ASSEMBLY AND PARTS ALBUM KGE3500Ti

Castor Assembly (Spare Part)

Control Assembly

Manual Starting Reel Assembly

Qty.

No.

Qty.

No.

Qty.

No.

1

KGE3500Ti-01100

Gasoline Engine

1

25

KG160-07005

Carburetor Gasket

1

49

KGE3500Ti-08401

Front Case

1

73

KGE3500Ti-08304

Lock Washer

1

2

KG205GTi-15000

Starter Motor Assembly

1

26

KG200GTi-11000

Governor & Controller System

1

50

KGE3500Ti-13100

Control

1

74

KGE3500Ti-08303

Lock Knob

1

3

KGE3500Xi-02002

Stator Locating Pin

2

27

KG200GTi-02019

Carburetor Washer B

1

51

JK425

Starting Key Unit

1

75

KGE3500Ti-08300

Entrance

1

4

KD30-02100

Stator Assembly

1

28

KG200GTi-10000

Carburetor Assembly

1

52

KMDK-01

Three -in -one Ignition System

1

76

KGE5000T-05017

Fuel Tank Seat

1

5

KD30-02200

Rotor Assembly

1

29

KG160-02018

Carburetor Washer A

1

53

WZ-Z2

DC Receptacle

1

77

KGE3500Ti-08100

Side Parts of Engine Cover

1

6

KGE3500Ti-05000

Fan

1

30

KG200GTi-02017

Carburetor Insulator

1

54

RF-1003-BB2

Cymbiform Switch

1

78

KGE3500Ti-11010

Fuel Tank Cover Assembly

1

7

KG160-05004

Flywheel Nut

1

31

KG160-02013

Inlet Pipe Washer

1

55

10A/16A 250V

E-Type Receptacle

2

79

KGE3500Ti-08106

Viewport Setting Sheath

1

8

KDE3500Ti-03010

Wheel Mounting Plate Weldment

1

32

24BYJ2

Stepping Electric Machine

1

56

KGE3500Ti-13150

Grounding Terminal

1

80

KGE3500Ti-11300

Oil Indicator

1

9

KG160-05005a

Starter Wheel

1

33

KGE3500Xi-05401

Stepping Engine

1

57

KGE3500Ti-11005

Fuel Tank Switch

1

81

KGE3500Ti-08108

Fuel Tank Cushion

1

10

KGE3500Ti-04001

Engine Air Cover

1

34

KGE3500Ti-13300

High-pressure Ignition Assembly

1

58

KGE3500Ti-14100

Smart Throttle

1

82

KGE3500Ti-18001

Truckle

4

11

KGE3500Ti-01200

Manual Starter Assembly

1

35

KGE3000Ti-13601

Triggle

1

59

8KM.214.002

Bushing

3

83

KGE3500Ti-18003

Wheel Axle

2

12

KG160-12011

Starter Handle

1

36

KGE3500Ti-13320

Iginite Wiring Weldment

1

60

KGE3500Ti-13500

Module Assembly

1

84

GB/T-91-86

Cotter Pin

4

13

KG160-12009

Starter Rope

1

37

KGE3500Ti-01012

Cylinder Bottom Cover

1

61

8KM.213.002

Cushion

3

85

KGE3500Ti-18002

Plate (Left)

2

14

KG160-12101

Starter Outer Case

1

38

KGE3500Ti-10302

Washer A

1

62

KGE3500Ti-08700

Bracket Unit

1

86

KGE3500Ti-18004

Plate (Right)

2

15

KG160-12003

Recoil Starter Spring

1

39

KGE3500Ti-10301

Muffler Syphon

1

63

KGE3500Ti-03002

Underpan Washer

2

87

GB/T5782-86

Bolt

4

16

KG160-12002a

Starter reel

1

40

KGE3500Ti-10100

Muffler Body Assembly

1

64

KGE3500Ti-12300

Washer

4

88

GB/T5789-1986

Bolt M6 12

12

17

KG240-12007

Ratchet Spring

2

41

KGE3500Ti-10303

Washer B

1

65

KGE3500Ti-03000

Underpan Assembly

1

89

GB/T5789-1986

Bolt M6 20

3

18

KG240-12008

Ratchet

2

42

KGE3500Ti-10200

Muffler Cover Assembly

1

66

KGE3500Ti-12100

Cushion

2

90

GB/T845-85

Self-tapping Screw ST-4.2

6

19

KG240-12004

Friction Spring Baffler

1

43

KGE3500Ti-17004

Accumulator 10Ah

1

67

KGE3500Ti-12200

Cushion

2

91

GB6177-86

Nut M6

8

20

KG240-12005

Ratchet Baffler

1

44

KGE3500Ti-17002

Accumulator Locating Short Bolt

1

68

KGE3500Ti-08600

Exhaust Fence Assembly

1

92

GB/T5789-1986

Bolt

3

21

KG240-12006

Locating Bolt

1

45

KGE3500Ti-17001

Accumulator Pressure Plate

1

69

KGE3500Ti-08501

Rear Case

1

93

GB70-85

Hexagonal Internal Bolt M8 12

4

22

KG205GTi-07002

Air Cleaner Cover

1

46

KGE3500Ti-17003

Accumulator Locating Long Bolt

1

70

KGE3500Ti-11001

Fuel Tank

1

94

GB5788-86

Bolt M6 12

20

23

KG200GTi-07100

Element Unit

1

47

KGE3500Ti-08200

Handle Assembly

2

71

KGE3500Ti-08305

Lock Locating Plate

1

95

KGE3500Ti-04002

Mounting Plate

1

24

KG205GTi-07001

Air Cleaner Bottom Case

1

48

KGE3500Ti-08204

Handle Rubber Sheath

4

72

KGE3500Ti-08306

Lock

1

96

KGE3500Ti-13510

Module Connecting Plate

1

No.

Description

Code.

Description

Code.
