HYUNDAI GETZ

CONTENTS

BUMPER BAR REMOVAL – FRONT

1

BUMPER BAR REMOVAL – REAR

3

BODY COMPONENTS

4

Page 1

HYUNDAI GETZ

BUMPER BAR REMOVAL – FRONT

1.Loosen the 2 mounting bolts in the front bumper grille inside.

4. Loosen the screws (right: 1EA, left: 1EA) in the inside of the front bumper cover side

2. Loosen e front bumper grille mounting bolts (2EA).

3. Loosen the screws (right: 3EA, left: 3EA) in the wheelhouse inside.

5. Loosen the front bumper lower mounting screw.

6. Disconnect the fog lamp connectors and remove the front bumper cover

Page 2

HYUNDAI GETZ

FRONT BUMPER RAIL

1.Loosen the front bumper rail side mounting bolts. (Right: 5EA Left: 5EA)

2. After loosening the front bumper rail center mounting bolts (3EA), remove the front bumper rail.

FOG LAMP

1.Disconnect the (-) battery terminal. Remove the front wheel guard.

2. Loosen the 4 fog lamp mounting screws, disconnect the connector, and remove the fog lamp.

Page 3

HYUNDAI GETZ

BUMPER BAR REMOVAL – REAR

1. Loosen the rear bumper cover upper mounting screws (4EA).

4.After removing the bumper cover and the rail mounting screws (6EA), detach the bumper cover and rail.

2. Remove the 2 mounting screws in the rear wheelhouse inside.

3. After loosening the rail mounting bolts (2EA) in the rear bumper cover inside, remove the rear bumper assembly.

Page 4

BODY COMPONENTS

HYUNDAI GETZ

Page 5

HYUNDAI GETZ

1

Plastic carrier

54

2

Radiator upper center

55

Fender apron upper member Apron upper reinforcement

3

Radiator center

56

Hood inner

4

Radiator center reinforcement

57

Hood outer

5

Dash

58

Cowl inner lower

6

Brake booster reinforcement

59

Cowl side outer

7

Dash lower center reinforcement

60

Cowl top outer

8

Center floor

61

Cowl side upper outer member

9

Rear floor extension

62

Cowl inner rear

10

Front seat mounting rear side bracket

63

Fender

11

Rear floor front cross member

64

Front door upper mounting bracket

12

Rear floor

65

Front pillar outer bracket

13

Towing hook bracket

66

Front door lower mounting reinforcement

14

Rear seat rear bracket

67

Side outer

15

Rear floor center cross member

68

Side outer reinforcement

16

Tail gate striker reinforcement

69

Center pillar outer upper reinforcement

17

Rear transverse member

70

Center pillar outer lower reinforcement

18

Back

71

Rear door lower mounting bracket

19

Tail gate wiper motor reinforcement

72

Front pillar inner upper reinforcement

20

Lifter tail gate side reinforcement

73

Front side belt upper mounting bracket

21

Tail gate inner

74

Assist hold mounting bracket

22

Tail gate outer

75

Roof side inner rail

23

Rear door reinforcement beam

76

Fuel filler housing

24

Rear door belt outer rail

77

Quarter outer rear lower extension

25

Rear door frame rear reinforcement

78

Quarter outer rear upper extension

26

Rear door window channel

79

Rear combination lamp housing

27

Rear door inner

80

Tail gate lifter bracket

28

Rear door outer

81

Roof rear upper rail

29

Rear floor side member extension

82

Roof rear lower rail

30

Rear floor side member reinforcement

83

Roof rear center rail

31

Rear floor side member

84

Roof center side rail

32

Trailing arm mounting reinforcement

85

Roof center rail

33

Rear floor side front member

86

Side roof rear lower reinforcement

34

Parking brake cable mounting reinforcement

87

Side roof reinforcement ring

35

Parking brake aperture

88

Roof center front rail

36

Front seat mounting rear inner bracket

89

Roof front rail

37

Front seat cross member

90

Roof

38

Center floor front reinforcement

91

Quarter inner

39

Center floor side member

92

Quarter inner upper reinforcement

40

Side sill inner

93

Quarter inner rear lower extension

41

Side inner

94

Quarter pillar inner reinforcement

42

Front side rear member

95

Rear spring house cover

43

Front side rear lower reinforcement

96

Wheel house inner front extension

44

Front side rear lower member

97

Wheel house inner

45

Front side member rear lower extension

98

Front door outer

46

Front side outer member

99

Front door inner

47

Transmission mounting bracket

100 Front door quadrant reinforcement

48

Front side inner member

101 Front door hinge lower bracket

49

Battery tray leg reinforcement

102 Front door window upper channel

50

Fender apron inner front

103 Front door frame rear reinforcement

51

Fender apron inner

104 Front door belt outer rail

52

Cowl under cover extension

105 Front door belt inner rail

53

Front shock absorber cover

106 Front door reinforcement beam

Note – Not all items are available separately.

High Str



Zinc Gal



High Str

Zinc Gal

BODY COMPONENTS
