Toner compatibilty analog minolta copiers: EP70=EP1030=EP1050/1080/1052/1054=EP2050/3050/4050/4000 digital minolta copiers: DI152/183/1611=DI181=DI250/350/351=DI450/470/550/=DI2510/3510=BIZHUB163/210 Old color copiers : CF 910=CF911P=CF9001=CF1501=CF2001 new color copiers: CF3102=CF2002=BIZHUB C350/450=BIZHUB C250/252=BIZHUB C451/550/650= BIZHUB PRO C6500

bizhub 250/350 code c2557 April 25, 2009 Troubleshooting for bizhub 250/350 are generally the same like DI250/350 the major difference is this code : 2557 Code usually appears when the meter count of drum and developer (in service mode) was reseted without changing deleloper followed by F8. how to reset: -the simplest way is to change developer and run F8. -without change the developer: —First : add a spoon of toner in dev. unit and instantly run F8. —Second (if first way was not good) : in service mode-level history-atdc,There you will see displayed the current value of ATDC. Usually this value should be approximately 13 %, but after resseting it becomes 5-6 % and comes into contradiction with the presetting value in tech rep choice-printerATDC gain (155). So, increase the concentration of toner in developing unit adding little amount of toner or decrease or increase the default value (in tech rep choice-printer - ATDC gain) to match the actual concentration in developing unit. This procedure is logical and it works but requires some patience and experience.

bizhub 420 code reset-service mode April 22, 2009 how to enter in service mode when error code appear? turn of the copier -main switch. press and hold utility key and turn on the copier and still hold utility key until "trouble reset "appear on the screen. now you can enter in service mode (without uti/counter,details), only code Now , in service mode you can view or modify various parameters.

minolta di2510 drum reset April 4, 2009 How to reset PC drum or imaging unit: Enter in service mode (you already know that procedure),counter, PM , select PC/drum life, press clear key, exit from service menu- do not press reset key. Life expectation-in good condition-of Minolta Di2510/di3510 drum is about 150.000 copies.

bizhub c451/550/minolta c650 parts reset March 28, 2009 HOW TO: fusing unit reset: • • • • •

turn of the main switch remove the fusing unit remove the left cover of the fusing unit change the old fuse (green resistor) with 80mA new fuse put back the cover andthe fusing unit turn on the machine

transfer unit reset: to reset use a new 80 mA glass fuse

bizhub c451,c 550,minolta c650 trouble March 28, 2009 Jam in DF611: -on 2-nd side: Check mylar on the 2nd transport guide plate. Replace the damaged mylar p/n : 9J07 4703 01 -on 1st side: • •

put the tension spring of feed roller in lower position. ckech the sensors inside DF611 case and use some adhesive (super glue, super bond) so that the sensors cases will be hard-set.

P21 warning :

- color shift in main scan direction the amount of color shift is different between front and back side. Color shift occurs at 1 to 2 mm in the worst position. bizhub C650/C550/C451 (FW Ver.6B only) The problem will be observed when below 2 conditions meet. However it is not always but it depends on the gain of image density sensor (IDC). 1. When MFP returns from sleep mode within 8 hours from the last image stabilization. 2. In case MFP detects temperature change in printer head at more than 2 degrees from the last regist control when returning from sleep mode.

Regist control, which takes place in above condition, is carried out with improper sensor gain setting. - P-21 is displayed when the sensor gain is low for the MFP to detect toner pattern. - Color shift occurs when MFP miss-detect toner pattern due to improper gain setting. How to recover the problem:

-Apply FW Ver.6M or later - Turn off/on the main switch - Carrying out image stabilization

minolta cf9001 March 27, 2009 • •

Old product “oldies but goldies “: Minolta CF9001 and Minolta CF910:

1. undifferntiated,aleatory and recurrent trouble codes just after power on : check, clean or CHANGE main relay p/n 9341221021. 2. white dots on magenta :change the magenta starter 3. blue background in middle of the page : in service mode, counter, life, check the drum’s life : if life reached on 20.000 -change the drum and cleaning blade ,reset counter life for both.4 .white strips : in service mode test mode halftone –print C,M,Y,K test: If the white strips are in same arrangement : -clean or change corona wire of transfer corona unit (inside of transfer drum) -clean (use water and soap -no alcohol)- grid of drum charging corona -remove and clean mirror’s box and laser path on the right side of the copier .

minolta di350 reset all counters March 21, 2009 In this mode you can reset all counters to 0. How to reset all couters: follow the procedure for reset trouble code (insert a paper clip into a small hole situated on the right side of the control ).

The copier will be restarted. when a small black dot is on the screen- press 3 key. Now, in this menu press total clear tab.

di2510/di3510 trouble March 5, 2009 abort code and restart after power-up: -check if the CF card is inserted properly -if CF card it’s, OK -need to reset BRAM: next to CF card are INI jumpers. -turn off the machine, pull the jumpers off and cross the pins to the far right and the middle in the verticale direction. -power ON for 20 seconds then power off. -remove jumpers and put them back in the original position. power on.

How to reset C0500 code : - open the right door -in the small hole on the right side of the control (same as DI 350,di351)press the soft initialization - When the dot appears on the LCD after reboot, press 3 key. -enter the service code (default 0000000) - The mode will change to the initialization screen. -Choose trouble reset. -after reboot close the right door -if same trouble appear again- check the thermal fuse or thermistors(heat sensing elements) or replace the fusing unit.

Light copy on ADF (DF): -clean with alcohol the optical unit (original glass, mirrors, lamp, lens) -use the two screws in rear side of DF to correct the position of DF againts original glass. -pull out the imaging unit and clean the frame glass of laser unit. -still light copies? but print it’s OK - clean the CCD sensor (only for tech.rep.)

dialta di350, minolta di350 trouble March 1, 2009 -how to imaging unit reset : remove he imaging unit, remove the conector -in back of the IU. in back of the conector you will see a black thin duct - inside this- a green resistor (in fact fuse) Cut this resistor so that …..see more How to trouble Co500 reset : in the right side on control , beside LCD contrast currsor is situated a small hole . insert a pick in this hole until copier will be restarted, then…. see more…

dialta di152 trouble March 1, 2009 how to maintenance code reset : utillity-stop -0-0-stop- 01-3-start-3-start-3-start.on display will be apear 00 .Press now ‘clear’ key .on display will be apear 40000 .Touch ’start’ and reset .That’s it ! code J– reset : open the right door- check tension spring and lever’s movement in right side of the fusing unit . The tension spring is usualy too weak , so change it with new one , more strong. Then clean sensor and

check correct highness of actuator(in sensor frame). If the actuator is too down -loosen screws of fusing unit , push up the fusing unit-in right side and tight screws. Fix minolta di 152, minolta di 183 in same way. spilling toner from imaging unit : -remove the imaging unit ond open it in usual mode. -remove the cover of the developing unit -check in right (back) side of magnet roller -condition of the mylar .If is broken change it with a new one .you cane made new one from thin OHP film.Insert it under doctor blade and put here some adhesive (super bond, super glue). Meantime clean charging corona , charging grid , and replace drum in was broken from old mylar.Check also or replace the roll :

4163-5298-01

Fix minolta di 152, minolta di 183,,minolda di1611, minolta di2011, bizhub 162,bizhub 163 ,bizhub210 in same way.

how to fix cleaner unit : ….soon

Bizhub c350 trouble reset February 26, 2009 1.how to imaging unit reset:

the real life of drums and IUs is at least 100k - but chips are set to end at most 50k -good reason to reset it with chip reseter 2. how to reset transfer unit : the real life of transfer unit is at least 300k

to reset use a 80 mA fuse

2.foggy background and blurred text : -remove waste box, remove trnsfer belt, remove all IUs and clean with alcohool LED bars- under IUs. see more

bizhub 420 c2804 reset February 25, 2009 Description: Too low toner density(in developing unit) -read from ATDC sensor Posible causes: 1.Defective toner supply mechanism - defective TONER CONVEYANCE GEAR p/n 26NA 3268 0

Solution: grease with silicone vaseline toner conv gear and worm gear (at Motor M4) or replace toner conv gear if broken 2. tubby noise -toner sub hooper overflow -use vaccum cleaner -clean all toner inside hooper

bizhub 420 c2403 February 25, 2009

Trouble code: C2403 (C-2403).

PROBABLE CAUSES: 1. When an empty toner bottle is rotated while removing it from the machine, the alignment tab goes out of home position. Then, when a new bottle is inserted, it does not insert correctly and it does not rotate —pull out and insert it correctly —Push again(until clack) toner bottle after insert it. 2. Toner sensor position ps28 contaminated with toner— use vaccum cleaner and clean all parts around toner bottle esspecially ps28. 3.Defective toner bottle 3.Defective toner rotate mechanism claws

Note : To reset C-2403 after replacing the toner bottle, perform the following: a. Power OFF main SW, inside front door.

b. Slide the toner bottle cradle and remove spent toner bottle. c. Prepare new toner bottle per instructions and place toner bottle in the cradle (line up the two notches at the rear so the cartridge is laying level in the cradle). d. Turn bottle completely around and line up the arrow at the 12 o’clock position clockwise or counterclockwise and push cradle in and lock toner door. e. The power should be re-enabled to ON while holding the Utility key; the Konica Minolta blue screen within 2 minutes, then the white screen with Trouble Reset. Touch and OK will appear. f. Power OFF/ON and should go to Ready. This procedure may have to be redone several times. 2. Toner bottle is not turning. Ensure that the toner bottle does not have any manufacturing defects. Also ensure that the pressure spring inside the pressure assembly (p/n 26TA-3332) is applying sufficient pressure when locked into place. 3. Excessive pressure from the Toner Bottle Door. Remove the two pressure springs located in toner door. 4. The toner bottle position sensor (PS28) may have shifted when the drive section on the back of the machine was removed or installed. As a result, PS28 cannot detect rotation of the toner bottle. Install a new mounting plate (p/n 50GA33161E) and stopper seal (p/n 447042481) for PS28. These parts prevent PS28 from becoming dislodged. Complete 5. between parts around the bottle guide section. Please install the Toner supply auxiliary cover countermeasure as explained in the attached Parts Modification Notice. 6. If toner bottle is not installed correctly and the customer forces it then it may cause tearing of the drive tabs on the toner bottle. This will cause the bottle not find the home position generating this error. Please ensure that the toner bottle is inserted correctly. 7. Even though the correct procedure was used p, there still may be burrson theflange tips at neck of the toner bottle.Also,PS4

and PS28 may not be sensing properly. the correct operation of PS4 and PS28. Check for burrson theflange tips at neck of the toner bottle. Remove the burrs on the toner bottle. Note : The service documentation does not include a procedure for checking PS4 (Toner Bottle Sensor) and the PS28 (Toner Bottle Position Sensor). To check: a. Enter the State Confirm mode=>’Service Mode screen’; press [State Confirmation]. b.’State Confirmation screen’; press [Sensor check]. c. ‘Sensor Check screen’; press [Check Code] and, when entering the sensor check code in 3-digit format through the copy count setting button, a state (ON/OFF) or value is displayed in the Result area. d. For the multi-mode, press [Multi Code] and enter a three-digit multi-code through the copy count setting key. When conducting the sensor check of other signal sources, repeat stepscand d. IMPORTANT : Code 57, multi-mode 2, which is not listed in the bizhub 420/500 Service Manual, is used to monitor the output signals ofPS4 (Toner Bottle Sensor), and multi-mode 3 for monitoring the output signal ofPS28 (Toner Bottle Position Sensor). These sensors are located at the rear of the hopper assembly at the 11 o’clock position forPS28 and at the 12 o’clock position forPS4. The state of these sensors will switch from 0 to 1 if the bottle is moved.
