How To Configure Sametime Business Cards And Photo Read From Connections Profiles. 3u4d4e

How to configure sametime business cards and Photo read from connections profiles? Abstract：Sametime server use domino as ldap server. How to configure sametime business cards and Photo read from connections profiles.

There are 7 steps to perform the configration: 1. Modify domino ldap server configuration. To enable anonymous s can query fileds. 2. Enable the business cards feature on the IBM® Sametime® Community Server. 3. Disable InfoConfig.xml to be read from the IBM Sametime System Console. 4. Configuring business cards using IBM Connections 5. Configuring Sametime to enable business card photos to display on mobile devices 6. Start Sametime Client to test. You can find some photo in list. 7. Troubleshooting 1. Modify domino ldap server configuration. To enable anonymous s can query fileds. 1) 2) 3)

Open names.nsf in domino ldap server, pilot to Configuration-->Servers->Configurations Open "All Servers" document --> Ldap tab : Use Domino to enable Domino LDAP directory write access. Within default Configuration Setting Document LDAP, click Yes to Allow LDAP s write access.

4)

Add to the "Anonymous s can query" fields:

5)

Then follow the screen shots below to add (Title ,Company,Telephone,Photo URL from left to right and click Ok).

6) 7)

8)

Edit the persons document by opening "names.nsf" under - People - Pick the (s) name and click on their document. The document will open and look like below screen shot and please fill in the field with the exact location of the photo folder we have created earlier. Note: Pls input Photo URL as connections photo url address. For example: http://connections.test.com/profiles/photo.do?uid=zhangsan

Important Note: the size of jpeg must be smaller than 64 Kbits, Pls refer the connections Photo URL, if you access the url, it will display her photo. http://connections.test.com/profiles/[email protected]

9) Restart the Domino server. Note: one Domino server need configuration only once. The fields we need fill for s: For Information with Domino directory: Field Name Name MailAddress Title Location(postalAddress) Company Telephone Photo URL

Fields need input values in NAB Basics Tab- First name,Middle name,Last name Basics Tab- Internet address Work/Home Tab- Title Work/Home Tab- Location Work/Home Tab- Company Work/Home Tab- Office phone Miscellaneous- Photo URL

2. Enable the business cards feature on the IBM® Sametime® Community Server. 1) 2) 3)

to the Sametime System Console. Click Sametime Servers > Sametime Community Server. In the Sametime Community Servers list, click the deployment name of the server with the business card information that you want to add or change.

4)

Click the Business Card tab.  In the Business Card Contents section, select the attribute you want displayed in s' business cards, and then click Add to include the selected attribute. 

5)

To remove any preselected attribute, click the attribute and then click Remove.  For Attribute Definition, choose Attribute Values that are appropriate for your deployment. If you prefer to map another attribute value to the attribute name instead of the default value, choose Defined, and then enter a value for the attribute. The following table lists the default attribute value that is mapped to each attribute name. Attribute names and values Attribute Name

Attribute Value

Address

Location

Company

CompanyName

Email address

InternetAddress

Name

FirstName, MiddleInitial, LastName


Photo Url

Attribute names and values Attribute Name

Attribute Value

Telephone

OfficePhoneNumber

Title

JobTitle

Click OK.

3. Disable InfoConfig.xml to be read from the IBM Sametime System Console. 1)

Open the InfoConfig.xml file in a text editor to that names and values match the attributes defined in the Sametime System Console. The file is located in the Domino program directory (\\domino\InfoConfig.xml). Here is a section of the InfoConfig file:

2)

To force STInfo to use the configuration information stored in InfoConfig.xml, add a tag with a false value.

3)

Please add

as shown below.

This setting, when set to false, will force the STInfo SA to use the configuration information stored in InfoConfig.xml 4)

In the same InfoConfig.xml file we must add the 2 fields below. Note: Make sure the lines are not already present.

5)

While editing the InfoConfig.xml, you must also add the values to the end of the "ParamsSets" field below. <ParamsSets> <Set SetId="1" params="MailAddress,Name,Title,Cellphone,Telephone,PhotoURL,ImagePath"/> <Set SetId="1" params="MailAddress,Name,Title,Cellphone,Telephone,PhotoURL,ImagePath"/>

6)

Now you can edit your Domino LDAP Configuration. Please be aware that other LDAP directories configuration may slightly be different.

7) Save InfConfig.xml file and restart Sametime Server. 8) Save all documents that are open and restart your Domino LDAP. 9) pls test below url and right information. http://im.test.com/servlet/InfoServlet? operation=3&setid=1&Id=CN=ldap,O=Test

4. Configuring business cards using IBM Connections 1) 2) 3)

to the Sametime System Console with privileges. Example: https://yourserver.com:8701/ibm/console Click .Sametime System Console > Sametime Proxy Servers. Click the Sametime Proxy Server's link to open its Configuration page.

4) 5)

6)

In the "General Properties" section, navigate to the "Business card server" section. Click Connections Server and enter the server's address. The address for a Connections Profile server typically looks like this: http://connections_server.example.com/profiles

5. Configuring Sametime to enable business card photos to display on mobile devices 1) 2) 3) 4) 5)

6) 7)

Browse to the IBM WebSphere® Integrated Solutions Console on the server hosting the IBM Sametime System Console. to the Integrated Solutions Console as the WebSphere . Click Sametime System Console > Sametime Servers > Sametime Proxy Servers. From the list of Sametime Proxy Servers, select the server you are configuring. In the Mobile device settings section, select the Enable photo cacheoption.

Click OK. Restart the Sametime Proxy Server.

6. Start Sametime Client to test. You can find some photo in list.

Start Web Sametime Client, you will find your photo.

7. Troubleshooting Please enable this logging level in the client. The instructions for enabling debug vary by client operating system. To enable the appropriate debug, select the correct operating system version, and then use these steps: 1. Stop the Notes client. 2. Edit the rinstall.properties file in a text editor. The file location can vary based on where the client was installed. Here is the default install location.

Windows OS \Data\workspace\.config\rinstall.properties Linux OS \Data\workspace\.config\rinstall.properties MAC OS /s/name/Library/Application /Lotus Notes Data/Expeditor/Applications/.config/rinstall.properties add the following lines:- and save the text file. com.ibm.rtc.meetings.messages.util.level=FINEST com.ibm.rtc.meetings.participants.ParticipantImageManager.level=FINEST 4. Start the Notes client, to Sametime, and reproduce the issue for "broken image" - Capture a screen shot when the issue occurs if possible. - Note the date and time that you reproduced the issue, and any names involved. - Note the exact steps that were performed. - Log out of the Notes client. 5. Then gather the logs. - Compress (zip up) the files in the directory named \Data\workspace\logs. - Make notes of any specific errors and the times that the unexpected behaviour occurred. - It is also important to note that if this issue occurs for specific s please provide the names being tested. Windows OS \Data\workspace\logs Linux OS \Data\workspace\logs MAC OS /s/name/Library/Application /Lotus Notes Data/Expeditor/Application Logs
