A Seminar On Multimedia Authoring

1

Contents 

Multimedia application  Multimedia Authoring  s of Multimedia  Authoring v/s Programming  Design Issues  Types of multimedia Authoring Systems  Multimedia Authoring Metaphor  Categories of Multimedia Tool  HyperMedia Application  Flash Basics 2

Objectives   

How multimedia products are created and authored. What are different multimedia authoring metaphor What kinds of multimedia authoring tools you have to choose from to suit your project needs.

3

Multimedia Application Three kinds of multimedia applications:  Mail  Information Repository  Business processes All applications are shared and distributed. First step in developing application is UI Thus,mm authoring is important

4

Multimedia Authoring Applications that allow to create mm objects and link or embed them in other compound objects such as documents or database records are called authoring systems

5

s 

Professional s: who prepare documents, audio or sound tracks and full motion video clips for wide distribution.



Business s: prepare documents, audio recording, or full motion video clips for stored messages or presentations

6

Authoring v/s Programming •

Authoring tools are what we call high level tools  A lot of the technical details of how things are done is hidden from the developer. The developer can concentrate on the functionality instead of how to make the hardware work  Can be used by non-programmers

•

Programming tools are low level tools  They provide access to the low level hardware features for those who want to get the most out of the computer  Are used by programmers or software engineers 7

Design issues for mm authoring Display resolution  Data formats for captured data  Compression algorithms  Network interfaces  Storage formats 

8

Types of Multimedia Authoring system Dedicated authoring system  Timeline based authoring system  Structured mm authoring system  Programmable authoring system 

9

Dedicated Authoring system Simplest type of system  Designed for single and for single stream  These are at the desk of end s 

10

Authoring is performed on objects captured by camera, scanner or already stored objects  Follow real world metaphors  Eg: VCR metaphor 

11

Timeline based Objects are placed along a timeline  Resources are specified and positioned in the timeline  Editing a component causes all objects in the timeline to be reassigned  To overcome timing relations are defined directly between the objects 

Track 1

Track 2 Track 3 Track 4

Background music Animation Voice over (narration)

Video

12

Structured Multimedia Authoring Based on structured object level construction of complex presentation  Allows explicit manipulation of the structure of mm presentation  Timing constraints are derived from the structure  Consist of two stages:  Construction of structure of presentation  Assignment of detailed timing constraint 

13

Capabilities of Structured Multimedia Authoring Ability to view the complete structure  Maintain a hierarchy of objects  Capability to zoom  View specific component  Show the timing relationship between components  Ability to address all mm types 



Inability to express automatic functions for handling routine tasks

14

Programmable authoring Overcome the shortcoming of structured authoring  Return the timestamp of next frame  Delete a specified movie segment  Copy or cut a specified movie segment  Replace the current segment with clipboard content 

15

Multisource Multi- Authoring System 

Objects are arranged in geographic plane just as in temporal scale



Besides information about the object data,information to locate the object with reference to other object in time as well as space is required



Task of rendering become very complex in compositing a scene with multiple independent objects



Knowledge of spatial alignment of objects allows the authoring to optimize the resolution 16

Synchronization issues 

The inputs must be managed in a intelligent manner and coordinated when multiple server writing the object to workstation



Editing the objects by multiple authors result in timeline shifts that must be adjusted dynamically

17

Telephone authoring system 

The phone can be used as reading input device  Digitized voice clips are captured via phone and embedded in electronic mail message  Phones can be used to create email message where the voice is converted to ascii text on fly 18

Telephone authoring system 

1. 2. 3. 4.

It the following distinct kind of application: Workstation control for phone mail Voice command control for phone mail Embedding of phone mail in e-mail Integration of phone mail and voice message with e-mail. 19

What is an Authoring Metaphor 

It is the methodology by which authoring system accomplishes the task

20

Types of Authoring Metaphor •

There are numerous methods that can be used for multimedia applications

•

Authoring metaphor are of following types  Scripting language  Iconic/Flow control  Frame  Card scripting  Cast score scripting  Time line based 21

Scripting Language • •

•

Scripting languages are cut-down versions of complete programming languages. It specifies (by filename) multimedia elements, sequencing, hotspots, synchronization Scripting metaphor allow the developer to write small scripts (programs) which can be associated with a multimedia object  e.g. you may write a script to make a graphic image move across the screen or to make a window pop up when an item is clicked

22

Features of Scripting language 

Longer in development time  More powerful interactivity  The runtime speed gains over other authoring methods are minimal. Example  Lingo scripting language of macromedia director  Apple’s hypertalk for hypercard 23

Frame metaphor •

Each part of the application is self-contained in a single page or frame • Fast development system • Requires a good auto-debugging function

24

Iconic/Flow control Authoring •

The core of the paradigm is the Icon Palette, containing the possible functions/interactions of a program, and the Flow Line, which shows the actual links between the icons • High Speed authoring style • Best suited for rapid prototyping & short development time projects

25

Macromedia Authorware Iconic/Flow Control Examples

26

Score Scripting metaphor 

This model has an analogy with a musical score



Instead of musical instruments playing notes we have multimedia objects (sounds, images, video, text, etc.) that do something at specific points (times) in the score



There is usually some way to animate the objects (e.g. rotation, scaling, colour changes, etc.) between each transition (i.e. when they start and when they finish)



Each multimedia object lives in a track



A score has one or more tracks 27

Screenshot of Macromedia Director Cast

Stage

Score

28

Timeline based 

Timelines are a useful way of representing multimedia data during the course of a presentation or application  Time is represented along the x-axis  Tracks are represented along the y-axis



The developer can move objects left and right to change the order of the information and can lengthen or shorten the bars to change their duration

0 seconds Track 1 Track 2 Track 3 Track 4

5 seconds

10 seconds

15 seconds

Background music Animation Voice over (narration) Video 29

Macromedia Director

Macromedia Flash

30

What is an Authoring Tools 

The tools by which various media components are brought together (integrated) into a structure and flow.

31

Categories of Authoring Tools 

Can be categorized into 1. Presentation software 2. Tools for creating production 3. Interactive training and education



Some authoring tools can fit into more than one category.

32

1. Presentation software  

Enable s to create and deliver business presentations in the form of the slide show. Each major heading is the beginning of a new slide.

heading

33

1. Presentation software 

Templates are used to determine how the heads and subheads are formatted and displayed over backgrounds, including: (etc PowerPoint)  position  size  font  style  color

34

Example: PowerPoint Interface

Style and format

templates 35

2. Tools for creating production 

Typically oriented toward producing content that is more ambitious than the slide-show level  (more interactive & dynamic)



Usually integrate all types of' multimedia data into a multitrack timeline that determines the evolution of events



Interactivity takes the form of conditional branching (multiple linking) that can make navigation decisions based on input and other conditions



Production software creates dynamic content  EXAMPLE: mTropolis / AppleMedia Tool / MediaForge

36

3. Interactive training and education tools 

To create education or training content.  Designed primarily to present information in an Interactive book.  Multimedia-oriented programming languages such as Visual Basic represent another authoring alternative.  Offers the higher flexibility, performance speed and power  Example: Macromedia Flash, Authorware & Director

37

Flash Interface

38

Director Interface

39

Authorware Interface

40

Terminology 

   

Complex Application-consist of various multimedia objects Rendering-to display completely with all specifications Authoring tool-create multimedia application using metaphor Authoring metaphor-method to create multimedia application Storyboarding- prestep of animated movie 41

References 

Multimedia System Design by Prabhat K. Andleigh,Kiran Thakrar  en.wikipedia.org/wiki/Authoring_system  www.trivantis.com/resources/what-authoringtool  New Metaphors for Multimedia Authoring Environments by Christine Strothotte Carola Zwick ,Institute of Industrial Design, Magdeburg, Interaction Design Group 42

Queries?

43

Hypermedia Application Design

•These

applications consisting of compound objects that include multimedia objects •An

authoring application may use existing mm objects or call upon media editor •Primary

role is to structure mm document

•Once

the media streams are selected ,these are combined in some form of higher level object- a hypermedia object 44

Structuring the information •

Identify the information objects and to develop an information model to define relationship among these objects.

•

The information structure is fully defined in a database system

•

MM objects pose a problem- size, created in different way and cannot be interpreted as alphanumeric data

45

Primitives of good modeling structure •

Object types and object hierarchies

•

Object representations

•

Object connections

•

Derived connections and representations

46

Steps to design hypermedia system •

Determine the type of hypermedia application

•

Structuring the information

•

Determining the navigation throughout the application

•

Methodologies for accessing the information

•

Deg the interface

47

Compound object

Rich text

Image document

ASCII text

Video clip

Graphics

Video track

Image page2

Image page1

Image page3

Voiceover track

Sound track

Example of Object Hierarchy 48

Attaching sounds and video clips to Objects •

Dialogue, music and sound effects merge along parallel paths through recording, editing, premixing, final mixing & print mastering

•

Dialogue is recorded separately

•

Production sound is recorded on the set along with actions

•

Then dubbing takes place

•

Rerecording is required for this, in a professional studio

49

Attaching sounds and video clips to Objects •

Then music and sound effects are added

•

Music editing ensures that the music is properly synchronized with the scene

•

Other examples : whistle of train, roar of car racing & thunder all are recorded separately and then edited

•

Premixing combines a number of concurrent sound effects into a synchronized sound effect

•

Final mix brings the dialogue, music , and sound effects together in of timing synchronization, although the three remain on separate tracks 50

Introduction

to Flash

•

It is a simple authoring tool that facilitates the creation of interactive movies •

Adobe Flash (Macromedia Flash) is a multimedia platform used to add animation, video, and interactivity to Web pages. Flash is frequently used for ments and games •

Flash manipulates vector and raster graphics to provide animation of text, drawings, and still images

51

Introduction to Flash •

•

Originally acquired by Macromedia, Flash was introduced in 1996, and is currently developed and distributed by Adobe Systems Flash files are in the SWF format, traditionally called "Shockwave Flash" movies, usually have extension .swf

52

Terminologies •

Frame: graphics are designed on each frame

•

Key frame: starting and ending frame

•

Tweening: no. of frames between keyframes

•

Synchronization: to set the timing between two objects that are going to be display simultaneously

•

Timeline: set the display timings of objects

53

Frames, Key frames and Timeline

54

Frames, Key frames and Timeline

55
