ABB India Limited LV Motors

FRSM - 60 Effective from 15.06.2015

Price List

(Superseding FRSM-59C dated 01.03.2015)

1. Standard Totally Enclosed Fan Cooled (TEFC) Squirrel Cage Motors (Enclosure Conforming to protection IP55 ) Horizontal Foot Mounted Induction motors, continuously rated suitable for operation on 415±10%, 3-Phase, 50Hz±5%, AC Supply with class 'F' insulation for an ambient of 50 Deg.C and altitude less than 1000M above MSL and conforming to IS:325-1996

Two Pole Output kW 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00 37.00 45.00 55.00 75.00 90.00

Four Pole H.P 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00 50.00 60.00 75.00 100.00 125.00

Frame size M2BA71A2 M2BA71B2 M2BA80A2 M2BA80B2 M2BA90S2 M2BA90LB2 M2BA100LB2 M2BA132SA2 M2BA132SBB2 M2BA132SC2 HX+160MLB2 HX+160MLD2 HX+160MLE2 HX+180MLB2 HX+200MLB2 HX+200MLC2 HX+225SMC2 HX+250MB2 HX+280SMB2 HX+280SMC2

Price (Rs) 9975 11025 11393 12495 14459 18501 22700 37328 38367 59756 67032 78603 101871 113558 168683 206168 264705 356433 463932 537800

3000 rpm Ex. Duty (Rs) 499 551 570 625 723 925 1135 1866 1918 2988 3352 3930 5094 5678 8434 10308 13235 17822 23197 26890

Output kW 0.25 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00 37.00 45.00 55.00 75.00 90.00

Price (Rs) 11351 11571 12464 12737 14385 15813 20150 24098 36803 40971 66150 78278 82299 112403 146412 158981 247737 333900 425565 482895

1000 rpm Ex. Duty (Rs) 568 579 623 637 719 791 1007 1205 1840 2049 3308 3914 4115 5620 7321 7949 12387 16695 21278 24145

Output KW 0.09 0.12 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00 37.00 45.00

Six Pole Output KW 0.18 0.25 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00 37.00 45.00 55.00

H.P 0.33 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00 50.00 60.00 75.00 100.00 125.00

Frame size M2BA71A4 M2BA71B4 M2BA80A4 M2BA80B4 M2BA90S4 M2BA90L4 M2BA100LA4 M2BA112M4 M2BA132S4 M2BA132M4 HX+160MLB4 HX+160MLD4 HX+160MLE4 HX+180MLB4 HX+180MLC4 HX+200MLC4 HX+225SMB4 HX+225SMC4 HX+250MB4 HX+280SMB4 HX+280SMC4

Price (Rs) 10185 10532 11729 11834 13482 14762 19499 24969 34398 40100 63504 64218 79800 107552 119952 161742 202965 240786 330645 423360 491159

1500 rpm Ex. Duty (Rs) 509 527 586 592 674 738 975 1248 1720 2005 3175 3211 3990 5378 5998 8087 10148 12039 16532 21168 24558

Frame size M2BA71A8 M2BA71B8 M2BA90L8 M2BA90LB8 M2BA100LA8 M2BA100LB8 M2BA112MA8 M2BA132S8 HX+160MLB8 HX+160MLD8 HX+160MLE8 HX+180MLA8 HX+180MLB8 HX+200MLC8 HX+225SMB8 HX+225SMC8 HX+250MB8 HX+280SMB8 HX+280SMC8

Price (Rs) 11582 11813 13787 15120 18522 22607 26135 34619 54411 66150 83895 109148 114881 162288 209475 252693 339791 434385 503843

750 rpm Ex. Duty (Rs) 579 591 689 756 926 1130 1307 1731 2721 3308 4195 5457 5744 8114 10474 12635 16990 21719 25192

Eight Pole H.P 0.25 0.34 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00 50.00 60.00 75.00

Frame size M2BA71A6 M2BA71B6 M2BA80A6 M2BA80B6 M2BA90L6 M2BA90LB6 M2BA100L6 M2BA112M6 M2BA132MA6 M2BA132MC6 HX+160MLC6 HX+160MLD6 HX+160MLE6 HX+180MLC6 HX+200MLB6 HX+200MLC6 HX+225SMC6 HX+250MB6 HX+280SMB6 HX+280SMC6

H.P 0.12 0.16 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00 50.00 60.00

2. M2000 ENERGY EFFICIENT MOTORS Standard TEFC Squirrel Cage Motor Suitable for Ambient temperature of 50 Deg. Centigrade, Horizontal foot mounting and conforming to IS:325-1996

Two Pole Output KW 110.0 125.0 132.0 150.0 160.0 180.0 200.0 250.0 315.0

Four Pole H.P 150.00 170.00 180.00 200.00 220.00 240.00 270.00 340.00 425.00

Frame size M2BA315SMA2 M2BA315SMB2k M2BA315SMB2 M2BA315MLA2k M2BA315MLA2 M2BA315MLC2k M2BA315MLC2 M2BA355SMA2 M2BA355MLA2

Price (Rs) 712215 836220 875165 925880 957968 1009670 1124550 1248030 1359120

3000 rpm Ex. Duty (Rs) 35611 41811 43758 46294 47898 50483 56228 62402 67956

Output KW 110.0 125.0 132.0 150.0 160.0 180.0 187.0 200.0 225.0 250.0 260.0 315.0 355.0

H.P 100.00 125.00 150.00 170.00 180.00 220.00 240.00 270.00 340.00 376.00 425.00

Frame size M2BA315SMA6 M2BA315SMB6 M2BA315SMC6 M2BA315SMC6k M2BA315MLC6 M2BA315MLD6 M2BA355SMB6k M2BA355SMB6 M2BA355MLA6 M2BA355MLB6K M2BA355MLB6

Price (Rs) 598658 752787 839003 913973 979577 1033043 1149362 1163138 1252440 1510000 1983398

1000 rpm Ex. Duty (Rs) 29933 37639 41950 45699 48979 51652 57468 58157 62622 75500 99170

Output KW 55.0 75.0 90.0 110.0 132.0 150.0 160.0 180.0 200.0 225.0 250*

Six Pole Output KW 75.0 90.0 110.0 125.0 132.0 160.0 180.0 200.0 250.0 280.0 315.0

H.P 150.00 170.00 180.00 200.00 220.00 240.00 250.00 270.00 300.00 340.00 350.00 425.00 475.00

Frame size M2BA315SMA4 M2BA315SMB4k M2BA315SMB4 M2BA315MLA4k M2BA315MLA4 M2BA315MLB4k M2BA315MLB4 M2BA315MLC4 M2BA355SMA4k M2BA355SMA4 M2BA355SMA4h M2BA355MLA4 M2BA355MLB4

Price (Rs) 624015 714525 734486 791595 859425 917280 949253 1046273 1070528 1153215 1153215 1320795 1702260

1500 rpm Ex. Duty (Rs) 31201 35726 36724 39580 42971 45864 47463 52314 53526 57661 57661 66040 85113

Frame size M2BA315SMA8 M2BA315SMB8 M2BA315SMC8 M2BA315MLC8 M2BA355SMA8 M2BA355MLA8k M2BA355MLA8 M2BA355MLB8i M2BA355MLB8 M2BA355MLB8h M2BA355MLB8k

Price (Rs) 613988 766238 864360 915075 1117935 1199520 1231493 1319693 1347255 1910633 2113493

750 rpm Ex. Duty (Rs) 30699 38312 43218 45754 55897 59976 61575 65985 67363 95532 105675

Eight Pole

Type Three phase squirrel cage induction motor Enclosure Totally enclosed fan cooled Voltage +/- variation 415+/- 10% Frequency +/- variation 50Hz +/- 5% Combined +/- variation 10% ( Absolute Sum) Mounting Reference As per IS 4691 Frame Dimensions As per IS 1231 : IS 2223 Altitude Upto 1000 M Relative Humidity Upto 100% Degree of Protection IP55 Class of Insulation Class F Ambient Temperature/ Temperature 50 Deg Rise C/ 70 Deg C Duty S1 / Continuous Position of terminal box Top at drive end Connection / No. of leads Upto 2HP- STAR / 3 Leads > 2 HP- DELTA / 6 Leads Direction of Rotation Bi-directional Grease Type Lithium complex grease Greasing arrangement Online greasing arrangement for frame 250 and above Cooling IC411 (TEFC) Paint Polyurethane( Shade: Munsell Blue)

H.P 75.00 100.00 125.00 150.00 180.00 200.00 220.00 240.00 270.00 300.00 340.00

* This rating is suitable for class F temp rise only

The M2000 Series M2000 motors have been engineered for the twin objective of high power to weight ratio and efficiency at a designed ambient of 50Deg.C. The performance of M2BA' is well ahead of relevant IEC & IS standards resulting in lower consumption, reduced operational costs and ultimately faster returns on investment. M2BA motors have a wide range of applications including windmill. Heavy Duty Design The electrical and mechanical design of 'M2BA' motors offer high performance values in all the mounting arrangements, protection class and in all operations. M2BA' motors have withstood the test of time and are established for reliability in stringent operating conditions like thermal power plants worldwide.

Ex d

Totally Enclosed Fan Cooled (TEFC) Squirrel Cage Flame Proof Motors Enclosure conforming to protection IP55 as per IEC: 60034-5:2006, Horizontal foot mounted (B3) induction motors, continuously rated suitable for , operation on 415V+/-10%, 3 phase, 50Hz+/-5%A.C supply with class ’F’ insulation for 50 Deg.C ambient temperature in Gas Group IIA & IIB and altitude less than 1000M above MSL and conforming to IS/IEC 60079-1 (2007)

Two Pole Output kW 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00 37.00

Four Pole H.P 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00 50.00

Frame size JHX71C2 JHX71D2 JHX80C2 JHX80D2 JHX90SLC2 JHX90SLD2 JHX100LB2 JHX132SMB2 JHX132SMC2 JHX132SME2 JHX160MLB2 JHX160MLD2 JHX160MLE2 JHX180MLB2 JHX200MLB2 JHX200MLC2

Price (Rs) 21389 24035 24812 27668 30870 38588 49172 69794 77175 109694 135608 164273 187425 221550 300300 388500

3000 rpm Ex. Duty (Rs) 1069 1202 1241 1383 1544 1929 2459 3490 3859 5485 6780 8214 9371 11078 15015 19425

Output kW 0.25 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00 30.00

H.P 0.33 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00

Frame size JHX80D6 JHX80D6 JHX80E6 JHX90SLD6 JHX90SLE6 JHX100LB6 JHX112MB6 JHX132SMC6 JHX132SME6 JHX160MLC6 JHX160MLD6 JHX160MLE6 JHX180MLC6 JHX200MLB6 JHX200MLC6

Price (Rs) 24476 24581 25137 29211 30314 43764 50715 67358 81585 126231 146633 154350 208635 259350 281400

1000 rpm Ex. Duty (Rs) 1224 1229 1257 1461 1516 2188 2536 3368 4079 6312 7332 7718 10432 12968 14070

Output kW 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00

Six Pole Output kW 0.25 0.37 0.55 0.75 1.10 1.50 2.20 3.70 5.50 7.50 9.30 11.00 15.00 18.50 22.00

H.P 0.33 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00 25.00 30.00 40.00

Frame size JHX71B4 JHX71C4 JHX80D4 JHX80E4 JHX90SLD4 JHX90SLE4 JHX100LB4 JHX112MB4 JHX132SMC4 JHX132SME4 JHX160MLB4 JHX160MLD4 JHX160MLE4 JHX180MLB4 JHX180MLC4 JHX200MLC4

Price (Rs) 20948 21053 23258 24255 27668 29988 38252 48510 66696 76073 116309 122703 149499 169050 202650 273000

1500 rpm Ex. Duty (Rs) 1047 1053 1163 1213 1383 1499 1913 2426 3335 3804 5815 6135 7475 8453 10133 13650

Frame size JHX90SLA8 JHX90SLD8 JHX100LA8 JHX100LB8 JHX112MA8 JHX132SMB8 JHX160MLB8 JHX160MLD8 JHX160MLE8 JHX180MLA8 JHX180MLB8 JHX200MLC8

Price (Rs) 28665 31196 37706 44100 52584 69458 112455 129318 157658 202650 213150 288750

750 rpm Ex. Duty (Rs) 1433 1560 1885 2205 2629 3473 5623 6466 7883 10133 10658 14438

Eight Pole

Note:- Special Features given below shall not be applicable for Flame Proof Motors. ABB reserves the right to change the price, design, technical specification and dimensions without prior notice

H.P 0.50 0.75 1.00 1.50 2.00 3.00 5.00 7.50 10.00 12.50 15.00 20.00

Additional charges for specific requirements Frame 71-355 of TEFC Sl no

Description for extra features

Extra charge

1.0 Shaft 1.1 Non standard single/ double shaftextension, diameter of shaft being same or less as standard. kindly refer to us for following: a) Dia more than standard b) Length more than twice of the standard 1.2 Shaft material - EN24

10% of LP

2.0 Mounting Standard flange or face mounting ( B14, B5, V1, V18 & V19) or foot cum flange/ face mounting( B35, B34, V14, V36) ( for frames 225 and above in TEFC please refer to us.) 2.1 Upto frame 160 2.2 Frame 180 and above

3% of LP 5% of LP

3.0 3.1 3.11 3.12 3.2 3.21 3.3

Non standard paint shadeas per IS 5 Epoxy Epoxy 631/632 Paint shade other than munshell blue and 631/632 shade Non-Epoxy Paint shade other than munshell blue and 631/632 shade Paint Thickness Rust Coat Primer + PU paint is 70 microns For Additional Thickness upto 150 micros For thickness > 150 upto 215microns

4.0 Epoxy gel coat on winding overhang 5.0 Insulation class "H" 6.0 Vaccum pressure impregnation 7.0 Stainless steel hardware 8.0 Non standard nominal voltage 220-550 V with frequency 50 HZ and 60 HZ

5 % of LP

3% of LP 5% of LP 5% subject to max of RS 6500/-nett 4% of LP 6% of LP 3% of LP 10% on LP 5% on LP Rs 500/-nett

3% of LP

9.0 Multi speed motors Dual speed motor upto 8 pole (to be taken on higher frame) Tapped winding is indicated by speed ratio 1:2( e.g 4/8, 2/4) Two winding e.g. 4/6, 6/8

10.0 Crane duty motor( SCR) ( KHX motors) 11.0 11.1 11.2 11.3 11.4

Enclosure/ Types Ring frame (Textile motors){ RHX motors) Non sparking Type "n"motors ( NHX motors) Increased safety Type "e" motors ( IHX motors) IP56

12.5% on LP for Tapped wdg 20% on LP for Two wdg. 10% on LP ( frame wise)

5% on LP 7.5% on LP 15% on LP 5% on LP

12.0 Space Heaters 12.1 Frame 160 12.2 Frame 180-355 frame

Rs 1200/-nett Rs 2650/-nett

13.0 PTC thermistors (without relays) 13.1 3 no's 13.2 6 no's

Rs 2150/-nett Rs 4300/-nett

14.0 RTD ( frame 160-355) 14.1 3 no's 14.2 6 no's

Rs 4000/-nett Rs 8000/-nett

15.0 BTD( Frame 225-355) 2 no's simplex

Rs 7500/-nett

16.0 Cable glands 16.1 Single compression cable gands Frame 71-132 Frame 160-225 Frame 250-355 16.2 Double compression cable gland Frame 71-132 Frame 160-225 Frame 250-355

Rs 400/-nett Rs 1000/-nett Rs 1300/-nett Rs 800/-nett Rs 2000/-nett Rs 2500/-nett

17.0 Forced cooling arrangement Frame 200- 225 Frame 250-280 Frame 315 Frame 355 18 Roller Bearing Frame 160- 200 Frame 225- 250 Frame 280-315 Frame 355- 400 19.0 Testing 19.1 Routine Test per motor Frame 71-132 Frame 160-225 Frame 250-355 19.2 Type test per rating on one motor Frame 71-132 Frame 160-225 Frame 250-280 Frame 315-355 19.3 First Numeral IP55 Test Frame 71-200 19.4 Second Numeral IP55 Test Frame 71-355

Rs 20000/-nett Rs 25000/-nett Rs 31000/-nett Rs 35000/-nett Rs 1500/-nett Rs 3000/-nett Rs 5000/-nett Rs 9000/-nett

Rs 1200/-nett Rs 2400/-nett Rs 3600/-nett Rs 5000/-nett Rs 7500/-nett Rs 10000/-nett Rs 15000/-nett Rs 5000/-nett Rs 3000/-nett

& Conditions 1. Taxes & Duties: The list price is exclusive of Excise Duties, Sales Tax and any other Central or Local Taxes, Octroi Duty and other levies. These will be charged extra as the rates ruling on the date of supply. Excise duty shall be inclusive of E. Cess. and H Cess 2. Delivery: Prices are Ex works/Ex- Godown basis 3. Conditions of Sale: The price list is subject to our Standard 'General and Conditions' of Tender and sale and the prices are subject to revision without prior notice.

4. General: a) Due to improvement being made from time to time, Frame sizes indicated above are provisional and subject to change without notice. b) For more details, please us.
