Requirement Specifications Document For Kids And Babies Day Care Center 1j6t61
This document was ed by and they confirmed that they have the permission to share it. If you are author or own the copyright of this book, please report to us by using this report form. Report 2z6p3t
Overview 5o1f4z
& View Requirement Specifications Document For Kids And Babies Day Care Center as PDF for free.
More details 6z3438
- Words: 4,461
- Pages: 32
Muhammad Salman Habib
Page 1
1/15/2009
Muhammad Salman Habib
Page 2
Index 1. Introduction a. Goals and Objectives b. Statement of Scope c. Software Context d. Major Constraints 2. Scenarios a. Profiles b. Use-cases c. Use-case Diagrams d. Use-case Descriptions 3. Data Model a. Data Objects b. Relationships c. Complete Data Model 4. Functional Model and Description a. Class Diagrams b. Software Interface Description 5. Behavioral Model a. Events and States b. State-chart Diagram 6. Limitation and Constraints 7. Test Cases a. Classes of Test b. Expected Software Response c. Performance Bounds
1/15/2009
Muhammad Salman Habib
Page 3
1/15/2009
Introduction The goal of deg software for a “Day care center” is to provide a complete Day Care Management system, keeping the day care provider and clients in mind. It is essentially an electronic filing cabinet that maintains a complete record of clients and employee information. The clients are the customers that is, parents and children. The system maintains information such as parents and child address and their personal data in a database. The software system is modeled and designed such that it has the seamless integration between all feature based elements that makes it very friendly. s of the software have the ability to add/update/delete all information based on their access levels. Secure entry into the system is envisaged through all employees being identified by a unique ID and given . Family & child data collection is a fundamental requirement for all Child Care businesses. Our collection capabilities are robust and simple with an ease of use that makes the task of data entry quick and efficient.
a. Goals and Objectives: The objective of the software is to build a tool for the use for a day care management With the following features: 1. Create data base for family and child information with features: Parent names, addresses, phone numbers, email addresses, emergency s, authorized pickups, Child Name, Birth Date, and Class. 2. Immunization tracking information: recording immunization types, physicals and dates. Classroom Tracking & Scheduling Classrooms, programs, activities schedules.
Muhammad Salman Habib
Page 4
1/15/2009
3. Waiting List & Potential Customer Tracking, Daily Reminders, appointments, contract renewals. 4. Customer Log Notes, Maintain records of correspondence with parents, children special need, incident reports, and more. 5. is required for all s. 6. s be divided into groups and access is granted on a per group basis. 7. We aim to provide continuity throughout each phase of a project. 8. activity reports and receipt printing. Track each family’s balance including their child care billing history of registration fees, tuition charges, family discounts and payments received. Billing History, history of registration fees, tuition charges, family discounts and payments 9. Generate a report of all the expenses. 10.We also aim to design the software to be much friendly, all the interfaces to be self descriptive and interactive.
b. Statement of Scope: As per the requirements of the client, different functionality has been designed keeping in view the constraints of time and manpower. The major software inputs are the parents and child information and major outputs are billing forms, receipts etc. The software very closely matches the requirements laid down by the end s, viz. Employees, s. It maintains a data repository containing the information related to each child. It has the required features of parent and child information, tracking each child for
Muhammad Salman Habib
Page 5
1/15/2009
information related to his/her done through interface which manages efficiently and thoroughly all issues related to child. There are requirements, which are desirable and would increase the scope of the final product if incorporated in the project. One such feature is incorporating additional features such making appointments and contract renewals through web based service, which would be added in near future, due to time constraints. All major functionality, which falls in the category of essential and desirable prioritization of the day care centre software, will be implemented with an attempt to model the future priority needs as well if time permits.
REQUIREMENT PRIORITIES Requirement
Requirement
Description
reference
Priority
Secure
, unique ID
Specification
Essential
number
R0
documentation template R1
R2
R3
R4
Secure
, 6-8
Specification
alphanumeric only
documentation
Store child
Child full-name, SSN,
template Specification
information
Birthday,
documentation
Store parent
Parent full name, SSN,
template Specification
information
address, emergency
document
Child
s Child ID, child name
template Specification
immunization
Immunization tracking,
document
immunization type, date
template
of immunization, due date, doctors name.
Essential
Essential
Essential
Essential
Muhammad Salman Habib
R5
R6
Class
Expenses
Page 6
1/15/2009
class activities,
Specification
class schedules, class
document
room tracking, instructor
Template
building maintenance
Specification
electricity
document
Essential
Essential
template R7
Profile
employee ability to
Specification
management
change
document
Desirable
template R8
Child status
Active, inactive
Specification
Essential
document R9
Report
Customer log notes,
template Group Decision
Desirable
Web
Future
correspondence records, child special notes, child R10
Scheduling
immunization history, Appointment, contract
R11
Information Employee
Renewal SSN, name , address ,
information
phone number, gender, email address, birth date.
Muhammad Salman Habib R12
R13
R14
Page 7
1/15/2009
Billing
Tuition charges, Late fee, Specification
Information
family discount &
document
payments, print balance
template
Billing
Charging late fee for
Specification
information
overdue payment
document
Using electronic ID
template System Access
Security
Essential
Future
Future
c. Software Context: As per the requirements of the client, different functionality has been designed keeping in view the constraints time and manpower. The major software inputs are the parents and child information and major outputs are billing forms, receipts etc. The software very closely matches the requirements laid down by the end s, viz. Employees, s. It maintains a data repository containing the information related to each child, parent. It has the required features of tracking each child for information related to each individual done through interface which manages efficiently and thoroughly all issues related to child development and needs. There are requirements, which are desirable and would increase the scope of the final product if incorporated in the project. One such feature is incorporating additional features such making appointments and contract renewals through web based service, which would be added in near future, due to time constraints. All major functionality, which falls in the category of essential and desirable prioritization of the day care centre software, will be implemented with an attempt to model the future priority needs as well if time permits.
d. Major Constraints: There are few points that we have not covered like loss of unsaved data, any sort of security feature. No restoring facility has been provided. Our software system is not redundant that is there is no backup facility. The system also depends on the network that
Muhammad Salman Habib
Page 8
1/15/2009
is its speed. If the speed of the network is not sufficient there is a likelihood of slow response. DOTNET framework has to be installed on the web server since the software runs of DOTNET environment. And moreover we need a high performance web server for good performance.
Usage Scenario a. Profiles: The profiles are divided into three types in this system. 1. Parent: A parent will have the accessibility to view their child’s information and schedule. They are restricted to very low profile when compared to others. 2. Employee: An employee can view the billing information of all children along with viewing and updating the privileges given to parent. 3. : He can access, view, delete and update all the information available in the website. He is given all the privileges.
b. Use-Cases: A Use-Case Diagram is used to depict the main aspects of the system and the ways a can interact with the system. Separate use cases and their description follows the Use-case diagram below.
Muhammad Salman Habib
Page 9
1/15/2009
c. Use Case Diagrams: Please refer the next page for the figure. Manage Children
«uses»
Manage Classes
«uses» «uses» «uses» «uses» «uses» «uses» «uses» Employee
«uses» «uses» «uses» «uses» «uses»
Manage Activities
Manage Child Immunization «uses» Manage child Schedule
«uses» «uses»
«uses»
«uses» «uses»
Parent Manage Parent Info
«uses» «uses»
Manage Payments on Child A/C
Manage Billing on Child A/C
Manage Expenses
This is the system use-case diagram that displays all the different tasks that are accomplished by the system. Following this, we will have brief description of each of these use-cases.
Muhammad Salman Habib
Page 10
1/15/2009
d. Use-Case Descriptions: 1. Manage Children:
«uses»
Employee
«uses»
Manage Children
Objective: and Employee will be able to add, delete and update child information.
Pre-condition: has logged in successfully as or Employee. Post-condition: NA Main Flow: 1. System displays a form with editable fields for child's information. For Add, it would be empty fields and for Edit child info, there will be child information for selected child 2. /Employee fills out new child information or edits the existing child info [A1] 3. /Employee hits submit button on the page 4. System saves the child information in database 5. System notifies the
Muhammad Salman Habib
Page 11
1/15/2009
Alternative flow: A1 1. /Employee presses delete button on edit child info page 2. System asks for confirmation on child delete 3. On confirm, system checks whether the child's has any bills due 4. If payment is due on child A/C, System notifies the employee of due bill 5. On confirm system adds the amount in Day care Expenses table 6. System deletes the child from database 7. is notified 2. Manage Class:
«uses»
Manage Classes
Employee «uses»
Objective: Employee/ can add, delete or update a class information. Pre-condition: has successfully logged in as Employee/ Main Flow: 1. Employee/ can either select a class from dropdown list and modify the fields and edit it, or they can add a new class and finally click submit.
Muhammad Salman Habib
Page 12
1/15/2009
2. On submit, the system performs validation and adds the class to database or updates the class.
Alternative Flow: 1. Employee/ can select one class from drop down list, and can click delete button. 2. System asks for confirmation and on confirm, system deletes the class from database. 3. Manage Activities:
«uses»
Manage Activities
Employee «uses»
Objective: Employee/ can add, delete or update a activity. Pre-condition: has successfully logged in as Employee/ Main Flow: 1. Employee/ can either select an activity from dropdown list and modify the fields and edit it, or they can add a new activity and finally click submit 2. On submit, the system performs validation and adds the class to database or updates the activity
Muhammad Salman Habib
Page 13
1/15/2009
Alternative Flow: 1. Employee/ can select one activity from drop down list, and can click delete button. 2. System asks for confirmation and on confirm, system deletes the activity from database. 4. Manage Child Immunization:
«uses»
Manage Child Immunization
Employee
«uses»
«uses»
Parent
Objective: Employee/ can add child immunization information, can also update or delete an immunization record
Pre-condition: must have successfully logged in as an employee or Post-condition: Employee/ updates child's immunization information Main Flow:
Muhammad Salman Habib
Page 14
1/15/2009
1. System shows the the child's immunization information. 2. When applying immunizations to the child, the Employee/ can add information about child's immunization info @ date, type of immunization, physicals... etc. and press submit.
3. System stores this information in database
Alternative flow: 1. can also edit or delete an immunization entry 2. Select an immunization entry from the list, to edit, or click delete 3. System deletes or updates the information from database
5. Manage child Schedule:
Muhammad Salman Habib
Page 15
1/15/2009
«uses»
Manage Child Immunization
Employee
«uses»
«uses»
Parent
Objective: Add or delete a class or activity in a child's schedule, A parent can only view child schedule, cant update it
Pre-condition: has logged into the system as Employee or , to view Parent have to be logged in as parent
Post-condition: Employee/ can update child's schedule Main Flow: 1. Employee/ selects a class or an activity to the student's schedule 2. System checks if there is already another class existing at the same time 3. If there is no class at the same time then the class is added, activities have more priority than class 4. Information is stored in the database and is notified of that
Alternative flow: 1. Parent can view the student schedule online
Muhammad Salman Habib
Page 16
1/15/2009
2. Parent logs in and chooses to view the child's schedule 3. system fetches the schedule information of that child from database and displays in proper format 6. :
«uses» «uses» Employee
«uses»
Parent
Objective: Log the into the system and direct him to the proper interface(webpage) Pre-condition: NA Post-condition: is logged into a system and sees an /Employee/Parent interface
Main Flow: 1. System shows the a screen with editable boxes for name, and a dropdown menu for category: Employee, or Parent 2. puts name and and then selects a category from the dropdown list 3. hits submit 4. System authenticates the name and
Muhammad Salman Habib
Page 17
1/15/2009
5. System shows the proper interface as per selection, if the authentication is successful
Alternative Flow: 1. If the name and don’t match, the system shows screen again 7. Manage Parent Info:
«uses» «uses» Employee
Manage Parent Info «uses»
Parent
Objective: and Employee will be able to add, delete and update Parent information.
Pre-condition: has logged in successfully as or Employee. Post-condition: NA Main Flow: 1. System displays a form with editable fields for parent's information. For Add, it would be empty fields and for Edit child info, there will be Parent information for selected parent
Muhammad Salman Habib
Page 18
1/15/2009
2. /Employee fills out new child information or edits the existing parent info and selects the child(/children) the parent is associated with [A1] 3. /Employee hits submit button on the page 4. System saves the parent information in database 5. System notifies the
Alternative flow: A1 1. /Employee presses delete button on edit Parent info page 2. System asks for confirmation on Parent delete 3. On confirm, system checks whether the Parent is the only parent for any children 4. If parent is the only parent for any child, System notifies the employee of it, no changes made to database 5. If that is not the case, System deletes the child from database 6. is notified 8. Manage Payments on Child A/C:
«uses»
Manage Payments on Child A/C
Objective: should be able to add update or delete a payment to a child's Pre-condition: must be logged in as an Post-condition: can add update or delete records for payment to a child
Muhammad Salman Habib
Page 19
1/15/2009
Main Flow: 1. selects a child 2. System displays a button saying Add payment on top, and displays all the Payment entries below it, with edit and delete buttons [A1] 3. goes to edit billing page with blank editable fields for add entry or editable fields with data for the selected record 4. makes changes to the fields and hits submit button 5. System does the validation and adds an entry in the database 6. is notified
Alternative Flow A1: 1. selects delete button next to one of the payment records 2. The payment record is deleted from database 3. is notified 9. Manage Billing on Child A/C:
«uses»
Manage Billing on Child A/C
Objective: should be able to add update or delete a bill to a child's Pre-condition: must be logged in as an Post-condition: can add update or delete records for billing from a child
Muhammad Salman Habib
Page 20
1/15/2009
Main Flow: 1. selects a child 2. System displays a button saying Add billing on top, and displays all the billing entries below it, with edit and delete buttons [A1] 3. goes to edit billing page with blank editable fields for add entry or editable fields with data for the selected record 4. makes changes to the fields and hits submit button 5. System does the validation and adds an entry in the database 6. is notified
Alternative Flow A1: 1. selects delete button next to one of the billing records 2. The billing record is deleted from database 3. is notified 10. Manage Expenses:
«uses» Manage Expenses
Objective: should be able to add update or delete expenses Pre-condition: must be logged in as an
Muhammad Salman Habib
Page 21
1/15/2009
Post-condition: can add update or delete records for day care expenses into the system
Main Flow: 1. System displays a button saying Add Expense on top, and displays all the expenses records below it, with edit and delete buttons [A1] 2. goes to edit expenses page with blank editable fields for add entry or editable fields with data for the selected record 3. makes changes to the fields and hits submit button 4. System does the validation and adds an entry in the database 5. is notified
Alternative Flow A1: 1. selects delete button next to one of the expenses record 2. The expense record is deleted from database 3. is notified
Data Model
a. Data objects: The major data objects that we are using in the system are basically the main entities that are described in the requirements. •
Child
•
Parent
Muhammad Salman Habib •
Classes
•
Activities
•
Schedule
•
Billing
•
Payment
•
Expense
Page 22
1/15/2009
We will describe them as classes in the next section and identify their essential attributes and essential operation that are performed on these objects.
b. Relationships: We identify the relationships between two or more Data objects and describe them below:
c. Complete data model
class
-Manages *
-Has 1
*
-has
schedule
*
* *
activity
Child
-Has *
* * *
*
*
* *
billing
-Views * *
Parent
*
-Views
Parent
* -Views *
payment
* *
-Manages * -Manages * * -Manages -Manages -Manages *
Employee
*
-Manages -Manages -Manages * * * Employee
* Expenses
*
Muhammad Salman Habib
Page 23
1/15/2009
The next section will take each of these data object and describe them as a class, mentioning the important attributes and operations.
Functional Model and Description a. Class Diagrams: Here we have all the classes that we will consider for deg the system. We take care that all the Use-cases that we want to accomplish and all the operations can be performed by the use of following classes. 1. child -SSN -Name -BirthDate -Gender -FirstParent +AddChild() +UpdateChild() +DeleteChild()
2. This is one of the actor classes Parent -SSN -Name -BirthDate -Gender -ID - -Address -EmailAddress -PhoneNumber +AddParent() +UpdateParent( ) +DeleteParent() +ViewChildrenSchedule() +ViewChildrenImmunization() +ViewBilling()
Muhammad Salman Habib 3. This is the other actor class Employee -SSN -Name -BirthDate -Gender -ID - - -Address -EmailAddress -PhoneNumber +AddEmployee() +UpdateEmployee() +DeleteEmployee() +ManageChildren() +ManageParent() +ManageClasses() +ManageActivities() +ManageSchedules() +ManageBilling() +ManagePayment() +ManageExpenses() +ManageImmunization()
4. Class -ClassID -ClassName -Instructor -Description -Timing1 -Timing2 +AddClass() +UpdateClass() +DeleteClass()
5. Activity -ActID -ActName -Instructor -Description -Timing +AddActivity() +UpdateActivity() +DeleteActivity()
Page 24
1/15/2009
Muhammad Salman Habib 6. ChildSchedule -SchID -ChildID -ClassAct -ClassID -ActID +AddSchedule() +UpdateSchedule() +DeleteSchedule()
7. BillingInfo -BillingID -BillingDescription -BillingAmount +AddBill() +UpdateBill() +DeleteBill()
8. PaymentInfo -PaymentID -PaymentDescription -PaymentAmt +AddPayment() +UpdatePayment() +DeletePayment()
9. ExpenseInfo -ExpenseID -ExpenseDesc -ExpenseAmt +AddExpense() +UpdateExpense() +DeleteExpense()
Page 25
1/15/2009
Muhammad Salman Habib
Page 26
1/15/2009
b. Software Interface Description: Our software system is a simple, friendly web based solution. It has no external system interfaces and no external machine interfaces. It has only a human interface that is a GUI(Graphical Interface). GUI is basically the interface description of the software system contained in the requirement documentation. There are three types of human interfaces in our system namely employee, parent, which will be interacting with the software system. Although we can have an external system interface by maintaining database in a different server but the depends on the size of the database
Behavioral Model and Description
The behavioral model indicates how software will respond to external events or stimuli. It depicts the dynamic behavior of the system as a function of specific events and time. These specific events are triggered by the actors who use the system. There are three types of actors in this system depending on their access levels. 1. Parent: A parent can and only view class schedule, billing information and immunization information of his/her child. He cannot make any type of modifications to the information displayed. 2. Employee (Staff): An employee’s accessibility is also limited. An Employee can view and make changes to class schedules, activities, and child and parent information and also to immunization information.
Muhammad Salman Habib
Page 27
1/15/2009
3. : has no restrictions in accessing any type of information or updating it. He can manage the
a. Description for software behavior To better understand the behavioral model of this system, the events which result in different states are listed below. The actors who trigger the particular event are also listed.
Events: Event: Actor: Parent/Employee/ Event: View class schedule Actor: Parent Event: View Billing Information Actor: Parent Event: View Immunization Information Actor: Parent Event: View/Delete/Update Classes Actor: Employee/ Event: View/Delete/Update Activities Actor: Employee/ Event: View/Delete/Update Immunization Information
Muhammad Salman Habib
Page 28
1/15/2009
Actor: Employee/ Event: View/Delete/Update Child Information Actor: Employee/ Event: View/Delete/Update Parent Information Actor: Employee/ Event: View/Delete/Update Billing Information Actor: Event: View/Delete/Update Payment Information Actor: Event: View/Delete/Update Expenses Information Actor: Event: Actor: Parent/Employee/
States: A state is any observable mode of behavior and a state diagram depicts the actions taken as a consequence of a particular event. The whole system is divided into 3 states namely depending on the access levels. Two other states are also defined to enter and exit the system. The states are as follows: 1. : By entering a valid id, and the type of , he will gain access to the system.
Muhammad Salman Habib
Page 29
1/15/2009
2. : By entering valid information, the can enter this state and will be able to perform all the operations he can access and make changes to the database. Generally he has the control of the whole system. He can exit the system by logging out. 3. Employee: After logging into the system, an employee can manage the system depending on his access level. He has certain limitations in accessibility. Logging out of the system will take him to state. 4. Parent: A parent can enter the system by entering valid id and . After entering the system, can view his own child’s information. He cannot make any kind of changes to the database. Exits the system by logging out. 5. : will be taken to this state once he logs out of the system. Here he can go back to state through re- information.
Muhammad Salman Habib
Page 30
1/15/2009
b. Statechart Diagram: Initial State
Enter ID Enter Select type
Home Employee Home Parent Home View Class Schedule View Billing Information View Immunization Information
View, delete and Update Class Schedule View, delete and Update Immunization Information View, delete and Update Activities View, delete and Update Child Information View, delete and Update Parent Information
again
Final State
View, delete and Update Class Schedule View, delete and Update Immunization Information View, delete and Update Activities View, delete and Update Child Information View, delete and Update Parent Information View, delete and Update Billing Information View, delete and Update Payment Information View, delete and Update Expenses Information
Muhammad Salman Habib
Page 31
1/15/2009
Restrictions, Limitations & Constraints •
The size of the database is restricted to few hundreds.
•
The software doesn’t have any security features, network features or doesn’t have any compatibility for it. So software has to be further developed to deploy it network.
•
It is developed in such a way that the employee can work only on one interface and therefore employee cannot open multiple interfaces and perform task simultaneously.
•
Some applications can only be used by e.g. change the fees structure of children, add or remove the employees etc.
•
The Graphical Interface (GUI) is planned to be developed in Java 1.5 or above and the minimum hardware requirements are: 1. Intel® Pentium® III processor (or higher preferred) 2. 256 MB memory 3. 20MB free disk space 4. Windows 2000/Xp/Vista
Validation Criteria The validation criteria for the software system is such that the information provided in the fields is checked for the correct format and if any information of child or parent is found to be wrong or missing then it will not be able to enter the database. Business rules are validated that is: only the can change certain things such as billing information, add and remove employee’s names etc. Each has a unique ID and provided by the .
Muhammad Salman Habib
Page 32
1/15/2009
a. Classes of Tests: The inputs are going to be entered erroneously to check the system performance. Basically test cases are going to be developed by using brainstorm sessions. This will help us to figure out behavior of system and performance of the system. Method of testing: •
The system’s internal structure will be tested (white box testing)
•
The overall system will be tested (black box testing)
•
Specimen test cases: 1. Click add button to add the parent without his or her social security number. 2. Click staff information to add or remove the name of employee from the staff . 3. Click add button to add the child without his or her parent information.
b. Expected Software Response This software will perform certain operations like Add, Remove or Update the detail Information of child, parent, employee, etc. It will keep track of billing, Immunization and class activities. When searching for a particular child a unique id will be specified and all the information about the child will be displayed.
c. Performance Bounds The major performance bound in our software system is the size of the database although this could be improved by using another external system interface. The performance of the software in of response time is at best immediately or at worst 20 seconds. A major factor pertaining to response time is the network speed. END OF Requirement Specifications Document
Page 1
1/15/2009
Muhammad Salman Habib
Page 2
Index 1. Introduction a. Goals and Objectives b. Statement of Scope c. Software Context d. Major Constraints 2. Scenarios a. Profiles b. Use-cases c. Use-case Diagrams d. Use-case Descriptions 3. Data Model a. Data Objects b. Relationships c. Complete Data Model 4. Functional Model and Description a. Class Diagrams b. Software Interface Description 5. Behavioral Model a. Events and States b. State-chart Diagram 6. Limitation and Constraints 7. Test Cases a. Classes of Test b. Expected Software Response c. Performance Bounds
1/15/2009
Muhammad Salman Habib
Page 3
1/15/2009
Introduction The goal of deg software for a “Day care center” is to provide a complete Day Care Management system, keeping the day care provider and clients in mind. It is essentially an electronic filing cabinet that maintains a complete record of clients and employee information. The clients are the customers that is, parents and children. The system maintains information such as parents and child address and their personal data in a database. The software system is modeled and designed such that it has the seamless integration between all feature based elements that makes it very friendly. s of the software have the ability to add/update/delete all information based on their access levels. Secure entry into the system is envisaged through all employees being identified by a unique ID and given . Family & child data collection is a fundamental requirement for all Child Care businesses. Our collection capabilities are robust and simple with an ease of use that makes the task of data entry quick and efficient.
a. Goals and Objectives: The objective of the software is to build a tool for the use for a day care management With the following features: 1. Create data base for family and child information with features: Parent names, addresses, phone numbers, email addresses, emergency s, authorized pickups, Child Name, Birth Date, and Class. 2. Immunization tracking information: recording immunization types, physicals and dates. Classroom Tracking & Scheduling Classrooms, programs, activities schedules.
Muhammad Salman Habib
Page 4
1/15/2009
3. Waiting List & Potential Customer Tracking, Daily Reminders, appointments, contract renewals. 4. Customer Log Notes, Maintain records of correspondence with parents, children special need, incident reports, and more. 5. is required for all s. 6. s be divided into groups and access is granted on a per group basis. 7. We aim to provide continuity throughout each phase of a project. 8. activity reports and receipt printing. Track each family’s balance including their child care billing history of registration fees, tuition charges, family discounts and payments received. Billing History, history of registration fees, tuition charges, family discounts and payments 9. Generate a report of all the expenses. 10.We also aim to design the software to be much friendly, all the interfaces to be self descriptive and interactive.
b. Statement of Scope: As per the requirements of the client, different functionality has been designed keeping in view the constraints of time and manpower. The major software inputs are the parents and child information and major outputs are billing forms, receipts etc. The software very closely matches the requirements laid down by the end s, viz. Employees, s. It maintains a data repository containing the information related to each child. It has the required features of parent and child information, tracking each child for
Muhammad Salman Habib
Page 5
1/15/2009
information related to his/her done through interface which manages efficiently and thoroughly all issues related to child. There are requirements, which are desirable and would increase the scope of the final product if incorporated in the project. One such feature is incorporating additional features such making appointments and contract renewals through web based service, which would be added in near future, due to time constraints. All major functionality, which falls in the category of essential and desirable prioritization of the day care centre software, will be implemented with an attempt to model the future priority needs as well if time permits.
REQUIREMENT PRIORITIES Requirement
Requirement
Description
reference
Priority
Secure
, unique ID
Specification
Essential
number
R0
documentation template R1
R2
R3
R4
Secure
, 6-8
Specification
alphanumeric only
documentation
Store child
Child full-name, SSN,
template Specification
information
Birthday,
documentation
Store parent
Parent full name, SSN,
template Specification
information
address, emergency
document
Child
s Child ID, child name
template Specification
immunization
Immunization tracking,
document
immunization type, date
template
of immunization, due date, doctors name.
Essential
Essential
Essential
Essential
Muhammad Salman Habib
R5
R6
Class
Expenses
Page 6
1/15/2009
class activities,
Specification
class schedules, class
document
room tracking, instructor
Template
building maintenance
Specification
electricity
document
Essential
Essential
template R7
Profile
employee ability to
Specification
management
change
document
Desirable
template R8
Child status
Active, inactive
Specification
Essential
document R9
Report
Customer log notes,
template Group Decision
Desirable
Web
Future
correspondence records, child special notes, child R10
Scheduling
immunization history, Appointment, contract
R11
Information Employee
Renewal SSN, name , address ,
information
phone number, gender, email address, birth date.
Muhammad Salman Habib R12
R13
R14
Page 7
1/15/2009
Billing
Tuition charges, Late fee, Specification
Information
family discount &
document
payments, print balance
template
Billing
Charging late fee for
Specification
information
overdue payment
document
Using electronic ID
template System Access
Security
Essential
Future
Future
c. Software Context: As per the requirements of the client, different functionality has been designed keeping in view the constraints time and manpower. The major software inputs are the parents and child information and major outputs are billing forms, receipts etc. The software very closely matches the requirements laid down by the end s, viz. Employees, s. It maintains a data repository containing the information related to each child, parent. It has the required features of tracking each child for information related to each individual done through interface which manages efficiently and thoroughly all issues related to child development and needs. There are requirements, which are desirable and would increase the scope of the final product if incorporated in the project. One such feature is incorporating additional features such making appointments and contract renewals through web based service, which would be added in near future, due to time constraints. All major functionality, which falls in the category of essential and desirable prioritization of the day care centre software, will be implemented with an attempt to model the future priority needs as well if time permits.
d. Major Constraints: There are few points that we have not covered like loss of unsaved data, any sort of security feature. No restoring facility has been provided. Our software system is not redundant that is there is no backup facility. The system also depends on the network that
Muhammad Salman Habib
Page 8
1/15/2009
is its speed. If the speed of the network is not sufficient there is a likelihood of slow response. DOTNET framework has to be installed on the web server since the software runs of DOTNET environment. And moreover we need a high performance web server for good performance.
Usage Scenario a. Profiles: The profiles are divided into three types in this system. 1. Parent: A parent will have the accessibility to view their child’s information and schedule. They are restricted to very low profile when compared to others. 2. Employee: An employee can view the billing information of all children along with viewing and updating the privileges given to parent. 3. : He can access, view, delete and update all the information available in the website. He is given all the privileges.
b. Use-Cases: A Use-Case Diagram is used to depict the main aspects of the system and the ways a can interact with the system. Separate use cases and their description follows the Use-case diagram below.
Muhammad Salman Habib
Page 9
1/15/2009
c. Use Case Diagrams: Please refer the next page for the figure. Manage Children
«uses»
Manage Classes
«uses» «uses» «uses» «uses» «uses» «uses» «uses» Employee
«uses» «uses» «uses» «uses» «uses»
Manage Activities
Manage Child Immunization «uses» Manage child Schedule
«uses» «uses»
«uses»
«uses» «uses»
Parent Manage Parent Info
«uses» «uses»
Manage Payments on Child A/C
Manage Billing on Child A/C
Manage Expenses
This is the system use-case diagram that displays all the different tasks that are accomplished by the system. Following this, we will have brief description of each of these use-cases.
Muhammad Salman Habib
Page 10
1/15/2009
d. Use-Case Descriptions: 1. Manage Children:
«uses»
Employee
«uses»
Manage Children
Objective: and Employee will be able to add, delete and update child information.
Pre-condition: has logged in successfully as or Employee. Post-condition: NA Main Flow: 1. System displays a form with editable fields for child's information. For Add, it would be empty fields and for Edit child info, there will be child information for selected child 2. /Employee fills out new child information or edits the existing child info [A1] 3. /Employee hits submit button on the page 4. System saves the child information in database 5. System notifies the
Muhammad Salman Habib
Page 11
1/15/2009
Alternative flow: A1 1. /Employee presses delete button on edit child info page 2. System asks for confirmation on child delete 3. On confirm, system checks whether the child's has any bills due 4. If payment is due on child A/C, System notifies the employee of due bill 5. On confirm system adds the amount in Day care Expenses table 6. System deletes the child from database 7. is notified 2. Manage Class:
«uses»
Manage Classes
Employee «uses»
Objective: Employee/ can add, delete or update a class information. Pre-condition: has successfully logged in as Employee/ Main Flow: 1. Employee/ can either select a class from dropdown list and modify the fields and edit it, or they can add a new class and finally click submit.
Muhammad Salman Habib
Page 12
1/15/2009
2. On submit, the system performs validation and adds the class to database or updates the class.
Alternative Flow: 1. Employee/ can select one class from drop down list, and can click delete button. 2. System asks for confirmation and on confirm, system deletes the class from database. 3. Manage Activities:
«uses»
Manage Activities
Employee «uses»
Objective: Employee/ can add, delete or update a activity. Pre-condition: has successfully logged in as Employee/ Main Flow: 1. Employee/ can either select an activity from dropdown list and modify the fields and edit it, or they can add a new activity and finally click submit 2. On submit, the system performs validation and adds the class to database or updates the activity
Muhammad Salman Habib
Page 13
1/15/2009
Alternative Flow: 1. Employee/ can select one activity from drop down list, and can click delete button. 2. System asks for confirmation and on confirm, system deletes the activity from database. 4. Manage Child Immunization:
«uses»
Manage Child Immunization
Employee
«uses»
«uses»
Parent
Objective: Employee/ can add child immunization information, can also update or delete an immunization record
Pre-condition: must have successfully logged in as an employee or Post-condition: Employee/ updates child's immunization information Main Flow:
Muhammad Salman Habib
Page 14
1/15/2009
1. System shows the the child's immunization information. 2. When applying immunizations to the child, the Employee/ can add information about child's immunization info @ date, type of immunization, physicals... etc. and press submit.
3. System stores this information in database
Alternative flow: 1. can also edit or delete an immunization entry 2. Select an immunization entry from the list, to edit, or click delete 3. System deletes or updates the information from database
5. Manage child Schedule:
Muhammad Salman Habib
Page 15
1/15/2009
«uses»
Manage Child Immunization
Employee
«uses»
«uses»
Parent
Objective: Add or delete a class or activity in a child's schedule, A parent can only view child schedule, cant update it
Pre-condition: has logged into the system as Employee or , to view Parent have to be logged in as parent
Post-condition: Employee/ can update child's schedule Main Flow: 1. Employee/ selects a class or an activity to the student's schedule 2. System checks if there is already another class existing at the same time 3. If there is no class at the same time then the class is added, activities have more priority than class 4. Information is stored in the database and is notified of that
Alternative flow: 1. Parent can view the student schedule online
Muhammad Salman Habib
Page 16
1/15/2009
2. Parent logs in and chooses to view the child's schedule 3. system fetches the schedule information of that child from database and displays in proper format 6. :
«uses» «uses» Employee
«uses»
Parent
Objective: Log the into the system and direct him to the proper interface(webpage) Pre-condition: NA Post-condition: is logged into a system and sees an /Employee/Parent interface
Main Flow: 1. System shows the a screen with editable boxes for name, and a dropdown menu for category: Employee, or Parent 2. puts name and and then selects a category from the dropdown list 3. hits submit 4. System authenticates the name and
Muhammad Salman Habib
Page 17
1/15/2009
5. System shows the proper interface as per selection, if the authentication is successful
Alternative Flow: 1. If the name and don’t match, the system shows screen again 7. Manage Parent Info:
«uses» «uses» Employee
Manage Parent Info «uses»
Parent
Objective: and Employee will be able to add, delete and update Parent information.
Pre-condition: has logged in successfully as or Employee. Post-condition: NA Main Flow: 1. System displays a form with editable fields for parent's information. For Add, it would be empty fields and for Edit child info, there will be Parent information for selected parent
Muhammad Salman Habib
Page 18
1/15/2009
2. /Employee fills out new child information or edits the existing parent info and selects the child(/children) the parent is associated with [A1] 3. /Employee hits submit button on the page 4. System saves the parent information in database 5. System notifies the
Alternative flow: A1 1. /Employee presses delete button on edit Parent info page 2. System asks for confirmation on Parent delete 3. On confirm, system checks whether the Parent is the only parent for any children 4. If parent is the only parent for any child, System notifies the employee of it, no changes made to database 5. If that is not the case, System deletes the child from database 6. is notified 8. Manage Payments on Child A/C:
«uses»
Manage Payments on Child A/C
Objective: should be able to add update or delete a payment to a child's Pre-condition: must be logged in as an Post-condition: can add update or delete records for payment to a child
Muhammad Salman Habib
Page 19
1/15/2009
Main Flow: 1. selects a child 2. System displays a button saying Add payment on top, and displays all the Payment entries below it, with edit and delete buttons [A1] 3. goes to edit billing page with blank editable fields for add entry or editable fields with data for the selected record 4. makes changes to the fields and hits submit button 5. System does the validation and adds an entry in the database 6. is notified
Alternative Flow A1: 1. selects delete button next to one of the payment records 2. The payment record is deleted from database 3. is notified 9. Manage Billing on Child A/C:
«uses»
Manage Billing on Child A/C
Objective: should be able to add update or delete a bill to a child's Pre-condition: must be logged in as an Post-condition: can add update or delete records for billing from a child
Muhammad Salman Habib
Page 20
1/15/2009
Main Flow: 1. selects a child 2. System displays a button saying Add billing on top, and displays all the billing entries below it, with edit and delete buttons [A1] 3. goes to edit billing page with blank editable fields for add entry or editable fields with data for the selected record 4. makes changes to the fields and hits submit button 5. System does the validation and adds an entry in the database 6. is notified
Alternative Flow A1: 1. selects delete button next to one of the billing records 2. The billing record is deleted from database 3. is notified 10. Manage Expenses:
«uses» Manage Expenses
Objective: should be able to add update or delete expenses Pre-condition: must be logged in as an
Muhammad Salman Habib
Page 21
1/15/2009
Post-condition: can add update or delete records for day care expenses into the system
Main Flow: 1. System displays a button saying Add Expense on top, and displays all the expenses records below it, with edit and delete buttons [A1] 2. goes to edit expenses page with blank editable fields for add entry or editable fields with data for the selected record 3. makes changes to the fields and hits submit button 4. System does the validation and adds an entry in the database 5. is notified
Alternative Flow A1: 1. selects delete button next to one of the expenses record 2. The expense record is deleted from database 3. is notified
Data Model
a. Data objects: The major data objects that we are using in the system are basically the main entities that are described in the requirements. •
Child
•
Parent
Muhammad Salman Habib •
Classes
•
Activities
•
Schedule
•
Billing
•
Payment
•
Expense
Page 22
1/15/2009
We will describe them as classes in the next section and identify their essential attributes and essential operation that are performed on these objects.
b. Relationships: We identify the relationships between two or more Data objects and describe them below:
c. Complete data model
class
-Manages *
-Has 1
*
-has
schedule
*
* *
activity
Child
-Has *
* * *
*
*
* *
billing
-Views * *
Parent
*
-Views
Parent
* -Views *
payment
* *
-Manages * -Manages * * -Manages -Manages -Manages *
Employee
*
-Manages -Manages -Manages * * * Employee
* Expenses
*
Muhammad Salman Habib
Page 23
1/15/2009
The next section will take each of these data object and describe them as a class, mentioning the important attributes and operations.
Functional Model and Description a. Class Diagrams: Here we have all the classes that we will consider for deg the system. We take care that all the Use-cases that we want to accomplish and all the operations can be performed by the use of following classes. 1. child -SSN -Name -BirthDate -Gender -FirstParent +AddChild() +UpdateChild() +DeleteChild()
2. This is one of the actor classes Parent -SSN -Name -BirthDate -Gender -ID - -Address -EmailAddress -PhoneNumber +AddParent() +UpdateParent( ) +DeleteParent() +ViewChildrenSchedule() +ViewChildrenImmunization() +ViewBilling()
Muhammad Salman Habib 3. This is the other actor class Employee -SSN -Name -BirthDate -Gender -ID - - -Address -EmailAddress -PhoneNumber +AddEmployee() +UpdateEmployee() +DeleteEmployee() +ManageChildren() +ManageParent() +ManageClasses() +ManageActivities() +ManageSchedules() +ManageBilling() +ManagePayment() +ManageExpenses() +ManageImmunization()
4. Class -ClassID -ClassName -Instructor -Description -Timing1 -Timing2 +AddClass() +UpdateClass() +DeleteClass()
5. Activity -ActID -ActName -Instructor -Description -Timing +AddActivity() +UpdateActivity() +DeleteActivity()
Page 24
1/15/2009
Muhammad Salman Habib 6. ChildSchedule -SchID -ChildID -ClassAct -ClassID -ActID +AddSchedule() +UpdateSchedule() +DeleteSchedule()
7. BillingInfo -BillingID -BillingDescription -BillingAmount +AddBill() +UpdateBill() +DeleteBill()
8. PaymentInfo -PaymentID -PaymentDescription -PaymentAmt +AddPayment() +UpdatePayment() +DeletePayment()
9. ExpenseInfo -ExpenseID -ExpenseDesc -ExpenseAmt +AddExpense() +UpdateExpense() +DeleteExpense()
Page 25
1/15/2009
Muhammad Salman Habib
Page 26
1/15/2009
b. Software Interface Description: Our software system is a simple, friendly web based solution. It has no external system interfaces and no external machine interfaces. It has only a human interface that is a GUI(Graphical Interface). GUI is basically the interface description of the software system contained in the requirement documentation. There are three types of human interfaces in our system namely employee, parent, which will be interacting with the software system. Although we can have an external system interface by maintaining database in a different server but the depends on the size of the database
Behavioral Model and Description
The behavioral model indicates how software will respond to external events or stimuli. It depicts the dynamic behavior of the system as a function of specific events and time. These specific events are triggered by the actors who use the system. There are three types of actors in this system depending on their access levels. 1. Parent: A parent can and only view class schedule, billing information and immunization information of his/her child. He cannot make any type of modifications to the information displayed. 2. Employee (Staff): An employee’s accessibility is also limited. An Employee can view and make changes to class schedules, activities, and child and parent information and also to immunization information.
Muhammad Salman Habib
Page 27
1/15/2009
3. : has no restrictions in accessing any type of information or updating it. He can manage the
a. Description for software behavior To better understand the behavioral model of this system, the events which result in different states are listed below. The actors who trigger the particular event are also listed.
Events: Event: Actor: Parent/Employee/ Event: View class schedule Actor: Parent Event: View Billing Information Actor: Parent Event: View Immunization Information Actor: Parent Event: View/Delete/Update Classes Actor: Employee/ Event: View/Delete/Update Activities Actor: Employee/ Event: View/Delete/Update Immunization Information
Muhammad Salman Habib
Page 28
1/15/2009
Actor: Employee/ Event: View/Delete/Update Child Information Actor: Employee/ Event: View/Delete/Update Parent Information Actor: Employee/ Event: View/Delete/Update Billing Information Actor: Event: View/Delete/Update Payment Information Actor: Event: View/Delete/Update Expenses Information Actor: Event: Actor: Parent/Employee/
States: A state is any observable mode of behavior and a state diagram depicts the actions taken as a consequence of a particular event. The whole system is divided into 3 states namely depending on the access levels. Two other states are also defined to enter and exit the system. The states are as follows: 1. : By entering a valid id, and the type of , he will gain access to the system.
Muhammad Salman Habib
Page 29
1/15/2009
2. : By entering valid information, the can enter this state and will be able to perform all the operations he can access and make changes to the database. Generally he has the control of the whole system. He can exit the system by logging out. 3. Employee: After logging into the system, an employee can manage the system depending on his access level. He has certain limitations in accessibility. Logging out of the system will take him to state. 4. Parent: A parent can enter the system by entering valid id and . After entering the system, can view his own child’s information. He cannot make any kind of changes to the database. Exits the system by logging out. 5. : will be taken to this state once he logs out of the system. Here he can go back to state through re- information.
Muhammad Salman Habib
Page 30
1/15/2009
b. Statechart Diagram: Initial State
Enter ID Enter Select type
Home Employee Home Parent Home View Class Schedule View Billing Information View Immunization Information
View, delete and Update Class Schedule View, delete and Update Immunization Information View, delete and Update Activities View, delete and Update Child Information View, delete and Update Parent Information
again
Final State
View, delete and Update Class Schedule View, delete and Update Immunization Information View, delete and Update Activities View, delete and Update Child Information View, delete and Update Parent Information View, delete and Update Billing Information View, delete and Update Payment Information View, delete and Update Expenses Information
Muhammad Salman Habib
Page 31
1/15/2009
Restrictions, Limitations & Constraints •
The size of the database is restricted to few hundreds.
•
The software doesn’t have any security features, network features or doesn’t have any compatibility for it. So software has to be further developed to deploy it network.
•
It is developed in such a way that the employee can work only on one interface and therefore employee cannot open multiple interfaces and perform task simultaneously.
•
Some applications can only be used by e.g. change the fees structure of children, add or remove the employees etc.
•
The Graphical Interface (GUI) is planned to be developed in Java 1.5 or above and the minimum hardware requirements are: 1. Intel® Pentium® III processor (or higher preferred) 2. 256 MB memory 3. 20MB free disk space 4. Windows 2000/Xp/Vista
Validation Criteria The validation criteria for the software system is such that the information provided in the fields is checked for the correct format and if any information of child or parent is found to be wrong or missing then it will not be able to enter the database. Business rules are validated that is: only the can change certain things such as billing information, add and remove employee’s names etc. Each has a unique ID and provided by the .
Muhammad Salman Habib
Page 32
1/15/2009
a. Classes of Tests: The inputs are going to be entered erroneously to check the system performance. Basically test cases are going to be developed by using brainstorm sessions. This will help us to figure out behavior of system and performance of the system. Method of testing: •
The system’s internal structure will be tested (white box testing)
•
The overall system will be tested (black box testing)
•
Specimen test cases: 1. Click add button to add the parent without his or her social security number. 2. Click staff information to add or remove the name of employee from the staff . 3. Click add button to add the child without his or her parent information.
b. Expected Software Response This software will perform certain operations like Add, Remove or Update the detail Information of child, parent, employee, etc. It will keep track of billing, Immunization and class activities. When searching for a particular child a unique id will be specified and all the information about the child will be displayed.
c. Performance Bounds The major performance bound in our software system is the size of the database although this could be improved by using another external system interface. The performance of the software in of response time is at best immediately or at worst 20 seconds. A major factor pertaining to response time is the network speed. END OF Requirement Specifications Document
Related Documents c2h70
Requirement Specifications Document For Kids And Babies Day Care Center 1j6t61
April 2020 14
Day Care Center Dswd 3h1l2n
November 2019 50
Customer Requirement Document(crd) 49591i
October 2019 42
Day Care Center - Chart Of s 5r4n5j
October 2019 37
Supplier Document Requirement List 1p4p1d
November 2019 86
Contoh Requirement Document 64c6y
October 2019 71More Documents from "Muhammad Salman Habib" 2t2i8
Digital Image Processing Using Visual C++ 2iq35
November 2021 0
Requirement Specifications Document For Kids And Babies Day Care Center 1j6t61
April 2020 14
Electrolytic Tank Experimentlabsheet 7b
February 2022 0
Polidaktili 2n5vc
November 2020 0
Referat Ablasio Retina 4l515c
April 2020 14
