Technical Description Hydraulic Excavator

`

Operating weight with backhoe attachment 138,8 – 143,0 t Operating weight with shovel attachment 141,2 – 146,3 t Engine output 575 kW / 782 HP Bucket capacity 3,70 to 9,50 m3 Shovel capacity 7,00 to 12,00 m3

litronic

` – the total “system” comprised of intelligent electronics and functional hydraulics – controls, regulates and coordinates all key systems of the excavator. Powerful – turbo-charged and after-cooled 12 cylinder diesel engine, with direct injection and low operating RPM. Productive – optimum utilization of available engine output via electronic engine speed sensing pump regulation. Increased work speed through pump flow summation. Operating safety – the electronic engine-speed-sensing control protects the engine from overload. Pressure – and flow compensation eliminate unnecessary oil circulation and consequently avoid excess heat as well as component wear.

Comfortable – large well equipped, air conditioner and sound insulated cab. Seat and joystick console independently adjustable to individual operator’s size and weight. Environmentally sound – low noise and exhaust emission. Optional: Bio degradable oil. Easy service – clear and easy access to all components. Large catwalks, steps and platforms. Sealed attachment pivots, central lubrication system and extended service intervals reduce maintenance costs. Versatile – different lengths of gooseneck booms, assortment of sticks and an extensive variety of buckets, bottom dump shovels and grapples provide application versatility. Economical – the combination of all the above, results in top performance at low operating costs. ` This is .

litronic

The Better Machine.

Engine Cummins diesel engine Rating per DIN/ISO 3046-1 Model Type Displacement Bore/Stroke Air cleaner Fuel tank Electrical system Voltage Batteries Alternator Engine idling Air system

Swing Drive 575 kW/782 HP at 1900 RPM reduced to 492 kW/668 HP at 1800 RPM VTA 28 C 800 12 cylinder V-engine, water-cooled, direct injection, turbo-charged, after-cooled 28 l 140/152 mm dry-type air cleaner with automatically dust ejector, primary and safety elements 1780 l 24 V 2 x 170 Ah/12 V 24 V/75 Amp sensor controlled 1 cylinder compressor, maintenance-free, pressure regulator, anti-freeze pump

Hydraulic motor Gear Swing ring Swing speed Swing torque Swing-Holding brake

Uppercarriage Design Attachment mounting Catwalks

Hydraulic pumps for attachment and travel drive Max. flow Max. hydraulic pressure Pump regulation Hydraulic pump for swing drive Max. flow Max. hydraulic pressure Hydraulic tank pressurization Hydraulic tank capacity Hydraulic system capacity Hydraulic oil filter Hydraulic oil cooler Electronic engine speed sensing Lubrication

3 variable flow axial piston pumps 2 x 555 l/min + 1 x 318 l/min 320 bar Electro-hydraulic, pressure compensation, flow compensation, automatic oil flow optimizer 1 reversible swash plate pump, closed-loop circuit 450 l/min

torque resistant modular design upper frame parallel length girders on both sides of the upper

Operator’s Cab Design

Operator’s seat

Hydraulic System

Liebherr axial piston motor Liebherr planetary reduction gear Liebherr, sealed triple roller swing ring, internal teeth 0 – 5,6 RPM 415 kNm air-over hydraulic multi-disc brakes, maintenance-free

Option Controls Monitoring Acoustical and optical signal Optical signal Heating system/ air conditioning Noise emission (86/662/EWG)

resiliently mounted, sound insulated, large windows for 360 h visibility, integrated falling object protection (FOPS) suspended, body-contoured with shock absorber, adjustable to operator’s weight additional training seat joystick levers integrated into armrest of seat via LED Display in case of low engine oil pressure or low coolant level. Automatic engine shut of in case of engine overheating or low hydraulic oil level. Destroking of main pumps heavy duty, high output air conditioner and heater unit inside cab = 78 dB(A) outside = 116 dB(A)

340 bar 0,5 bar 1380 l 2190 l 1 full flow filter in return line, 1 high pressure filter for each main pump 2 separate coolers thermostatically regulated fan at rated engine speed setting central lubrication system

Undercarriage Hydraulic motor Travel gear Travel speed Drawbar pull Parking brake Hydraulic brake valve Track components Track rollers/ carrier rollers Track pads Track chain adjustment Transport

Axial piston motor Liebherr planetary reduction gear 0 – 3,1 km/h 886 kN hydraulically actuated wet multi-disc brakes, maintenance-free integrated in main valve block B 10 S, maintenance-free 9/2 Forged double gro hydraulic undercarriage side frames are removable

Hydraulic Controls Servo circuit Emergency control Power distribution Flow summation Control functions Attachment and swing Travel Additional functions

Independant, electric over hydraulic proportional controls of each function via accumulator for attachment functions with stopped engine via 3 monoblock control valves with integrated primary and flanged-on secondary relief valves to attachment, hoist, stick and bucket cylinders and travel drive – proportional via joystick levers – proportional via foot pedals or hand levers for all travel functions – via foot pedals or joystick toggle switch

Technical Data 2

Attachment Design Pivots Pivots bucket-to-stick bucket-to-link Lubrication Hydraulic cylinder Hydraulic connections Bucket

box-type, welded structures with large cast steel components sealed and lubricated O-ring sealed and completely enclosed connected to the centralized lubrication system Liebherr manufactured cylinders, sealed sherical, self aligning bearings, hydraulic piston cushioning pipes and hoses equipped with SAE split-flange connections with lifting eye 50 t

A A1 A2 C D D1 E K L X M

mm 4200 4700 5825 6280 4915 5035 3973 1893 5407 3200 6962

A A1 A2 C D D1 E K L X M

mm 4200 4700 5825 6280 4915 5035 3973 1893 5407 3200 6962

P Q T W N B G

600 5300

mm 1832 806 8253 4500 800 5300 5585

C1 T1 T2

6350 10850 15300

P Q T W N B G

mm 1830 805 8253 4500 800 5300 5525

C1 T1 T2

600 5300 5525

4850 12700 16000

Dimensions 3

Diesel engine The heavy duty, water-cooled, turbo-charged and aftercooled Cummins Diesel engine delivers superior power and high power reserves. Its low operating speed results in lower fuel consumption, reduced emissions and an extended engine life. The enclosed engine compartment is easily accessible through full sized, easy to open doors and permits “walk in” access to all components for easy service.

Litronic-System The electronic engine-speed-sensing pump regulation allows full utilization of the engines available output, independent from external influences. The variable displacement axial piston pumps are fitted with an electro-hydraulic regulator which reacts in fractions of a second to the changing requirements of power or speed. Flow compensation reduces pump flow to a minimum when joystick levers are in neutral, avoiding excess heat and energy loss. The same effect is achieved with pressure compensation which minimizes pump flow prior to reaching maximum operating pressure. An automatic oil flow optimizer assures efficient power distribution to each individual function. The operators comfort and efficiency is enhanced by the LED display and monitoring system. It monitors all vital machine functions and includes a variety of automatic safety features. The Litronic system offers extensive customer benefits, such as improved efficiency, reduced fuel consumption and overall economy.

Undercarriage An overall low center of gravity for the machine is achieved through favorable weight distribution of the machine’s undercarriage, upper structure and attachment. This low center of gravity, combined with a wide undercarriage base, provides excellent stability for smooth, precise work and efficient transmission of the high dig and breakout forces. It also increase the life expectancy of undercarriage components. Standard bolt-on track chain guides on each side frame protect and improve the life expectancy of track components. The two side frames are removable for easy transportation. Carbody and side frames are connected with a unique “hook and key” design, which shortens and simplifies assembly.

More Benefits Through Advanced Techno 4

Cab The raised, spacious and comfortable cab features oversized, tinted windows and offers an excellent view of the trucks being loaded and general all-around visibility. The comfortable, air suspended and shock absorbed seat is adjustable to each individual operators size and weight. An air conditioner, integrated into the cab roof, is standard and increases operator comfort even in the most adverse conditions. A falling object protective structure (FOPS) is integrated into the roof. The control and instrument is within easy view of the operator. Service and control indicators, combined in a display screen, conveniently and continuously informs the operator, via symbols, of all machine functions. Effortless and precise joystick levers are comfortably integrated into the seat console.

Attachments Strict use of fine grain alloy steel plates, true hollow box structures and large size cast steel components in high stress areas result in strong attachments with high availability and long life expectancy. Widely spaced pivots in the attachment allow the use of two short, large diameter, hardened and chromed pins and low wear, high alloy steel bushings. Completely sealed, floating pins and bushings increase lubrication intervals and attachment availability. Shovel and backhoe buckets are especially strong and wear resistant. The optimized bucket shape achieves a faster and higher degree of fill. A number of different length sticks, booms and various size buckets allow the machine to be tailored to all types of materials and applications.

Swing Drive Swing acceleration of the upper carriage is accomplished via an axial piston motor flanged to a Liebherr planetary reduction gear. The swing pump and swing motors are linked in an independent closed-loop circuit. This system produces high swing torque, fast swing accelerations and deceleration, requires less power and shortens cycle times. The high swing torque created by the Liebherr planetary reduction gear, is transmitted to the Liebherr swing ring which features internal teeth for maximum protection from external damage and contamination. The swing operation is independent from all other travel and attachment functions.

logy 5

To order a complet machine you need the following: x Basic machine and track pads x Hoist cylinders

Id. No. see page 12

9327202

x Gooseneck boom

8,00 m

9377146

x Stick with bucket cylinder 3,65 m

9377203

x Bucket – size as applicable

see below

Max. reach at ground level Max. teeth height Max. dump height Max. digging depth

14,40 m 15,20 m 9,90 m 8,30 m

Max. digging force: Max. breakout force:

512 kN (52,2 t) 640 kN (65,2 t)

Buckets Cutting width SAE mm Capacity SAE heaped m3 Weight kg Id. No. – Suitable for material up to a specific weight of t/m3 1) 2) 3)

20001) 5,70 6900 9355834 2,40

22001) 6,50 7600 9357602 2,20

24502) 7,50 7000 9355835 2,00

Heavy duty rock bucket with teeth size 86 (SD) Bucket with teeth size 76 (FP) Loading bucket with teeth size 76 (FP)

Backhoe Attachment with Gooseneck Boom 8,00 m 6

26502) 8,50 7200 9355837 1,80

29003) 9,50 6900 9355836 1,50

To order a complete machine you need the following: x Basic machine and track pads x Hoist cylinders x Gooseneck boom

Id. No. see page 12

9327202 9,40 m

9322569

x Stick with bucket cylinder 3,65 m 5,15 m

9377203 9332575

x Bucket – size as applicable

see below

Digging envelope 1 2

Stick Stick

3,65 m 5,15 m

Stick length Max. reach at ground level Max. teeth height Max. dump height Max. digging depth

m m m m m

Max. digging force: Max. breakout force:

3,65 15,90 16,20 10,90 9,50

5,15 17,40 17,10 11,80 11,00

512 kN (52,2 t) 640 kN (65,2 t)

Buckets Cutting width SAE Capacity SAE heaped Weight Id. No. Suitable for material up to a specific weight of 1) 2)

with Stick 3,65 m with Stick 5,15 m

mm m3 kg – t/m3 t/m3

16501) 3,70 5500 9333517 – 2,20

18501) 4,50 6000 9333518 2,20 1,80

20002) 5,70 6900 9355834 1,80 1,50

22002) 6,50 7600 9357602 1,50 –

Bucket with teeth size 76 (FP) Heavy duty rock bucket with teeth size 86 (SD)

Backhoe Attachment with Gooseneck Boom 9,40 m 7

To order a complete machine you need the following: x Basic machine

Id. No. see page 12

x Extra hydraulic controls for bottom dump bucket

9579465

x Hoist cylinders

9327202

x Shovel boom with crowd cylinder

9358879

x Shovel stick with bucket cylidners

9358878

x Bottom dump bucket – size as applicable

see below

Max. reach at ground level Max. dump height 45 h Max. crowd length Bucket opening width F

10,80 m 10,00 m 4,30 m 2110 mm

Crowd force at ground level: Max. crowd force: Max. breakout force:

705 kN (71,8 t) 900 kN (91,7 t) 700 kN (71,3 t)

Buckets Cutting width SAE mm Capacity SAE heaped m3 Weight kg Id. No. – Suitable for material up to a specific weight of t/m3 1) 2) 3)

26501) 7,00 11500 9368041 2,60

Bottom dump bucket with Delta cutting edge and teeth size 86 (LP) Bottom dump bucket with Delta cutting edge and teeth size 76 (LP) Coal bottom dump bucket with straight spade nose and teeth size 66 (FP)

Shovel attachment 8

30502) 8,60 11400 9368039 2,20

30502) 9,20 12000 9368044 2,00

30502) 10,00 14000 9368042 1,80

33503) 12,00 11800 9329783 1,40

Cab L Length H Height Width Weight

mm mm mm kg

3400 2800 1700 2000

Cab elevation L Length H Height Width Weight

mm mm mm kg

2460 1325 1700 1100

Upper with swing ring L Length H Height Width Weight

mm mm mm kg

6960 2160 3650 29200

Counterweight L Length H Height Width Weight

mm mm mm kg

675 2080 4960 18800

Fuel Tank (one) L Length H Height Width Weight

mm mm mm kg

1330 1185 1180 900

Hydraulic oil cooling unit (one) L Length H Height Width Weight

mm mm mm kg

1910 1185 1285 800

Side (one) L Length H Height Width Weight

mm mm mm kg

545 1900 1660 320

Catwalk right L Length H Height Width Weight

mm mm mm kg

5470 270 520 200

Dimensions and Weights 9

Catwalk left L Length H Height Width Weight

mm mm mm kg

Catwalk for cab L Length H Height Width Weight

mm mm mm kg

2850 270 520 110

lateral1) 3360 410 410 130

back2) 550 350 510 30

Railing (1 kit) L Length H Height Width Weight

mm mm mm kg

2100 1500 1000 230

Undercarriage central girder L Length H Height Width Weight

mm mm mm kg

3060 1890 3700 10200

Side frame with complete travel drive (each) Track pads

mm

600

800

L Length H Height Width Weight

mm mm mm kg

6962 1830 1215 21600

6962 1830 1215 23150

Ladder (one each)

Cab1)

Undercarriage2)

L Length H Height Width Weight

600 2930 550 50

mm mm mm kg

180 1330 925 2 x 80

Hoist cylinder (two) L Length l Diameter Weight

mm mm kg

3550 380 2 x 1500

Gooseneck boom with stick cylinders Length

mm

8000

9400

L Length H Height Width Weight

mm mm mm kg

8500 3000 1550 13000

9900 3200 1550 14000

Dimensions and Weights 10

Stick with bucket cylinders, link and lever Length

mm

3650

5150

L Length H Height Width Weight

mm mm mm kg

5000 2300 1100 8500

7000 2200 1100 9200

Backhoe buckets Cutting width

mm

1450

1650

1850

2000

Capacities L Length H Height Width Weight

m3 mm mm mm kg

3,00 3000 1750 1450 4300

3,70 3000 1750 1650 4900

4,50 3000 1750 1850 5100

5,70 3000 2100 2000 6000

Backhoe buckets Cutting width

mm

2200

2450

2650

2900

Capacities L Length H Height Width Weight

m3 mm mm mm kg

6,50 3000 2100 2200 6700

7,50 3000 2100 2450 6800

8,50 3000 2100 2650 7000

9,50 3100 2100 2900 7200

Shovel boom with two crowd cylidners L Length mm H Height mm Width mm Weight without cylidners kg Weight of crowd cylidners kg

5540 1550 1550 9400 2 x 800

Shovel stick L Length H Height Width Weight

mm mm mm kg

4100 1250 1750 5800

Bucket tilt cylidners (two) L Length l Diameter Weight

mm mm kg

3390 285 2 x 950

Bottom dump buckets Cutting width

mm

2650

3050

3050

3050

3350

Capacity SAE L Length H Height Width Weight

m3 7,00 8,60 9,20 10,00 12,00 mm 2500 2500 2900 3200 2700 mm 2700 2700 2900 2900 2900 mm 2650 3050 3050 3050 3350 kg 10800 11400 12000 14000 11800

Dimensions and Weights 11

Basic Machine Contents

Id. No.

x Basic machine R 992 litronic` HD-undercarriage

0001053

x Double gro pads 600 mm 800 mm

9373196 9373197

Operating Weight and Ground Pressure With backhoe attachment 8,00 m with 600 mm pads: with 800 mm pads:

139000 kg – 1,95 kg/cm2 142000 kg – 1,49 kg/cm2

The operating weight includes the basic machine with backhoe attachment, 8,00 m gooseneck boom, 3,65 m stick and 8,50 m3 bucket.

With backhoe attachment 9,40 m with 600 mm pads: with 800 mm pads:

138800 kg – 1,95 kg/cm2 141800 kg – 1,49 kg/cm2

The operating weight includes the basic machine with backhoe attachment, 9,40 m, gooseneck boom, 5,15 m stick and 4,50 m3 bucket.

With shovel attachment 143200 kg – 2,00 kg/cm2 146300 kg – 1,54 kg/cm2

The operating weight includes the basic machine with shovel attachment and bottom dump bucket 10,00 m3.

LIEBHERR- S.A. 2, Avenue Joseph Rey, B.P. 287, F-68005 Colmar-Cedex, ç 03 89 21 35 10, Fax 03 89 21 37 93 www.liebherr.com, E-Mail: infoØlfr.liebherr.com With compliments:

LFR/SP 8410685-2-03.95 Printed in by Gagstatter. Illustrations and data may differ from standard equipment. Subject to change without notice.

with 600 mm pads: with 800 mm pads:
