vag immo emulator white immo box

VAG IMMO EMULATOR Very old project, but sometimes useful : immobilizer emulator for VAG cars. Currently, VAG immo emulator is the fastest, easiest and cheapest solution in case defect the Immobilizer unit in old VAG cars ( 1995 to about 2000/2001 IMMO1 and IMMO2 ). Presented solution we use more than ten years; It has some drawbacks but is simple, tested and working. Project based on AT89C2051 microcontroller and can be modified in many ways. Working module, in the basic version, you can build within several minutes.

Hot

price drop

VAG IMMO EMULATOR SCHEMATICS V.1

Component list :

Cx : 10uF R2 : 100k R1, R2 : 10k Trigger : 74HC14

Microcontroller : AT89C2051 X1 ( crystal oscillator ) : 11.0592MHz Transistor : simple NPN transistor. For example BC547 LED indicating: will turn off if module properly working

www.transpondery.com/projects/vag-immo-emulator.html

1/5

26/04/2019

TRANSPONDERY.COM > VAG IMMO EMULATOR - SCHEMATIC AND DUMP

THE SIMPLEST SCHEME FOR VAG IMMO EMULATOR V.2

Component list :

R2 : 4.7K R1, R3, R5 : 10K Microcontroller : AT89C2051 X1 ( crystal oscillator ) : 11.0592MHz Transistor : simple NPN transistor. For example BC547 Cx : 220nF ( can be changed for proper communication via K-Line ) LED indicating: will turn off if module properly working

Program dump for VAG Immo Emulator you can here ( rar compressed, : TRANSPONDERY.COM )

PCB Fab and Assembly PCB Fab & Assembly. Low price, High Quality, On Time, No Moq, No NRE. Online order now!

e den Opera Browser opera.com Schnell, Sicher, Intelligenter Der Opera Browser mit kostenlosem VPN, Ad Blocker und Energiesparmodus! ÖFFNEN

www.transpondery.com/projects/vag-immo-emulator.html

2/5

26/04/2019

TRANSPONDERY.COM > VAG IMMO EMULATOR - SCHEMATIC AND DUMP

VAG IMMO EMULATOR V.1

VAG IMMO EMULATOR V.1

ASSEBLED MODULE '2001

PCB '2001

VAG IMMO EMULATOR V.2 ASSEBLED MODULE '2001

VAG IMMO EMULATOR V.2 PCB '2001

IMMOBILIZER EMULATOR INSTALLATION GUIDE FOR AUDI A4, A6, A8 WITH WHITE AND BLACK IMMO BOX Immobilizer 4A0953234, 4B0953234, 8D0953234 and others.

9 : W Line 10 : K Line 11 : GND ( terminal 31 ) 12 : +12V ( terminal 15 ) - disconnect the immobilizer - connect W-Line ( pin 9 ) with K-Line ( pin 10 ) in wiring connector and connect it to K-Line in immobilizer emulator - connect GND ( pin 11 ) with GND in immobiliser emulator - connect IGNITION ( pin 12 ) to +12V in immobilizer emulator

www.transpondery.com/projects/vag-immo-emulator.html

3/5

26/04/2019

TRANSPONDERY.COM > VAG IMMO EMULATOR - SCHEMATIC AND DUMP

IMMOBILIZER EMULATOR INSTALLATION GUIDE FOR VW, SEAT, SKODA WITH 6-PIN IMMO BOX ( IMMO 1 ) Immobilizer 1H0953257, 5WK4678, 7M0953257, 5WK477, 5WK4634 and others.

1 : +12V ( terminal 15 ) 2 : K Line 3 : W Line 4 : GND ( terminal 31 ) 6 : GND ( terminal 31 ) - disconnect the immobilizer - connect W-Line ( pin 3 ) with K-Line ( pin 2 ) in wiring connector and connect it to K-Line in immobilizer emulator - connect GND ( pin 4 and pin 6 ) with GND in immobiliser emulator - connect IGNITION ( +pin 1 ) to +12V in immobilizer emulator

IMMOBILIZER EMULATOR INSTALLATION GUIDE FOR VW, SEAT, SKODA WITH 8-PIN IMMO BOX ( IMMO 2 ) Immobilizer 6HO953257, 5WK47740, 7M0953257, 5WK48080 and others.

1 : +12V ( terminal 30 ) 2 : +12V ( terminal 15 ) 4 : GND ( terminal 31 ) 5 : GND ( terminal 31 ) 7 : W Line 8 : K Line - disconnect the immobilizer - connect W-Line ( pin 7 ) with K-Line ( pin 8 ) in wiring connector and connect it to K-Line in immobilizer emulator - connect GND ( pin 4 and pin 5 ) with GND in immobiliser emulator - connect IGNITION ( +pin 2 ) to +12V in immobilizer emulator

www.transpondery.com/projects/vag-immo-emulator.html

4/5

26/04/2019

TRANSPONDERY.COM > VAG IMMO EMULATOR - SCHEMATIC AND DUMP
