< Front view >

<1>

Document Cover : Open when loading an original document on the Platen Glass.

<2>

Paper

: Open to load paper in the Rear Tray.

<3>

Paper

:

Extension

Pull out to paper loaded on the tray.

<4>

Paper Guide

: s paper so that it feeds properly.

<5>

Rear Tray

: Load paper here before printing. Paper feeds automatically, one sheet at a time.

<6>

Direct Print Port : Connect your PictBridge compliant device, such as a digital camera, here to print directly from it.

<7>

Paper Output

:

Tray <8>

Output Tray Extension

<9>

Platen Glass

s the printout. Close it when you are not using it. : s output printouts. : Load original documents to copy or scan here.

< 10 > Operation : Changes the settings and operates the machine.

< Inside the printer >

<1>

FINE Cartridge : Install the FINE Cartridges here. Holder

<2>

FINE

: A replaceable cartridge that is Print Head and ink tank integrated.

Cartridges (Ink

- Black FINE Cartridge: Insert it into the left slot of the ink

Cartridges)

cartridge holder. - Color FINE Cartridge: Insert it into the right slot of the ink cartridge holder.

<3>

Scanning Unit : Contains the scanner components. Open it to replace FINE Cartridges or to remove jammed paper. (Printer Cover)

<4>

Paper

: Switches the clearance between the Print Head and the loaded

Thickness

paper to match the paper type.

Lever

Adjust its position according to the type of paper you are printing on. - Left position: When printing on the paper (such as plain paper) other than an envelope/T-Shirt Transfers. - Right position: When printing on an envelope/T-Shirt Transfers.

<5>

Scanning Unit : Holds the Scanning Unit (Printer Cover) when it is opened.

< Rear view >

< 1 > Power Connector : Plug in the supplied power cord here. < 2 > USB Connector

: Plug in the USB cable connecting the machine to a computer here.

< Operation >

<1>

ON/OFF button / POWER lamp

<2>

LED

: Turns the machine on and off. Lights or flashes green to indicate the power status. : Displays the number of copies, Maintenance menu selections or the operational status.

(Light Emitting Diode) <3>

[ + ] button

: Increases the number of copies.

<4>

Alarm lamp

: Lights or flashes orange when an error, such as paper-out or inkout, occurs.

<5>

Black / Color Ink lamps : Lights or flashes to show the ink status

<6>

SCAN button

: Opens the MP Navigator Ex to scan a document to your computer according to the settings selected. To use this button, the machine must be connected to a computer.

<7>

Stop / Reset button

: Cancels operations or a print job in progress.

<8>

Color button

: Starts color copying. Also, finalizes your selection for the menu or setting item.

<9>

Black button

: Starts black & white copying. Also, finalizes your selection for the menu or setting item.

< 10 > Maintenance Button

: Accesses the Maintenance menu.

< 11 > Fit to Page button / Fit

: Enables/disables the Fit-to-Page copying. Lights when Fit-to-Page

to Page lamp < 12 > Paper button

copying is enabled. : Switches the page size and media type for copying.

< 13 > Paper lamp

: Displays the selected page size and media type for copying.
