Dilli Haat Janakpuri 2g1c3o

Site Name: Dilli Haat, Janakpuri

IAD Section A

Group : Aanchal Agarwal Aakshita Jain Anushree Kumar Bhavna Lahoti Chhaya Sharma

Source: Author

HISTORY : DELHI HAAT 1. Delhi Haat , INA

Source: Author

3 Delhi Haath ,Janakpuri . Delhi Haat was built in Janakpuri to create another nucleus around which cultural life in west Delhi could thrive

This new Delhi haat is based on the music theme Source : /DHP%20Presentation%pdf

2. Delhi Haat, pitampura

Source: https://ww w.google.

Breaking free of the convention look and feel of its other two counterparts with their brick vocabulary, Dilli Haat, Janakpuri takes a fresh look at the material palette .

Source : /DHJP%20Presentation%2027.06.201

The only material that is extensively used in this Delhi Haat is bamboo. Also , tensile canopies are the new to the design . Source : /DHP%20Presentation%.pdf

Source: Author

LOCATION MAP

Janakpuri

SOURCE : google

Delhi Haat

TRANSPORTATION LINK

Nearest Metro Station: Tilak Nagar

Nearest Bus Stand : Harinagar

Source: Author

Source : Google Earth

SITE MAP

E

Amphitheatre

W

Craft Shops

Central Plaza Expositio n Hall

3

4 Sunpath Entrance (2)Food Court

Café / Toilet

Circulation Parking

1 Source: Author

2

Entrance (1)

1,2,3,4 Basket Tower

Site Plan

Source: Author for all the images

ENTRANCE The another interesting element is the puncture in the roof ,which allows the natural light to enter .

Entrance 2 was closed ,which leads to the craft shops area.

Ticket Counter

ANALYSIS Positive: The placement of the baskets were overwhelming.

Negative: Low Heighted entrance appeared comparatively compact and dull.

Bamboo

The pathway was not Lively, it was more of an Un-Active zone.

Section Source: Author for all the images

CENTRAL PLAZA 1

1 1

2

2

2

The central zone gives a rhythmic flow to the space as it leads to different zones of the haat.

The flooring pattern gives a essence of central zone.

These arches allow partial light to enter the exhibition hall

Source: Author for all the images

Level Up

From the upper level we can have a look at various zones in the haat, whereas if we are standing at the ground level we are enable to see on level 1

1

1 The ramp leads the way to level 1, its constructed in such a way that it’s a journey for a person who can climbs up can gradually have a look at the central courtyard.

2

2 Source: Author for all the images

FOOD COURT NO. OF STALL 28 (16.50 sqm + 11.6 sqm)

Source: Author

Front Facade

Source: Author

Wash Room

Glass is used to give the people sitting inside the feeling of being in delhi haat . the natural light aspect is missing on the end points .

Double height sitting space.

Play zone

Wash room Source : /DHJP%20Presentation%2027.06.2012.pdf

•Kitchen area behind the food stalls . •Service lane is connected to the parking area behind the food court

PARMANENT STALLS

Source :Author

Source :Author

Source :Author

These are built in the most natural stone masonry, covered with the most technologically advance tensile canopies.

Source :Author

Source :Author

The space between the two is been well utilized by putting planters.

Source :Author

PERMANENT STALLS BRICK WALL

Source :Author

Source :Author

Typical craft shops (9.62 sqm) Typically made up of rubble stone from outside and brick wall from inside to keep the aesthetics. The circular shape of these haats allows us to have a full of the haat TENSILE STRUCTURE from point and can see all the things which are displayed TENSILE STRUCTURE

Source :Author

RUBBLE MASONRYAGRA STONE

This is low maintenance space.

Source :Author

Source :Author

EXPOSITION HALL : 960 sqm

Glass and wooden frame facade. Source :Author

Source :Author

This hall works as both individual exhibition hall and can also be used as a whole.

Colourful flowering creepers that soften the scale and help temperature control further cover the steel sheeting on top.Also helps to maintain the temp.

Source : /DHJP%20Presentation%2027.06.2012.pdf

INTERIOR OF EXPOSITION HALL Source :Author

Source : /DHJP%20Presentation%2027.06.2012.pdf

Source :Author

AMPHITHEATRE

Source : /DHJP%20Pr esentation% 2027.06.20 12.pdf

From the top we can see the entire green scale of dilli haat.

Source :Author

SLATE

AGRA STONE

Source :Author

There is a underground auditorium which provides seating for over 800 people at time.

Source :Author Source :Author

Source :Author

Ramps are there for physically disable people and senior citizen

the top of the amphitheatre gives an entire view of dilli hast , janakpuri. the stage is comparatively smaller.

Source :Author

MATERIALS

Walls: slates

Flooring : Sand stone .

Source :Author

2.

Source :Author

Source :Author

Slate pavers gives the strength of concrete, with a unique texture and style. It also provides shade.

Sand stone has been used as flooring, creating different patterns which differentiates between two zones. Source :Author Source :Author

Source :Author

Dholpur (agra stone ) is used as its gives strength, durability, resistance to abrasion and environmental weathering.

PRESENT GROUPS

VISITORS

Source :Author

Source :Author

No. of people in different days of the week

Source :Author Source :Author

No. of people in Different time of the day Regular Days 35 30 25 20 15 10 5 0

Festivals 70 60 50 40 30 20 10 0

Male

Male

Female

Female

Children

Children

Platinum Zone - Food Court, Entrance. Gold Zone - Amphitheatre. Silver Zone - Central Plaza. Bronze Zone - Stalls, Basket Towers.

Different Zones Stalls Amphitheatre

Functional and Non- Functional Zones

Central Plaza Food Court

Basket Towers

Exposition Hall Source :Author

Entrance Parking

Private &Semiprivate spaces Source :Author

Semi- private Public Source :Author

-Non- Functional Zones(Exposition Hall, some stalls, Basket towers) -Functional Zones(Amphitheatre, Central Plaza, stalls, Parking)
