SPM TRIAL EXAMINATIONS 2017 2017
English Version Test Paper Kertas soalan versi Bahasa Inggeris
August
4531/2
KERTAS PERCUBAAN SIJIL PELAJARAN MALAYSIA
2017
PHYSICS PAPER 2: Structure and Essay Questions
2 hours and 30 minutes 2 ½ hours
QUESTION BOOKLET CANDIDATE NAME
CLASS
CANDIDATE’S CODE
READ THIS INSTRUCTION FIRST Write your candidate name, centre number and candidate number on the space given. Write your answer in your answer booklet given with dark blue ball pen or black ball pen. The questions booklet is in English Language. Candidates are required to read the following information: 1. The question paper consists of Section A, Section B and Section C. 2. Answer all the questions in Section A. Write your answers for Section A in the spaces provided in question paper. 3. Answer one question in Section B and one question in Section C. 4. Show your working, it may help you to get marks. 5. The diagrams in the question provided are not drawn to scale unless stated. 6. The marks allocated for each question or sub-section of a question are shown in brackets. 7. If you wish to cancel any answer, nearly cross out the answer. Then write down the new answer. 8. A list of formulae is provided on next page. 9. You may use non-programmable scientific calculator. However, steps in calculation must be shown. 10. The time suggested to complete Section A is 90 minutes, Section B is 30 minutes and Section C is 30 minutes. This document has 8 printed pages PRINTED IN SINGAPORE.BASED ON CURRICULAR SYSTEM OF MALAYSIA.
2 The following information maybe useful. The symbols have their usual meaning. 1. 2.
vu t 1 s ut at 2 2
a=
3.
v 2 u 2 2as
4.
Momentum = mv
5.
F =ma
6.
F kx
7.
Gravitational potential energy = mgh
8.
Kinetic energy =
9.
Elastic potential energy =
10.
g = 10 m s-2
11.
12.
Pressure, P
13.
Heat, Q = mcƟ
14.
1 2 mv 2
1 1 Fx kx2 2 2
m v F A
pV cons tan t T
15.
E = mc2
16.
v f
17.
Power, P
18.
1 1 1 f u v
19.
energy time
ax D
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
3
20.
n
sin i 1 , n sin r sin c
21.
n
real depth apparent depth
22.
Q = It
23.
V = IR
24.
Power, P = IV
Power, P
25.
N s Vs N p Vp
26.
Efficiency =
V
2
R
I sV s 100% I pV p
27.
c = 3.0 x 108 m s-1
28.
g = 10 m s-2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
4 Section A (60 marks) Instruction: Answer all the questions. 1. The Diagram 1 shows a micrometer screw gauge that can be used to measure diameter of a pencil
3 Diagram 1/Rajah 1 (a)
Label the part that is called spindle with the letter (X) [1 mark]
(b)
Identify the sensitivity of above micrometer screw gauge.
.................................................................................................................................................. [1 mark] (c) If the zero error of a micrometer screw gauge is (− 0.03), what is the diameter of the pencil?
(d)
................................................................................................................................................ [1 mark] Name one type of error that must be avoided when taking the readings. .................................................................................................................................................. [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
5 2
Diagram 2 shows a simple electromagnet used for lifting and releasing a small metal ball.
Diagram 2 (a)
Mark the direction of the current flow in Diagram 2, when the switch is on. [1 mark]
(b)
(c)
(i)
Name the material used for the core.
(ii)
...................................................................................................................... [1 mark] Give your reason.
(i)
........................................................................................................................ [1 mark] Name the magnetic pole at the end of the core P when the switch is on.
(ii)
.......................................................................................................................... [1 mark] Based on Diagram 2, draw the magnetic field lines that is form around the solenoid when the switch is on. In your diagram show the direction of the magnetic field lines. [1 mark]
(iii) State the rule used to determine the pole of the magnetic field.
.......................................................................................................................... [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
6 3
A student is trying to make a device to enable him to see objects behind him. He cuts a square box in half diagonally and sticks two plane mirrors on the inside of the box. A side view of the arrangement is shown in figure 3.1.
Figure 3.1
(a)
Name the phenomenon involved in the formation of the image. ............................................................................................................................. [1 mark]
(b)
State one characteristic of the image form by plane mirror. ............................................................................................................................. [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
7
Figure 3.2
(c)
Figure 3.2 shows parallel rays from two different points on a distant object behind the student. (i)
Complete the ray diagram to show how the image is formed. [3 marks]
(ii)
Based on answer in 3(c)(i) , what can be said about the image formed. ………………………………………………………………………… [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
8 4 Diagrams 4.1 and 4.2 shows two biased conditions which occur at a diode.
Diagram 4.1
Diagram 4.2
a) State the biased conditions which occur in Diagram 4.1 and 4.2. i.
Diagram 4.1
ii.
Diagram 4.2 [2 marks]
b) Name the types of semiconductors used in section X and section Y. i.
Section X
ii.
Section Y [2 marks]
c) (i) The circuit in which diagram can light up the bulb? [1 mark] (ii) Explain how the bulb in (c) (i), lights up. _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ [3 marks] 4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
9 5. Figure 5.1 shows two metals P and Q heated until a temperature 90 oC . P and Q are then transferred into two containers X and Y respectively. Both the metal P and Q have the same mass. The volume of water in container X and Y are same. The initial temperature of the water is 30 0C. [Assume no heat is lost to the surroundings]
Figure 6.1/ RAJAH 6.1 Diagram 5.1 Diagram 5.2 shows the graph of the temperature of water against time in containers X and Y.
Figure 6.2/ RAJAH 6.2 Diagram 5.2 (a) What is meant by temperature? _____________________________________________________________________ [1 mark] (b)
Base on the figure 5.1 , compare the surface area of metal P and Q.
_____________________________________________________________________ [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
10
(c) Based on the figure 5.2, compare the time taken by the water in containers X and Y to become constant. ________________________________________________________________________ [1 mark] (d) (i) Base on your answer in (b) and (c), state the relationship between the surface area and the time taken by the temperature of the water to become constant. ______________________________________________________________________ [1 mark] (ii) Give a reason why the temperature of the water become constant. ______________________________________________________________________ [1 mark] (iii) Name the physics concept that causes the temperature of water to become constant.
6.
______________________________________________________________________ [1 mark] A student carries out an activity to record the temperature change of oil and water. Both liquids are heated by identical heaters for two minutes. The initial temperature of oil o and water are 30 C. thermometer
1kW heater
1kW heater
water
oil
Measuring scale
Diagram 6.1
Diagram 6.2 4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
11 (a)
Name the condition in which the temperature of the water is equal to the temperature of the thermometer. ..................................................................................................................................... [1 mark]
(b)
Observe Diagram 6.1 and Diagram 6.2. Compare, (i) the mass of oil and mass of water.
....................................................................................................................... [1 mark] (ii) the temperature change in oil and also in water. .................................................................................................................................. [1 mark] (c) (i) Compare the amount of heat supplied by the heater to the oil and to the water. .................................................................................................................................. [1 mark] (ii) Compare the amount of heat absorbed by oil and water. .................................................................................................................................. ..................[1 mark] (iii) Name the physical quantity that will explain the comparison you made in5(b)(ii). ......................................................................................................................................... [1 mark] d) If the heating time is increased to 5 minutes, will there be any change in the physical quantity in (c)(iii)? Explain your answer. .................................................................................................................................................... .................................................................................................................................................... [2 marks]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
12 7
Diagram 7.1 shows an athlete in a heavy weight event. The mass he achieved to lift is 60 kg. Diagram 7.2 shows an officer walking with a bag of mass 5 kg
2.0 m
DIAGRAM 7.1
DIAGRAM 7.2
(a) (i) What is the weight lifted by the athlete?
[1 mark]
(ii) What is the work done for lifting that mass?
[2 marks] 4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
13
(iii)
Explain why no work is done for the situation in Diagram 7.2 .................................................................................................................................. .................................................................................................................................. .................................................................................................................................. [2 marks]
(b) Diagram 7.3 shows a staircase used by three students in an experiment at school. Time taken for the students to be at position P are shown in Table 7.1
12.0 m
DIAGRAM 7.3
Student A B C
Mass (kg) 65 80 55
Time taken to reach P (s) 55 50 40 TABLE 7.1
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
14 (i) Calculate the power for each student. Student A / Pelajar A :
Student B / Pelajar B:
Student C / Pelajar C :
[3 marks]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
15 (ii)
Does the student with a shorter time taken has more power? Give a factor which influences the power of a student in the above experiment ................................................................................................................................. .................................................................................................................................. [2 marks]
8
Diagram 8.1 and Diagram 8.2 show circuits consist of three identical bulbs arranged in two different ways. Each bulb has resistance of 4Ω.
Diagram 8.1 Diagram 8.2
a. (i) Name the circuits arranged in Diagram 8.1 and Diagram 8.2. ………………………………………………………………………………………… ………………………………………………………………………………………… [2 marks]
(ii) Calculate the effective resistance in each diagram.
[3 marks] 4531/2 SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
16 b.
(i) State which circuit will produce greater brightness of the bulb. ………………………………………………………………………………………… [1 mark] (ii)
Give two reasons for your answer in b (i).
………………………………………………………………………………………… ………………………………………………………………………………………… [2 marks] c. Diagram 8.3 shows the illuminating torch light.
Diagram 8.3
It is found that the torch light is not bright enough even when new cells are used. A modification is required to make it light brighter. Suggest the modification that needs to be done through these aspects: i. Number of cells ………………………………………………………………………………………… [1 mark] ii. The way the cells are arranged ………………………………………………………………………………………… [1 mark] iii. Internal resistance of the cell …………………………………………………………………………………………………… [1 mark] 4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
17 Give a reason. …………………………………………………………………………………………………… [1 mark]
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
18 Section B (20 marks) Instruction: Answer one question only 9. The Diagram 9.1 and Diagram 9.2 two types of aircraft with different sizes.
Diagram 9.1 Diagram 9.1 shows the world largest commercial aircraft, Airbus A380.
Boeing 777-300ER
Diagram 9.2 Diagram 9.2 shows the commonly used commercial aircraft, Boeing 777-300ER.
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
19 Table 9.1 shows the specification of Airbus A380.
Airbus A380 Typical Seating
555 engers
Maximum Take-off Weight
560,000kg (1,234,600lb)
Maximum Landing Weight
386,000kg (850,984lb)
Maximum Zero Fuel Weight
361,000kg (795869lb) Table 9.1
Table 9.2 shows the specification of Boeing 777-300ER.
Boeing 777-300ER Typical Seating
365 engers
Maximum Take-off Weight
351,533 kg (775,000 lb)
Maximum Landing Weight
251,290 kg (554,000 lb)
Maximum Zero Fuel Weight
167,829 kg (370,000 lb)
Based on the diagram, (a) Name the principle used in aircraft when flying. (1 mark) (b) Compare the size between the aircraft, the number of engers, the number of engines and the size of wings. (4 marks)
(c) The conventional wings is used in Boeing 777-300ER but not used in Airbus A380. Explain why there is the different in design of the wings of both aircraft. (5 marks)
4531/2
SINGAPORE PRINTED BY: SWANS PRINTING PTE LTD
20 (d) There are some important aspects need to be considered when deg an aircraft. Suggest some important specification of an aircraft which can carry a large number of engers. Your suggestions must include the following aspects: (i)
The number and size of engine
(ii)
The design of wings
(iii)
The design of the body of aircraft
(iv)
ways to maintain the air pressure inside aircraft
(v)
size of body of an aircraft
