Material Schematic Hydraulic System Track Type Tractors D8r Dozer Caterpillar 1w3l5i

FLUID POWER SYMBOLS

Component Locations (Volume 1) Item Number

Description

Part Number

Schematic Location

1

Pump Gp - Steering / Cooling

139-4151

F-4

2

Motor Gp - Steering

159-7162

F-7

3

Pump Gp - Implement

9T-8346

D-3

4

Valve Gp - Dozer & Ripper Imp Dozer Only

160-5951 160-5952

D-5

5

Manifold Gp - Inlet & Relief

163-0829

D-5

6

Valve Gp - Dozer Lift Section

160-5953

D-5

7

Valve Gp - Tilt Section

160-5954

C-5

8

Valve Gp - Ripper Lift & Tilt Sections

169-3323

B-5

10

Cover - End

169-9119

A-5

11

Valve Gp - Dozer Pilot Control

200-0189

A-3

12

Valve Gp - Ripper Pilot Control

184-5321

A-8

14

Valve Gp - Implement Lockout

130-4531

B-8

15

Accumulator - Pilot Circuit

200-0750

C-8

16

Valve Gp - Pressure Reg Manifold

162-0162

C-8

17

Valve Gp - Cooler By

126-0747

E-3

18

Cooler - Hydraulic Oil

153-1271

D-2

19

Filter Gp - Steering Charge

177-6979

F-3

20

Valve Gp - Steering Pilot

9T-8693

E-3

21

Valve Gp - Pressure Control

163-0057

E-7

22

Valve Gp - Quick Drop

109-6942

D-2

23

Cylinder Gp - Lift

6E-1102

D-1

24

Cylinder Gp - Dual Tilt

6E-0397

C-1

25

Cylinder Gp - Single Tilt

6E-1175

B-1

26

Cylinder Gp - Ripper Tip (LH)

155-3652

D-8

27

Cylinder Gp - Ripper Tip (RH)

165-0102

D-8

28

Cylinder Gp - Ripper Lift

155-3653

D-7

29

Cylinder Gp - Pin Puller

6E-3113

D-7

30

Tank Gp - Hydraulic Oil

164-3700

C-3

32

Valve Gp - Dual Tilt

106-9648

C-1

20

Description Implement Pump Signal Pressure

D-4

Charge Pump Discharge Pressure

E-7

G

Case Return

E-7

H

Filter Outlet Pressure

F-3

HA

Implement Pump Discharge At Pump

E-7

HC

Left Steering Loop

F-7

HD

Right Steering Loop

F-7

Hydraulic Oil Cooler Inlet Pressure

D-2

K

Filter Inlet Pressure (SOS)

F-3

X1

Right Steer Actuator Signal Pressure

F-4

X2

Left Steer Actuator Signal Pressure

F-4

Y1

Left Steer Pilot Signal

E-3

Y2

Right Steer Pilot Signal

E-3



Pilot Oil Supply Pressure Non Tap Location Points Of Reference

B-8

Implement Pump Discharge Pressure

D-4

Charge Pump Relief Pressure

E-5

Right Steer Loop At Pump

F-5

E MA MB

Left Steer Loop At Pump

E-5

PS

Steer Pump Control Supply

E-5

BASIC COMPONENT SYMBOLS

PUMP or MOTOR

21

32

CONTROL VALVES

SPRING

FLUID CONDITIONER

LINE RESTRICTION (FIXED)

RESTRICTION

PRESSURE COMPENSATION

LINE RESTRICTION (VARIABLE)

SPRING (ADJUSTABLE)

VARIABILITY

2

PUMP: VARIABLE and PRESSURE COMPENSATED

2-SECTION PUMP

HYDRAULIC PNEUMATIC ENERGY TRIANGLES

ATTACHMENT

LINE RESTRICTION VARIABLE and PRESSURE COMPENSATED

VALVES VALVE ENVELOPES

18

VALVE PORTS

TWO POSITION

ONE POSITION

TWO-WAY

THREE POSITION

22

12 14

CHECK VALVES

AB

AB

P T SHIFTED POSITION

P T NORMAL POSITION

15 16

INFINITE POSITION

PRESSURE

30

PILOT CONTROLLED

ROTATING SHAFTS

FLOW

TEMPERATURE

3

UNIDIRECTIONAL

BIDIRECTIONAL

FLUID STORAGE RESERVOIRS

D8R Track-Type Tractor Hydraulic System

7 8 10 19 30

12 14

SHUTTLE

SPRING LOADED

BASIC SYMBOL

MEASUREMENT

4 5 6

FOUR-WAY

THREE-WAY

CONTROL VALVES

Schematic Location

F

A

17

11 20

15 16

HB

J

1

MAIN AUX.

Tap Locations Pressure, Sampling, and Sensor Tap Number

19

RENR3680-01 August 2005

VENTED

RETURN BELOW FLUID LEVEL

COMBINATION CONTROLS

AKA1-UP 6YZ1-UP

22

RETURN ABOVE FLUID LEVEL

PRESSURIZED

SOLENOID or MANUAL

SOLENOID

SERVO

SOLENOID and PILOT or MANUAL

SOLENOID and PILOT

DETENT

THERMAL

MANUAL CONTROL SYMBOLS

4 5 6

MANUAL SHUTOFF

PUSH-PULL LEVER

GENERAL MANUAL

PUSH BUTTON

PEDAL

SPRING

PILOT CONTROL SYMBOLS

7 8 10

RELEASED PRESSURE

32

21

EXTERNAL RETURN

18

REMOTE SUPPLY PRESSURE

INTERNAL RETURN

SIMPLIFIED

CROSSING AND ING LINES

ACCUMULATORS

SPRING LOADED

GAS CHARGED

LINES CROSSING

HYDRAULIC PUMPS FIXED DISPLACEMENT

2

1 3

17

HYDRAULIC AND PNEUMATIC CYLINDERS

SINGLE ACTING

LINES ING

FIXED DISPLACEMENT

VARIABLE DISPLACEMENT NON-COMPENSATED

UNIDIRECTIONAL

UNIDIRECTIONAL

BIDIRECTIONAL

BIDIRECTIONAL

DOUBLE ACTING

INTERNAL AGEWAYS

HYDRAULIC MOTORS

VARIABLE DISPLACEMENT NON-COMPENSATED

INTERNAL SUPPLY PRESSURE

COMPLETE

INFINITE POSITIONING

PARALLEL FLOW

FLOW IN ONE DIRECTION

TWO POSITION

THREE POSITION

CROSS FLOW

FLOW ALLOWED IN EITHER DIRECTION

Volume 1 - with Ripper Printed in U.S.A.

© 2005 Caterpillar All Rights Reserved

26 28

27

2

G

X1

HC

HB

Transducer (Fluid)

RIPPER

Pressure Switch (Adjustable)

M

Generator

Electric Motor

Electrical Wire

Temperature Switch

Electrical Symbols (Electrical)

HA

H

21

K

24 25

FW D

Transducer (Gas / Air)

Pressure Switch

23 23

Hydraulic Symbols (Electrical)

T

Pressure Symbol

F

Temperature Symbol

19

G

Wire Number Identification Codes Electrical Schematic Example

Hydraulic Schematic Example Current Standard

Current Standard Harness identification code This example indicates wire 135 in harness "AG".

Wire Color

325-AG135 PK-14

IMPLEMENT SYSTEM

Y1

Wire Circuit Number Identification

18 Y2

Flow Symbol

Level Symbol

325-PK Circuit Identification Number

Wire Color

Wire Gauge

Previous Standard

24

21

J

Wire Color

Wire

325-PK-14 B

DOZER BLADE

STEERING SYSTEM

Circuit Number Identification

A

Wire Gauge (EXAMPLE VALVE)

16 Page

HD

3

RENR3680-01 VOL 1

1

X2

28

29

Electrical Symbols Table

8

7

6

HD

2

4

5

1

MA

2

3

X2

19

K

X1

1

H

LINES GROUP COLOR DESCRIPTIONS STEER PUMP OUTPUT IMPLEMENT PUMP OUTPUT TILT CYLINDER CONTROL CIRCUIT IMPLEMENT PUMP SIGNAL RIPPER TIP CYLINDER CONTROL CIRCUIT SUPPLY LINE DRAIN / RETURN LINE

F

STEERING LOOP CIRCUIT WINCH FREE SPOOL CONTROL CIRCUIT LIFT CYLINDER CONTROL CIRCUIT

F

29

RIPPER LIFT CYLINDER CONTROL CIRCUIT WINCH CONTROL CIRCUIT

20

CONTROL PRESSURE SUPPLIED BY TRANSMISSION

STEERING PILOT CONTROL CIRCUIT

F Y1 PS

HC

MB

E

Y2

G

17

E

E

21

HA

4

28

HB

RIPER TIP

MARGIN

5

26

3

CUT-OFF

J

18 D

D

27

B

A

23 6

RIPPER LIFT

28

22

A

LIFT

16

7

32 24

C

30 TILT

15

DUAL TILT OPTION

8

25

SINGLE TILT OPTION

16 Page, Color 2

RENR3680-01 VOL 1

PILOT SUPPLY

C

14

B

LOWER

RAISE LOWER

RAISE

RIPER LIFT

Pressure Line

TILT LEFT



Pilot / Load Sensing Pressure

TILT RIGHT

8 RAISE 1

RAISE

2

3

4

Drain / Return Lines Component Group

TILT 2

1

TIP

B

LINE PATTERNS

3

4

11

Attachment Air Line

ELEC. DET.

CALLOUTS

TIP/IN

12

TIP/OUT 1

T

S

2

3

T

S

4

1

RIPER TIP

T

S

2

3

T

S

YY

Taps (Pressure, Sampling,Sensor) by letter

52

Components by number

4

10

A

A FLOAT PILOT BOOST SIGNAL

THIS SCHEMATIC IS FOR THE D8R TRACK-TYPE TRACTOR PILOT SUPPLY

PILOT DRAIN

Part #: 163-5975 CHG 06 (RIPPER VERSION) VOLUME 1 OF 2 Components are shown installed on a fully operable machine with the key and engine off and transmission shifter in neutral.

8

7

6

5

4

3

2

1

20
