ALCOHOL DETECTION WITH VEHICLE CONTROL Guided by:-

Prof. P. J. Mondhe

ALCOHOL DETECTION WITH VEHICLE CONTROL USING ARDUINO

Created By:16.Vaibhav Chopde 18.Akash Davange 22.Deepak Gaikwad

ABSTRACT Road accidents are very common in today’s busy life. Most of the people use private vehicles and sometimes being careless, people may drive in a drunken state.  This may lead to hazardous accidents.  To avoid such conditions, we have worked upon this project that enhances safety on roads. It aims to prevent drunk and driving and thus avoiding accidents 

OVERVIEW          

Introduction Literature Review Block Diagram Circuit Diagram Arduino Hardware Details Software Details Benefits Of Project Applications Future Scope

INTRODUCTION An alcohol sensor is being used to detect presence of alcohol in the inner atmosphere of a car.  The sensor detection activates the system that is programmed in Arduino controller which will trigger an alarm and a flash light in order to keep driver in conscious state.  Engine will not start until alcohol sensor senses the absence of alcohol in inner atmosphere of a car. 

LITERATURE REVIEW World Health Organization’s , first ever Global Status Report on Road Safety reveals that 90% of deaths on the world's roads occur in low and middle- income countries (21.5 and 19.5 per lakh of population, respectively) though they have just 48% of all ed vehicles.  India has the second largest road network in the world with over 3 million km of roads of which 60% are paved. These roads make a vital contribution to the India's economy. According to a government report, road accidents in India killed 1,34,000 people in 2010 (an average of 336 a day). 

Accidents due to drunken driving are a major problem in India. The problem is unrecognized and hidden due to lack of good quality research data.  A study conducted by Alcohol & drug Information Centre (AIDC), India revealed that around 40% of the road accidents have occurred under the influence of alcohol. Young male drivers are at a high risk of such accidents.  Though some efforts are being taken to reduce the Road Accidents due to drunken driving, considering the gravity of the situation it is important to change strategies and mechanisms with foresight and effective implementation. 

BLOCK DIAGRAM

DESCRIPTION The functional block diagram of the Alcohol Detection With Vehicle Control system which is shown in the figure, mainly divided in to three main sections as follows.  Sensor output section: The MQ-3 alcohol sensor contains a kind of polymer which on heats changes its resistance according presence of alcohol in a car. It sends analog signals to the microcontroller in the form of several values according to intensity of alcohol.  The Microcontroller section: In this section the microcontroller AT-MEGA 328P receives the analog signal that comes from alcohol sensor via inbuilt Analog to Digital Convertor (ADC).

The microcontroller processes the input data from sensor according to coding developed by the in ARDUINO software.   The Display & Controlling section: This section mainly consists of 16x2 LCD display and the mainly controlling action of the circuit. According to the alcohol detected in earlier section the microcontroller sets the condition as per program by . If alcohol is present in a car, then the microcontroller sends the message ” ALCOHOL DETECTED” & prints sensor value on the LCD display and it controls the car ignition system using relay driver which is connected to microcontroller and also sounds the pizeo Buzzer. It glows respective LED as per the state detected by the microcontroller.

LCD 16X2 DISPLAY 1.Now a days many LCD modules are available which have built-in drivers for LCD and interface them to microcontroller and microprocessor system. 2.They available in 16x2,20x2,20x4,40x2 size. 3.The pin are:Vss=ground. Vcc=+5v Vee=Used for LCD contrast. RS=0:Data is selected. RS=1:Command is selected. R/W=1:for reading. R/W=0:for writing. E=enable. D0 to D7=8bit data bus

VOLTAGE REGULATOR IC 7805

o 7805 is a voltage regulator integrated circuit. o It is a member of 78xx series of fixed linear voltage regulator ICs. o The voltage source in a circuit may have fluctuations and would not give the fixed voltage output. o The voltage regulator IC maintains the output voltage at a constant value. o The xx in 78xx indicates the fixed output voltage it is designed to provide. o 7805 provides +5V regulated power supply. Capacitors of suitable values can be connected at input and output pins depending upon the respective voltage levels.

ATMEGA 328P High Performance, Low Power AVR® 8-Bit Microcontroller  Advanced RISC Architecture  131 Powerful Instructions – Most Single Clock Cycle Execution  32 x 8 General purpose working  23 Programmable I/O Lines  28-pin PDIP, 32-lead TQFP  Operating Voltage: 1.8 - 5.5V  Temperature Range: -40°C to 85°C  Speed Grade: 0 - 20 MHz @ 1.8 - 5.5V 

PIN CONFIGURATION OF ATMEGA 328P

Port B (PB7:0) XTAL1/XTAL2/TOSC1/TOSC2 & Port D (PD7:0) : Port B & Port D are 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit).  Port C (PC5:0): Port C is a 7-bit bi-directional I/O port with internal pull-up resistors (selected for each bit).  PC6/RESET: If the RSTDISBL Fuse is programmed, PC6 is used as an I/O pin.  AVcc: AVcc is the supply voltage pin for the A/D Converter, PC3:0, and ADC7:6.  AREF:AREF is the analog reference pin for the A/D Converter.  ADC7:6 (TQFP and QFN/MLF Package Only) : In the TQFP and QFN/MLF package, ADC7:6 serve as anaputs to the A/D converter. 

ULN 2003 ULN 2003A is a high-voltage, high-current Darlington transistor arrays. Each consists of seven npn Darlington pairs.  500-mA-Rated Collector Current(Single Output)  High-Voltage Outputs . . . 50 V  Output Clamp Diodes  Inputs Compatible With Various Types of Logic  Relay-Driver Applications 

MQ 3 GAS SENSOR MQ-3 is semiconductor sensor for Alcohol.  Sensitive material of MQ-3 gas sensor is SnO2, which with lower conductivity in clean air. When the target alcohol gas exist, The sensor’s conductivity is more higher along with the gas concentration rising. 



MQ-3 gas sensor has high sensitity to Alcohol, and has good resistance to disturb of gasoline, smoke and vapor. The sensor could be used to detect alcohol with different concentration, it is with low cost and suitable for different application.

5V DOUBLE POLE RELAY 92/8 gold silver alloy on silver palladium type is suitable for low level switching application.  Small size and light weight can provide high density P.C. Board mounting.  2.54gmm Terminal Pitch.  Low Coil Power Consumption of GS-T Type and high Coil Power Consumption of GS-D type are available to meet ’s selection.  Employment of suitable plastic materials to be applied to high temperature and various chemical solution.  Plastic epoxy resin sealed type for washing . 

DC MOTOR When the first start up, they draw a lot more current, up to 10x more.  If you “stall” them (make it so they can’t turn), they also draw a lot of current  They can operate in either direction, by switching voltage polarity  Usually spin very fast: >1000 RPM  To get slower spinning, need gearing 

BUZZER 

The buzzer acts as an alarm in the circuit which is used to keep the driver in a conscious state when he or she has consumed alcohol the buzzer used here is a piezo circuit that produces a sharp sound when provided with a suitable amount of voltage.

SOFTWARE ARDUINO 1.0.5-r2 The Arduino development environment contains a text editor for writing code, a message area, a text console, a toolbar with buttons for common functions, and a series of menus. It connects to the Arduino hardware to programs and communicate with them.

FLOWCHART:-

START Initialize gas pin to pin AN0 as input, relay1 to pin 10 as output port, SAFELED to pin 7 as output port, buzzer to pin 6 as output port Initialize library for 16*2 LCD display Read the analog sensor value

Sensor value/2

Set LCD cursor at position (0,1)

Print sensor value to LCD

A

A

Add delay of 250 ms

Is sensor value ≥350 ?

NO

NO

Is Sensor value ≤120?

YES Print “ALCOHOL DETECTED” on LCD Make relay1 and SAFELED pins to high

YES

Play the Buzzer

Add delay

Print “ALCOHOL ABSENT”,Make relay1 and SAFELED pin to low state Stop Buzzer

STOP

BENEFITS OF PROJECT Almost road traffic deaths could be prevented every year.  Easy installation.  Regular servicing would help curbing vehicle pollution. 

APPLICATIONS Helpful for private organizations and police.  RTO can use this system for curbing vehicle pollution.  "Alcohol Detection System in Vehicles" provides an automatic safety system for vehicles. 

CONCLUSION This paper gives a detailed concept about ALCOHOL DETECTION WITH VEHICLE CONTROL by the use of sensors, microcontroller, etc. These unit scan because and installed on public transport vehicle and on heavy duty vehicles, for industries, schools and in college’s uses.  The project “ALCOHOL DETECTION WITH VEHICLE CONTROL” has been successfully designed and has been developed by using integrating features of all the hardware components used. Presence of every module has been reasoned out and placed carefully thus contributing to the best working of the unit. 

FUTURE ASPECTS The system can be further advanced by interfacing a GPS in the system that will inform about the position of the car; thus provides easy location.  The car using alcohol and proximity sensor can be increased in side for sideways protection and easy alcohol detection. Since the blood pressure changes due alcohol consumption instead of using alcohol sensor we can monitor the blood pressure or heart beat by different sensors thus it can lead to a better method. 
