Spring Operated Safety Relief Valve Sizing Program POINT MOUSE ON RED ARROW TO VIEW DISCLAIMER
To use the Mercer Valve sizing program, the information on "DATA ENTRY" sheet must be comple information in the "DATA ENTRY" sheet, notice the red arrows thoughout the sheet. Point on th infomation about the program. This information may help entering correct data in the program. location and phone numbers in the first set of highlighted cells. Use the "Tab" key to jump fro choose the infomation from list boxes in Section 1. These list boxes choose appropriate sizing and valve type being sized. Enter service conditions in highlighted cells in section 2, and enter section 3. When all information is entered and correct, the program will solve for required area a to meet given conditions. Use the tabs at the bottom of the page labeled printout to view a data These sheets can be sent in to Mercer for a formal quote. Thank you for using Merc
Conventional valve Sizing Program Version: 4.99-CUST released on 10-DEC-08
Oklahoma City Home Office NW 4TH ST., OKLA. CITY, OK 73127 (405) 495-6533 (F): (405) 495-8728 Toll Free 1-800-833-6402 [email protected]
Bridgeport Branch Office
8 LONG DR., HOUSTON, TX 77087 (940) 683-9002 (F): (940) 683-9004 Toll Free 1-866-683-9002 [email protected]
Chicago Branch Office
Customer Relations Department BOX 597, LIBERTYVILLE, IL 60049 Toll Free 1-866-855-5460 [email protected]
Valve Sizing Program TO VIEW DISCLAIMER
ENTRY" sheet must be completed. While entering in oughout the sheet. Point on these arrows for more g correct data in the program. Enter name, company, Use the "Tab" key to jump from cell to cell. Next xes choose appropriate sizing method, sizing units, ed cells in section 2, and enter media information in m will solve for required area and choose a valve size labeled printout to view a datasheet for the valve. ote. Thank you for using Mercer Valve.
v4.99Cust as of 10-DEC-08 SAK
01/04/2017 CONVENTIONAL SPRING OPERATED RELIEF VALVE SIZING 1/4/17 9:07 AM
NAME: COMPANY: LOCATION: PHONE: FAX: EMAIL: TAG NUMBER: REFERENCE #: 1) Select information from boxes below.
2) Sizing Conditions and Fluid Information
Sizing Method: ASME, Section VIII Media Type: GAS
Atmospheric Pressure:
14.7
psia
Allowable Over Pressure: 10%
Valve Type: 9100 THREADED Compressor Service
Required Flow Units: scfm
Fluid Name: Natural Gas MOLECULAR WEIGHT
Pressure Units: psi
GAS CONSTANT
Temperature Units: FAHRENHEIT 3) Pressures
Compressiblity Factor:
17.400 344.000 1
4) Temperatures
Operating Pressure:
50.0
psig
Operating Temperature:
60.00
ºF
Valve Set Pressure:
100.0
psig
Relieving Temperature:
60.0
ºF
100
scfm
5) Back Pressure
6) Capacity & Calculations Superimposed Back Pressure Variable:
0.00
psig
Constant:
0.00
psig
Required Capacity
Required Orifice Area:
0.0429
in²
"C" Orifice Built-up Back Pressure Variable:
INLET & OUTLET SIZE: 3/4 x 1 CONNECTION TYPE: MNPT x FNPT
0.00
psig
Selected Orifice Area:
0.0620
in²
Selected Orifice Flow:
144.621
scfm
MATERIALS: CARBON STEEL INLET/CARBON STEEL BODY CAP TYPE: CLOSED CAP 1/4" PIPE TAP: NO
SOUR GAS SERVICE: NO Quantity 1
01/04/2017
As per ASME code, Section VIII, Division 1, para. UG-125(a), the customer accepts all responsibility in insuring that the correct pressure relief valve is installed for their application. The purchase order for the pressure relief valve confirms the sizing calculations and material compatibility choices made by Mercer Valve are correct for the application. Note: This sizing program does not take material compatibility or pressure and temperature limitations into for choosing materials. Please all material choices with Mercer Valve Company, Inc.
Disclaimer
Disclaimer
v4.99Cust as of 10-DEC-08 SAK
v4.99Cust as of 10-DEC-08 SAK
01/04/2017
Conventional Valve Data Sheet
Oklahoma City Home Office
1/4/2017 9:07
9609 NW 4TH ST., OKLA. CITY, OK 73127 (P): (405) 495-6533 (F): (405) 495-8728 Toll Free 1-800-833-6402 [email protected]
Houston Branch Office 6218 LONG DR., HOUSTON, TX 77087 (P): (713) 242-6960 (F): (713) 242-6963 Toll Free 1-866-833-6402 [email protected]
Customer Name: Company: Location: Phone: Fax: Email: Reference #: SYSTEM INFORMATION
FLUID DATA
Bridgeport Branch Office 6218 LONG DR., HOUSTON, TX 77087 (P): (940) 683-9002 (F): (940) 683-9004 Toll Free 1-866-683-9002 [email protected] VALVE TAG NUMBER SYSTEM TYPE
Vessel or Pipeline
FLUID
FLUID STATE
Natural Gas
MOLECULAR WEIGHT
GAS
SPECIFIC GRAVITY
17.400
0.600
RATIO of SPECIFIC HEA
Gas Constant
1.2680
344.000
COMPRESSIBILITY FACTOR
1.000
REQUIRED CAPACITY
100.000 0.00
psig
0.00
psig
TOTAL BACK PRESSURE
0.00
psig
0.00
psig
OPERATING PRESSURE OPERATING TEMPERATURE
50.00 60.0 100.00 10.00%
psig ºF psig
60.00 14.70
ºF psia psia psig
BUILT-UP BACK PRESS
SIZING INFORMATION
RELIEVING TEMPERATURE ATMOSPHERIC PRESSURE
SET PRESSURE % OVER PRESSURE
FLOWING PRESSURE ALLOWABLE OVER PRESS.
SIZING METHOD
0.043 in²
SELECTED ORIFICE SIZE
"C" Orifice
SELECTED ORIFICE AREA
0.062 in²
MAXIMUM CAPACITY of VALVE AT OVER PRESS.
MATERIALS
144.621 scfm
VALVE BODY MATERIAL INLET BASE MATERIAL DISC NOZZLE SEAT MATERIAL O-RING MATERIAL
CARBON STEEL CARBON STEEL 440C 17-4 SS VITON 90 DUROMETER STD (VITON & BUNA-N)
SPRING MATERIAL OPTIONS
17-7 PH STAINLESS STEEL
1/4" PIPE TAP SOUR GAS SERVICE
NO NO
CAP TYPE VALVE TYPE PART NUMBER INLET SIZE VALVE INFORMATION INLET CONNECTION
124.70 10.0
ASME, Section VIII
REQUIRED AREA SIZING RESULTS
scfm
SUPERIMPOSED VARI
SUPERIMPOSED CONST
CLOSED CAP 91-
12
OUTLET SIZE OUTLET CONNECTION
C 3/4
5
1
9100 THREADED V 05 C in. 1
MNPT
REPAIR KIT NUMBER
1
QUANTITY
1 in.
FNPT C
1
V
1
C
1
1
0
DISCLAIMER
As per ASME code, Section VIII, Division 1, para. UG-125(a), the customer accepts all responsibility in insuring that the correct pressure relief valve is installed for their application. The purchase order for the pressure relief valve confirms the sizing calculations and material compatibility choices made by Mercer Valve are correct for the application.
Note: This sizing program does not take material compatibility or pressure and temperature limitations into for choosing materials. Please all material choices with Mercer Valve Company, Inc. NOTES
Standard Spring C Range Spring 15 A7 31 03 51 04 81 05 126 06 231 07 401 09 801 11 1501 13 2501 14 3501 15 4601 56 6201 17 7601 19 8701 N/A
