NEC PASOLINK NEO (SDH)

SUBMITTED BY- AKASH RAY 1

INTRODUCTION To provide reliable digital access links and fully exploit the potential of end-to-end advanced networks, NEC has developed the PASOLINK NEO, a narrow band point-topoint digital microwave relay system operating at radio frequency (RF) bands of 6/7/8/10/11/13/15/18/23/26/28/32/38/52 GHz. This system meets an increasing demand for digital transmission services, and will satisfy the needs for common carrier access links, private links, urban area networks, rural area networks, temporary networks or emergency links for data and transmissions. The PASOLINK equipment offers very high performance with large system flexibility, which is easy to install and is a field proven to be very reliable. The PASOLINK NEO system provides interface types of PDH, SDH and LAN. The systems consist of antennas, outdoor unit (ODU) and Indoor unit (IDU) same as PASOLINK series. They are connected through a coaxial cable for each radio channel. Available configurations are non-protected type (1+0) and protected type (1+1). The protected type is available for twin-path type and hot-standby type.

2

INDEX CONTENT 1. KEY SPECIFICATIONS 2. PRODUCT DESCRIPTION 2.1) ANTENNA , ODU 2.2) MICROWAVE ANTENNA IMAGE 2.3)CONNECTION FROM ODU TO IDU IMAGE 2.4)ODU IMAGE 2.5) IDU 2.6) IDU IMAGE 3. DESIGN CONSIDERATION 4. MAIN FEATURES 5. MAINTENANCE FACILITIES 6. CROSS POLARIZATION INTERFERENCE CANCELLER 7. XPIC FUNCTION MENU 8. OTHER TOOLS & MATERIALS 9. LIST 10.DESIGN CONCEPT 11.COMPATIBILITY AMONG PASOLINK FAMILY

Pg . no 5 6 7 8 9 10, 11 12 13 14,15 16 17 18 19,20 21 22, 23 24 3

CONTENT

PG NO.

12. IDU & ODU COMPATIBILITY 25 13. EQUIPMENT MENU (PASOLINK NEO) 26 14. IDU FLEXIBILITY 27 15. SYSTEM UPGRADE 28, 29 16. E1 & LAN SETTING 30 31 ,32 17. INSTALLATION & INSTRUCTION 33 18. INSTALLATION FLOW CHART 34 19. IDU MOUNTING 35,36 20. MOUNTING OF ODU & ANTENNA 37 21. CABLE TERMINATION 38- 43 22. CABLE & TERMINAL CONNECTION 44 23. ANTENNA ALLIGNMENT 45, 46, 47

4

Key Specifications: Frequencies: 6, 7, 8, 10, 11, 13, 15, 18, 23, 26, 28, 32, 38, and 52 GHz Traffic capacities: 5 x 2 Mbps, 10 x 2 Mbps, 16 x 2 Mbps, 20 x 2 Mbps, 32 x 2 Mbps, 40 x 2 Mbps, 48 x 2 Mbps ,1 x 155 Mbps, 2 x 155 Mbps LAN: 10/100Base-T(X), 1000Base-SX/LX, 1000 Base-T Modulation: QPSK, 16/32/128QAM Common platform design (PDH, SDH, and LAN) V4 & Mx & PASO+(PDH) & PASO+(SDH) >> NEO (Same Equipment) Bitrate Free (PDH to SDH) 10MB/ 20MB/ 40MB/ 80MB/ 100MB/ STM-1 (Same MODEM Unit) Compact size/ Low power 1+0/1+1 @ 1U without FAN Various Application (E1+LAN), (E3+E1), (4PLAN + E1), (STM-1), APS for STM-1(opt), XPIC etc. ..., Bandwidth and Modulation Free ODU Coverage from 5E1 to 2xSTM-1 or from 10M to 2x155Mbps. Scalability up to your needs: Capacity upgradable by software 5E1 to 16E1 or 5E1 to 32E1 or 40E1 to 48E1 16E1 to 32E1 or 16E1 to 48E1 (interface card swap) 16E1 to STM-1 (interface card swap)

5

Antenna The complete menu of PASOLINK+ antennas includes diameters of 0.3m to 1.8m. They are designed to meet stringent requirements on mechanical rigidity. Antennas with diameters of 0.3m to 1.8m can be mounted directly to the ODU, making waveguides obsolete. This has relevant cost and reliability merits and makes the installation quicker and easier. The PASOLINK+ pole mounting structure is designed in a way that the ODU can be replaced while keeping the antenna and mounting bracket, including orientation, in place. The reflectors of the antennas are covered with white diffusive paint and the mounting structure is hot-dip galvanized. In the 6 - 8 GHz band, coaxial or waveguide cable with transducer is used for connecting between the ODU and IDU.

Transmitter-Receiver (ODU) The transmitter-receiver is designed to handle a STM-1 signal in 6-38 GHz bands. The equipment is designed to withstand severe weather conditions. 32/128-Quadrature amplitude modulation (32/128 QAM) is applied. Local Oscillator is employed for APC (Automatic Phase Control) loop circuit at the transmitter and receiver.

6

MICROWAVE ANTENNA Type 1- 11-38 GHz 128 QAM/32 QAM type (0.3m Diameter Antenna)

Type 2- 6-8 GHz 128 QAM type (Low Loss Coaxial cable connection to Antenna)

7

CONNECTION FROM ODU TO IDU

8

ODU

9

Indoor Unit (IDU) The IDU consists of six (6) s that have following functions. 1. ODU INTFC · Performing the multiplexing/demultiplexing of the transmitting signal, receiving signal, SV and EOW signal · Compensating the signal loss depending on IF cable length · Automatic Gain control 2. 32 QAM MODEM / 128 QAM MODEM · 32/128 QAM (Quadrature Amplitude Modulation), Modulator/Demodulator · Compensating quality degradation caused by fading · Error correction of burst error using the Reed –Solomon encoding/decoding · MLC (Multi Level Code) encoding/decoding. (Only for 32-AM) · Data streams conversion depending on the modulation scheme · Scrambling/de-scrambling of the data · RFCOH multiplexing/demultiplexing · Velocity conversion for radio frame

10

3. 150M INTFC / OPT INTFC / 10/100 BASE-T(X) INTFC (Selectable) · STM-1 signal interface (150M INTFC / OPT INTFC) · RSOH multiplexing/demultiplexing (150M INTFC / OPT INTFC) · Hitless switching of No.1 and No.2 receiving signal (150M INTFC / OPT INTFC) · 2 ports 10 BASE-T/100 BASE-TX INTFC (Each port traffic is separated) (10/100 Base-T(X)) · Transparency for VLAN (IEEE 802.1Q Tagged frame) (10/100 Base-T(X)) 4. CTRL · Setting of equipment operation · Monitoring alarm status of the equipment · Performing performance monitoring · Providing upper rank NMS interface · LCT terminal interface · EOW interface 5. WS INTFC (option) (32-QAM option) · Interface of 2048/1544 kbps Wayside signal 6. LAN CARD (Option) · Ethernet interface (10 Base-T) card with bridge function (exclusive use against WS interface)

11

IDU (a) 1+1 1U height with PDH+LAN interface

(b) 1+1 1U height with SDH interface

12

DESIGN CONSIDERATIONS Protection Capability- PASOLINK+ provides a protection switching system of Hot standby protection (1 + 1), and twin-path protection (1 + 1). 1. Non-Protection System- Non-protection system consists of one ODU, one IDU for 1+0 System, and one antenna. 2. Hot-Standby System- Hot-Standby system consists of two ODUs, one IDU for 1 + 1 system, and one or two sets of antennas. The protection switch of this systems is performed by the TX switches on the ODUs at the transmitting end and Hitless switch on the 150 M INTFC (or OPT INTFC) module in the IDU at the receiving end. 3. Twin-path System- Twin-Path system consists of two ODUs, one IDU for 1 + 1 System, and two sets of antennas. The protection switch of this system is performed by the Hitless switch on the 150 M INTFC (or OPT INTFC) module in the IDU at the receiving end.

13

MAIN FEATURES Advanced Technologies and Superb Performance • High reliability and Quality • Excellent field proven MTBF • Low power consumption • 10 Base-T/100 Base-TX, 1000 Base-SX/LX, 1000 Base-T (LAN interface) • APS for STM-1 optical • VLAN implementation • E1 Line Digital Cross Connect (DXC) High System Gain / High spectrum efficiency • High System Gain achieved by each modulation with Forward Error Correction (FEC) Technology and distortion cancelling technique called linearizer. • High spectrum efficiency achieved by QPSK to 128 QAM selectable technology. • Allowing smaller antennas and reducing system cost. 14

MAIN FEATURES Easy and Quick Installation • Interconnection : Only one coaxial cable and automatic equalization • Very Compact and Light • Various mounting methods for IDU, ODU and Antenna • Easy Antenna direction adjustment • Graphical Interface for installation and monitoring Frequency Agility and Easy Tuning • Field tunable local oscillator (Synthesizer) • RF point frequency can be changed through Local Craft Terminal (LCT). • Sub-band of type is changeable by replacing RF Filter. System Flexibility • Non-protected (1+0) or Protected (1+1) • 1+1 Hot Standby / Space Diversity / Twin Path System with Hitless switch • IDU is used commonly for 6 - 52 GHz • Software settable Modulation (QPSK/16 QAM/32 QAM/128 QAM) of IDU • Common ODU for PDH/SDH/LAN, also Co-Channel Dual Polarization system • Wide Input Line Voltage range is -40.5 to -57 VDC 15

Maintenance Facilities • Local and remote supervision function on IDU through LCT or PNMTj • Remote monitoring of ODU operating condition on IDU through PNMTj • Full front access at IDU for all cabling and interface • Loop back facility -Near end baseband, Far end baseband IF loop back • Pre-settable BER alarm point: 10-3, 10-4 or 10-5 (ext. alarm/AIS injection point). APS (Automatic Protection Switch) function (Option) APS realizes optical line protection for STM-1. This is simplified from conventional MSP (Multiplex Section Protection) function in order to fit RST mode equipment (ITU-T G.841, Non-revertive Mode).

16

XPIC (Cross Polarization Interference Canceller) PASOLINK NEO can improve its transmission capacity up to dual STM-1 in 28 MHz (27.5 MHz for 18 GHz band) bandwidth by using XPIC technology. In case of this capacity upgrading from one STM-1 system, the additional parts are dual polarized antenna, one more ODU/ IDU set, some XPIC cable kit and additional firmware. The upgrading can be realized with existing STM-1 equipment.

17

18

Other Tools and Materials 1. LCT- Local Craft Terminal (LCT) is the simple provisioning and maintenance terminal for PASOLINK+ system. LCT connects to the IDU. The LCT can control all functions and measures all monitor levels.

2. PNMS - NEC can provide an Element Network Management tool (PNMS: PASOLINK Network Management System). These tools can be used for maintenance and performance monitoring. These tools consist of software for UNIX or WINDOWS NT® OS. 3. Coaxial Cable (Interconnection between IDU and ODU)- The 5D-FB, 8D-FB, 10D-FB or 12D-FB coaxial cable (Low loss 50 ohms) serves as the interconnection between the transmitter-receiver (ODU) and baseband unit (IDU). The cable exchanges I/O data signals, DC power, alarm signals, control signals for frequency and TX power, RX level and ODU primary voltage monitoring signals and a pair of order wire signals. Due to the use of different IF (Intermediate Frequency) for TX and RX, a single coaxial cable is sufficient. This results in faster and easier installation.

19

4. Power Supply Voltage- The nominal power supply voltage is ±48 VDC. The guaranteed range of the same unit is sufficient for nominal voltage of ±36 to ±60 V (±48 V) as well. In this way, commonality between modules is achieved throughout the network even if different DC voltages are applied at different locations. (±24 VDC power supply is available as an option.)

5. PASOLINK MONITOR (OPTION)- PASOLINK MONITOR is used for receiving signal level monitor and ODU-IDU/ODU-ODU EOW system. This is an installation tool for antenna direction pointing. (Receiving level can be measured as voltage by voltmeter without PASOLINK MONITOR.)

6. Head set- Head set is used for EOW system.

20

LIST

21

22

23

COMPATIBILITY AMONG PASOLINK FAMILY THE DIFFERENCE BETWEEN NEO & EXISTING EQUIPMENTS.

24

IDU & ODU Compatibility

25

Equipment Menu (PASOLINK NEO)

26

27

28

29

30

31

32

INSTALLATION & INSTRUCTION Before going to site check list : Before going to any site, please be sure you completely prepared the following items: 1- The installation tools. 2- The test equipment ,materials ,and tools.( for test work only) 3- Site installation drawings. 4- All labels/stickers (hard and soft copy) 5- Frequency plan and system configuration documents. 6- Test procedure and test data sheets .( for test work only) 7- Confirm access to site/station. 8- Check the condition of the vehicle to be used. 9- Make sure you and your staff are in good conditions (physically) 10- Confirm the site/station entrance conditions. 11- Arrive to site/station safely.

33

Installation Flow Chart

34

IDU Mounting The installation procedure for the IDU is shown below. (a) Accessories Required- Screwdriver (b) Procedure for Mounting and Dismounting (1) Mounting- Mounting method of IDU is shown in Fig. 2-11. (2) Dismounting- For dismounting IDU (if necessary), use the following procedure. Step Procedure 1 Hold the IDU so that it does not drop, and remove two screws each from both sides. 2 Take out the IDU from the 19-inch rack. STEP1: Align the IDU to the mount position on the 19-inch rack. Step2: Fix each side of the IDU to the rack with the two screws(M5) Step3: To mount the IDU in a 19-inchrack ,allow space more than 200mm to the rear section and space for one unit to the top and bottom.

35

36

Mounting of ODU and ANT.: There are two different cases as follows: 1- The ODU is direct mounted to the antenna. 2- The ODU is mounted with a separate bracket. According to which case you have ,you will follow the assembling procedure included with each antenna And you will know how to fix that ODU. Note: In case two you have to install an additional RF cable between the ODU and the Antenna. The tools required: Wrench, Monkey wrench or Torque wrench , and suitable screwdriver. ODU Demounting (if necessary): 1- Remove the four fixed bolts from the ODU. 2- Then demount the ODU.

37

Cable Termination In the following, list of tools and material and the method for cable termination are described. The following cables are described for reference. • BNC connector • D-sub connector • N-P connector • Molex M5557-4R connector Note: Use ISO standardized screw (mm unit) for D-SUB connector. The necessary tools and materials are summarized as follow. Tools and Material List 1 .Soldering Iron 2 .Knife 3 .Measure 4 .Wire Stripper 5 .Adjustable Wrench 6 .Hand Crimping Tool (CL250-0012-2/CL250-0013-5)For D-Sub connector (57026-5000/57027-5000)For Molex connector 7 .Solder

38

Terminating Coaxial (Baseband Signal) Cable with BNC Connector

39

Terminating Coaxial (Baseband Signal) Cable with BNC Connector

40

Terminating Coaxial (IF Signal) Cables with N-P Connector:

41

Terminating Coaxial (IF Signal) Cables with N-P Connector:

42

Terminating Coaxial (IF Signal) Cables with N-P Connector:

43

Cable and Terminal Connections During cables and terminal connections, refer to the following connecting method. (a) Connect baseband signal cable(s) Align the BNC connector guide groove to the other connector guide ridge and turn the connector cap clockwise fully until it is locked firmly. (b) Connect IF signal cable Connect the connector and tighten it by turning the tightening ring clockwise. (c) Connect supervisory cable(s) Take care to connect the D-sub connector the right way round and fix it with two screws (M3). (d) Connect power supply cable Take care to catch the Molex connector the right way round. (e) Connect terminal Take care to connect the D-sub connector the right way round and fix it with two screws (M3).

44

Antenna Alignment Pan the antenna by Multi-meter & LCT

+3.45V

ODU

IF CABLE

•

Multi-Meter RSSI or AGC Voltage

RSSI/VAGC

Azimuth

1st Side Lobe

IDU

Main beam

45

Antenna Alignment (Horizontal)

46

Antenna Alignment (Up and Down) Up and Down Misaligned

Reflecting Ground or Specular Plane 47

THANK YOU FOR READING IT HAVE A GOOD DAY
