOLVE THE PROBLEM:

1 20

All menu icons: OFF Power button: OFF Machine cannot be switched on.

CAUSE OF TROUBLE:

2 20

Check if the power plug is plugged correctly into a mains power socket. If yes, check your electricity supply.

1 20

Coffee is not being dispensed properly from the coffee outlet.

TROUBLESHOOTING 2/2

If machine still cannot be switched on desk. If machine still cannot be switched on, desk through the information found on the back page.

2 20

Stop preparation.

Clean mixing chamber, slider cover and drawer according to cleaning procedure on page 12-13.

Coffee box cannot be inserted anymore. Power button: steady red Espresso icon: flashing green

PROCEDURE TO SOLVE THE PROBLEM:

1 21

2 21

Clean dosing unit and its parts (see page 13-14). Reassemble it with coffee box. Put coffee box back to machine. Do not push it in by force! Doing so may damage it!

Remove coffee cup and place a container with a capacity of at least 200 ml under the coffee outlet.

3 21

4 21 Click !

Gently swivel coffee box to the front until Espresso icon lights up. Hold coffee box in this position.

Touch Espresso icon while holding coffee box in same position until coffee extraction starts. Then push coffee box down.

1

Click !

3

5 21

6 21

Close top cover.

Touch Espresso icon to start the rinsing process. Afterwards throw away water from container.

2

Only hot water is being dispensed.

Tap on the top cover and open it. Remove coffee box and refill it according to procedure on page 7.

20

21

www.nescafe.com.sg
