SINUMERIK FM-NC Software Version 3 Configuring, Manuals NCU 570 and FM 354 Manual

Manufacturer/Service Documentation

04.96 Edition

SINUMERIK FM-NC Software Version 3 Configuring, Manuals NCU 570 and FM 354

Manual

Manufacturer/Service Documentation

Valid for

Control SINUMERIK FM-NC

04.96 Edition

Software version 3

Configuring

PJ

NCU 570

NC

FM 354

FM

Declaration of Conformity

A

Abbreviations

B

References

C

Preface Notes for the reader

The SINUMERIK documentation is organized in three parts:

General Documentation Documentation Manufacturer/Service Documentation For more detailed information on SINUMERIK FM-NC publications and other publications covering all SINUMERIK controls, please your local SIEMENS office.

Subject of the manual

The information contained in this manual enables s to install operator components units for the FM-NC numerical control and carry out proper care and maintenance.

Target group

Project planning engineers, electricians and fitters Servicing and operating personnel

SINUMERIK FM–NC, Software Version 3, Configuring, Manuals NCU 570 and FM 354

Preface

04.95 07.94 4

Definitions

Qualified Personnel In respect to this publication and warnings on the products themselves persons concerned with erection, installation and commissioning of the product should have the necessary knowledge and qualifications, e.g.:

Training or instruction and/or authorization in the switching on and off, earthing and marking of electrical ciricuits and devices in accordance with established safety practices.

Training and instruction in the proper care and use of protective equipment in accordance with established safety practices.

Instruction in First Aid.

!

!

!

!

Danger This symbol appears whenever death, severe bodily injury or substantial material damage will occur if the appropriate precautions are not taken.

Caution This symbol appears whenever minor bodily injury or material damage can occur if the appropriate precautions are not taken.

Warning This symbol appears, whenever death, severe bodily injury or substantial material damage could occur if the appropriate precautions are not taken.

Important This symbol appears in the documentation whenever attention has to be paid to something of particular importance.

Note ‘Note’ in the case of this publication refers either to important product information or a part of the publication to which particular importance should be paid.


Preface

04.95 07.94 5

Danger notes

!

The following notes are intended for your own personal safety and to prevent the described product and devices and machines connected to it from being damaged.

Warning Hazardous voltages are present in this electrical equipment during operation. Non-compliance with warnings and notes can result in severe bodily injury or material damage. Commissioning of this equipment may only be carried out by qualified personnel. These personnel must be well familiar with all warnings and maintenance measures in accordance with these operating instructions. Correct transport, storage, erection and mounting as well as careful operation and maintenance are essential for proper and safe operation of the equipment. During work on the plant dangerous axial movements can occur. In addition, national, regional and plant specific regulations are to be ad-hered to.


Preface

04.95 07.94 6

Further notes

!

Whenever measuring or testing jobs have to be carried out on live equipment, the regulations of Safety Code VBG 4.0 have to be observed, in particular § 8 “Permissible Deviations when Working on Live Parts”. Suitable electric tools should be used.

Warning

Repair on equipment supplied by our company may only be carried out by SIEMENS Service or repair stations authorized by SIEMENS. Any defective parts or components are only to be replaced by parts contained in the relevant spare parts list.

Disconnect the power supply before opening the equipment. Emergency Stop facilities according to EN 60204 IEC 204 (VDE 0113 Part 1) must remain operative in all operating modes of the automation equipment. Any disengaging of the Emergency Stop facility must not lead to uncontrolled or undefined restart.

Wherever faults occurring in the automation equipment can lead to substantial material damage or even grievous bodily injury, i.e. are potentially dangerous faults, additional external precautions must be taken or facilities must be provided ensuring or enforcing safe operation even when a fault occurs (e.g. independent limit switches, mechanical interlocks etc.).

!

Caution Connecting and signal lines must be installed so as to safely prevent inductive and capacitive interferences from affecting automation functions.

Note When installing, care should be taken that the connecting cables

are not damaged are not under tension do not come into with rotating parts.

!

Warning Correct transport, storage, erection and mounting as well as careful operation and maintenance are essential for proper and safe operation of the equipment. Non-compliance with warnings and notes can result in severe bodily injury or material damage.


Preface

ESD notes

04.95 07.94 7

Electrostatically Sensitive Components ESD are single components, integrated switches or modules, which during handling, testing or transportation can be damaged by electrostatic fields or electrostatic discharges. In English these parts are called ESDS (ElectroStatic Discharge Sensitive Devices). Handling of ESD devices:

When handling electrostatically sensitive components make sure that operator, workplace and packing material are properly earthed

Generally, electrostatically sensitive components must not be touched unless work has to be carried out on them.

Touch components of the equipment only if –

you are permanently earthed by means of an antistatic chain

–

you are wearing ESD boots or ESD boots with earthing strips in conjunction with an ESD flooring.

Modules may be set down only on electrically conducting surfaces (table with ESD top, conductive ESD foam plastic, ESD packing bags, ESD transport containers).

Keep modules away from visual display units, monitors, or TV sets (minimum distance from screen > 10 cm).

Modules must not be allowed to come into with electrically insulating materials such as plastic film, insulating table tops or clothing made of synthetic fibers.

Measurements on modules are allowed only if

Use for intended purpose only

–

the measuring instrument is properly earthed (e.g. equipment grounding conductor) or

–

before measuring with a potential-free measuring instrument, the probe is briefly discharged (e.g. touch the unpainted metal parts of the control housing).

The equipment may be used only for applications stated in the manual and only in conjunction with devices and components (e.g. SIMATIC S7) recommended and authorized by SIEMENS. The applications are described in: References:

/VS/, Technical Information.

addresses

Should any questions or problems arise in studying this manual, please the SIEMENS office concerned using the form provided at the end of this manual.

Hotline

In case of queries, please : Test Hotline, SIN FM-NC

++49 / 9131 - 63104 or ++49 / 911 - 895 - 7000

Configuring (PJ)

PJ

Contents 1

2

3

Fundamentals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9

1.1

System landscape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9

System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

14

2.1

System components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

14

2.2

Lettering and adhesive labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

18

2.3

Configuring the mechanical construction . . . . . . . . . . . . . . . . . . . . . . . . .

19

Power Supply Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

20

3.1 3.1.1 3.1.2 3.1.3 3.1.4 3.1.5

Ambient conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electromagnetic compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . Climatic and mechanical environmental conditions in operation . . . . . Conditions for transportation and storage . . . . . . . . . . . . . . . . . . . . . . . . Exposure to contaminants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Requirements for direct current supply . . . . . . . . . . . . . . . . . . . . . . . . . . Mains buffering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Detailed requirements for power supply . . . . . . . . . . . . . . . . . . . . . . . . . Earthing concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Measures for interference suppression . . . . . . . . . . . . . . . . . . . . . . . . . .

20 21 22 23 25 26 26 26 26 27 28 30 30 32 34 36 36

3.2.6

Installing and mounting the FM-NC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mounting the NCU 570 and FM 354 modules . . . . . . . . . . . . . . . . . . . . Connecting the power supply unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Connecting the drive unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Connecting drive units with ”10 V interface . . . . . . . . . . . . . . . . . . . . . . . Connecting stepping motor drive units . . . . . . . . . . . . . . . . . . . . . . . . . . . Mixed operation of drive units with ”10 V power supply and stepping motor interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Connecting the measuring systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wiring the front connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Connecting handwheels to the NCU 570 . . . . . . . . . . . . . . . . . . . . . . . . Connecting probes or proximity sensors (BEROs) to the NCU 570 . . Connecting the NC READY to the NCU 570 . . . . . . . . . . . . . . Inserting the backup battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

37 38 40 42 42 43 43

3.3

MPI connecting cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

44

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

45

4.1

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

45

4.2

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

46

4.3

NCU 570 battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

46

4.4

Replacing the NCU 570 or the FM 354 . . . . . . . . . . . . . . . . . . . . . . . . . .

48

3.1.6 3.1.7 3.2 3.2.1 3.2.2 3.2.3

3.2.4 3.2.5

4


Configuring (PJ) 1 Fundamentals

04.96 07.94 9

PJ

1

Fundamentals 1.1

System landscape

Operator (OP)

PG

Operator (OP)

PG

Machine control

Programming device

Machine control

Programming device

MPI

MPI 187.5 kbaud

1.5 Mbaud

SIMATIC S7-300

SIMATIC S7-300 I/Os

VSA VSA FDD FDD

SM

SM

IM

Communication bus I/O bus

Local I/O bus

Servo and/or stepping motor drives

21 kW

SM

SIMATIC-S7-300 Modular Packaging System

Communication bus I/O bus

I/R

SM

NCU 570

FM 354

SM

SM

SM

e.g. 24 V/5 A

SM

S7-300 PS 307

S7–300 U

SINUMERIK FM-NC

FDD MSD

FDD

21 A

7A

7A 2x7 A

Drive ±10 V servo drive

S7-300 IM I/O I/O I/O 318

NCU 571/572/ 573 and S7-300 16 kW U integrated I/R

3x 1x FDD MSD

2x5A 1x5A 21 A

SIMODRIVE Modular Packaging System

SINUMERIK 840D SIMODRIVE 611-A

SIMODRIVE 611-D

Performance

Fig. 1-1

SINUMERIK, SIMODRIVE and SIMATIC system landscape

The SINUMERIK FM-NC has been implemented as a function module of the SIMATIC S7-300.


Configuring (PJ) 1.1 System landscape

04.95 07.94 10

FM-NC

The SINUMERIK FM-NC is a low-priced automation product for machine tools of the lower performance range. It consists of a SIMATIC S7-300 automation system and an NCU 570 function module, both of the same modular packaging system with which up to four axes/spindles can be controlled. The system can be expanded to control a fifth axis/spindle with the FM 354.

SIMATIC S7-300

The automation system consists of a U and different input/output devices fixed on a mounting channel. The construction is of the single- or multi-tier type, depending on the configuration. One SIMATIC S7-300 U can control up to four tiers with a maximum of eight bus s each (see Figure).

PLC

The S7-300 U and the connected digital or analog signal modules (SMs) together form the PLC area of the control. The U 314 can control a maximum of 512 inputs or outputs. Positioning axes can also be integrated in the PLC area if the system includes the relevant function modules (FMs).

NCU 570

The NC area consists of the NCU 570. The NCU 570 communicates

with the SIMATIC S7-300 U via serial I/O and communication bus, with up to four stepping motor drives via a 10 V interface with a maximum of four servo drives and/or via pulse interfaces,

with incremental or absolute measuring systems via four measuring circuit interfaces and

with operator s (OP), programmers (PG) and machine control s (M) of different performance classes via the multi-point serial interface (MPI). A 20-way front connector with point-to-point connections is used to connect:

2 probes 4 sensing elements, e.g. non- sensors 2 handwheels If necessary, the NC area can be expanded by configuring the NCU 570 to control an FM 354 via a local bus. In addition, signal modules can be controlled (the maximum configuration per tier must not be exceeded) to implement additional NC-specific inputs/outputs on the local I/O bus.

FM 354

The FM 354 communicates as an axis expansion module

via serial I/O bus with the NCU 570 via a 10 V interface with a servo drive and via a servo loop interface with an incremental or absolute measuring system.

PJ



04.96 04.95 07.94 11

The following can be connected with a 20-way front connector with single-wire terminals:

4 digital inputs 4 digital outputs FM STEPDRIVE

For several applications, it is possible to implement feed axes with low cost stepping drives. FM STEPDRIVE is a performance control for 3-phase stepper motors up to 15 Nm (SIMOSTEP). FM STEPDRIVE is actuated via the drive interface of NCU 570.

PJ



04.96 04.95 07.94 12

PJ

Operator (OP)

PG Programming device

Machine control (M) MPI

I/O bus Tier 3

IM

SM

SM

SM

digital/ analog

digital/ analog

digital/ analog

SM

SM

SM

digital/ analog

digital/ analog

digital/ analog

24 V Communication bus I/O bus I/O bus

Tier 2

IM

Communication bus 24 V

SM

SM

SM

digital/ analog

digital/ analog

digital/ analog

SM digital/ analog

SM

SM

digital/ analog

digital/ analog

Communication bus Tier 1

IM

SM

SM

SM

SM

SM

digital/ analog

digital/ analog

digital/ analog

digital/ analog

digital/ analog

NCU 570

24 V Communication bus Tier 0

PS 24 V 2/5/10 A

SIMATIC S7-300 U

I/O bus

IM

SM

SM

digital/ analog

digital/ analog

NCU 570

Local I/O bus

FM 354

SM

MPI 24 V

Communication bus

Encoder

Encoder

Servo and/or ±10 V servo drive stepping motor drive

Fig. 1-2

SIMATIC S7-300 U with NCU 570



Power supply units

04.96 04.95 07.94 13

A power supply unit (PS 307) can be arranged to the left of the SIMATIC S7-300 U. It is connected to 230 V automating voltage on its primary side and provides 24 V direct voltage on its secondary side. The PS 307 can also be arranged in tiers 1 to 3 to the left of the IM module. The PS 307 is available in three versions:

S 24 V/2 A S 24 V/5 A S 24 V/10 A Single-tier construction

The single-tier construction consists of the S7-300 U, the NCU 570 and a maximum of seven modules (SM, FM). The SIMATIC S7-300 U drives all eight bus s and provides the logic power supply for their signal modules. The NCU 570 has its own power supply terminal for supplying its logic.

Multi-tier construction

In the multi-tier construction, an interface module (IM) must be arranged in tier 0 to the right of the S7-300 U. Beside the interface module, eight modules (SM, FM and the NCU 570) can be arranged. Tier 1 and each consecutive tier starts with an interface module (IM) and may incorporate another eight modules (SM, FM, NCU 570). Power supply to the logic is from the IM which has its own power supply terminal. One system may have a maximum of two NCU 570. In configuring the construction, the following parameters of the modules must be taken into :

S Mounting dimensions S Power inputs from 24 V S Power inputs from the 5 V I/O bus supply References:

Distributed arrangement

/S7H/, Manual

The multi-tier construction allows distributed arrangement of modules because the tiers can be connected by IM connecting cables with a maximum length of 10 m. For example, in the case of two-tier construction, signal modules can be arranged up to 10 m away from the NCU 570, in the case of four-tier construction up to 30 m.

Local P bus

The S7-300 U can usually address all 32 bus nodes via the serial I/O bus. However, the NCU 570 can interrupt this bus. This means that all modules positioned to the right of the NCU 570 can then only be addressed by the NCU 570 but not by the S7-300 U.

J

PJ


Configuring (PJ) 2 System Overview

04.96 07.94 14

PJ

2

System Overview

2.1

System components

Components

The complete FM-NC control consists of various individual components as listed in the Figure. Table 2-1 No. (see Fig. 2-1)

FM-NC components Component

Description

1

SIMATIC components

References: /S7H/, Manual

2

NCU 570.2

NC module

3

Operator

Display and keyboard for operating the control References: /BH/, Manual Operating and Monitoring References: /ST7/, Catalog ST 70

Operator OP 25 4

MMC submodule

Operator computer (to be installed in the operator ) MMC 101/102 with hard disk MMC 100 without hard disk References: /BH/, Manual

5

Machine control

Machine operation References: /BH/, Manual

6

ISA adapter

Allows AT modules to be used in conjunction with the MMC submodule MMC101/102 (to be installed in the operator ) References: /BH/, Manual

7

CNC keyboard (QWERTY)

Full keyboard connectable to an MMC submodule References: /BH/, Manual

8

Disk drive unit (accessory)

Built-in device to be connected to the MMC submodule References: /BH/, Manual

Connecting cable

References: /Z/, Catalog Accessories NC Z

15

SIMODRIVE components

References: /PJ1/, Planning Guide

16

FM 354 as axis expansion

Positioning module for a drive with analog setpoint interface

17

FM STEPDRIVE

Power Control for stepping drive References: /FBST/, Description of Functions

9 to 14


Configuring (PJ) 2.1 System components

04.96 07.94 15

8

PJ

Disk drive unit 6

MMC

4

Operator

3 9 5

Machine control

11 CNC keyboard

7

10

1

2 16 DIN rail

SIMATIC bus PS

17

U 314 IM

SM

SM

NCU 570 FM 354 FM STEPDRIVE

15

12

14

Measuring (2x) Handwheel (2x)

13 Incremental encoder with RS 422

ROD 320 (built-on encoder with 1FT5 motor) SIMODRIVE

SSI absolute encoder

NE (I/R or UE) Fig. 2-1

MSD

System components

FDD

FDD

FDD

Linear scale with EXE



04.96 07.94 16

Disk drive unit1)


Parallel interface 1) e.g. printer/streamer

PG

V.24 cable data input/output X8 X10

MPI cable or MPI-PG cable

Operator (rear view)

X9

MPI connecting cable

Machine control

X2

SIEMENS

External 24 V power supply

MMC 101/102 X4

X6

U 314

X3

X4

X3

X5

X6

X2

FM 354

NCU 570 Axis 1...5

NCU 570 setpoint cable

FM 354 setpoint cable Measuring system cable

SIMODRIVE 611-A

Incremental encoder with RS 422

Handwheel 1

ROD 320 (builton encoder in 1FT5 motor)

Probe 1

Handwheel 2

Probe 2


SIEMENS SIMODRIVE

I/R

Connecting cable to handwheel

MSD

FDD FDD

FDD FDD

Linear scale with EXE 1) X8/X9 with MMC 101/102 only

Fig. 2-2

Overview SINUMERIK FM-NC connecting cables with servo drives

PJ



04.96 07.94 17

Disk drive unit1)


Parallel interface 1) e.g. printer/streamer

PG

V.24 cable data input/output X8 X10

MPI cable or MPI-PG cable

Machine control

X2

SIEMENS

X3

X4

X5

X6

SIEMENS

SIEMENS

FM STEPDRIVE

NCU 570

Handwheel 1

Probe 1

Handwheel 2

Probe 2

Connecting cable to handwheel

NCU 570 setpoint cable

1) X8/X9 with MMC 101/102 only

Fig. 2-3

X4

X9

MPI connecting cable

U 314 External 24 V power supply

MMC 101/102 X6

Overview SINUMERIK FM-NC connecting cables with stepping drives

Operator (rear view)

PJ


Configuring (PJ) 2.2 Lettering and adhesive labels

2.2

04.96 07.94 18

Lettering and adhesive labels

PJ

When ing your local SIEMENS office for enquiries or necessary servicing do not fail to state all specifications given on the type plate. The modules NCU 570 and FM 354 are provided with one of the following labels:

NCU 570, FM 354

Example:

Component name: NCU 570.2 MLFB: 6FC5 357-0BH00-0XE1 Component number: 2GE.570037.9006.00 Product version: A

)

))

000.000.001 570037.9006.00 )' %! !" #% "&$ %(


Configuring (PJ) 2.3 Configuring the mechanical construction

2.3

04.96 07.94 19

Configuring the mechanical construction

NCU 570 in the S7-300

PJ

The NCU 570 is installed in the SIMATIC S7-300 control as a function module. Adding the U 314 and input/output modules makes up the FM-NC control. Regarding the S7-300-U the NCU 570 behaves as a function module (FM).

Configuring the mechanical construction

The manual “SIMATIC S7; S7-300 Automation System; Configuring an S7-300” tells you which possibilities there are for configuring the mechanical construction and how to proceed. References:

/S7H/, Manual

Some additional information supplementing the instructions in the manual is given below.

Mounting position

Preference should be given to the horizontal mounting position. For the vertical mounting position, the necessary limitation of ambient temperatures should be taken into (maximum 40 °C).

Points to be observed when configuring the mechanical construction

When configuring the mechanical construction of your control which determines the mounting location of the NCU 570, the following rules should be followed: 1. A maximum of eight SMs or FMs (including the NCU 570 and FM 354) can be mounted in each tier. 2. This maximum number may be restricted by the width of the modules or the length of their mounting channel. The NCU 570 requires a mounting width of 200 mm, the FM 354 80 mm. 3. The maximum number is also restricted by the sum of the power input of all modules to the right of the U from the 5 V backplane bus supply. The U 314 can supply up to 1.2 A. The NCU 570 and the FM 354 each require 100 mA.

Installation of FM STEPDRIVE

The FM STEPDRIVE modules can be installed in addition to the eight SMs or FMs. They are not connected to the SIMATIC bus, therefore only the installation width required must be taken into .

J


Configuring (PJ) 3 Power Supply Conditions

07.94 20

PJ

Power Supply Conditions

3.1

3

Ambient conditions

Compliance with power supply conditions

The SINUMERIK FM-NC control is structured for compliance with the following ambient conditions. Trouble-free operation is guaranteed only if:

These ambient conditions are complied with in operation and transportation. Original components and spare parts are used. This applies in particular to the use of specified cables and plug connectors.

Mounting is carried out properly. Starting up is not permitted until compliance with the 89/392/EEC Directive has been established.

!

!

Warning In the operational state, the equipment offers protection against direct in accordance with DIN VDE 0160, Sections 5.5 and 6.5 (specifications concerning the suitability for installation in closed electrical operating areas).

Warning To ensure safe operation of the equipment, it must first be installed and started up properly by qualified personnel, observing the warnings given in the Instruction Manual. In particular, attention must be paid to the general installation and safety rules for work on power systems and equipment (e.g. DIN VDE), to the correct application of lifting equipment and tools, and to the regulations relating to the use of personnel protective devices (such as safety glasses). Death, serious bodily injury or substantial material damage can result from non-observance of these rules. The national installation codes of practice applicable to the country concerned must be observed.

Additional information

References:

Assistance and advice

Power supply conditions must be complied with for the whole installation. Please your local Siemens office or representative for assistance and advice.

/EMC/, EMC Guidelines


Configuring (PJ) 3.1 Ambient conditions

3.1.1

07.94 21

Electromagnetic compatibility (EMC)

Interference suppression

PJ

The plant operator is responsible for interference suppression of the entire installation (control, drives, sensors, actuators, machine etc.). The SINUMERIK FM-NC when installed complies with the requirements of limiting value class A according to EN 55011. Table 3-1

Interference suppression limit values Limit value in accordance with

Interference suppression in cables

Limit value class A for use in industrial areas

Radio interference irradiation

Limit value class A for use in industrial areas

As regards compliance with limit value class B (residential areas) please your local Siemens office or representative.

Immunity to noise

Immunity to rapid transient power distortions (burst) Test in accordance with IEC 801-4 –

Power supply cables (via coupler networks or coupling pincer): Test voltage: Test duration:

–

w 2 kV w 1 min

Signal cables: Test voltage: Test duration:

w 2 kV w 1 min

Immunity to static discharging Test in accordance with IEC 801-2 Test voltage:

w 8 kV discharging across air clearance w4 kV discharging across s

Immunity to high-frequency irradiation Test in accordance with IEC 801-3 Test field strength: Frequency:

w 10 V/m 26 - 1000 MHz



3.1.2

07.94 22

Climatic and mechanical environmental conditions in operation

Operating conditions Climatic environmental conditions

The FM-NC has been designed for sheltered and stationary use.

Table 3-2

Climatic environmental conditions

Temperature

0...60°C for horizontal mounting 0...40°C for vertical mounting

Dew-point temperature (td) and relative air humidity (U) annual average td

17°C

U

75 %

Dew-point temperature (td) and relative air humidity (U) on 30 days per year td

24°C

U

95 %

Dew-point temperature (td) and relative air humidity (U) on the remaining days td

20°C

U

85 %

Temperature variation Within one hour

v10 K

Within three minutes

v1 K

Atmospheric pressure

860...1080 hPa

Condensation

Mechanical environmental conditions

Table 3-3

not allowed

Mechanical environmental conditions

Vibratory load Test in accordance with IEC 68-2-6 Shock load Test Ea in accordance with IEC 68-2-27

Free fall

Frequency range 10 - 58 Hz exceeding 58 - 500 Hz

Constant excursion 0.075 mm Acceleration amplitude 9.8 m/s2

Acceleration

15g

Acceleration for visual display units

2g

Duration of nominal shock

11 ms / 30 ms for drive units

Unpacked

50 mm

When transported in original packing

500 mm

PJ



3.1.3

07.94 23

Conditions for transportation and storage

Transportation and storage

PJ

The following conditions apply to products transported and stored in original packing. Table 3-4

Climatic conditions for transportation and storage

Temperature

-40...70°C

Dew-point temperature (td) and relative air humidity (U) annual average td

17°C

U

75 %

Dew-point temperature (td) and relative air humidity (U) on 30 days per year td

24°C

U

95 %

Dew-point temperature (td) and relative air humidity (U) on the remaining days td

20°C

U

85 %

Temperature variation Within one hour

v10 K

Within three minutes

v1 K


660...1080 hPa

Brief and light condensation is acceptable under the following conditions:

Maximum duration of condensation: 3 hours Frequency of occurrence: Annual average 3, maximum 10 Shortest sequence of condensation cycles: 1 day The values specified apply to a transportation altitude of up to 3500 m above mean see level.



Transportation of backup batteries

07.94 24

Backup batteries have to be transported in original packing only. No special approval is needed for transporting backup batteries. The lithium proportion is approximately 300 mg. Note:

The backup battery is classified in dangerous-materials class 9 in accordance with the relevant air-freight transportation regulations.

Rules for handling backup batteries

!

Caution Improper handling of backup batteries involves the risk of ignition, explosion and burning. The following regulations must therefore be strictly adhered to:

Backup batteries

must not be charged heated or thrown into fires pierced or squeezed nor tempered with mechanically or electrically in any other way

PJ



3.1.4

07.94 25

Exposure to contaminants

PJ

Hazardous gases Table 3-5

Hazardous gases

Sulfur dioxide (SO2) Test in accordance with IEC 68-2-42 and 43

Hydrogen sulfide (H2S)

Test in accordance with

Severity

10 cm3/m3 0.3 cm3/m3

Temperature

25 °C 2 °C

Relative air humidity

75% 5%

Test duration

4 days

Severity

1 cm3/m3 0.3 cm3/m3

Temperature

25 °C 2 °C

Relative air humidity

75% 5%

Test duration

4 days

IEC 68-2-42 and 43

Hazardous dust

When working in areas where there is an unacceptably high dust burden, the control must be operated with heat exchanger or in a cabinet with suitable air intake. Additionally, an air filter should be used when carrying out servicing jobs with open cabinet door.

Clearances in air and creepage distances

It is the ’s responsibility to make sure that the requirements of contamination class 2 are complied with for clearances in air and creepage distances.



3.1.5

04.95 07.94 26

Power supply

PJ

Requirements for direct current supply

The 24 V direct voltage must be generated as a functional extra-low voltage with safe electric isolation (in accordance with the requirements of EN 60204-1, Section 6.4, PELV).

Mains buffering

The internal power supplies of the S7-300 U, the NCU 570, the FM 354, the IM 361 R and the IM 360 S identify power supply voltage dips < 18.5 V DC with a duration exceeding 5 ms as voltage failures and initiate safety measures leading to shutdown of the installation. To be able to cope with mains voltage dips > 5 ms the

SIMATIC S7 U, NCU 570, FM 354, IM 361 R, 24 V DC supply of the digital inputs and 24 V DC load voltage supply of the digital outputs should be fed from a common 24 V DC power supply which should be separate from the machine power supply and provided with suitable mains buffering. The PS 307 can cope with mains failures up to 20 ms duration.

Detailed requirements for power supply

Table 3-6

Requirements for power supply Direct current supply

Alternating current supply

Mains voltage

24 V DC "5 %

1AC 230 V

Voltage range (mean value)

20.4 V DC...28.8 V DC

1AC 184 V...1AC 253 V

Ramp-up time when powering up

v 100 ms

< 100 ms

Harmonic contents (in accordance with IEC 950 Section 6.5 and DIN VDE 0160, Section 5.3.1.2)

10 %

10 %

Non-periodic overvoltages Duration Restoration time Events per hour

v35 V v 500 ms w 50 s v 10

Short voltage dips Duration Restoration time Events per hour

< 18.5 V v 5 ms w 10 s v 10

< 184 V v 10 ms w 10 s v 10

Ripple/frequency

3.6 V

47...63 Hz



3.1.6

04.95 07.94 27

Earthing concept

Components and precautions

PJ

The FM-NC control is composed of several individual components each of which must be in accordance with EMC and the relevant safety standards:

Operator , consisting of monitor and MMC Machine control S7-300 with U and NCU 570 and FM 354 All load current circuits should be earthed to guarantee perfectly safe operation.

Earthed operation of S7-300

The reference potential (earth) of the S7-300 is earthed by means of a removable connection in the form of a jumper at the 24 V terminal block of the U. This jumper connects the ground (M) with the functional earth (PE) by making a low-resistance connection to the mounting channel. In the case of multi-tier construction, make sure that the earthing jumper is also fitted at all 24 V terminal blocks of the IM 361 R. The mounting channel is provided with an earth terminal for connection to the central earth bar inside the cabinet.

Mounting rail

Operator

U 314 MMC

S7-300 I/Os

NCU 570 FM 354

M

PA/SL

- Ground (frame) in the cabinet M M: G: PA: SL:

Machine control Motor Encoder Equipotential bonding Protective conductor

PA/SL

SL in motor cable

Drive unit

PA

Non-floating signal interface Floating signal interface

Fig. 3-1

Earthing concept

References:

/EMC/, EMC Guidelines

M

G



3.1.7

04.95 07.94 28

Measures for interference suppression In addition to the protective earthing of system components in accordance with VDE, special precautions must be taken to guarantee interference-free operation of the system. These measures include shielded signal cables, special equipotential bonding and earthing conductors.

Shielded signal cables

Only use specified cables according to the individual diagrams to ensure safe, interference-free operation of the system. As cable connectors the specified connector types only should be used. For signal cables, the shield must always have a conductive connection to both sides of the housings. Exceptions: 1. Standard shielded cables connected to one side only can be used for devices of other makes (printers, programmers, etc.). These devices must, however, not be connected to the control during normal operation. Whenever operation with devices of other makes is unavoidable, the shields must be connected to both housing sides. In cases like this, the device must additionally be connected to the control by means of an equipotential bonding conductor. 2. For analog signal (e.g. 10 V interface to the drive unit), one-sided connection of the shield to the control side should be preferred to suppress mains irradiation.

Cable definitions

Signal cables (e.g.) –

Setpoint and actual value cables

–

Data cables (MPI, sensor cables, etc.)

–

All NC power supply unit monitoring and control cables

–

EMERGENCY STOP cables

Load cables (e.g.) –

Low-voltage supply cables (+24 V DC etc.)

–

Mains supply cables (230 V AC etc.)

–

Supply cables to ors (primary and secondary circuit)

PJ



Installation of signal and load cables

04.95 07.94 29

In order to maintain the greatest possible noise immunity of the whole installation (control, power section, machine) the following EMC Guidelines must be observed:

The space between signal and load cables must be as great as possible. If necessary, signal and load cables can cross over (at an angle of 90°, if possible) but they should never run close together in parallel.

Signal cables from and to the NC and PLC should only be those offered by SIEMENS.

Signal cables must not be placed in the neighbourhood of strong external magnetic fields (e.g. motors and transformers).

High-current/high-voltage cables carrying pulses must always be led completely separate from all other cables.

If it is not possible to maintain an adequate distance between cables, signal cables must be shielded by laying them in cable ducts (metal).

The distance (interference irradiation area) between the following cables must be as small as possible:

!

–

Signal cable and signal cable

–

Signal cable and accompanying equipotential bonding conductor

–

Equipotential bonding conductor and protected conductor incorporated in the cable

Important Please refer to References: /EMC/, Manual for additional advice regarding interference suppression measures and the connection of shielded cables.

PJ


Configuring (PJ) 3.2 Installing and mounting the FM-NC

3.2

04.95 07.94 30

Installing and mounting the FM-NC For the mechanical and electric construction of the control, the rules and specifications for the SIMATIC S7-300 automation system apply. References:

3.2.1

/S7H/, Manual

Mounting the NCU 570 and FM 354 modules

Mounting procedure

Procedure for mounting the control: 1. Fit the mounting channel. 2. Fit the power supply unit PS 307 first, if you use one. 3. Fit the U 314 next. 4. Fit an IM module, if you require multi-tier construction. 5. A maximum of eight SMs or FMs can be fitted to the right of the U or IM. You can fit the NCU 570 in any of the eight possible slots. Please that modules that are operated on the local bus of the NCU 570 must be inserted to the right of this module. The maximum number of eight modules must not be exceeded. 6. If you are using an FM 354 for axis expansion, you must insert this module to the right of the NCU 570. 7. If you are using additional NC inputs/outputs on the local bus of the NCU 570, you must also insert the necessary SMs to the right of the NCU 570 or FM 354.

!

Important The slot determines the initial address of each module. For start-up, you set the address of the NCU 570 and the FM 354 in the PLC basic program according to the slot used. References:

Required tools

/IAF/, Installation and Start-up Guide /S7H/, Manual

4.5 mm screwdriver

PJ



Mounting the NCU 570

04.95 07.94 31

Procedure: 1. The NCU 570 is supplied with a bus coupler enclosed as loose part. Plug the coupler on the bus connector of the module to the left of the NCU 570. (The bus connector is located at the rear, you must loosen the module again, if necessary). 2. Fit the NCU 570 in the mounting channel and swing it downwards. 3. Tighten the NCU 570 (tightening torque approx. 80...110 Ncm). If further modules are to be mounted to the right of the NCU 570, you plug the bus coupler of the next module on the right backplane bus connector of the NCU 570 before fitting these modules. You do not plug on a bus coupler, if the NCU 570 is the last module of the tier!

Mounting the FM 354

Proceed as for mounting the NCU 570.

Further procedure

After mounting of the NCU 570 has been completed, you proceed as described in the next Sections:

Wire up the load current supply unit Connect the drive unit and the position encoder next Wire up the front connector Insert the backup battery Following this, the FM-NC can be started up. References:

/IAF/, Installation and Start-up Guide

PJ



3.2.2

04.95 07.94 32

Connecting the power supply unit

PJ

Note The NCU 570, the FM 354 and the S7-300 U should be connected to a common load current supply unit. Suitable supply units are, e.g., the S7-300 power supply modules PS 307 or other SIEMENS load current supply units (e.g. 6EP1 series). Otherwise, equipotential bonding between the supply units will be necessary.

Mains buffering

A mains buffering of 20 ms is guaranteed when you use the PS 307 supply unit.

L1 L2 L3 N PE

Low voltage distribution e.g. TNS system (3 x 400 V)

Mounting rail

PS 307

U

L N

PE M L+ M

M

NCU 570

L+ M

FM 354

L+ M

Earth bar inside cabinet Mounting rail U

NCU 570

FM 354

PE M

Earth bar inside cabinet AC D C

Fig. 3-2

L+ M

L+ M

L+ L–

Possibilities for power supply to modules

!

Warning Wire up the S7-300 when de-energized only!

L+ M

M



04.95 07.94 33

Use flexible cables having cross sections of 1.0...2.5 mm2 (or AWG 18... AWG 14).

Cables

Stripped cable length 12 mm Wire end sleeves are not required. You can also use wire end sleeves without insulating collars according to DIN 46228, Shape A, long version.

Wiring the NCU 570

Procedure: 1. Open the left front cover of the NCU 570. 2. Connect the flexible cable to the terminals of the screw terminal block. Make sure of correct polarity. 3. Fasten the cables using a 3.5 mm screwdriver, tightening torque approx. 60...80 Ncm. 4. Connect to the power supply unit (e.g. PS 307).

Note You can use the upper or lower pair of terminals. You can use the unassigned pair of terminals for power supply to input/output devices or power supply to subsequent modules.

Wiring the FM 354

Procedure: 1. Open the right front cover of the FM 354. 2. Connect the flexible cable to the terminals 19 and 20 of the front connector. Make sure that the polarity is correct. 3. Fasten the cables using a 3.5 mm screwdriver, tightening torque approx. 60...80 Ncm. 4. Connect to the power supply unit (e.g. PS 307). You can use the free pair of terminals of the NCU 570.

Reverse voltage protection

!

Important The module will not operate with incorrect polarity. The built-in reverse voltage protection prevents damage to the electronics. In the case of correct polarity and power supply ON, LED “5V DC” green will light.

Fuse

The built-in fuse will only blow, if there is a fault in the module. The module must then be replaced.

PJ



3.2.3

04.95 07.94 34

Connecting the drive unit

PJ

Note Use shielded and paired cables only. The shield must be connected to the metal or metal-plated connector housing on the control side. To keep away low-frequency interference from the analog setpoint signal, we recommend earthing the shield on the drive side. The prepared cable offered as an accessory affords optimum interference immunity.

The following figure displays the connection of NCU 570 and FM 354 to a SIMODRIVE 611-A-wiring drive unit.

X2

X3

X5

X4

X3

X6

X2

FM 354

NCU 570 Connecting cable

SIMODRIVE 611-A

SIEMENS SIMODRIVE

I/R Fig. 3-3

MSD

FDD

FDD

FDD

FDD

Connection of a SIMODRIVE 611-A drive unit



04.95 07.94 35

The following figure displays the connection of NCU 570 to FM STEPDRIVE drive units.

Axis 1 X2

X3

X4

X5

X6

NCU 570

SIEMENS

Axis 2 SIEMENS

Axis 3 SIEMENS

FM STEPDRIVE

Connecting cable

SIMODRIVE (main spindle drive)

Fig. 3-4

Connection of FM STEPDRIVE-drive unit

PJ



Connecting drive units with 10 V interface

04.95 04.96 07.94 36

Procedure: 1. Wire up the free cable end of the connecting cable at the terminals of the drive unit. (The terminal designations at the cable ends indicate the terminals to be used for SIMODRIVE units). 2. Open the front door and plug the D sub-connector on the module. 3. Lock the connector by means of knurled screws. Close the front door. Connecting cable for NCU 570 Prepared cable with integral connectors for four axes with anaterface, terminal designation for SIMODRIVE drive units. The connecting cable is available in different lengths. References:

/Z/, Catalog Accessories NC Z

Connecting cable for FM 354 Prepared cable with integral connectors for one axis with anaterface, terminal designation for SIMODRIVE drive units. The connecting cable is available in different lengths. References:

Connecting stepping motor drive units


Procedure: 1. Wire up the free cable end of the connecting cable at the terminals of a terminal distributor or prepare the cable with plug-in connectors according to the specifications of the manufacturer of the power section. Connect tot the drive unit. 2. Open the front door and plug the D sub-socket on the module. 3. Lock the connector by means of knurled screws. Close the front door.

!

Important Make sure that the signals are assigned with correct polarity. Refer to the Technical Documentation of your drive unit and to the NCU 570 Manual, Section 2.2.2 to make sure of correct interconnection.

References:

/FBST/, Description of Functions, FM STEPDRIVE

PJ



04.95 04.96 07.94 37

Connecting cable for NCU 570 Prepared cable with integral connectors for three stepping motor axes and one spindle axis with anaterface. The connecting cable is available in different lengths. References:

!


Important You can operate three stepper motors on axes 1 to 3 with this cable. Axis 4 is assigned to an anaterface.

Further cables, e.g. for four stepping motor axes available on request.

Mixed operation of drive units with 10 V power supply and stepping motor interface

Proceed as described for the connection of stepping motor drive units. Whether you install a terminal distributor or wire directly by preparing the connecting cable depends on the specific design conditions. Connecting cable for NCU 570 Prepared cable with integral connectors for three stepping motor axes and one axis with anaterface. The connecting cable is available in different lengths. References:

!


Important This cable assigns the anaterface to axis 4. this when you configure your control.

Further cables for other configurations are available on request.

PJ



3.2.4

04.95 04.96 07.94 38

Connecting the measuring systems

PJ

Note Use shielded cables only, the shield must be connected to the metal or metal-plated connector housing. The prepared connecting cables offered as accessories afford optimum interference immunity as well as amply-dimensioned cross sections for power supply to the position encoder.

X2

X3

X4

X5

X6

X3

X2

FM 354

NCU 570 Axes 1...5 Connecting cable

Incremental encoder with RS 422

Fig. 3-5

ROD 320 (built-on encoder in 1FT5)

Connection of measuring systems


Linear scale with EXE



04.95 07.94 39

Connection 1. Connect the cable to the measuring system. For SSI encoders, it may be necessary to prepare the cable (cable end to encoder) according to manufacturer’ specifications. 2. Open the front door and plug the D sub-connector to the module. 3. Lock the connector by means of knurled screws. Close the front door. Connecting cable for NCU 570 and FM 354

Prepared cable with integral connectors for built-on encoder or EXEs (for connecting linear scales).

Prepared cable for ROD 320 built-in encoder with 17-way circular connector. Prepared cable for SSI absolute encoder with free cable end. The connecting cables are available in different lengths. References:


PJ



3.2.5

04.96 07.94 40

Wiring the front connector

PJ Lettering on door inside

NCU 570

FM 354

X4 1 2 3 4 5 6 7 8 9 10

A A B B +5V M A A B B

HANDLE1

X3

NCU 570

HANDLE2

X2

FM 354

X1

X5 X6

11 12 13 14 15 16 17 18

Shield connection element 2 x handwheel

NCRDY

L+

20 M

3 4 5 6 9 10 X1 11 12 13 14

19 20 L+ M

Digital inputs NC READY Digital outputs 2 x probe

Fig. 3-6


Connecting cables

Flexible cable, cross section 0.25...1.5 mm2 Wire end sleeves are not required. You can use wire end sleeves without insulating shroud according to DIN 46228, Shape A, long type. You can connect two cables with 0.25...0.75 mm2 each in one wire end sleeve.

!

Tools required

Important Use shielded cables for connecting handwheels, probes or BEROs to ensure optimum interference immunity.

3.5 mm standard or powered screwdriver.




04.95 07.94 41

Proceed as follows: 1. Strip 6 mm cable, press on wire and sleeve if necessary. 2. Open front door, bring front connector into wiring position (while pressing the locking element). The connector is locked without having electric to the module. 3. Fit the strain relieve clamp to the connector. 4. If you bring out the cable standards, you start wiring at the bottom, otherwise at the top. Screw unassigned terminals as well. The tightening torque is 60...80 Ncm. 5. Tighten the strain relieve clamp for the cable harness. 6. Shift the front connector into operating position (while pressing the locking element). 7. Fill in the enclosed label and fix it in the front door.

Shielded cables at the front connector

Proceed as follows when using shielded cables: 1. Place cable shield on an earthed shielding bus after entry of cable into cabinet (strip cable to do this). Use for this purpose the shield conducting element which is fitted in the mounting channel and can accommodate up to eight shield terminals. References:

/S7H/, Manual

2. Lay shielded cable to the module but do not connect to the shield. Shield connection element This element can be fitted in the mounting channel for shield conducting of shielded cables. It accommodates up to eight shield terminals (KLBÜ series, Messrs Weidmüller). References:

/BU/, Ordering Information, Catalog NC 60.1 /S7H/, Manual

PJ



Connecting handwheels to the NCU 570

04.96 07.94 42

Proceed as follows:

PJ

1. Connect connecting cables to the handwheel. 2. Remove the cable jacket on the control side until you can connect the shield to the shield connection element and wire the cable ends at the front connector. 3. Wire up the cable at the front connector. Connecting cable Prepared cable for handwheel. The connecting cables are available in different lengths. References:

Connecting probes or proximity sensors (BEROs) to the NCU 570


Proceed as follows: 1. Wire up the power supply unit for your sensors. The sensor supply must satisfy the same conditions as the FM-NC load current supply. Use the load current supply terminals of the NCU 570 for power supply to the sensors. If not, you will have to provide equipotential bonding between the control and the sensor power supply. 2. Connect the shielded signal cable to the sensors. 3. Remove the cable jacket on the control side until you can connect the shield to the shield extracting element and via the free cable ends at the front connector. 4. Wire the signal cable at the front connector.

+

S7-300 X1

– +

13

– +

14 15

– +

16 17

– +

18

20 NCU 570

– +

Shield conducted to the shield connection element

– L+ M

Fig. 3-7

Terminal diagram for probes or proximity switches



Connecting the NC READY to the NCU 570 Connecting additional actuators/ sensors

The EMERGENCY STOP system is actuated when opening the NC READY .

If you want to connect additional actuators/sensors to the FM 354 or SMs on the local bus, proceed in the same way as described for the connection of digital inputs/outputs to the SIMATIC S7-300. References:

3.2.6

04.96 07.94 43

/S7H/, Manual

Inserting the backup battery Insert the enclosed lithium battery into the battery compartment of the NCU 570 before starting up the control.

Insert battery 1. Plug the battery connector into the socket in the battery compartment. The notch on the connector must point to the right. 2. Insert battery into the compartment and close the front door.

Service life

2 years minimum, normally 4 to 6 years, depending on battery operating time.

Compartment for backup battery

SF BA D F C 5V DIAG

X2

L+ M L+ M

Fig. 3-8

Inserting the backup battery

X3

X5

X4

X6

PJ


Configuring (PJ) 3.3 MPI connecting cables

3.3

07.94 44

MPI connecting cables

PJ

The MPI connecting cable are available in different lengths. The cables are used to make the following connections:

S S7-300 U - operator S Operator - machine control S S7-300 U - programming device The MPI connection can be ed on from one load to the next by attaching the MPI connector of the outgoing cable to the MPI connector of the incoming cable.

Terminating resistor

The cable must be terminated with its surge impedance. To do this, you switch on the terminating resistor in the MPI connector of the first and last load.

ON

ON

Terminating resistor Off

Fig. 3-9

On

MPI connector

J


Configuring (PJ) 4 Care and Maintenance

07.94 45

PJ

Care and Maintenance

4.1

4

Warnings

!

Warning Hazardous voltages are present in this electrical equipment during operation. Failure to properly maintain the equipment can result in death, serious bodily injury or substantial material damage. The instructions contained in this section and product labels have to be followed when carrying out maintenance work.

Maintenance must be performed by qualified personnel only. Always de-energize and ground the equipment before carrying out any work (exception: when changing batteries).

Use authorized spare parts only. The inspection intervals as well as the instructions for repair and replacement must strictly be adhered to.

!

Caution To not attempt to reactivate discharged batteries by heating or other methods. Batteries must not be recharged, as this can lead to leakage or explosion. Failure to comply with these regulations can lead to bodily injury or material damage.

Note Old batteries can be re-used and are taken back by the manufacturer on request. They must be disposed of as special waste if necessary.


Configuring (PJ) 4.2 Cleaning

4.2

07.94 46

Cleaning

PJ The surfaces of the control can be cleaned. Light dirt can be cleaned with household washing up liquid. Other cleansers containing one or several of the following components may also be used for a short time.

Diluted mineral acids Bases Alcohol Organic hydrocarbons Dissolved detergents Greases and oils

4.3

NCU 570 battery replacement

When to replace the battery

Replace the battery as soon as the relevant error message is output. The “BAF” LED also indicates the battery voltage and the status of the battery-backed memory. The battery needs no maintenance for at least two years. Normally, the battery will have to be replaced after five years or more, depending on operating conditions. We recommend replacing the battery after no more than five years, because batteries will deteriorate with increasing age.

“BAF” LED flashing

The battery-backed data are still available, but the battery starts discharging itself. Replace battery.

“BAF” LED lights permanently

The battery-backed data are lost, perform restart after battery has been replaced. This is enforced by the NCU 570.

!

Important Batteries must always be replaced with the load current supply switched on, otherwise battery-backed data will get lost.

Remove battery 1. Swing left front door upwards. 2. Remove battery while pulling the connector from its socket in the battery compartment.


Configuring (PJ) 4.3 NCU 570 battery replacement

07.94 47

Insert battery 1. Plug the battery connector into the socket in the battery compartment. The notch on the connector must always point to the right. 2. Insert battery into the compartment and close the front door (see Section 3.2.6).

Battery type

Only prepared batteries with plug-in connector can be used. Order No.:

6ES7-971-1AA00-0AA0

PJ


Configuring (PJ) 4.4 Replacing the NCU 570 or the FM 354

4.4

04.95 07.94 48

Replacing the NCU 570 or the FM 354

!

PJ

Warning The NCU 570 or the FM 354 can only be replaced when the load current supply is disconnected. Therefore, switch off the power supply, e.g. by operating the power On/Off switch on the PS 307 power supply unit.

Note Observe the instructions for data protection when performing initial start-up because this will facilitate restarting after module change. References:

Dismantling the module


Proceed as follows: 1. Open the front doors. Take out label, if necessary. 2. Loosen the connections at the terminal block for power supply. 3. Loosen the D sub-connector to the position encoder and drive unit. 4. Unlock front connector and pull it off. 5. Loosen the fastening screws and swing the module out upwards.

Mounting the new module

Proceed as follows: 1. Remove the upper part of the front connector coding element from the new module. 2. Fit a module of the same type, swing it downwards and tighten. 3. Plug in the front connector and switch it into operating position. The coding element adjusts itself to ensure that the front connector will only fit on this module. 4. Connect the D Sub connector. 5. Wire the load current supply at the terminal block. 6. Close the front doors and insert the label. The control is in Ready status again and can be put into operation. References:


J

NCU 570 (NC)

Contents 1

2

NC

System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

50

1.1

SINUMERIK FM-NC control system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

50

1.2

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

52

Technical Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

55

2.1

Hardware configuration of the module . . . . . . . . . . . . . . . . . . . . . . . . . . .

55

2.2 2.2.1 2.2.2

2.2.3 2.2.4 2.2.5 2.2.6

Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SIMATIC interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Drive interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Drives with anaterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stepping motor drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Measuring system interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I/O interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Memory module interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

59 59 59 61 62 65 69 72 72

2.3

Displays and operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

73

2.4

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

74


NCU 570 (NC) 1 System Overview

04.96 07.94 50

System Overview

1 NC

1.1

SINUMERIK FM-NC control system

What is the NCU 570?

The NCU 570 is a microprocessor-controlled module for the position-controlled motion control of up to four axes/spindles for servo or stepping motor drives. Together with other system components it makes up the SINUMERIK FM-NC control system. Considered from the S7-300 U, the NCU 570 operates like a function module (FM).

Further system components

S7-300 U as PLC U, e.g. U 314 S7-300 signal modules (SMs) as input/output modules S7-300 interface modules (IMs) for system expansion S7-300 power supply modules (PS) for load current supply Operator s (OPs) or hand-held unit with MPI (Multi Point Interface) Machine control with MPI Programming devices with MPI (PGs) S7-300 function modules (FMs), e.g. positioning modules FM STEPDRIVE for activation of stepper motors


NCU 570 (NC) 1.1 SINUMERIK FM-NC control system

04.96 07.94 51

SIEMENS

Operator

NC Machine control


SINUMERIK FM-NC with SIMATIC S7-300

FM STEPDRIVE PS

U 314

IM

SM

SM

NCU 570

SIMODRIVE 611-A

SIEMENS

SIMODRIVE

NE (I/R or UE) Fig. 1-1

MSD

FDD

SINUMERIK FM-NC system overview (schematic)

FDD


NCU 570 (NC) 1.2 Use

1.2

07.94 52

Use

Positioncontrolled motion control for servo axes

The NCU 570 enables the position-controlled motion control of up to four axes. Three of these axes can be dependent (interpolating). The NCU 570 provides for this purpose for each axis one analog output for the setpoint speed and one position encoder input for cyclic measurement of the actual position value. This is the way feed drives are normally controlled.

Spindle control

Spindles can be controlled by analog outputs by just setpoint speeds being output. A position encoder is not required.

Rotary axes

If the spindle position (angle of rotation) is measured by a position encoder, this spindle can be moved to an exact position like a servo axis (rotary axis operation).

Stepping motor control

In addition to the analog setpoint outputs, the NCU 570 is provided with pulse outputs for up to four stepping motor axes. In this case, the stepping motor is controlled via clock pulses. The number of pulses determines the position and their frequency the speed (velocity) of the spindle. The actual position value is not measured in controlled operation, the position controller considers the number of output pulses (setpoint position value) to be the actual value. To ensure exact positioning, the motor must not lose any steps.

Positioncontrolled stepping motor control

The NCU 570, having one position encoder input per axis, offers the possibility of operating stepping motors under position control like a servo axis.

Incremental measuring system

As a rule, position encoders are installed for position measurement. These supply counting pulses for the traversed path increments according to their resolution. Both rotary encoders and linear scales can be used for this purpose.

Reference point approach

To determine the absolute position of an axis, the control evaluates the zero mark of the incremental position encoder when a reference cam is overrun (cam connected to the PLC).

Absolute measuring system

Absolute encoders with serial interface can be connected instead of conventional incremental position encoders which only supply one measure for the path traversed. No reference point approach is required any more because these measuring systems always supply the absolute position as actual position value.

-Distance-coded re-

When linear scales with distance-coded reference marks are used as position encoders, measurement has to be performed across three marks only to determine the reference point because the control can establish the absolute position from these three distances.

ference marks

NC



07.94 53

Reference point approach with BERO

For stepping motor control, the zero pulse of a position encoder can be replaced by a proximity switch (BERO) attached to the shaft of the stepping motor and connected to the NCU 570.

Handwheel operation

The machine can also be operated “by hand” by connecting up to two handwheels which can be assigned to defined axes and the rotary movement of which is measured.

Measuring

Two probes can be connected and assigned to defined axes. In measuring mode, the actual position value is measured when a probe is reached during the traversing movement. References:

/FB/, Description of Functions

NC



04.96 07.94 54

Servo system with converter, e.g. SIMODRIVE 611-A SINUMERIK FM-NC

DAC +

Position controller

Converter

X2

Setpoint speed

–

X1

M 3

Power section Current controller

Enable

X3 X4 X5 X6

Position measuring system

Servo motor

Speed controller

Actual speed value

e.g. TachogeneratorRotor position encoder

NC

Actual position value, zeromark

2 handwheels 2 probes

Controlled stepping motor system with drive circuit, e.g. FM STEPDRIVE SINUMERIK FM-NC

+

Position controller

Oscillator

Drive circuit

X2

–

Clock direction

Power section

Enable

Ring counter Phase current controller

SIMOSTEP

SM

BERO

X3 X4 X5 X6

2 handwheels X1

(Rotation monitor)

2 probes 4 BEROs

Position-controlled stepping motor system with drive circuit, e.g. FM STEPDRIVE Drive circuit

SINUMERIK FM-NC

Position controller

+

Oscillator

X2

Enable

–

X3 X4 X5 X6 X1

Fig. 1-2

Clock direction

SIMOSTEP

Power section

Position measuring system

SM

Ring counter Phase current controller Actual position value, zeromark

2 handwheels 2 probes

SINUMERIK FM-NC with servo and stepping motor drive

J


NCU 570 (NC) 2 Technical Overview

07.94 55

Technical Overview

2

2.1

NC

Hardware configuration of the module

Features

S7-300 modular packaging system Low-volume plastic holder

(height x width x depth approx. 125 x 200 x 118 mm3)

No forced ventilation All terminals covered, cable outlet upwards or downwards Function units S7 bus

I/O bus

Communication bus

COM processor

Link RAM

NC processor

FLASH 24 V DC

Integrated power supply SRAM

Servo loops

DAC

Position encoder

Analog outputs

I/O module

Handwheels

Fig. 2-1

Digital inputs

NC READY

NCU 570 function units

+

Oscillator module

Pulse outputs


NCU 570 (NC) 2.1 Hardware configuration of module

07.94 56

Function units, continued

NC processor 32-bit RISC processor i960SB with integrated floating point unit

COM processor 16-bit SAB C165 controller for communication with the S7-300 U and control units and programmers

Memory –

FLASH memory for operating system and function software

–

SRAM for data

–

SRAM, battery-backed, for part programs and non-volatile data

–

Link RAM for communication channels

I/O bus interface for communication with the S7-300 U (VDI interface)

Communication bus interface for communication with control units and programmers (OPs and PGs) on –

Start-up

–

Parameter assignment

–

Operator control and monitoring

Servo loops Counters/s for connecting four incremental or absolute position encoders.

Digital/analog converter (DAC) Four analog setpoint outputs 10 V for triggering drive power sections for servo axes or spindles.

Oscillator unit Four oscillators for triggering stepping motor power sections.

I/O unit –

Two inputs for connecting handwheels

–

Four fast inputs for connecting 24 V switching elements including two probes

–

One floating NC READY for integration in the EMERGENCY STOP loop

Integrated power supply DC/DC converter with 24 V direct voltage input for generating the internal 5 V logic supply, the power supply of the analog part and for power supply to position encoders. The I/O bus interface is supplied with 5 V via the S7-300 backplane bus.

NC



04.96 07.94 57

Location of interfaces and front elements

DIN rail

NC

Bus coupler SIMATIC interface

Front door (swinging out) Label

Startup switch

Front view without front doors

Fault and status displays SF

Slot for memory module

X2

BAF

X3

X4

1

1 2 3 4 5 6 7 8 9 0

1 1 1 1 1 1 1 1 1 2

1 2 3 4 5 6 7 8 9 0

DC 5V DIAG

Compartment for backup battery

Front connector

Terminals for power supply

L+ M L+ M

X5

X2 drive interface

Fig. 2-2


X6

X3...X6 measuring system interface

X1 I/O interface



04.96 07.94 58

Interfaces

SIMATIC interface Rear-side connector for connecting the NCU 570 to further control components via the S7-300 backplane bus (I/O and communication bus).

Drive interface 50-way D sub-connector (X2) for connecting the power sections for up to four analog or stepping motor drives.

Measuring system interfaces One position encoder can be connected to each of the D sub-sockets (X3...X6) via a 15-way connector (maximum 4).

I/O interface 20-way front connector (X1) for connecting the handwheels, for fast inputs including probes and for wiring the NC READY relay.

Power supply terminal 4-way screw terminal block (X10) for connecting the 24 V load current supply.

Storage module interface 68-pole PCMCIA-card-connector for storage modules

Displays

4 LEDs for fault and status displays

Operating elements

Startup switch

Battery compartment

for connecting one lithium battery, prepared with connector

NC


NCU 570 (NC) 2.2 Interfaces

04.96 07.94 59

2.2

Interfaces

2.2.1

SIMATIC interface

Backplane bus

2.2.2

The SIMATIC interface distributes the S7-300 backplane bus (I/O and communication bus) from the S7-300 U to all modules of one line (see Configuring Manual, Mounting of the NCU 570 and FM 354 modules).

Drive interface

Overview

Drives with anaterface Stepping motor drives

Connector to drive unit

The 50-way D sub-connector X2 of the NCU 570 is used to connect power sections with anaterface (10 V) or stepping motor power sections that have at least one clock and directional input. Any mixed configurations for up to four drives are possible. Additionally, the NCU 570 provides one enable signal per axis.

Location of connector ANALOG OUT 1–4/ STEPPER CONTR. 1–4 SF BAF DC 5V DIAG

X2

L+ M L+ M

Fig. 2-3

Location of X2 connector

X3

X5

X4

X6

1

1 2 3 4 5 6 7 8 9 0

1 1 1 1 1 1 1 1 1 2

1 2 3 4 5 6 7 8 9 0

33 18 1

50 33 17

X2

NC



Connector pin assignments

07.94 60

Drive interface (servo interface for 4 axes) Connector designation:

X2 ANALOG OUT 1-4/STEPPER CONTR. 1-4 50-way D sub-plug connector

Connector type: Table 2-1

X2 connector assignments X2

Pin

Name

Type

Pin

Name

Type

Pin

Name

Type

1

SW1

VO

2

BS2

VO

18

ENABLE1

O

19

ENABLE1_N

O

34

BS1

VO

35

SW2

VO

3

SW3

VO

20

ENABLE2

O

36

BS3

VO

4 5

BS4

VO

21

ENABLE2_N

PULS1

O

22

Unassigned

O

37

SW4

VO

38

PULS1_N

O

6

DIR1

O

23

Unassigned

39

DIR1_N

O

7

PULS2_N

O

8

DIR2_N

O

24

Unassigned

40

PULS2

O

25

Unassigned

41

DIR2

O

9

PULS3

O

26

ENABLE3

O

42

PULS3_N

O

10

DIR3

O

27

ENABLE3_N

O

43

DIR3_N

O

11

PULS4_N

O

28

ENABLE4

O

44

PULS4

O

12

DIR4_N

O

29

ENABLE4_N

O

45

DIR4

O

13

Unassigned

30

Unassigned

46

Unassigned

14

RF1.1

K

31

Unassigned

47

RF1.2

K

15

RF2.1

K

32

Unassigned

48

RF2.2

K

16

RF3.1

K

33

Unassigned

49

RF3.2

K

17

RF4.1

K

50

RF4.2

K

Signal names for stepping motor drives: PULS[1...4], PULS[1...4]_N DIR[1...4], DIR[1...4]_N ENABLE[1...4], ENABLE[1...4]_N for analog drives: SW[1...4] BS[1...4] RF[1.1...4.1], RF[1.2...4.2]

Setpoint Reference potential for setpoint (analog earth) Controller enable

Signal type O VO K

Clock pulse true and negated Directional signal true and negated Controller enable true and negated

Signal output Voltage output Switching

NC



Drives with anaterface

07.94 61

Signals: One voltage and one enable signal are provided for each channel.

SETPOINT (SW) Analog voltage signal within the range of 10 V for the output of one speed setpoint.

REFERENCE SIGNAL (BS) Reference potential (analog ground) for the setpoint signal, internally connected to the logic ground.

CONTROLLER ENABLE (RF) Pair of relay s used to activate axis-specific enables of the power section, e.g. a SIMODRIVE drive unit. The NCU 570 activates this signal when cyclic control operation is started, i.e. when ramp-up and parameter assignment have been successfully completed. Signal parameters The setpoint is output as an analog differential signal Table 2-2

Electric setpoint signal parameters Parameter

Minimum

Maximum

Unit

Voltage range

-10.5

10.5

V

Output current

-3

3

mA

Relay s The axis enables are activated via relay outputs (make s). Table 2-3

Electric relay parameters Parameter

Maximum

Unit

Switching voltage

50

V

Switching current

1

A

Switching power

30

VA

Cable length: 35 m maximum

Minimum

NC



Stepping motor drives

07.94 62

Signals: One clock, directional and enable signal is provided for each channel as true and negated signal.

PULSE (CLOCK) The clock pulses serve to control the motor which performs one step with each rising pulse edge. The number of output pulses determines the angle of rotation, i.e. the path to be traversed. The pulse frequency determines the speed of rotation, i.e. the traversing velocity.

!

Important If your drive unit reacts to trailing clock edges, you must change the true for the negated clock signal when wiring. Otherwise discrepancies may result between the position calculated by the control and the actual position.

DIRECTION The output signal level determines the direction of rotation of the motor. ON signal: OFF signal:

“Counter-clockwise rotation” “Clockwise rotation”

Note If the direction of rotation of your motor should be other than stated above, your can reverse the direction of rotation via machine data. Make sure that the assignment of signal levels to the direction of rotation is correct by checking up in the Technical Documentation provided for your drive unit.

ENABLE The NCU 570 activates this signal when cyclic control operation is started. ON signal: OFF signal:

Enable power drive circuit One or several of the following reactions are possible, depending on the power section:

-

Disable pulse input De-energize motor Reset ring counter Cancel error message

Note The ENABLE signal is output together with the RF controller enable , i.e. you can also use the relay s as an alternative.

NC



07.94 63

Stepping motor drives, continued Signal parameters All signals for stepping motor drives are output via differential signal line drivers in accordance with the requirements of the RS422 standard. The power section should be provided with differential signal receivers or optocoupler inputs enabling symmetrical pulse transmission for optimum interference immunity. Unsymmetrical transmission is also possible, but only for cable lengths of up to 10 m. All outputs are electronically protected against short-circuits and thermal overload. Figure 2-4 shows different possibilities of signal connection and Table 2-4 gives an overview of the electrical data of interface output signals. Table 2-4

Electrical parameters of signal outputs for stepping motor drives Parameter

Min.

Max.

Unit V

RL = 100 Ω

3.7

V

IO = -20 mA

V

IO = -100 µA

V

IO = 20 mA

VOD

Output voltage “High”

VOH

Output voltage “Low”

VOL

Load impedance

RL

Output current

IO

60

mA

Pulse frequency

fP

250

kHz

Cable length:

At

2

Differential output voltage

4.5 1

Ω

55

Maximum 50 m 35 m for mixed operation with analog axes 10 m for unsymmetrical transmission

NC



07.94 64

Symmetrical transmission with differential input in accordance with RS422 L 50 m

NCU 570

Drive unit

IO + RL

VOD

NC

– VOL

VOH

GND Symmetrical transmission with optocoupler input L 50 m

=

GND Unsymmetrical transmission with optocoupler input L 10 m

=

GND Unsymmetrical transmission with voltage input L 10 m

GND

Fig. 2-4

GND

Possibilities of signal connection of the stepping motor interface



2.2.3

04.96 07.94 65

Measuring system interface

Connector to position encoder Location of connector

A 15-way D Sub socket for connecting one position encoder is provided for each axis.

NC

ENCODER 1, 2 SF BAF DC DIAG 5V

X2

X3

L+ M L+ M

Fig. 2-5


X5

X4

X6

1

1 2 3 4 5 6 7 8 9 0

1 1 1 1 1 1 1 1 1 2

1 2 3 4 5 6 7 8 9 0

X3...X6 15

8

9 1

ENCODER 3, 4

Location of connectors X3 to X6

Measuring system interface (incremental position measurement/SSI) Connector designation:

X3, X4, X5, X6 ENCODERS 1...4 X3 Axis 1 X4 Axis 2 X5 Axis 3 X6 Axis 4 15-way D Sub socket connector

Connector type: Table 2-5

Assignment of sockets X3 to X6 X3, X4, X5, X6 Position encoder

Pin

Incremental

1

Absolute

Position encoder Type

Pin

Unassigned

Incremental

9

Absolute

MEXT

Type VO

2

CLS

O

10

N

I

3

CLS_N

O

11

N_N

I

4

P5EXT

VO

12

B_N

I

5

P24EXT

VO

13

B

I

6

P5EXT

VO

14

A_N

DATA_N

I

7

MEXT

VO

15

A

DATA

I

8

Unassigned

Signal names



04.96 07.94 66

CLS, CLS_N DATA, DATA_N A, A_N B, B_N N, N_N P5EXT P24EXT MEXT

SSI Shift cycle true and negated (abs. pos. encoder) Track SSI data true and negated (abs. pos. encoder) Track A true and negated (incr. position encoder) Track B true and negated (incr. position encoder) Zero mark true and negated (incr. position encoder) +5 V supply +24 V supply Ground supply

Signal type VO O I

Connectable encoder types

NC Voltage output (supply) Output (5 V signal) Input (5 V signal)

Incremental 5 V or absolute SSI encoders can be connected directly (e.g. digital rotary encoders) selection is made via machine data. Encoders with SINE/COSINE signals (e.g. linear scales) can be connected via external pulse shaper electronics (EXE) which changes the signals to 5 V level. Measuring systems with distance-coded reference marks can also be connected.

Characteristics

Directly connectable encoders (or EXEs) must satisfy the following conditions Incremental encoders Transmission system:

Differential transmission with 5 V rectangular signals (in accordance with RS422 standard)

Output signals:

Track A as a true and negated signal (Ua1, Ua1) Track B as a true and negated signal (Ua2, Ua2) N zero signal as a true and negated signal (Ua0, Ua0)

Max. output frequency:

1.5 MHz

Phase shift of tracks A to B:

90° 30°

Power input:

Max. 300 mA

Absolute encoder Transmission system:

Synchronous serial interface (SSI) with 5 V differential signal transmission (in accordance with RS422 standard)

Output signal:

Data as a true and negated signals

Input signal:

Shift cycle as a true and negated signal

Resolution:

Max. 25 bits

Max. transmission frequency 1 Mbit/s Power input:

5 V encoder supply voltage

Max. 300 mA

The 5 V encoder supply voltage for the position encoders is generated inside the modules and is available at the D Sub sockets, i.e. you can supply the encoders via the signal cable without any additional wiring being required. The voltage supplied is protected electronically against short circuits and thermal overload and is monitored.



!

24 V encoder supply voltage

!

04.96 07.94 67

Important Please note that the maximum current that can be drawn from the 5 V power supply (P5EXT terminals) must not exceed 1.35 A for all connected position encoders and handwheels.

If you intend to use position encoders with 24 V operating voltage, the 24 V DC power supply is distributed to the D Sub sockets, i.e. the encoders can be supplied via the signal cable without any additional wiring being required. The voltage supplied is protected electronically against short circuits and thermal overload and is also monitored.

Important Please note that the maximum current that can be drawn from the 24 V power supply must not exceed 1 A for all position encoders connected.

Table 2-6

Electric parameters of encoder power supply Parameters

Minimum

Maximum

Unit

5.1

5.3

V

50

mVpp

Load-carrying capacity per encoder

0.3

A

Maximum load carrying capacity 1)

1.35

A

5 V supply voltage Voltage Ripple

24 V supply voltage Voltage

28.8

V

Ripple

20.4

3.6

Vpp

Load-carrying capacity per encoder

0.3

A

1

A

Maximum load carrying capacity

Notes: 1) Connectable handwheels, see Section 2.2.4

Cable lengths

The maximum cable length depends on the specification of the encoder power supply and on the transmission frequency. When using prepared Siemens connecting cables, the following values must not be exceeded to guarantee interference-free operation: References:

/Z/, Catalog NC Z

NC



04.96 07.94 68

Table 2-7

Maximum cable lengths dependent on encoder power supply.

Supply voltage

Tolerance

Power input

Maximum cable length

5 V DC

4.75 V...5.25 V

< 300 mA

25 m

5 V DC

4.75 V...5.25 V

< 220 mA

35 m

24 V DC

20.4 V...28.8 V

< 300 mA

100 m

24 V DC

11 V...30 V

< 300 mA

300 m

NC Note Select an encoder type with a 24 V supply voltage if you wish to use incremental encoders with cable length exceeding 25 m or 35 m, respectively.

Table 2-8

Maximum cable lengths dependent on transmission frequency

Encoder type Incremental

Absolute (SSI)

Frequency


1 MHz

10 m

500 kHz

35 m

1.25 Mbit/s

10 m

125 kbit/s

300 m



2.2.4

04.96 07.94 69

I/O interface

Front connector

The 20-way X1 front connector with single-wire connection is used to connect handwheels, probes, BEROs or other sensing elements. In addition, a separate supply voltage can be connected to supply position encoders with 24 V supply voltage. Moreover, a pair of s is available for the ready signal. This pair must be integrated into the EMERGENCY-STOP system.

Location of the connector Lettering on door inside

Front connector in wiring position

A A B B +5V M A A B B

HANDLE2

1

1 2 3 4 5 6 7 8 9 10

HANDLE1

X1 1 2 3 4 5 6 7 8 9 0

X1 1 1 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0

Fig. 2-6


11 12 13 14 15 16 17 18 20 M

NCRDY L+

NC




04.96 07.94 70

I/O interface (handwheel and I/O connection) Connector designation: Connector type:

Table 2-9

X1 20-way S7 front connector for single-wire connection

X1 front connector assignments X1

Pin

Name

Type

Pin

Name

Type

1

A1

I

11

NCRDY.1

K

2

A1_N

I

12

NCRDY.2

K

3

B1

I

13

I0/BERO1

DI

4

B1_N

I

14

I1/BERO2

DI

5

P5_EXT

VO

15

I2/BERO3

DI

6

M5_EXT

VO

16

I3/BERO4

DI

7

A2

I

17

I4/MEPU1

DI

8

A2_N

I

18

I5/MEPU2

DI

9

B2

I

19

Unassigned

10

B2_N

I

20

M

VI

Signal names A1...2, A1...2_N B1...2, B1...2_N P5_EXT, M5_EXT NCRDY.1...2 I0...I5, BERO1...BERO4 MEPU1, MEPU2 M

Track A true and negated (handwheels 1...2) Track B true and negated (handwheels 1...2) 5 V supply voltage for handwheels Ready (NC-READY s 1...2) Rapid digital input 0...5 BERO input for axes 1...4 Measuring pulse inputs 1 and 2 Reference potential for inputs

Signal type VO VI I DI K

Handwheels

Voltage output Voltage input Input (5 V signal) Input (24 V signal) Switching

(HANDLE 1, 2) Two electronic handwheels can be connected which must satisfy the following conditions: Transmission system:

5 V square-wave signals (TTL level or RS422)

Signals:

Track A as a true and negated signal (Ua1, Ua1) Track B as a true and negated signal (Ua2, Ua2)

Maximum output frequency:

500 kHz

Phase displacement of tracks A to B:

90° 30°

Supply voltage:

5 V, max. 250 mA

NC



4 digital inputs including 2 probes

04.96 07.94 71

(I0...I5) These fast inputs are PLC-compatible (24 V P-switching). Both switches and proximity sensors (2- or 3-wire sensor) can be connected to these inputs. They can be used

as probes (MEPU1, 2), assignment to axes is programmed as switches for reference point approach (BERO1...BERO4), inputs are

NC

permanently assigned to axes 1 to 4 Table 2-10

Electrical parameters of digital inputs Parameters

NC READY output

Value

Unit

1 signal, voltage range

11...30

V

1 signal, current input

6...30

mA


-3...5

V

Signal delay 0 ³ 1

15

µs

Signal delay 1 ³ 0

150

µs

Remarks

or input open

(NCRDY) Ready as a relay (make ) must be integrated in the EMERGENCY-STOP circuit. Table 2-11

Electrical parameters of NCRDY relay Parameters

DC switching voltage

Maximum

Unit

50

V

Switching current

1

A

Switching power

30

VA



2.2.5

04.96 07.94 72

Power supply

Screw terminal block

The required 24 V DC load current supply is wired at the screw terminal block.

Load current supply parameters

The 24 V direct voltage must be generated as a functional extra-low voltage with safe electric isolation (in accordance with EN 60204-1, Section 6.4, PELV). Table 2-12

Electrical parameters of load current supply Parameter

Voltage range, mean value

Min.

Max.

20.4

28.8

V

Ripple

3.6

Vpp

Non-periodic overvoltage

35

V

Nominal current input

1

A

2.6

A

Starting current

Terminal assignments

Unit

Table 2-13

Remarks

500 ms duration 50 s restoration time

Screw terminal block assignments

Terminal 1

L+

24 V DC

2

M

Ground

3

L+

24 V DC

4

M

Ground

s 1/3 and 2/4 are internally wired.

2.2.6

Overview

Memory module interface

FLASH memory modules according to SIMATIC or PCMCIA standard can be inserted into the slot.

NC


NCU 570 (NC) 2.3 Displays and operating elements

2.3

04.96 07.94 73

Displays and operating elements

Error and status displays

Four LEDs are arranged at the front of the NCU 570.

SF (red)

Group error This LED indicates and error status of the NCU 570. To remove the fault, it may be necessary to carry out a restart, a firmware update or to replace a hardware component.

DIAG (yellow)

Diagnostics This LED indicates different diagnostic statuses. You can locate faults from the flashing of this LED if you do not use an operator (OP) or programmer (PG) for display.

BAF (red)

Battery fault Flashing of this LED indicates that the batteries must be replaced. If this LED lights permanently, the data content of the battery-backed memory is no longer safe. Replacement of the battery must be followed by a restart.

DC 5V (green)

Logic supply switched on This LED indicates that the hardware is ready for operation. If this LED is not lit, this indicates different possibilities.

Your mains is not ok, There is a fault in the load current supply unit, The module has not been properly connected, Your control has not been configured correctly (sum of nominal and starting current s too large) or

There is a fault in the module. Startup switch

The startup switch serves for startup Position 0/4: Position 1, 2/5, 6: References:

Normal mode Startup /IAF/, Installation and startup Guide

NC


NCU 570 (NC) 2.4 Technical data

2.4

04.96 07.94 74

Technical data

UL/CSA approval

The following is approved for S7-300: UL Recognition Mark Underwriters Laboratories (UL) in accordance with Standard UL 508, File E 116536 CSA Certification Mark Canadian Standard Association (CSA) in accordance with Standard C 22.2 No. 142, File LR 48323

FM approval

!

The following FM approval exists for S7-300: FM approval according to Factory Mutual Approval Standard Class Number 3611, Class I, Division 2, Group A, B, C, D.

Warning Risk of hazard to people or material. Risk of hazard to people or material in explosion hazardous areas with separation of plug connections with S7-300 in operation. Always disconnect S7-300 from power for separating plug connections in explosion hazardous areas.

! CE marking

Warning WARNING - DO NOT DISCONNECT WHILE CIRCUIT IS LIVE UNLESS LOCATION IS KNOWN TO BE NONHAZARDOUS

Our products meet the requirements of the EU Directive 89/336/EC ”Electromagnetic Compatibility” on the harmonized European Standards (ES) listed there. The EC Declaration of Conformity in accordance with the EU Directive, Article 10, stated above form part of this manual (see Section B).

NC



Range of application

04.96 07.94 75

SINUMERIK products are designed for application in the industry. Together with an individual approval, SINUMERIK products can also be used in houses (residential or commercial buildings, small enterprises). local authorities or inspection office for individual approval. In , individual permits are given by the Ferderal Office for Telecommunication. Demands on


Noise emission

Observe directives for setup

Noise immunity

Industry

EN 50081-2 : 1993

EN 50082-2 : 1995

Residential buildings

Industrial approval

EN 50082-1 : 1992

SINUMERIK products meet the requirements if you observe the directives for setup described in the manuals for installation and operation.

Connection values Table 2-14

Connection values Parameters

Min.

Supply voltage

Weights and dimensions

20.4

Power input from 24 V

1

Power loss

15

Max.

Unit

28.8

V A W

Starting current

2.6

A

Power input from 5 V backplane bus

100

mA

5 V encoder supply Maximum output current 1)

1.35

A

24 V encoder supply Maximum output current

1.0

A

Table 2-15

Weights and dimensions Parameters

1)

Typical

Mounting dimensions H x W x D

125 x 200 x 118 mm

Weight

approx. 1150 g

Sum for position encoders and handwheels

NC



Ambient conditions during operation

04.96 07.94 76

Table 2-16

Ambient conditions in operation Parameters

Temperature range

0...60 °C for horizontal installation 0...40 °C for vertical installation

Permissible relative air humidity

5...95 % without condensation


860...1080 hPa

NC

The operating conditions are in accordance with IEC 1131-2. The NCU 570 must be installed in a cabinet.

Conditions for transport and storage

Table 2-17

Conditions for transport and storage Parameters

Temperature range

-40...70 °C




660...1080 h Pa

Height for transportation

-1000...3000 m

Free fall

v 500 mm

Lithium battery:

!

Lithium content approx. 0.25 g No special approvals are required for transportation. Dangerous-materials class 9 in accordance with Regulations for Air Freight Transportation. The NCU 570 must be stored in a cool and dry place.

Warning Wrong handling of lithium batteries involves the risk of ignition, explosion and burning. The following rules should therefore be strictly adhered to:

S Do not charge S Do not heat up or set on fire S Do not pierce S Do not squeeze

Protective quality and degree of protection

Safety class I in accordance with DIN VDE 0106 Part 1 and IEC 536. A safety earth terminal must be provided on the DIN rail. Protection against ingress of solid foreign bodies and water in accordance with type of protection IP 20 satisfying the requirements of IEC 529.

J

FM 354 (FM)

Contents 1

System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

78

2

Technical Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

80

2.1

Hardware configuration of the module . . . . . . . . . . . . . . . . . . . . . . . . . . .

80

2.2 2.2.1 2.2.2 2.2.3 2.2.4

Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SIMATIC interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Drive interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Measuring system interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I/O interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

84 84 84 86 89

2.3

Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

93

2.4

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

94

FM


FM 354 (FM) 1 System Overview

04.95 07.94 78

System Overview

1

What is the FM 354?

The FM 354 is a microprocessor-controlled module for the position-controlled motion control of a servo drive. In an S7-300 automation system the FM 354 is used as a positioning control.

FM 354 with FM-NC

The FM 354 serves as an axis expansion module in the FM NC control system. It is connected to the local bus of an NCU 570. The scope of functions of the FM-NC is thus extended to

one additional feed axis or spindle 4 digital fast inputs 4 digital fast outputs

FM


FM 354 (FM) 1 System Overview

04.95 07.94 79

SIEMENS

Operator

Machine control

QWERTY keyboard

FM

SINUMERIK FM-NC with SIMATIC S7-300

PS

U

IM

SM

SM

FM NCU 570 FM 354

SM

SIMODRIVE 611-A

SIEMENS SIMODRIVE

NE (I/R or UE)

Fig. 1-1

MSD

FDD

FDD

FDD

SINUMERIK FM-NC system overview (schematic)

J


FM 354 (FM) 2 Technical Overview

04.95 07.94 80

Technical Overview

2

2.1

Hardware configuration of the module

Features

S7-300 modular packaging system Low-volume plastic holder (height x width x depth approx. 125 x 80 x 118 mm3) No forced ventilation All terminals covered, cable outlet upwards or downwards

Function units S7 bus

I/O bus

Communication bus

Microprocessor

24 V DC

FLASH Integrated power supply SRAM

I/O module

Digital inputs

Fig. 2-1

Digital outputs

FM 354 function units

Servo loops

DAC

Position encoder

Analog output

FM


FM 354 (FM) 2.1 Hardware configuration of the module

04.95 07.94 81

Function units, continued

Microprocessor 16 bit SAB C165 controller for communication with other system components and for program processing.

Memory –

FLASH memory for operating system and function software

–

SRAM for data

I/O bus interface for communication with the S7-300-U or the NCU 570

Communication bus interface for communication with control units and programmers (OPs and PGs) on –

Start-up

–

Parameter assignment

–

Operator control and monitoring

This interface is not used for operation with the NCU 570 local bus.

Servo loop Counters/s for connecting an incremental or absolute position encoder

Digital/analog converter (DAC) Analot setpoint output 10 V for triggering drive power sections for servo axes or spindles.

I/O unit –

Four fast inputs for connecting 24 V sensors

–

Four fast outputs for connecting 24 V actuators

Integrated power supply DC/DC converter with 24 V direct voltage input for generating the internal 5 V logic supply, the power supply of the analog part and for power supply to position encoders. The I/O bus interface is supplied with 5 V via the S7-300 backplane bus.

FM



04.95 07.94 82


DIN rail

FM Labelling on the module: FM 354 F.SERVO MOTOR Bus coupler SIMATIC interface Front door (swinging out)

Label Front view without front doors ENCODER X3

SF

Status and fault displays

1 1 1 1 1 1 1 1 1 2

1 2 3 4 5 6 7 8 9 0

DC5V DIAG

X3 measuring system interface

X2 drive interface ANAL.OUT X2

X1 I/O interface

Fig. 2-2

1

1 2 3 4 5 6 7 8 9 0


Front connector I0 I1 I2 I3 RM

Q0 Q1 Q2 Q3

Display of digital inputs and outputs



04.95 07.94 83

Interfaces

SIMATIC interface Rear-side connector for connecting the FM 354 to further control components via the S7-300 backplane bus (I/O and communication bus).

Drive interface 9-way D sub-connector (X2) for connecting the drive unit

Measuring system interfaces A position encoder can be connected to the 15-way D sub-socket (X3)

I/O interface 20-way front connector (X1) for connecting the fast inputs/outputs and for wiring the power supply

FM Displays

3 LEDs for fault and status displays 8 LEDs for digital inputs/outputs 1 LED for “controller signal” input (not used with the FM NC)


FM 354 (FM) 2.2 Interfaces

04.95 07.94 84

2.2

Interfaces

2.2.1

SIMATIC interface

Backplane bus

2.2.2

The SIMATIC interface distributes the S7-300 backplane bus (I/O and communication bus) from the S7-300 U to all modules of one line (see Configuring Manual, Mounting the NCU 570 and FM 354 modules).

Drive interface

Connector to drive unit

The 9-way D sub-connector X2 of the FM 354 is used to connect power sections with anaterface (10 V). Additionally the FM 354 provides an enable signal.

Location of connector

Figure 2-3 shows the mounting position and the designation of the connector on the module. ANAL. OUT X2

6

1

9 5

FM 354 Fig. 2-3



Connector designation: Connector type: Table 2-1

X2 ANAL. OUT X2 9-way D sub-plug connector

X2 connector assignments

Pin

Name

Type

Pin

Name

Type

1

SW

VO

6

BS

VO

2

Unassigned

7

Unassigned

3

Unassigned

8

Unassigned

4

Unassigned

9

RF.1

5

RF.2

K

K

FM



04.95 04.96 07.94 85

Signal names

SW BS RF.1...2

Setpoint 10 V Reference potential for setpoint Controller enable

Signal type

VO K

Voltage output Switching

Signals

One voltage and one enable signal are provided.

SETPOINT (SW) Analog voltage signal within the range of 10 V for the output of one speed setpoint.

REFERENCE SIGNAL (BS) Reference potential (analog ground) for the setpoint signal, internally connected to the logic ground.

CONTROLLER ENABLE (RF) Pair of relay s used to activate axis-specific enables of the power section, e.g. a SIMODRIVE drive unit. The FM 354 activates this signal when cyclic control operation is started, i.e. when ramp-up and parameter assignment have been successfully completed.

Signal parameters

The setpoint is output as an analog differential signal Table 2-2

Electric setpoint signal parameters Parameters

Relay s

Minimum

Maximum

Rated voltage

10

10

V

Output current

-3

3

mA

The axis enables are activated via relay outputs (make s). Table 2-3

Electric relay parameters Parameters

Switching voltage

Connecting cable to drive

Unit

Maximum

Unit

50

V

Switching current

1

A

Switching power

30

VA

Permissible length: max. 35 m

FM



2.2.3

04.95 07.94 86

Measuring system interface

Connector to position encoder

Incremental (5 V) or absolute (SSI) position encoders can be connected to the 15-way subminiature D socket.

Location of connector

Figure 2-4 shows the mounting position and the designation of the connector on the module.

ENCODER X3 15 8

9

FM

1

FM 354 Fig. 2-4



Connector designation: Connector type: Table 2-4

X3 ENCODER X3 15-way subminiature D socket connector

Assignment of X3 socket Position encoder

Pin 1

Incremental

Absolute

W_N

Position encoder Type

Pin

I

9

Incremental

Absolute

MEXT

Type VO

2

CLS

O

10

N

I

3

CLS_N

O

11

N_N

I

B_N

I

4

P5EXT

VO

12

5

P24EXT

VO

13

B

6

P5EXT

VO

14

A_N

DATA_N

I

7

MEXT

VO

15

A

DATA

I

8

Unassigned

I



04.95 07.94 87

Signal names

W_N A, A_N B, B_N N, N_N CLS, CLS_N DATA, /DATA_N P5EXT P24EXT MEXT

Signal type

VO O I

Connectable encoder types

Incremental (5 V) or absolute (SSI) position encoders can be connected directly (e.g. digital rotary encoders), selection is made via machine data.

Maintenance signal negated (incr. position encoder) Track A true and negated (incr. position encoder) Track B true and negated (incr. position encoder) Zero mark true and negated (incr. position encoder) SSI Shift cycle true and negated (abs. pos. encoder) Track SSI data true and negated (abs. pos. encoder) +5 V supply +24 V supply Ground supply

Voltage output (supply) Output (5 V signal) Input (5 V signal)

Encoders with SINE/COSINE signals (e.g. linear scales) can be connected via external pulse shaper electronics (EXE) which changes the signals to 5 V level.

Characteristics of position encoders

Directly connectable position encoders (or EXEs) must satisfy the following conditions: Incremental position encoder Transmission system:

Differential transmission with 5 V square-wave signals (in accordance with RS422 standard)

Output signals:

Track A as a true and negated signal (Ua1, Ua1) Track B as a true and negated signal (Ua2, Ua2) N zero signal as a true and negated signal (Ua0, Ua0)

Max. output frequency:

1.5 MHz

Phase shift of tracks A to B:

90° 30°

Power input:

max. 300 mA

Absolute position encoder Transmission system:

Synchronous serial interface (SSI) with 5 V differential signal transmission (in accordance with RS422 standard)

Output signal:

Data as a true and negated signal

Input signal:

Shift cycle as a true and negated signal

Resolution:

Max. 25 bits

Max. transmission frequency: 1.25 Mbit/s Power input:

Encoder supply voltage

Max. 300 mA

The 5 V or 24 V encoder supply voltage for the position encoders is generated inside the modules and is available at the D Sub sockets, i.e. you can supply the encoders via the signal cable without any additional wiring being required. The voltage supplied is protected electronically against short circuits and thermal overload and is monitored.

FM



04.95 07.94 88

Table 2-5

Electric parameters of encoder power supply Parameters

Minimum

Maximum

5.1

Unit


5.3

V

Ripple

50

mVpp

Load-carrying capacity

0.3

A

28.8

V

Ripple

3.6

Vpp

Load-carrying capacity

0.3

A


Connecting cable to position encoder

20.4

The maximum cable length depends on the specification of the encoder power supply and on the transmission frequency. When using prepared SIEMENS connecting cables, the following values must not be exceeded to guarantee interference-free operation: References: Table 2-6

/Z/, Catalog NC Z Maximum cable lengths dependent on encoder power supply

Supply voltage

Tolerance

Power input


5 V DC

4.75 V...5.25 V

< 300 mA

25 m

5 V DC

4.75 V...5.25 V

< 220 mA

35 m

24 V DC

20.4 V...28.8 V

< 300 mA

100 m

24 V DC

11 V...30 V

< 300 mA

300 m

Note Select an encoder type with a 24 V supply voltage if you wish to use incremental encoders with a cable length exceeding 25 m or 35 m, respectively.

Table 2-7

Maximum cable lengths dependent on transmission frequency Encoder type

Incremental position encoder (5 V)

Absolute position encoder (SSI)

Frequency


1 MHz

10 m

500 kHz

35 m

1.25 Mbit/s

10 m

125 kbit/s

300 m

FM



2.2.4

04.95 07.94 89

I/O interface

Front connector

The 20-way X1 front connector with single-wire connection is used to connect four digital inputs/outputs and the ready signal (controller signal).

Location of the connector

Figure 2-5 shows the front connector in wiring position and the lettering on the front door inside.

Front connector in wiring position

X1

Lettering on door inside

Interlocking element

1

1 2 3 4 5 6 7 8 9 0

1 1 1 1 1 1 1 1 1 2

1 2 3 4 5 6 7 8 9 0

FM 3 4 5 6 9 10 X1

Fig. 2-5


11 12 13 14

19 20 L+ M




04.95 04.96 07.94 90

Connector designation: Connector type:

Table 2-8

X1 20-way S7 front connector for single-wire connection

X1 connector assignments

Pin

Name

Type

1

Unassigned

2

Unassigned

3

Pin

Name

Type

VI

11

DA1

O

VI

12

DA2

O

DE1

I

13

DA3

O

4

DE2

I

14

DA4

O

5

DE3

I

15

Unassigned

6

DE4

I

16

Unassigned

7

Unassigned

17

Unassigned

8

Unassigned

18

Unassigned

FM

9

RM_P

I

19

L+

VI

10

RM_N

I

20

M

VI

Signal names

DE1...4 DA1...4 RM_P RM_N L+, M

Digital input 1...4 Digital output 1...4 Positive input controller signal Negative input controller signal Load current supply 24 V/ground

Signal type

O I VI

Output Input Voltage input

Four digital inputs (DE1...4)

These fast inputs are PLC-compatible (24 V P-switching). Both switches and proximity sensors (2- or 3-wire sensor) can be connected to these inputs. Table 2-9

Electrical parameters of digital inputs Parameters

Value

Unit

1-signal, voltage range

11...30

V

1-signal, current input

6...15

mA


–3...5

V

Signal delay 0 ³ 1

15

µs

Signal delay 1 ³ 0

150

µs

Remarks

or input open



Input “Controller signal” (RM)

04.95 04.96 07.94 91

The ready signal of the drive power section (controller signal) can be connected to an additional input.

Note This input is not evaluated when used with the FM NC.

Table 2-10

Electrical parameters input “controller signal” Parameters

Value

Unit

15...30

V

1-signal, current input

2...6

mA


–3...5

V

Signal delay 0 ³ 1

30

µs

Signal delay 1 ³ 0

150

µs


Four digital outputs (DA1...4)

Remarks

or input open

FM

All outputs have equal priority. The switching function is assigned to the respective output number according to machine data. The four outputs are used for wiring application-specific signals. These include:

Position reached, stop Switching function M command Rotation direction forwards/backwards The outputs switch up to 0.5 A against reference ground. Table 2-11

Electrical parameters of the digital outputs Parameters

Value

Unit

1-signal, nominal voltage

24

V

Voltage drop

3

V

Output current Lamp load Switching frequency 0-signal, leakage current

0.005...0.6

A

2

W

100 0.25

Hz Hz

2

mA

Remarks

for ohmic load for inductive load



Load current supply (L+, M)

04.95 04.96 07.94 92

The device must be connected to a 24 V load current supply. Polarity reversal is not possible.

Note Follow the SIMATIC installation guidelines. Please note that terminal M (reference potential) must be connected to the frame of the automation device (terminal M at the S7-300 U terminal block). References:

/S7H/, Manual

The 24 V direct voltage must be generated as a functional extra-low voltage with safe electrical isolation (in accordance with EN 60204-1, Section 6.4, PELV).

FM


FM 354 (FM) 2.3 Displays

2.3

04.95 04.96 07.94 93

Displays

Error and status displays

12 LEDs are arranged at the front of the FM 354.

SF (red)

Group error This LED indicates an error status of the FM 354. To remove the fault, it may be necessary to carry out a restart, a firmware update or to replace a hardware component.

DIAG (yellow)

Diagnostics This LED indicates different diagnostic statuses. You can locate faults from the flashing of this LED if you do not use an operator (OP) or programmer (PG) for display.

DC 5V (green)

Logic supply switched on This LED indicates that the hardware is ready for operation. If this LED is not lit, this indicates different possibilities.

Your mains is not ok, There is a fault in the load current supply unit, The module has not been properly connected, Your control has not been configured correctly (sum of nominal and starting current is too large) or

There is a fault in the module. I0...I3 (green)

Digital inputs These LEDs indicate that the input is switched on.

Q0...Q3 (green)

Digital outputs These LEDs indicate that the output is switched on.

RM (green)

Drive unit ready This LED indicates that the drive unit is ready for operation.

FM


FM 354 (FM) 2.4 Technical data

2.4

04.95 04.96 07.94 94

Technical data

UL/CSA approval

The following is approved for S7-300: UL Recognition Mark Underwriters Laboratories (UL) in accordance with Standard UL 508, File E 116536 CSA Certification Mark Canadian Standard Association (CSA) in accordance with Standard C 22.2 No. 142, File LR 48323

FM approval

!

The following FM approval exists for S7-300: FM approval according to Factory Mutual Approval Standard Class Number 3611, Class I, Division 2, Group A, B, C, D.

Warning Risk of hazard to people or material. Risk of hazard to people or material in explosion hazardous areas with separation of plug connections with S7-300 in operation. Always disconnect S7-300 from power for separating plug connections in explosion hazardous areas.

! CE marking

Warning WARNING - DO NOT DISCONNECT WHILE CIRCUIT IS LIVE UNLESS LOCATION IS KNOWN TO BE NONHAZARDOUS

Our products meet the requirements of the EU Directive 89/336/EC ”Electromagnetic Compatibility” on the harmonized European Standards (ES) listed there. The EC Declaration of Conformity in accordance with the EU Directive, Article 10, stated above form part of this manual (see Section B).

FM




04.95 04.96 07.94 95

SINUMERIK products are designed for application in the industry. Together with an individual approval, SINUMERIK products can also be used in houses (residential or commercial buildings, small enterprises). local authorities or inspection office for individual approval. In , individual permits are given by the Ferderal Office for Telecommunication. Range of application

Demands on Noise emission

Observe directives for setup

Noise immunity

Industry

EN 50081-2 : 1993

EN 50082-2 : 1995

Residential buildings

Industrial approval

EN 50082-1 : 1992

SINUMERIK products meet the requirements if you observe the directives for setup described in the manuals for installation and operation.

FM Connected loads Table 2-12

Connected loads Parameters

Min.

Supply voltage

20.4

Power input from 24 V Power loss

Dimensions and weights

Typ.

Max.

Unit

28.8

V

0.35

A

8

W

Starting current

2.2

A

Power input from 5 V backplane bus

100

mA

5 V encoder supply max. output current

0.3

A

24 V encoder supply max. output current

0.3

A

Table 2-13

Dimensions and weights Parameters

Mounting dimensions H x W x D [mm]

125 x 80 x 118

Weight

approx. 550 g



Ambient conditions during operation

04.95 07.94 96

Table 2-14

Ambient conditions in operation Parameters

Temperature range

0...60 °C for horizontal installation 0...40 °C for vertical installation




860...1080 hPa

The operating conditions are in accordance with IEC 1131-2. The FM 354 must be installed in a cabinet.

Conditions for transport and storage

FM Table 2-15

Conditions for transport and storage Parameters

Protective quality and degree of protection

Temperature range

–40...70 °C




660...1080 hPa

Height for transportation

–1000...3000 m

Free fall

v 500 mm

Safety class I in accordance with the requirements of DIN VDE 0106 Part 1 and IEC 536. A safety earth terminal must be provided on the DIN rail. Protection against ingress of solid foreign bodies and water in accordance with type of protection IP 20 satisfying the requirements of IEC 529.

J

EC Declaration of Conformity

A

A

EC Declaration of Conformity No. 002 V 05/03/96 Manufacturer:

SIEMENS AG

Address:

SIEMENS AG AUT 2 Frauenauracherstraße 80 91056 Erlangen

Product description:

SINUMERIK 805, 805SM-P, 805SM-TW, 810, 810D, 820, 840C, 840D, FM NC, FM Servo, FM Step, FM Stepdrive SIROTEC RCM1D, RCM1P SIMODRIVE 610, 611A, 611D, MCU

The described product is in conformity with the provisions of the following European directives: 89/336/EEC Council Directive on the approximation of the law of the Member States relating to electromagnetic compatibility (amended by 91/263/EEC, 92/31/EEC and 93/68/EEC) Compliance with this directive presupposes installation of the products in the total system in conformity with electromagnetic compatibility. For system configurations in which compliance with this directive as well as applicable standards has been proven, please refer to: - Annex A1 - A11 ( System configurations ) - Annex B1 - B7 ( Components ) - Annex C ( Standards )

SIEMENS Erlangen , 05.03.1996 R. Müller Development management Name, function

P. Müller Quality ma nagement signature

Name, function

signature

The annex is a constituent part of this declaration. This declaration certifies the conformity to the specified directive but contains no assurance of other properties within the meaning of the law on product liability. The safety documentation accompanying the product shall be considered in detail.

Annex A to the EC Declaration of Conformity No. 002 V 18/12/95 A8: Typical system configuration SINUMERIK FM NC / SIMODRIVE 611A

Metal cabinet

FM NC PS U NCU 307 314 570

Operator Fil- SIMODRIVE ter 611A

*)

Mach. cont. p.

Machine base Filter

**)

LG

el. handwheel TG

M

Netzklemme

*) for I/R module **)for UE module

• All components which according to the order documents are approved for the system interconnection of SINUMERIK FM NC and SIMODRIVE 611A fulfill the 89/336/EEC Directive in the interconnected system. • For conformity with standards see Annex C Note: Only the basic measures for compliance with the Directive 89/336/EEC of a typical system configuration are shown in the sketch of the system configuration. In addition, especially in the case of deviation from this system configuration, the installation instructions for system structure in conformity with the EMC requirements of the product information and of the Siemens EMC Directive (Order No.:6ZB5410-0HX02-0AA0) must be observed.

________________________________________________________________________ ___ A-8/11

Siemens AG 1995 All Rights reserved

Abbreviations AS

Automation System

AT

Advanced Technology

COM

Communications Module

U

Central Processing Unit

DAC

Digital-to-Analog Converter

DRV

Driver Module

DP

Distributed I/Os

EMC

Electromagnetic Compatibility

ESD

Electrostatically Sensitive Devices

EXE

External Pulse Shaper Electronics

FDD

Feed Spindle Drive

FM

Function Module

HD

Hard Disk

IM

Interface Module

ISA

Industry Standard Architecture

I/R

Infeed/Regenerative Submodule

K-Bus

K Bus

MLFB

Machine Readable Product Designation

MMC

Man Machine Communication

MPI

Multi Point Interface

MSD

Main Spindle Drive

NC

Numerical Control

B

B


B Abbreviations

07.94 101

NCU

Numeric Control Unit

OP

Operator

P-Bus

I/O Bus

PCMCIA

Personal Computer Memory Card International Association

PELV

Protective Extra Low Voltage

PG

Programming device

PLC

Programmable Logic Controller

PS

Power Supply (SIMATIC S7-300 power supply)

SM

SIMATIC S7-300 signal module, e.g. input/output modules

SSI

Synchronous Serial Interface

UE

Unstabilized Supply

UI

Interfaces

VGA

Video Graphics Array

J

C

References

General documentation /W/

SINUMERIK FM-NC/SINUMERIK 840D/810D/FM-NC Brochure

/BU/

SINUMERIK FM-NC/SINUMERIK 840D/810D/FM-NC Ordering Information Catalog NC 60.1 Order No.: E86060-K4460-A101-A3-7600

/VS/

SINUMERIK FM-NC/SINUMERIK 840D/810D/FM-NC Technical Information Catalog NC 60.2 Order No.: E86060-D4460-A201-A3-7600

/Z/

SINUMERIK, SIROTEC, SIMODRIVE Accessories and Equipment for Special-Purpose Machines Catalog NC Z Order No.: E86060-K4490-A001-A4-7600

/ST7/

SIMATIC Programmable Controllers SIMATIC S7 Catalog ST 70 Order No.: E86 060-K4670-A101-A2-7600

C


C References

04.96 07.94 103

documentation /BAE/

SINUMERIK EBF Operator’s Guide, Unit Operator (04.96 Edition) Order No.: 6FC5 298-3AA60-0BP1

/AK/

SINUMERIK 840D/810D/ FM-NC Short Guide Operation AUTOTURN (09.95 Edition) Order No.: 6FC5 298-3AA30-0BP0

/BAA/

SINUMERIK 840D/810D/FM-NC Graphic Programming System AUTOTURN (09.95 Edition) Operator’s Guide –

Part 1: Programming Order No.: 6FC5 298-3AA40-0BP0

–

Part 2: Setup Order No.: 6FC5 298-3AA50-0BP0

/BA/

SINUMERIK 840D/810D/FM-NC Operator’s Guide (03.96 Edition) Order No.: 6FC5 298-3AA00-0BP1

/BAK/

SINUMERIK 840D/810D/FM-NC Short Guide Operation (03.96 Edition) Order No.: 6FC5 298-3AA10-0BP0

/PG/

SINUMERIK 840D/810D/FM-NC Programming Guide Fundamentals (03.96 Edition) Order No.: 6FC5 298-3AB00-0BP1

/PGA/

SINUMERIK 840D/810D/FM-NC Programming Guide Advanced (03.96 Edition) Order No.: 6FC5 298-3AB10-0BP1

/PAK/

SINUMERIK 840D/810D/FM-NC Short Guide Programming (03.96 Edition) Order No.: 6FC5 298-3AB30-0BP0

/BNM/

SINUMERIK 840D/810D/FM-NC ’s Guide Measuring Cycles (03.96 Edition) Order No.: 6FC5 298-3AA70-0BP1

C


C References

04.96 07.94 104

/PAZ/

SINUMERIK 840D/810D/FM-NC Programming Guide Cycles (03.96 Edition) Order No.: 6FC5 298-3AB40-0BP0

/DA/

SINUMERIK 840D/810D/FM-NC Diagnostics Guide (03.96 Edition) Order No.: 6FC5 298-3AA20-0BP0

/PI /

PCIN 4.2 Software for Data Transfer to/from MMC Module Order No.: 6FX2 060 4AA00-2XB0 (German, English, French) Order from: WK Fürth

Manufacturer/Service documentation

/LIS/

SINUMERIK 840D/810D/FM-NC Lists (03.96 Edition) Order No.: 6FC5 297-3AB70-0BP2

/BH/

SINUMERIK 840D/810D/FM-NC Operator Components Manual (03.96 Edition) Order No.: 6FC5 297-3AA50-0BP0

/PHF/

SINUMERIK FM-NC NCU 570 Manual (04.96 Edition) Order No.: 6FC5 297-3AC00-0BP0

/PHD/

SINUMERIK 840D NCU 571-573 Manual (03.96 Edition) Order No.: 6FC5 297-3AC10-0BP0

/PHG/

SINUMERIK 810D Configuring Manual (12.95 Edition) Order No.: 6FC5 297-1AD10-0BP0

/FB/

SINUMERIK 840D/810D/FM-NC Description of Functions, Basic Machine (Part 1)- (03.96 Edition) (the various sections are listed below) Order No.: 6FC5 297-3AC20-0BP1 A2 A3 B1 B2 D1

Various Interface Signals Axis Monitoring, Contour Tunnel Monitoring, Protection Zones Continuous Path Mode, Exact Stop and Look Ahead Acceleration Diagnostics Tools

C


C References

04.96 07.94 105

D2 F1 G2 K1 K2 K4 N2 P1 P3 R1 S1 V1 W1

/FB/

SINUMERIK 840D/FM-NC Description of Functions, Extended Functions (Part 2)-(03.96 Edition)including FM-NC: Turning, Stepping Motor (the various sections are listed below) Order No.: 6FC5 297-3AC30-0BP0 A4 B3 B4 F3 H1 K3 K5 L1 M1 N3 N4 P2 P5 R2 S3 S5 S6 S7 T1 W3 W4

/FB/

Interactive Programming Travel to Fixed Stop Velocities, Setpoint/Actual Value Systems, Cycle Times Mode Group, Channel, Program Operation Coordinate Systems, Axis Types, Axis Configuration, In-Process Actual Value System, External Zero Offset Communication EMERGENCY STOP Transverse Axes Basic PLC Program Reference Point Approach Spindles Feeds Tool Compensation

Digital and Analog NCK I/Os Several Operator s and NCUs Operating via PG/PC Remote Diagnostics Jog with/without Handwheel Compensations Mode Groups, Channels, Axis Exchange FM-NC Local Bus Kinematic Transformation Software Cams, Position Switching Signals Punching and Nibbling Positioning Axes Oscillation Rotary Axes Synchronous Spindles Synchronous Actions Stepping Motors Memory Configuration Indexing Axes Tool Change Grinding

SINUMERIK 840D/FM-NC Description of Functions, Special Functions (Part 3) - (03.96 Edition) (the various sections are listed below) Order No.: 6FC5 297-3AC80-0BP0 F2 G1 G3 K6 M3 M4 S8 T3

5-Axis Transformation Gantry Axes Cycle Times Contour Tunnel Monitoring Coupled Axes Measuring Cycles Constant Workpiece Speed for Centerless Grinding Tangential Control

C


C References

04.96 07.94 106

V2 W5

/FBA/

Preprocessing 3D Tool Radius Compensation

SIMODRIVE 611D/SINUMERIK 810D Description of Functions, Drive Functions (12.95 Edition) (the various sections are listed below) Order No.: 6SN1 197-0AA80-0BP0 DB1 DD1 DD2 DF1 DG1 DM1 DS1 DÜ1

Operational Messages/Alarm Reaction Diagnostic Functions Speed Control Loop Enables Encoder Parametrization Calculation of Motor/Power Section Parameters and Controller Data Current Control Loop Monitors/Limitations

/FBD/

SINUMERIK 840D/FM-NC Description of Functions, Digitizing (03.96 Edition) Order No.: 6FC5 297-2AC50-0BP1

/PK/

SINUMERIK MMC100/EBF Unit Operator Description of Functions, Configuring Kit (04.96 Edition) (the various sections are listed below) Order No.: 6FC5 297-3EA00-0BP0 EU PS

Development Kit Configuring Syntax

/IK/

SINUMERIK MMC100/EBF Unit Operator Description of Functions, Screen Kit: Software Update and Configuration (04.96 Edition) Order No.: 6FC5 297-3EA10-0BP1

/FBO/

SINUMERIK 840D/810D/FM-NC Description of Functions, Planning Guide, OP 030 Operator Interface (03.96 Edition) (the various sections are listed below) Order No.: 6FC5 297-3AC40-0BP1 BA DK PS UB

Operator’s Guide Development Kit (Configuring Kit) Configuring Syntax (Configuring Kit) Screen Kit: Software Update Guide and Configuration

C


C References

04.96 07.94 107

/FBW/

SINUMERIK 840D/810D/FM-NC Description of Functions, Tool Management (03.96 Edition) Order No.: 6FC5 297-3AC60-0BP1

/FBP/

SINUMERIK 840D Description of Functions, PLC C-Programming (03.96 Edition) Order No.: 6FC5 297-3AB60-0BP0

/PJ1/

SIMODRIVE 611-A/611-D Planning Guide Transistor PWM Inverters for AC Feed Drives and AC Main Spindle Drives Order No.: 6SN1 197-0AA00-0BP1

/PJ2/

SIMODRIVE Planning Guide AC Motors for Feed and Main Spindle Drives Order No.: 6SN1 197-0AA20-0BP1

/SP/

SIMODRIVE 611-A/611-D SimoPro 3.1 Program for Configuring Machine-Tool Drives Order No.: 6SC6 111-6PC00-0AAj Order from: WK Fürth

/S7H/

SIMATIC S7-300 Manual (HW Description) Order No.: 6ES7 030-0AA01-8AA0

/S7HT/

SIMATIC S7-300 Manual, Using the Tools (SW description) Order No.: C79000-B7000-C102

(11.95 Edition)

(08.95 Edition)

/S7S/

SIMATIC S7-300 FM 353 Positioning Function Module for Step Drive Order together with Configuring Kit (6ES7 353-1AH00-7AG0)

/S7L/

SIMATIC S7-300 FM 354 Positioning Function Module for Step Drive Order together with Configuring Kit (6ES7 354-1AH00-7AG0)

/FBST/

SIMATIC FM STEPDRIVE/SIMOSTEP Description of Functions Order No.: 6SN1 197-0AA70-0YP0

C


C References

04.96 07.94 108

/EMV/

EMC Guidelines for SINUMERIK and SIROTEC Controls Manual Order No.: 6ZB5 410-0HX01-0AA0

/IAF/

SINUMERIK FM-NC Installation & Start-up Guide (04.96 Edition) Order No.: 6FC5 297-3AB00-0BP0

/IAD/

SINUMERIK 840D Installation & Start-up Guide (03.96 Edition) (including description of start-up software SIMODRIVE 611D) Order No.: 6FC5 297-3AB10-0BP1

/IAG/

SINUMERIK 810D Installation & Start-up Guide (12.95 Edition) (including description of start-up software SIMODRIVE 611D) Order No.: 6FC5 297-1AD20-0BP0

/IAA/

SIMODRIVE 611A Installation & Start-up Guide (01.96 Edition) Order No.: 6SN 1197-0AA60-0BP3

J

C

Snumerik Ncu 570.pdf q4f68

Overview 5o1f4z

More details 6z3438

Related Documents c2h70

Snumerik Ncu 570.pdf q4f68

The Ncu Northerner | Nov. 2018 z4q2r

6fc5247 0aa00 0aa1 Ncu Box Sinumerik 840d Siemens Manual 3x33r

More Documents from "Nicole Gibson" 1v5065

Snumerik Ncu 570.pdf q4f68

Form Fisioterapi 524p1o

Eurotherm 3208 Controller Manual Pdf 2r54s

Feminism A Very Short Introduction Margaret Walters Non Fiction Mobiepubpdf K Slender 4j4o35

Eric Clapton Reptile Pdf s5i3r
