AquaCiser® III Underwater Treill System March 2011 GLO Pub. No. 234-3253-02
Read this Manual and Retain for Future Reference
AquaCiser® III Disclaimer
Proprietary Notice
This manual contains general instructions for the use, operation and care of this product. The instructions are not all-inclusive. Safe and proper use of this product is solely at the discretion of the . Safety information is included as a service to the . All other safety measures taken by the should be within and under consideration of applicable regulations. It is recommended that training on the proper use of this product be provided before using this product in an actual situation.
The information disclosed in this manual is the property of Hudson Aquatic Systems, LLC, Inc., Wilmington, Ohio, USA. Hudson Aquatic Systems, LLC, Inc. reserves all patent rights, proprietary design rights, manufacturing rights, reproduction use rights, and sales use rights thereto, and to any article disclosed therein except to the extent those rights are expressly granted to others or where not applicable to vendor proprietary parts.
Retain this manual for future reference. Include it with the product in the event of transfer to new s. Additional free copies are available upon request from Customer Relations.
Limited Warranty Statement The products sold by Hudson are covered by a limited warranty, which is printed on the invoice you received when you purchased the product. Please refer to the warranty as printed on your invoice. The complete and conditions of the limited warranty, and the limitations of liability and disclaimers, are also available upon
Hudson Customer Relations
Serial Number and Ratings Plate
Customer service and product are important aspects of each Hudson product. For assistance or information, your Hudson distributor or Hudson Customer Relations.
The serial number and other technical data is supplied on the ratings plate, located on the electrical access door. Write the serial number in the space provided below.
Please have the product serial number available when calling Hudson Customer Relations, and include it in all written communications.
Serial Number _________________________
Hudson Aquatic Systems, LLC, Inc. 1190 Wohlert Street Angola, IN 46703 Telephone 1.888.206.7802 Fax (Worldwide) 1.260.665.8069 Internet www.hudsonaquatic.com E-Mail
[email protected]
AQUACISER ADDITIONAL INFORMATION ● ●
Quick Reference Sheet Service Manual
234-3280 234-3278
To request additional free documents, Hudson Customer Relations, your Hudson distributor, or www.Hudsonperformancepools.
Ratings Plate
© Copyright Hudson Aquatic Systems, LLC, Inc. All Rights Reserved. 2
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
TABLE OF CONTENTS Section Page
Section Page
Hudson Customer Relations_____________________ 2 Serial Number and Ratings Plate_________________ 2 1 - Safety Information____________________________ 4 1.1 Danger__________________________________ 4 1.2 Warning_________________________________ 4 1.3 Important________________________________ 4 1.4 Bloodborne Disease Notice__________________ 4 1.5 Recycling_______________________________ 4 1.6 Safety and Instruction Labels________________ 5 1.7 Symbol Glossary__________________________ 6 2 - Operator Skills And Training___________________ 7 2.1 Skills___________________________________ 7 2.2 Training_________________________________ 7 2.3 Glossary of _________________________ 7 3 - Patient Evaluation____________________________ 8 3.1 Require Each Patient To Be Evaluated_________ 8 Major Contraindications (Should NOT Use AquaCiser)____________________ 8 Major Indications (Potential Patient Populations)____ 8 4 - About the AquaCiser__________________________ 9 4.1 AquaCiser® Description____________________ 9 4.2 Certification______________________________ 9 4.3 General Specifications_____________________ 9 4.4 Components____________________________ 10 5 - Using the Command Console__________________ 14 5.1 Before You Begin________________________ 14 5.2 Main Screen____________________________ 14 5.3 Therapy Pool Functions Screen_____________ 16 5.4 Treill Functions Screen________________ 20 5.5 Personal Program Screens__________________ 22 5.6 Operator Assistance Screens________________ 24 5.7 Fault Indication Notices___________________ 25 5.8 Automatic Heat Start-Up__________________ 26 5.9 Maintenance Functions Screen______________ 28 Creating a Personal Program____________________ 23 Dealing With Contaminated Water_______________ 19 Leaving the Filter Enabled_____________________ 18 Protection__________________________ 29 When to Use Auto Heat Start-Up________________ 26
6 - Using the AquaCiser_________________________ 30 6.1 Before Placing the AquaCiser in Service______ 30 6.2 General Guidelines for Use_________________ 30 6.3 Daily Start-up Routine____________________ 31 6.4 Before Each Therapy Session_______________ 33 6.5 Therapy Session_________________________ 34 6.6 End of Day_____________________________ 38 Reversing Treill Direction__________________ 35 Using the Resting Seat________________________ 36 7 - Maintaining the AquaCiser____________________ 40 7.1 Maintenance Schedule____________________ 40 7.2 Inspecting the AquaCiser__________________ 41 7.2 Replacing the Chlorine Container____________ 41 7.4 Lubricate the Chlorine Dispenser____________ 41 7.5 Maintenance Sequence____________________ 42 7.6 Cleaning the Filter Cartridge_______________ 47 7.7 Adjusting the Temperature_________________ 47 Maintenance Sequence________________________ 42 8 - Water Condition_____________________________ 48 8.1 General Guidelines_______________________ 48 8.2 Test the Water Twice Daily (Minimum)_______ 48 8.3 Adjusting the Water Condition______________ 49 8.4 Using the Water-Condition Log_____________ 49 9 - Basic Troubleshooting________________________ 50 9.1 Basic Troubleshooting____________________ 50 9.2 Resetting the Heater______________________ 51 10 - Supplies___________________________________ 52 10.1 AquaCiser Supplies_______________________ 52 10.2 Related Products_________________________ 52 11 - Parts and Service___________________________ 53 11.1 U.S.A. and Canada_______________________ 53 11.2 Worldwide______________________________ 53 11.3 AquaCiser Parts List______________________ 53 Training Record_______________________________ 54 Maintenance Record____________________________ 55 Water-Condition Log________________________ 56, 57 Index______________________________________ 58, 59
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
3
Safety Information
AquaCiser® III
1 - SAFETY INFORMATION 1.1 Danger Danger notices indicate an immediate hazardous situation which, if not avoided, will result in injury or death.
DANGER Electric shock can cause death or serious injury. Install, operate, and maintain the AquaCiser only as described in this manual. 230/240 VAC Hazardous voltage inside. Follow procedure before servicing.
WARNING Improper water conditioning can cause injury and damage the AquaCiser. Maintain the water condition as directed in this manual and keep a Water-Condition Log. Improper parts and service can cause injury. Use only Hudson parts and Hudson-approved service on the AquaCiser. Modifying the AquaCiser can cause injury and damage.
lockout/tagout
Flooded electrical components can shock and cause death or serious injury. Discard the water and turn the Main Power switch OFF before opening the lint basket or filter cover.
1.3 Important Important notices emphasize important usage or maintenance information.
Important
1.2 Warning Warning notices indicate a potentially hazardous situation which, if not avoided, could result in injury or death.
WARNING Untrained operators can cause injury or be injured. Permit only trained personnel to operate the AquaCiser. Certain medical conditions can place a patient at risk. Require all patients to have a physician’s order for treatment. Improper use of the AquaCiser can cause injury. Use the AquaCiser only for the purpose described in this manual. Contaminated water can spread disease. Discard contaminated water and clean and disinfect the AquaCiser. Improper operation of the AquaCiser can cause injury. Operate the AquaCiser only as described in this manual. An unattended patient can be injured. Stay with the patient at all times. Hot water can cause injury. Water temperature may increase during AquaCiser use. Monitor the water temperature and keep the temperature below 105°F (40.5° C). Clothing, footwear and medical accessories can come loose and cause injury. Operators are responsible for determining the appropriateness of items worn in the AquaCiser. Overflowing the reservoir can cause injury due to electric shock, and can damage the AquaCiser. Never leave the AquaCiser unattended while filling the reservoir. Improper maintenance can cause injury. Maintain the AquaCiser only as described in this manual and the Service Manual provided. Improper handling or use of water-treatment chemicals can cause injury. Follow the chemical manufacturer’s directions for use.
4
1.4 Bloodborne Disease Notice In the United States of America, OSHA (Occupational Safety and Health istration) requires employers to protect workers from workplace exposure to bloodborne diseases such as HIV-1 and hepatitis. For more information, visit www.osha.gov on the Internet or write to: U.S. Department of Labor, OSHA Office of Public Affairs, Room N-3647 200 Constitution Ave., NW Washington, DC 20210 U.S.A. To reduce the risk of exposure to bloodborne diseases when using the AquaCiser, follow the disinfecting and cleaning instructions in this manual.
1.5 Recycling The battery inside the AquaCiser contains lead, which must be disposed of properly through recycling. U.S.A. In the United States of America, recycling is regulated by the Environmental Protection Agency (EPA). your state EPA for recycling information in your area. WEEE DIRECTIVE (E.U.) European Union directive 2006/66/EC Waste Electrical and Electronic Equipment (WEEE) limits the disposal of electrical and electronic equipment in landfills. The AquaCiser battery must be separated from regular municipal waste and disposed of properly according to this standard. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Safety Information
1.6 Safety and Instruction Labels Safety and instruction labels place important information from the s’ manual on the AquaCiser. Read and follow label instructions. Replace worn or damaged labels immediately. Replacement labels are available (see Parts and Service, page 53). The following labels are affixed to the AquaCiser. Door Pinch Point Label (Location: beside door handle)
Electrical Shock Warning (9) (Location: electrical components) Restart Label (Location: top of command console)
General Information Label (Location: command console)
Emergency Stop Label (Location: side of command console)
Emergency Drain Label (Location: each end of therapy pool)
Main Power Label (Location: electrical at Main Power switch)
Filter Label (Location: reservoir )
Lint Basket Label (Location: lint basket cover)
Electrical Access Label (Location: electrical access )
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Moving Parts Warning (Location: treill access )
5
Safety Information
AquaCiser® III
1.7 Symbol Glossary The symbols here are used on the AquaCiser labels and in this s’ manual. Hudson uses symbols recognized by the International Standards Organization (ISO), American National Standards Institute (ANSI) and the medical therapy industry.
General Warning of Potential Injury
General Warning Risk of Electric Shock
Door Pinch Point: Keep Hands Clear
Emergency Stop
Emergency Drain
Read the s’ Manual
Operation Requires One Trained Operator
Wear Gloves
Wear Eye Protection
Wear Dust Mask
Read the Service Manual
Wear Protective Apron
Alarm Bell: System Fault Indicated
Main Power Breaker Switch
WEEE Directive: Dispose of Battery Properly
250 lb 113 kg Belt Pinch Point: Keep Hands Clear
Power ON/ RESTART
Protective Earth (Ground)
Lockout/Tagout Before Performing Service
ON
OFF
6
Unlocked
Locked
Seat Load Limit (Dry)
Product Meets European Union Standards
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Operator Skills and Training
2 - OPERATOR SKILLS AND TRAINING 2.1 Skills Operators using the AquaCiser need: ●
a working knowledge of aquatic physical therapy procedures.
●
the ability to assist the patient.
2.2 Training Operator trainees need to: ●
be trained in aquatic physical therapy protocols.
●
be familiar with the types of patients who should or should not use the AquaCiser (see Patient Evaluation, page 8).
●
read and understand this manual.
●
be trained to use the AquaCiser.
●
practice with the AquaCiser before using it with a patient.
●
record their training information. A sample training record sheet is provided on page 54.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
WARNING Untrained operators can cause injury or be injured. Permit only trained personnel to operate the AquaCiser.
2.3 Glossary of The following are used throughout this manual: ●
Lamps/Lights - Refers to the four color-changing lamps in the therapy pool. An internal light box contains a high-intensity light aimed at a color wheel. Fiberoptic wires carry the colored light to the lamps in the therapy pool. See the Service Manual for information on the light box.
●
Therapy Pool - Refers to the treill and exercise chamber portion of the AquaCiser. The therapy pool can be filled with water up to a depth of 48". The therapy pool contains the treill, therapy and turbo jets, lights, handles, and a resting seat.
●
Drain - Refers to moving the water from one place to another. “Drain to Reservoir” refers to pumping the water from the therapy pool to the reservoir. “Drain Discard” refers to disposing of the water down the waste drain.
●
Jets - “Therapy jets” force a mixture of air and water through the therapy pool. “Turbo jets” forcefully push water (without air) through the therapy pool.
7
Patient Evaluation
AquaCiser® III
3 - PATIENT EVALUATION 3.1 Require Each Patient To Be Evaluated Require all patients to have a physician evaluate their medical condition and order treatment before permitting them to begin therapy in the AquaCiser. The patient populations listed in Major Indications chart may benefit from therapeutic exercise in the AquaCiser. Patients with certain medical, mental or physical conditions should not use the AquaCiser. A patient experiencing any of the Major Contraindications should not use the AquaCiser. Also see the Bloodborne Disease Notice on page 4.
WARNING Certain medical conditions can place a patient at risk. Require all patients to have a physician’s order for treatment.
Major Indications (Potential Patient Populations) ORTHOPEDIC ●
Lower extremity strengthening
●
Ligament injury rehabilitation
●
Lower extremity post-surgical rehabilitation
●
Acute/chronic low back pain
●
Gait analysis SPORTS MEDICINE
●
Gait analysis
●
General conditioning
●
Lower extremity sprains, strains, and rehabilitation GERIATRICS
●
General conditioning
●
Movement limitations due to arthritic pain OBESITY
●
General weakness
●
Loss of endurance
Major Contraindications (Should NOT Use AquaCiser)
8
●
High or low blood pressure
●
Light-headedness
●
Fever
●
History of heart disease (unless monitored)
●
Non-ambulatory
●
Incontinence
●
Open wounds
●
History of seizures
●
Urinary infections
●
Senility or confusion
●
Infectious disease
●
Lower-extremity sensory deficit
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
About the AquaCiser
4 - ABOUT THE AQUACISER 4.1 AquaCiser® Description
4.2 Certification
The AquaCiser III Underwater Treill System (called the AquaCiser in this manual) is a device for hydrotherapy. A patient using the AquaCiser receives a high-resistance, low-impact aerobic workout by walking or jogging on an underwater treill.
Hudson products meet the requirements of Medical Device Directive 93/42/EEC as established by the European Union.
®
AquaCiser features include: ● Reinforced gelcoat fiberglass construction ● Electronic controls ● -programmable exercise programs ● Temperature control ● Filtration ● Chlorine dispenser ● Variable-speed, reversible treill ● Viewing windows ● 12 Therapy and 2 Turbo jets ● Patient resting seat ● 4 Underwater lamps A pH/chlorine test kit, an additional filter cartridge, four gallons of chlorine, and a water-condition log are included with the AquaCiser.
WARNING Improper use of the AquaCiser can cause injury. Use the AquaCiser only for the purpose described in this manual. AQUACISER III RATINGS PLATE The ratings plate (below) affixed to the AquaCiser provides specific power consumption information. The plate affixed to your AquaCiser will have the serial number in the space indicated “S/N” and a punch-mark indicating that it operates using 50 Hz or 60 Hz electricity.
4.3 General Specifications Length Width Height
DIMENSIONS
WEIGHT
Therapy pool Midsection Reservoir Steps Total weight (without water) Total weight (with water)
102 in (259 cm) 103 in (262 cm) 65 in (165 cm)
1060 lb (481 kg) 630 lb (286 kg) 470 lb (213 kg) 70 lb (32 kg) 2230 lb (1012 kg) 5260 lb (2386 kg)
ADDITIONAL SPECIFICATIONS
Temperature setting max Treill speed range Water capacity Water depth max Fill time (pump to therapy pool)** Drain time (pump to reservoir)** Drain Discard time (waste drain)
105°F (40.5°C) 0-9.9 mph (0-15.9 kph) 365 gal (1382 L) 48 in (122 cm) 3-4 minutes 3-4 minutes approx. 20 minutes
AC MOTOR SPECIFICATIONS*
230/240 VAC, 60 Hz (or 50 Hz), 2 HP, 3 PH, 5.8 FLA
ADDITIONAL SPECIFICATIONS
Expected Service Life 10 years Maximum Continuous Noise Level <80 dB Permissible Environmental Conditions of Use: Indoor, conditioned environment 50°F (10°C) or higher * Motor specifications expressed as Volts of Alternating Current (VAC), hertz (Hz), horsepower (HP), phase electric (PH), and full load amps (FLA). Note: 60-Hz and 50-Hz versions of the AquaCiser are available to match the local power supply. ** The distance between the AquaCiser and the source of water or drain may cause the fill and drain times to vary from the average times listed above. General specifications are rounded to the nearest whole number. Metric conversions are calculated before rounding the Imperial measurements. For more information, Hudson Customer Relations (page 2). Hudson reserves the right to change specifications without notice.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
9
About the AquaCiser
AquaCiser® III
4.4 Components
CONTROLS BOX
Filter Access
Command Console
Emergency Drain Buttons
Door Lever Electrical Access Door Lint Basket Access Plumbing Access
THERAPY POOL
WATER RESERVOIR
Reservoir Access
Handrails (2 outside, 4 inside)
Chlorine Dispenser Access CENTER PLATFORM
Power Indicator Touch Screen
Handrails (4) (2 each end)
Resting Seat
Turbo Jets (2)
Restart Button
Emergency Stop (side of console)
Lamps (4) (2 each end)
Command Console Therapy Jets (12) (6 each end) Therapy Pool (Looking Forward) 10
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
About the AquaCiser
AquaCiser® III 4.4.1 Reservoir
The water reservoir (see Components, page 10) holds and filters the water that is used in the therapy pool. Pumps move the water back and forth between the reservoir, filter, and the therapy pool. The flow of water is controlled from the command console and the EMERGENCY DRAIN buttons.
4.4.2 Controls Box The controls box contains the command console and electrical cabinet. COMMAND CONSOLE
Emergency Stop Symbol
The command console (see Components, page 10 and Figure 1) is located on top of the controls box. See Using the Command Console, pages 14-29 for instructions on using, operating, and programming the AquaCiser. EMERGENCY STOP BUTTON The red EMERGENCY STOP button is located on the right side of the command console (Figure 1).
Figure 1 - Emergency Stop Button
Push EMERGENCY STOP to cut the electric power to the pump and treill. Pressing the button will activate an alarm that sounds until the RESTART button is pressed. Any water in the therapy pool will remain in the chamber.
Restart Symbol
The AquaCiser will not operate after the EMERGENCY STOP button has been pressed. To reset the system and restore power, twist the EMERGENCY STOP button clockwise to release the button lock, then press the green RESTART button on the command console (See Restart Button below). RESTART BUTTON The green RESTART button is located on the command console (Figure 2). To reset the system after the EMERGENCY STOP button has been pressed, first twist the EMERGENCY STOP button clockwise to release the button lock, then press the green RESTART button to reset the computer and allow the AquaCiser to be used.
Figure 2 - Restart Button
ELECTRICAL
Main Power/ Breaker Symbol
The white, electrical access door (see Components, page 10) allows access to the electrical (Figure 3). The Main Power breaker switch can be accessed without opening the (See Main Power Switch, below). The electrical itself has an electrical interlock feature, which requires power to the AquaCiser to be shut off before it can be opened. Only a qualified electrician should open the electrical . See the Service Manual for access instructions. MAIN POWER SWITCH The Main Power breaker switch controls electrical power to the AquaCiser. The switch is located inside the electrical but can be accessed from a plastic enclosure (Figure 3A). Turn the main power switch OFF before opening the lint basket, performing maintenance, or making repairs to the AquaCiser. Leave the main power switch ON at all other times.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 3 - Interlocked Electrical
Figure 3A - Main Power Switch (GFCI Breaker)
11
About the AquaCiser
AquaCiser® III
4.4.3 Center Platform The center platform is the area between the reservoir and therapy pool (See Components, page 10). The operator stands on the platform to operate the Command Console and monitor the therapy session. Access s for the lint basket, plumbing, and chlorine dispenser are located in the center platform. CHLORINE DISPENSER ACCESS The chlorine dispenser (Figure 4) is located inside the first access at the top of the stairs (see Components, page 10). The chlorine dispenser adds chlorine to the water to help control bacteria and algae growth, and the chlorine minimizes soap and mineral buildup. Most s should set the rocker power switch on the chlorine dispenser to ‘TIMER’ and use the control knob to adjust how quickly chlorine is added to the water (see Chlorine Dispenser Settings at right and Water Condition on pages 48 and 49). PLUMBING ACCESS The plumbing access is in the center of the platform and allows access to the heater, Jandy valves and plumbing. LINT BASKET ACCESS The lint basket access is located nearest the Controls Box and allows access to the lint basket for cleaning, and to additional plumbing.
4.4.4 Therapy Pool The therapy pool (see Components, page 10) is the chamber in which a person exercises for aquatic therapy. The therapy pool contains the entry/exit door, treill, Emergency Drain buttons, therapy and turbo jets, and lamps. THERAPY POOL DOOR LEVER The door lever (Figure 5) secures the therapy pool door. Keep the door securely fastened at all times, including when the AquaCiser is not in use. Open only for a patient to enter or exit the therapy pool. To open: Swing the lever up until it is parallel with the door. To secure: Shut the door and pull the lever down until it stops (Figure 5). If the door is not fastened securely, a sensor on the door latch indicates a fault, “Tank Door Open,” and filling or draining the therapy pool is disabled. Always the door is securely closed by pulling the lever to the completely closed position as shown in Figure 5.
Control Knob
Figure 4 Chlorine Dispenser
Rocker Switch
Chlorine Dispenser Settings Most s should set the rocker switch to “TIMER” and use the control knob to set the amount of chlorine added to the water. An AquaCiser with VERY LOW use (1-3 people per day) may need to use the “ON” setting in order to keep enough chlorine in the water. When set to “ON,” chlorine is added to the water whenever the pump or filter are in use.
Important Flooding can occur if the therapy pool door is not securely fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
LAMPS The AquaCiser has one light and a rotating color wheel. Fiber-optic lines direct the colored light to four lamps in the therapy chamber. (Two are visible in Figure 6, page 13). Use the command console to turn the lamps ON and OFF (see Components, page 10). When ON, the lights change color periodically.
Figure 5 - the Door Lever is Completely Closed
12
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Closed Position
About the AquaCiser
AquaCiser® III JETS The AquaCiser has two types of water jet: therapy and turbo (Figure 6). The jets are controlled from the command console (see Components, page 10). Only one type of jet can be used at a time. Turning one type of jet ON automatically turns the other type of jets OFF. All jets can be aimed as needed.
Therapy Jets (6 this end)
Note: The filter operates when the jets are used. Therapy Jets (12 total, 6 each end) - Therapy jets inject a mixture of water and air into the therapy pool. Six jets are installed at each end of the therapy chamber. They provide resistance and massaging pressure for the patient from multiple angles. The water level must be above the jets for the jets to be used. Sensors in the therapy pool read the water level and turn on only the jets that are below water level. For example, to use only the lowest therapy jets (2 front and 2 rear), stop filling the therapy pool when the water level covers the lowest jets. Turbo Jets (2) - The turbo jets are located at the front (command console end) of the therapy pool. They forcefully push streams of water (without air) through the therapy pool and provide strong pressure or resistance for the patient, from one direction. The water level must be above the turbo jets for use. Examples: If the patient is walking or jogging while facing the therapy chamber doors, the turbo jets provide assistance by pushing water toward the back of the patient’s legs. If the patient is facing the command console end, the turbo jets provide resistance by pushing water against the front of the legs. Follow your therapy protocols for appropriate use of the turbo jets.
Turbo Jets (2) Lamps (2 this end)
Figure 6 - Therapy Jets, Turbo Jets, Lamps Locking Clamps
RESTING SEAT 250 lb 113 kg
The clear acrylic plastic resting seat is located at the front (command console end) of the therapy pool. Lower the seat to provide a place for the patient to sit if he/she tires during the therapy session. Also use the seat to allow the patient to sit and perform stretching exercises with or without therapy jets in use. Pull the seat down to lower it for use. Push the seat up and into its locking clamps (Figure 7) to store it. The load limit of the seat when dry (not under water) is 250 pounds (113 kg).
Seat Load Limit (Dry)
Figure 7 - Resting Seat
EMERGENCY DRAIN BUTTONS An EMERGENCY DRAIN button (Figure 8) is located at each end of the therapy pool (see Components, page 10). ●
To interrupt a therapy session: Press an EMERGENCY DRAIN button to stop the treill and pump the water in the therapy pool to the reservoir.
●
If there is a power outage and a patient is in the AquaCiser: Press either EMERGENCY DRAIN button to drain discard the water from the therapy pool to the waste drain. See Drain Discard Via Emergency Drain Button, page 19.
Emergency Drain Symbol
Figure 8 - Emergency Drain Button (1 of 2) © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
13
Using the Command Console
AquaCiser® III
5 - USING THE COMMAND CONSOLE 5.1 Before You Begin
5.2 Main Screen
Follow the instructions in Before Placing the AquaCiser in Service and General Guidelines for Use, page 30 before using the command console.
Turn the Main Power switch to ON (page 11). When the computer finishes its start-up procedure, the Main Menu Screen will be displayed (Figure 9). The functions of the buttons on the main screen are explained on page 15.
The command console features a touch-sensitive screen. To access and control AquaCiser functions, press the spot on the screen where the feature is indicated.
Note: If a system fault is present, a red Alarm Bell will flash in the upper right corner of the Main Screen (Figure 9). See Fault Indication Notices, page 25.
Alarm Bell (if present) indicates a system fault (See page 25)
Figure 9 - Main Menu Screen
14
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Using the Command Console
THERAPY POOL FUNCTIONS
OPERATOR ASSISTANCE
Press to access the Therapy Pool Functions screen. Use this screen to control general AquaCiser functions such as filling and draining the therapy pool, setting the water temperature, and controlling the therapy jets, turbo jets and lamps. See pages 16-19 for details.
Press to access the Operator Assistance screens. These screens offer brief text explanations of AquaCiser functions. See pages 24-25 for details. Refer to this s’ manual or the Service Manual for complete instructions.
TREILL FUNCTIONS
AUTO HEAT START-UP
Press to access the Treill Functions screen. Use this screen to control the treill during an unprogrammed therapy session.
Press to access the Automatic Heat Start-up screens. Use these screens to program the AquaCiser to begin cycling and filtering the water before a time when the AquaCiser will be used, such as early in the morning before therapy sessions begin.
Features include setting the treill direction, starting and stopping the treill, increasing and decreasing treill speed, and monitoring the distance meter and timer. The water temperature is also displayed on this screen. See pages 20-21 for details.
Note: An operator must be present to turn the filter OFF after an automatic heat start-up begins. You can also set the date and time in this area. See pages 26-27 for details.
PERSONAL PROGRAM FUNCTIONS
MAINTENANCE FUNCTIONS
Press to access the Personal Program screens. Use these screens to create, edit, run, save or delete personal programs. Each program can contain as many as 10 individual steps allowing you to set the water jets, timer, and treill speed. See pages 22-23 for details.
Press this button to access the Maintenance Functions screens. Use these screens to troubleshoot problems, interpret fault indicators for the AquaCiser, or to select English or Metric measurements to be displayed on various screens. See pages 28-29 for details. Note: Most areas of the maintenance section are protected. See Protection, page 29.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
15
Using the Command Console
AquaCiser® III
5.3 Therapy Pool Functions Screen Use the Therapy Pool Functions Screen (Figure 10) to control general AquaCiser functions. Features include filling and draining the therapy pool, setting the desired temperature, and turning the filter, lamps, therapy jets and turbo jets ON or OFF.
Important After pressing the FILL or DRAIN TO RESERVOIR buttons, there is a normal pause of 2-5 seconds before the pump begins moving water between the reservoir and therapy pool. Be patient and allow time for the pump to begin operating.
Note The temperature can be displayed in either degrees Fahrenheit or degrees Celsius (Figure 10). To change the units displayed, see Maintenance Functions, pages 28-29.
Display in Degrees Fahrenheit or Degrees Celsius
Figure 10 - Therapy Pool Function Screen
16
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Using the Command Console
AquaCiser® III SETTING THE WATER TEMPERATURE To set the water temperature, press SETPOINT in the Water Temperature area of the screen. This will bring up a small numeric keypad screen. Enter the desired temperature on the keypad and press the enter key (an arrow pointing down and to the left).
Enter Symbol The command console software will not accept a Setpoint above 105°F (40.5° C). An alarm will sound and the AquaCiser will stop if the actual temperature exceeds 106° F (41.1° C). Changing the Setpoint does not, by itself, change the water temperature. To warm the water, use either of the following methods to move water over the heater: ●
If the water is in the reservoir, press ENABLE FILTER.
●
If the water is in the therapy pool, turn either set of jets to ON. , the jets operate only when the water level is above them. Figure 11 - Water Level Knee High
Important After pressing the FILL or DRAIN TO RESERVOIR buttons, there is a normal pause of 2-5 seconds before the pump begins moving water between the reservoir and therapy pool. Be patient and allow time for the pump to begin operating. FILLING AND DRAINING THE THERAPY POOL
Important Flooding can occur if the therapy pool door is not fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
The trained AquaCiser operator does the following: 1. Assist the patient as he/she enters the therapy pool, if needed. 2. Securely close the therapy pool door. that the door is secure before continuing. 3. Follow the physician’s and/or therapist’s order and set the appropriate water level for the patient (for examples, see Figures 11 and 12). ●
To fill the therapy pool, press the FILL button.
●
To stop filling the therapy pool, press POOL OFF when the water is at the desired level.
●
If the filling process is not stopped earlier, a sensor will shut off the pump when the water depth reaches 48" (about 122 cm) inside the therapy pool.
Before draining the therapy pool: 1. Stop the treill using the Treill Functions screen (see Treill Functions Screen, pages 20-21). 2. Press JETS OFF on the Therapy Pool Functions screen. 3. Press DRAIN TO RESERVOIR. This will pump the water into the reservoir. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 12 - Water Level Waist High 17
Using the Command Console
AquaCiser® III
USING THE JETS Use the jets to provide resistance and massaging action for the patient (Figure 13). To turn the jets ON, press JETS NORMAL to activate the therapy jets, or press JETS TURBO to activate the turbo jets. Only one type of jet can be used at a time. Selecting one type of jet will automatically deactivate the other type. Press JETS OFF to turn off all jets. Note: The water level in the therapy pool must be higher than the level of the jets in order to use the jets. USING THE LAMPS Press the LAMP ON and LAMP OFF buttons to control the four lamps in the therapy pool. While activated, the light will change color periodically (Figure 13). FILTER
Figure 13 - Therapy Jets and Lamps in Use
When the filter is ON (Enabled): ●
The water is cycled through the filter.
●
The water moves through the heater.
●
Chlorine is added to the water.
Hudson strongly recommends that you press ENABLE FILTER to filter the water whenever the water is in the reservoir. Filtering the water removes impurities, controls algae growth and keeps the water at the Setpoint temperature by warming it as needed. Note: All of the water must be in the reservoir for the filter to run. The filter cannot be enabled when there is water in the therapy pool. Enabling the filter is one way to increase the water temperature if the water is colder than the Setpoint. To warm the water, enter a Setpoint that is higher than the current water temperature and press ENABLE FILTER. The filter will run until the water reaches the Setpoint and will stop automatically. Note: The other way to warm the water is to turn ON any of the jets while the water is in the therapy pool.
Leaving the Filter Enabled It is good operating practice to allow the AquaCiser to filter and/or warm the water as needed. Do the following: 1. Move all of the water to the reservoir any time the AquaCiser will be idle, and during the End of Day sequence (page 38). 2. Press ENABLE FILTER. ●
If the water temperature is at the Setpoint, the AquaCiser will turn ON and run (“cycle”) for a minimum of 10 minutes every eight hours to filter and add chlorine to the water (see Water Condition, pages 48-49).
●
If the water temperature falls below the Setpoint before eight hours have elapsed, the filter and heater will operate to maintain the water temperature at the Setpoint.
●
The heater operates with the filter when the water temperature is 2° F (1.1° C) or more colder than the Setpoint temperature. The heater and filter will run until the water temperature equals the Setpoint and then stop automatically.
Important Move all water to the reservoir and press FILTER ENABLE whenever the AquaCiser will be idle. The filter will run 10 minutes every 8 hours to cycle the water (minimum), or it will turn on as needed to keep the water at the Setpoint temperature.
18
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Using the Command Console
DRAIN DISCARD BUTTON If the water becomes contaminated (See Dealing with Contaminated Water, this page), or if you are ready to clean the AquaCiser during the Maintenance Sequence, press the DRAIN DISCARD button (Figure 14) to send water to the waste drain.
WARNING Contaminated water can spread disease. Discard contaminated water and clean and disinfect the AquaCiser.
The most common use of the DRAIN DISCARD button is when you wish to clean the AquaCiser. See Maintenance Sequence, pages 42-46.
DISCARDING WATER If there is water in the therapy pool and the water level is higher than the first sensor above the treill, press DRAIN DISCARD once to discard only the water in the therapy pool to the waste drain. Press DRAIN DISCARD a second time to drain all water from the AquaCiser reservoir and therapy pool.
Figure 14 - Drain Discard Button
If there is no water in the therapy pool or the water level is lower than the first sensor above the treill, pressing DRAIN DISCARD once will drain all water from both the therapy pool and reservoir.
DRAIN DISCARD VIA EMERGENCY DRAIN BUTTON If the electrical power to the AquaCiser is interrupted (for example, during a power outage), press either EMERGENCY DRAIN button (Figure 15) to discard the water from the therapy pool to the waste drain. This allows a patient to exit the therapy pool when a power outage occurs. Note: If the AquaCiser has electrical power, pressing either EMERGENCY DRAIN button stops the treill and activates the pump to move the water from the therapy pool to the reservoir. The EMERGENCY DRAIN button only discards water to the waste drain when there is no electrical power to the AquaCiser.
Figure 15 - Emergency Drain Button (1 of 2)
Dealing With Contaminated Water If the patient is incontinent or if the water in the therapy pool becomes contaminated by any other means, do the following: ●
If the jets and pump are OFF and contamination is limited to the therapy pool, press DRAIN DISCARD to send the water in the therapy pool to the waste drain. Clean the therapy pool following Steps 1-3 of the Maintenance Sequence, pages 42 and 43.
●
If any jets are in use or if the pump is moving water to the reservoir when the contamination is discovered, DRAIN DISCARD all water and clean the entire AquaCiser. Follow the complete Maintenance Sequence on pages 42-46.
Note: If contaminated water in limited to the Therapy Pool, do not pump the water to the reservoir - this will contaminate additional areas of the AquaCiser.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
19
Using the Command Console
AquaCiser® III
5.4 Treill Functions Screen Use the Treill Functions Screen (Figure 16) to control the treill during an unprogrammed therapy session. Features include setting the treill direction, starting and stopping the treill, increasing and decreasing treill speed, and monitoring (or resetting) the distance meter and timer.
Note The water temperature is displayed on the Treill Functions screen but cannot be adjusted here. To adjust the water temperature, go to the Therapy Pool Functions screen. See Setting the Water Temperature, page 17. The temperature is displayed in either degrees Fahrenheit or degrees Celsius (Figure 16). To change the units displayed, see the subsection, “Units Selection” under the Maintenance Function Screen, page 29.
Display in Degrees Fahrenheit or Degrees Celsius
Display in Miles or Kilometers
Display in Miles per Hour or Kilometers per Hour
Figure 16 - Treill Functions Screen
20
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III TREILL DIRECTION The treill runs in either direction. If the patient’s mobility is limited, the reversible treill can be used to have the patient walk forward and backward during the same therapy session without requiring the patient to turn around. To set the treill direction: ● Press FORWARD to set the treill to move toward the therapy pool door. This is the appropriate direction for a patient to walk or jog while facing the Command Console end of the AquaCiser (Figure 17). ● Press REVERSE to set the treill to move toward the Command Console (Figure 17). This is the appropriate direction for a patient to walk or jog while facing the therapy pool door (Figure 18). ● If you press FORWARD or REVERSE while the treill belt is moving, the treill will slow to a stop and then begin moving in the new direction. ● The therapist controlling the AquaCiser should face the patient in the proper direction before starting the therapy session. Tell the patient when the treill is to start, and in which direction it will move. The patient can face either end of the therapy pool as desired (Figures 17 and 18). ● The two turbo jets are located at the command console-end of the AquaCiser. ○○ To have the turbo jets provide resistance for the patient, the patient should face the jets (toward the command console end of the AquaCiser, as in Figure 17). ○○ To have the turbo jets provide pressure on the back of the patient’s legs, face the patient toward the therapy pool door during the therapy session, as shown in Figure 18. USING THE TREILL AND ADJUSTING SPEED The Treill Speed area displays the speed you have set for the treill. The treill always begins at 0.1 miles per hour (or 0.1 kilometers per hour) and will ramp up to the speed that you have set. ● Press START to start the treill. ● Press the INC (increase) and DEC (decrease) buttons repeatedly to increase or decrease the treill speed. When the treill has adjusted to the new speed you have set, a yellow “AT SPEED” indicator will light. ● Press the red STOP button to stop the treill. The treill will ramp down in speed until it stops.
Using the Command Console
Treill Direction: REVERSE Treill Direction: FORWARD Figure 17 - Reversible Treill
Figure 18 - The Patient May Face in Either Direction While Using the Treill
Important Communicate with the patient at all times. Tell the patient when the treill will start or stop, when the treill speed will change, or when the jets will be activated or stopped.
DISTANCE METER AND RUN TIMER The Distance Meter displays the distance the treill has traveled. The Run Timer displays the elapsed time the treill has been running since the last reset. Use the RESET TIMER and RESET DISTANCE buttons to reset the displays to zero. WATER TEMPERATURE The current water temperature is displayed here. To set a new temperature, go to the Therapy Pool Functions screen. See Setting the Water Temperature, page 17. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
21
Using the Command Console 5.5 Personal Program Screens Use the Personal Program screens to create or begin a saved personal program. Each program can contain as many as 10 individual steps including treill speed, timer, and water jet operation. Press PERSONAL PROGRAM FUNCTIONS on the main screen to display the Personal Program Menu screen (Figure 19).
AquaCiser® III Three options are available on the Personal Program Menu screen (Figure 19): ●
Personal Program Overview. Press this button to use the Overview Functions screen (Figure 20) and see all 10 steps of a personal program at once, load a different program, or change the treill direction.
●
Personal Program Monitor. Press this button to use the Monitor screen (Figure 21, page 23) to look in detail at one step within a Personal Program or to edit that step. The large size of the display on this screen also allows the patient to view the step while exercising in the therapy pool.
●
Delete a Personal Program. Press this button to remove a Personal Program from the memory.
Figure 19 - Program Main Menu
Figure 20 - Personal Program Overview 22
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III PERSONAL PROGRAM GUIDELINES ●
PROGRAM NAMES: Names can have a maximum of 8 characters. They can include numbers, but not spaces. To save multiple programs for a patient, add a number (‘David1’, ‘David2’, etc.). Tip: You may decide to give each patient a number. Maintain records with the patient’s Personal Program name and/or number with the patient’s information.
●
CHANGES: To make permanent changes to an existing program, simply save the edited program using the same program name.
●
FEWER STEPS: To create a program with less than 10 steps, set the time for unwanted steps to zero. Steps with zero time are skipped. ○○
Using the Command Console Creating a Personal Program 1. Load an existing Personal Program. 2. Press Step 1 to open the Step #1 Setup screen (Figure 22). 3. Set the time (in increments of one minute), treill speed (in increments of 0.1 miles or kilometers per hour), and jets mode. 4. Press NEXT to go to the next step. Continue for all 10 steps. Set any unwanted steps to zero time. 5. Save the Personal Program and give it a name.
Example: To have a 3-step program, set all times to zero for Steps 4-10.
●
SKIPPING STEPS: To skip a step, set the time to zero before the program begins the step. The program will skip to the next step with a programmed time.
●
EDITING WHILE RUNNING A PROGRAM: Edit the current step by pressing the step and making changes to the time or speed. Or, press a later step to edit it before the program reaches it.
●
TREILL DIRECTION: Set the treill direction on the Overview screen (Figure 20, page 22). This direction will be in effect for all steps. To change the treill direction, press the “Treill Direction” area of the screen and then enter the number for the new direction on the numeric keypad (0 for FORWARD, 1 for REVERSE). The treill will slow to a stop and then begin moving in the new direction.
●
PAUSE, STOP or RESUME PROGRAM: Use the buttons at the left side of the screen.
●
END-OF-SEGMENT ALERT BEEPS: The AquaCiser will sound one long beep when 10 seconds remain in each program step, then sound short beeps each of the final 5 seconds.
●
PROGRAM MONITOR: If the patient would like to see the display screen, use the Personal Program Monitor (Figure 21). The large numbers on this screen are readable for most patients.
●
DELETE PROGRAM: To delete a program, press DELETE A PERSONAL PROGRAM from the Program Main Menu (Figure 19 on page 22). Select the program to be deleted from the list and confirm your selection.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 21 - Personal Program Status/Monitor
Figure 22 - Personal Program Step Setup Screen (Step #1 Shown)
23
Using the Command Console
AquaCiser® III
5.6 Operator Assistance Screens Use this set of screens for brief text explanations of AquaCiser functions. Three buttons are on the main Operator Assistance screen (Figure 23): ●
THERAPY POOL FUNCTIONS
●
TREILL FUNCTIONS
●
PERSONAL PROGRAM FUNCTIONS
Press the appropriate button for an explanation of the function of Command Console buttons or AquaCiser features in that area. Refer to this s’ manual or the Service Manual (provided) for complete, detailed explanations and procedural information. For additional manuals, Hudson Customer Relations, page 2. Also see Operator Skills and Training, page 7 for operator and operator trainee requirements. Reminder: The AquaCiser is for use with a trained operator leading a therapy patient. Operators should understand all AquaCiser features and functions and should communicate with the therapy patient so the patient Operation Requires is prepared for (and will not be One Trained Operator surprised by) treill starts or stops,
Figure 23 - Operator Assistance Main Screen
Important Communicate with the patient at all times. Tell the patient when the treill will start or stop, when the treill speed will change, or when the jets will be activated or stopped.
Figure 24 - Understand the AquaCiser and Communicate Changes in Speed, Direction, or Jet Use to the Patient 24
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III 5.7 Fault Indication Notices
Using the Command Console Fault Indicator Line
Alarm Indicator
If a fault occurs, most screens in the command console will display a line of text with a red background to alert you to the fault. A red alarm bell indicator may also be present (Figure 25). Refer to the Service Manual provided for explanations of faults and how to correct them.
Figure 25 - Fault Indicator Line
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
25
Using the Command Console
AquaCiser® III
5.8 Automatic Heat Start-Up Use the Automatic Heat Start-Up screens to program a time for the AquaCiser to automatically begin warming and filtering the water after the AquaCiser has been inert (not in use) for a long period of time. The Automatic Heat Start-Up will not be used often. However, if the AquaCiser will be idle for more than two days, you may use the Heat Start-Up Settings screen (Figure 26) to program a time for the AquaCiser to begin cycling and filtering the water.
When to Use Auto Heat Start-Up If you follow the normal End of Day procedure (pages 38 and 39), you do not need to use the Automatic Heat Start-Up feature. Use Automatic Heat Start-Up only when you want the AquaCiser to sit idle for an extended period of time (more than two full days) and then have the machine cycle and warm the water for use at a given time. To use this feature: ●
place the AquaCiser in its inert mode by pressing POOL OFF and DISABLE FILTER.
●
program a day and time for the AquaCiser to turn on and begin cycling and warming the water.
Note: You can also set the date and time from this screen.
Important Several hours may be needed to warm the water to the Setpoint after the AquaCiser has been idle.
Important An operator must be present to turn the filter OFF after an automatic heat start-up begins.
Figure 26 - Auto Heat Start-up Screen
26
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Using the Command Console
SETTING THE HEAT START-UP To set the automatic heat start-up: 1. Press the day of the week on the Heat Start-Up Settings Menu screen (Figure 26, page 26). 2. Press the hour and minute buttons and enter the time for the cycle to begin (Figure 27). Note: Enter the time using “military” or 24-hour time. For example, 1 p.m. is 13:00 using 24-hour time. 3. Press ENABLE
AUTO HEAT START-UP. To disable an automatic start-up, press the day of the week and then press DISABLE
AUTO HEAT START-UP (Figure 27). Note: When an Automatic Heat Start-Up is activated, the AquaCiser will filter and heat the water until the temperature Setpoint is reached. that the Temperature Setpoint is the desired temperature before setting an Automatic Heat Start-Up.
SETTING THE SYSTEM DATE AND TIME
Figure 27 - Setting an Auto-Heat Start-Up
Important Before setting an Automatic Heat Start-Up, that the Temperature Setpoint is the desired temperature.
To set the date and time for the AquaCiser, press the SET SYSTEM TIME AND DATE button on the Heat Start-Up Settings Menu screen (Figure 26, page 26). On the Date and Time Setup screen (Figure 28), enter the information for: ●
the year, month, and date;
●
the hour, minutes, and seconds;
●
the day of the week: Sunday is day zero, Monday is day one, etc.
When you have entered the date and time, press SET CLOCK.
Figure 28 - Setting the Date and Time
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
27
Using the Command Console
AquaCiser® III
5.9 Maintenance Functions Screen Use the Maintenance Functions screen (Figure 29) to troubleshoot Programmable Logic Control problems and to set or reset the filter hours timer. The AquaCiser display units preference (ENGLISH or METRIC) is also set on this screen. Note: Most areas of the Maintenance Functions screen are -protected. See “ Protection”, page 29.
Figure 29 - Maintenance Functions Screen
28
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Using the Command Console
AquaCiser® III PLC INPUTS - PLC OUTPUTS STATUS Press the PLC Inputs or PLC Outputs buttons to display screens that report the status of the Programmable Logic Controls. Each logic control is preceded by an indicator that will be either yellow or black, depending on the status of the control (Figure 30). Which indicators are yellow or black at a given time is dependent on if there is a fault in the system or if the lights, treill, jets, pumps, or other AquaCiser components are running. See the Service Manual provided for detailed information regarding the logic controls and their status. TEMPERATURE CALIBRATION OFFSET The Temperature Calibration Offset is a programmed setting that matches the AquaCiser’s thermocouple to a thermometer. The calibration is set by Hudson when the AquaCiser is constructed, and should not require service by the end-. Note: This feature is -protected but is unlocked when the is entered (See Protection at right). Do not change the temperature calibration setting. FILTER HOURS Total Filter Run Hours displays the total hours the AquaCiser has been used since the filter was last changed. The “Change Filter” fault indicator will be displayed when the total run hours matches or exceeds the setpoint. After changing the filter during the Maintenance Sequence, press RESET HOURS to reset the time to zero.
Figure 30 - PLC Status Screen
Protection Portions of the Maintenance Functions screen are -protected. When you press any of these areas, you will be asked for the system : To unlock this screen, type: Hudson <enter>. Pressing Main Menu to leave the Maintenance screen will re-lock the -protected areas.
Note: These features are -protected (See Protection at right). Only a trained maintenance person should edit the Filter Run Hours, Filter Run Hours Setpoint or Reset the Filter Hours. UNITS SELECTION The “Active Units” displays the type of measurements that will be displayed on all AquaCiser screens: ●
ENGLISH (Imperial): speed in miles per hour, distance in miles, temperature in degrees Fahrenheit
●
METRIC: speed in kilometers per hour, distance in kilometers, temperature in degrees Celsius
To change the type of units displayed, press the Units Selection area and enter the . Select either “Metric” or “English”.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
29
Using the AquaCiser
AquaCiser® III
6 - USING THE AQUACISER 6.1 Before Placing the AquaCiser in Service ●
● ●
● ●
A Hudson service technician will install the AquaCiser and conduct an in-service start-up. For installation information, see the Service Manual provided or Hudson Customer Relations, page 2. Personnel who will work with the AquaCiser need to read this manual. Confirm that the AquaCiser operates Read s’ properly. See Scheduled Inspection and and Service Maintenance in the Service Manual Manuals provided. Personnel who will operate the AquaCiser must be trained (See Operator Skills and Training, page 7). Practice using the AquaCiser before using it in a work situation.
6.2 General Guidelines for Use ●
Medical advice is beyond the parameters of this manual.
●
The AquaCiser is for professional use only.
●
Use the AquaCiser only as described in this manual.
●
Require patients to have a physician’s order for treatment before permitting them to begin therapy in the AquaCiser. See Patient Evaluation, page 8.
●
Follow your state and local therapy procedures and the physician’s order for treatment when operating the AquaCiser (see Patient Evaluation, page 8).
●
Stay with the patient at all times.
●
Monitor the water temperature. Hot water can cause injury to the patient.
●
It is the operator’s responsibility to ensure safe usage practices for the patient.
●
Do not allow patients using lanolin or mineral oil to enter the therapy pool as these substances can clog the filter. Use alternative products.
●
Have the patient shower, put on a clean bathing suit and appropriate protective footwear and/or medical devices.
●
The operator is responsible for determining the appropriateness of footwear and other items worn in the AquaCiser. Do not allow improper items to be worn.
●
Communicate changes in the AquaCiser’s state to the patient before they occur. Tell the patient when the treill will start or stop, when the treill speed will change, or when the jets will be activated or stopped.
●
A normal pause of 2-5 seconds occurs before the pump begins to move water between the reservoir and therapy pool. Be patient after pressing the FILL or DRAIN TO RESERVOIR buttons. Allow time for the machine to begin operating.
30
DANGER Electric shock can cause death or serious injury. Install, operate, and maintain the AquaCiser only as described in this manual.
WARNING Improper operation of the AquaCiser can cause injury. Operate the AquaCiser only as described in this manual. An unattended patient can be injured. Stay with the patient at all times. Hot water can cause injury. Water temperature may increase during AquaCiser use. Monitor the water temperature and keep the temperature below 105°F (40.5° C). Certain medical conditions can place a patient at risk. Require all patients to have a physician’s order for treatment. Clothing, footwear and medical accessories can come loose and cause injury. Operators are responsible for determining the appropriateness of items worn in the AquaCiser.
Important Communicate with the patient at all times. Tell the patient when the treill will start or stop, when the jets will be activated or when the treill speed will change.
Important Lanolin and mineral oil can clog the filter. Do not use products that contain lanolin or mineral oil on the patient or in the AquaCiser.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Using the AquaCiser
AquaCiser® III 6.3 Daily Start-up Routine Follow the Daily Start-up routine at right before beginning therapy sessions. Refer to the section, Using the Command Console, pages 14-29 for instructions on controlling the AquaCiser. 1 - CHECK THE WATER LEVEL Open the filter access or reservoir access (see Components, page 10) and check the water level in the reservoir. Use a garden hose (not supplied) to add water as needed to keep the water at the fill line shown in Figure 31. Note: Be attentive when adding water to the reservoir and do not leave the AquaCiser unattended during filling. Overflowing the reservoir can cause injury and damage. 2 - TEST THE WATER CONDITION Test the water condition two times each day: before therapy sessions begin, and after therapy sessions are finished. Treat the water (see Water Condition, pages 48 and 49) if it fails to meet any of the following levels:
Daily Start-up 1. 2. 3. 4.
Check the Water Level Test the Water Condition (2 times daily) Check Treill Operation Check the Water Temperature
WARNING Overflowing the reservoir can cause injury due to electric shock, and can damage the AquaCiser. Never leave the AquaCiser unattended while filling the reservoir.
Water Fill Line
Water Hardness 250-500 ppm Total Chlorine less than 2 ppm Free Chlorine 1-3 ppm pH 7.2-7.8 Alkalinity 80-120 ppm Use and maintain records of the water condition. Sample Water-Condition logs are provided on pages 56 and 57.
Figure 31 - Checking the Water Level
3 - CHECK TREILL OPERATION
Important
1. Make sure the therapy pool door is securely shut and fastened.
Flooding can occur if the therapy pool door is not fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
2. Begin filling the therapy pool with water. On the Therapy Pool Functions screen, press the FILL button. 3. Stop filling the chamber when the water is slightly above the lights by pressing POOL OFF. 4. On the Treill Functions screen, press START and increase the treill speed until the maximum 9.9 mph is reached. Then, decrease the speed to 0.1 mph and press STOP. Watch and listen to the moving treill belt to confirm that it is tracking properly and that the belt is running smoothly and quietly at all speeds. If service is required, remove the AquaCiser from service. Have a qualified service person follow the procedures in the Service Manual provided or Hudson Customer Relations (page 2) or your Hudson distributor. 5. On the Therapy Pool Functions screen, press DRAIN TO RESERVOIR to move the water to the reservoir. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Important The treill belt will stretch with use over time. As a result, tensioning or tracking adjustments will be needed. When adjustments are needed or when the treill does not operate properly, remove the AquaCiser from service and Hudson (page 2) or your Hudson distributor.
Important Improper repairs can damage the treill. Do not attempt treill repairs. Hudson Customer Relations (page 2) or your Hudson distributor. 31
Using the AquaCiser 4 - CHECK THE WATER TEMPERATURE If the AquaCiser has been idle, press ENABLE FILTER on the Therapy Pool Functions screen before reading the temperature display for an accurate temperature reading. If the filter is already in its enabled state due to the End of Day procedure, that the water is at the Setpoint.
AquaCiser® III WARNING Hot water can cause injury. Water temperature may increase during AquaCiser use. Monitor the water temperature and keep the temperature below 105°F (40.5° C).
Note: The water temperature is displayed (but cannot be adjusted) on the Treill Functions screen. To adjust the water temperature, see Setting the Water Temperature, page 17. Note: If needed, one quick way of lowering the water temperature is to discard some of the water and add fresh, cold water. After adding water, test the water condition and make adjustments as needed (see Water Condition, pages 48 and 49).
32
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III 6.4 Before Each Therapy Session Before each therapy session, follow the instructions in the Before Each Therapy Session routine at right.
Using the AquaCiser Before Each Therapy Session 1. Check the Water Temperature 2. Prepare the Patient for the Therapy Session
1 - CHECK THE WATER TEMPERATURE For an accurate temperature reading, press ENABLE FILTER on the Therapy Pool functions screen before reading the temperature display. See Check the Water Temperature, page 32.
2 - PREPARE THE PATIENT FOR THE THERAPY SESSION 1. Have the patient shower, put on a clean bathing suit, and if desired, protective footwear. Cleanliness is essential to keeping water in the AquaCiser clean. Clean water increases filter life, reduces the need for chemicals, and reduces maintenance. Note: The operator must determine the appropriateness of footwear and other items worn in the AquaCiser. Do not allow improper items to be worn in the AquaCiser. 2. Apply any waterproof devices (such as a heart monitor) needed for the therapy session. Before applying a device, confirm that it is approved by its manufacturer for use in water.
WARNING Hot water can cause injury. Water temperature may increase during AquaCiser use. Monitor the water temperature and keep the temperature below 105°F (40.5° C).
WARNING Certain medical conditions can place a patient at risk. Require all patients to have a physician’s order for treatment.
WARNING Clothing, footwear and medical accessories can come loose and cause injury. Operators are responsible for determining the appropriateness of items worn in the AquaCiser.
Important Lanolin and mineral oil can clog the filter. Do not use products that contain lanolin or mineral oil on the patient or in the AquaCiser.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
33
Using the AquaCiser 6.5 Therapy Session During each therapy session, follow the instructions in the Therapy Session routine at right. 1 - HELP THE PATIENT ENTER THE THERAPY POOL
AquaCiser® III Therapy Session 1. Help the Patient Enter the Therapy Pool 2. Fill the Therapy Pool 3. Begin the Therapy Session
1. Open the therapy pool door.
4. End the Therapy Session
2. Have the patient grasp the outside handrails for when entering the therapy pool. Assist the patient as needed (Figure 32).
5. Drain Therapy Pool and press ENABLE FILTER
3. Close and fasten the door securely. 4. Explain to the patient how the treill and water jets work. 5. Explain the use of the EMERGENCY DRAIN buttons, and show the patient where the buttons are located. 6. Explain how to use the handrails for and balance, and how to unfold and use the resting seat.
6. Help the Patient Exit the Therapy Pool 7. Wipe Down the Therapy Pool 8. Check the Water Level
Important Flooding can occur if the therapy pool door is not fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
2 - FILL THE THERAPY POOL 1. Go to the Therapy Pool Functions screen and press FILL to begin moving water into the therapy pool. 2. Fill the therapy pool with as much water as is appropriate for the patient for his/her therapy. Press POOL OFF to stop filling the chamber. 3. Turn the lamps in the therapy pool ON if desired. Note: A sensor will automatically stop the FILL command when the water depth inside the therapy pool reaches 48" (122 cm). The sensor compensates for patient displacement. Note: The water level must be above the jets before they may be used.
Figure 32 - Help the Patient Enter the Therapy Pool 34
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Using the AquaCiser
3 - BEGIN THE THERAPY SESSION If the patient has a pre-saved Personal Program: 1. Go to the Personal Program Functions screen and press PERSONAL PROGRAM OVERVIEW. 2. Press LOAD PROGRAM and select the program for this patient. 3. Tell the patient that the treill (and jets) will begin, and start the program. 4. Follow the guidelines in “During the Therapy Session” below. To create a new Personal Program, see Creating a Personal Program, page 23. If you will not be using a Personal Program with this patient, go to the Treill Functions screen and operate the AquaCiser manually.
DURING THE THERAPY SESSION ●
Run the treill slowly while the patient warms up and adjusts to the treill motion. Gradually increase the speed until the desired speed is reached (Figure 33).
●
To change the direction of the treill after the therapy session has started, see Reversing Treill Direction below or see Treill Direction on page 21.
●
Watch the patient closely and do not leave the patient unattended (Figure 34). If the patient tires during the session, have the patient use the resting seat (see Using the Resting Seat, page 36).
●
Turn the therapy jets, turbo jets, or the lamps ON as needed.
Figure 33 - Patient and Operator During a Therapy Session
Reversing Treill Direction To change the treill direction: DURING AN UNTIMED THERAPY SESSION 1. If the treill is running, press STOP on the Treill Functions screen. 2. Press FORWARD or REVERSE. 3. Press treill START and repeatedly press INCREASE until the desired speed is reached. DURING A PERSONAL PROGRAM 1. On the Personal Program Overview screen, press the Treill Direction area of the screen and then enter the number for the desired direction on the numeric keypad (see Figure 20, page 22).
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 34 - Observe the Patient During the Therapy Session
35
Using the AquaCiser Using the Resting Seat If the patient tires, or if the therapy session calls for the patient to sit and perform stretching exercises: 1. Have the patient grasp the handrails. If the patient is able to straddle the treill, have the patient step off the treill and onto the non-moving guards at the sides of the treill.
AquaCiser® III 250 lb 113 kg Seat Load Limit (Dry)
2. If you are on the Treill Functions screen, press STOP. If using a Personal Program, press PAUSE PROGRAM. 3. Go to the Therapy Pool Functions screen (page 16) and press JETS OFF if needed. 4. If the patient is tired, have the patient lower and sit on the resting seat until his/her strength is regained or a decision is made to end the therapy session (Figure 35). If the patient will be performing seated exercises, direct the patient (Figure 36).
Figure 35 - Patient Using the Resting Seat
5. Have the patient push the resting seat up and into its locking clamps to store it. 6. To continue an unprogrammed session, press the treill START button and repeatedly press the INCREASE button on the Therapy Pool Functions screen until the desired speed is reached. To continue a Personal Program, go to the Personal Programs screen and press RESUME PROGRAM. Also see Resting Seat, page 13.
4 - END THE THERAPY SESSION The AquaCiser will signal the end of a Personal Program segment with audible beeps. The AquaCiser will sound one long beep when 10 seconds remain, and then will beep once per second for the final five seconds of each segment. At the end of a Personal Program, the treill will also slow and stop. Go to the Therapy Pool Functions screen and press JETS OFF. Turn the therapy pool lamps OFF if desired.
Figure 36 - Performing Seated Exercises 36
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III 5 - DRAIN THE THERAPY POOL 1. Keep the therapy pool door closed and fastened until the water is completely drained from the chamber. 2. Go to the Therapy Pool Functions screen. ○○
If the water is clean, press DRAIN TO RESERVOIR to move the water into the reservoir.
○○
If the water is contaminated, press DRAIN DISCARD to drain the water directly into the waste drain.
Using the AquaCiser WARNING Contaminated water can spread disease. Discard contaminated water and clean and disinfect the AquaCiser.
3. If the AquaCiser will be idle for a time before the next patient, press ENABLE FILTER to filter the water once it is in the reservoir. If another patient will enter the AquaCiser momentarily, this step may be skipped.
6 - HELP THE PATIENT EXIT THE THERAPY POOL 1. When the water is completely drained from the therapy pool, open the door and help the patient exit (Figure 37). 2. Close and fasten the door securely. 3. Have the patient shower after the therapy session.
7 - WIPE DOWN THE THERAPY POOL 1. Wipe down the therapy pool. Hudson recommends you use a spray bottle filled with isopropyl alcohol or warm water and a clean, soft cloth. Do not use an ammonia-based cleaner. 2. If the water in the therapy pool was discarded due to contamination, clean and disinfect the therapy pool (see Clean and Disinfect the Therapy Pool, page 43). Figure 37 - Help the Patient Exit the Therapy Pool 8 - CHECK THE WATER LEVEL If water was splashed out of the therapy pool during the session or was lost for any other reason, check the water level with all of the water in the reservoir (See Check the Water Level, page 31). If you add water, recheck the water temperature and chemical levels.
Important Do not use ammonia-based cleaners (such as Windex®) to clean the AquaCiser. Hudson recommends using isopropyl alcohol to clean the therapy pool windows and door.
Important Flooding can occur if the therapy pool door is not fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
37
Using the AquaCiser 6.6 End of Day
AquaCiser® III End of Day
At the end of the work day, follow the instructions in the End of Day routine at right.
1. Press ENABLE FILTER
1 - ENABLE THE FILTER
2. Test the Water Condition
The AquaCiser will automatically filter and keep the water at the Setpoint temperature if you do the following:
3. Check the Filter Cartridge
1. Move all of the water to the reservoir. Press DRAIN TO RESERVOIR on the Therapy Pool Functions screen. 2. that the therapy pool door is closed securely. 3. Press ENABLE FILTER.
4. (Optional) Set the Auto Heat Start-Up 5. Check the Door Seal (daily); Clean and Lubricate the Door Seal (if necessary) 6. Close and Fasten the Therapy Pool Door
Note: Leave the AquaCiser Main Power ON. 4. that the water temperature Setpoint is the desired temperature (see Setting the Water Temperature, page 17). In this state, the AquaCiser will periodically cycle and keep the water warmed to the Setpoint temperature. 2 - TEST THE WATER CONDITION
Important Leave the AquaCiser Main Power ON. ONLY turn the Main Power OFF when performing maintenance, accessing the lint basket or filter, or plan to leave the AquaCiser inactive for a long period of time.
Test the water condition two times each day - before therapy sessions begin, and after therapy sessions are finished. Treat the water (see Water Condition, pages 48-49) if it fails to meet any of the following levels: Water Hardness 250-500 ppm Total Chlorine less than 2 ppm Free Chlorine 1-3 ppm pH 7.2-7.8 Alkalinity 80-120 ppm Use and maintain records of the water condition. Sample Water-Condition Logs are provided on pages 56 and 57.
38
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Using the AquaCiser
AquaCiser® III 3 - CHECK THE FILTER CARTRIDGE With the Filter Enabled and running (ON), open the filter access (see Components, page 10), and read the pressure gauge (Figure 38). If the pressure is 5-10 psi higher than “normal”, remove and clean the filter as instructed in Change the Filter Cartridge, page 45. If the pressure remains higher than “normal” after changing the filter, replace the filter. NOTE ON “NORMAL” PRESSURE GAUGE READING: The pressure gauge will read differently depending on many factors, including the water level in the therapy pool, if the jets are in use, etc. To establish a normal pressure for your location, check the pressure regularly when the AquaCiser is in the same mode (for example, with all the water in the reservoir and the filter enabled and running as indicated above).
Figure 38 - Filter Pressure Gauge
Filter Pressure Gauge
4 - (OPTIONAL) SET THE AUTO HEAT START-UP If the AquaCiser will be idle for more than two days, press POOL OFF and DISABLE FILTER, then set the Auto-Heat Start-up function by scheduling a time for the AquaCiser to turn ON and begin filtering and warming the water. See the Auto Heat Start-up, pages 26-27. 5 - CHECK THE DOOR SEAL (DAILY); CLEAN, LUBRICATE DOOR SEAL (IF NECESSARY) Unfasten and open the therapy pool door and check the door seal. If it is dry or dirty, clean the seal and apply a very small amount of petroleum jelly. Use only enough to lightly coat only the edge of the seal that the therapy pool door presses against. Wipe off excess petroleum jelly. 6 - CLOSE AND FASTEN THE THERAPY POOL DOOR Close the therapy pool door securely by pulling the lever to the completely closed position (see Therapy Pool Door Lever, page 12). The door has a sensor on the lower latch that will not allow the AquaCiser to fill or drain discard if the door is not shut securely. Always keep the door closed and fastened except when a patient enters or exits the therapy pool.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Important Flooding can occur if the therapy pool door is not fastened. Always close and secure the door by pulling the lever down after the patient enters or exits the therapy pool.
39
Maintaining the AquaCiser
AquaCiser® III
7 - MAINTAINING THE AQUACISER 7.1 Maintenance Schedule
DANGER
The AquaCiser requires regular maintenance. Set up and follow a maintenance schedule. A form to record maintenance is provided on page 55. The schedule below represents minimum maintenance.
Electric shock can cause death or serious injury. Install, operate, and maintain the AquaCiser only as described in this manual.
When using maintenance products, follow the manufacturers’ directions and read the manufacturers’ material safety data sheets. You can purchase a recommended disinfectant from Hudson Customer Relations (page 2) or your Hudson
Maintenance Schedule Wipe Down the Therapy Pool (page 37) Test the Water Condition (pages 48-49) Filter the Water (page 38)
Each Use
WARNING Improper maintenance can cause injury. Maintain the AquaCiser only as described in this manual and the Service Manual provided.
Each Day
Each Week
• •*
•*
Each Month
Every 6 months
• •• •
Replace the Water and Clean the AquaCiser (pages 42-46) Check the Door Seal; Clean and Lubricate Door Seal (pages 39, 46)
As Needed
•
•
Change the Filter Cartridge (page 45)
•
Inspect Function of Emergency Stop/Emergency Drain Buttons (pages 11, 13) and Main Power/ GFCI (see the Service Manual)
•
Inspect the AquaCiser (page 41; also see the Service Manual)
•
Lubricate the Chlorine Dispenser (page 41)
•
Inspect All Electrical Parts (See the Service Manual)
• SCHEDULE NOTES
• • Test the water condition at least two times each day. water weekly or as needed, based on the number of patients using the AquaCiser. Always change the •* Replace water immediately if it becomes contaminated (such as with body fluids).
40
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Maintaining the AquaCiser
7.2 Inspecting the AquaCiser Have your service technician inspect the AquaCiser. Follow the various inspection sections in the Service Manual provided. If the inspection indicates an electrical fault or other problem, take the AquaCiser out of service. Have a qualified service person follow instructions in the Service Manual, or Hudson Customer Relations (page 2).
Read the Service Manual
7.2 Replacing the Chlorine Container The chlorine dispenser draws its chlorine supply from a replaceable 1-gallon container. When the container is empty, replace it. 1. Unlock the chlorine dispenser access , then open and set the aside. This is located nearest the steps (see Components, page 10).
Wear Gloves
2. Wear Personal Protective Equipment before touching the old chlorine container, cap or tubing. Wear rubber gloves. 3. Remove the bottle cap and suction tube from the empty chlorine container (Figure 40). 4. Attach the bottle cap to the new chlorine container and push the suction tube through the bottle cap until the tube touches the bottom of the container. 5. Return the access to the proper position and lock the in place to prevent untrained people from accessing the chlorine container or pump.
Figure 40 - Wear Protective Gloves When Exchanging the Chlorine Container
7.4 Lubricate the Chlorine Dispenser Have your service technician inspect the chlorine dispenser every six months and lubricate the chlorine dispenser head assembly when needed (Figure 41). See Semiannual Maintenance in the Service Manual for details. See Supplies, page 52 to order lubrication gel.
Lubrication Point
Figure 41 - Chlorine Dispenser Lubrication Point
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
41
Maintaining the AquaCiser
AquaCiser® III
7.5 Maintenance Sequence The Maintenance Sequence is shown at right. ● Follow all local, state, and governmental wastewater disposal and sanitation regulations. ● Follow lockout/tagout procedures before servicing the AquaCiser (see page 44 or see the Service Manual). ● When using maintenance products, follow the manufacturers’ directions and read the manufacturers’ material safety data sheets. ● In the U.S.A., use disinfection procedures that meet OSHA standards (see the Bloodborne Disease Notice, page 4). Hudson Customer Relations to order Hudson disinfectants and cleaners (page 2). ● Hudson recommends you inspect for obvious damage as you clean and disinfect the AquaCiser. ● Before beginning the Maintenance Sequence, put on all Personal Protective Equipment recommended by the manufacturer(s) of the cleaning chemical(s) being used. Refer to the MSDS sheets for each chemical. 1 - DISCARD THE WATER 1. Drain any water in the therapy pool by pressing DRAIN DISCARD on the Therapy Pool Functions screen (see pages 16 and 19). 2. Drain any water from the reservoir by pressing DRAIN DISCARD a second time. The waste drain will remain open until POOL OFF is pressed. Keep the waste drain open until you finish cleaning the AquaCiser.
1.
2.
3.
4.
5.
6.
42
2 - CLEAN THE TREILL Put on all Personal Protective Equipment recommended by the manufacturer(s) of the cleaning chemical(s) being used. Refer to the MSDS sheets for each chemical. To disinfect, spray the surface of the treill belt and guards with a hard-surface disinfectant such as Hudson’s SaniZene®. Follow the chemical manufacturer’s directions. Run the treill to expose additional treill belt surface for cleaning. Stop the treill and repeat Step 2 until the entire treill belt has been disinfected. To clean, use a boat wash/cleaner, available from a marine supply store. Do not use an abrasive cleaner, as this can scratch the gelcoat fiberglass surrounding the treill. Follow the manufacturer’s directions for use. Use a small brush with soft bristles to clean deep-down dirt. Do not use a metal wire brush. Run the treill to expose additional treill belt surface for cleaning. Stop the treill and repeat Step 4 until the entire treill belt has been disinfected. Rinse dirt and debris from under the treill to the waste drain by flushing the area with water.
DANGER 230/240 VAC Hazardous voltage inside. Follow lockout/tagout procedure before servicing.
Maintenance Sequence 1. Discard the Water 2. Clean the Treill 3. Disinfect and Clean the Therapy Pool 4. Disinfect and Clean the Reservoir 5. Lockout/Tagout to Power is OFF 6. Clean the Lint Basket 7. Change the Filter Cartridge 8. Refill the Reservoir 9. Lubricate the Door Seal 10. Test the Water Condition 11. Wipe Down the AquaCiser
Important Personal Protective Equipment may be required. Follow the manufacturer’s instructions and refer to the MSDS sheets for all cleaning chemicals used.
Important Lanolin and mineral oil can clog the filter. Do not use products that contain lanolin or mineral oil on the patient or in the AquaCiser.
Important Abrasive cleaners can scratch. Follow the maintenance instructions in this manual when cleaning the AquaCiser.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III 3 - DISINFECT AND CLEAN THERAPY POOL 1. To disinfect, wipe all surfaces except the windows and door with a hard-surface disinfectant such as SaniZene® and a soft-bristle brush. Follow the disinfectant manufacturer’s directions for application method and time. 2. Clean the windows and door using a spray bottle filled with isopropyl alcohol, or use a mild disinfectant and a clean, soft cloth. Do not use an ammonia-based cleaner. 3. To clean, apply a cleaner designed for use on gelcoat fiberglass, such as “Babe’s™ Boat Bubbles”, “Meguire’s™ One-Step Cleaner-Wax” or similar boat wash/cleaner, available from a marine supply store. Follow the manufacturer’s directions, and use a chamois cloth to wipe down the fiberglass s inside and outside of the therapy pool. 4. Rinse the therapy pool thoroughly. Using a hose, run water down between the treill and the chamber wall and rinse all around the treill. Run the water long enough to completely flush the area under the treill. 5. If desired, the fiberglass surfaces may be waxed to enhance the shine. Apply a boat/marine wax as instructed by the wax manufacturer to the gelcoat fiberglass. Do not use an automotive wax.
Maintaining the AquaCiser Important Abrasive cleaners can scratch. Follow the maintenance instructions in this manual when cleaning the AquaCiser.
Important Do not use ammonia-based cleaners (such as Windex®) to clean the AquaCiser. Hudson recommends using isopropyl alcohol to clean the therapy pool windows and door.
Important When cleaning or waxing the AquaCiser, use only products designed for use on gelcoat. Chemicals designed for use on gelcoat may be purchased from a boat/marine supply store.
4 - DISINFECT AND CLEAN THE RESERVOIR 1. Remove the reservoir access (Figure 42). 2. Wipe down the reservoir walls with a soft-bristled brush or clean cloth. 3. To disinfect, apply a hard-surface disinfectant such as SaniZene® to all surfaces and scrub with a soft-bristle brush. Follow the cleaning chemical manufacturer’s directions. 4. To clean, apply a cleaner designed for use on gelcoat fiberglass, such as “Babe’s™ Boat Bubbles”, “Meguire’s™ One-Step Cleaner-Wax” or similar boat wash/cleaner, available from a marine supply store. Follow the manufacturer’s directions, and use a chamois cloth to wipe down the fiberglass s inside and outside of the therapy pool.
Gelcoat Surfaces
5. Rinse the reservoir thoroughly. 6. If desired, the fiberglass surfaces may be waxed to enhance the shine. Apply a boat/marine wax as instructed by the wax manufacturer to the gelcoat fiberglass. Do not use an automotive wax. 7. Replace the reservoir access .
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 42 - Accessing the Reservoir “Babe’s” is a trademark of Babe’s Boat Care Products, Inc., Hayward, California, USA. Meguiar’s is a trademark of Meguiar’s Inc., Irvine, California, USA, and Meguiar’s International in various countries.
43
Maintaining the AquaCiser 5 - LOCKOUT/TAGOUT TO POWER IS SHUT OFF 1. Open the electrical access door (see Components, page 10). 2. Open the transparent cover and flip the Main Power switch to OFF (Figure 43). The Main Power switch is a safety switch or Residual Current Device (RCD), also known as a Ground Fault Lockout/ Circuit Interrupter (GFCI). Tagout Symbol 3. Place a lock on the switch to prevent others from activating the system while you are working on it.
DANGER
AquaCiser® III DANGER 230/240 VAC Hazardous voltage inside. Follow lockout/tagout procedure before servicing.
Figure 43 - Locking Out the Main Power Switch
Flooded electrical components can shock and cause death or serious injury. Discard the water and turn the Main Power switch OFF before opening the lint basket or filter cover. 6 - CLEAN THE LINT BASKET 1. Remove the floor mat nearest the command console and open the lint basket access (Components, page 10). 2. To remove the lint basket cover, turn the cover until the tab in the cover aligns with the notch in the housing (Figures 44 and 45). 3. Remove the lint basket from the holder. 4. Empty the lint basket. 5. Rinse and disinfect the lint basket. 6. Place the lint basket in the holder by turning the basket until the notch in the basket aligns with the holder. Secure the basket in the holder (Figures 44 and 45). 7. Replace the lint basket cover and that it is securely closed. 8. Close the lint basket access and replace the mat.
Cleaning Lint Basket At Other Times (NOT DURING MAINTENANCE SEQUENCE) If you need to clean the lint basket other than during the maintenance sequence, do the following first: ●
Move water into the therapy pool until the water level is lower than the filter housing (see the Filter Components diagram on page 45).
●
Turn the Main Power switch OFF.
●
Open the bleeder valve to allow any excess water to move away from the filter.
●
Follow the instructions in Maintenance Sequence subsection “5 - Clean the Lint Basket” above.
Figure 44 - Removing the Lint Basket Cover Lint Basket Basket Handle Notch
Figure 45 - Securing the Lint Basket in the Holder 44
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Maintaining the AquaCiser
7 - CHANGE THE FILTER CARTRIDGE Two filter cartridges are provided with the purchase of an AquaCiser. Alternate the filters. When one filter is dirty, place the clean, dry filter in the AquaCiser and clean the dirty filter (See Cleaning the Filter Cartridge, page 47). If a filter is worn, order a replacement (see Supplies, page 52). Note: If you need to clean the filter other than during the maintenance sequence, move enough water into the therapy pool so the water level in the reservoir is below the top of the filter housing, then flip the MAIN POWER switch to OFF.
1. 2. 3. 4. 5. 6.
TO REMOVE A DIRTY FILTER Open the filter access (Components, page 10). Loosen the wing nut and remove the filter cover (Figure 46). Inspect the O-ring (Figures 46 and 47). If it is cracked or worn, replace it. Remove and clean the shaft guide cap (Figure 47). Remove the dirty filter. Use a vacuum capable of vacuuming up water (commonly known as a Wet/Dry Vac™ or Shop-Vac®) to remove excess water from the filter housing.
TO INSTALL A CLEAN FILTER 1. Place a clean, dry filter in the filter housing. 2. If a replacement O-ring is used, stretch the new O-ring onto the filter cover (Figure 47). 3. Spread a thin, light coating of petroleum jelly on the surface of the O-ring. 4. Reassemble the filter components (Figure 46). 5. Remove the lockout device from the Main Power switch and turn the switch ON. Note: The master alarm will sound until the RESTART button is pressed (See the next procedure, Refill the Reservoir, page 46). 6. On the Maintenance Functions screen, press RESET HOURS in the Filter Run Hours area of the screen. You will be asked for the . See Filter Hours and Protection, page 29.
Wing Nut
Pressure Gauge
Bleeder Valve
Not Shown: Reducer Nut
Filter Cover
O-Ring
Not Shown: Shaft Guide Cap Inside Cover
Filter
Shaft
Filter Housing
Figure 46 - Filter Components
O-Ring
Guide Cap
Important Use filter-cleaning chemicals only as directed and only for the time required by the chemical manufacturer. To prepare the AquaCiser for service more quickly, install the clean, dry spare filter (provided) while the dirty filter is being cleaned. Wet-Dry Vac™ and Shop-Vac® are trademarks of Shop-Vac Corporation, Williamsport, PA, USA. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 47 - Filter Cover, O-Ring and Guide Cap 45
Maintaining the AquaCiser
AquaCiser® III
8 - REFILL THE RESERVOIR 1. Close and fasten the therapy pool door. 2. The master alarm tone should be sounding (See To Install a Clean Filter, page 45). On the Command Console, twist the red Emergency Stop button clockwise to unlock the button, then press the green RESTART button. This resets the computer system and restores power.
WARNING Overflowing the reservoir can cause injury due to electric shock, and can damage the AquaCiser. Never leave the AquaCiser unattended while filling the reservoir.
3. Fill the reservoir with clean water, using a garden hose or similar (not supplied). Be attentive and do not fill the reservoir past the fill line (Figure 48). Never leave the AquaCiser unattended while filling the reservoir. Overflowing the reservoir can lead to injury and damage. 4. Turn the bleeder valve on the filter housing to open the valve and bleed the air from the system (Figure 49). 5. When water begins to escape, hand-tighten the bleeder valve.
Fill Line
Figure 48 - Reservoir Fill Line
9 - LUBRICATE THE DOOR SEAL Remove excess lubricant from the door seal, using isopropyl alcohol to clean the rubber seal, the door area where the seal s the door, and the metal water sensors. Apply a very small amount of petroleum jelly. Use only enough to lightly coat only the edge of the seal that the therapy pool door presses against. Wipe off excess petroleum jelly. 10 - TEST THE WATER CONDITION that the chlorine bottle is not empty (See Replacing the Chlorine Container, page 41). The water should meet the following criteria: Water Hardness 250-500 ppm Total Chlorine less than 2 ppm Free Chlorine 1-3 ppm pH 7.2-7.8 Alkalinity 80-120 ppm If the water does not meet the criteria above, treat the water (see Water Condition, pages 48-49). Maintain records of the water condition. Sample WaterCondition Logs are provided on pages 56 and 57, or develop your own water-condition log. 11 - WIPE DOWN THE AQUACISER ●
Use a spray bottle filled with isopropyl alcohol, or use a mild detergent and a clean, soft cloth to wipe down the entire outside of the AquaCiser.
●
Clean the mats and the areas under the mats.
●
Clean around the rims of the access s.
46
Figure 49 - Turning the Bleeder Valve
Important Do not use ammonia-based cleaners (such as Windex®) to clean the AquaCiser. Hudson recommends using isopropyl alcohol to clean the therapy pool windows and door.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Maintaining the AquaCiser
7.6 Cleaning the Filter Cartridge 1. Fill a large plastic or fiberglass container with lukewarm water deep enough to cover the filter. Do not put the filter in the container at this time. Do NOT use a metal or porcelain container to clean the filter. 2. If using Filter-Cleanse™ crystals (not included), add 1 pound of crystals for every 10 gallons of water. 3. Stir the solution with a wooden stick until the solution turns red and the crystals dissolve. 4. Place the filter in the solution. Ensure the solution completely covers the filter. 5. Remove the filter after the solution has turned yellow or orange. 6. Discard the solution. Follow your facility’s protocols and your municipality’s regulations regarding the disposal of chemicals. 7. Rinse the filter from the inside out with warm water from a non-pressurized hose.
Important Do not use a galvanized steel, aluminum, or porcelain container to clean the filter. Filter-Cleanse can corrode these materials. Use only a plastic or fiberglass container.
Important When cleaning the filter, wear Personal Protective Equipment as recommended by the cleaning product’s Material Safety Data Sheet. The Filter-Cleanse™ manufacturer recommends gloves, safety goggles and a dust mask be worn while using the chemical. Use only in a well-ventilated area. When using Filter-Fresh™, gloves, safety goggles and a plastic or rubber apron must be worn. Use only in a well-ventilated area.
8. Allow the filter to air dry. The filter must be dry before it can be used in the AquaCiser. 9. Reuse the filter until it begins to show wear. Replace worn filters (See Supplies, page 52). Note: to reset the Filter Hours timer on the Maintenance Functions Screen (Figure 50).
Wear Gloves
Wear Eye Protection
Wear Dust Mask
Wear Apron
7.7 Adjusting the Temperature 1. On the Therapy Pool Functions screen, press the Temperature Setpoint area and enter the desired temperature. 2. Filter the water by pressing ENABLE FILTER to move the water through the heater. Alternatively, you can fill the therapy pool and turn the therapy or turbo jets ON to warm the water (the water moves through the heater when the jets are ON)
Figure 50 - Reset the Filter Run Hours When You Change Filters
GLB Filter-Cleanse™ and GLB Filter-Fresh™ are trademarks of GLB Pool & Spa, a division of Laporte Water Technologies and Biochem Inc., Alpharetta, GA, USA. © Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
47
Water Condition
AquaCiser® III
8 - WATER CONDITION 8.1 General Guidelines Maintaining clean and proper water condition is important for the patient’s health, for controlling algae and bacteria, and for maintaining the AquaCiser. Each facility is unique. The time it takes to condition the water in your AquaCiser will vary based on the water supply and the patient load. In-service training and maintaining a proper Water-Condition Log (included) are the best ways to learn how to condition your water. See Using the Water-Condition Log, page 49. Sample Water-Condition Logs are provided on pages 56 and 57, or you can make your own Water-Condition Log.
8.2 Test the Water Twice Daily (Minimum) Test the chlorine and the pH levels in the water at least twice daily. Hudson recommends testing the water during the Daily Start-up and End of Day sequences. The water should meet the following criteria: Water Hardness 250-500 ppm Total Chlorine less than 2 ppm Free Chlorine 1-3 ppm pH 7.2-7.8 Alkalinity 80-120 ppm
WARNING Improper handling or use of water-treatment chemicals can cause injury. Follow the chemical manufacturer’s directions for use.
WARNING Improper water conditioning can cause injury and damage the AquaCiser. Maintain the water condition as directed in this manual and keep a Water-Condition Log.
Water Condition Sequence 1. Test the Water Condition 2. Adjust the Chlorine Levels 3. Adjust the pH 4. Adjust the Alkalinity Record all water condition data on a Water-Condition Log (see sample on page 49). Water-Condition Logs are provided on pages 56 and 57.
Note: A pH and chlorine test kit is included with the AquaCiser. To order additional test kits and chlorine, see Supplies, page 52. To test the water, move all of the water to the reservoir. Use a chlorine test kit and follow the test kit manufacturer’s directions. If the readings are in the proper ranges, keep the chlorine dispenser setting on LOW so the level does not change when the filter is in use. If the levels are out of range, see Adjusting the Water Condition, page 49.
48
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III
Water Condition
8.3 Adjusting the Water Condition
range, press DISABLE FILTER.
Do NOT attempt to adjust all three properties of the water (chlorine, pH and alkalinity) at the same time. Each property affects the others. Always adjust the chlorine levels first, followed by the pH and then the alkalinity.
For additional chlorine dispenser information, see the RolaChem Chlorinator manual included with the AquaCiser. Also see the Chlorine Dispenser information on page 11. If problems persist, see Basic Troubleshooting, pages 50-51.
ADJUSTING THE CHLORINE LEVELS
ADJUSTING PH AND ALKALINITY LEVELS
If the chlorine levels are within the proper ranges: turn the chlorine dispenser setting to LOW so the level does not change when the filter is running. If the chlorine levels tested high: Bring the levels down by replacing some of the water in the AquaCiser. After adding water, retest the water condition and make further adjustments as needed. If the chlorine levels tested low: 1. Check the chlorine container to that it is not empty and that the suction tube is reaching the chlorine (See Replacing the Chlorine Container, page 41). 2. Press ENABLE FILTER to begin cycling the water, or fill the therapy pool above at least one pair of therapy jets and turn the jets ON. 3. the chlorine dispenser rocker switch is on TIMER (not OFF) and adjust the chlorine dispenser control knob to the next highest number on the dial.
●
Adjust the pH after adjusting the chlorine levels. Chemicals are available to raise or lower the pH level (see Supplies, page 52). Follow the chemical manufacturer’s guidelines for use and consult the chemical MSDS sheet for details on any required Personal Protective Equipment.
●
If needed, adjust the alkalinity after the chlorine levels and pH levels are in range.
●
If the three water properties cannot be brought into the acceptable range, the water may be contaminated. Discard the water, clean the AquaCiser and add fresh water, following the Maintenance Sequence, pages 42-46.
●
If you still have trouble after changing the water and you are sure no contamination is taking place, test the incoming water source outside of the AquaCiser.
●
If the incoming water source is out of range, your local or state water authority for assistance and further testing.
4. Retest the chlorine levels in one-half hour to one hour and see how much the levels have changed. 5. Repeat Steps 2 and 3 to make further water adjustments as needed. 6. When the chlorine levels are within the acceptable
8.4 Using the Water-Condition Log A sample Water-Condition Log is shown below. Blank forms are provided on pages 56 and 57. Maintaining a log can show water condition patterns and help you establish chlorine settings. The first row should be filled out during the in-service training; use this as a baseline. Note: The number of patients using the AquaCiser in a given time period affect the chlorine levels. WATER CONDITION Total Chlorine <= 2 ppm
Free Chlorine 1-3 ppm
7.2-7.8
Total Alkalinity 80-120 ppm
0
350
0
1/Hi
7.3
100
4
350
0
1/Lo
7.3
100
1
350
1
1/2
7.3
100
1
350
1
1/2
7.3
100
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
pH
COMMENTS (Filter Changed, Water Added, etc.)
E
Water Hardness 250-500 ppm
PL
6/20 In-service 6/21 8 am, DB 6/21 11:30, DB 6/21 5 pm, DB
NUMBER OF PATIENTS
SA M
DATE, TIME, INITIAL
49
Basic Troubleshooting
AquaCiser® III
9 - BASIC TROUBLESHOOTING 9.1 Basic Troubleshooting This section contains a few basic problems and solutions. If the problem you are experiencing is listed on this page, try these solutions first.
Important If these Basic Troubleshooting solutions do not correct the problem:
For more complete Troubleshooting assistance, see the AquaCiser III Service Manual (provided).
●
Refer to the AquaCiser III Service Manual (provided) for additional Troubleshooting assistance.
PROBLEM: A System Fault has occurred.
●
Hudson Customer Relations (page 2) or your Hudson distributor.
SOLUTION: Refer to the Service Manual for assistance in clearing system faults. PROBLEM: Jets do not work. SOLUTION 1: The water level has not reached the height of the sensor. Fill the therapy pool until the water is above the jets and sensor. SOLUTION 2: The sensor(s) are dirty or are coated with petroleum jelly from over-lubricating the door seal. Clean the sensor(s) and retest. If the problem persists, check the PLC Inputs/Outputs (refer to the Service Manual), or call for service. PROBLEM: Use of chlorine increases. SOLUTION 1: Patients may be bringing dirt into the AquaCiser. Have patients shower before using the AquaCiser. SOLUTION 2: Check and clean or replace the filter. SOLUTION 3: your local or state water authority for information and further testing. PROBLEM: AquaCiser will not fill therapy pool. SOLUTION 1: The sensor that checks that the door is closed may not be activated. Check the door lever for tightness and pull the door lever down as far as it will go. SOLUTION 2: The alarm is sounding and/or a fault such as the over-temperature warning is shown on the Command Console. If the water is over temperature, discard some water and refill with cooler water. If a different fault is indicated, refer to the Service Manual for assistance. PROBLEM: AquaCiser will not completely fill the Therapy Pool. SOLUTION: The reservoir does not have enough water in it. Press DRAIN TO RESERVOIR to pump all the water to the reservoir, then add water until the water level reaches the Fill Line (see Check the Water Level, page 31). : test the water condition if water is added. 50
PROBLEM: Water does not heat. SOLUTIONS: ●
The heater setting is too low. Adjust the water temperature Setpoint (See Setting the Water Temperature, page 17).
●
The thermal overload on the heater circuit breaker has tripped. Reset the heater (see page 51).
●
The pump motor has overheated. Allow time for the pump motor to cool.
●
The lint basket is clogged. Clean the basket (See Clean the Lint Basket, page 44).
●
The filter is clogged. Change the filter (See Change the Filter Cartridge, page 45).
PROBLEM: Water gets too hot. SOLUTION: The water Setpoint is too high. Adjust the Setpoint to a lower temperature. See Setting the Water Temperature, page 17. SOLUTION: The jets have been in use for a long time (the filter runs when the jets are ON). Reduce jet use or schedule patients so the jets are not ON for long periods of time. PROBLEM: Treill won’t run. SOLUTIONS: ●
The treill is stopped. Press START on the Treill Functions Screen and press INC to increase the speed (See Treill Functions Screen, pages 20-21).
●
The Personal Program is stopped or paused. Press RESUME PROGRAM.
●
A System Fault has occurred. Read the screen for the fault and consult the Service Manual.
●
The drive mechanism has encountered interference. Inspect the treill for blockage.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
AquaCiser® III PROBLEM: Chlorine Levels too low/levels do not increase. SOLUTIONS: ● The chlorine container is empty. Change the chlorine container (See Replacing the Chlorine Container, page 41). ● The rocker power switch on the side of the chlorine dispenser has been turned to OFF. Move the rocker to the ‘ON’ or ‘TIMER’ position (Figure 51). ● The chlorine dispenser is set too low. the chlorine dispenser rocker switch is on TIMER, then adjust the chlorine dispenser control knob (See the chlorine dispenser information on page 12 and Adjusting the Chlorine Levels, page 49). PROBLEM: When filling the therapy pool, the AquaCiser stops and a “Low Pressure” message is displayed. SOLUTIONS: ● There is too little water in the AquaCiser, causing the heater to lose pressure. Press DRAIN TO RESERVOIR to pump all the water to the reservoir, then add water until the water level reaches the Fill Line (see Check the Water Level, page 31). : test the water condition if water is added. ● If the water level is okay, check the heater pressure switch. (Refer to the Service Manual) or call for assistance. PROBLEM: “Possible Leak Detected” message displayed. SOLUTIONS: ● If a patient was undergoing vigorous exercise in the therapy pool, water may have been splashed down inside the AquaCiser, setting off this alarm. Allow the sensor to dry. ● Water may be leaking under the AquaCiser. See Troubleshooting Water Leaks in the Service Manual.
9.2 Resetting the Heater
Basic Troubleshooting
Figure 51 - Chlorine Dispenser Switch
Heater ON Indicator Light
To increase the water temperature: ● Adjust the Water Setpoint to a higher temperature ● Press ENABLE FILTER with the water in the reservoir. OR ● Press JETS ON with the water in the therapy pool. If the water temperature does not increase in time, the heater might need to be reset. 1. Remove the center floor mat and open the Plumbing Access (See Components, page 10). Check if the in-use indicator light is ON (Figure 52). 2. Push the temperature overload button on the heater to reset it (Figure 52). If the temperature overload button will not stay pushed in, or if it pops out again after being reset, Hudson, page 2 for service.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Figure 52 - Heater Reset Button
51
Supplies & Related Products
AquaCiser® III
10 - SUPPLIES 10.1 AquaCiser Supplies
10.2 Related Products
Hudson offers a complete line of supplies for the AquaCiser. To order supplies, Hudson Customer Relations (page 2) or your Hudson distributor.
Hudson also offers a complete line of performance pools, bathing and hydrotherapy products for the healthcare professional.
Description
Products include therapy tanks, whirlpool tanks, custom therapy and fitness pools, the AquaGaiter™ Underwater Treill, hot and cold spas, and residential pools and spas. Hudson Customer Relations (page 2) or your Hudson distributor for product information.
Part #
Water Test Kit (Chlorine/pH) Chlorine (4 ea., 1 gallon) Filter-Cleanse™ (1 quart) Filter-Fresh™ (1 quart) Foam Out (1 quart) Chlorinator Gel Lubricant (3 packets) Protect Plus (12 ea., 1 quart) pH Up (1 pound) pH Down (1 pound) Alkalinity Up (1 pound)
078-9730 078-9731 078-9546 078-9458 078-9459 078-9828 078-9456 078-9460 078-9461 078-9462
Filter Cartridge C-1750 or C-8417 (Single, tall for AquaII or AquaIII)
078-9800
SaniZene® Hard Surface Cleaner/Disinfectant 4 ea., 1 gallon
078-9214
52
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Repair Parts & Service
AquaCiser® III
11 - PARTS AND SERVICE 11.1 U.S.A. and Canada In the United States and Canada, to order parts or for professional AquaCiser repair, Hudson Customer Relations (page 2) for a qualified service provider in your area. Hudson
Phone 888.206-7802
WARNING Improper parts and service can cause injury. Use only Hudson parts and Hudson-approved service on the AquaCiser.
WARNING
E-Mail
[email protected]
Modifying the AquaCiser can cause injury and damage. Use the AquaCiser only as designed by Hudson.
11.3 AquaCiser Parts List Ref. # 1 2 3 4 5 6 7 8 9 10 11
Description
Seat cushion Upper platform floor mats (3) Steps floor mats (right-side, 2) Steps floor mats (center, 2) Steps floor mats (left-side, 2) Chlorine dispenser tubing (3'/1 m) Therapy pool light bulb Arm pad, right Arm pad, left AquaCiser Logo (1) AquaCiser Labels*
Part #
095-1424 095-1425 095-1426 095-1427 095-1428 095-1429 095-1430 095-1431 095-1432 195-1146 195-1147
* This kit includes the water depth gauge label and all warning and information labels.
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
53
Training Record
AquaCiser® III
TRAINING RECORD Date
54
Name
Training Method
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Maintenance Record
AquaCiser® III
MAINTENANCE RECORD Date
Maintenance Performed
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
By
55
Water-Condition Log
AquaCiser® III
WATER-CONDITION LOG DATE, TIME, INITIAL
56
NUMBER OF PATIENTS
WATER CONDITION Water Hardness 250-500 ppm
Total Chlorine <= 2 ppm
Free Chlorine 1-3 ppm
pH 7.2-7.8
Total Alkalinity 80-120 ppm
COMMENTS (Filter Changed, Water Added, etc.)
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Water-Condition Log
AquaCiser® III
WATER-CONDITION LOG DATE, TIME, INITIAL
NUMBER OF PATIENTS
WATER CONDITION Water Hardness 250-500 ppm
Total Chlorine <= 2 ppm
Free Chlorine 1-3 ppm
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
pH 7.2-7.8
Total Alkalinity 80-120 ppm
COMMENTS (Filter Changed, Water Added, etc.)
57
Index
AquaCiser® III
INDEX A
F
Alarm Bell (Icon on Screen) 6, 25 Alarm Sound (Master Alarm) 45 Alkalinity (see Water) AquaCiser Description, Purpose, Specifications 9 Automatic Heat Start-Up 26-27, 39
B
Basic Troubleshooting Beeps (End of Personal Program Segment) Bloodborne Disease Notice
C
50, 51 23 4
CE Certification 9 Chlorine Dispenser 10, 12, 41, 49-51 Chlorine Levels (see Water) Cleaning 40-47 Command Console 10, 11, 14-29 Components 10-13 Contaminated Water (see Water) Chemicals For Filter 47 For Water Condition 49 Ordering 52 Customer Relations 2
D
Danger Notices Daily Start-Up Date and Time Door Lever Door Seal Definitions Dimensions (Specifications) Direction (Treill) Discarding Water Disinfect Lint Basket Therapy Pool Treill Reservoir Wipe Down After Each Session Distance Meter Drain Discard (Button On Touch-screen) Drain to Reservoir
E
Emergency Drain Button/Symbol Emergency Stop Button Evaluating Patients
58
4 31, 32 27 10, 12 39, 45 (See ) 9 21 11, 19, 42, 49 44 43 42 43 37 20, 21 19, 42 16, 17, 19, 37 5, 6, 10, 11, 19 10, 11 8
Fault Indication Notices Hudson Customer Relations Fill the Therapy Pool Filter Checking the Filter Cartridge Cleaning the Cartridge Leaving Enabled (End of Day Filtering) Removing/Installing Filter Hours/Resetting Filter Hours
G
General Guidelines GFCI (Main Power) Switch Heat Start-Up (Automatic) Heater/Water Heating Important Box Inspecting the AquaCiser Jets
H I J L
25 2 17, 35 18 39 47 18, 38 45 28, 29 30 43
26-27, 39 18, 26, 27, 32, 33, 47, 51 4 40, 41 10, 12, 16, 18
Labels 6 Lamps (Lights) 7, 10, 12, 18 Lanolin (Not Permitted) 30, 33, 42 Lead Battery (Recycling Information) 4 Lint Basket 44 Lockout/Tagout 42, 44 Lubrication Door Seal 39, 46 Chlorine Dispenser 41 O-Ring 45
M
Main Power Switch Main Menu Screen Maintenance Schedule/Table Sequence Mineral Oils (Not Permitted)
N
Normal Jets (Therapy Jets)
O
13, 43 14, 15 40 42-46 30, 33, 42 See Jets
Operator Assistance Screens 24, 25 Operator Skills 7 OSHA 4
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
Index
AquaCiser® III P Parts 53 29 Patient Evaluation 8 Facing Direction 21 Help Enter 34 Help Exit 37 Prepare for Therapy Session 33 Resting 36 Personal Programs 22, 23 Personal Protective Equipment (PPE) 41, 42, 47 pH (see Water) Physician Evaluation 8 Power Switch 13, 43 PLC (Programmable Logic Controls) 28, 29 Problems (See Faults)
R
Ratings Plate 2, 9 RCD (Main Power) Switch 43 Recycling 4 Repairs 53 Reservoir 10, 13 Filling 46 Water Level 31, 37, 46 Clean and Disinfect 43 Reset Filter Hours 47 Restart Button 10, 13, 46 Resting Seat 13, 36 Routines Before Each Session 33 Daily Start-Up 31, 32 End of Day 38, 39 Maintenance 40, 42-46 Therapy Session 34-37 Water Condition 48, 49 Run Timer 21
S
Seat 13, 36 Service 53 Settings Automatic Heat Start-Up 27 Date and Time 27 Filter Hours 29 Units (Metric or Imperial) 29 Water Temperature 16, 17, 47 Set-Up Before Use 30 Specifications 9 Speed 20, 21 Supplies 52 Symbols Glossary 6
T
Table of Contents 3 Temperature 16, 17, 32, 33, 47 7 Therapy Jets 10, 12, 16, 18 Therapy Pool Clean and Disinfect 43 Component 10 Function Screen 16-19 Wipe-Down 37 Therapy Session 33-37 Timer (see Run Timer) Time and Date 27 Touch-Sensitive Screen (Command Console) 14 Training, Operator 7, 24 Treill Cleaning 42 Treill Direction 21, 35 Treill Functions Screen 20, 21 Treill Operation (Checking) 32 Treill Speed 20, 21 Troubleshooting (Basic) 50, 51 Turbo Jets 10, 12, 18
W
SaniZene® 42, 43, 52 Safety Information 5-7 Safety Labels 5 Screens 14-29 Automatic Heat Start-Up 26-27 Main Menu Screen 14-15 Maintenance Functions 28-29 Operator Assistance 24-25 Personal Programs 22-23 Therapy Pool Functions 16-19 Treill Functions 20-21
Warning Notices 4 Warranty Statement 2 Water Adjusting Chlorine, pH, Alkalinity 49 Condition 31, 38, 46, 48, 49 Condition Log 49, 56, 57 Contaminated Water (Dealing With) 19 Discarding 11, 19, 42, 49 Temperature 17, 18, 20, 21, 26, 27, 32, 33, 47, 51 Water Level (Reservoir) 31, 37, 46, 51 Water Level (Therapy Pool Fill/Drain) 16, 17, 34 WEEE Directive 4 Windex® (Don’t Use) 37, 43, 46
© Hudson Aquatic Systems, LLC, Inc. 234-3253-02 July 2009
59
