Lab 6

BCD Multiplication and Division

6 BCD Multiplication and Division

6.1 Objectives: In this lab, we will look at the 68HC12 instructions to do the rest of the arithmetic functions, like multiplication, division, and BCD addition and subtraction. When you complete this lab you will be able to: •

Write programs to do BCD addition and subtraction.

•

Write a program to do BCD-to-binary and binary-to-BCD conversion.

•

Use the 68HC12 to do multiplication and division.

6.2 Related material to read: •

Writing Programs to do Arithmetic: Section 2.5 in the text, pages 37 – 50.

•

Instruction Reference: Appendix A in the text, pages 635 – 653.

6.3 BCD numbers: Humans do arithmetic calculations with decimal numbers because our number system is base ten. Because microprocessors use a binary number system, special techniques are needed to add or subtract decimal numbers. Each of the decimal digits can be coded in binary using four bits. This representation is called binary coded decimal or BCD. The BCD code is shown in Figure 6.1. Thus the decimal numbers 26 and 27 would be stored as 0010 0110 and 0010 0111 in BCD. Many data input or output devices represent numbers as decimal digits and encode them as BCD. For this reason, it is useful to do addition and subtraction in BCD, but special techniques are required.

-1-

Lab 6

BCD Multiplication and Division Decimal Number 0

Binary Coded Decimal (BCD) 0000

1 2 3 4

0001 0010 0011 0100

5 6 7 8

0101 0110 0111 1000

9

1001

Figure 6.1: Binary Coded Decimal equivalent of the decimal number. 6.3.1

BCD Addition:

The addition of two decimal numbers 26 and 27 gives the decimal number 53, but if the microprocessor added these two numbers using their binary representation, instead of getting the true answer, the result would be: 0010 0110 + 0010 0111 0100 1101 = 4D hex = 77 decimal You can correct this by using the decimal adjust accumulator or DAA instruction. After a two-digit BCD addition is done, the DAA instruction looks at the result in accumulator A, the carry bit, and the H or half carry bit of the condition code . The H bit is set if the addition caused a carry from the least significant half-byte to the most significant half-byte, in other words, from bit-3 to bit-4 in binary. If the least significant half-byte in the accumulator is greater than nine, or if the H bit is set, six is added to the result. Next, six is added to the most significant half-byte if it is greater than nine, or if the C flag is set. In this example, because the least significant half-byte is greater than nine, 6 is added to 4D, giving the correct result in BCD of 53. 0100 1101 + 0000 0110 0101 0011 = 53 decimal (correct answer) The flow chart in Figure 6.2 shows how to implement BCD multi-byte addition.

-2-

Lab 6

BCD Multiplication and Division

Start

Get LS bytes

Add them

Decimal Accumulator Adjust

Get MS bytes

Add them

Decimal Accumulator Adjust

End Figure 6.2: Two-byte BCD addition.

6.3.2

BCD Subtraction:

The DAA instruction does not correct the result of BCD subtraction. When doing BCD subtraction, the ten's complement of the subtrahend (the number being subtracted) must be added to the minuend (the number from which the subtrahend is subtracted from). The

-3-

Lab 6

BCD Multiplication and Division

ten's complement is formed by subtracting the number from 99 for single-byte or 9999 for double-byte numbers. Note how this is done for the operation 8713 - 4395: Subtract 4395 from 9999: 9999 – 4395 5604 Now add 1 to form the 10’s complement: 5604 + 1 5605 Finally add the 10’s complement result to 8713: 8713 + 5605 1 4318 This is the correct answer and the carry bit being 1 indicates the result is a positive number. If the carry bit were 0, this would be a negative number. The flow chart in Figure 6.3 shows how to implement two-byte BCD subtraction. 6.3.3

Multiplication:

The MUL instruction multiplies the binary, unsigned number in accumulator A times the binary, unsigned number in accumulator B and places the result in accumulator D. Because A and B are both 8 bits and D is 16 bits, there can be no overflow. The largest product you can get is $FF x $FF = $FE01. 6.3.4

Division:

The IDIV instruction performs an unsigned integer division of two 16-bit numbers. The dividend should be stored in accumulator D and the divisor should be stored in the X before the instruction is issued. After the instruction is executed, the quotient and remainder are stored in the X and the D accumulator, respectively. IDIV expects the quotient to be 1 or greater. The FDIV instruction works in the same way as IDIV, but it expects the quotient to be less than 1.

-4-

Lab 6

BCD Multiplication and Division

Start Decimal Accumulator Adjust

Subtract LS byte of subtrahend from 99

Subtract MS byte of subtrahend from 99

Add LS byte of 10’s complement to LS byte of minuend

Add 1 to LS byte of subtrahend for 10’s complement

Decimal Accumulator Adjust

Decimal Accumulator Adjust

Add MS byte of 10’s complement with carry to MS byte of minuend

Add 00 with carry to MS byte of subtrahend to propagate carry

Decimal Accumulator Adjust

End

Figure 6.3: Two-byte BCD subtraction.

-5-

Lab 6

BCD Multiplication and Division

6.4 Conversion between BCD and binary numbers: There are no 68HC12 instructions for multiplying or dividing BCD numbers. The BCD numbers must first be converted to binary; then they can be multiplied or divided. 6.4.1

BCD to binary conversion:

To do BCD to binary conversion, start with the most significant BCD digit, multiply it by $0A and then add the next most significant digit. This can be considered as the partial conversion number. Now multiply this partial conversion number by $0A and add the next most significant digit. This procedure is repeated until the digit to be added is the least significant digit. A flow chart for this algorithm is shown in Figure 6.4. 6.4.2

Binary to BCD conversion:

To do binary to BCD conversion, the IDIV instruction can be used to do repeated division by $0A. The binary number to be converted is divided by $0A and the remainder becomes the least significant digit. The quotient of this division is then divided by $0A and this remainder becomes the next BCD digit. This is continued until the quotient is less than $0A. When the quotient is less than $0A, it becomes the most significant BCD digit. A flow chart for this algorithm is included in Figure 6.5. The BCD digits need to be packed two digits per byte. This can be done by saving them in separate memory locations and then shifting every even digit four positions to the left. Now if you OR every pair of even and odd digits, they will be combined into one byte. 6.5 More utility subroutines: We have already introduced 3 monitor utility subroutines in the previous labs, viz., INCHAR, OUTSTRG and OUT1BSP. In this lab, we introduce 1 more utility subroutine, i.e., OUT2BSP. This subroutine combines the 2 hex numbers starting at address in the index X and outputs the resultant 4 digit hex number on the screen followed by space. It returns the address of the next byte in the index X. Following code shows a sample program that uses this utility subroutine. 1 2 3 4 5 6 7 8 9 10

out2bsp equ addr equ org start lds ldd std ldx jsr swi end

$ff58 $0800 $0A00 #$0DFF #$1278 addr #addr out2bsp

The equ directive in line 1 just makes the hard to address of the subroutine, $FF58, equal to an easy to name out2bsp. Line 4 initializes the stack pointer. In line 5 and 6, $1278 is stored in two memory address locations $0800 and $0801. In line 7, the index X points to the address $0800. Line 8 calls the subroutine out2bsp that outputs 1278 (contents of $0800 and $0801) on the screen.

-6-

Lab 6

BCD Multiplication and Division

Start

Current Digit = Current MSB Partial Convert = 0

Add Current Digit to Partial Convert

Was that the Last Digit?

No Multiply Partial Convert by $0A

Current Digit = Next Digit

Figure 6.4: BCD to binary conversion.

-7-

Yes

End

Lab 6

BCD Multiplication and Division

Start

Result = Binary number Memory = 0

Is Result < 10?

Yes

No

Save Result in the Memory

Pack BCD digits in the Memory

Divide Result by $0A End Result = Quotient

Save Remainder in the Memory

Memory = Memory + 1

Figure 6.5: Binary to BCD conversion.

-8-

Lab 6

BCD Multiplication and Division

6.6 Procedure: Before you come to the lab, individually draw flowcharts and write programs for the following procedures. 1. Write a program to add two four-digit BCD numbers together. To test your program, load the two numbers into memory manually (using ‘mm’ command) and have the program read them. Display them to the terminal screen, save the result in memory, and display that result to the screen. Show the working program to TA. 2. Write a program to perform BCD subtraction on two four-digit BCD numbers. Follow the same procedure as above. 3. Write a program to multiply two unsigned two-digit BCD numbers that are stored in memory. Read the BCD numbers from memory, convert them to binary, perform the multiplication, and then convert the result back to BCD. Display the numbers and the product to the terminal screen. Show the working program to TA. (NOTE: You will use these conversion subroutines again in the future labs. Hence keep them handy.) 6.7

Questions:

1. Draw the flowchart for a subroutine that would do multiplication of two signed 8-bit numbers represented as two's complement numbers. Make the flowchart detailed enough so a program could easily be written from it. 2. Draw a flowchart for a program that multiplies two 16-bit numbers. Assume that EMUL instruction is not available and the microprocessor can multiply only two 8-bit numbers at a time. 6.8

Lab Report:

For the lab write up, include 1. Your individual flowcharts and programs that you wrote before the lab. 2. A copy of your working .asm files (DO NOT include .lst files). 3. A brief discussion of the objectives of the lab and the procedures performed in the lab. 4. Answers to any questions in the discussion, procedure, or question sections of the lab.
