Physics Project For Class 12 Cbse p6r1o

Contents 1. Acknowledgements 2. Certificate 3. Introduction 4. Principal 5. Step Down Transformer 6. Construction

7. Theory 8. Energy Losses In Transformer 9. Bibliography

Acknowledgement I sincerely extend my deepest gratitude to our principal Dr. Nidhi Maheshwari for providing us with

all the facilities and kind moral for carrying out this project work.

I take this opportunity to give my special thanks to our esteemed physics teacher Mr. J.P.Jain for his inevitable help. It is much because of his guidance that endeavors to accomplish this project material.

Certificate

This is to certify that Hardik Seth of class XII has completed his physics project entitled "Transformer & its Working".

I appreciate his effort and wish him for his bright future.

Submitted to: Mr. J.P. Jain

Principal M.D.S. Public School, Udaipur (Raj.)

Introduction

The transformer is a device used for converting a low alternating voltage to a high alternating voltage or a high alternating voltage into a low alternating voltage.

Principal

It is based on the principle of mutual induction that is if a varying current is set-up in a circuit induced e.m.f. is produced in the neighboring circuit. The varying current in a circuit produce varying magnetic flux which induces e.m.f. in the neighboring circuit.

Step Down Transformer

In our project step-down transformer is used: This transformer converts high voltage at alternating current into low voltage alternating current. In step-down transformer the number of turns in primary coil remains large as compare to secondary coil.

Construction

The transformer consists of two coils. They are insulated with each other by insulated material and wound on a common core. For operation at low frequency, we may have a soft iron. The soft iron core is insulating by ing thin iron strips coated with varnish to insulate them to reduce energy losses by eddy currents. The input circuit is called primary. And the output circuit is called secondary.

Theory Suppose, the number of turns in the primary coil is NP and that in the secondary coil is NS. The resistance of the coil is assumed to be zero. Let be the rate of change of flux in each turn of the primary coil. If Ep be the e.m.f. in the primary circuit then. EP = –NP

(1)

We suppose that there is no loss of flux between the primary and secondary coils.

Then, the induced e.m.f. in the secondary coil will be: ES = –NS

(2)

From equations (i) and (ii), we find:

Ns/Np = K is called transformer ratio or turn ratio. For step up transformer K > 1

For step down transformer K < 1

That is for step-up transformer NS > NP, therefore ES>EP.

For the step down transformer NS < NP therefore ES < EP.

Efficiency: The efficiency of the transformer is given by:

If Ip and Is be the currents in the primary and secondary circuits.

For ideal transformer

= 1 = 100%.

Therefore ESIS = EPIP Or

Therefore, for step up, transformer current in the secondary is less than in the primary (IS < IP). And in a step down transformer we have IS > IP.

Energy

Losses

in

Transformer

In practice, the output energy of a transformer is always less than the input energy, because energy losses occur due to a number of reasons as explained below.

1.

Loss of Magnetic Flux: The coupling between the coils

is seldom perfect. So, whole of the magnetic flux produced by the primary coil is not linked up with the secondary coil.

2.

Iron Loss: In actual iron cores inspite of lamination,

Eddy currents are produced. The magnitude of eddy current

may, however be small. And a part of energy is lost as the heat

produced in the iron core.

3.

Copper Loss: In practice, the coils of the transformer

possess resistance. So a part of the energy is lost due to the heat produced in the resistance of the coil.

4.

Hysteresis Loss: The alternating current in the coil tapes

the iron core through complete cycle of magnetization. So

Energy is lost due to hysteresis.

5.

Magneto restriction: The alternating current in the

Transformer may be set its parts in to vibrations and sound

may be produced. It is called humming. Thus, a part of energy

may be lost due to humming.

Bibliography

www.Google.com www.Wikipedia.com www.idoub.com
