How to Use USB BIOS Flashback - ASUS

1 of 2

http://event.asus.com/2012/mb/usb_bios_flashback_guide/

System requirements: Power supply USB storage formaƩed to FAT16 or FAT32 ASUS X79 motherboard featuring USB BIOS Flashback

Example: BIOS

and extract BIOS CAP files from the official ASUS website at www.asus.com *Check the below table to confirm your current BIOS version is either .ROM or .CAP. If your BIOS version is .ROM, to update it to the latest .CAP version, go to BIOS UƟliƟes in the secƟon of the official ASUS product site and use the BIOS Converter for .CAP first. Detailed installaƟon guides provided. Rampage IV Extreme Rampage IV P9X79 DELUXE BIOS-UƟliƟes Extreme/BATTLEFIELD 3 P9X79 PRO Model lists Rampage IV Formula P9X79 WS P9X79 Rampage IV SABERTOOTH X79 Formula/BATTLEFIELD 3 Rampage IV GENE

*If your BIOS version is 1404 or older: Go to BIOS-UƟliƟes to and install the BIOS Converter uƟlity before updaƟng the BIOS.

BIOS version 1203 .ROM BIOS BIOS version 1404 or or previous previous version version

BIOS version 1305 or previous version

.CAP BIOS

BIOS version 3003 or later version

BIOS version 2002 BIOS version 2003 or later or later version version

Rename the file as below table, and then save it to the USB storage device’s root directory. Model name P9X79 DELUXE P9X79 PRO

Rename the file P9X79D.CAP P9X79PRO.CAP

P9X79 SABERTOOTH X79

P9X79.CAP SABERX79.CAP

Rampage IV Extreme Rampage IV Formula Rampage IV GENE

R4E.CAP R4F.CAP R4G.CAP

P9X79WS

P9X79WS.CAP

Connect to a power supply

If you are sƟll using .ROM BIOS versions, check the ASUS website for the .ROM to .CAP BIOS Converter, which comes with a detailed guide.

1/12/2014 10:09 PM

How to Use USB BIOS Flashback - ASUS

2 of 2

http://event.asus.com/2012/mb/usb_bios_flashback_guide/

press the USB BIOS Flashback buƩon/ROG Connect buƩon for three seconds Ɵll the LED begins to blink, then release.

Wait Ɵll the LED stops blinking, indicaƟng that BIOS flashing has been completed

Check this video guide

Note: 1. Do not unplug the portable storage device, power the system down, or press the CLR_CMOS buƩon while BIOS updaƟng is ongoing, or the update will be interrupted. In case of interrupƟon, follow the recommended procedures again to complete the BIOS update. 2. If the light flashes for five seconds and turns stable, USB BIOS Flashback is not operaƟng properly. This may be caused by improper installaƟon of the portable storage device, an error in the file name, or incompaƟbility in file formats. If this is the case, restart the system unƟl the light clears, and check the file name and format. 3. BIOS updates may affect a PC in various ways. Should any issues with the BIOS arise as a result or your system is unable to boot, please your local ASUS center for further assistance.
