Well hi to all. I hope this helps. I'm going to show how I brought my Sy lvania Tablet ( 7", android 2.1 Express model from CVS pharmacy) back from a sta te of brick after trying to run Pandora. *Be sure you plug your tablet into the charger before starting!* 1. iuw1.2 package and unzip. ( I use the desktop to make it eas y) there will be 2 folders. 2. 11.2.0.7.2.0_beta3 Sylvania works.ius file and unzip. 3. Plug in a USB cable to a windows XP computer (heard it doesn't work o n other OS) 4. Plug other end into otg port next to audio out. 5. Push power button like you are turning it on and set the tablet down. 6. Computer will recognize new device and ask for drivers. Point the dri ver tool at the second folder called otg_driver for all drivers needed. (comes i n iuw package) 7. Now open first folder in iuw package iuw1.2 (iuw1.2 :P) and run progr am. 8. Select link USB, set USB mode to easy burn. 9. Next choose a wrapped image(click the button next to the text window labeled ... and choose the beta3 .ius file) 10. In the link information window under Dv. the box should be green mea ning the tablet is connected and ready. Click Burn. 11. During all this the screen should be black, but shortly after you cl ick burn communicating with computer will appear on the screen along with progre ss bars. Just be patient, When it is all done it will tell you to unplug from ot g port and reset, so do just that unplug from the tablet and take your stylus an d tap the reset button on back to shut down. 12. After you power back on it will take a little time to apply the imag e file but all the sudden the logo will start to flash and then the all satisfyi ng touch screen to calibrate. I Hope all goes well, it took me hours to figure out how to get a workin g img. file to work in a working flasher. As a side note it is the updated android 2.2 ver. also it says HDMI conn ected (lol express ver, no hdmi) however still has full functionality. 11.2.0.7.2.0_beta3 sylvania works.ius.zip (11.2.0.7.2.0_beta3 Sylvania w orks.ius file) Attached Files Attached Files File Type: zip iuw1.2.zip (200.1 KB, 1118 views) Last edited by dwarf365; 07-17-2011 at 12:59 PM. Reply With Quote Reply With Quote 07-17-2011 01:28 AM # ADS Ads Circuit ment Date Always Posts Many 07-17-2011, 02:11 AM #2 cfrockit cfrockit is offline

Senior Member Points: 241,930, Level: 100 Level completed: 0%, Points required for next Level: 0 Overall activity: 0% Achievements: 50000 Experience Points 1 year ed 25000 Experience Points 10000 Expe rience Points 5000 Experience Points Awards: s cfrockit's Avatar Member # 10570 Date Dec 2010 Posts 627 Thanked 175 times Points 241,930 Level 100 Device Sylvania SYNET7LP Quote Originally Posted by dwarf365 View Post Well hi to all. I hope this helps. I'm going to show how I brought my Sy lvania Tablet ( 7", android 2.1 Express model from CVS pharmacy) back from a sta te of brick after trying to run Pandora. I Hope all goes well, it took me hours to figure out how to get a workin g img. file to work in a working flasher. Welcome! A "factory reset - (three finger method)" posted as a Sticky th read at the top of this forum may have more easily resolved your issue however, if "No recovery image is found ..." then burning an update, as you have found, r estores the tablet. Sorry it took you so long to figure out all that information as it is also posted in the Sticky thread How to manually update SYNET7LP/SYTAB EX7 to Android 2.2 "Froyo" at the top of this forum. Many of the SYTABEX7 tablet s have been successfully updated/restored using 11.2.1.5.2.0_beta4.ius. There ar e more discussions specific to the CVS Express model in the Sticky thread Sylvan ia SYTABEX7 Owners: Must Read. As a side note it is the updated android 2.2 ver. also it says HDMI conn ected (lol express ver, no hdmi) however still has full functionality. Yes, all of the InfoTM firmware includes drivers for HDMI, Bluetooth, Et hernet, and GPS even though many of the tablets do not have the physical hardwar e to . Some of that information is posted in the Sticky thread Resources for the SYNET7LP/SYTABEX7/Disgo 6000 which is a great place to start to understa nd the unique characteristics of these tablets. Last edited by cfrockit; 07-17-2011 at 10:17 AM. dwarf365 thanked this. Use the Thank button, "Thumbs up" icon in bottom right of the post, if t his Reply was of assistance. Thanks Resources for the SYNET7LP/SYTABEX7/Disgo 6000/SYTAB10MT (SYNET10LP) Sylvania infoTMIC Update Wrap (*.ius) files & Wrap Information

Custom Sylvania ROM development infoTMIC Hardware ID's "hwver" and updates (*.ius) Reply With Quote Reply With Quote 07-17-2011, 02:51 AM #3 st0ne st0ne is offline Senior Member Points: 3,012, Level: 33 Level completed: 75%, Points required for next Level: 38 Overall activity: 0% Achievements: 1 year ed 1000 Experience Points 500 Experience Points 250 Experienc e Points 100 Experience Points st0ne's Avatar Member # 19905 Date Mar 2011 Location Las Vegas, NV Posts 209 Thanked 10 times Points 3,012 Level 33 Device Sylvania 7" Mini Tablet Express Quote Originally Posted by dwarf365 View Post 3. Plug in a USB cable to a windows XP computer (heard it doesn't work o n other OS) I never could get the drivers from the 1.1 IUW to work with Win7 or Vist a. (both 64-bit) But I WAS able to get the 1.2 IUW drivers to work on the Vista laptop. I have flashed from beta 4 to beta 5 and back to beta 4 with the1.2IUW u sing the Sticky cfrockit mentioned as a guide each time. The only problem I had installing the drivers was the timing. the first time I tried the Tab stopped wa iting for the OTG connection just before the drivers were done installing and IU W wouldn't see the tab. The second time the timing was right and it all installe d and has worked every time. dwarf365 thanked this. Reply With Quote Reply With Quote 07-17-2011, 12:01 PM #4 dwarf365 [OP] dwarf365 is offline Junior Member Achievements: 7 days ed 31 days ed 100 Experience Points 100 Experience Po ints dwarf365's Avatar Member # 40793 Date

Jul 2011 Posts 10 Thanked 1 times Three Finger salute doesn't work on this tablet even after doing a 2.2 u pdate on the device. also the resources are so deeply buried and split apart its near impossible to find the files. So my post stays. Reply With Quote Reply With Quote 07-17-2011, 04:50 PM #5 cfrockit cfrockit is offline Senior Member Points: 241,930, Level: 100 Level completed: 0%, Points required for next Level: 0 Overall activity: 0% Achievements: 50000 Experience Points 1 year ed 25000 Experience Points 10000 Expe rience Points 5000 Experience Points Awards: s cfrockit's Avatar Member # 10570 Date Dec 2010 Posts 627 Thanked 175 times Points 241,930 Level 100 Device Sylvania SYNET7LP SYSBACK - zSYS.img Quote Originally Posted by dwarf365 View Post Three Finger salute doesn't work on this tablet even after doing a 2.2 u pdate on the device. also the resources are so deeply buried and split apart its near impossible to find the files. So my post stays. Thanks for the consolidated steps, one of the biggest issues is much of the information for these tablets is buried throughout the forum and on multiple other sites. It would be great to have a wiki as do some of the more popular in foTM tablets. In order to obtain the ability to apply a "Three Finger salute" the zSYS .img needs to be burned separately. Since the individual images (U0, Ramdisk, data, system) didn't exist without a lot of effort to extract them form the InfoTM Update Wrap (.ius) mult i-part files this was previously not possible. However, again buried deep within the Custom Sylvania ROM development th read is a "How To" extract ADR_AS using vio's IusEdit_0.41 application to obtain the zSYS.img from the InfoTM Update Wrap (.ius) file that can be burned as SYSB

ACK using IUW.exe in USB mode: Expert burn. Once burned, this should provide the ability to apply a factory reset (three finger method). This image has been resized. Click this bar to view the full ima ge. The original image is sized 701x459. Click image for larger version. Name: zSYS.JPG Views: 3976 Size: 46.3 KB ID: 3227 dwarf365 thanked this. Use the Thank button, "Thumbs up" icon in bottom right of the post, if t his Reply was of assistance. Thanks Resources for the SYNET7LP/SYTABEX7/Disgo 6000/SYTAB10MT (SYNET10LP) Sylvania infoTMIC Update Wrap (*.ius) files & Wrap Information Custom Sylvania ROM development infoTMIC Hardware ID's "hwver" and updates (*.ius) Reply With Quote Reply With Quote 07-18-2011, 09:06 PM #6 dwarf365 [OP] dwarf365 is offline Junior Member Achievements: 7 days ed 31 days ed 100 Experience Points 100 Experience Po ints dwarf365's Avatar Member # 40793 Date Jul 2011 Posts 10 Thanked 1 times cfrockit thanks so much for all your posts! your info and files brought a 1 week old tablet back from death (because i had to try Pandora from a nexus o ne. worked for a min then freaked out) Also thanks for looking over my post and adding where necessary. You are my newest hero! lol Thank you so much! Reply With Quote Reply With Quote 11-13-2012, 10:53 PM #7 orkamcclurg orkamcclurg is offline Junior Member Points: 63, Level: 1 Level completed: 26%, Points required for next Level: 37 Overall activity: 0% Achievements: 7 days ed orkamcclurg's Avatar Member # 154270 Date Nov 2012 Location usa Posts

1 Points 63 Level 1 Device sylvania tablet what does Quote Originally Posted by dwarf365 View Post Well hi to all. I hope this helps. I'm going to show how I brought my Sy lvania Tablet ( 7", android 2.1 Express model from CVS pharmacy) back from a sta te of brick after trying to run Pandora. *Be sure you plug your tablet into the charger before starting!* 1. iuw1.2 package and unzip. ( I use the desktop to make it eas y) there will be 2 folders. 2. 11.2.0.7.2.0_beta3 Sylvania works.ius file and unzip. 3. Plug in a USB cable to a windows XP computer (heard it doesn't work o n other OS) 4. Plug other end into otg port next to audio out. 5. Push power button like you are turning it on and set the tablet down. 6. Computer will recognize new device and ask for drivers. Point the dri ver tool at the second folder called otg_driver for all drivers needed. (comes i n iuw package) 7. Now open first folder in iuw package iuw1.2 (iuw1.2 :P) and run progr am. 8. Select link USB, set USB mode to easy burn. 9. Next choose a wrapped image(click the button next to the text window labeled ... and choose the beta3 .ius file) 10. In the link information window under Dv. the box should be green mea ning the tablet is connected and ready. Click Burn. 11. During all this the screen should be black, but shortly after you cl ick burn communicating with computer will appear on the screen along with progre ss bars. Just be patient, When it is all done it will tell you to unplug from ot g port and reset, so do just that unplug from the tablet and take your stylus an d tap the reset button on back to shut down. 12. After you power back on it will take a little time to apply the imag e file but all the sudden the logo will start to flash and then the all satisfyi ng touch screen to calibrate. I Hope all goes well, it took me hours to figure out how to get a workin g img. file to work in a working flasher. As a side note it is the updated android 2.2 ver. also it says HDMI conn ected (lol express ver, no hdmi) however still has full functionality. 11.2.0.7.2.0_beta3 sylvania works.ius.zip (11.2.0.7.2.0_beta3 Sylvania w orks.ius file) what does it mean if your computer doesnt see it and ask for drivers Reply With Quote Reply With Quote
