INITIAL ELECTRICAL ASSESSMENT REPORT (EAR)
Factory Name:
4 YOU CLOTHING LTD
Address: Assessor:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh Bureau Veritas
Date:
27 May 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 1/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Introduction to the Report The following report contains a site profile and summary of non-conformities identified during an onsite assessment commissioned by the Alliance for Bangladesh Worker Safety (Alliance) and conducted by a third-party Qualified Assessment Firm (QAF). The assessment was conducted against the Alliance for Bangladesh Worker Safety Assessment Protocols (APs) and Fire Safety and Structural Integrity Standard, which is harmonized with the factory assessment guidelines developed by Bangladesh University of Engineering and Technology (BUET) for the Bangladesh National Tripartite Plan of Action (NTPA). The goal of the Alliance process is to provide clear and practical technical requirements by which Bangladeshi Ready Made Garment (RMG) Factories producing for Alliance may be consistently and fairly evaluated for fire, structural, and electrical safety in a non-duplicative manner. Each assessment will prompt action plans that will be used by RMG factories to systematically and sustainably improve safety conditions for garment workers. Beyond tracking and reporting on action steps taken in a transparent manner, the Alliance organization and its will seek to further factory improvements through technical assistance, training, implementation for functional Worker Committees, and in some cases financial assistance and wage for workers if factories are closed for remediation. The contents of the report do not constitute a guarantee of compliance with the applicable laws, the Alliance Standard or the absolute or continued safety against fire, electrical and/or structural integrity issues that may lead to injury or loss of life. The report is designed to provide a non-exhaustive summary of risk issues, based on a limited sampling and duration of time onsite by the named QAF. Neither the QAF nor the Alliance can certify or guarantee the quality, outcome, or effectiveness of actions taken in response to the report. For more information and report please go to: www.bangladeshworkersafety.org.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 2/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
GENERAL INFORMATION General Information Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Country:
Bangladesh
Province:
Dhaka
City:
Dhaka
Zip Code:
1216
Audit Duration:
1 Days
Re-Audit:
Re-Audit After 0 Months
Draft Report Date :
05-28-2014
Final Report Date :
06-23-2014
Are all action items from previous assessment complete? :
N/A
Buildings in Complex :
There is one building on the factory premises. The building is named as: 1) Ten story RCC Main Production Building.
Is the building(s) owned or rented by the Factory?:
Owned
Number of Building Levels (Stories) :
1) Ten story RCC Main Production Building: Building height (Highest occupied floor level): 28.05 m or 92.00 ft [Height up to roof: 31.10 m or 102.00 ft], Stories above grade: 10, Stories below grade: 0, Occupied levels: 10.
Approximate Building Area (SF) :
Total area: 78342.5 SF. 1) Ten story RCC main production building: 78342.5 SF (Ground floor: 7834.25 SF, 1st floor: 7834.25 SF, 2nd floor: 7834.25 SF, 3rd floor: 7834.25 SF, 4th floor: 7834.25 SF, 5th floor: 7834.25 SF, 6th floor: 7834.25 SF, 7th floor: 7834.25 SF, 8th floor: 7834.25 SF, 9th floor: 7834.25 SF).
Date of Building Construction :
Factory personnel informed the date of construction as follows: 1) Ten story RCC Main Production Building: Started in December-1995 but no record of a finish date.
Date of Last Building Renovation/Addition :
Factory personnel informed the date of last building renovation as follows: 1) Ten story RCC Main Production Building: Renovation work is on going.
Ancillary Structures in Complex :
There is no ancillary structure on factory premises.
Approximate Ancillary Structures Area (SF) :
There is no ancillary structure on factory premises.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 3/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Number of Occupants :
Total number of occupants: 1640. 1) Ten story RCC Main Production Building: 1640 (Ground floor: 60, 1st floor: 210, 2nd floor: 212, 3rd floor: 230, 4th floor: 80, 5th floor: 235, 6th floor: 90, 7th floor: 218, 8th floor: 225, 9th floor: 80).
Provide brief description of the electrical system for each building.:
Source: DESCO: Transformer-1 (1000 KVA), Generator-3, (650 KVA, 110 KVA, 200 KVA), Change Over Switch(COS)-4, Low Tension (LT) -1, Main Distribution Board (MDB)-2, Distribution Board (DB)-10, Sub Distribution Board (SDB)-5.
Physical location of Substation? :
Substation located in Ground Floor of the building.
What equipment/loads does the UPS serve? :
IPS serves fire alarm, emergency lighting and exit signage.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 4/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
ASSESSMENT FINDINGS Electrical System Information Question:
Are as-built electrical drawings indicating information such as and circuit locations throughout the building(s) available for review?
Priority Level:
High
Non-Compliance Level:
3
Description:
There are no proper working or “as-built” electrical diagrams of the main distribution circuit or floor level circuits connecting electrical loads (machines/lights/cooling system, etc.) available on site.
Source of Findings:
Document Review: No as-built electrical drawings.
Suggested Plan of Action:
Have a qualified electrical engineer develop an as-built single line diagram detailing key components and capacity of the electrical system.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.7
Electrical System Maintenance Question:
Is the electrical switchgear and boards inspected on an annual basis to ensure that the equipment is installed in accordance with the listed ratings?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The electrical switchgear and boards are not inspected on an annual basis.
Source of Findings:
Document Review: No annual inspection record for electrical switchgear and boards.
Suggested Plan of Action:
Inspect electrical switchgear and boards on an annual basis to ensure that the equipment is in good working condition.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.13.8 Electrical Inspections
Question:
Are thermographic scans of electrical equipment completed at least every three years?
Priority Level:
Medium
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 5/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Non-Compliance Level:
3
Description:
Thermographic scans of electrical equipment are not properly completed.
Source of Findings:
Document Review: No thermographic scans for electrical equipment.
Suggested Plan of Action:
Complete thermographic scans at least on a three year cycle. Thermographic scans should be completed in accordance with the Standard for Infrared Inspection of Electrical Systems & Rotating Equipment and NFPA 70B or a comparable standard.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.13.8 Electrical Inspections
Question:
Transformers do not contain harmful substances such as PCBs.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
No testing results found to ensure that transformers do not contain harmful substances.
Source of Findings:
Document Review: No testing results found to ensure that transformers do not contain harmful substances.
Suggested Plan of Action:
Consult with your transformer manufacturing company, and ensure transformers do not contain any harmful substances by having tests run and reviewing the results.
Suggested Deadline Date:
23 Jul 2014
Standard:
Not Applicable
Question:
A transformer oil analysis is routinely completed on main service transformers.
Priority Level:
Low
Non-Compliance Level:
3
Description:
No documentation on transformer oil analysis was found.
Source of Findings:
Document Review: A transformer oil analysis report was not found.
Suggested Plan of Action:
Complete an oil analysis on applicable transformers at appropriate intervals based on voltage and power.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.13.8 Electrical Inspections
Electrical System Conditions
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 6/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Underground service cables are laid in conformity with the requirements of concealed wiring.
Priority Level:
High
Non-Compliance Level:
3
Description:
Underground service cables are not laid in conformity with the requirements for concealed wiring. Location: Substation Room, Ground Floor.
Source of Findings:
Photograph: Improper wiring of underground service cables.
Suggested Plan of Action:
Ensure underground cables for electrical distribution on the premises/garden/compound of the building are encased in GI or PVC pipes and laid in earth trenches of sufficient depth as per BNBC 2.5.7.2.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.10 Service Entry
Question:
The substation room has the required fire rating/protection and is physically separated from the remainder of the building.
Priority Level:
High
Non-Compliance Level:
3
Description:
The substation room does not have fire rating protection and is not physically separated from the remainder of the building.
Source of Findings:
Photograph: Substation room does not have fire rating protection and is not physically separated.
Suggested Plan of Action:
Provide adequate fire rating protection for substation room, and make it separate from rest of the building.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 3 Section 3.4.2.1.4
Question:
No circuits are drawn for loads without the incorporation of a overcurrent protection device (circuit breaker).
Priority Level:
High
Non-Compliance Level:
3
Description:
Circuits are drawn for loads without the incorporation of an overcurrent protection device (circuit breaker). Location: DB-1/8th Floor, DB-1/3rd Floor, DB-1/1st Floor, DB-1/2nd Floor, DB-1/6th Floor, DB-1/4th Floor, DB-1/5th Floor, DB-1/7th Floor, DB-1/9th Floor, SDB-2/Ground Floor, SDB-4/Hydrant Room.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 7/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Source of Findings:
Photograph: No protection device.
Suggested Plan of Action:
Ensure overcurrent protection device (circuit breaker) for each and every load.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.9 Protection of Circuits
Question:
All metal in the building is connected to the building earthing/grounding system such as metal rebar in concrete, metal frame of building, or metal water pipe.
Priority Level:
High
Non-Compliance Level:
3
Description:
There is metal in the building that is not connected to the building earthing system. Location: Water pipe (GI), cable ladder throughout the building.
Source of Findings:
Visual Assessment: Not all metal in the building is connected to the building earthing.
Suggested Plan of Action:
Connect all metal in the building to the building earthing/grounding system, such as metal rebar in concrete, metal frame of building, or metal water pipe.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.10 Earthing
Question:
Shielding or additional insulation is provided for wiring exposed to external heat sources.
Priority Level:
High
Non-Compliance Level:
2
Description:
Additional insulation is not provided for wiring that is exposed to external heat sources. Location: Boiler Room, Ground Floor.
Source of Findings:
Photograph: Inadequate insulation for the wiring.
Suggested Plan of Action:
Provide shielding and/or additional insulation for wiring exposed to external heat sources.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.4.2 External heat sources.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 8/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Do switchboards and/or distribution boards have a minimum clearance of 1 m (39 in) in front?
Priority Level:
High
Non-Compliance Level:
1
Description:
Distribution boards do not have adequate clearance. Location: DB-1/6th Floor, DB -1/8th Floor, DB -1/9th Floor.
Source of Findings:
Photograph: Inadequate clearance in front of distribution boards.
Suggested Plan of Action:
Provide clearance of at least 1m (39in.) in front of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standards Part 10 Section 10.7 Main Switch, Switchboards and Metal Clad Switchgear
Question:
Power and telecommunication or antenna cables are led in separately.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Power cables and telecommunication or antenna cables are not led in separately. Location: All cable trays where power cables and telecommunication or antenna cables are routed together.
Source of Findings:
Photograph: Power and telecommunication cables are not separated.
Suggested Plan of Action:
Lead telecommunication or antenna cables separately to the main point of service. Power and telecommunication cables must have a separate entrance.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.10 Service Entry
Question:
Do switchboards and/or distribution boards have capacity information labels?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
No capacity information labels are provided for any of the distribution boards. Location: All distribution boards.
Source of Findings:
Photograph: No capacity information labels provided on distribution boards.
Suggested Plan of Action:
Provide capacity information labels (maximum current rating, number of circuit breakers, etc.) for switchboards and/or distribution boards.
Suggested Deadline
09 Jul 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 9/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Date: Standard:
Alliance Standard Part 10 Section 10.7 Main Switch, Switchboards And Metal Clad Switchgear and 10.13.7 Inspection of the Installation
Question:
Are switchboards and/or distribution boards provided with physical means to prevent the installation of more over current devices than that number for which the board was designed, rated, and listed.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Distribution boards are not provided with a physical means to prevent the installation of more over current devices than that number for which the board was designed, rated and listed. Location: All distribution boards.
Source of Findings:
Photograph: No means to prevent the installation of more over current devices.
Suggested Plan of Action:
Ensure distribution boards are provided with a physical means to prevent the installation of more over current devices than that number for which the board was designed, rated, and listed following NFPA 70 Section 408.54.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.7 Main Switch, Switchboards and Metal Clad Switchgear
Question:
Cable ts are through porcelain/PVC connectors with PIB tape wound around t.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Improper cable ts. Location: All distribution boards.
Source of Findings:
Photograph: Improper cable ts.
Suggested Plan of Action:
Ensure cable ts are through porcelain/PVC connectors with PIB tape wound around the ts.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.8.4 Cable ts
Question:
The substation room has adequate illumination levels.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
The substation room has inadequate illumination levels.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 10/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Source of Findings:
Photograph: Improper illumination in transformer room.
Suggested Plan of Action:
Provide additional light fixtures to increase illumination levels as provided for in the BNBC.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.13.7.1 Inspection of Substation Installations.
Question:
Are all internal components of switchboards and/or distribution boards properly concealed (No missing circuit breaker or knockout covers)?
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Internal components of distribution boards are not properly concealed. Location: DB-1/8th Floor, MDB-2/Substation room, LT /Substation room, DB-1/1st Floor, DB-1/2nd Floor, DB-1/6th Floor.
Source of Findings:
Photograph: Internal components are not properly concealed.
Suggested Plan of Action:
Provide covers or blanks to conceal all live internal components of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.3.9 Sub-Distribution Boards
Question:
Stranded conductors having a nominal cross-sectional area 6mm2 or greater are provided with cable sockets. Conductors below 6 mm2 without cable sockets, all strands at the exposed ends are soldered together or are crimped using suitable sleeve or ferrules.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Cable sockets are not provided for stranded conductors. Location: All distribution boards (except LT and all MDBs).
Source of Findings:
Photograph: No cable sockets.
Suggested Plan of Action:
Provide cable sockets for stranded conductors with a nominal cross-sectional area of 6 mm2 or greater and conductors below 6 mm2 without cable sockets, all strands at the exposed ends are to be soldered together or are crimped using suitable sleeve or ferrules.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.8.3 Cable Ends
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 11/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Is all electrical wiring/cable properly terminated at its point of termination (No un-terminated wires, lugs are provided at terminals, etc)?
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Electrical cables are not properly terminated. Location: DB-1/4th Floor, DB-1Finishing/6th Floor, Sewing Machine/7th Floor, Sewing Machine/8th Floor.
Source of Findings:
Photograph: Un-terminated wires.
Suggested Plan of Action:
Ensure all electrical wiring/cables are properly terminated at their point of termination.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.9.2 Wiring of Sub-distribution Boards
Question:
Are lighting and receptacle (socket) circuits segregated?
Priority Level:
Medium
Non-Compliance Level:
1
Description:
Lighting and sockets are not separated. Location: Technical Room/7th Floor.
Source of Findings:
Photograph: Lighting and sockets are not separated.
Suggested Plan of Action:
Separate lighting and socket circuits at the noted locations. Have a qualified electrician separate the lighting and sockets into separate circuits.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.7.2
Question:
A wire/cable shaft is provided for the whole building. Wiring and cables are arranged in shaft for ease of inspection and maintenance.
Priority Level:
Medium
Non-Compliance Level:
1
Description:
A shaft for BBT system is available in the floor but a shaft for cable is not provided for the whole building.
Source of Findings:
Photograph: Cable shaft is not found.
Suggested Plan of Action:
Provide cable shaft for the whole building for ease of inspection and maintenance.
Suggested Deadline Date:
15 Sep 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 12/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Standard:
BNBC Part 8 Section 2.5.6.1
Question:
Electrical wiring and conduit is properly ed.
Priority Level:
Medium
Non-Compliance Level:
1
Description:
Electrical wiring and conduit are not properly ed. Location: Substation Room.
Source of Findings:
Photograph: Inadequate cable .
Suggested Plan of Action:
Provide adequate s for electrical wiring and conduit.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.2, 10.3.4.3, and 10.3.5
Question:
Signage indicating the prohibition of light fixtures without protective covers is installed at required locations.
Priority Level:
Low
Non-Compliance Level:
3
Description:
No signs to indicate the prohibition of light fixtures without protective covers are installed at the required locations. Location: Storage Area/Ground Floor.
Source of Findings:
Photograph: No signage indicating the prohibition of the installation of light fixtures without protective covers.
Suggested Plan of Action:
Ensure signage indicating the prohibition of light fixtures without protective covers is installed at required the locations.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standards Part 10 Section 10.15 Naked Lights
Question:
Required equipment and safety signage is posted within the room.
Priority Level:
Low
Non-Compliance Level:
2
Description:
Some equipment has required equipment signage but there is no safety signage in the substation room.
Source of Findings:
Photograph: No safety signage was found.
Suggested Plan of Action:
Required safety equipment and safety signage must be posted within the room.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 13/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.3.7, Section 10.7.3, and 10.13.7, NFPA 70 Chapter 1 Article 110.21, and Bangladesh Electricity Rules of 1937 Rule 46
Question:
Are electrical insulation mats provided in front of substation, switchboards and/or distribution boards?
Priority Level:
Low
Non-Compliance Level:
1
Description:
Electrical insulation mats are not provided in front of distribution boards. Location: DB-1 (4th Floor), SDB-2 (4th Floor), SDB -3 (6th Floor).
Source of Findings:
Photograph: No electrical graded insulation mats provided in front of distribution boards.
Suggested Plan of Action:
Provide electrical graded insulation mats in front of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.13.7 Inspection of the Installation.
Question:
Phase separators are provided between terminals on circuit breakers.
Priority Level:
Low
Non-Compliance Level:
1
Description:
Phase separators are not provided between terminals on circuit breakers. Location: DB-1-Finishing/6th Floor, DB-1/7th Floor, DB-1/8th Floor.
Source of Findings:
Photograph: No phase separators.
Suggested Plan of Action:
Install phase separators between terminal connections at the noted locations.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.1 Electrical Connections
Emergency Power System Question:
Is the generator room properly rated and physically separated from the remainder of the building?
Priority Level:
High
Non-Compliance Level:
3
Description:
Generator room is not properly rated and is not physically separated from the
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 14/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
remainder of the building. Source of Findings:
Photograph: Generator room is not rated and separated.
Suggested Plan of Action:
Ensure the generator room is properly rated and physically separated from the remainder of the building.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.8.4 Generator Room
Question:
Are emergency power switchboards, distribution boards, and circuits properly identified?
Priority Level:
High
Non-Compliance Level:
3
Description:
Emergency power distribution boards and circuits are not properly identified.
Source of Findings:
Visual Assessment: No identification of emergency DBs/CKTs.
Suggested Plan of Action:
Ensure proper identification of emergency power switchboards, distribution boards, and circuits.
Suggested Deadline Date:
25 Jun 2014
Standard:
NFPA 70 Chapter 7 Article 700.10 Wiring, Emergency System
Question:
Are cable trenches properly covered?
Priority Level:
High
Non-Compliance Level:
2
Description:
Cable trenches are not covered properly. Location: Generator Room, Ground Floor.
Source of Findings:
Photograph: There is no cable trench cover.
Suggested Plan of Action:
Provide a cover for cable trenches.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.13.7 Inspection of the Installation
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 15/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Is the generator frame earthing (grounding) provided at two separate points?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Generator frame earthing is only provided at single point.
Source of Findings:
Photograph: Inadequate generator frame earthing.
Suggested Plan of Action:
Provide two separate points earthing (grounding) for each generator.
Suggested Deadline Date:
21 Jul 2014
Standard:
Alliance Standard 10.8.2.2
Question:
Is the generator room appropriately sized in order to properly access the generator to perform routine maintenance activities?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The size of generator room is not appropriate.
Source of Findings:
Photograph: Inadequate generator room size.
Suggested Plan of Action:
Ensure that the generator room is appropriately sized in order to gain proper access to the generator to perform routine maintenance activities.
Suggested Deadline Date:
20 Aug 2014
Standard:
Alliance Standard Part 10 Section 10.8.4 Generator Room
Question:
Are inspection, maintenance, and testing procedures of the UPS being completed and documented?
Priority Level:
Low
Non-Compliance Level:
1
Description:
Inspection, maintenance and testing procedures of the IPS are performed by the supplier but documentation is not complete.
Source of Findings:
Photograph: Improper documentation found for IPS mantenance.
Suggested Plan of Action:
Establish an inspection testing and maintenance program for the Uninterruptible Power Supply (UPS) and/or Instant Power Supply (IPS) associated components. The program must be based on the following: (1) Manufacturer's recommendations (2) Manufacturer's instruction manuals (3) Minimum Requirements of NFPA 111 Chapter 8 (4) Minimum Requirements of NFPA 70B Chapter 28.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 16/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Suggested Deadline Date:
18 Aug 2014
Standard:
Alliance Standard Part 13 Section 13.11 NFPA 111 Chapter 8 NFPA 70B Chapter 28
Lightning Protection System Question:
The lightning protection ground terminals are bonded to the building or structure grounding.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The lightning protection ground terminals are not bonded to the building or structure grounding.
Source of Findings:
Visual Assessment: The lightning protection ground terminals are not bonded to the building or structure grounding.
Suggested Plan of Action:
Consult with an expert electrical engineer to ensure the lightning protection ground terminals are bonded to the building or structure grounding.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.11 Lightning Protection
Question:
The air termination network vertical and horizontal conductors are appropriately spaced.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
The air termination network vertical and horizontal conductors are appropriately spaced, but “as-built” electrical drawing (SLD) for the lightning protection system was not available for review. The adequacy and functionality of the system could not be verified/checked. Location: Roof Floor, Main Building.
Source of Findings:
Worker Interviews: Factory personnel said that the air termination networks are appropriately spaced but no drawing was found to review and this information.
Suggested Plan of Action:
Consult with an expert electrical engineer and ensure your system is secured against lightning.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.11 Lightning Protection
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 17/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 18/18
Factory Name:
4 YOU CLOTHING LTD
Address: Assessor:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh Bureau Veritas
Date:
27 May 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 1/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Introduction to the Report The following report contains a site profile and summary of non-conformities identified during an onsite assessment commissioned by the Alliance for Bangladesh Worker Safety (Alliance) and conducted by a third-party Qualified Assessment Firm (QAF). The assessment was conducted against the Alliance for Bangladesh Worker Safety Assessment Protocols (APs) and Fire Safety and Structural Integrity Standard, which is harmonized with the factory assessment guidelines developed by Bangladesh University of Engineering and Technology (BUET) for the Bangladesh National Tripartite Plan of Action (NTPA). The goal of the Alliance process is to provide clear and practical technical requirements by which Bangladeshi Ready Made Garment (RMG) Factories producing for Alliance may be consistently and fairly evaluated for fire, structural, and electrical safety in a non-duplicative manner. Each assessment will prompt action plans that will be used by RMG factories to systematically and sustainably improve safety conditions for garment workers. Beyond tracking and reporting on action steps taken in a transparent manner, the Alliance organization and its will seek to further factory improvements through technical assistance, training, implementation for functional Worker Committees, and in some cases financial assistance and wage for workers if factories are closed for remediation. The contents of the report do not constitute a guarantee of compliance with the applicable laws, the Alliance Standard or the absolute or continued safety against fire, electrical and/or structural integrity issues that may lead to injury or loss of life. The report is designed to provide a non-exhaustive summary of risk issues, based on a limited sampling and duration of time onsite by the named QAF. Neither the QAF nor the Alliance can certify or guarantee the quality, outcome, or effectiveness of actions taken in response to the report. For more information and report please go to: www.bangladeshworkersafety.org.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 2/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
GENERAL INFORMATION General Information Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Country:
Bangladesh
Province:
Dhaka
City:
Dhaka
Zip Code:
1216
Audit Duration:
1 Days
Re-Audit:
Re-Audit After 0 Months
Draft Report Date :
05-28-2014
Final Report Date :
06-23-2014
Are all action items from previous assessment complete? :
N/A
Buildings in Complex :
There is one building on the factory premises. The building is named as: 1) Ten story RCC Main Production Building.
Is the building(s) owned or rented by the Factory?:
Owned
Number of Building Levels (Stories) :
1) Ten story RCC Main Production Building: Building height (Highest occupied floor level): 28.05 m or 92.00 ft [Height up to roof: 31.10 m or 102.00 ft], Stories above grade: 10, Stories below grade: 0, Occupied levels: 10.
Approximate Building Area (SF) :
Total area: 78342.5 SF. 1) Ten story RCC main production building: 78342.5 SF (Ground floor: 7834.25 SF, 1st floor: 7834.25 SF, 2nd floor: 7834.25 SF, 3rd floor: 7834.25 SF, 4th floor: 7834.25 SF, 5th floor: 7834.25 SF, 6th floor: 7834.25 SF, 7th floor: 7834.25 SF, 8th floor: 7834.25 SF, 9th floor: 7834.25 SF).
Date of Building Construction :
Factory personnel informed the date of construction as follows: 1) Ten story RCC Main Production Building: Started in December-1995 but no record of a finish date.
Date of Last Building Renovation/Addition :
Factory personnel informed the date of last building renovation as follows: 1) Ten story RCC Main Production Building: Renovation work is on going.
Ancillary Structures in Complex :
There is no ancillary structure on factory premises.
Approximate Ancillary Structures Area (SF) :
There is no ancillary structure on factory premises.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 3/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Number of Occupants :
Total number of occupants: 1640. 1) Ten story RCC Main Production Building: 1640 (Ground floor: 60, 1st floor: 210, 2nd floor: 212, 3rd floor: 230, 4th floor: 80, 5th floor: 235, 6th floor: 90, 7th floor: 218, 8th floor: 225, 9th floor: 80).
Provide brief description of the electrical system for each building.:
Source: DESCO: Transformer-1 (1000 KVA), Generator-3, (650 KVA, 110 KVA, 200 KVA), Change Over Switch(COS)-4, Low Tension (LT) -1, Main Distribution Board (MDB)-2, Distribution Board (DB)-10, Sub Distribution Board (SDB)-5.
Physical location of Substation? :
Substation located in Ground Floor of the building.
What equipment/loads does the UPS serve? :
IPS serves fire alarm, emergency lighting and exit signage.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 4/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
ASSESSMENT FINDINGS Electrical System Information Question:
Are as-built electrical drawings indicating information such as and circuit locations throughout the building(s) available for review?
Priority Level:
High
Non-Compliance Level:
3
Description:
There are no proper working or “as-built” electrical diagrams of the main distribution circuit or floor level circuits connecting electrical loads (machines/lights/cooling system, etc.) available on site.
Source of Findings:
Document Review: No as-built electrical drawings.
Suggested Plan of Action:
Have a qualified electrical engineer develop an as-built single line diagram detailing key components and capacity of the electrical system.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.7
Electrical System Maintenance Question:
Is the electrical switchgear and boards inspected on an annual basis to ensure that the equipment is installed in accordance with the listed ratings?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The electrical switchgear and boards are not inspected on an annual basis.
Source of Findings:
Document Review: No annual inspection record for electrical switchgear and boards.
Suggested Plan of Action:
Inspect electrical switchgear and boards on an annual basis to ensure that the equipment is in good working condition.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.13.8 Electrical Inspections
Question:
Are thermographic scans of electrical equipment completed at least every three years?
Priority Level:
Medium
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 5/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Non-Compliance Level:
3
Description:
Thermographic scans of electrical equipment are not properly completed.
Source of Findings:
Document Review: No thermographic scans for electrical equipment.
Suggested Plan of Action:
Complete thermographic scans at least on a three year cycle. Thermographic scans should be completed in accordance with the Standard for Infrared Inspection of Electrical Systems & Rotating Equipment and NFPA 70B or a comparable standard.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.13.8 Electrical Inspections
Question:
Transformers do not contain harmful substances such as PCBs.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
No testing results found to ensure that transformers do not contain harmful substances.
Source of Findings:
Document Review: No testing results found to ensure that transformers do not contain harmful substances.
Suggested Plan of Action:
Consult with your transformer manufacturing company, and ensure transformers do not contain any harmful substances by having tests run and reviewing the results.
Suggested Deadline Date:
23 Jul 2014
Standard:
Not Applicable
Question:
A transformer oil analysis is routinely completed on main service transformers.
Priority Level:
Low
Non-Compliance Level:
3
Description:
No documentation on transformer oil analysis was found.
Source of Findings:
Document Review: A transformer oil analysis report was not found.
Suggested Plan of Action:
Complete an oil analysis on applicable transformers at appropriate intervals based on voltage and power.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.13.8 Electrical Inspections
Electrical System Conditions
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 6/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Underground service cables are laid in conformity with the requirements of concealed wiring.
Priority Level:
High
Non-Compliance Level:
3
Description:
Underground service cables are not laid in conformity with the requirements for concealed wiring. Location: Substation Room, Ground Floor.
Source of Findings:
Photograph: Improper wiring of underground service cables.
Suggested Plan of Action:
Ensure underground cables for electrical distribution on the premises/garden/compound of the building are encased in GI or PVC pipes and laid in earth trenches of sufficient depth as per BNBC 2.5.7.2.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.10 Service Entry
Question:
The substation room has the required fire rating/protection and is physically separated from the remainder of the building.
Priority Level:
High
Non-Compliance Level:
3
Description:
The substation room does not have fire rating protection and is not physically separated from the remainder of the building.
Source of Findings:
Photograph: Substation room does not have fire rating protection and is not physically separated.
Suggested Plan of Action:
Provide adequate fire rating protection for substation room, and make it separate from rest of the building.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 3 Section 3.4.2.1.4
Question:
No circuits are drawn for loads without the incorporation of a overcurrent protection device (circuit breaker).
Priority Level:
High
Non-Compliance Level:
3
Description:
Circuits are drawn for loads without the incorporation of an overcurrent protection device (circuit breaker). Location: DB-1/8th Floor, DB-1/3rd Floor, DB-1/1st Floor, DB-1/2nd Floor, DB-1/6th Floor, DB-1/4th Floor, DB-1/5th Floor, DB-1/7th Floor, DB-1/9th Floor, SDB-2/Ground Floor, SDB-4/Hydrant Room.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 7/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Source of Findings:
Photograph: No protection device.
Suggested Plan of Action:
Ensure overcurrent protection device (circuit breaker) for each and every load.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.9 Protection of Circuits
Question:
All metal in the building is connected to the building earthing/grounding system such as metal rebar in concrete, metal frame of building, or metal water pipe.
Priority Level:
High
Non-Compliance Level:
3
Description:
There is metal in the building that is not connected to the building earthing system. Location: Water pipe (GI), cable ladder throughout the building.
Source of Findings:
Visual Assessment: Not all metal in the building is connected to the building earthing.
Suggested Plan of Action:
Connect all metal in the building to the building earthing/grounding system, such as metal rebar in concrete, metal frame of building, or metal water pipe.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.10 Earthing
Question:
Shielding or additional insulation is provided for wiring exposed to external heat sources.
Priority Level:
High
Non-Compliance Level:
2
Description:
Additional insulation is not provided for wiring that is exposed to external heat sources. Location: Boiler Room, Ground Floor.
Source of Findings:
Photograph: Inadequate insulation for the wiring.
Suggested Plan of Action:
Provide shielding and/or additional insulation for wiring exposed to external heat sources.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.4.2 External heat sources.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 8/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Do switchboards and/or distribution boards have a minimum clearance of 1 m (39 in) in front?
Priority Level:
High
Non-Compliance Level:
1
Description:
Distribution boards do not have adequate clearance. Location: DB-1/6th Floor, DB -1/8th Floor, DB -1/9th Floor.
Source of Findings:
Photograph: Inadequate clearance in front of distribution boards.
Suggested Plan of Action:
Provide clearance of at least 1m (39in.) in front of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standards Part 10 Section 10.7 Main Switch, Switchboards and Metal Clad Switchgear
Question:
Power and telecommunication or antenna cables are led in separately.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Power cables and telecommunication or antenna cables are not led in separately. Location: All cable trays where power cables and telecommunication or antenna cables are routed together.
Source of Findings:
Photograph: Power and telecommunication cables are not separated.
Suggested Plan of Action:
Lead telecommunication or antenna cables separately to the main point of service. Power and telecommunication cables must have a separate entrance.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.10 Service Entry
Question:
Do switchboards and/or distribution boards have capacity information labels?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
No capacity information labels are provided for any of the distribution boards. Location: All distribution boards.
Source of Findings:
Photograph: No capacity information labels provided on distribution boards.
Suggested Plan of Action:
Provide capacity information labels (maximum current rating, number of circuit breakers, etc.) for switchboards and/or distribution boards.
Suggested Deadline
09 Jul 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 9/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Date: Standard:
Alliance Standard Part 10 Section 10.7 Main Switch, Switchboards And Metal Clad Switchgear and 10.13.7 Inspection of the Installation
Question:
Are switchboards and/or distribution boards provided with physical means to prevent the installation of more over current devices than that number for which the board was designed, rated, and listed.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Distribution boards are not provided with a physical means to prevent the installation of more over current devices than that number for which the board was designed, rated and listed. Location: All distribution boards.
Source of Findings:
Photograph: No means to prevent the installation of more over current devices.
Suggested Plan of Action:
Ensure distribution boards are provided with a physical means to prevent the installation of more over current devices than that number for which the board was designed, rated, and listed following NFPA 70 Section 408.54.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.7 Main Switch, Switchboards and Metal Clad Switchgear
Question:
Cable ts are through porcelain/PVC connectors with PIB tape wound around t.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Improper cable ts. Location: All distribution boards.
Source of Findings:
Photograph: Improper cable ts.
Suggested Plan of Action:
Ensure cable ts are through porcelain/PVC connectors with PIB tape wound around the ts.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.8.4 Cable ts
Question:
The substation room has adequate illumination levels.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
The substation room has inadequate illumination levels.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 10/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Source of Findings:
Photograph: Improper illumination in transformer room.
Suggested Plan of Action:
Provide additional light fixtures to increase illumination levels as provided for in the BNBC.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.13.7.1 Inspection of Substation Installations.
Question:
Are all internal components of switchboards and/or distribution boards properly concealed (No missing circuit breaker or knockout covers)?
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Internal components of distribution boards are not properly concealed. Location: DB-1/8th Floor, MDB-2/Substation room, LT /Substation room, DB-1/1st Floor, DB-1/2nd Floor, DB-1/6th Floor.
Source of Findings:
Photograph: Internal components are not properly concealed.
Suggested Plan of Action:
Provide covers or blanks to conceal all live internal components of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.3.9 Sub-Distribution Boards
Question:
Stranded conductors having a nominal cross-sectional area 6mm2 or greater are provided with cable sockets. Conductors below 6 mm2 without cable sockets, all strands at the exposed ends are soldered together or are crimped using suitable sleeve or ferrules.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Cable sockets are not provided for stranded conductors. Location: All distribution boards (except LT and all MDBs).
Source of Findings:
Photograph: No cable sockets.
Suggested Plan of Action:
Provide cable sockets for stranded conductors with a nominal cross-sectional area of 6 mm2 or greater and conductors below 6 mm2 without cable sockets, all strands at the exposed ends are to be soldered together or are crimped using suitable sleeve or ferrules.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.8.3 Cable Ends
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 11/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Is all electrical wiring/cable properly terminated at its point of termination (No un-terminated wires, lugs are provided at terminals, etc)?
Priority Level:
Medium
Non-Compliance Level:
2
Description:
Electrical cables are not properly terminated. Location: DB-1/4th Floor, DB-1Finishing/6th Floor, Sewing Machine/7th Floor, Sewing Machine/8th Floor.
Source of Findings:
Photograph: Un-terminated wires.
Suggested Plan of Action:
Ensure all electrical wiring/cables are properly terminated at their point of termination.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.3.9.2 Wiring of Sub-distribution Boards
Question:
Are lighting and receptacle (socket) circuits segregated?
Priority Level:
Medium
Non-Compliance Level:
1
Description:
Lighting and sockets are not separated. Location: Technical Room/7th Floor.
Source of Findings:
Photograph: Lighting and sockets are not separated.
Suggested Plan of Action:
Separate lighting and socket circuits at the noted locations. Have a qualified electrician separate the lighting and sockets into separate circuits.
Suggested Deadline Date:
23 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.7.2
Question:
A wire/cable shaft is provided for the whole building. Wiring and cables are arranged in shaft for ease of inspection and maintenance.
Priority Level:
Medium
Non-Compliance Level:
1
Description:
A shaft for BBT system is available in the floor but a shaft for cable is not provided for the whole building.
Source of Findings:
Photograph: Cable shaft is not found.
Suggested Plan of Action:
Provide cable shaft for the whole building for ease of inspection and maintenance.
Suggested Deadline Date:
15 Sep 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 12/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Standard:
BNBC Part 8 Section 2.5.6.1
Question:
Electrical wiring and conduit is properly ed.
Priority Level:
Medium
Non-Compliance Level:
1
Description:
Electrical wiring and conduit are not properly ed. Location: Substation Room.
Source of Findings:
Photograph: Inadequate cable .
Suggested Plan of Action:
Provide adequate s for electrical wiring and conduit.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.2, 10.3.4.3, and 10.3.5
Question:
Signage indicating the prohibition of light fixtures without protective covers is installed at required locations.
Priority Level:
Low
Non-Compliance Level:
3
Description:
No signs to indicate the prohibition of light fixtures without protective covers are installed at the required locations. Location: Storage Area/Ground Floor.
Source of Findings:
Photograph: No signage indicating the prohibition of the installation of light fixtures without protective covers.
Suggested Plan of Action:
Ensure signage indicating the prohibition of light fixtures without protective covers is installed at required the locations.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standards Part 10 Section 10.15 Naked Lights
Question:
Required equipment and safety signage is posted within the room.
Priority Level:
Low
Non-Compliance Level:
2
Description:
Some equipment has required equipment signage but there is no safety signage in the substation room.
Source of Findings:
Photograph: No safety signage was found.
Suggested Plan of Action:
Required safety equipment and safety signage must be posted within the room.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 13/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.3.7, Section 10.7.3, and 10.13.7, NFPA 70 Chapter 1 Article 110.21, and Bangladesh Electricity Rules of 1937 Rule 46
Question:
Are electrical insulation mats provided in front of substation, switchboards and/or distribution boards?
Priority Level:
Low
Non-Compliance Level:
1
Description:
Electrical insulation mats are not provided in front of distribution boards. Location: DB-1 (4th Floor), SDB-2 (4th Floor), SDB -3 (6th Floor).
Source of Findings:
Photograph: No electrical graded insulation mats provided in front of distribution boards.
Suggested Plan of Action:
Provide electrical graded insulation mats in front of distribution boards.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.13.7 Inspection of the Installation.
Question:
Phase separators are provided between terminals on circuit breakers.
Priority Level:
Low
Non-Compliance Level:
1
Description:
Phase separators are not provided between terminals on circuit breakers. Location: DB-1-Finishing/6th Floor, DB-1/7th Floor, DB-1/8th Floor.
Source of Findings:
Photograph: No phase separators.
Suggested Plan of Action:
Install phase separators between terminal connections at the noted locations.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standard Part 10 Section 10.3.1 Electrical Connections
Emergency Power System Question:
Is the generator room properly rated and physically separated from the remainder of the building?
Priority Level:
High
Non-Compliance Level:
3
Description:
Generator room is not properly rated and is not physically separated from the
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 14/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
remainder of the building. Source of Findings:
Photograph: Generator room is not rated and separated.
Suggested Plan of Action:
Ensure the generator room is properly rated and physically separated from the remainder of the building.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.8.4 Generator Room
Question:
Are emergency power switchboards, distribution boards, and circuits properly identified?
Priority Level:
High
Non-Compliance Level:
3
Description:
Emergency power distribution boards and circuits are not properly identified.
Source of Findings:
Visual Assessment: No identification of emergency DBs/CKTs.
Suggested Plan of Action:
Ensure proper identification of emergency power switchboards, distribution boards, and circuits.
Suggested Deadline Date:
25 Jun 2014
Standard:
NFPA 70 Chapter 7 Article 700.10 Wiring, Emergency System
Question:
Are cable trenches properly covered?
Priority Level:
High
Non-Compliance Level:
2
Description:
Cable trenches are not covered properly. Location: Generator Room, Ground Floor.
Source of Findings:
Photograph: There is no cable trench cover.
Suggested Plan of Action:
Provide a cover for cable trenches.
Suggested Deadline Date:
25 Jun 2014
Standard:
Alliance Standard Part 10 Section 10.13.7 Inspection of the Installation
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 15/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Question:
Is the generator frame earthing (grounding) provided at two separate points?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
Generator frame earthing is only provided at single point.
Source of Findings:
Photograph: Inadequate generator frame earthing.
Suggested Plan of Action:
Provide two separate points earthing (grounding) for each generator.
Suggested Deadline Date:
21 Jul 2014
Standard:
Alliance Standard 10.8.2.2
Question:
Is the generator room appropriately sized in order to properly access the generator to perform routine maintenance activities?
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The size of generator room is not appropriate.
Source of Findings:
Photograph: Inadequate generator room size.
Suggested Plan of Action:
Ensure that the generator room is appropriately sized in order to gain proper access to the generator to perform routine maintenance activities.
Suggested Deadline Date:
20 Aug 2014
Standard:
Alliance Standard Part 10 Section 10.8.4 Generator Room
Question:
Are inspection, maintenance, and testing procedures of the UPS being completed and documented?
Priority Level:
Low
Non-Compliance Level:
1
Description:
Inspection, maintenance and testing procedures of the IPS are performed by the supplier but documentation is not complete.
Source of Findings:
Photograph: Improper documentation found for IPS mantenance.
Suggested Plan of Action:
Establish an inspection testing and maintenance program for the Uninterruptible Power Supply (UPS) and/or Instant Power Supply (IPS) associated components. The program must be based on the following: (1) Manufacturer's recommendations (2) Manufacturer's instruction manuals (3) Minimum Requirements of NFPA 111 Chapter 8 (4) Minimum Requirements of NFPA 70B Chapter 28.
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 16/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Suggested Deadline Date:
18 Aug 2014
Standard:
Alliance Standard Part 13 Section 13.11 NFPA 111 Chapter 8 NFPA 70B Chapter 28
Lightning Protection System Question:
The lightning protection ground terminals are bonded to the building or structure grounding.
Priority Level:
Medium
Non-Compliance Level:
3
Description:
The lightning protection ground terminals are not bonded to the building or structure grounding.
Source of Findings:
Visual Assessment: The lightning protection ground terminals are not bonded to the building or structure grounding.
Suggested Plan of Action:
Consult with an expert electrical engineer to ensure the lightning protection ground terminals are bonded to the building or structure grounding.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.11 Lightning Protection
Question:
The air termination network vertical and horizontal conductors are appropriately spaced.
Priority Level:
Medium
Non-Compliance Level:
2
Description:
The air termination network vertical and horizontal conductors are appropriately spaced, but “as-built” electrical drawing (SLD) for the lightning protection system was not available for review. The adequacy and functionality of the system could not be verified/checked. Location: Roof Floor, Main Building.
Source of Findings:
Worker Interviews: Factory personnel said that the air termination networks are appropriately spaced but no drawing was found to review and this information.
Suggested Plan of Action:
Consult with an expert electrical engineer and ensure your system is secured against lightning.
Suggested Deadline Date:
09 Jul 2014
Standard:
Alliance Standards Part 10 Section 10.11 Lightning Protection
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 17/18
Factory Name:
4 YOU CLOTHING LTD
Address:
367/1 SENPARA PARBATA, MIRPUR-10, Dhaka Dhaka Dhaka Bangladesh
Assessor:
Bureau Veritas
Date:
27 May 2014
Created with EO.Pdf for .NET trial version. http://www.essentialobjects.com. The Alliance for Bangladesh Worker Safety
Page 18/18
Related Documents c2h70
4 You Clothing Ltd_electrical t64o
December 2019 15
Computer Clothing 5h2939
December 2019 54
Clothing Technology u4v1e
April 2020 30
Clothing Wordsearchhard 2b1m3j
December 2019 40
Clothing Allowance 6a2k1v
January 2022 0
Clothing Imagery 543j4g
November 2019 50More Documents from "ShafiqulHasan" 3c5r31
4 You Clothing Ltd_electrical t64o
December 2019 15
Internship Report On Bb 454k4g
December 2019 44
Factory Compliance Requirement 3037e
November 2019 30
