G610-U15 V100R001C527B111 Update Guide


Prepared by

Li Jiachang (ID: 00195401)

Date

2013-08-03

Reviewed by

Zhao Dejie (ID: 00145016)

Date

2013-08-03

Approved by

Zhao Dejie (ID: 00145016)

Date

2013-08-03

Huawei Technologies Co., Ltd. All rights reserved

Issue ¡Error! Nombre desconocido de propiedad de documento. (¡Error! Nombre desconocido de propiedad de documento.)

1 Huawei Confidential


SECRET

Contents 1 Basic Requirements ................................................................................................ 3 1.1 Update Environment Requirements ....................................................................................... 3 1.2 Update Package ...................................................................................................................... 3

2 Update Preparations ............................................................................................... 4 2.1 microSD Card Update ............................................................................................................ 4 2.2 USB Update ........................................................................................................................... 4

3 Update Description ................................................................................................. 5 3.1 Update Method....................................................................................................................... 5 3.2 Precautions ............................................................................................................................. 5

4 Update Procedure .................................................................................................... 6 4.1 Performing a USB Update ..................................................................................................... 6 4.2 Performing a microSD Card Update .................................................................................... 10 4.2.1 Prerequisites ................................................................................................................ 10 4.2.2 Update Procedure........................................................................................................ 10 4.2.3 Exceptions .................................................................................................................. 13 4.2.4 Log File....................................................................................................................... 14

5 Verification............................................................................................................. 15




1

SECRET

Basic Requirements

1.1 Update Environment Requirements This guide is applicable to G610-U15 mobile phones. You can update the mobile phone either using a microSD card, or by connecting the mobile phone to a computer with a USB cable and performing the update on the computer. 

For a microSD card update, prepare a readable and writable microSD card.



For a USB update, prepare a computer that runs Windows XP or Windows 7 and a USB cable.

1.2 Update Package Update Method

Update Package

USB update

HD1G610M00V100R001C527B111.RAR

microSD card update

UPDATE.APP




2

SECRET

Update Preparations

2.1 microSD Card Update Make sure the microSD card is readable and writable.

2.2 USB Update Make sure the computer runs Windows XP or Windows 7. Step 1 Decompress 服务驱动-2012-11-27.rar, double-click Handset WinDriver1.3.exe, and follow the installation wizard to install the driver for Flash_tool. Step 2 Install the mobile phone driver on the computer. 1.

Power on the mobile phone, and connect it to the computer using a USB cable. The 内置光盘 dialog box is then displayed.

2.

Click 是 to open the virtual drive.

3.

Open My Computer (on a computer running Windows XP) or Computer (on a computer running Windows 7). You will then see CD 驱动器(G):HiSuite. Double-click it to find Setup.exe.

4.

Double-click Setup.exe and follow the setup wizard to install HiSuite. If HiSuite is already installed on the computer, double-clicking Setup.exe will uninstall it before the installation The USB driver is installed along with the installation of HiSuite.

----End




3

SECRET

Update Description

3.1 Update Method USB update or microSD card update

3.2 Precautions 

Before the update, make sure the mobile phone has enough battery power.



data will be erased during the update. Back up important data before the update.




4

SECRET

Update Procedure

4.1 Performing a USB Update Use SP_Flash_Tool_v3.1316.0.148_DLInfoV1-cust.rar to the update package. Make sure the Flash_tool version is v3.1316.0.148, because using an earlier version may result in failures.

Step 1 Decompress SP_Flash_Tool_v3.1316.0.148_DLInfoV1-cust.rar, open it, and double-click Flash_tool.exe. Figure 4-1 Opening Flash_tool

Step 2 On Options, make sure USB MODE is selected, and click .




SECRET

Figure 4-2 Clicking

Step 3 If the update package is a compressed file, decompress it first. Then click Scatter-loading. Figure 4-3 Clicking Scatter-loading

Step 4 Select the MT6589_Android_scatter_emmc.txt file in the update package, and click Open.




SECRET

Figure 4-4 Clicking Open

Step 5 If the mobile phone is connected to the computer using a USB cable, disconnect the USB cable. Click Firmware -> Upgrade. Figure 4-5 Clicking Firmware ->Update

The screen shown in Figure 4-6 is then displayed.




SECRET

Figure 4-6 After clicking Firmware ->Update

Step 6 Install the battery to the mobile phone, keep it off, and connect it to a computer using a USB cable. The tool then starts the . The progress is displayed, as shown in Figure 4-7. Figure 4-7 progress

If the succeeded, the screen shown in Figure 4-8 is displayed. If an error message is displayed during the update, repeat the update procedure from Step 1.




SECRET

Figure 4-8 Update succeeded

----End

4.2 Performing a microSD Card Update 4.2.1 Prerequisites 

Make sure the current software version is G610-U15 V100R001C527B111.



Format the microSD card using FAT32.



Create a dload folder in the microSD card's root directory, copy the update package UPDATE.APP to the dload folder, and insert the microSD card into the mobile phone.

4.2.2 Update Procedure 

Forcible Update

Remove the mobile phone's battery and install it back. Then press and hold the volume up, volume down, and power buttons to power on the mobile phone. When the mobile phone vibrates, release the power button. Do not release the volume up and down buttons until the screen shown in Figure 4-10 is displayed. 

Update in Engineering Mode

Step 1 Power on the mobile phone as usual, enter *#*#1673495#*#* on the dialer to access engineering mode.




SECRET

Figure 4-9 Engineering mode

Step 2 Choose SD card upgrade. The mobile phone then automatically restarts and displays the screen shown in Figure 4-10 after the logo, which means that a microSD card update is in progress. A progress bar is displayed.




SECRET

Figure 4-10 Update started

After the update succeeds, the screen shown in Figure 4-11 is displayed. The mobile phone then automatically restarts.




SECRET

Figure 4-11 Update succeeded

----End

4.2.3 Exceptions If the update fails, the screen shown in Figure 4-12 is displayed with the failure cause. If no cause is displayed, capture the update log and the R&D personnel.




SECRET

Figure 4-12 Update failed

4.2.4 Log File Apart from the update information displayed on the mobile phone screen, most information is saved in the sdload.log file, which you can find in the dload folder.



SECRET


5

Verification

Check whether the updated software version is the target one in either of the following ways. Input

Output

Query the version number in engineering mode. For the detailed operations, the R&D personnel.

G610-U15 V100R001C527B111

In normal mode, choose Settings > About Phone > Software Version.

G610-U15 V100R001C527B111
