Maintenance instructions

Translation from the original document • 10013865-0AWDE— • 10/30/2014

Combi Steamer

Unit

Model

Type of energy

Unit type

FlexiCombi Magiilot

6.15

Electric

Tabletop unit

FlexiCombi Classic

6.21

Gas

Pedestal unit

10.15 10.21 20.15 20.21

10013865-0AWAE—

en-US

Maintenance instructions

2

Directory of contents

1 Introduction ...........................................................................  5 1.1 About this manual ...............................................................................  5 1.2 General information  ............................................................................  5 1.3 Maintenance interval  ..........................................................................  5

2 Safety instructions  ................................................................  6 3 Maintenance schedule ..........................................................  7 3.1 Company performing the work  ...........................................................  7 3.2 Customer data  ....................................................................................  7 3.3 Unit data  .............................................................................................  7 3.4 Water connection ................................................................................  7 3.5 Chassis and cooking chamber  ...........................................................  8 3.6 Component check ...............................................................................  9 3.7 Software  .............................................................................................  9 3.8 Expected maintenance on gas units  ................................................  10

4 Information about the maintenance schedule  ....................  11

10013865-0AWAE—

4.1 Water connection ..............................................................................  11 4.2 Chassis and cooking chamber  .........................................................  11 4.3 Component check .............................................................................  11 4.4 Software  ...........................................................................................  12 4.5 Expected maintenance on gas units  ................................................  12

Maintenance instructions

3

10013865-0AWAE—

Directory of contents

4

Maintenance instructions

Introduction

1 Introduction 1.1 About this manual This manual contains information that the service technicians need for the professional maintenance of the unit. The service technician must also heed the contents of the service instructions, installation instructions, and operating instructions. Target group The target group for this manual is trained qualified personnel entrusted with the technical functioning and operation of the unit. Figures All figures in this manual are intended as examples. Discrepancies can arise between this and the actual unit.

1.2 General information The purpose of maintenance is to prevent a later unit defect due to unfavorable preconditions. The most frequent cases generally occur due to heavy soiling or penetrating moisture.

1.3 Maintenance interval

10013865-0AWAE—

We recommend performing maintenance every 12 months in order to guarantee a long life span. With a heavier use, a maintenance interval of 6 months is recommended.

Maintenance instructions

5

Safety instructions

2 Safety instructions For servicing tasks, the service technician must be familiar with and observe regional regulations. In addition, the notes in the service manual must be observed. DANGER Risk of personal injury and property damage from electric shock • Inspection and adjustment work that can be carried out only with the housing open and the unit under power must be performed only by electrically trained qualified personnel. DANGER Risk of explosion and fire from leaking, gas-conducting parts • Check the gas connection line and all gas-conducting parts for leakage tightness at the operating pressure. • Use only bubble-forming agents and gas leak detectors approved for use with gas.

10013865-0AWAE—

DANGER Risk of fatal injury from gas ü Disconnect the unit from gas supply prior to performing gas installation tasks. • Lock site gas supply and secure it against restart.

6

Maintenance instructions

Maintenance schedule

3 Maintenance schedule 3.1 Company performing the work Service company performing the work Service company performing the work: ________________________________________________ Service technician performing the work: ____________________________________________ Street, no.: ___________________________________ Postal code, city:_______________________________________ Telephone: _______________________________________________

3.2 Customer data Customer data Commission: ________________________________________________ person: ____________________________________________ Street, no.: ___________________________________ Postal code, city:_______________________________________ Telephone: _______________________________________________

3.3 Unit data Unit data Designation: __________________________________________________ Type number:__________________________________________________ Serial number: _____________________________

3.4 Water connection Step

Description

OK Yes

1

Check water filter (if present).

2

Only if the unit is operated on a water filter:

No

Determine building-side water hardness and compare to filter setting.

10013865-0AWAE—

If the water filter supplies only the combi steamer, the water capacity can be stored in the unit software. 3

Check lines and connections for leaks.

4

For a calcified unit, remove building-side water connections and check sieves; clean if necessary. Heed installation specifications!

Comments / Miscellaneous:

Maintenance instructions

7

Maintenance schedule

3.5 Chassis and cooking chamber Step

Description

OK Yes

1

Is the unit levelled?

2

Check door seal for damage and to ensure it does not leak. If necessary, replace door seal and adjust cooking chamber door.

3

Only for 20.x pedestal units: check profile seal on the cooking chamber door for damage and to ensure that it does not leak. Replace if necessary.

4

Check cooking chamber, fan, heating element, and water supply pipe for calcification and remove calcium deposits if necessary.

5

Only for 6.x, 10.x tabletop units: check WaveClean cartridge holder. It must be aligned horizontally.

6

Check hand shower and hose for leaks and function.

7

Unlock and open control . Check control for leaks and close. The control locks noticeably at multiple points.

8

Check operating foil on the on/off switch for damage.

9

Check core temperature sensor for damage.

10

Check cooking chamber sensor and protective basket for damage and deposits.

11

Check air intake area for soiling and clean if necessary.

12

Check cover of USB interface for damage.

13

Check the steam outlet nozzle and connected piping for deposits. If necessary, clean according to instructions.

No

10013865-0AWAE—

Comments / Miscellaneous:

8

Maintenance instructions

Maintenance schedule

3.6 Component check Step

Description

OK Yes

1

Cooking chamber light

2

Cooling fan (the number of cooling fans varies depending on the unit variant)

3

Air inlet flap / solenoid

4

DynaSteam²

5

Magnetic valve water vapor elimination

6

WaveClean drain pump

7

WaveClean circulation pump

8

Check cooking chamber motor for noise development (bearing damage).

9

Check electrical s for arcing spots and overheating

10

Check unit for moisture/residual water

No

Comments / Miscellaneous:

3.7 Software Software information In the course of maintenance, we recommend determining the software installed on the unit and if necessary, performing an update. Software version present on the unit before update: Software version present on the unit after update:

10013865-0AWAE—

Comments / Miscellaneous:

Maintenance instructions

9

Maintenance schedule

3.8 Expected maintenance on gas units Step

Description

OK Yes

1

Does the information on the gas type supplemental label match the gas type available?

2

Gas type present Natural gas:

No

Liquefied gas (LPG):

E/H, G20, 20 mbar

B/P, G30/G31, 50 mbar

LL/L, G25, 20 mbar

B/P, G30/G31, 30 mbar

L, G25, 25 mbar Other gas type: ________________________ Connection pressure: ________________________ mbar 3

Gas connection line leak-free?

4

Gas-conducting parts inside the unit leak-free?

5

Static pressure (connection pressure) OK? Static pressure: ________________________ mbar

6

Dynamic pressure (flow pressure, unit operation under full load) OK? Dynamic pressure: ________________________ mbar

7

Exhaust values with high output with CO2 Gas calibration OK? measured CO2: __________ Vol % measured CO2: __________ Vol % (lower burner, only for pedestal unit 20.x)

8

set CO2: __________ Vol % set CO2: __________ Vol % (lower burner, only for pedestal unit 20.x)

Exhaust values with low output with CO2 Gas calibration OK? measured CO2: __________ Vol % measured CO2: __________ Vol % (lower burner, only for pedestal unit 20.x)

set CO2: __________ Vol % set CO2: __________ Vol % (lower burner, only for pedestal unit 20.x)

Comments / Miscellaneous:

The maintenance work was performed by:

Installer

Place, date

Signature

10013865-0AWAE—

Company

10

Maintenance instructions

Information about the maintenance schedule

4 Information about the maintenance schedule 4.1 Water connection Step

Description

1

Check remaining capacity of water filter. If necessary, perform maintenance.

2

The capacity of the water filter can be stored on the Service menu. When the capacity set has been reached, a note appears.

4

The sieves are on the connections for raw water and soft water. Clean or replace sieves. Do not operate unit without sieves.

4.2 Chassis and cooking chamber Step

Description

1

Align tabletop units with the unit feet. Align pedestal units without EasyIn move-in system according to the tray trolley. Align pedestal units with EasyIn according to installation instructions. In addition, check roller bearing on tray trolley.

2

Replace defective door seals. Escaping steam and heat can cause damage.

3

The profile seal can be damaged due to incorrect unit alignment or lacking care. Always move the tray trolley in completely before closing the cooking chamber door.

4

Unlock air diverter and unfold. Remove calcium deposits according to operating instructions. Dismount the water intake pipe and also remove the calcium deposits

5

Bent cartridge holders affect the cleaning behavior of the WaveClean automatic cleaning.

8

Replace damaged foil immediately. Danger due to penetrating moisture.

10

Deposits on the protective basket affect the temperature measurement and change the cooking results.

11

Deposits in the air intake area under the unit must be removed with a brush and cleaning agent. A clogged air intake area causes an overheating of the control.

12

Replace damaged cover immediately. Danger due to penetrating moisture.

13

Examine steam outlet nozzles (exhaust pipe) for deposits with a flashlight. If necessary, clean cold unit with spray bottle and liquid cleaner. Use a liquid cleaner containing at most 20% sodium or potassium hydroxide. Spray the steam outlet nozzles completely with the spray bottle and allow to work. Rinsing with water is not necessary.

4.3 Component check

10013865-0AWAE—

Step

Description

1

Ensure function of the cooking chamber light. Replace defective light bulbs.

2

Start unit in any cooking mode. All cooling fans must be active.

3

Activate relay K8 via the relay test on the service menu. The solenoid is activated. Remove lower clamp from the silicone hose and push hose upward. Check seal of solenoid for damage and soiling. If necessary, replace seal.

4

Check DynaSteam steaming unit using the DynaSteam test on the service menu. -> See also service instructions.

5

Activate relay K4 via the relay test on the service menu. The magnetic valve water vapor elimination is active.

6

Check both pumps using the WaveClean test on the service menu. -> See also service instructions.

7

Maintenance instructions

11

Information about the maintenance schedule

Step 10

Description Start unit in the steaming cooking mode. Check unit from the left and right side for leaks.

4.4 Software Locate installed software version using the unit information on the service menu. If necessary, perform the software update using the service menu. New versions can include function expansions and eliminate errors.

4.5 Expected maintenance on gas units Step

Description

7

Check CO22 exhaust values via the CO2 settings on the service menu. If necessary, perform CO2 calibration with help of the document "Gas orifices & fan speeds". -> See also installation instructions. The specified CO2 exhaust values must be adhered to according to applicable safety regulations. Exhaust values that are outside the specifications can cause a non-optimal burning process and reduce the life span of the gas heat exchanger.

10013865-0AWAE—

8

12
