Products Pressure Gauges

Pressure Gauges -----------------------------

Thermometers

1.NON-FERROUS PRESSURE GAUGE:

Testing Equipments

PARTICULARS

Accessories

SPECIFICATIONS

178

H.GURU

Make

Bourdon

Type

NFPG

Code

Refer below

Model Accuracy Dial Size Bourdon Material Movement Material Socket Material Connection Case & Bezel

± 1% of FSD Refer below Non Ferrous Non Ferrous Non Ferrous 3/8” BSP(M) (Standard) Cast Aluminum, Weatherproof, Painted Stove Enameled Black with Screwed Inner Bezel of ABS Plastic.

Glass

Plain

Mounting

Refer below

Over Range Protection

125%

Standard Fitments

Micro Adjustable Pointer & Blow Out Disc.

2.LOW RANGE PRESSURE GAUGE: PARTICULARS

Make Type Code Model Accuracy Dial Size Sensing Element Movement Material

SPECIFICATIONS

H.GURU Bourdon LRPG Refer below ± 1.5% of FSD Refer below SS 316 Diaphragm Non Ferrous

4/19/2018, 7:16 PM

non ferrouse pressure gauge, temprature gauge company, low range pres...

2 of 3

Bottom Chamber Material Connection Case & Bezel

http://www.hguruindustries.com/pages/product.html

SS 304 1/2” BSP(M) (Standard) Aluminum, Weatherproof, Painted Stove Enameled Black with Screwed Inner Bezel of ABS Plastic.

Glass

Plain

Mounting

Direct Bottom Entry

3.STAINLESS STEEL PRESSURE GAUGE: PARTICULARS

SPECIFICATIONS

H.GURU

Make

Bourdon

Type

SSPG

Code

Refer below

Model Accuracy Dial Size Bourdon Material Movement Material Socket Material Connection Case & Bezel

± 1% of FSD Refer below SS 316 SS 304 SS 304/316 1/2” NPT (M) (Standard) Cast Aluminum, Weatherproof, Painted Stove Enameled Black with Screwed Inner Bezel of ABS Plastic.

Glass

Plain

Temperature Limitation ( for

270ºC

178

sensing element system) Over Range Protection

125ºC

Standard Fitments

Micro Adjustable Pointer & Blow Out Disc

4.DIAPHRAGM PRESSURE GAUGE: PARTICULARS

SPECIFICATIONS

Make

H.GURU

Type

Bourdon

Code

DPG

Model

Refer below

Accuracy

± 1.5% of FSD

Dial Size

Refer below

Sensing Element

Steel Diaphragm with Teflon foil protection Non Ferrous

Movement Material

SS 304

Bottom Chamber Material

1/2” BSP(M) (Standard)

Connection

Aluminum, Weatherproof, Painted Stove

Case & Bezel

Enameled Black with Screwed Inner Bezel of ABS Plastic. Plain

Glass Mounting

Direct Bottom Entry

5.RECEIVER PRESSURE GAUGE: PARTICULARS

SPECIFICATIONS

4/19/2018, 7:16 PM

non ferrouse pressure gauge, temprature gauge company, low range pres...

3 of 3

http://www.hguruindustries.com/pages/product.html

Make

H.GURU

Type

Bourdon

Code

RPG

Model

Refer below

Accuracy

± 1% of FSD

Dial Size

Refer below

Bourdon Material

Refer below

Movement Material

Refer below

Socket Material

Refer below

Connection

1/4” NPT (M) (Standard)

Case & Bezel

Die Cast Aluminum, Weatherproof, Painted Stove Enameled Black with Screwed Inner Bezel of ABS Plastic. Plain

Glass

0.2 to 1 Kg/Cm2 (3 to 15 PSI)

Input Signal

0 to 100% Linear or

Range

o to 10Sq. Rt. Scale W2=Direct Bottom Entry W5= Mounting with Back Entry

Mounting Over Range Protection

125%

Standard Fitments

Micro Adjustable Pointer & Blow Out Disc.
