Uninterruptible Power Supply (UPS) Batteries & Brackets Product Bulletin Code No. LIT-12011183 Issued April 10, 2006
Introduction Johnson Controls offers a secondary power (battery backup) solution for devices housed in S300 enclosures, providing continuous, temporary power to critical Cardkey® security controllers and field devices in the event of a power failure. The following batteries and bracket kits are available for purchase: •
S300-BAT (Battery)
•
S300-BAT-2.8AH (Battery)
•
S300-DIN-BRK (Bracket Kit for S300-DIN Enclosures
•
S300-BRK2 (Bracket Kit for S300-XL, S300-XS, and S300-XXS Enclosures)
Figure 1: S300-BAT Battery
Features and Benefits •
UPS backup keeps critical systems up and running during a power failure.
•
Batteries are activated by power-fail sense circuitry on Cardkey controllers.
•
One to three hours of battery backup on a fully loaded system, depending on the controller or field device.
•
All batteries are U.L. listed.
•
Long shelf life in ambient temperatures.
•
Batteries can be easily replaced without ordering an additional bracket kit.
Figure 2: S300-BAT-2.8AH Battery
Battery Type and Quantity for Backup Table 2 lists the type and quantity of batteries required for a battery backup system according to the type of enclosure being used. Table 2: Battery Type and Quantity for Backup
Backup Battery Ratings
Enclosure
Battery
Table 1 lists the number of hours of backup power the batteries provide on a fully loaded system.
S300-XL, S300-XS, & S300-XXS
S300-BAT
1
S300-BRK2
S300-DIN-L
S300-BAT
2
S300-DIN-BRK
S300-DIN-S
S300-BAT2.8AH
2
S300-DIN-BRK
Table 1: Backup Battery Ratings Device
No. of Battery Backup Hours
CK705
3
CK720
3
CK721
1
S300-DIN-RDR2S
1
S321-DIN
1
Qty.
Bracket
Note: Each battery and bracket kit are sold separately.
Uninterruptible Power Supply (UPS) Batteries & Brackets Product Bulletin
1
S300-BAT Battery This battery is a Power Sonic®, Model PS-1270, 12 VDC, 7 Ah, sealed lead acid battery. Table 3: S300-BAT Specifications Description
Specification
Nominal Voltage
12 volts
Nominal Capacity 20 hour rate (350mA to 10.50 volts)
7.0 A.H.
10 hour rate (650mA to 10.50 volts)
6.5 A.H.
5 hour rate (1.2A to 10.20 volts)
6.0 A.H.
1 hour rate (4.5A to 9.00 volts)
4.5 A.H.
15 min rate (14A to 9.00 volts)
3.5 A.H.
Energy Density (20 hour rate)
1.43 Watt-hours/cubic inch (87.3 Watt-hours/l)
Specific Energy (20 hour rate)
14.7 Watt-hours/pound (32.4 Watt-hours/kg)
Internal Resistance (Fully Charged Battery)
22 milliohms (approximately)
Maximum Discharge Current ( <_ 7 Min.)
21 amperes
Maximum Short-Duration Discharge Current ( <_ 10 Sec.)
70 amperes
Terminal configurations
Quick disconnect tabs, “F1”: 0.187” x 0.032”, mate with AMP. INC. FASTON “187” Quick disconnect tabs, “F2”: 0.250” x 0.032”, mate with AMP. INC. FASTON “250”
Shelf Life — % of nominal capacity at 68°F (20°C) 1 Month
97%
3 Months
91%
6 Months
83%
Operating Temperature Range Charge
-4°F (-20°C) to 122°F (50°C)
Discharge
-4°F (-20°C) to 140°F (60°C)
Case
ABS Plastic
Weight
5.70 pounds (2.59 kg)
Dimensions
2.56W x 5.95L x 3.70H inches 65W x 151L x 94H mm
2
Uninterruptible Power Supply (UPS) Batteries & Brackets Product Bulletin
S300-BAT-2.8AH Battery This battery is a Power Sonic, Model PS-1228, 12VDC, 2.8Ah, sealed lead acid battery. Table 4: S300-BAT-2.8AH Specifications Description
Specification
Nominal Voltage
12 volts
Nominal Capacity 20 hour rate (140mA to 10.50 volts)
2.80 A.H.
10 hour rate (250mA to 10.50 volts)
2.50 A.H.
5 hour rate (480mA to 10.20 volts)
2.40 A.H.
1 hour rate (1700mA to 9.00 volts)
1.70 A.H.
15 min rate (5300mA to 9.00 volts)
1.32 A.H.
Energy Density (20 hour rate)
1.29 Watt-hours/cubic inch (78.9 Watt-hours/l)
Specific Energy (20 hour rate)
12.9 Watt-hours/pound (24.47 Watt-hours/kg)
Internal Resistance (Fully Charged Battery)
45 milliohms (approximately)
Maximum Discharge Current ( <_ 7 Min.)
8.4 amperes
Maximum Short-Duration Discharge Current ( <_ 10 Sec.)
28 amperes
Terminals
“F1”: Quick disconnect tabs, 0.187" x 0.032"- Mate with AMP. INC. FASTON “187” series
Shelf Life — % of nominal capacity at 68°F (20°C) 1 Month
97%
3 Months
91%
6 Months
83%
Operating Temperature Range Charge
-4°F (-20°C) to 122°F (50°C)
Discharge
-4°F (-20°C) to 140°F (60°C)
Case
ABS Plastic
Weight
2.6 pounds (1.18 kg)
Dimensions
1.30W x 5.24L x 4.09H inches 33W x 133L x 104H mm
Uninterruptible Power Supply (UPS) Batteries & Brackets Product Bulletin
3
S300-DIN-BRK Bracket Kit
S300-BRK2 Bracket Kit
The S300-DIN-BRK bracket kit is used to mount S300BAT batteries to S300-DIN-L enclosures and S300BAT-2.8AH batteries to S300-DIN-S enclosures.
The S300-BRK2 bracket kit is used to mount the S300BAT battery to S300-XL, S300-XS, and S300-XXS enclosures.
Each kit contains the following:
Each kit contains the following:
•
Two brackets
•
One bracket
•
Mounting hardware
•
Mounting hardware
•
Short battery cable assembly (S300-DIN-S enclosures only)
•
Short battery cable assembly (S300-XXS enclosures only)
•
Long battery cable assembly (S300-DIN-L enclosures only)
•
Long battery cable assembly (S300-XL and S300XS enclosures only)
•
Two adhesive cable tie mounting pads
•
Two adhesive cable tie mounting pads
•
Two cable ties
•
Two cable ties
Ordering Information Table 5: Ordering Information Part Number
Description
S300-BAT
12 V, 7.2 AHr battery for S300-DIN-L, S300-XL, S300-XS, & S300-XXS enclosures.
S300-BAT-2.8AH
12 V, 2.8 AHr battery for S300-DIN-S enclosures.
S300-DIN-BRK
Battery bracket kit for S300-DIN-L and S300-DIN-S enclosures.
S300-BRK2
Battery bracket kit for S300-XL, S300XS, and S300-XXS enclosures.
Figure 3: S300-DIN-BRK Battery Bracket Kit
