Calculation For Stored Energy 11306j

calculation1 Line Size Outside Dia Length of Line Volume Pressure 5 bar=50000kg/m2 Energy= PV

1 Joule= 10.197KgFCm 1KJ=1000J Stored Energy

calculation2 24" 0.6096 410 119.6033737 5

Inch Mtr Mtr m3 bar

6,000,000 KgM 600,000,000 KgCm 58840835.54 58840835.54

58,841 KJ

Line Size Outside Dia Length of Line Volume Pressure 5 bar=50000kg/m2 Energy= PV

1 Joule= 10.197KgFCm 1KJ=1000J Stored Energy

24" 0.6096 809 235.9978764 5

Inch Mtr Mtr m3 bar

11,800,000 KgM 1,180,000,000 KgCm 115720309.9

115,720 KJ

SAFE DISTANCE COMMONLY USED FOR PNEUMATIC TESTS For Stored Energy Less than 27,134KJ Minimum safe Distance= +100Ft =31Mtr For Stored Energy Greater than 27,134KJ Minimum safe Distance= +150Ft =46Mtr The maximum calculated stored energy of any vessel or piping system being pneumatically pressure tested should not be greater than 271,000 KJ . If the calculated stored energy is greater than the mentioned then the system shall be divided into smaller volumes.
