2G & 3G New Project 2012 BTS 3900 Hardware Installation www.huawei.com

Prepared by: Yanuar Wahyudi

HUAWEI TECHNOLOGIES CO., LTD. HUAWEI TECHNOLOGIES CO., LTD.

Page 1

ANT_RXB

ANT_RXB

ANT_TX/RXA

ANT_TX/RXA

2 cm from connector

2 cm from connector

1 cm distance

1 cm distance

BTS 900Hz GSM / 2G Add one white color ring near connector for 3G Red for : sector 0 Yellow for : sector 1 Blue for : sector 2 2 ring for Main ANT_TX/RXA 1 ring for Diversity ANT_RXB

BTS 1800Hz(DCS 1) Add one white color ring near connector for DCS 2 Red for : sector 0 Yellow for : sector 1 Blue for : sector 2 4 ring for Main ANT_TX/RXA 3 ring for Diversity ANT_RXB

LABEL COLOR for JUMPER AND FEEDER CABLE HUAWEI TECHNOLOGIES CO., LTD.

Page 2

Feeder and Jumper cable Outdoor BTS

HUAWEI TECHNOLOGIES CO., LTD.

Page 3

Feeder and Jumper cable indoor BTS

HUAWEI TECHNOLOGIES CO., LTD.

Page 4

THANK YOU
